KYLAND Technology KIEN5000 User manual

KIEN5000/6000 Industrial Ethernet Switch
Dedicated Network Management
User’s Manual
Beijing KYLAND Telecom Technology Co., Ltd.

KIEN5000/6000 Industrial Ethernet Switch dedicated
Network Management User’s Manual
Copyright © 2009 Beijing KYLAND Telecom Technology CO., LTD.
All rights reserved.
No part of this documentation may be excerpted, reproduced, translated, annotated or
duplicated, in any form or by any means without the prior written permission of KYLAND
Corporation.
Beijing KYLAND Telecom Technology Co., Ltd.
Address: Chongxin Mansion No.4 Building, 2nd Floor, Xijing Road 3#,
Shijingshan District, Beijing,China
Website: http://www.kyland.cn
Postcode: 100041
Tel:[phone]
Fax: [phone]
E-mail: [email protected]
Version: v3, Feb. 2009

Preface
KIEN5000 and KIEN6000 is high-performance network-managed industrial Ethernet
switch specially designed by KYLAND Telecom Technology CO., LTD. for industrial
applications. Its high-performance switch engine, solid and closed case design,
high-efficient single-rib shape case heat dispersion surface without fans, over current,
over voltage and EMC protection at power input side, and excellent EMC protection of
RJ45 port allows KIEN5000 and KIEN6000 applicable in harsh and dangerous
industrial environments. The redundant function of optical fiber network, independent
entire network management channel, redundant power input function, and powerful
entire network real-time management system provides multiplex guarantee for reliable
operation of the system.
The KIEN5000/6000 Industrial Ethernet Switch Dedicated Network Management
User’s Manual mainly introduces the usage and operation of the network management
and local configuration software in the KIEN5000 and KIEN6000 industrial Ethernet
switch dedicated network management, and provides the reference for users to
commence, expand and routine maintain the system. At the same time, it applies to the
user training and learning for related technical personnel, so it is the practical teaching
material for mass users to learn about the KIEN5000 and KIEN6000 industrial
Ethernet switch-dedicated network management system.
This manual mainly includes the following contents:
Chapter 1 introduces general description and system features of KIEN5000 and
KIEN6000 industrial Ethernet switch;
Chapter 2 introduces Network Management Operation Process of KIEN5000 and
KIEN6000;
Chapter 3 introduces aggregate commands of KIEN5000 and KIEN6000;
Chapter 4 introduces WEB Network Management Operation Process of KIEN5000 and
KIEN6000;
This document can be used together with the KIEN5000 Industrial Ethernet
Switch-dedicated Network Management User’s Manual and the KIEN6000 Industrial

Ethernet Switch-dedicated Network Management User’s Manual.
Statement: For continuous update and perfection of the product and technology, the
contents of this material may not be consistent with the actual product, please contact
us about related contents. If it is necessary for you to query the latest information on
the product, please query our Website or contact with your local service representative
directly.

Safety Consideration
This product can provide excellent and reliable performance within its design scope.
However, it needs to avoid the damage or destroy by human reasons.
zRead this Manual thoroughly and keep it well for future reference.
zDo not place the Device next to the source of water and the damp place.
zDo not place anything on the power cable. Please place where it cannot be
reached.
zIn order to avoid fire, do not tie or pack the cable.
zThe connector of the power supply and other Device connection should be firmly
connected and regularly checked.
Under following conditions, please power off and contact with our company
immediately.
1. Water into Device;
2. The Device is broken or the crust is cracked.
3. The Device works abnormally or the performance provided has changed
completely.
4. The Device gives off odor, smoke or noise.
zPay attention to the cleanness of the fiber socket and jack. When the Device
operates, do not watch the end-face of the fiber directly.
zPay attention to the cleanness of the Device and clean it with soft cotton cloth if
necessary.
zDo not repair the Device by yourself unless it is definitely indicated in this
manual.

Description of Warning Mark:
This manual uses two kinds of obvious warning marks to prompt users that more
attention should be paid during operation. The meanings of these marks as follows:
Warning: The comment after this mark should be paid more attention, the
incorrect operation will cause the switch to be damaged seriously or it will
cause body injury for the operator.
Caution, Note and dangerous: Prompt where more attention should be
paid.

Content
Chapter One System Overview......................................................................................................5
1.1 Product overview ................................................................................................................5
1.2 Feature.................................................................................................................................5
1.3 Packing List and unpacking check......................................................................................7
Chapter Two Console Management ..............................................................................................8
2.1 Console ...............................................................................................................................8
2.1.1 Serial Port RS232 Console.......................................................................................8
2.1.2 Telnet console.........................................................................................................11
2.2 Console Management........................................................................................................12
2.2.1 Status and Counter .................................................................................................13
2.2.2 Switch Configuration.............................................................................................15
2.2.3 The Protocol Related Configuration.......................................................................31
2.2.4 Restart Switch........................................................................................................40
2.2.5 Command Line.......................................................................................................41
2.3 1K Xmodem software.......................................................................................................42
Chapter Three Command of Port Console.................................................................................43
3.1 System Configuration .......................................................................................................43
3.2 Switch Configuration——Advanced................................................................................43
3.3 Port Control.......................................................................................................................44
3.4 Trunking............................................................................................................................45
3.5 Filtering Data ....................................................................................................................46
3.6 VLAN................................................................................................................................47
3.7 Spanning Tree ...................................................................................................................48
3.8 Sniffer................................................................................................................................49
3.9 Table A..............................................................................................................................49
Chapter Four WEB Management................................................................................................50

