Labomed Prima OPH User manual

To ensure proper use of this instrument as well as to avoid injury while operating
instrument, understanding this manual completely before use is highly recommended.
User Manual
Prima OPH
Ophthalmic Microscopy
R

CONTENTS
10.1 SETTING UP MICROSCOPE 12
12 13CHANGING THE OBJECTIVES AND EYEPIECES
13 ADJUSTMENT OF TENSION WHILE USING ACCESSORIES 13
14 DISINFECTION AND STERILIZATION 13
15 CLEANING AND SERVICING 14
16 TROUBLE SHOOTING TABLE 15-16
17 TECHNICAL SPECIFICATION 17-18
11 HOW TO FOCUS THE OBJECT 13
10.2 SETTING UP MAGNIFICATION 12
10 INSTRUCTIONS FOR USING THE MICROSCOPE 12
9 CONTROLS 11
8 ELECTRICAL CONNECTIONS 10
7 INSTRUCTIONS 7-10
6 SYSTEM DIAGRAM 6
5 DESCRIPTION OF PARTS 5
4 UNPACKING 4
3 3SPECIAL INSTRUCTIONS
2 SAFETY INSTRUCTIONS 2
1 INTRODUCTION 1

The LABOMED Prima OPH is an Ophthalmic microscope, which is adaptable for different surgical needs without
compromise to performance.
The microscope provides extremely high optical image quality, good depth of focus and wide field of view for
precise surgery. Illumination control, inbuilt tilt, adjustment of the observation head help to reduce the
surgeon’s work fatigue and allow comfortable use over long period.
1. The observation head can easily be positioned with the help of suspension arm .
2. An advanced 5-step magnification changer allows an optimal magnification for a particular surgery from
five different magnifications.
3. Auto home position for X-Y movement can be done by touch of a button.
4. Cold light illumination with a high intensity 150W Halogen lamp is provided using a fiber optic guide for
proper illumination. The illumination is further adjustable up to its most suitable brightness using
intensity control knob suitably located at the suspension arm, and is easily approachable to the surgeon.
5. The simple lamp changing mechanism allows to change lamp quickly when the lamp in use blows
during operation.
6. The power supply to the lamp automatically goes OFF when the suspension arm is raised to its top
most position.
7. When the microscope is not in use, the suspension arm can be folded over the main body to store it
compactly.
8. Rigid H-form base with castor wheels provides greater stability as well as mobility to the instrument.
Salient features of this Microscope are:
INTRODUCTION
1
1

2
SAFETY INSTRUCTIONS
2Prima OPH
Very important : For identification, service people must know the serial number of the
microscope.
Intended Use:
1. This microscope is manufactured according to the safety norms as per CE regulation and FDA.
2. This microscope is intended for use only as prescribed in this manual.
3. Servicing and repairs are allowed through authorized persons only.
4. Replace burnt out fuses by live fuses of the same type only (rated voltage, rated current, switch
– off characteristics.)
5. Use mains plug and mains socket both with protective earth conductors only.
6. Do not use force while fixing cable connections. If the male and female parts do not readily
connect, make sure that they are appropriate for one another. If any of the connectors are
damaged. Please contact the representative.
7. Make sure that inlets and outlets of ventilation system for cooling the housing are open (not
covered).
8. The microscope is built for use in dry rooms only. Take care that no fluids enter the microscope
components. Do not place any fluid-filled container on top of instrument.
9. Microscope is protected against overheating through a thermal cut-off.
10. The manufacturer will not accept any liability for damage caused by unauthorized persons
tampering with the instrument; this will also forfeit any rights to claim warranty.
11. It is recommended to use the instrument only with the accessories supplied. In case you wish to
use other accessory, make sure that LABOMED has certified that its use will not impair the
safety of instrument.
The Prima OPH is a universal instrument for operative and diagnostic medical use. It is useful for
optimal illumination and magnification of the attendance area with the possibility of:
1. Manual variations of magnification
2. Motorized focusing (Z-axis) through foot control
3. Motorized centering of attendance area in XY directions through a Joystick provided on the foot
control (applicable to the suitable model)

