Kyocera TASKalfa 3051ci User manual

Legal Notes
Unauthorized reproduction of all or part of this guide is prohibited.
The information in this guide is subject to change without notice.
We cannot be held liable for any problems arising from the use of this product, regardless of the information herein.
Regarding Trademarks
KYOCERA Net Admin is a trademark of KYOCERA Document Solutions Inc.
Microsoft®, Windows®, and Internet Explorer are registered trademarks of Microsoft Corporation in the U.S. and/or other
countries.
All other brand and product names herein are registered trademarks or trademarks of their respective companies.
Examples of the operations given in this guide support the Microsoft Windows Server 2008 R2 printing environment.
Essentially the same operations are used for Microsoft Windows XP, Vista, and Windows 7 environments.
The features described in this guide vary depending on your device model.
© 2013 KYOCERA Document Solutions Inc.

Table of Contents
Chapter 1 Installation
System Requirements ................................................................................................................... 1-1
Upgrade KYOCERA Net Admin .................................................................................................... 1-2
Creating a Backup of Earlier Versions ..................................................................................... 1-3
Installing the New Version 3.x ................................................................................................. 1-3
Restoring a Database in Version 3.x ....................................................................................... 1-3
Restore Files Manually ............................................................................................................ 1-4
Server Installation ......................................................................................................................... 1-4
Installing KYOCERA Net Admin .............................................................................................. 1-4
PostgreSQL Files .................................................................................................................... 1-5
Uninstalling KYOCERA Net Admin .......................................................................................... 1-5
Removing PostgreSQL Files ................................................................................................... 1-6
Remote Agent Installation ............................................................................................................. 1-6
RPC Connections for Remote Agent Installation ..................................................................... 1-6
Stand-alone Agent Installation ................................................................................................. 1-7
USB Device Connections .............................................................................................................. 1-8
Connecting a USB device ........................................................................................................ 1-9
Local Device Agent Installation ............................................................................................... 1-9
Installing a Local Device Agent ................................................................................................ 1-9
Multi-Set Template Editor Installation .......................................................................................... 1-10
Installing the Multi-Set Template Editor ................................................................................. 1-10
KYOCERA Net Admin Login ....................................................................................................... 1-10
Starting and Logging In ......................................................................................................... 1-11
KYOCERA Net Admin 3.1 i

1 Installation
The KYOCERA Net Admin installation consists of two main software
components or consoles: Administration and Device Manager. The KYOCERA
Net Admin Agent and Multi-Set Template Editor are included in the installation,
and are also available as separate installers along with the Local Device Agent
(LDA). The KYOCERA Net Admin Agent and Multi-Set Template Editor can be
installed locally or remotely at multiple sites.
The Administration console lets you manage user accounts and roles, user
subscriptions, network discovery, and system settings. The Device Manager
console lets you manage device data, reports, polling, alerts, and preferences.
The KYOCERA Net Admin Agent is a service that communicates network
device information to KYOCERA Net Admin. The LDA is a service that
communicates information about USB-connected Kyocera devices on a
network. The Multi-Set Template Editor lets you create or change settings
templates.
Required third party software, Java 2 SDK and PostgreSQL is provided.
Microsoft .NET Framework 4.0 or later is needed to install KYOCERA
NetAdmin, Agent, Local Device Agent (LDA) and Multi-SetTemplate Editor.
System Requirements
Supported Operating Systems
Microsoft Windows® Server 2003/2008 R2 any Service Pack
Microsoft Windows® XP Professional 32 bit with Service Pack 3 or higher
Microsoft Windows® XP Professional 64 bit with Service Pack 2 or higher
Windows Vista™ 32 bit any Service Pack
Windows Vista™ 64 bit with Service Pack 1 or higher
Windows 7™ 32 bit any Service Pack
Windows 7™ 64 bit any Service Pack
CPU and Memory Requirements
Memory and CPU requirements vary depending on the number of managed
devices and networks. Insufficient CPU or available memory may cause the
application to be very slow or to stop responding.
The following examples provide rough estimates for minimum system
requirements for various environments.
Small to Medium
Devices: Up to 500
Number of supported networks: Up to 10
KYOCERA Net Admin Server
1-1 Installation Guide

