KYLAND Technology KIEN2032 User manual

KIEN2032 Industrial Ethernet Switch
User’s Manual
KYLAND Telecom Technology Co., Ltd.

KIEN2032 Industrial Ethernet Switch
User’s Manual
Copyright © 2005 KYLAND Telecom Technology CO., LTD.
All rights reserved.
No part of this documentation may be excerpted, reproduced, translated, annotated or
duplicated, in any form or by any means without the prior written permission of KYLAND
Corporation.
Publisher: KYLAND Telecom Technology CO., LTD
Address: P.O.Box 100096, 085, Beijing, China
Website: http://www.kyland.cn
Postcode: 100096
Tel: [phone]
Fax: [phone]
E-mail：marketing @ kyland. com. cn
Version: V1, Dec. 2005
No.: e6t04050901

Preface
KIEN2032 is the high-performance network management Ethernet switch developed
by KYLAND for industrial application. It is integrated optical communication
equipment, which integrates with Ethernet access and serial data transmission. Its
high-performance switching engine, firmness and closed case design, high-effective
ribbed casing for heat removal without fan, over-current, over-voltage and EMC
protection for power supply input terminal, excellent EMC protection performance for
the Ethernet RJ45 port, RS232 and RS485 port enable the KIEN2032 to adapt the
tough and dangerous industrial environment. The redundant function of the optical
fiber network, independent network management channel for the whole network and
powerful real time network management system for the whole network provide
strongly guarantee for the reliable operation of the system.
The KIEN2032 Industrial Ethernet Switch User’s Manual mainly introduces the
technical principle, performance index, installation and commission of the KIEN2032
industrial Ethernet switch, and provides the reference for users to commence, expand
and routine maintain the system. At the same time, it applies to the user training and
learning for related technical personnel, so it is the practical teaching material for mass
users to learn about the KIEN2032 industrial Ethernet switch.
This document mainly contains following contents:
Chapter1 Overview and System Features
Chapter2 Performance Index and Service Function
Chapter3 Hardware Architecture
Chapter4 Installation Procedure
Chapter5 Configuration andApplication Method
Chapter6 Field Test Method
Chapter6 Networking Modes and System Configuration
Appendix A Twisted-pair and Pin Assignment Rules
Appendix B Type and Specification of Cable
Appendix C Abbreviation

This document is used together with the Kyvision Industrial Ethernet Switch Dedicated
Network Management User’s Manual.
Statement: For continuous update and perfection of the product and
technology, the contents of this material may not be consistent with the
actual product, please contact with us about related contents. If it is
necessary for you to query the latest information on the product, please
query our cooperation Website or contact with your local service
representative directly.

Safety Notices
This product can provide excellent and reliable performance within its design scope.
However, it needs to avoid the damage or destroy by human reasons.
Read this Manual thoroughly and keep it well for future reference.
Do not place the equipment next to the source of water and the damp place.
Do not place anything on the power cable. Please place it somewhere that can not
be reached.
In order to avoid fire, do not tie or pack the cable.
The connector of the power supply and other equipment connection should be
connected firmly and regularly checked.
Under following conditions, please power off and contact with our company
immediately.
1. Water into equipment;
2. Equipment is broken or the crust is cracked.
3. The equipment works abnormally or the performance provided has changed
completely.
4. The equipment gives off odor, smoke or noise.
Pay attention to the cleanness of the fiber socket and jack. When the equipment
operates, do not watch the end-face of the fiber directly.
Pay attention to the cleanness of the equipment and clean it with soft cotton cloth
if necessary.
Do not repair the equipment by yourself unless it is definitely indicated in this
manual.

Description of Warning Mark:
This manual uses two kinds of obvious warning marks to prompt users that more
attention should be paid during operation. The meanings of these marks as follows:
Warning: The comment after this mark should be paid more attention, the
incorrect operation will cause the switch to be damaged seriously or it will
cause body injury for the operator.
Caution, Note, Warning and Dangerous: Prompt where more attention
should be paid.

