Service Manual
Published: October 18, 2023
700-C Frame Assembly Machine
700-C Service Manual

KVAL 700-CService Manual
Proprietary Notice
This Manual is confidential and contains proprietary information and intellectual property of Kval
Inc., and is to be used solely by Customer as an operating manual for Kval Inc. machines. Neither
this Manual nor any of the information contained herein may be reproduced or disclosed under
any circumstances without the express written permission of Kval Inc. For authorization to copy
this information, please call Kval Customer Support at [phone] or fax [phone].
Manual Name: 700-C Service Manual
Manual Revision: 46-CS1-MV101.1, 46-CS1-MV100.2
700-C is a trademark of Kval Incorporated.
Copyright 2021 Kval Incorporated. All rights reserved.
Beckhoff®, TwinCAT, and EtherCat® are registered trademarks and are licensed by Beckhoff
Automation GmbH
All other products are trademarks or registered trademarks of their respective holders, all rights
reserved. Reference to these products is not intended to imply affiliation with or sponsorship of
Kval Incorporated.
Contacting Kval
For further information about this manual or other Kval Incorporated products, please contact us.
Mailing address:
Kval Incorporated
825 Petaluma Boulevard South
Petaluma, CA 94952
Phone and Fax:
call: [phone]
fax: [phone]
General Office Business Hours
Mon-Thu:6:00 AM - 4:00 PM PST
Fri: 6:00 AM - 3:30 PM PST
Parts
Contact us for all parts related needs, from orders to inquiries. Call, email, contact us on our web-
site at the “Contact Us” page.
email: [email protected]

KVAL 700-CService Manual
KVAL 700-CService Manual
Technical Support
For machinery support and troubleshooting. Call, email, contact us on our website at the “Contact
Us” page.
Mon-Fri:4:00 AM - 4:00 PM PST
email: [email protected]
Field Service Support
For any other inquiries or to schedule on-site service. Call, email, contact us on our website at the
“Contact Us” page.
email: [email protected]
Sales Support
For machinery information, specifications, and quotes. Call, email, contact us on our website at
the “Contact Us” page.
email: [email protected]
Kval Website
Learn about Kval, order parts, get information on our array of machines (including new machine
releases), learn about our machine software solutions, download machine documentation, view
videos of our machines in action, contact all the departments.
http://www.kvalinc.com

KVAL 700-CService Manual
Access Manuals and Videos Easily
You can easily access a range of resources including downloadable PDF manuals, Quick Start
guides, Maintenance Summaries, links to instructional videos, and Electro-Mechanical Maps. To
access these valuable materials, simply follow these steps:
1. Visit https://kvalinc.com/machine-support or scan the QR code provided in this sec-
tion.
2. Hover your cursor over the Support option located at the top bar of the website.
3. From the drop-down menu that appears, select Machine Support.
Once you've reached the Machine Support page:
1. Enter either the machine model name or the machine serial number.
2. This will take you to the document page related to your specific machine.
3. From there, you can easily select and download the desired files and resources.
This streamlined process ensures you have quick and convenient access to the information you
need for your machine
.
FIGURE 1-1. Machine Support Page
QR Code
https://kvalinc.com/machine-support

Table of Contents
Introduction and Safety...Chapter 1
About the 700-C ........................................................................................1-1
Table Options ..............................................................................................1-1
About this Manual ....................................................................................1-3
Service Manual ...........................................................................................1-3
Quick Start ...................................................................................................1-3
Safety First! .................................................................................................1-4
Safety Sheet Sign-Off Sheet ....................................................................1-4
Safety Terminology of Labels ...................................................................1-4
Safety Guidelines .....................................................................................1-5
Training ........................................................................................................1-5
Protective Gear ...........................................................................................1-5
When the Machine is Powered and Running ........................................1-5
Lockout/Tagout Guidelines ...................................................................1-6
Follow the P-R-O-P-E-R lockout rule of thumb. ....................................1-6
Lockout/Tagout Procedure ...................................................................1-7
Before Lockout/Tagout: Inspect the Machines ......................................1-7
Lockout/Tagout Power ...............................................................................1-7
Lockout/Tagout Air Supply ........................................................................1-8
Start Maintenance ......................................................................................1-8
Post Maintenance Steps ...........................................................................1-9
Zero-Energy to Start-Up ........................................................................1-10
Inspect ........................................................................................................1-10
Clean Up ....................................................................................................1-10
Replace Guards ........................................................................................1-10
Check Controls .........................................................................................1-10
Remove Locks ..........................................................................................1-10
Perform Visual Checks ............................................................................1-10
Close the Cage Gate ...............................................................................1-11
Getting Help from Kval ...........................................................................1-12
Kval Return and Warranty Policy .......................................................1-13
Send the Item ............................................................................................1-13
Acceptance of Return ..............................................................................1-13
Refund Turnaround Time ........................................................................1-13
Kval Errors .................................................................................................1-13
Customer Errors .......................................................................................1-14
Shipper Errors ...........................................................................................1-14
Warranty Replacement Parts .................................................................1-14
Safety Sign-Off Sheet .............................................................................1-16

