Modular Media Converter Center System
KC-1300
Operation Manual

-2-
(C)2005KTINetworksInc.Allrightsreserved.Nopartofthisdocumen-
tation may be reproduced in any form or by any means or used to make
any directive work (such as translation or transformation) without per-
missionfromKTINetworksInc.
KTI Networks Inc. reserves the right to revise this documentation and to
make changes in content from time to time without obligation on the part
of KTI Networks Inc. to provide notification of such revision or change.
For more information, contact:
UnitedStates KTINetworksInc.
P.O.BOX631008
Houston,Texas77263-1008
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
URL: http://www.ktinet.com/
International Fax: [phone]
E-mail: [email protected]
URL: http://www.ktinet.com.tw/

-3-
The information contained in this document is subject to change without prior
notice. Copyright (C) KTI. All Rights Reserved.
TRADEMARKS
Ethernet is a registered trademark of Xerox Corp.
WARNING:
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and if not installed and used in accordance
with the instruction manual may cause harmful interference in which case the
user will be required to correct the interference at his own expense.
NOTICE:
(1) The changes or modifications not expressively approved by the party re-
sponsible for compliance could void the user's authority to operate the equip-
ment.
(2) Shielded interface cables and AC power cord, if any, must be used in order
to comply with the emission limits.
CISPR A COMPLIANCE:
This device complies with EMC directive of the European Community and meets
or exceeds the following technical standard.
EN 55022 - Limits and Methods of Measurement of Radio Interference Character-
istics of Information Technology Equipment. This device complies with CISPR
Class A.
WARNING:Thisis a ClassA product. Inadomestic environmentthis productmay
cause radio interference in which case the user may be required to take ad-
equate measures.
CE NOTICE
Markingby thesymbol indicatescompliance ofthis equipment tothe EMC
directive of the European Community. Such marking is indicative that this equip-
ment meets or exceeds the following technical standards:
EN 55022: Limits and Methods of Measurement of Radio Interference character-
istics of Information Technology Equipment.
EN 50082/1:Generic Immunity Standard -Part 1: Domestic Commercial and Light
Industry.
EN 60555-2: Disturbances in supply systems caused by household appliances
and similar electrical equipment - Part 2: Harmonics.

-4-
Table of Contents
1. Introduction.........................................................6
1.1 Features ........................................................................................ 7
1.2 Technical Specifications ............................................................... 8
2. Installation.........................................................12
2.1 Unpacking .................................................................................... 12
2.2 System Units ............................................................................... 12
2.2.2 Management Module................................................................ 14
2.2.3 Power Chassis Modules .......................................................... 16
2.3 Rack Mounting ............................................................................. 22
3. Network Management .......................................23
3.1 Management Functions............................................................... 23
3.2 Protocols Supported ................................................................... 24
3.3 Setup for Out-of-band (Console) Management........................... 25
3.4 Setup for In-band Management ................................................... 27
4. Console and Telnet Operation .........................28
4.1 IP Menu ........................................................................................ 32
4.2 SNMP Menu ................................................................................. 33
4.3 View System Status..................................................................... 34
4.4 View Converter Slots Status........................................................ 35
4.5 Restore Default Values................................................................ 37
4.6 Security Manager ......................................................................... 38
4.7 Update Firmware......................................................................... 39
4.8 Reboot System ............................................................................ 40
5. SNMP Management ..........................................41
5.1 Configuring SNMP Settings via Console Operation ................... 42
5.2SNMPPrivate MIB ........................................................................ 43
5.3 SNMP Traps................................................................................. 44
6. Web Management .............................................45
6.1 Start Browser Software and Making Connection......................... 45
6.2 Login to the System Unit ............................................................. 46
6.3 Converter Status.......................................................................... 48
6.4 System Status ............................................................................. 50
6.5 Administrator Menu...................................................................... 51

-5-
6.5.1 Basic ......................................................................................... 52
6.5.2 Console Port Information ......................................................... 57
6.5.3 Security Manager ...................................................................... 58
6.5.4 Image Refresh Time ................................................................ 59
6.5.5 Update Firmware...................................................................... 60
6.5.6 Reboot System ......................................................................... 61
6.6 Slot Icon Operations.................................................................... 62