-i-
Contents
Chapter1 System Overview..........................................................................................................................1
1.1 Product Overview ..........................................................................................................................1
1.2 Features..........................................................................................................................................2
1.3 Packing List and Unpacking Check............................................................................................... 3
Chapter2 Performance Index.......................................................................................................................5
2.1 System Index ....................................................................................................................................... 5
2.2Service interface ................................................................................................................................... 6
2.3 Service Functions........................................................................................................................... 7
Chapter3 Hardware Structure.....................................................................................................................9
3.1 System structure.............................................................................................................................9
3.2 Switch Structure........................................................................................................................... 10
3.2.1 Case....................................................................................................................................... 10
3.2.2 Front Panel............................................................................................................................ 11
3.2.3 Top Panel............................................................................................................................... 15
3.2.4 Bottom Panel......................................................................................................................... 18
Chapter 4 Hardware Installation............................................................................................................ 21
4.1 Installation Requirement.............................................................................................................. 21
4.2 Installation of Main Machine.......................................................................................................21
4.2.1 Rail Installation.....................................................................................................................21
4.2.2 Wall-mounted Installation..................................................................................................... 23
4.3 Cable Connection.........................................................................................................................27
4.4 Optical Fiber Connection.............................................................................................................27
4.5 Cable Layout................................................................................................................................ 29
Chapter 5 Configuration and Application of Data Port........................................................................ 31
5.1 Configuration of Data Port........................................................................................................... 31
5.1.1 Logon Console Network Management .................................................................................31
5.1.2 Console Network Management.............................................................................................33

-ii-
5.1.3 WEB Network Management..................................................................................................41
5.2 Application of Data Ports .............................................................................................................44
5.2.1 As TCP Server .......................................................................................................................44
5.2.2 As TCP Client........................................................................................................................45
5.2.3 UDP Method..........................................................................................................................45
Chapter 6 Testing Methods.......................................................................................................................47
6.1 Self Testing...................................................................................................................................47
6.2 Testing of Ethernet Ports ..............................................................................................................47
6.3 Testing of Fiber Ports .........................................................................................................................48
6.4 Data Ports Test..............................................................................................................................49
Chapter 7 Networking Modes and System Configuration.....................................................................51
7.1 Networking Modes .......................................................................................................................51
7.2 System Configuration...................................................................................................................52
AppendixATwisted-pair and Pin Distribution.........................................................................................55
Appendix B Type and Specification of Cable............................................................................................57
Appendix C Glossary...................................................................................................................................59

-1-
Chapter1 System Overview
1.1 Product Overview
KIEN2032 is the high-performance network management Ethernet switch developed
by KYLAND for industrial application. It is the integrated optical communication
equipment which integrates with Ethernet access and serial data transmission. Its
high-performance switching engine, firmness and closed case design, high-effective
ribbed casing for heat removal without fan, over-current, over-voltage and EMC
protection for power supply input terminal, excellent EMC protection performance for
the Ethernet RJ45 port, RS232 and RS485 port enable the KIEN2032 to adapt the
tough and dangerous industrial environment. The redundant function of the optical
fiber network, independent network management channel for the whole network and
powerful real time network management system for the whole network And it can
strongly guarantee the reliable operation of the system.
The KIEN2032 industrial Ethernet switch can provide two installation methods such as
DIN rail and wall-mounted. The front panel presents two pair of 100Base-FX single
mode or multi-mode optical fiber interface with uplink redundancy. It can take
advantage of the uplink redundant optical fiber interface to form the optical fiber
redundant ring network, so the recovery time for the ring network redundancy is less
than 300ms when the system failure occurs. There are three 10Base-T/100Base-TX
Ethernet RJ45 ports. Each RJ45 port can provide the adaptive function and can be
configured to 10Base-T or 100Base-TX status automatically and the full duplex and half
duplex operation mode. Furthermore, it can connect MDI/MDI-X automatically. 2
channel of RS232 and 2 channels of RS485 data interface which can implement the
point to point and point to multi-point communication on the network, to implement
the remote online of the serial port equipment readily.

KIEN2032 Industrial Ethernet Switch User's Manual
-2-
1.2 Features
High-performance Industrial Ethernet Switch
1. 10/100Base-T/TX Ethernet ports, auto-sensing, full/half duplex, Auto MDI/MDI-X
connection
2. 100Base-FX fiber ports, single mode/multimode, full duplex
3. High-speed redundant optical fiber ring (recovery time < 300ms)
4. VLAN to take control of broadcast domain and segment flow
5. Broadcast storm control
Powerful Management Function
1. Integral management platform for the entire network based on RS232 standard.
The management system is immune against the attack of virus or hacker since
the management channel is independent to service channel.
2. Special-designed management software for upper PC realizes the
auto-configuration of IP address for networking devices and auto-scan/spanning
of network topology.
3. Individual naming for each devices in the network.
4. Setting and query for VLAN.
5. Setting and query for alarm of power and ports.
6. Setting and query for port working mode, prioritization, and rate
Industrial Power
1. Industrial power input of DC24V（DC18V～36V）.
2. Reliable protection for EMC and against over-current/over-voltage.