Table of Contents
A Note to the Operator ..........................................................................1-16
Maintenance of the 700-C...Chapter 2
Maintenance Schedule ..........................................................................2-1
Lubrication Schedule ..............................................................................2-3
Kval Lubrication Kit ....................................................................................2-4
About Bearings ..........................................................................................2-5
About Pillow Block Bearing Housings .............................................2-6
About Flange Bearing Housings ..............................................................2-6
About Ball Rail Bearings .......................................................................2-7
Machine Lubrication Map ......................................................................2-8
Greasing Staple Gun Carriage Bearings .......................................2-9
Recommended Tools .................................................................................2-9
Staple Carriage Greasing Procedure ......................................................2-9
Staple Carriage Grease Point Locations ................................................2-9
Greasing the Movable Fence Bearings ..........................................2-11
Recommended Tools ...............................................................................2-11
Movable Fence Greasing Procedure ....................................................2-11
Movable Fence Grease Point Locations ..............................................2-11
Greasing the Rack and Pinion Bearings ........................................2-13
Recommended Tools ...............................................................................2-13
Rack and Pinion Greasing Procedure ..................................................2-13
Rack and Pinion Grease Point Locations .............................................2-13
Description of Air Input System ..........................................................2-15
Air Input with Lubrication ........................................................................2-15
Adjusting the Air Line Lubricator ...........................................................2-15
Priming the Air Line Lubricator ...............................................................2-16
Air Line Without Lubricator .....................................................................2-16
Troubleshooting the 700-C...Chapter 3
Get Live Technical Help .........................................................................3-1
About a Typical Pneumatic Circuit ....................................................3-2
Typical Pneumatic Assembly ....................................................................3-3
About the Coil (Solenoid) ..........................................................................3-3
About Cylinder Operation ..........................................................................3-4
How the Pneumatic System Works ..................................................3-5
Important Notice about Adjusting Cylinder Speed ................................3-7

Table of Contents
Adjusting Cylinder Extend Speed ............................................................3-7
Adjusting Cylinder Retraction Speed ......................................................3-7
Pneumatic Assembly Locations .........................................................3-8
Description of the Light Tower ...........................................................3-9
Bottom Light (Control Power) ..............................................................3-10
Bottom Light Conditions ..........................................................................3-10
If the Bottom Light is OFF .......................................................................3-10
If the Bottom Light is ON .........................................................................3-10
Top Light (Machine Status) ..................................................................3-11
Top Light Conditions ................................................................................3-11
If the Top Light is OFF .............................................................................3-11
If the Top Light Flashing White ...............................................................3-11
If the Machine Status Light is Red .........................................................3-12
If the Machine Status Light is Yellow .....................................................3-13
If the Machine Status Light is Blue ........................................................3-13
If the Machine Top is Solid Green ..........................................................3-13
About the Three Light Panel ................................................................3-14
Control Power Light .................................................................................3-14
Start Light ..................................................................................................3-15
About Switches and Sensors ..............................................................3-16
Using Sensors to Trouble Shoot ............................................................3-17

1-2
Door Transfer System Service Manual
CHAPTER 1 Introduction and Safety
This chapter provides an overview of the Kval Door Transport System (DTS) and important safety
information to follow when operating the machine.
Chapter 1 at a Glance
Section Name Summary Page
Overview of the DTS
System
This section provides an overview of the DTS This
section includes a general description and a table
of available options.
page 1-1
Safety! IMPORTANT safety information is described in this
section.
page 1-5
Zero-Energy to Start-
Up
Procedure to power up your machine for the first
time.
page 1-10
Getting Help from Kval This section describes the method to contact the
Kval service center for help. The section includes
how to get information from the specification plate
tor provide to Kval, service center hours, and
return procedures.
page 1-12
Safety Sign-Off Sheet A record to track operators that are trained on the
machine.
page 1-16