Installation
CPU: 2.0 GHz, 2.0+ GHz, 1 CPU
Memory: 1 GB, 2 GB
Hard Disk space: 500 MB, 1 GB
KYOCERA Net Admin Agent
CPU: 1.5 GHz, 1 CPU
Memory: 512 MB
Hard Disk space: 250 MB
Enterprise
Devices: Up to 5000
Number of supported networks: Up to 50
KYOCERA Net Admin Server
CPU: 3.0 GHz, 2+ CPU
Memory: 4 GB
Hard Disk space: 2+ GB
KYOCERA Net Admin Agent
CPU: 2.0 GHz, 2+ CPU
Memory: 1 GB
Hard Disk space: 250 MB
Supported Browsers
Microsoft Internet Explorer 7 or higher. Cookies must be enabled.
Supported Printers
Kyocera network printers and most third-party network printers that support
the standard printer Management Information Base (MIB), and printers
connected locally to network computers.
Supported Languages
English, French, German, Italian, Japanese, Portuguese, Spanish.
Upgrade KYOCERA Net Admin
You can upgrade your older version of KYOCERA Net Admin to the latest
version. Depending on your current version, the following upgrade operations
are required:
All older versions – back up the database, and then restore the database
after installing the new version.
Versions 1.03, 1.04, 1.5 – save settings such as firmware files and Map view
background images, and then manually import them into the new version.
When upgrading from version 2.0 to version 3.x, the Accounting Manager and
Print Job Manager consoles are not supported in the new version.
Since KYOCERA Net Admin 3.x uses agents to communicate with devices,
networks are migrated to the new version with a link to a Local Agent. You
must install local or remote agents using the Add Network wizard or the stand-
alone agent installer.
Devices are migrated as unmanaged and not connected, and are displayed with
default settings. After installation, you should run Networks and Agents >Start
Discovery (Administration console) and Add Devices (Device Manager
KYOCERA Net Admin 3.1 1-2

Installation
console). After discovery, KYOCERA Net Admin 3.x lists each device as
managed and linked to a specified network. Select the Show Unmanaged
Devices check box in the Status filter list to display both the managed and
unmanaged devices. Clear the check box to show only the managed devices.
Creating a Backup of Earlier Versions
Before upgrading from versions 1.03, 1.04, 1.5 or 2.0, you must create a backup
file. The following steps apply to version 2.0.
1In the navigation area, select Database.
2Select the Immediate option.
3Click Submit.
4After the backup file is created, open “C:\KNetAdminBackup” folder and locate
the backup zip file. An example of the file name format is “backup-
#############.zip”.
5Copy the backup file into another folder on the computer.
If the upgrade is from version 1.03, 1.04, or 1.5, save a copy of the following
files. You can restore them manually in the new version.
Log files
Firmware files
Map view background images
Installing the New Version 3.x
After creating backup files from the older version, you can install KYOCERA Net
Admin 3.x.
1Use the Windows Uninstall or change a program to remove KYOCERA Net
Admin from the computer.
2Install KYOCERA Net Admin 3.x or use a computer with KYOCERA Net Admin
3.x already installed.
Restoring a Database in Version 3.x
After KYOCERA Net Admin 3.x is installed, you can restore a database backup.
This uses a backup file (.ZIP) in the default backup location
C:\KNetAdminBackup, or in another user-specified backup location.
1Open the Administration console.
2Click Preferences >Database restore.
3Select from the list the backup file created from the previous version. If the file is
not in the list, click the Upload Backup File icon and browse to find the list.
4Click the Start Restore Process icon, and then click OK.
1-3 Installation Guide

