FS-1020D
Page Printer
Installation Guide
Ifs1020ep-eng.book 1 ページ ２００３年９月３日 水曜日 午後４時４７分

Caution
NO LIABILITY IS ASSUMED FOR ANY DAMAGE CAUSED BY IMPROPER INSTALLATION.
Notice on Software
SOFTWARE USED WITH THIS PRINTER MUST SUPPORT THE PRINTER'S EMULATION
MODE. The printer is factory-set to emulate the HP PCL 6. The emulation mode can be changed by
following the procedures described in the Operation Guide contained as an electronic file in the
Kyocera Mita Document Library CD-ROM supplied with the printer.
Notice
The information in this manual is subject to change without notification. Additional pages may be
inserted in future editions. The user is asked to excuse any technical inaccuracies or typographical
errors in the present edition.
No responsibility is assumed if accidents occur while the user is following the instructions in this
manual. No responsibility is assumed for defects in the printer's firmware (contents of its read-only
memory).
This manual, any copyrightable subject matter sold or provided with or in connection with the sale
of the page printer, are protected by copyright. All rights are reserved. Copying or other reproduc-
tion of all or part of this manual, any copyrightable subject matter without the prior written consent
of Kyocera Corporation is prohibited. Any copies made of all or part of this manual, any
copyrightable subject must contain the same copyright notice as the material from which the copy-
ing is done.
Table of Contents
STEP 1 Unpacking .......................................................................1
STEP 2 Positioning the Printer....................................................3
STEP 3 Installing the Toner Container........................................4
STEP 4 Connecting the Printer to the Computer .......................7
STEP 5 Connecting the Power Cord...........................................9
STEP 6 Adding Paper to the Paper Cassette and MP Tray......10
STEP 7 Printing a Status Page..................................................17
©2003 by KYOCERA MITA CORPORATION All rights reserved. Revision 1.0., September 2003
Ifs1020ep-eng.book 1 ページ ２００３年９月３日 水曜日 午後４時４７分

1
-
Unpacking
Carefully remove the printer and other items from the box. Check that nothing is miss-
ing against the list of shipped components below.
List of Shipped Components
STEP
1
Printer
Power Cord (D)
Toner Container [TK-18] (B)
Installation Guide [this booklet] (A)
CD-ROMs (A)
Cleaning Cloth (A)
Printer
(C)
(B)
(D)
(A)
Extension Tray (C)
[for U.S.A. only]
Ifs1020ep-eng.book 1 ページ ２００３年９月３日 水曜日 午後４時４７分

2
Removing Shipping Material
Remove the tape on the rear side of the printer, and remove the protective packing
from the paper cassette.
Ta p e
Protective Packing
Ifs1020ep-eng.book 2 ページ ２００３年９月３日 水曜日 午後４時４７分

3
Positioning the Printer
Make sure that the place of installation meets the following requirements:
Clearance
Be sure to secure enough space
around the printer. Prolonged
use without sufficient clearance
may cause heat to build up
within the printer, resulting in
fire.
Environment
Do not install the printer where temperature or humidity is outside the rec-
ommended range. Print quality may suffer and there will be an increased
chance of paper jams.
Places to Avoid
Avoid installing the printer in locations subject to:
• Direct drafts of hot or cold air
• Direct drafts from outside (Avoid locations near building entrances.)
• Sudden temperature or humidity changes
• Sources of high temperature, for example, near stoves or radiators
•Excessivedust
•Vibration
• Unstable surfaces and surfaces that are not level
• Ammonia or other harmful fumes (If you are planning to fumigate the room, or
make liberal use of insecticide, remove the printer first!)
• Excessive sunlight or humidity
• Lack of ventilation
• Low air pressure, e.g., elevations greater than 2000 meters (6500 feet) above
sea level
Te m p e r a tu r e 10 to 32.5 °C (50 to 90.5 °F), ideally about 23 °C (73.4 °F)
Humidity 20 to 80 %, ideally 60 %
STEP
2
30 cm (11-13/16 inches)
40 cm
(15-3/4
inches)
25 cm
(9-7/8
inches)
50 cm
(19-11/16
inches)
25 cm (9-7/8
inches)
Ifs1020ep-eng.book 3 ページ ２００３年９月３日 水曜日 午後４時４７分