About the 700-C
About the 700-C
1-1
About the 700-C
The Kval 700-C Frame Assembly Machine is generally used in-line with the Commander 3 or 990
Series of machines.
The operation includes placing the strike jamb and header into the machine and clamping into
place. The door, with hinge jamb installed, is then moved into position, gently lowered into place,
and then securely clamped into position. Two-Hand control Palm Buttons activate the clamping
sequence and vertically move staple guns into position to attach the jambs to the header. Activat-
ing staple gun "fire" sequence is initiated with one palm button and the "fire guns" push-button on
the control panel on machine. The door is then raised and rolled out of the machine to the next sta-
tion to the packaging station.
The 700-C is adjustable for doors from 18" to 4', wide with a standard length capacity of 6'8" or an
optional capacity for 7'0" and 8'0" doors. The 700-C can have up to four staple guns mounted on
four corner brackets. Spot Nail Staple guns, with 7/16” crown staples are supplied with machine
as standard.
Table Options
Each table or conveyor is assigned an option.
TABLE 1-1. 700-C Options
Option Table Description
B: Reverse Feed Direction Normal direction is left to right. For right to left, add this
option.
54X: 5/4 Spacers for Thick Jambs Spacers for frame width adjust bars to accommodate
both 11/16" thick jambs and 5/4" thick jambs.
D: 7’0” and 8’.0” Door Frame Allows operator to quickly adjust end clamps from 6'8" to
7'0" or 8'0" doors. Quick changeover time of approxi-
mately one minute required.
G: 7’0” Door Frame Allows operator to quickly adjust end clamps from 6'8" to
7'0" doors. Quick changeover time of approximately one
minute required.
I: Leg Extensions For variable height applications. Customer to specify
height.
J: End Clamp Spacers For use on 6’6” doors. Jamb spacer blocks connect to
the end clamp pads. Four spacers required.
N: End Clamp Spacers For use on 6’6” doors. Jamb spacer blocks connect to
the end clamp pads. Four spacers required.
N: Narrow Jamb Via removable spacer blocks and increased cylinder
stroke, operator is able to reduce minimum jamb width
from 4-1/4" to 3-1/2".

About the 700-C
About the 700-C
1-2
A: Duplex Edge Nailers Not recommended for MDF jambs. This option includes
and utilizes two(2) Stanley Bostich F28WW Round Head
Framing Nailer's (nails 2" to 3 1/2" in length) with remote
fire valves
SG1: Custom Staple Gun Mounts Customer requests to utilize their own staple guns and
remote fires which differ from the outlined standard engi-
neered models in Option SG. Note: Not all staple guns
can be applied to the 700-C machine.
SGS4: Stanley Bostitch Staple
Guns-1/2” Crown
Replaces the standard staple guns with four(4) Stanely
Bostitch SB650S4 (1/2" crown) staple guns and remote
fires necessary to fasten wood jambs, headers, and sills
on 700 series framing machines.
SGS5: Stanley Bostitch Staple
Guns-7/16” Crown
Replaces the standard staple guns with four(4) Stanely
Bostitch SB650S5 (7/16" crown) staple guns and remote
fires necessary to fasten wood jambs, headers, and sills
on 700 series framing machines.
SGMAX: MAX Staple Gun-7/16”
Crown
Replaces the standard staple guns with four(4) MAX TA
551B/16 (7/16" crown) staple guns and remote fires nec-
essary to fasten wood jambs, headers, and sills on 700
series framing machines.
TABLE 1-1. 700-C Options
Option Table Description