Installation
Restore Files Manually
After KYOCERA Net Admin 3.x is installed, you can manually restore files that
were saved from version 1.03, 1.04, or 1.5.
Log files
Copy the saved files to the default folder in C:\Program
Files\Kyocera\NetAdmin\Admin\log, or to the log folder where version 3.x is
installed.
Firmware files
Copy the saved files to the server, to use with the Select file from
KYOCERA Net Admin Server option in the Firmware Upgrade wizard. The
default location is C:\Program Files\Kyocera\NetAdmin\Admin\firmwares.
Or copy the saved files to the desired folder, to use with the Select file from
local client option in the Firmware Upgrade wizard.
Office device layout image files saved in Map view
Copy the saved files to the desired folder, to use with the Select local image
(and copy to server) option in the Add/replace background dialog box.
Any changes you made in default list view settings in the earlier version cannot
be saved or restored. Use the Edit Default List View Mode feature to edit the
default List View tabs.
Server Installation
The KYOCERA Net Admin server installer provides an easy and intuitive
process for installing and configuring KYOCERA Net Admin. The wizard gathers
the administrator’s selections and system information to prepare the installation.
To ensure secure communication, the time setting must be no more than 1
minute apart on server and agent computers. For computers in different time
zones, use a global time server or domain time server to ensure synchronized
time settings.
Installing KYOCERA Net Admin
You can install the KYOCERA Net Admin server.
Note: Make sure your firewall is configured correctly to allow communication
between KYOCERA Net Admin components (TCP port: 8731). KYOCERA Net
Admin cannot be installed on a server used as a domain controller.
1Copy and extract the KYOCERA Net Admin (KNA) zip file to your preferred
server, and click KmInstall.exe to start the installation wizard.
2On the license agreement screen, click View License Agreement to read,
view, and print a copy of the license agreement. To proceed with the setup
installation, click Accept.
3On the Manage Products page, click Install. You can also open and view the
user and installation guides and the Readme from the Documentation icon.
4On the Products to install page, click Next to accept the default options. Note
that clicking Install now begins the installation automatically.
KYOCERA Net Admin 3.1 1-4

Installation
5On the Destination for all software page, click Next to accept the default
folder, or click Browse to locate another folder of your choice. Click Next.
6On the Ports page, accept the defaults or type custom port numbers. Available
port numbers range from 1 to 65535. Click Next.
7On the Network Setup page, select Local network (default), or Remote
network.
8If this is the first time you are installing the application, the Password page
appears. Type a valid password and then click Next. The installation begins and
the wizard displays the progress of the installation. You can click Back to make
any changes, or click Install now to proceed.
9When the process completes, the Finished page appears. You can select the
Start now check box and then click Close to login to KYOCERA Net Admin with
the default login credentials.
For Administrator, the username and password is admin and admin, or for a
read-only user, the username and password is guest and guest.
10 Bookmark the link to your Favorites for easier future access.
PostgreSQL Files
The KYOCERA Net Admin installer automatically installs the PostgreSQL
database if it is not already installed. If the installer detects previous
PostgreSQL files, a message appears at the beginning of the KYOCERA Net
Admin server installation wizard, and the installation is canceled. By default, the
KYOCERA Net Admin database connects to the PostgreSQL server through
port 5432.
Uninstalling KYOCERA Net Admin
You can uninstall KYOCERA Net Admin or any of its components.
1Copy and extract the KYOCERA Net Admin (KNA) zip file to your preferred
server, and click KmInstall.exe to start the installation wizard.
2On the licensing screen, click Accept.
3On the Manage Products page, click Uninstall.
4On the Products to remove page, select the options to uninstall and click
Uninstall now.
5The uninstallation starts and the wizard displays the progress of the
uninstallation.
6When the process completes, the Finished page appears. You can select the
Restart your system check box and then click Close to restart KYOCERA Net
Admin.
1-5 Installation Guide

Installation
Removing PostgreSQL Files
If you want to completely uninstall KYOCERA Net Admin from your computer,
after removing the PostgreSQL program, you should remove the remaining
PostgreSQL files. You should also back up your data before uninstalling.
Removing PostgreSQL files and KYOCERA Net Admin Windows user accounts
from the server ensures a clean reinstallation.
1Click Start >Computer.
2Right-click on Computer and select Manage.
3Under Local Users and Groups, click Users.
4Right-click on NetAdmin and click Delete to remove it from the list.
5Uninstall the PostgreSQL program from your PC using Uninstall or change
program, and reboot your PC.
6Remove any remaining user data by deleting the entire PostgreSQL folder at
C:\Program Files\PostgreSQL (C drive is the default).
Remote Agent Installation
This section is required for administrators who install KYOCERA Net Admin
Agent on a remote network.
The KYOCERA Net Admin Agent is a service that communicates network
device information to KYOCERA Net Admin. Agents can be installed on the
KYOCERA Net Admin server and on remote computers.
To ensure secure communication, the time setting must be no more than 1
minute apart on server and agent computers. For computers in different time
zones, use a global time server or domain time server to ensure synchronized
time settings.
You can choose to install KYOCERA Net Admin Agent on a remote computer
either by RPC connections or by a Stand-alone installer.
RPC Connections for Remote Agent Installation
For agent installation on a remote computer with a Windows operating system
of 2003 or later, the Remote Procedure Call (RPC) endpoint for the spooler
must be set up to allow agent connections.
Allowing the Remote Agent to Access Client Connections
The administrator can set policies that are applied to the computer for any user
who logs on to the KYOCERA Net Admin server. The Allow Print Spooler to
accept client connections policy manages access to the Print Spooler. For
information about group policy settings, refer to Microsoft documentation.
1In the Local Group Policy Editor, click Computer Configuration >
Administrative Templates >Printers.
2From the Setting list, double-click the Allow Print Spooler to accept client
connections policy.
KYOCERA Net Admin 3.1 1-6

