Kyocera FS-1920 Ecosys User manual

FS-1920
Page Printer
Installation Guide
FS-1920IG.book 1 ページ ２００４年１月１５日 木曜日 午前１０時２１分

Caution
No liability is assumed for any damage caused by improper installation.
Notice on Software
Software used with this printer must support the printer’s emulation mode. The printer is factory-set to emulate
the HP PCL 6. The emulation mode can be changed by following the procedures described in the Operation
Guide contained as an electronic file in the CD-ROM supplied with the printer.
Notice
The information in this manual is subject to change without notification. Additional pages may be inserted in
future editions. The user is asked to excuse any technical inaccuracies or typographical errors in the present
edition.
No responsibility is assumed if accidents occur while the user is following the instructions in this manual. No
responsibility is assumed for defects in the printer’s firmware (contents of its read-only memory).
This manual, any copyrightable subject matter sold or provided with or in connection with the sale of the page
printer, are protected by copyright. All rights are reserved. Copying or other reproduction of all or part of this
manual, any copyrightable subject matter without the prior written consent of Kyocera Mita Corporation is pro-
hibited. Any copies made of all or part of this manual, any copyrightable subject must contain the same copy-
right notice as the material from which the copying is done.
Table of Contents
STEP 1 Unpacking ......................................................................... 1
STEP 2 Positioning the Printer ..................................................... 2
STEP 3 Installing the Toner Container ......................................... 3
STEP 4 Installing the Waste Toner Box........................................ 5
STEP 5 Connecting the Printer to the Computer ........................ 7
STEP 6 Connecting the Power Cord ............................................ 9
STEP 7 Adding Paper to the Paper Cassette and MP Tray....... 10
STEP 8 Turning the Power Switch On ........................................ 18
STEP 9 Printing a Status Page.................................................... 19
©2003, 2004 by KYOCERA MITA CORPORATION All rights reserved.
Revision 1.1 January 2004
FS-1920IG.book 1 ページ ２００４年１月１５日 木曜日 午前１０時２１分

1
Unpacking
Carefully remove the printer and other items from the box. Check that nothing is miss-
ing against the list of shipped components below.
List of Shipped Components
STEP
1
Printer
(E)
(D)
(A)
(B)
(F)
(C)
(for
U.S.A.
only)
Printer
Power Cord (F)
Installation Guide
[this booklet] and
other printed matter
(B)
CD-ROMs (B)
Waste Toner
Box (E)
To n e r
Container (D) Plastic Bag for
Developer Unit (A)
Dust Cover (C)
[for U.S.A. only]
FS-1920IG.book 1 ページ ２００４年１月１５日 木曜日 午前１０時２１分

2
Positioning the Printer
Make sure that the place of installation meets the following requirements:
Clearance
Be sure to secure enough space
around the printer. Prolonged
usewithout sufficientclearance
may cause heat to build up
within the printer, resulting in
fire.
Environment
Do not install the printer where temperature or humidity is outside the rec-
ommended range. Print quality may suffer and there will be an increased
chance of paper jams.
Places to Avoid
Avoid installing the printer in locations subject to:
• Direct drafts of hot or cold air
• Direct drafts from outside (Avoid locations near building entrances.)
• Sudden temperature or humidity changes
• Sources of high temperature, for example, near stoves or radiators
• Excessive dust
•Vibration
• Unstable surfaces and surfaces that are not level
• Ammonia or other harmful fumes (If you are planning to fumigate the room, or
make liberal use of insecticide, remove the printer first!)
• Excessive sunlight or humidity
• Lack of ventilation
• Low air pressure, e.g., elevations greater than 2000 meters (6500 feet) above
sea level
Te m p e r a t u r e 10 to 32.5 °C (50 to 90.5 °F), ideally about 23 °C (73.4 °F)
Humidity 20 to 80 %, ideally 60 %
STEP
2
30 cm (11-13/16 inches)
25 cm
(9-7/8
inches)
60 cm
(23-5/8
inches)
30 cm
(11-13/16
inches)
20 cm (7-7/8 inches)
[40 cm (15-3/4 inches) when the option
rear tray is installed]
FS-1920IG.book 2 ページ ２００４年１月１５日 木曜日 午前１０時２１分