Chapter1 System Overview
-3-
Multiple Serial Data Transmission
1. 2 x RS232, 2 x RS485 or 1 x RS232 and 1 x RS485.
2. Supports TCP and UDP and distribute the data from IP level according to TCP
and UDP user-targeted ports.
3. Open SOCKET mode for store data.
4. Point-to-point or multipoint-to-multipoint.
Industrial Design
1. Solid IP40 housing
2. Operation at -35℃to +75℃
3. Air humidity 10% to 95%
4. Easy DIN-Rail mounting
1.3 Packing List and Unpacking Check
１.Packing List
The packing box contains following contents:
KIEN2032 1
3-pin DC Power Supply Terminal 1
8-pin Data Interface Terminal 1
KIEN2032 Industrial Ethernet Switch User’s Manual 1
Kyvision Industrial Ethernet Switch Dedicated Network Management User’s
accompanying with 1 software CD 1
Customer Service Manual 1
Ф3 Grounding Cool Terminal, M3*8 Grounding Screw 1 set

KIEN2032 Industrial Ethernet Switch User's Manual
-4-
２.Unpacking Check
Place the box smoothly before it is opened and note direction of the packing box
and ensure its face upward to prevent dropping of the switch after unpacking. Avoid
the KIEN2032 drops after the box is opened. If the hard material is used to open
this box, the hard material should not enter the case body too much to prevent the
internal equipment damaged.
Check the quantity of KIEN2032 according to the packaging check list (including
the KIEN2032 host, the equipment parts, user’s manual and customer service
manual) and check the appearance quality of KIEN2032.
Warning:
The equipment is built in precision device, please note to gentile take and place it to
avoid drastic vibration which will have an effect on the performance of the equipment.

-5-
Chapter2 Performance Index
2.1 System Index
The system performance index of the KIEN2032 industrial Ethernet switch is shown as
table 2-1.
Table2-1 System Index
System Index KIEN2032
Quantity of RJ45 port 3 10Base-T/100Base-TX
Quantity of uplink redundant
fiber port 2 100Base-FX-SM/MM
Number of serial data
interfaces 2 RS232s, 1 RS485 or 1 RS232 and 2 RS485s
System parameters
Support standard: IEEE802.3, IEEE 802.3x, IEEE 802.3u, IEEE
802.1p and IEEE 802.1Q
Storage and forward rate: 148810 pps
Maximum filtering rate: 148810 pps
MAC address table: 4K
Switch method: storage and forward
System switching bandwidth: 4.8G
Maximum number of VLANs: 16
EMC interference: EN55022
EMC immunity: EN50082-2
Ethernet port
Physical interface:RJ-45 with shield
RJ-45 port: 10Base -T/100Base-TX can support the
self-negotiation function.
Interface standard: Comply with IEEE802.3 standard.
Transmission distance: less than 100m
Data port
Physical interface: 3.81 phoenix wiring terminal
BER for data transmission: ≤10-10
Asynchronous rate: 0~115.2Kbps (adaptive)
Support both TCP/IP and UDP/IPprotocol
RS-485 interface: Can connect to 32-128 nodes with
communication distance 120m.
Electrical characteristics: comply with 3-wire RS232- and
2-wire RS485-related standard.
Fiber port
Light Transmission Power: >-13dbm(SM) >-20dbm(MM)
Light Receiving Sensitivity: <-28dbm(SM) <-35dbm(MM)
Wavelength: 1310nm(SM) 1550nm(SM) 1310 nm(MM)

