User & Installation Guide
LAM4601
Built in
Double Electric Oven

02_
LAMONA Appliances
Dear Customer,
Congratulations on your choice of oven which has been designed to give you excellent service.
The user manual will help you use your product quickly and safely.
• Please read this user manual before installing and using the oven.
• Always follow the safety instructions.
• Keep this user manual within easy reach for future reference.
• Please read any other documents supplied with the product.
Explanation of symbols
Throughout this user manual the following symbols are used:
Important information or useful tips about usage.
Warning for possible hazards to health and property.
Warning possibility of electric shock.
This product’s packaging material is recyclable. Help recycle it and protect the
environment by dropping it off in the municipal receptacles provided for this purpose.
Your product also contains a great amount of recyclable material. It is marked with this
label to indicate the used appliances that should not be mixed with other waste. This
way, the appliance recycling organised by your manufacturer will be done under the
best possible conditions, in compliance with European Directive 2002/96/EC on Waste
Electrical and Electronic Equipment. Contact your town hall or your retailer for the used
appliance collection points closest to your home. We thank you doing your part to protect
the environment.

_ 03
User manual LAM4601
Index
Index
01 - Before using the oven 05
02 - Safety 05
General 06
Safety for children 07
Safety when working with electricity 07
03 - General information 08
04 - Preparation 09
Initial use 09
Tips for energy saving 09
First cleaning of the appliance 09
Initial heating 09
05 Operation modes 10
Operating modes 10
06 How to operate the main oven 11
How to use the main oven 11
Select a temperature and operating mode 11
Shelf positions 11
Switch off the oven 11
07 How to operate the top oven 12
How to use the top oven 12
Select a temperature and operating mode 12
Shelf positions 12
Switch off the oven 12
08 - How to operate the Grill 13
How to use the grill 13
Switch on the grill 13
Shelf positions 13
Switch off the grill 13
09 - How to operate the timer 14
How to operate the oven timer 14
Switch on fully automatic operation 14
Switch on semi-automatic operation 14
Interrupting the cooking process 15
How to activate the program lock 15
How to use the alarm clock 15
Setting the alarm clock 15
Switching off the alarm 15
10 Cooking and baking advice 16
11 Cooking tables 17
12 Care and maintenance 19
General information 19
Cleaning the control panel 19
Cleaning the door 19
Removal of the oven door 19
Removing the inner door glass 20
Replacing the oven Lamp 21
13 Installation 21
Before installation 21
Installation and connection 22
Cooling Fan 23
24
15 Troubleshooting 25
16 Your Guarantee 26
Important Information 05

04_
LAMONA Appliances

Safety_ 05
User manual LAM4401
•This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the applian ce in a safe way and
understand the hazards involved.
Children shall not play with the appliance. Cleaning and user mainte -
nance shall not be made by children without supervision.
•The appliance and its accessible parts become hot during use. Care
should be taken to avoid touching heating elements. Children less
than 8 years of age shall be kept away unless continuously
supervised.
•Do not use steam cleaners to clean the appliance as this may cause an
electric shock.
-
ons”.
•If the power connection cable for the product is damaged, it must be
persons in order to avoid a hazard.
•During use the appliance becomes hot. Care should be taken to avoid
touching heating elements inside the oven.
•The appliance must be installed so that it can be completely
disconnected from the network. The separation must be provided
-
lation, according to construction regulations.
•Accessible parts may become hot during use. Young children should
be kept away.
•Do not use harsh abrasive cleaners or sharp metal scrapers to clean
the oven door glass since they can scratch the surface, which may
result in shattering of the glass.
•Rear surface of the oven gets hot when it is in use. Make sure that the
gas/electrical connection does not contact the rear surface; other -
wise, connections can get damaged.
•Ensure that the appliance is swit fore replacing the lamp to
avoid the possibility of electric shock.
Important instructions and warnings for safety and environment