3
Installing the Toner Container
Before you can use the printer for the first time, you must prepare it by installing the
toner container, waste toner box, and set up the interfacing with the computer.
1Open the printer top cover all the way.
2Take the toner container from the bag.
3With the label side down, thoroughly
shake the toner container (in the direc-
tion of the arrow) ten times or more to
loosen and mix the toner inside.
4Carefully remove the protective seal.
5Install the toner container into the
printer.
STEP
3
Top Cover
Toner Container
10 times or
more
Protective Seal
FS-1920IG.book 3 ページ ２００４年１月１５日 木曜日 午前１０時２１分

4
6Push firmly on the top of the toner con-
tainer at the positions marked PUSH
HERE.
When thetonercontainer fits into place,
it will lock with a clicking sound.
7Close the top cover.
To remove the toner container
Pull the lock lever (blue colored) to the
right and gently lift the toner con-
tainer.
Lock Lever
FS-1920IG.book 4 ページ ２００４年１月１５日 木曜日 午前１０時２１分

5
Installing the Waste Toner Box
The waste toner box is supplied with the printer. The waste toner box must be installed
in the printer.
1Open the cap of the waste toner box.
2Open the left cover on the left side of the
printer.
3Insert the waste toner box as shown in
the figure. The box will be locked when
it fits into place.
STEP
4
Cap
Waste Toner
Box
Left Cover
FS-1920IG.book 5 ページ ２００４年１月１５日 木曜日 午前１０時２１分

6
4Ensuring that it is correctly inserted,
close the left cover.
To remove the Waste Toner Box
While holding the waste toner box,
press the lock lever and then gently
remove the waste toner box.
Lock Lever
FS-1920IG.book 6 ページ ２００４年１月１５日 木曜日 午前１０時２１分

7
Connecting the Printer to the Computer
There are various ways of connecting the printer to the computer, such as through the
parallel interface connector, through the USB (Universal Serial Bus) interface connec-
tor, through the option serial interface board kit (IB-11) or through the option network
interface card.
Printer Connections
Before performing this step, be sure to turn off both the printer and the com-
puter’s power switches and unplug the printer’s power plug from the power
outlet. Failure to do so may result in electrical shock.
The standard Centronics parallel interface connector ( ) and USB interface
connector ( ) are located on the rear of the printer.
STEP
5
Printer (Rear)
Parallel Interface
Network Option Network
Interface Card
(3.3 V DC)
Serial Interface
Power Supply
Connector for option sorter
(See the option sorter’s
user’s manual.)
USB Interface
Option Serial Interface
Board Kit (3.3 V DC)
FS-1920IG.book 7 ページ ２００４年１月１５日 木曜日 午前１０時２１分

8
Parallel Interface Connection
1Plug one end of the printer cable (not
included) into the parallel interface con-
nector on the rear of the printer.
• Use a parallel printer cable
that complies with the
IEEE1284 standards.
• The printer will work best if it
is installed near the coputer.
The connecting cable should
be shielded and not be longer
than 3 meters (10 feet).
2Close the clips on both sides to fix the
connector in place.
Plug the other end of the printer cable
into the computer’s parallel interface
connector.
USB (Universal Serial Bus) Interface Connection
1Plug one end of the USB cable on the
rear of the printer.
• Use a cable that complies
with Revision 2.0 of USB stan-
dard.(a rectangular Type A
plug and a square Type B
plug).
• The connecting cable should
be shielded and not be longer
than 5 meters (16 feet).
2Plug the other end of the USB cable into
the computer’s USB interface connec-
tor.
Parallel Printer
Cable
Clip Clip
USB Cable
FS-1920IG.book 8 ページ ２００４年１月１５日 木曜日 午前１０時２１分