KIEN2032 Industrial Ethernet Switch User's Manual
-6-
Transmission distance: 20～80Km(SM) <2Km(MM)
Connector type: SC/FC
Transmission rate: 125Mbps
CONSOLE interface
Physical interface: RJ-45 with shield
Interface standard: Comply with IEEE802.3 standard (3-wire).
Interface rate: 19200bps
Power supply
Input voltage: DC24V (DC 18V～36V)
Input power consumption: <6W
Over-current protection: Built-in
Mechanical parameters
Physical dimension (H * W * D): 142 ㎜55.4 ㎜120.5 ㎜(don’t
include DIN rail and wall-mounted assemble dimension)
Installation method: DIN rail and wall-mounted method
Heat removal method: Ribbed aluminum casing heat dissipation
without fan.
Outgoing wire method: Service\power supply lead from front
and the network management lead from upper.
Crust protection: IP40
Weight: 1kg
Ambient conditions
Operation temperature: -35～75
Storage temperature: -45～85
Humidity: 10%～95% (non-condensing)
2.2Service interface
1．Three 10Base-T/100Base-TX Ethernet RJ4 ports, each of which presents the
adaptive function. Can be adaptive of 10/100M and operate in half duplex/full
duplex mode automatically, and support MDI/MDI-X auto-connection. The
transmission distance is less than 100m.
2．2 pair of 100Base-FX single-mode or multi-mode fiber ports, each of which
provides the throughput up to 100Mbps and is forced to be in the 100M full
duplex working mode. Support optical route redundant technology and the
redundant recovery time is less than 300ms.
3．Comply with the IEEE802.3/802.3U/802.3X.
4．The meaning of RJ45 ports is: Yellow light – Indication for port rate.ON:
100M,;OFF: 10M. Green Light – Indication for connection status: ON: effective
connection network; BLINKING: network active; OFF: connectionless.
5．2 0~115.2Kbps adaptive serial data with two types of interfaces such as RS232
and RS485.

Chapter2 Performance Index
-7-
2.3 Service Functions
Connection of Serial Data
In KIEN2032, a serial port server is embedded to make serial data into Ethernet packets and
realize Ethernet switching and transmitting for serial data.
Independent Management of Serial Port Server
The embedded serial port server of KIEN2032 owns its independent IP address, and the
relevant parameters of server and its ports can be managed, queried, and set through remote
Telnet, WEB and serial port mode.
100Mbit/s Optical Fiber Redundancy
It is critical for network to re-configure immediately once disconnection occurs in the
industrial fields. Accordingly, KIEN2032 comes with DT-Ring, which is developed by
KYLAND, and offers 2 redundant fiber ports to realize the redundant ring network. The
system will be able to re-configure within 300ms after cable fault.
Configuration and Management
At KIEN2032, the settings, queries and management can be realized for the whole switch
or network system through CONSOLE interface.
LED Indicating
The LEDs indicate the port status correctly including transmission rate, link status and
system status.
VLAN
The network can be divided into several VLANs according to ports, through which the
users in one VLAN can communicate each other. The VLAN of KIEN2032 conforms to
IEEE802.1Q and can realize the communication within one VLAN of different switches.
KIEN2032 supports up to sixteen VLANs based on IEEE802.1Q.
802.1p Prioritization
KIEN2032 conforms to 802.1p, which is used the most widely in LAN environment. The
end-users of KIEN2032 can make use of this function to configure the port-based
prioritization when 802.1p is not supported at user’s end and different priority is necessary
for different ports’ services. Only the data package without Prioritization in the Packet in
the ports can be affected by this function. Each port of KIEN2032 supports 2 levels (high,

KIEN2032 Industrial Ethernet Switch User's Manual
-8-
low) prioritization.
Layer-2 Switching
Switches work in two ways: Cut-Through and Store-and-Forward. In Cut-Through, a
data packet is immediately relayed further after detecting the target address; in
Store-and-Forward, a data packet is first read-in completely and checked for errors
before the switch relays the same. KIEN2032 employs Store-and-Forward that is a
switching mode widely used.
Broadcast Storm Control
Broadcast storm is the ceaseless transfer of broadcast frame or multicast frame in
bridge, which is caused by loop and will waste much bandwidth. The purpose of
broadcast storm control is to optimize the performance of switch network. KIEN2032
supports the broadcast storm based on percentage. With the control percentage, the
broadcast flow of KIEN2032 will be monitored and controlled effectively. The switch
will filter out the over flow and ensure the flow percentage is normal once the
bandwidth of broadcast flow exceed the limit.
Alarming Function
KIEN2032 offers the alarming functions for port link and network. Through
management software, all the alarming functions can be configured functionally. The
alarming information is shown on management interface.
Setting for Working Mode of Port
KIEN2032 is able to set the working mode of all ports through management: full/half
duplex, auto-sensing, enforced full/half duplex, enforced 10M/100M etc.
Setting for Port Rate
KIEN2032 is able to set the rate of all ports through management as any integer
multiple of 32kbps.