Installation
3Select Enabled so the Print Spooler will always accept client connections.
4Click OK.
5Restart the Print Spooler service for changes to this policy to take effect. For
information about restarting the Print Spooler, refer to Microsoft
documentation.
Remote Networks and Remote Agents
You can obtain access, establish communication, and add a network and agent
to a remote computer. Make sure you have the user name, password, domain,
and IP address of the remote computer. You may have to ask the computer
administrator about your system-specific settings. The remote computer’s
firewall must be turned off, or ports TCP 8731 and UDP 162 need to be enabled
for incoming connections in the firewall.
Adding a Remote Network and Remote Agent
You can add a network and agent to a remote computer.
1Open KYOCERA Net Admin in your Internet browser.
2Open the port remotely, or ask the computer administrator to do it.
In the Administration console, click Preferences >Networks and agents >
Add Network, and proceed through the wizard to the Enter the Agent Details
page.
3Type the Agent Name and Agent IP Address. Type the Agent Port and Agent
Timeout, or accept the defaults. Under Administrator login information for
the remote host (available if you selected New Agent in the previous page),
type the Agent Login,Agent Password, and Agent Domain of the
administrator. Click Next.
4Continue and finish the Add Network wizard.
Stand-alone Agent Installation
In some situations, an administrator may want to install an agent on a network
other than KYOCERA Net Admin. The administrator can send an agent
installation package to a remote user, and the user can manually install the
agent at their location. If security and communication is set up, KYOCERA Net
Admin can then manage the new remote agent.
To ensure secure communication, the time setting must be no more than 1
minute apart on server and agent computers. For computers in different time
zones, use a global time server or domain time server to ensure synchronized
time settings.
Installing an Agent with the Stand-alone Installer
You can install an agent at a location that is remote from the KYOCERA Net
Admin server.
1-7 Installation Guide

Installation
1Copy the folder C:\Program
Files\Kyocera\NetAdmin\Admin\install\agent\standalone-install (C drive is the
default) to the target computer.
Note: A security certificate is created during the installation of KYOCERA Net
Admin that links the agents to it. You must use the folder at the path above to
create a stand-alone agent installer. If you use a folder from the KYOCERA Net
Admin package before it is installed on your server, agent communication will
fail.
2Open the folder and run the Setup.exe file. You must have administrator rights
on the computer.
3On the Install Service page, click Install. The progress of the installation is
displayed on the next page. The agent service files are copied to the KYOCERA
Net Admin location in the folder: C:\Program Files\Kyocera\NetAdmin\Agent (C
drive is the default).
4On the Installation Completed page, click Close to exit the wizard.
Adding a Network to a Remote Agent
You can add a network to an existing remote agent (installed by the stand-alone
installer).
1Open KYOCERA Net Admin in your Internet browser.
2In the Administration console, click Preferences >Networks and agents >
Add Network, and proceed through the wizard to the Enter the Agent Details
page.
3Type the Agent Name, and Agent IP Address. Type the Agent Port, and
Agent Timeout, or accept the defaults. Leave the administrator login
information blank. Click Next.
4Continue and finish the Add Network wizard.
USB Device Connections
KYOCERA Net Admin can discover and manage local USB devices (connected
to computers in the network) through the Local Device Agent (LDA). It displays
them in the device list the same way as network-connected devices. The LDA
can support several USB connected devices at the same time, but KYOCERA
Net Admin shows only one of them.
Install the USB device to the computer first, then the LDA.
Requirements
The following requirements are needed for the USB connection and LDA to
function correctly:
KYOCERA Net Admin must be installed and operating on the server.
Microsoft Windows XP SP3 or higher operating system must be installed on
the computer.
Microsoft .NET Framework 4.0 or higher must be installed on the computer.
KYOCERA Net Admin 3.1 1-8