4
Installing the Toner Container
Before you can use the printer for the first time, you must set up the printer by installing
the toner container and interfacing with the computer.
1Open the printer top cover all the way.
2Confirm that the lock lever is in the
release (UNLOCK) position. If not, pull it
forward until it is in the release posi-
tion.
3Take the toner container from the bag.
Hold it with the protective seal (orange-
colored) facing up. Shake the toner con-
tainer horizontally at least 5 times. This
ensures that the toner is evenly distrib-
uted inside.
STEP
3
Ifs1020ep-eng.book 4 ページ ２００３年９月３日 水曜日 午後４時４７分

5
4Carefully remove the protective seal.
5Install the toner container into the
printer.
6Push firmly on the top of the toner con-
tainer at the positions marked PUSH
HERE.
Ifs1020ep-eng.book 5 ページ ２００３年９月３日 水曜日 午後４時４７分

6
7Push the lock lever to the lock (LOCK)
position.
8Close the top cover.
To remove the toner container
Pull the lock lever #1 to the release
(UNLOCK) position, pull the lock lever
#2, then gently remove the toner con-
tainer.
LOCK
UNLOCK
LOCK
UNLOCK
Lock Lever #2
Lock Lever #1
Ifs1020ep-eng.book 6 ページ ２００３年９月３日 水曜日 午後４時４７分

7
Connecting the Printer to the Computer
There are various ways of connecting the printer to the computer, such as throughthe
parallel interface connector, through the USB (Universal Serial Bus) interface connec-
tor, through the optional serial interface board kit (IB-11) or through the optional net-
work interface board.
Printer Connections
Before performing this step, be sure to turn off both the printer and the com-
puter’s power switches and unplug the printer’s power plug from the power
outlet. Failure to do so may result in electrical shock.
The standard Centronics parallel interface connector and USB interface connec-
tor are located on the rear of the printer.
STEP
4
Printer (Rear)
Optional Serial Interface
Board kit (IB-11)
Parallel Interface
Network
Optional Network
Interface Board
(DC 3.3V)
Serial Interface
Power Supply
USB
Interface
Ifs1020ep-eng.book 7 ページ ２００３年９月３日 水曜日 午後４時４７分

8
Parallel Interface Connection
1Plug one end of the printer cable (not
included) into the parallel interface con-
nector on the rear of the printer.
• Use a parallel printer cable
that complies with the
IEEE1284 standards.
• The printer will work best if it
is installed near the computer.
The connecting cable should
be shielded and not be longer
than 3 meters (10 feet).
2Close the clips on both sides to fix the
connector in place.
Plug the other end of the printer cable
into the computer’s Centronics paral-
lel interface connector.
USB (Universal Serial Bus) Interface Connection
1Plug one end of the USB cable on the
rear of the printer.
•Useacablethatcomplies
with Revision 2.0 of USB stan-
dard (a rectangular Type A
plug and a square Type B
plug).
• The connecting cable should
be shielded and not be longer
than 5 meters (16 feet).
2Plug the other end of the USB cable into
the computer’s USB interface connec-
tor.
To p r i n t e r
Clips
Printer Cable
To p r i n t e r
USB Cable
Ifs1020ep-eng.book 8 ページ ２００３年９月３日 水曜日 午後４時４７分

