laguna PX-16 SHEARTEC II User manual

Owner's Manual
Laguna Tools
744 Refuge Way Grande Prairie, TX
Service: [phone]
Email: [e-mail]
Updated January 2022
PX-16 SHEARTEC II Planer
Copyright Laguna Tools 2022
Owner's Manual

Laguna Tools, Inc. LAGUNA® and the LAGUNA Logo® are the registered trademarks of
Laguna Tools, Inc. All rights reserved. 04/01/2019
LAGUNA AMERICAN HEADQUARTERS
Texas: 744 Refuge Way Suite 200, Grand Prairie, Texas 75050, U.S.A. Phone:
[phone]
Huntington Beach: 7291 Heil Ave Huntington Beach, CA 92647, U.S.A. Phone:
[phone]
South Carolina: 825 Bistline Dr. Ste 101, West Columbia, SC 29172, U.S.A. Phone:
[phone]
Minnesota: 5250 West 74th St, Edina, MN 55439, U.S.A Phone: [phone]
lagunatools.com
supermaxtools.com
lagunacleanair.com
lagunalathe.com
LAGUNA EUROPE
Walker Rd, Bardon Hill, Coalville LE67 1TU, United Kingdom. Phone: [phone]
lagunatools.uk
DAKECORPORATION
724 Robbins Road, Grand Haven, MI 49417, United States [phone]
dakecorp.com
Call: [phone]
or
Email: [e-mail]
For immediate service on any Laguna Tools products:

All rights reserved. No parts of this work maybe reproduced in anyform or by any means - graphic, electronic, or
mechanical, including photocopying, recording, taping, or information storage and retrieval systems - without the
written permission of Laguna Tools.
Products that are referred to in this document are either trademarks and/or registered trademarks of Laguna Tools,
Inc. The publisher and the author make no claim to these trademarks.
While every precaution has been taken in the preparation of this document, the publisher and the author assume no
responsibility for errors or omissions, or for damages resulting from the use of information contained in this
document or from the use of programs and source code that mayaccompany it. In no event shall the publisher and
the author be liable for anyloss of profit or any other commercial damage caused or alleged to have been caused
directly or indirectlybythis document.
Published: August 2021 in South Carolina

5Contents
5
Contents
Letter to the Woodworker 7
General Information 8
Safety Rules ...................................................................................................................... 12
Electrical Safety ................................................................................................................ 16
Grounding Methods ............................................................................................................................................ 17
Machine Overview ............................................................................................................ 19
Machine Specifications ..................................................................................................... 21
Machine Set-Up & Assembly 23
Unboxing ........................................................................................................................... 24
Machine Placement .......................................................................................................... 25
Inventory List ........................................................................................................................................................ 26
Assembly 27
Operation 33
Power Supply Circuit Requirements 34
Calibrating The Thickness 35
Calibrating The DRO (Digital Read Out) 36
Maintenance & Troubleshooting 37
Shear-tec II Knife Rotation/Replaement ............................................................................ 38
Lubrication ........................................................................................................................ 39
Front/Rear Precision Adjustment ....................................................................................... 42
Troubleshooting ................................................................................................................ 45
Wiring 46
Replacement Parts Diagrams 47
Replacement Parts Tables 49
Dealer Machinery Warranty 54
Customer Service Contact Information 55

PX-16 SHEARTEC II PLANER6
Laguna Tools 2021

Letter to the Woodworker 7
Letter to the Woodworker
Thank you for investing in a PX-16 Planer by Laguna Tools. This planer is one of a family of unique machines
proudly offered by Laguna Tools. Every Laguna machine is engineered for years of dependable service. Please feel
free to contact Laguna Tools if you have a question or suggestion. We appreciate working with you and your choice
of a Laguna Tools machine for your shop.
Regards, Torben Helshoj
President & Founder Laguna Tools

PX-16 SHEARTEC II PLANER8
General Information
SAVE THESE INSTRUCTIONS
Refer to them often and use them to instruct others.
Please read and understand all warnings and operation instructions before using any tool or equipment. Always
follow basic safety precautions to reduce the risk of personal injury. Improper operation, maintenance or
modification of tools or equipment could result in serious injury and property damage. There are certain applications
for which tools and equipment are designed. This product should NOT be modified and/or used for any application
other than for which it was designed.
NOTICE! It is important for you to read and understand this manual. The information it contains is provided for your
safety while assembling and operating this machine.
Safety Signs and Call-Outs:
An imminently hazardous situation which, if not avoided, will result in death or serious injury.
A potentially hazardous situation which, if not avoided, could result in death or serious injury.
A potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
A helpful tip from our technical staff. Sometimes displayed as NOTICE! instead.
Disconnect
from power
before
proceeding.
Wear ear
protection.
Be aware of
possible
laceration
danger.
Wear Eye
Protection.
Be aware of
possible
crushing
danger.
Wear a full
face shield.
Electrical
Hazard.
Wear lung
protection.
..X
Requires X
People

General Information 9
