INSTRUCTION MANUAL
AUTO CHARGE 11 PIM
AUTOMATIC BATTERY CHARGER
MODEL #091-11PIM
TEL: in NY 631-567-0314 TOLL FREE: 800-346-0857 FAX: [phone]
3 YEAR WARRANTY
NOTE :
This charger is designed for
vehicles with dual batteries
and negative ground.
INPUT :120 volts, 50/60 Hz, 2.5 amp max
KUSSMAUL ELECTRONICS CO., INC.
170 CHERRY AVE., WEST SAYVILLE, N.Y. 11796
BOOK# 091-11PIM
February 5,2003

INTRODUCTION
The Auto Charge 11PIM Battery Charger is a compact completely automatic charger
designed for installation on vehicles with two batteries. An internal charge divider charges
both batteries simultaneously while maintaining battery isolation. Remote sensing permits
longlinesbetweenthechargerandthebatteriesbycompensatingforthevoltagedropinthe
charging wires. An ammeter provides continuous indication of the charger output.
Construction of the Auto Charge 11PIM is extremely rugged to withstand the shock and
vibration normally encountered by vehicle mounted equipment. The unit operates com-
pletelyautomaticallyandstopschargingthebatterieswhentheyarefullycharged.Thereis
no trickle charge and therefore no danger of overcharging and water boil-off. Any parasitic
loadsonthebatterysuchasradio,lights,etc.,areautomaticallysuppliedwithcurrentbythe
charger.
INSTALLATION
The Auto Charge 11PIM Automatic Battery Charger should be installed in an area with
adequate ventilation. A power cord is supplied for connection to 120 volts 50/60 Hz.
1. Mount the charger using the four holes provided for this.
2. Connect the wiring from the batteries to the Output Terminal Strip. Spade lugs that
have been securely crimped, or soldered, should be used.
3. Double check all wiring before proceeding.
4. Wire the A.C. power line cord to 120 volts.
5. Pilot light will light to show that the charger has power.
Any 120 volt loads when plugged into the GFI on the Auto-Charge 11PIM will be protected
from ground faults. A separate lever operated circuit breaker protects the GFI connected
loads.Thiscircuitbreakermayalsobeusetodisconnecttheseloadsfromtheline.Thefuse
on the Auto-Charge 11PIM protects the charger only.

INSTALLATION WIRING DIAGRAM
NOTE:Senseleadsareshowncon-
nected to battery #1 but may be
connected to either battery at the
installers option. The sense leads
howevermustbeconnectedforthe
charger to operate. The charger
doesnotrequirea2battery vehicle
tofunction properly. For single bat-
teryvehicles connect to battery #1.
IMPORTANT: Wire size is for a
maximumlengthof20feet.Ifwiring
is to be longer, larger wiring is re-
quired. Additional information is
available on request.
WIRE SIZE CHART
CONNECTION ITEM DEFINITION WIRE
SIZE
COM BATTERY
COMMON NEGATIVE CHARGING LEAD FOR BATTERIES 12 AWG
BAT 1 BATTERY
#1 POSITIVE CHARGING LEAD FOR BATTERY # 1 12 AWG
BAT 2 BATTERY
#2 POSITIVE CHARGING LEAD FOR BATTERY # 2 12 AWG
SENSE
_NEGATIVE
SENSE NEGATIVE VOLTAGE SENSE LEAD. DETECTS VOLTAGE 16 AWG
SENSE
+POSITIVE
SENSE POSITIVE VOLTAGE SENSE LEAD. DETECTS VOLTAGE 16 AWG

AUTO CHARGE
4.25
12.75
4.75
6.75
OUTLINEDRAWING
9/32" DIA. 4 HOLES
12.00
SPECIFICATION & OUTLINE
SPECIFICATIONS:
Input: 120volts 50/60Hz, 2.5 amps
Fuse: 3 amp
Output: for 12 volt batteries
Output Current: 0-11 amps
Charge Indicator: 0-15 amps
Weight: 12 lbs

INSTALLATION RECORD & WARRANTY
Date Installed
Installed By
Vehicle Identification
Vehicle Owner
Allproducts of KussmaulElectronics Company Inc.are warranted tobe free
of defects of material or workmanship. Liability is limited to repairing or
replacing at our factory, without charge, any material or defects which
become apparent in normal use within 3 years from the date the equipment
wasshipped.Equipmentistobereturned,shippingchargesprepaidandwill
be returned, after repair, shipping charges paid.
Kussmaul Electronics Company, Inc. shall have no liability for damages of
any kind to associated equipment arising from the installation and /or use of
the Kussmaul Electronics Company, Inc. products. The purchaser, by the
acceptance of the equipment, assumes all liability for any damages which
may result from its installation, use or misuse, by the purchaser, his or its
employees or others.