9
Connecting the Power Cord
This section describes the procedure for connecting the power cable and various
cautions.
Notes on Power Supply
• Install the printer near an AC wall outlet, preferably one that can be used for
the printer alone.
• Only use this printer with the supply voltage indicated on the serial number
label attached to the printer’s rear panel.
• If an extension cord is used, the total length of the power cord plus extension
should be 5 meters (16 feet) or less.
Power Requirements
To Connect the Power Cord
• Be sure the printer’s power switch is turned off.
• Only use the power cord supplied with the printer.
1Plug the power cord into the power cord
connector on the rear of the printer.
2Connect the other end of the power cord
into a power outlet.
Be sure to connect to a 3-wire
grounded power strip.
Voltage 110 V, 120 V, 220 to 240 V, ±10 % at each voltage
Frequency 60 Hz (110 V, 120 V) ±2 %, 50/60 Hz (220 to 240 V) ±2 %
Current capacity Max. 6.5 A at 110 V, max. 7.1 A at 120 V, or max. 3.8 A at 220 to 240 V
STEPSTEP
5
Power Cord
Power Cord
Connector
Ifs1020ep-eng.book 9 ページ ２００３年９月３日 水曜日 午後４時４７分

10
Adding Paper to the Paper Cassette and
MP Tray
The paper cassette can accommodate A5 to Legal size paper and can hold approxi-
mately 250 sheets. The Multi-Purpose tray can accommodate the various paper sizes
and can hold approximately 50 sheets of paper.
The following paper weights can be used with the printer.
The edges of paper are sharp. When loading paper, be careful not to cut
your hand on the paper.
Paper cassette
Standard paper sizes are attached to the inside of the paper cassette as shown in
the following figure. Align the paper guides and paper stopper to the paper size
you want to print on as described on the next page.
Paper source Paper weight
Paper cassette 60 to 105 g/m²
MP tray 60 to 163 g/m²
STEP
6
A4
B5
A5
Ifs1020ep-eng.book 10 ページ ２００３年９月３日 水曜日 午後４時４７分

11
1Pull the paper cassette all the way out of
the printer.
2Adjust the position of the paper stopper
located at the rear of the paper cassette.
Press inthe releasebutton and slide the
stopper to the desired paper size. When
shipped from the factory, the paper cas-
sette is set to either A4 or Letter size.
In order to load either Folio or
Oficio II size paper into the
paper cassette, refer to Adjust-
ing the paper stopper for Folio
and Oficio II sizes on page 14
and adjust the paper stopper.
3Adjust the position of the paper guides
located on the left and right sides of the
paper cassette. Press in the release but-
ton on the left side guide and slide to the
desired paper size.
When using custom size paper, move
the paper guides and paper stopper all
the way out, insert the paper, then
adjust the paper guides and paper
stopper to the size of the paper. Adjust
them so that they are in light contact
with the paper.
The printer does not automati-
cally detect the size of the paper
loaded into the paper cassette
or MP tray. As a result, when-
ever you load paper having a
different size, you must adjust
the paper size. For details,
refer to the Operation Guide
contained as an electronic file
in the CD-ROM supplied with
the printer.
Release Button
Paper Stopper
Paper Guide
Release Button
Ifs1020ep-eng.book 11 ページ ２００３年９月３日 水曜日 午後４時４７分

12
Fan the media (paper/transpar-
encies), then tap it on a level
surface to avoid media jams or
skewed printing.
4Slide the paper into the paper cassette.
Do not load more paperthan will
fit under the load limits on the
top of the paper guides. (the
paper cassette will hold approx-
imately 250 sheets of paper with
a 80 g/m² (21 lb.) basis weight,
or with a thickness of 110
microns.)
5Insert the paper cassette into the slot in
the printer. Push it straight in as far as
it will go.
Load Limit
Ifs1020ep-eng.book 12 ページ ２００３年９月３日 水曜日 午後４時４７分

13
To u se la rg e s i z e p a p e r
Be sure to open the paper stopper
when printing onto A4 or Letter size
paper.
When printing onto paper of a size
larger than A4 or Letter, be sure to
open the paper stopper, and then open
the subtray as well.
When printing onto Legal size paper,
install the extension tray that is
included with your printer onto the
paper stopper. (The extension tray is
supplied for U.S.A. only.)
Paper Stopper
Extension Tray
Subtray
Ifs1020ep-eng.book 13 ページ ２００３年９月３日 水曜日 午後４時４７分