06_
LAMONA Appliances
Before Using the oven
• Make sure that you have removed all packaging, wrappings, stickers and from the oven’s
surface.
• It is recommended that you clean and wash the oven’s surface before using for the time.
01 - Before using the Oven
This appliance is for domestic cooking
purposes only. It must not be used for other
purposes, for example room heating. It is not
designed for any other uses such as room heating
or drying towels and dish cloths. Commercial use
will void the guarantee.
The manufacturer shall not be liable for any damage
caused by improper use or handling errors
General
This product is not intended to be used by persons
with physical, sensory or mental disorders or
unlearned or inexperienced people (including
children) unless they are supervised by a person
who will be responsible for their safety or who will
instruct them accordingly in the use of the product.
Children must be supervised to prevent them from
tampering with the product.
• Connect the product to an earthed outlet
protected by a fuse of suit-able capacity
as stated in the “Technical
table. Our company shall not be liable for
any problems arising due to the product not
being earthed in accordance with the local
regulations.
• Do not operate the product if the power cable
is damaged. Call service agent.
• Do not operate the product if it is defective or
has any visible damage.
• Do not carry out any repairs or
on the product. However, you may remedy
some the problems that do not require any
repairs or See Troubleshooting,
page 23.
• Never wash down the product with excessive
water, as there is the risk of electric shock!
• Never use the product when your judgment or
coordination is impaired by the use of alcohol
and/or drugs.
• Product must be disconnected from the mains
during installation, maintenance, cleaning and
repair procedures.
• Repair procedures must always be performed
by service agents. The manufacturer
shall not be held responsible for damages
arising from procedures carried out by
unauthorised persons, which may also void
the guarantee.
• Be careful when using alcoholic drinks in
your dishes. Alcohol evaporates at high
temperatures and may cause since it can
ignite when it comes into contact with hot
surfaces.
• Do not heat closed tins and glass jars in the
oven. The pressure that would build-up in the
tin/jar may cause it to burst.
• Do not place any materials close
to the product as the sides may become hot
during use.
• Do not place baking trays, dishes or aluminium
foil directly onto the bot-tom of the oven. The
heat accumulation might damage the oven
and it’s enamel surfaces.
• Keep all ventilation slots clear of obstructions,
as this may cause premature failure of the
oven element.
02 - Safety
•WARNING FIRE RISK -
Do not place aluminium foil, baking trays
or cook on the base of this oven, doing so
will cause permanent damage to your
appliance and cabinetry with the potential

_ 07
User manual LAM4601
Product may become hot when it is in use. Please
be careful not to touch these hot surfaces.
Always use heat resistant oven gloves when putting
dishes in or removing dishes from the hot oven.
Do not use the product if any door glass is removed
or damaged.
Rear surface of the oven may get hot when it is in
use. Make sure that the electrical connections do
not contact the rear surface; otherwise, connections
may be damaged.
Do not trap the mains cable and do not route it over
hot surfaces. The cable insulation may melt and
causeareasaresultofashortcircuit.
Make sure that the product function knobs are
switched off after every use.
Productmustbeinstalledbyaqualiedpersonin
accordance with the regulations in force. Otherwise,
the guarantee may become void.
Safety for children
Electrical products can be dangerous to children.
Keep children away from the product when it is
operating and do not allow them to play with or near
the product.
“CAUTION: accessible parts of the oven may
become hot when the oven or grill is in use. Children
should be kept away until the product has cooled
down.”
Do not store any items above the appliance that
children may reach for.
When the door is open, do not load any heavy object
on it and do not allow children to sit on it. The door
or door hinges may be damaged.
The packaging materials will be dangerous for
children. Keep the packaging materials away
from children. Please dispose of all parts of the
packaging according to environmental standards.
Safety when working with
electricity
Any work on electrical equipment and systems
should only be carried out by authorised and
qualiedpersons.
In case of any damage, switch off the product and
disconnect it from the mains. To do this, turn off the
fuse at the fuse box.
Make sure that fuse rating is compatible with the
product.
Safety