9
Connecting the Power Cord
This section describes the procedure for connecting the power cord and various cau-
tions.
Notes on Power Supply
• Install the printer near an AC wall outlet, preferably one that can be used for
the printer alone.
• Only use this printer with the supply voltage indicated on the serial number
label attached to the printer’s rear panel.
• If an extension cord is used, the total length of the power cord plus extension
should be 5 meters (16 feet) or less.
Power Requirements
To Connect the Power Cord
• Be sure the printer’s power switch is turned off.
• Only use the power cord supplied with the printer.
1Plug the power cord into the power cord
connector on the rear of the printer.
2Connect the other end of the power cord
into a power outlet.
Be sure to connect to a 3-wire
grounded power strip.
Voltage 120 V (U.S.A. and Canada), 220 to 240 V(European countries,
and the Asia Pacific region), ±10 % at each voltage
Frequency 60 Hz (120 V) ±2 %, 50/60 Hz (220 to 240V) ±2 %
Current capacity
8.0A at 120 V, or 3.9A at 220 to 240 V
STEP
6
Power Cord
Connector
Power Cord
FS-1920IG.book 9 ページ ２００４年１月１５日 木曜日 午前１０時２１分

10
Adding Paper to the Paper Cassette and MP
Tray
The paper cassette can accommodate A5 to A4/Letter and Legal (for U.S.A. only) size
paper and can hold approximately 500 sheets. The MP (Multi Purpose) tray can
accommodate the various paper sizes and can hold approximately 100 sheets of
paper.
Paper sizes that are not standard sizes (other sizes) but within the size limitations
can also be loaded into the cassette. When loading othersizes into the cassette, the
size must be input into the printer on the operator panel (Refer to the Operation
Guide [PDF file] provided on the CD-ROM). Standard size paper settings are indi-
cated as fixed positions in the cassette.
The following paper weights can be used with the printer.
The edges of paper are sharp. When loading paper, be careful not to cut
your hand on the paper.
Paper cassette
Standard paper sizes are attached to the inside of the paper cassette as shown in
the following figure. Align the paper guides and paper stopper to the paper size
you want to print on as described on the next page.
Paper source Paper weight
Paper cassette 60 to 105 g/m²
MP tray 60 to 200 g/m²
STEP
7
A4
B5
A5
Letter
FS-1920IG.book 10 ページ ２００４年１月１５日 木曜日 午前１０時２１分

11
1Pull the paper cassette all the way out of
the printer.
2Push the bottom plate down until it
locks.
Standard paper sizes are attached to
the inside of the paper cassette as
shown in the following figure. In the
paper cassette for U.S.A., Legal size
indication is also attached.
Paper Cassette
Bottom Plate
FS-1920IG.book 11 ページ ２００４年１月１５日 木曜日 午前１０時２１分

12
3Turn the paper size dial so that the size
of the paper you are going to use
appears in the paper size window.
When the paper size dial is set
to OTHER the paper size must
be set into the printer on the
operator panel. See the Opera-
tion Guide (PDF file) provided
on the CD-ROM.
4Adjust the position of the paper guides
located on the left and right sides of the
paper cassette. Pull the release lever on
the left side guide and slide to the
desired paper size.
5Adjust the position of the paper stopper
located at the rear of the paper cassette.
Pull the release lever and slide the
paper stopper to the desired paper size.
When shipped from the factory, the
paper cassette is set to A4 size.
When using other size paper, move the
paper guides and paper stopper all the
way out, insert the paper, then adjust
the paper guides and paper stopper to
the size of the paper. Adjust them so
that they are in light contact with the
paper.
Paper Size Dial Paper Size Window
Release
Paper Guides

Release
Paper
Stopper
FS-1920IG.book 12 ページ ２００４年１月１５日 木曜日 午前１０時２１分

13
Fan the media (paper/transpar-
encies), then tap it on a level
surface to avoid media jams or
skewed printing.
6Slide the paper into the paper cassette.
• Do not load more paper than
will fit under the load limits on
the paper guides.
• The paper cassette will hold
approximately 500 sheets of
paper with a 80 g/m² (21 lb.)
basis weight, or with a thick-
ness of 0.11 mm.
7Set the stack of paper so that it is under
the clips as shown.
Load Limit Load Limit
Clip Clip
FS-1920IG.book 13 ページ ２００４年１月１５日 木曜日 午前１０時２１分