About this Manual
1-3
Auto Cross Transfer System Operation and Service Manual
About this Manual
This manual is part of a package delivered with the machine line.
Note: Manuals and Quick Starts are available on line to download. Videos are avail-
able to view. See “Access Manuals and Videos Easily” at the beginning of this
manual.Operation Manual
Service Manual
This Manual.
Quick Start
A one page laminated sheet to aid in operating the machine.
Chapter Title Description
1Introduction Descriptions of Machine Line and Safety Information.
2Operation Descriptions of how to power machine line, and operator
user screens.
3Tour Descriptions of the Table Options of the 700-C.
Chapter Title Description
1Introduction Descriptions of Machine Line and Safety Information.
2Maintenance Descriptions of Calibration Routines and how to use the
interfaces
3Troubleshooting Common troubleshooting Tips.
700-C QUICK START
700-C QUICK START
Power-Down
Power-UP
VerifyArea is safe, power and air are applied,
E-Stops areout and Fence Gates are closed.
1. At the Electrical Box, turn the Electrical Dis-
connect to the ON position.
2. Turn the Control Circuit Switch to the ON
position.
(Approximately3 minute boot-up)
3. Pushthe Stat buton.
All the 3 lights should be illuminated. See re-
verse side for the 3-Light Description.
1. Push the Stop buton.
2. Turn the Control Circuit Switch to the OFF
position.
3. Turn the Electrical Disconnect to the OFF
position on the Electrical Cabinet.
Note:Some of these setings are options and may not be
located on your machine.
• Ensure the proper guns are enabled and staples are
loaded.
• Adjust the machine for the desired Door Width.
• Adjust the machine for Door Lenth.
• Adjust the machine for Jamb Width.
• Adjust the machine for Jamb Thickness.
Mechanical Setup
Before processing the door,set-up the following mechani-
cal adjustments.
Note: See the back of this Quick Stat for information on
these setings.
Main Panel Controls
Stage the door for framing.
1. Insetthe Header Jamb
ĻIdentiy the hand of the door.(See back
for hand location.)
ĻPatially pull the door into the 700-C.
ĻPlace the header jamb into Head Jamb
Clamp.
2. Insetthe Strike Jamb
ĻPlace strike jamb into the machine and
pull the door in all the way in.
ĻMake sure the strikejamb aligns to the
header.
ĻFlip the hinge jamb down.
ĻRoughly align the hinge jamb to the
header jamb.
Power Controls
Reset.
• Brings 700- C to stating position
TurnOn or OFF Staple Guns
Select Jamb Type(Reg or Split)
Select the Staple Syle Se-
quence.
• Select A = 0-3.
• Select B= 4-7.
• Sequence REV and FWD.
• Rev= Step back Clear Hands
Control.
• FWD = Go foward from Rev Step.
Width Butons:
• Select Jamb Width-Butons.
• Select Door Width-Black buton
control. Manually movefence to
door width position.
Stage the Door
Frame the Door
1. Bringin the Movable Heads and Header Clamps
ĻPress both Hands FreeButons simultaneously.
ĻThe movable side staple guns and strike jamb clamps
move close to the door.
ĻThe header and swing clamps extend.
ĻStaple guns and clamps are raised intoposition.
2. Drop Down the Door to Align
ĻPress both Hands FreeButons simultaneously.
ĻThe infeed wheels lower to align the door tothe header
and strike jambs.
3. Bring in the Fixed Heads
ĻPress both Hands FreeButons simultaneously.
ĻFixed side staple guns move in.
4. Raisethe Door and Frame into Stapling Position
ĻPress both Hands FreeButons simultaneously.
ĻOufeed wheels raise the door into position.
ĻBotom jamb clamps rise, pushing the frame up fromthe
botom.
ĻEnd jamb clamps move in.
ĻEnsure that door,header jamb, strike jamb are clamped
square.
5. Fire Staple Guns
ĻPress the let Hands FreeButon and the green Fire But-
ton simultaneously.
ĻOufeed wheels move down and the swing clamps
retract.
ĻStaple guns ire to the programmedpatern.
ĻStaple guns will ire when dropping
5a. FireNail Guns (Option)
ĻPress the right Hands FreeButon and the Yellow Fire
Buton simultaneously.
ĻNail guns ire.
Note: The Nail Guns are an optionand are not installed on all
700-C machines.
6. Unclampthe Do or
ĻPress both Hands FreeButons simultaneously.
ĻAll guns move away from the door.
ĻAll clamps retract.
ĻOufeed wheels move up.
ĻManually move the door out of the 700-C.
7. Reset 700-C
ĻPress both Hands FreeButons simultaneously.
ĻLast step before pulling in another door or shutingdown
the machine.
Note: Pressing the ResetButon on the Main Control Panel is
an alternate way to resetthe 700-C.
Ater the door is pulled in and the hinge and strike jambs
are aligned, use the Hands Free controlsto staple the
frame to the door.
If a step needs to be reversed, move the Main Control
panel Sequence switch to REV. Press the Hands Clear but-
tons to go back a step. Aterthe issue is resolved, set the
Sequence switch to back to FWD and continue process-
ing the door.
Hands Free
Hands Free
Hands Free
Hands Free
Hands Free
Hands Free
Hands Free
Hands Free
Hands Free
Hands Free
Hands Free
Hands Free
Hands Free
Hands Free
Hands Free
Hands Free
Hands Free
Hands Free
Green Fire Button
Green Fire Button
Yellow Fire Button
Yellow Fire Button
Hands Free
Hands Free
Align
Align
Staple Guns Fired
Staple Guns Fired
1: Headers/Movable Fence In Close
1: Headers/Movable Fence In Close
Nail Guns Fired
Nail Guns Fired
5a: Fire the Nail Guns
5a: Fire the Nail Guns
7: Reset the 700-C
7: Reset the 700-C
5: Fire the Staple Guns
5: Fire the Staple Guns
6: Unclamp the Door and Frame
6: Unclamp the Door and Frame
4:Raise the Door and Frame
4:Raise the Door and Frame
3: Bring in the Fixed Head Side
3: Bring in the Fixed Head Side
2: Align the Door
2: Align the Door
Hands Free (X2)
Hands Free (X2)
Download Manuals and Access Videos
htps://kvalinc.com/machine-suppot
At the web page, enter the 700-C serial
number in the search box. Access to the
manuals and videos will be available.
Hands Free (X2)
Hands Free (X2)