08_
LAMONA Appliances
a. Control panel
b. Handle
c. Top oven
d Handle
e Main Oven
03 - General Information
f. Grill heating element
g. Grill shelf supports
h Oven Light
i. Oven shelf positions
j. Fan motor (behind steel plate)
1 Main oven thermostat knob
2 Main oven function knob
3 Digital timer
4 Top oven / grill thermostat knob
5 Top oven/ grill function knob
6 Main oven temperature indicator
7 Top oven / grill temperature indicator
2
1
5
4
3
2
1
2
1
5
4
3
2
1
a
b
c
d
e
f
g
h
i
j
2
1
5
4
3
2
1
2
1
5
4
3
2
1
h
i
j
f
g
5
4
3
2
1
1
2
3
2
1
3
2
1
h
i
j
a b c d
e f g h i j
1 2 4 5 63 7
Oven tray / grill pan Grill pan wire rack / trivet Oven shelf
General Information
Oven layout
Control panel layout
Accessories
2
1
5
4
3
2
1
2
1
5
4
3
2
1
a
b
c
d
e
f
g
h
i
j
2
1
5
4
3
2
1
2
1
5
4
3
2
1
h
i
j
f
g
5
4
3
2
1
1
2
3
2
1
3
2
1
h
i
j
2
1
5
4
3
2
1
2
1
5
4
3
2
1
a
b
c
d
e
f
g
h
i
j
2
1
5
4
3
2
1
2
1
5
4
3
2
1
h
i
j
f
g
5
4
3
2
1
1
2
3
2
1
3
2
1
h
i
j

_ 09
User manual LAM4601
04 - Preparation
Initial use
Before using the oven the clock time must be
set. If the clock time is not set, the main oven will
not work.
a b c d
e f g h i j
1 2 4 5 63 7
Buttons for:
e. Alarm clock
f. Cooking time
g. End of cooking time
h. Switch on automatic
Keys for time adjustment:
i. Minus button
j. Plus button
1. To set the time of day, press and hold button
‘
a b c d
e f g h i j
1 2 4 5 63 7
’
2. Whilst continuing to hold button ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ set
the time of day by pressing buttons ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ or
‘
a b c d
e f g h i j
1 2 4 5 63 7
’. The clock will increase or decrease in
one minute increments. If you press and hold
button ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ or ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ for 3 seconds the time will
advance quickly
3. Once a time is set release all buttons
First cleaning of the appliance
1. Remove all packaging materials.
2. Wipe the surfaces of the appliance with a
damp cloth or sponge and dry with a clean
cloth
The surface may get damaged by some detergents
or cleaning materials.
Do not use aggressive detergents, cleaning powder/
cream or any sharp objects.
Initial heating
It is recommended to heat up the product for
about 30 minutes and then switch it off. Thus, any
production residues or layers will be burnt off and
removed.
1. Take the tray and the wire grid out of the oven.
2. Close the oven doors.
3. Select Fan and Grill cooking
4. Select the highest oven & grill power levels;
See How to use the electric oven, pages 8-11.
5. Operate oven & grill for about 30 minutes.
6. Turn off your oven & grill and allow to cool.
Small amounts of smoke& fumes may emit
during the initial heating process; this is normal,
however monitor the oven at all times and ensure
that the room is well ventilated.
Tips for saving energy
The following information will help you to use your
appliance in an ecological way, and to save energy:
• Use dark coloured or enamel coated cookware
in the oven as the heat transmission will be
better.
• Perform a preheating operation if it is advised
in the user manual or cooking instructions.
• Do not open the door of the oven frequently
during cooking.
• Try to cook more than one dish in the oven at
the same time whenever possible. You can
place two cooking vessels onto the wire shelf.
• Cook one dish after another. The oven will
already be hot.
• You can save energy by switching off your oven
a few minutes before the end of the cooking
time. Do not open the oven door.
• Defrost frozen dishes before cooking them if
possible.
Preparation