-6-
1. Introduction
TheModularConverterSystemKC-1300isamanaged mediaconverterrackthat
provides16slotsand hosts 16 units ofMediaConverter(MC).A wide range of
media converters are available depending on your variety of network cabling
environment.TheseoptionalmediaconvertersincludeGigabitandFastEthernet
coppertomultimodeorsinglemodefibercable.
The rack unit provides a centered power supply to the converter mod-
ules and serves as a converter center and wiring concentrator.
Forspecifications ofmediaconverter KC-300D,KC-300DM,KGC-300
and KGC-310, refer to the associated installation guides respectively.

-7-
1.1 Features
Some of the key features include:
• Managed Media Converter Center Rack
• 19-inch rack-mountable 2U chassis
• Managed system accommodates up to 16 media converters
• Highly modularized chassis design with
- modular media converters
-modularmanagementmodule
- two system power modules for power redundancy
• Provides high availability and maintainability
• Power backup feature with two power chassis
• Visible system status indication
• Supports in-band Telnet, SNMP and web-based management
• Supports out-of-band direct console management
• Management from anywhere and any platform using a web browser
• Easy-to-use point and click user interface
• Photographic quality interface to configure and monitor the system
• Supports in-band event SNMP trap report
• Photographic quality interface to configure and monitor the system
• TFTP Software Upgrade

-8-
1.2 Technical Specifications
System Model KC-1300L/1A KC-1300L/2A KC-1300/1A KC-1300/2A
Management support Unmanaged Unmanaged Managed Managed
Plug-in power modules 1 AC 2 AC 1 AC 2 AC
Input voltage 90~264V 90~264V 90~264V 90~264V
Power supply rating 60W 60W 60W 60W
Weight (no MC installed) 5.5Kg 6.2Kg 5.5Kg 6.2Kg
System Model KC-1300L/1D KC-1300L/2D KC-1300/1D KC-1300/2D
Management support Unmanaged Unmanaged Managed Managed
Plug-in power modules 1 DC 2 DC 1 DC 2 DC
Input voltage -48VDC -48VDC -48VDC -48VDC
Power supply rating 60W 60W 60W 60W
Weight (no MC installed) 5.5Kg 6.2Kg 5.5Kg 6.2Kg
Common Specifications
19-inch rack mount Yes
Number of MC slots 16 slots
Number of power slots 2
Cooling 1 DC Fan
Dimension H 88mm (2U) x W 443mm x D 328mm
Environmental
Operating temperature -5~40oC
Storage temperature -20~75oC
Operating humidity 10~90%RH
Emission standard
Conducted emission EN55022, CISPR 22
Radiated emission EN55022, CISPR 22
Voltage harmonics EN61000-3-2
Voltage fluctuation & flicker EN61000-3-3
Susceptibility
Electrostatic discharge immunity EN61000-4-2, IEC61000-4-2
Radiated immunity EN61000-4-3, IEC61000-4-3
EFT/Burst immunity EN61000-4-4, IEC61000-4-4
Surge immunity EN61000-4-5, IEC61000-4-5
Continuous wave voltage immunity EN61000-4-6, IEC61000-4-6
PFMF immunity EN61000-4-8, IEC61000-4-8
Voltage DIP/Interrupt immunity EN61000-4-11, IEC61000-4-11
Certifications
FCC Part 15, Class A
CE EMC Class A, EN50081-1,EN50082-1