14
Adjusting the paper stopper for Folio and Oficio II
sizes
Perform the following procedure in order to adjust the paper stopper when loading
Folio and Oficio II size paper into the paper cassette.
1Remove the stopper extension lockfrom
the paper stopper.
2Slide the paper stopper back until the
edge of the cut out portions (1) of the
paper stopper are aligned with the back
edge of the paper cassette.
3Insert the stopper extension lock into
the holes in the paper stopper.
4To secure the stopper extension lock in
place, press down on the lock and slide
the paper stopper back slightly. The
paper stopper will be fixed in place for
Folio and Oficio II size paper.
Stopper
Extension
Lock
(1)
Ifs1020ep-eng.book 14 ページ ２００３年９月３日 水曜日 午後４時４７分

15
Multi-Purpose (MP) tray
1Pull the MP tray towards you until it
stops.
2Pull out the subtray and unfold the flap.
3Adjust the position of the paper guides
on the MP tray. Standard paper sizes
are attached to the MP tray. For stan-
dard paper sizes, slide the guides to the
position marked correspondingly.
• Do not load more paper than
will fit under the load limits on
the inside of the MP tray.
• If the paper is considerably
curled in one direction, for
example, if the paper is
already printed on one side,
try to roll the paper in the
opposite direction to counter-
act the curl. Printed sheets
will then come out flat.
Subtray
Flap
Correct
Incorrect
Ifs1020ep-eng.book 15 ページ ２００３年９月３日 水曜日 午後４時４７分

16
Envelopes
Envelopes should be fed in the face-up position, right edge first.
Test a sample envelope on the printer and check that printing quality is sat-
isfactory before purchasing.
Some types of envelopes are not suit-
able for printing. For details on suit-
able types of envelopes, see the
Operation Guide contained as an elec-
tronic file in the CD-ROM supplied
with the printer.
To close the MP tray
Close the flap on the subtray, then push in the subtray and close the MP tray.
Be careful not to push the tray
back into the printer with the
subtray folded out horizon-
tally as shown in the figure.
No
Ifs1020ep-eng.book 16 ページ ２００３年９月３日 水曜日 午後４時４７分

17
Printing a Status Page
To test the printer, print a status page indicating factory settings.
1Turn on the printer’s power switch.
Upon turning on the power, the
printer’s 4 indicators flash in sequence
until printer initialization is complete,
then the indicator ( [on line]) lights
steadily.
If the indicator does not light,
check that previous steps were
performed properly.
If you install the toner container and
turn on the power, after a moment the
indicators light in sequencefrom top to
bottom. When the printer is first
switched on after toner installa-
tion, there will be a delay of
approximately 15 minutes before
the printer gets ready to print.
Once the indicator lights, printer
installation is complete.
2The printer can print two different
types of status page — standard and
service-purpose. A service-purpose sta-
tus page contains more detailed infor-
mation about printer settings than a
standard status page.
• To print a standard status page, press
the key for at least 3 seconds and
the indicators light in sequence from
top to bottom.
• To print a service-purpose status
page, press the key for more than
10 seconds and the indicators light in
sequence twice from top to bottom.
If the status page prints correctly,
printer setup is complete. For details
on using the printer, refer to the Oper-
ation Guide contained as an electronic
file in the CD-ROM supplied with the
printer.
STEP
7
Ifs1020ep-eng.book 17 ページ ２００３年９月３日 水曜日 午後４時４７分

18
Correcting a Paper Jam
If a paper jam occurs while you are printing, remove the jammed paper as
described below. After you have removed the jammed paper, open and close the
top cover once.
Jam at the Face-down Tray and the Rear Cover
Open the rear cover and remove the
jammed paper as shown in the figure.
Jam at the Paper Cassette
Pull out the paper cassette and remove
the jammed paper.
Jam at the Duplexer
1Open the rear cover and remove the jammed
paper as shown in the figure.
Rear Cover
Paper Cassette
Rear Cover
Ifs1020ep-eng.book 18 ページ ２００３年９月３日 水曜日 午後４時４７分