3
SPECIAL INSTRUCTIONS
3
3.1
1. Check all Electrical connections.
2. Attach sterilized covers, panels or caps which have been re-moved or opened.
3. Pay special attention to labels on the instrument, such as caution label, warning triangles
with exclamation marks or notes.
4. Do not cover nay ventilation openings.
3.2
1. Avoid looking directly into the light source, microscope objectives lens or light guide.
2. When the illumination is on, the light guide must be connected at both ends. Otherwise there
is a risk of fire or burn injuries.
3. Any kind of radiations has a detrimental effect on biological tissue. This also applies to
illuminating the surgical field, therefore adjust the brightness and duration of illumination on
the surgical field to the absolute minimum required.
4. Adjust tension of suspension arm as per convenience.
3.3
1. Switch off the Mains sullpy to the instrument.
2. When the microscope is not in use, the suspension arm can be folded over the main body for
compact storage.
Before every use and after re-equipping the instrument
When instrument is in use
After every use of the instrument

4
Prima OPH
UNPACKING
4
The appliance is delivered in sub-assembled groups along with one set of Installation Kit and one
instruction / service manual.
Please check following at the time of unpacking
1. Mobile supporting base with castor wheels, or as ordered
2. Column, as ordered
3. Illumination Box
4. Swivel arm and Suspension arm assembly
5. Cover for swivel arm
6. X-Y motorized coupling; if ordered
7. Z-axis motorized focusing attachment with magnichanger assembly
8. Foot controls, (with Joystick in case of XY model)
9. Observation Head
10. Paired Eye Pieces; as ordered
11. Power Cord
12. Set of sterilizable caps
13. Installation Kit
a) Allen Wrench 3.00mm
b) Allen Wrench 4.00mm
c) Allen Wrench 5.00mm
d) Allen Wrench 6.00mm
e) Allen Wrench 8.00mm
f) Spanner-12/ 13mm
12. Instruction cum Operating Manual / Service Manual

5
DESCRIPTION OF PARTS
5
1. Observation Head
2. Eyepieces
3. CMO - Common Main Objective
4. Fibre Optic Cable
5. X-Y Coupling
19
13. Swivel Arm
14. Swivel Arm Locking Knob
15. Illumination Box
16. Lamp Changing Knob
17. On/Off switch for Foot Control
6. Z axis coupling 18. Connectors
7. Intensity Control Knob . Pillar
8. Coupling Locking Knob 20. Moveable Base
9. Up/Down Movement Control Knob 21. Castor Wheel with Lock
10. Cable Cover 22. Foot Control with Joystick
11. Suspension Arm 23. Tension Adjustment
12. Suspension Arm Locking Knob
15
15
14
14
13
13
12
12
9
9
7
7
8
8
23
23
10
10
2
2
1
1
5
20
20
21
21
19
19
16
18
18
17
11
5
3
17
11
6
3

SYSTEM DIAGRAM
6
6
Ad- 613400-820
612086-600
A616500-811
613800-815
1271094 6122012 6122016 6122020
6134105-102
A612086-400 A6122015-800
6136000-900 6135000-800
6133176-00 6133201-000 6133251-000
6135000-809 6135000-909
6134105
6137500
6137100
6137200 6165000-817
6137300
6134100-800

INSTRUCTIONS
7
7
Prima OPH
Fig. 3
Fig. 4
7.1 Pull out the base from the wooden pallet by removing
two nuts with the help of spanner provided.
7.2 Remove allen screws from bottom side of the pillar.
7.3 Put the pillar on the base and align it with the pillar
guide pin (A). After aligning the screw holes with the
guiding holes on base, fix the screws removed in Fig 2
using allen wrench 8mm. Fig.2 and 3.
7.4 Remove safety cap from topside of the pillar.
7.5 Place swivel arm on the pillar by sliding in the groove
and rotate the suspension arm by 90° as shown in
Fig.4.
Fig. 2

8
Prima OPH
7.6 Firmly tight the safety lock screw provided on the
suspension arm by using allen wrench 3mm. See fig
5.
7.7 Remove four allen screws from the illumination box
before mounting it on pillar.
7.8 Fix the illumination box on the pillar only after having
the connectors passed through the hole provided on
the H- block. Refer to fig 6.
7.9 Secure the illumination box with four allen screws
provided using wrench 5mm. See fig 7.
7.10 Connect two appropriate male female connectors
provided for electrical connection. See fig 8. Do not
pull the cables too much to join the connector’s.
Additional force can damage wire connections.
Fig. 5
Fig. 6
Fig. 7
Fig. 8
A
A
B