4.1 WEB Network Management.............................................................................................50
4.2 Port Status.........................................................................................................................51
4.3 Port Statistics.....................................................................................................................52
4.4 Administrator ....................................................................................................................53
4.4.1 IPAddress ..............................................................................................................53
4.4.2 Configuration .........................................................................................................54
4.4.3 Console Information...............................................................................................57
4.4.4 Port Control............................................................................................................57
4.4.5 Aggregator..............................................................................................................58
4.4.6 Filter.......................................................................................................................60
4.4.7 VLAN.....................................................................................................................63
4.4.8 STP.........................................................................................................................67
4.4.9 Monitor Port...........................................................................................................69
4.4.10 SNMP...................................................................................................................70
4.4.11 Security ................................................................................................................71
4.5 TFTP software...................................................................................................................72
4.6 Backup ..............................................................................................................................72
4.6.1 TFTP Restore Configuration..................................................................................72
4.6.2 TFTP Backup Configuration..................................................................................73
4.7 Reset..................................................................................................................................73
4.8 Reboot...............................................................................................................................76

Chapter One System Overview
1.1 Product overview
KIEN5000 AND KIEN6000 are two kind of high-performance managed
industrial Ethernet switch specially designed by KYLAND Telecom
Technology CO., LTD. for industrial applications. Its high-performance
exchange engine, solid and closed case design, high-efficient single-rib shape
case heat dispersion surface without fans, over current, over voltage and EMC
protection at power input side, and excellent EMC protection of RJ45 port
allows KIEN5000 AND KIEN6000 applicable in harsh and dangerous
industrial environments. The redundant function of optical fiber network,
independent full network management channel, redundant power input
function, and powerful full network real-time management system provides
multiplex guarantee for reliable operation of the system.
KIEN5000 and KIEN6000 industrial Ethernet switch provide two mounting
ways, DIN rail and Wall-mounting.
On the front panel of KIEN5000, there are four uplink redundant
10Base-T/100Base-TX Ethernet RJ45 interfaces. The uplink redundant
Ethernet RJ45 can be used to form two twisted-pair redundant ring networks.
In the event of system failure, the recovery time of the redundant ring network
should be less than 300ms.
On the front panel of KIEN6000, there is two pair of 100Base-FX single
mode or multi-mode optical fiber interfaces. The uplink optical fiber
interfaces can be used to form an optical fiber redundant ring network. In the
event of system failure, the recovery time of the redundant ring network
should be less than 300ms.
KIEN5000 and KIEN6000 provide four 10Base-T/100Base-TX RJ45 ports.
Each RJ45 port has automatically adaptive function, capable of automatically
configuring to 10Base-T or 100Base-TX status and full duplex or half duplex
operation mode.
1.2 Feature
High-performance Industrial Ethernet Switch
1. 10/100Base-T/TX Ethernet ports, adaptive, full/half duplex, auto
MDI/MDI-X connection

2. 100Base-FX fiber ports, single mode/multimode, full duplex
3. High speed redundant ring with recovery time < 300ms
4. Supports VLAN to control broadcasting domain and segment flow.
5. Alarms relay output power supply and port link.
6. Broadcast storm control
Powerful Management Function
1. Integral management platform for the entire network based on RS232
standard. The management system is immune against the attack of virus or hacker
since the management channel is independent to service channel.
2. Special-designed management software for upper PC realizes the
auto-configuration of IP address for networking devices and auto-scan/spanning of
network topology.
3. Individual naming for each device in the network.
4. Setting and query of VLAN.
5. Setting and query for alarm of power and ports link.
6. Setting and query for port working mode, prioritization, and rate
Industrial Power
1. Industrial power input of DC24V（DC18V～36V）.
2. Reliable protection for EMC and against over-current/over-voltage.
3. Redundant power input.
Rugged Design
1. Ribbed heat-removal design (fan less); operation at -35℃to +75℃
2. Solid IP40 housing
3. Easy DIN-Rail mounting or optional wall-mounting

1.3 Packing List and unpacking check
１. Packing List
The packing case includes the following items:
KIEN5000 (or6000) 1 unit
3-coreDCpowerterminal 2pieces
2-corealarmingoutputterminal 1piece
User’s Manual for KIEN5000 (or6000) Industrial Ethernet Switch 1 copy
CustomerServiceGuideline 1copy
Ф3 grounding cold pressed terminal, M3×8 grounding screw 1 piece each
２. Unpacking check
Before opening the case, place it stably, pay attention to the direction of the
packing case, and ensure its right side is facing upward, so as to prevent
KIEN5000 AND KIEN6000 from falling apart after opening the case. If a hard
object is used to unclench the case, do not overly extend the hard object into
the case to avoid damage of the equipments inside the case.
After opening the case, check the amount of KIEN5000 AND KIEN6000
equipments (including main unit of KIEN5000 AND KIEN6000, parts of
equipment, user’s manual, customer service guideline) according to the
packing list, and check the appearance quality of KIEN5000 AND KIEN6000.
Warning:
For the built-in precise parts of equipments, please handle with care and avoid
strenuous vibration to avoid affecting the performances of equipments.