Installation
The computer must have at least one connected local Kyocera USB device.
The computer must have a real network interface card.
The computer must be connected to the network.
The computer must have an IP address in the connected network.
TCP port numbers 9000 and 9072 on the computer must be free and not
blocked by a firewall.
The user installing the LDA must have administrator rights to install a
Microsoft Windows service.
Connecting a USB device
You can connect a local device via USB to a network computer. The device can
then be discovered and managed by the application.
1Ensure that KYOCERA Net Admin is installed and operating.
2Select another computer located on the same network as the server.
3Connect the device to the computer with a USB cable.
4On the computer, install the KX driver of the USB model printing device.
5Continue by installing the LDA service on the computer.
Local Device Agent Installation
The Local Device Agent (LDA) is a Microsoft Windows service that lets the
agent discover and manage local devices that are connected to network
computers through USB ports. The LDA service is installed and started on a
computer with a local USB device. LDA uses the computer's IP address to
communicate with the agent. The KYOCERA Net Admin server has a
Connection type column to distinguish whether the device is network- or locally-
connected.
The types of device properties that can be requested through the LDA vary
according to the device model. Local USB devices do not support the full list of
properties that are supported by the same model on a network. The LDA does
not support setting of properties for a local connected device.
Note: The device home page cannot be opened from KYOCERA Net Admin
for USB-connected devices. The LDA service cannot be used at the same time
with some other utilities, such as the Status Monitor. If the LDA service does
not start, try disabling the Status Monitor and restarting the LDA service.
Installing a Local Device Agent
You can install a Local Device Agent (LDA) to discover and manage local
devices that are connected to network computers through USB ports. The USB
device must be connected to the target computer before installing the LDA.
1Copy the folder C:\Program Files\Kyocera\NetAdmin\Admin\install\local-device-
agent (C drive is the default) to the target computer.
1-9 Installation Guide

Installation
2Open the folder and run the Setup.exe file. You must have administrator rights
on the computer.
3On the Welcome page of the LDA installation wizard, accept the default folder
or click Browse to select another folder. Click Next. The LDA service files are
copied to the selected location in the Program Files folder.
4On the Confirm Settings page, verify that the installation settings are correct.
Click Install. The progress of the installation is displayed on the next page.
5On the Installation Completed page, click Close to exit the wizard.
Multi-Set Template Editor Installation
With the Multi-Set Template Editor, you can create or change template files to
use in KYOCERA Net Admin’s Multi-Set feature. The template files specify
settings for particular groups of devices that are managed by KYOCERA Net
Admin.
Installing the Multi-Set Template Editor
You can install an editor for Multi-Set templates.
1Copy the folder C:\Program Files\Kyocera\NetAdmin\Admin\install\multiset-
template-editor (C drive is the default) to the target computer.
2Open the folder and run the Setup.exe file. You must have administrator rights
on the computer.
3On the Welcome page of the installation wizard, accept the default folder or
click Browse to select another folder. Click Next. The Multi-Set Template Editor
files are copied to the selected location.
4On the Confirm Settings page, verify if the installation settings are correct.
Click Install. The progress of the installation is displayed on the next page.
5On the Installation Completed page, click Close to exit the wizard.
KYOCERA Net Admin Login
At the end of the installation wizard, you can leave the Open the KYOCERA
Net Admin login page check box selected to open the application after clicking
Finish. Once the application is opened, you can use the browser to bookmark
the KYOCERA Net Admin web address.
On the login page, you can use the same word for the User name and
Password:
An administrator uses admin
A read-only user uses guest
For greater security, we recommend changing the default passwords
immediately after the first login.
You will be automatically logged off after 30 minutes of inactivity.
KYOCERA Net Admin 3.1 1-10

Installation
Note: To prevent the browser from freezing, do not use the keyboard shortcut
Ctrl+N to open a new window while the application is running.
Starting and Logging In
You can start KYOCERA Net Admin from Internet Explorer 7 or higher.
1In the browser, click the application’s address in the format: http://<computer
name or IP address>:<port number>/netadmin/ or find the URL in the Favorites
or browser history.
2On the login page, type the User name and Password.
3Choose a console to open from the list, or choose Default Console. You can
change the default console after logging in.
4Click Log in.
1-11 Installation Guide

Rev. 3.12013.02