10_
LAMONA Appliances
05 - Operating modes
Operating modes
All functions for the ovens and grill are listed in this section.
The order of operating modes shown here might deviate from the arrangement on your appliance.
Oven lamp
The oven is not heated. Only the oven
lamp is lit, the outside cooling fan can also
be running to protect cabinets from heat.
Top and bottom heat
Top and bottom heat is used. The
foodstuffs are heated simultaneously
from above and below. Suitable for cakes,
cookies and casseroles. For best results
Cook with one tray only.
Bottom heat
Only bottom heat is used. Is particularly
suitable for dishes, such as pizza, which
are required to be baked from bottom.
Defrost
The oven is not heated. Only the fan (in
the rear wall) is in operation. Frozen
granular food can be thawed slowly at
room temperature, and cooked food can
be cooled down.
Fan Cooking
The element & fan (in the rear wall) are
both in operation. Hot air is distributed
evenly and quickly all over the cavity by
the fan. In most cases, preheating is not
required. This mode is suitable when
several levels are used for the cooking
and an even temperature is required
thought the oven cavity .
Grill-small
The inner grill element in the top oven is
in operation. This is suitable for small or
medium-sized portions
Ensure correct shelf position is used, set
the temperature to maximum level, and
turn the food as required to ensure even
cooking.
Grill -Full
The full grill element in the top oven is in
operation. This is suitable for grilling
larger dishes
Ensure correct shelf position is used, set
the temperature to maximum level, and
turn the food as required to ensure even
cooking.
Operating Modes

_ 11
User manual LAM4601
How to use the main oven
As your appliance has two ovens please ensure that
the appropriate function and thermostat control are
selected for the oven you wish to use.
a b c d
e f g h i j
1 2 4 5 63 7
- Main oven
Select temperature
& operating mode
a b
c d
e f g h i j
1 2 4 5 63 7
a. Main oven thermostat knob
b. Main oven function knob
The operating modes of the electric oven are
selected with the function knob. The temperature is
adjusted with the thermostat knob.
1. Set thermostat knob to the desired
temperature.
2. Set function knob to the required operating
mode.
The oven heats up to the adjusted temperature
and maintains it. During heating, the temperature
indicator light will remain on until the desired
temperature is reached.
Shelf positions
The main oven has 5 shelf positions as illustrated
below
It is important to position the wire shelf into the
runners correctly.
2
1
5
4
3
2
1
2
1
5
4
3
2
1
a
b
c
d
e
f
g
h
i
j
2
1
5
4
3
2
1
2
1
5
4
3
2
1
h
i
j
f
g
5
4
3
2
1
1
2
3
2
1
3
2
1
h
i
j
Please ensure shelves are fully inserted before
closing the oven door, failure to do so could lead to
damage to the door.
Warning -Do not place aluminium foil or baking
trays on the base of the oven. This can lead to
permanent damage to your appliance.
Warning –Do not place plates, dishes or trays on
theoorofthetopovencavitywhenmainovenis
in use.
Warning - Do not use the oven or grill cavity for
storage when not in use.
Switch off electric oven
Turn function knob and thermostat knob to off
position (top).
06 - How to operate the main oven
How to operate the main oven

12_
LAMONA Appliances
How to use the Top oven
As your appliance has two ovens please ensure that
the appropriate function and thermostat control are
selected for the oven you wish to use.
a b c d
e f g h i j
1 2 4 5 63 7
- Top oven / Grill
Select temperature
& operating mode
a b
c d
e f g h i j
1 2 4 5 63 7
c. Top oven thermostat knob
d. Top oven function knob
1. Set thermostat knob to the desired
temperature.
2. Set function knob to the required operating
mode.
The oven heats up to the adjusted temperature
and maintains it. During heating, the temperature
indicator light will remain on until the desired
temperature is reached.
Shelf positions
The top oven has 2 shelf positions as illustrated
below
It is important to position the wire shelf into the
runners correctly.
2
1
5
4
3
2
1
2
1
5
4
3
2
1
a
b
c
d
e
f
g
h
i
j
2
1
5
4
3
2
1
2
1
5
4
3
2
1
h
i
j
f
g
5
4
3
2
1
1
2
3
2
1
3
2
1
h
i
j
Please ensure shelves are fully inserted before
closing the oven door, failure to do so could lead to
damage to the door.
Warning -Do not place aluminium foil or baking
trays on the base of the oven. This can lead to
permanent damage to your appliance.
Warning –Do not place plates, dishes or trays on
theoorofthetopovencavitywhenmainovenis
in use.
Warning - Do not use the oven or grill cavity for
storage when not in use.
Switch off electric oven
Turn function knob and thermostat knob to off
position (top).
07 - How to operate the top oven
How to operate the top oven

