KVM Discovery SP-116R User manual

KVM Discovery powered by
Haitwin-Delphin Technologie GmbH,
Kieselstraße 15, 41472 Neuss / Germany
phone: [phone] email: [email protected]
SP series
VGA Video Splitter (Metal Housing)
User Manual
Factory: ISO9001 System Certified
Production certificate: CE, RoHS & FCC

User Manual
I.* Product Introduction:
VGA splitter(video splitter) is the equipment to distribute 1 video signal to multiple VGA output
equipments synchronously, to ensure different displays show the same image. The equipment with
additional power adapter, which can blow up and dispose the output signals, in order to ensure and
improve the signal output plus. Advantages: high bandwidth, resolution and reliability, As well as the
long-distance signal transmission, the max long-distance can reach 65 meters. it could be used in:
securities business, computer exhibition hall, public broadcasting and education & training center etc.
II.* Safety guide:
In order to make sure the correct use of the device and the security of the operator, please do as
following:
1. The power supply of the device is DC9V/300mA; DC9V/1000mA;
2. Do not put the device in the place where is too hot or too cold.
3. The power of the device will heat when working. So keep the working environment in good
ventilation in order not to damage the machine with high temperature.
4. The non-professional should not take apart the machine or repair it without permission in order
to avoid accident or aggravating damage extent of the device.
5. Do not spill any chemical product or liquid on the device or near it.
III.* Trouble shooting
1) When no output signal, please check::
A: Whether the power wire is plugged into the device.
B: Whether the connection wire is well.
C: Whether there is input signal.
2) If the power light is off, the power supply maybe wrong.
3) If the output image is interfered, the device may not be grounded properly.
4) If the output image is not clear, please check whether the connection wire has problem.
IV.* Specification:
Type SP-116R
SP-1215
SP-1415
SP-1815
SP-1235
SP-1435
SP-1835
SP-1250
SP-1450
SP-1850
Bandwidth 250MHz 150MHz 350MHz 500MHz
signal
Connector type Input HD15M; Output HD15F
Min input
voltage 0.5Vp-p
Max input
voltage 1.0Vp-p
I/O impedance 75Ω
Video
Optimal
Resolution 1280*1024 1920*1080 2048*1536
Max Resolution 1920*1080 2048*1536
Horizontal
frequency 30-120KHz 30-120KHz 30-120KHz
Vertical
frequency 40-120Hz 40-120Hz 40-120Hz
pertin
ence
Dimension
(mm) 132*92*41 432*115*45 432*115*45
Power AC100-240V DC9V/300mA DC9V/1000mA
House Metal