Chapter Two Console Management
2.1 Console Login
2.1.1 Login RS232 Serial Port Console
You can login the RS232 serial port console software from hyper terminal of
WINDOWS system, and realize the query, configuration and management in
KIEN5000/6000. If there is no such a software in the system, you can install it
from “Add/Delete Program”, afterwards, you can login as following:
1．To connect the RS232 console port of KIEN5000/6000 with PC’s serial
port(ex: COM1 or COM2 depending on the PC’s serial port hardware
and its occupation status.) by serial port cable (from RJ45 to
DB-9F/DB-25F).
2．Click “Star” Æ“All programs”Æ“Accessories”Æ“Communications” Æ
“Hyper Terminal”.
Figure2-1 Login Console Management
3．The following figure shows “New Connection” dialog box. For

example : “COMMON1” and then click“OK”.
Figure2-2 Connection
4．To select serial port according to the PC’s serial port hardware and its
occupation status. For example, to select “COM1” and click “OK”.
Figure2-3 Select port
5．As the following shows, to set the properties of “COM1”: Bits Per
Sedond:9600bps；Data bits:８；Parity: None；Stop bits:１；Flow Control:
None, click“OK”to enter the console interface.

Figure2-4 Port Setting
6．The console interface is shown as below. To enter Username: admin Æ
<Enter>; Password :123Æ<Enter>, and enter the main menu.
Figure2-5 Login Console
7．The main menu is shown as below, when in the menu, all operation
should be realized by the keyboard, the direction is as below:
Table2-1 Direction of Keyboard for menu
Key Function
<Tab>: Go to next item；
<Backspace>: Go to previous item；
<Enter>: Pitch on and enter the item；

<Space>: Convert current item’s configuration
<Ctrl>+A: Implement current operation
Figure2-6 RS232 Console Menu
2.1.2 Telnet console
You can also visit the console software of KIEN5000/6000 from network by
Telnet way. In this way, you need to connect any one of RJ45 ports of
KIEN5000/6000 with the Ethernet port in the network or the PC’s card by a
cross-over or straight-through copper cable. You can do as follows:
1. Windows Æ“Run” or MS-DOS command line, to enter the login page.
Figure2-7 Run Telnet
2. Username : adminÆ<Enter>, Password:123Æ<Enter>, KIEN5000 or
KIEN6000’s Telnet Console Management Main Menu.

Figure2-8 Login Telnet
3. The following figure shows the Main Menu, all operations are realized
by keyboard, whose detailed function is the same as RS232 console’s.
Figure2-9 Main Menu
2.2 Console Management
There are two kind of way login the Console Management, one is RS232
Console and another one is Telnet such as Figure 2-6 and Figure 2-9. Their
operations and functions are the same. So the following introductions to the
menus are for both managements.
Attention:

KIEN5000 and KIEN6000’s default IP address is192.168.0.2 , which can be
referred to the coding label on the device.
Do not apply the two ways: Telnet Console and RS232 Console at same
time!
Port 9 and 10 in the management is for the configuration of other products in
the system, you can make configuration in the available items and ignore if
any is not available.
2.2.1 Status and Counter
The following figure shows “Status and Counter”.
Figure2-10 Status and Counters
1. Port Status
The page of port status is shown as below, it shows the status of each
port.

Figure2-11 Port Status
Table2-2 Port Status
Entry Description
Type Type of Port.
Enabled It’s enabled or disabled according to user
configuration.
Status Shows port connected or disconnected..
Mode Shows port rate and duplex mode.
FlowCtrl Shows flow control enabled or disabled.
2. Port Counter
The following page shows device’s communication status.
Figure2-12 Port Counter

3. System Information
The following page shows the software and hardware information of
current system.
Figure2-13 Management Address Information
2.2.2 Switch Static Configuration
“Switch Configuration” Æ<Enter>.
“Switch Configuration” Æ“Administration Configuration”、“Port/Trunk
Configuration”、“Port Mirroring Configuration”、“VLAN Configuration”、
“Priority Configuration”、“MAC Address configuration”、“Misc
Configuration”. You can select item using by <Tab> and <Backspace>. The
seven next menus is introduced as following:
Figure2-14 Switch Configuration

2.2.2.1 Administration Configuration
“Switch Configuration” Æ“Administration Configuration” Æ<Enter>. It’s
including “Device Information”、“IP Configuration”、“Change
Username”、“Change Password”、“MAC Configuration”.
Figure2-15 Device Configuration
1．Device Information
The following figure shows device information. It’s including Device
Name, Device Content, device Location, and Device description.
Figure2-16 Device Information
2．IP configuration
The following figure shows IP configuration. It’s including IP
Address、Subnet Mask、Gateway.