_ 13
User manual LAM4601
How to use the grill
Asyourapplianceisttedwithagrillpleaseensure
that the appropriate function and thermostat
control are selected for the function you wish to use.
a b c d
e f g h i j
1 2 4 5 63 7
- Top oven / Grill
Switch on the grill
a b
c d
e f g h i j
1 2 4 5 63 7
c. Top oven thermostat knob
d. Top oven function knob
1. Set the function knob to the half or full grill
symbol.
2. Set grill temperature.
3. Preheat for approximately 5 minutes, if it is
necessary.
The grill heats up to the adjusted temperature
and maintains it. During heating, the temperature
indicator light will remain on until the desired
temperature is reached.
Hot surfaces may cause burns! Close oven
door during grilling.
Shelf positions
Do not use the upper level for grilling.
2
1
5
4
3
2
1
2
1
5
4
3
2
1
a
b
c
d
e
f
g
h
i
j
2
1
5
4
3
2
1
2
1
5
4
3
2
1
h
i
j
f
g
5
4
3
2
1
1
2
3
2
1
3
2
1
h
i
j
• Put large or medium-sized portions on shelf
position 1 under the grill element for grilling.
• Food which requires browning only should be
placed under the hot grill, either in the grill
pan,orontheoorofthegrillcompartment,
according to the depth of the dish. The grill
pan wire grid can be removed.
• Only use food for grilling which is suitable for
intensive grilling heat. Do not place the food
too high or too far back in the grill. This is the
hottest area and food may smoke, burn and
evencatchre.
Warning -Do not place aluminium foil or baking
trays on the base of the oven. This can lead to
permanent damage to your appliance.
Warning –Do not place plates, dishes or trays on
theoorofthetopovencavitywhenmainovenis
in use.
Warning - Do not use the oven or grill cavity for
storage when not in use.
Switch off the grill
Turn grill control knob and thermostat knob to off
position (top).
08 - How to operate the Grill
How to operate the grill

14_
LAMONA Appliances
How to operate the timer
How to operate the oven timer
a b c d
e f g h i j
1 2 4 5 63 7
Buttons for:
e. Alarm clock
f. Cooking time
g. End of cooking time
h. Switch on/off automatic mode
Buttons for time adjustment:
i. Minus Button
j. Plus Button
The maximum time to be set for the end of the
cooking process is 23 hours and 59 minutes. In the
case of a power cut, the program will be cancelled.
and reprograming is needed.
Switch on fully
automatic operation
Inthismodeofoperation,youcandenewhenthe
oven is to switch on/off automatically.
First, dine the end time:
1. Keep button ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ pressed.
2. Set the desired end of cooking time with
button ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ or ‘
a b c d
e f g h i j
1 2 4 5 63 7
’. The clock will increase
or decrease in one minute increments. If
you press and hold button ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ or ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ for 3
seconds the time will advance quickly.
(Theindication“AUTO”willlightuponthedisplay.)
3. Once desired end time is reached, release the
‘
a b c d
e f g h i j
1 2 4 5 63 7
’ button.
Next dene the length of cooking time:
4. Keep button ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ pressed.
5. Set the desired lenght of the cooking time with
button ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ or ‘
a b c d
e f g h i j
1 2 4 5 63 7
’. The clock will increase
or decrease in one minute increments. If
you press and hold button ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ or ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ for 3
seconds the time will advance quickly.
6. Onec the desired cooking time is programed
release the ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ button.
7. Put your dish into the oven.
8. Select the required operating mode and
temperature.
Theovenwillswitchonforthedenedlengthof
cookingtimepriortospeciedendtime.Duringthe
cooking process, the cooking symbol (
a b c d
e f g h i j
1 2 4 5 63 7
) on the
display is lit.
9. Once the cooking process has been completed
and an alarm will sound and heating of the
oven will stop.
(Theindication“AUTO”onthedisplaygoesoff.)
10. Switch the oven off by rotating the thermostat
and/or the function knob to the off position
(top).
Switch on
semi-automatic operation
Inthismodeofoperation,youcandenewhenthe
oven is to switch off automatically
1. Keep button ‘
a b c d
e f g h i j
1 2 4 5 63 7
’pressedtodenethenish
time or ‘
a b c d
e f g h i j
1 2 4 5 63 7
’todenethelengthofcooking.
2. Set the desired time with the ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ or ‘
a b c d
e f g h i j
1 2 4 5 63 7
’
buttons. The time will increase or decrease in
one minute increments. If you press and hold
button ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ or ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ for 3 seconds the time will
advance quickly.
3. Once desired time is reached, release the ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ or ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ button.
09 - How to operate the Timer