9
Prima OPH
Fig. 10
B
A
Fig. 9
Fig. 11
Fig. 12
7.11
7.12
7.13 Remove the cable cover by unscrewing two allen
screws provided at the lower side. Run the fibre optic
cable and the cable meant for intensity
7.14 Set the cable cover on the suspension arm by aligning
the guide screw with the groove provided on the cover
by using allen wrench 3mm.(Fig. 12)
Remove the caution label from the suspension arm.
Unscrew safety nut (A) from the carrier and guide the
shaft smoothly into the bush of suspension arm as
shown in Fig. 9
7.15 Remove the swivel arm locking knobs A & B. Remove
the self tapping screws fixed on the top and bottom
side of cover for swivel arm. Fix these panels on swivel
arm and fix back the screws removed earlier. Make
sure that wire for Fibre optic is passed through while
fixing the panels. See fig 11 and 12..
Install the microscope coupling to the suspension arm
prior to installing the head and eyepieces. Before
installing, loosen the coupling locking knob (A) and
safety position screw (B).Slide in the carrier shaft to
the suspension arm and screw it with locking nut.
Secure the locking knob (A) and safety position
screw (C).
control knob
and XYZ control through the tray.
AB
A
B
C

10
Prima OPH
Fig. 14
Fig. 15
Fig. 13
7.19 Assemble fibre optic cable into the hole provided at the
backside of magnichanger assembly by gently pushing
it in, as shown in fig 13. A click sound will confirm
correct position.
7.20 Plug in the wire for foot control into the illumination
box. See fig 14.
8Electrical Connections
8.1 Adjusting mains Voltage:
Connect the power cable to the AC inlet socket provided on
the illumination box and check the voltage settings at the
voltage selector switch. The line voltage of the electrical
system is set in the factory the rated line voltage of the
country of destination which must be either 110V or 220V
AC. The line voltage available at the site of installation must
lie within the admissible voltage range. If this is not the case
you must not operate the system.
8.2 Connections of Various Controls:
8.2.1 Connect 7 pin connector from X-Y coupling assembly to
terminal of electrical box.
8.2.2 Connect 4 pin connector from Z-axis motorized control
assembly to terminal of electrical box.
8.2.3 Connect 12-pin connector from foot control to terminal of
electrical box.
This completes your electrical connections.

Prima OPH
11
9Controls
9.1 ON/OFF Switch
9.1 ON/OFF switch
It is located on the Right hand side of illumination
box “1” indicates ‘ON’ position of microscope. At ‘ON’
position green LED glows and cooling fan starts
running. Keep the intensity control knob at minimum
level before changing / replacing the lamp.
It is located on the right hand side of illumination
box. If lamp blows off during the use of microscope,
the Prima OPH is provided with a spare lamp. Lamp
changing knob connects to the Lamp II for smooth
running of the operation by turning it anti-clockwise.
It is located on the suspension arm. Brightness of
field of view can be adjusted as per user comfort
using intensity control knob.
Locks the stand from unwanted movement by
pressing down the two brakes provided on caster
wheels. To unlock press upper portion of brake. See
Figure 9.
This knob helps you to lock the movement of swivel
arm at the desired position after initial focusing of the
attendance area by turning it clockwise.
To save burning life of lamp, switch OFF the
appliance if the microscope is not in use for longer
time.
9.2 Lamp changing knob
9.3 Intensity control knob
9.4 Brakes
9.5 Swivel arm locking knob
9.6 Suspension Arm locking knob
9.7 Coupling locking knob
9.8 Up / Down Movement Control Knob
This knob locks the movement of suspension arm at any
desired position by turning it clockwise.
This knob is located on the suspension arm and helps to
lock the position of observation head at any desired point
by turning it clockwise.
Locks the UP/Down movement of Suspension arm at a
desired position after initial focusing of the attendance
area. Fine focusing is done using F.O.V.
1
2
3
Fig. 17
Fig. 16

12
INSTRUCTIONS FOR USING THE MICROSCOPE
10
10.1 Setting up of Microscope:
10.1.1
10.1.2
10.1.3
10.1.4
10.2 Setting up of magnification
Lock all the brakes on base wheels after setting up of
microscope on the attendance area for stability.
Adjust tension on suspension arm using tension
adjustment screw as per your convenience by turning the
knob clock wise or anti-clock wise.
Lock the Up & Down movement of suspension arm using
locking knob after coarse focusing of the attendance
area.
Adjust the eye distance as per IPD scale according to your
convenience.
(Ref. 18)
1. Adjust to highest magnification with one of the rotating knobs provided at magnification
changer.
2. Fine focusing is done through F.O.V. knob
3. Absolute centering of observation area in field of view can be done by manual handle(21c)
4. Make sure that the magnification changer is engaged in the index point at the click stop position.
5. Use filter changing knob (18d) to change filters.
Fig. 18