-9-
AC Power Chassis Module Specifications
Dimension 194mm x 156.6mm x 40.3mm
Installation method Plug in from system rear panel
Maintenance Modular design for easy maintenance
AC power switch System power on/off switch
AC power receptacle IEC320 type receptacle
Power status indicator Green LED
Electric
Input voltage rating 100 ~ 240VAC
Input voltage range 90 ~ 264VAC
Input frequency 47 ~ 63Hz
Input surge current 20A max. @115VAC
Efficiency 75% @115VAC full load
Output power 60W
Over current protection All output with short circuit protection
Safety UL/cUL, TUV EN60950
Insulation Resistance >10M Ohm @DC500V
Dielectric withstands 1500VAC 10mA 1min.
DC Power Chassis Module Specifications
Dimension 194mm x 156.6mm x 40.3mm
Installation method Plug in from system rear panel
Maintenance Modular design for easy maintenance
DC power switch System power on/off switch
DC power receptacle Screw type terminal block
Power status indicator Green LED
Electric
Input voltage rating -48VDC
Input voltage range -48VDC +/-10%
Efficiency 73% typ. at full load
Output power 60W
Protection Over voltage, over power, short circuit
Safety Meet UL1950

-10-
Management Module Specifications
Dimension 107mm x 24mm x 86.4mm
Slot position Slot 0
CPU RISC-based ARM7
RAM size 2M bytes
Flash size 512K bytes
System interface
Connector FutureBus
Console interface
Interface RS-232 DTE
Connector 9-pin male D-SUB connector
Baud rate 38400, N, 8, 1, 0
Flow control Disabled
In-band interface
Interface 10/100M LAN port
Connector Shielded RJ-45 MDI
Standard IEEE 802.3 10BASE-T/100BASE-TX
Auto-negotiation Support
LED Indicators
P1, P2 Green LED, power module status
DIAG Green LED, CPU initialization
FAN Green LED, Fan failure indication
CONSOLE Green LED, Console RS-232 Rx activities
LNK/ACT. Green LED, LAN port link and activities status

-11-
Management Specifications
Management interface
Telnet Via direct RS-232 console connection
Telnet Via TCP/IP Telnet software
SNMP agent Via TCP/IP SNMP manager software
HTTP server Via web browser software
Protocols
IPv4 IP version4 RFC791
TCP Transmission Control Protocol RFC793
UDP User Datagram Protocol RFC768
ICMP Internet Control Message Protocol RFC792
SNMP SNMP agent v1 RFC1157
MIB-II Standard MIB RFC1213
TFTP Trivial File Transfer Protocol RFC1350
TELNET Telnet protocol RFC854
HTTP HTTP server for web management RFC1945
Management Objects
Password for access control Set and monitor
System status : CPU, memory, flash, software Monitor
System power 1&2 status Monitor
System fan status Monitor
IP address of the system Set and monitor
Subnet mask of the system Set and monitor
Default gateway IP address Set and monitor
SNMP name information Set and monitor
SNMP location information Set and monitor
SNMP contact information Set and monitor
SNMP community names (up to 4) Set and monitor
SNMP community access right (up to 4) Set and monitor
SNMP trap host IP address (up to 3) Set and monitor
Slot status : MC installed or not Monitor
MC status : media type, speed, duplex Monitor
MC link status of two ports Monitor
Remote MC link status (two KC-300DMs link only) Monitor
SNMP Traps
Cold Start System is powered on and completes initialization
Authentication failure SNMP community authentication failure
Power status The system power 1&2 failure and recovery
Fan failure System fan failure and recovery
Slot # Port A link Slot # MC Port A link down or up
Slot # Port B link Slot # MC Port B link down or up
Slot # RTP link Slot # Remote MC TP port link change
Update Firmware Via TFTP protocol
Remote boot system

-12-
2. Installation
2.1 Unpacking
The product package contains:
•The system unit
•One power cord
•One 19-inch rack mounting kit
•Operation Manual
2.2 System Units
The figure below illustrates the front view of the KC-1300 system:
Depending on the model purchased, the type and numbers of the pre-
installed media converters may be different. The figure shows a system
which is fully installed with media converters.
The following figures show the rear view of the KC-1300 system. The
main chassis provides two power chassis slots on the rear panel. Each
power chassis slot can be installed with one AC power chassis. Two
power slots design features the system a power redundant function.