-9-
Chapter3 Hardware Structure
3.1 System structure
The hardware architecture of the KIEN2032 industrial Ethernet switch is shown as
Figure .3-1.
CONSO
LE 口
DATA1 DATA2
Controller
Switching
Network
Power
Power Port
EMC
protections
Port 4 Ethernet Ports
1.3.6
Port 8
Serial Data Server
Figure .3-1 Hardware Structure
The system hardware mainly consists of following parts:
1．The switching network controller adopts the high performance ASIC chip
technology to provide the layer2 line rate forward for the data packet.
2．The serial data server adopts the high performance ASIC chip technology to
provide the conversion of TCP/IP protocol packet for the serial data.
3．Two channels of data can provide the RS232 and RS485 interface.
4．The optical fiber interface adopts the optical receiving and transmitting integrated
module to provide stable performance.
5．The power supply adopts the industrial-level one which can provide the
over-current, over-voltage and EMC protection.
6．All Ethernet interfaces, data interfaces and CONSOLE interfaces can provide the
EMC protection.

KIEN2032 Industrial Ethernet Switch User's Manual
-10-
3.2 Switch Structure
3.2.1 Case
The case of the KIEN2032 is a compact wall-mounted or DIN rail structure. The whole
equipment adopts the hexahedral full closed structure with the protection level up to
IP40. The left and right side ribbed plate of the case is made of aluminum and is a part
of the whole equipment head dissipation system. The ribbed structure can increase the
heat dissipation area double. The heat produced by the whole equipment can be
removed to the environment effectively by taking advantages of the ribbed caing in the
radiation and convection way, by which to greatly improve the high
temperature-resistance performance of the equipment. It spurns the traditional fan for
heating removal, and reduces the power consumption of the whole equipment as well
as improves the stability of the system. The profile of the case for the KIEN2032 is
shown as Figure .3-2.
Its external dimension (do not include the dimension of the DIN rail and the
wall-mounted assembly) is 142 ㎜x 55.4 ㎜x 120.5 ㎜(H x W x D).

Chapter3 Hardware Architecture
-11-
Figure .3-2 Outline drawing of KIEN2032
Warning:
The shell of this switch is a part of the whole equipment heat dissipation system. It will
get hot because of heat dissipation when the equipment works normally, do not touch
the crust when the equipment works to prevent from scalding.
3.2.2 Front Panel
The front panel of the KIEN2032 industrial Ethernet switch integrates with 2 pairs of
optical fiber interfaces, 3 10Base-T/100Base-TX Ethernet RJ45 ports, 1 power supply
input terminal, 1 data interface terminal and 9 system and port operation indication
lights as shown as Figure .3-3.

KIEN2032 Industrial Ethernet Switch User's Manual
-12-
Power Supply Indi cation LED
Port 8 Indication LED
Port 4 Indication LED
Speed LED
Port Connection Status
Indi cation LED
SystemRunning Status
Indication LED
Data Al armLED
Data 1 Indication LED
Data 2 Indication LED
Data Interface Terminal
Power Supply Input
Terminal
Figure .3-3 Front Panel Diagram
Optical Fiber Interface
The KIEN2032 presents 2 pairs of 100Base-FX full duplex single mode or
multi-mode optical fiber interface with uplink redundancy; the port number is 4
and 8. The connector can select the SC or FC. The optical fiber interface should
be used in pair (TX and RX in pair), where, the TX interface is the optical
transmitting terminal which connects to the optical receiving terminal RX for the
optical interface of the remote switching, the RX is the optical receiving terminal
which connects to the optical transmitting terminal TX for the same optical
interface of the remote switch. It can take advantages of 2 pairs of 100Base-FX
optical fibers interfaces to form the optical fiber redundant ring network. The ring
network redundant recovery time is less than 300ms to improve the reliability of
the network operation effectively when the system failure occurs.
Ethernet RJ45 Port