13
Changing the objectives/ eyepieces
How to focus the object
12
11
1. Adjust both the eyepieces to ‘0’ diopter adjustment.
2. Adjust IPD of the observation head using IPD scale.
3. Bring highest magnification factor in the click stop
position using one of the knobs provided at the
magnichanger unit. By doing so observation area will
remain parfocalized in all magnifications.
4. Fine focusing is done by using foot control by pressing
on up and down paddles.
1. The objectives can be taken out by rotating it in anti-
clockwise direction. It can be threated in by rotating in
clockwise direction.
2. To install the Eyepieces, insert in the Eyetubes of
observation head.
3. A range of objectives/eyepieces can be selected by
choice.
Adjustment of Tension while using Accessories
Disinfection and Sterilization
13
14
After Supplementary accessories are mounted, the
additional load of suspension arm must be compensated by
adjusting tension on tension control screw provided on
suspension arm by moving it clock wise or anticlockwise.
For Diagnosis:
Moisten smooth cotton with antiseptic fluid (for example Sagrotan – P); when required , clean often
touched parts, like rotating knobs, handles and so on.
Sterilizable polymer covers are provided on every part that require to be touched during operation.
Sterilize them after every use of the instrument.
After surgery:-
Fig. 19
Fig. 20
Fig. 21

Prima ENT
15.1 Cleaning of optical surfaces:
15.2 Cleaning of mechanical surfaces:
15.3 Servicing:
Remove coarse dirt particle with a clean dry air from optics outer surfaces (Objectives,
Eyepieces).
Moisten smooth cotton cloth with lens cleaning agent and wipe on the lens surface
gently starting from the middle of the lens to the outer edge.
All mechanical surfaces of the equipment can be cleaned by wiping with a moist cloth.
Don’t use any aggressive or abrasive cleaning agents.
Any household dish washing fluid can be used for cleaning residue.
Service whenever required, inform after-sale service.
CLEANING AND SERVICING
15
14

15
Problem Possible Cause Remedy
No Illumination at all Power cable not plugged Plug in power cable.
Power switch not pressed Press power switch
Defective instruments fuse Change instrument fuse
Defective power cable Change power cable
Line power failure Contact in-house Techician
Failure of suspension Contact service dept.
system electronics
Light guide not properly Insert light guide to the
inserted in lamp or maximum intensity.
microscope.
Insufficient Brightness level set too Adjust brightness using the
Illumination low brightness control knob.
Light guide not properly Insert light guide to the
inserted in lamp or maximum illumination
microscope.
Defective light guide Chance light guide.
(illumination not uniform)
Halogen lamp in the Knob for brightness control Turn the knob clock wise
illumination system not operated
remains dark, and
Lamp module has no Insert lamp
Defective halogen lamp. Switch to backup lamp.
Halogen lamp goes
constantly off and on Ventillation slots are Ventillation slots must be clear,
during operation. covered or contaminated clean them if necessary.
fan is running. module properly.
contact.
TROUBLESHOOTING TABLE
16 Prima OPH

16
Problem Possible Cause Remedy
Thermal cut-off in lamp Clean thermal cut-off with a
housing is contaminated. dry brush; blow it clean, if
necessary
Defective fan. Failure of Contact service dept.
system electronics. Illuminate surgical field using
an Or illuminator. Contact
service dept.
Up & Down motion Friction adjustment screw Loosen friction adjustment
of screw on on suspension system screw on suspension system
suspension system tightened too firmly. as require
too stiff
Microscope Unstable Brakes on wheels not Use Brakes.
used.
No image visible in Magnichanger is not Index magnichanger properly.
field of view. indexed properly.
Prima OPH

17
SPECIFICATIONS
17 Prima OPH
Binocular tubes 45° inclined
Eyepieces WF 10x/16mm with eye guards; optional WF
12.5x/16mm; WF 16x/16mm
Apochromatic Magnichanger 0.4x, 0.6x, 1.0x, 1.6x & 2.5x
Objective f=200, motorized fine focus
Light source 15V/150W halogen, twin lamp
Built-in filters Green & Blue
Vertical movement of arm 600 mm
Microscope carriers XY coupling or basic Ophthalmic carrier
(motorized fine focus)
Accessories Assistant Binocular attachment, iVu OP Beam
splitter integrated digital camera Module;
Double Beam splitter; 0 -210
Type: Floor stand
Base (Dimensions): 775mm width
762mm length
Stand Height: 1676mm
Weight of complete microscope: 72 Kg. Approx.
Elevation Stroke: 600mm
Stand Height in Horizontal Position: 1100mm
Field of illumination with F.O.V. f=200mm objective: Ø 70mm
° ° inclinable ergo
tube
Technical Data (Specifications)