14
8Insert the paper cassette into the slot in
the printer. Push it straight in as far as
it will go.
There is a paper gauge on the right
side of the front of the paper cassette
to indicate the remaining paper
supply. When paper is exhausted, the
pointer
will go down to the level of
(empty).
9If you have installed a paper cassette
that can hold the Legal size paper,
install the dust cover at the back of the
printer. (The Legal size cassette and the
dust cover are supplied for U.S.A. only.)
Removing the Dust Cover
Paper Gauge
FS-1920IG.book 14 ページ ２００４年１月１５日 木曜日 午前１０時２１分

15
MP (Multi Purpose) tray
1Pull the MP tray towards you until it
stops.
2Pull out the subtray.
3Adjust the position of the paper guides
on the MP tray. Standard paper sizes
are attached to the MP tray. For stan-
dard paper sizes, slide the guides to the
position marked correspondingly.
4Align the paper with the paper guides
and insert as far as it will go.
Do not load more paper than
will fit under the load limits on
the inside of the MP tray.
MP Tray
A4
LTR B5 A5
Paper Guides
Load Limit
FS-1920IG.book 15 ページ ２００４年１月１５日 木曜日 午前１０時２１分

16
If the paper is considerably curled in one direction, for example, if the
paper is already printed on one side, try to roll the paper in the opposite
direction to counteract the curl. Printed sheets will then come out flat.
To Close the MP Tray
Before closing the MP Tray, ensure the
subtray is pushed back in, and the
paper guides are opened as far as they
will go.
Envelopes
Envelopes should be fed in the face-up position, right edge first.
• Test a sample envelope on the printer and check that printing quality is
satisfactory before purchasing.
• To avoid trouble, we recommend that envelopes be delivered face-up
using the option rear tray. Refer to next page.
Sometypesofenvelopesare not suitable
for printing. For details on suitable
types of envelopes, see the Operation
Guide contained as a PDF file in the CD-
ROM supplied with the printer.
Correct
Incorrect
FS-1920IG.book 16 ページ ２００４年１月１５日 木曜日 午前１０時２１分

17
Installing the Option Rear Tray
Use the rear tray when you wish paper to be stacked with the printed side facing
up (reverse order), or when you are printing on envelopes, postcards, transparen-
cies, or thick paper.
This rear tray is a separate option.
Legal Size
A4 Size
Letter Size
Paper Stopper
Rear Tray
FS-1920IG.book 17 ページ ２００４年１月１５日 木曜日 午前１０時２１分

18
Turning the Power Switch On
This section describes the procedure for turning on the printer’s power.
During start-up, the language for the message display and status page of this printer
can be selected from English, French, German, Italian, Dutch, Spanish, and Portu-
guese.
The default message language is English. For how to change the message lan-
guage to another, refer to the Selecting a Message Language section.
1Switch on the printer’s power. The mes-
sage display should indicate Self
test.
If the indicator does not light,
check that previous steps were
performed properly.
When the printer is first switched
on after installation, there will be a
delay of approximately 8 minutes
before the printer gets ready to
print as the developer unit needs to
be filled with toner. During this
period, the message display shows
Please wait (Adding toner).
2Wait until the READY ( ) indicator is
also lit and the message display indi-
cates Ready. The printer is ready to
print.
Selecting a Message Language
The default message language is English. To change the message language to
another, follow the procedure described below. If required, your dealer can down-
load major languages other than English, French, German, Italian, Dutch, Span-
ish, and Portuguese to your printer. Please contact your dealer.
1Whilepressingthe ENTER key, turn the
power switch ON ( l). Keep pressing the
ENTER key until the message display
indicates Please wait (approximately
1 minute). The message display should
indicate Self test.
2When the message display shows
Please wait, release the ENTER key.
STEP
8
Power Switch
Ready
--- A4 PLAIN
GO
CANCEL MENU ENTER
?
Please wait
FS-1920IG.book 18 ページ ２００４年１月１５日 木曜日 午前１０時２１分