_ 15
User manual LAM4601
How to operate the timer
Theindicationwill“AUTO”lightuponthedisplay.
4. Put your dish into the oven.
5. Select operating mode and temperature.
The oven is heated up to the set temperature and
keeps this temperature until the end of the cooking
time that has been selected. During the cooking
process, the cooking symbol on the display (
a b c d
e f g h i j
1 2 4 5 63 7
) is
lit.
6. Once the cooking process has been completed
and an alarm will sound and heating of the
oven will stop.
7. Switch the oven off with the thermostat knob
and/or the function knob.
8. Finally press the ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ button to switch off the
automatic mode .
Theindication“AUTO”onthedisplaygoesoff.
If you press button ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ during the cooking
process, the display will show the remaining cooking
time for a short moment.
Interrupting the cooking process
1. Keep button ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ pressed.
2. Keep button ‘
a b c d
e f g h i j
1 2 4 5 63 7
’presseduntil“0.00”isshown
as remaining cooking time on the display.
3. Release button both buttons.
4. Finally press the ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ button to switch off the
automatic mode .
»Theindication“AUTO”onthedisplaygoesoff.
5. Switch the oven off by rotating the thermostat
and/or the function knob to the off position
(top).
How to Activate the program lock
1. Keep buttons‘
a b c d
e f g h i j
1 2 4 5 63 7
’ and ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ pressed
simultaneouslyfor8secondsuntil“.On”
appears on the display
2. Press button ‘
a b c d
e f g h i j
1 2 4 5 63 7
’.
Thedisplaywillshow“.oF”for3secondsandakey
symbol will appear.
(The oven timer is now locked.)
Deactivate the program lock
1. Keep buttons‘
a b c d
e f g h i j
1 2 4 5 63 7
’ and ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ pressed
simultaneouslyfor8secondsuntil“.oF”
appears on the display
2. Press button ‘
a b c d
e f g h i j
1 2 4 5 63 7
’.
Thedisplaywillnowshow“.oN”for3seconds.
(Now the oven timer can be used again.)
How to use the minute minder
In addition to using the timer for cooking, it can be
also used as a minute minder / alarm.
Assoonasthedenedperiodoftimehasexpired,
the alarm will signal. The minute minder has no
inuenceonthefunctionsoftheoven.
Setting the minute minder
1. Keep button ‘
a b c d
e f g h i j
1 2 4 5 63 7
’pressed.
2. Set the desired time with the ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ or ‘
a b c d
e f g h i j
1 2 4 5 63 7
’
buttons. The time will increase or decrease in
one minute increments. If you press and hold
button ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ or ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ for 3 seconds the time will
advance quickly.
The alarm clock symbol on the display lights up.
3. Release ‘
a b c d
e f g h i j
1 2 4 5 63 7
’button.
When you press the ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ button while the timer is
activated, the display will show the remaining time
for a brief moment.
Switching off the alarm
1. Press button ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ to silence the alarm sound.
The timer symbol on the display will disappear
In order to cancel the minute minder
1. Keep button ‘
a b c d
e f g h i j
1 2 4 5 63 7
’ pressed.
2. Simultaneously press the‘
a b c d
e f g h i j
1 2 4 5 63 7
’untiluntil“0.00”
is shown as remaining time on the display.
3. Release button all the buttons.
The timer symbol on the display will disappear