Safety First!
Safety First!
1-4
Safety First!
Safety Sheet Sign-Off Sheet
At the end of this chapter, there is a safety sign-off sheet. It lists personnel and machine safety cri-
teria to understand before operating the machine. It is highly recommended that personnel operat-
ing, working on a machine meet the criteria listed in this sheet. It is recommended the sheet be
signed and kept for records. See “Safety Sign-Off Sheet” on page 1-16.
Safety Terminology of Labels
In addition to the nameplate, Kval machines may have other warning labels or decals that provide
safety information to operators. Safety labels should be clearly visible to the operator and must be
replaced if missing, damaged, or illegible.
There are three types of warning labels or decals:
•DANGER means if the danger is not avoided, it will cause death or serious injury.
•WARNING means if the warning is not heeded, it can cause death or serious
injury.
•CAUTION means if the precaution is not taken, it may cause minor or moderate
injury.
This machine is a powerful electro-mechanical motion control
system. You should test your motion system for safety under
all potential conditions. Failure to do so can result in dam-
age to equipment and/or serious injury to personnel.

Safety Guidelines
Safety Guidelines
1-5
Safety Guidelines
In addition to the caution and warning labels affixed to this machine, follow the guidelines below
to help ensure the safety of equipment and personnel.
Note: Different versions of the stickers may have been applied to the machine. The
intent of safety is the same.
Training
Ensure that all employees who operate this machine are aware of and adhere to all safety precau-
tions posted on the machine and are trained to operate this machine in a safe manner. Figure 1-1
below shows a sample of safety labels addressing training.
FIGURE 1-1. Read the Manual Labels
Protective Gear
Never operate the machine without proper eye and ear protection. Figure 1-2 below shows a sam-
ple of safety labels addressing safety gear.
FIGURE 1-2. protective Gear Labels
When the Machine is Powered and Running
Serious injury or death could occur if these general rules are not followed.
•Never reach hands beyond safety cage. Servo motors can unexpectedly move
quickly.
•Never clear screws or hinges out of the machine while it is running.
•Never reach into the router area to retrieve a hinge. The router may still be running
down after shut down.

Lockout/Tagout Guidelines
Lockout/Tagout Guidelines
1-6
Lockout/Tagout Guidelines
Follow these Lockout/Tagout guidelines,
• Place a tag on all padlocks. On the tag, each operator must put their own name and
date. (These locks are only to be removed by the person who signs the tag)
• If more than one person is working on the machine, each additional person places a
lock and tag on each disconnect.
• Only each operator may remove their own lock and tag.
Important: When many people are all working on the same machine you will need a
multiple lockout device, such as the one shown here.
Follow the P-R-O-P-E-R lockout rule of thumb.
P...... Process shutdown
R ...... Recognize energy type (electrical, pneumatic, mechanical, etc.)
O...... OFF! Shut off all power sources and isolating devices
P...... Place lock and tag
E...... ENERGY: Release stored energy to a zero-energy state
R ...... Recheck controls and test to ensure they are in the “OFF” state