-13-
The following figure shows the model equipped with two AC power chassis.
MainChassis :provides insertion slots on front panel for CPU manage-
ment module and optional add-on media converters. It also provides two
chassis slots on rear for mounting power chassis modules.
ManagementModule:serves as a management agent tomonitorsystem
status and add-on converter modules for in-band and out-of-band man-
agement requests.
Power Chassis : provides full centered power supply for whole system
unit. It can receive commercial AC power with AC power chassis and -
48VDCpowerwithDCpowerchassis.
System Cooling Fan : provides forced air to cool down the temperature
for the system unit.

-14-
2.2.2 Management Module
The system unit comes with one pre-installed Management module. The
module facilitates the following functions:
•Direct out-of-band management via RS-232 console port
•SNMP agent to serve in-band management via SNMP protocol
•Telnet console in-band management via TCP/IP protocol
•HTTP host to serve web-based in-band management
•Monitoring all MCs status installed in the system
•Monitoring system power and fan status
See figure below for major components on the panel:

-15-
ConsolePort
This port is a 9-pin maleD-sub connector. It serves as an RS-232DTE port.
Refer to Chapter xx for the console operation. The pin definitions are:
Pin2 RXD
Pin 3 TXD
Pin 4 DTR
Pin 5 GND
Pin 6 DSR
UTPPort
This is an auto-negotiation 10/100BASE-TX LAN port and provides a
shielded RJ-45 jack with MDI definition. This port must connect to your
TCP/IP network for all in-band management operations.
LEDIndicators Color States Interpretation
P1 Green On Power1moduleisON
P2 Green On Power2moduleisON
DIAG Green On CPUinitialization
Off Initializationcomplete
FAN Green On Fan failure detected
Off Fan in normal operation
CONSOLE Green On Rx activities of console port
LNK/ACT Green On LAN port link is active
Green Blink Tx/RxactivitiesofUTPport

-16-
2.2.3 Power Chassis Modules
The system power supply is assembled in a plug-in chassis module as
shown below:
Each single power module is capable to supply full power for system
operation with media converters fully installed.
ACPowerChassisSpecifications(KC1300-AC)
AC power switch System power on/off switch
AC power receptacle IEC320 type receptacle
Input voltage range 90~264VAC
Input frequency 47~63Hz
Output power 60W
AC power cord IEC320typepowercord
Power status display GreenLED

-17-
DCPowerChassisSpecifications(KC1300-DC)
Input power switch System power on/off switch
Input power receptacle Terminal connector (screw type)
Input voltage rating -48VDC
Input voltage range -48VDC+/-10%
Output power 60W
Power status display GreenLED

-18-
RemovalofSystemPowerChassis
The system power chassis is pre-installed in the system unit when sys-
tem unit is shipped from factory. The chassis is designed for easy un-
installation from system unit in case of any inspection purpose. How-
ever, note that this removal only can be performed by a well-trained
technical person.
For safety reason before removing the power chassis, make sure:
•The power switch is turned off.
•The power cord is disconnected from the power chassis.
To remove the chassis, unscrew two chassis screws until they are re-
leased from system chassis, hold the handle and pull the chassis out
from the system chassis smoothly. See the following example figure:

-19-
InsertionofSystemPowerChassis
Before inserting the power chassis into system unit, make sure:
•The system power switch is turned off.
•The power cord is disconnected from the power chassis.
To insert the power chassis, hold the handle and push it into system unit
until it is seated in system chassis properly. Screw the chassis securely in
the system unit. See figure below:
The power chassis is designed to be hot plugged into or unplugged
from the system even when another power chassis is installed in
another power slot and in operation.

-20-
2.2.4MediaConverterSlots
The system chassis provides sixteen slots for installing optional slide-in
MCs.
A media converter can be inserted into an available slot or removed from
a slot anytime even when system unit is powered on. This hot-plug
design keeps all exiting connections on the other slots running with no
influence.
To insert an MC into a slot, the steps are:
1. Install a bracket, which is provided in the rack chassis package onto
the MC unit as shown below:
2. Remove slot cover first and insert the MC into slot slowly until it is
seated in slot properly.
3. Screw the bracket onto system chassis securely before making any
cable connection.