Lockout/Tagout Procedure
Lockout/Tagout Procedure
1-7
Lockout/Tagout Procedure
This policy is required by OSHA regulation 1910.147 and Cal OSHA’S
SB198 ruling of July 1991.
Use the following lockout procedure to secure this machine while it is
powered down. During a lockout, you disconnect all power and shut
off the air supply. Be sure to use the tagout guidelines noted below.
https://www.osha.gov/
Before Lockout/Tagout: Inspect the Machines
1. Evaluate the equipment to fully understand all energy sources (multiple electrical
supplies, air supply and pressure, spring tension, weight shifts, etc.).
2. Inform all affected personnel of the eminent shutdown, and the duration of the shut-
down.
3. Obtain locks, keys, and tags from your employer’s lockout center.
Lockout/Tagout Power
Note: When multiple people are working on the machine, each person needs to have a
lock on the handle in the extra holes provided.
4. Turn the Main Power on ALL electrical panels to the OFF position.
a.Lever style Electrical Panels: ensure the lever is in the down position, insert
lock and tag into the lever hole making sure the lever cannot move, lock as per
the tagout guidelines. (see illustration below).

Lockout/Tagout Procedure
Lockout/Tagout Procedure
1-8
b.Disconnect style Electrical Panels: push the red tab to pop it out. Place a pad-
lock through the hole. Place your tag on the padlock, as per the tagout guide-
lines below. (see illustration below).
Lockout/Tagout Air Supply
5. Turn all air valves to the OFF position and place a padlock through the hole (see
illustration below).
NOTE: Place your tag on the padlock, as per the tagout guidelines.
Start Maintenance
6. Once the locks and tags are in place and all personnel are clear, attempt to operate
the machine to ensure equipment will not operate.
7. Maintenance or repairs may started.
Insert Lock into hole.
Turn Switch to the
OFF position Lock and Tag out

Lockout/Tagout Procedure
Lockout/Tagout Procedure
1-9
Post Maintenance Steps
8. After maintenance is completed, the person performing the work must ensure all
tools, spare parts, test equipment, etc., are completely removed and that all guards
and safety devices are installed.
9. Before removing the locks and tags, the person who attached them shall inspect the
equipment to ensure that the machine will not be put in an unsafe condition when
re-energized.
10. The lock and tag can now be removed (only by the person(s) who placed them),
and the machine can be re-energized.
11. The tags must be destroyed and the locks and keys returned to the lockout center.

Zero-Energy to Start-Up
Zero-Energy to Start-Up
1-10
Zero-Energy to Start-Up
Starting the equipment properly is just as important as the Lockout/Tagout guidelines in terms of
safety.The following guidelines below should be followed to start the equipment.
Inspect
The equipment must be inspected for proper adjustment before starting equipment.
Clean Up
All materials and debris must be cleaned up. Any combustible materials or old parts used during
repairs must be cleaned up and/or properly disposed of.
Replace Guards
Replace all equipment guards. If part of equipment cannot be properly adjusted after start-up with
guard on, contact the Kval Technical Support. See “Getting Help from Kval” on page 1-12.
Check Controls
Confirm that all switches are in the “OFF” position. Please be advised that some components of
the machine may start automatically when energy is restored.
Remove Locks
Each operator must remove his or her own lock and tag. This will ensure that all operators are in a
safe place when the equipment is started.
Perform Visual Checks
If the equipment is too large to see all around it, station personnel around the area and sound the
personnel alarm before starting the equipment. If your operation is more complex, your com-
pany’s comprehensive safety procedure may involve additional steps. You will need to ask your
supervisor about these procedures. The company’s lockout procedure should be posted at each
machine. On larger or long-term maintenance or installation projects, the company’s procedures
must be explained to all new operators and a copy of the company’s procedures should be posted
on-site for the duration of the work.
The Company’s procedures should also include provisions for safely handling shift changes and
changes in operators or new operators.Comprehensive Lockout/Tagout may use a gang box or
other system to ensure that locks are secure and not removed without authorization.
Remember, Lockout/Tagout procedures work because you are the only one with the key to your
lock. Proper Lockout/Tagout can save lives, limbs, and money. Help make your work environment
safe for you and your fellow workers. Be sure to follow the P-R-O-P-E-R Lockout/Tagout proce-
dures, and that those around you do also.

Zero-Energy to Start-Up
Zero-Energy to Start-Up
1-11
Close the Cage Gate
Verify all cage gates are securely closed. Ensure all safety protocols are in effect.