16_
LAMONA Appliances
Risk of scalding by hot steam! Take care when
opening the oven door as steam may escape.
Tips for baking
• Use nonstick coated appropriate metal trays
and containers or heat-resistant silicone
moulds.
• Make best use of the space on the shelf.
• It is recommended to place the vessels in the
middle of the shelf.
• Select the correct shelf position before turning
the oven or grill on - don’t move oven shelves
when hot.
• Keep the oven door closed.
Tips for roasting
• Seasoning with lemon juice and black pepper
will improve the cooking performance when
cooking a whole chicken, turkey or a large
piece of meat.
• Meat with bones takes about 15 to 30
minutes longer to cook than a roast of the
same size without bones.
• Let meat rest in the oven for about 10 minutes
after the cooking time. The juices will be better
distributed throught the meat and will not run
out when the meat is cut.
• Fish in a heat proof dish should be placed at
the medium or lower level.
Tips for grilling
• Grillingisidealforcookingmeat,shand
poultry and will achieve nice browning without
drying out the food. Flat pieces, meat skewers
and sausages are particularly suited for
grilling, as are vegetables with a high water
content, such as tomatoes and onions.
• Distribute the pieces to be grilled on the wire
rack.
• Use tray or grill pan under the wire rack in
order to collect dripping fat or juices.
• Adding some water to the grill pan will assist
with cleaning.
10 - Cooking and baking advice
Tips for baking cake
• If the cake is too dry, increase the temperature
by 10°C and decrease the cooking time.
• If the cake is wet, use less liquid or lower the
temperature by 10°C.
• If the cake is too dark on top, place it on
a lower shelf, lower the temperature and
increase the cooking time.
• If cooked well on the inside but sticky on the
outside use less liquid, lower the temperature
and increase the cooking time.
Tips for baking pastry
• If the pastry is too dry, increase the
temperature by 10°C and decrease the
cooking time. Dampen the layers of pastry with
a wash composed of milk, oil, egg.
• If the pastry takes too long to bake, pay
attention that the thickness of the pastry you
have prepared
• If the upper side of the pastry gets browned,
but the lower part is not cooked, make sure
that the amount of wash you have used for the
pastry is not too much at the bottom of the
pastry. Try to spread the wash equally over the
pastry for an even browning.
• Cook the pastry in accordance with the mode
and temperature given in the cooking table. If
the bottom part is still not browned enough,
place it on one lower shelf next time.
Tips for cooking vegetables
• If the vegetable dish runs out of juice and gets
too dry, cook it in a dish with a lid instead of
an open tray. Closed vessels will preserve the
juice of the dish.
• If a vegetable dish is not cooked, boil the
vegetables beforehand.
Cooking and baking advice

_ 17
User manual LAM4601
MAIN OVEN COOKING TABLE
Dish Cooking level Oven Function Temperature °C Cooking Time min
Baking
Cakes in tray*
1 Level 175 30 - 40
2 Levels 175 45 - 50
Cakes in mould* 1 Level 175 50 - 60
Cakes in bun cases
1 Level 175 25 - 35
2 levels 175 35 - 45
3 levels 180 45 - 55
Sponge cake* 1 level 200 8 - 15
Cookies*
1 Level 175 25 - 30
2 levels 170 ... 190 35 - 45
3 levels 175 30 - 40
Dough pastry*
1 Level 200 35 - 45
2 levels 200 50 - 60
3 levels 200 55 - 65
Rich pastry*
1 Level 200 25 - 35
2 levels 200 35 - 45
3 levels 190 45 - 55
Meat
Lasagna* 1 level 200 30 - 40
Roast Beef 1 level 25 min at 250/max
then 180 ... 190 100 - 120
Leg of Lamb 1 level 25 min at 220
then 180 ... 190 70 - 90
Roasted chicken 1 level 25 min at 250/max
then 180 ... 190 55 - 65
Turkey (5.5kg) 1 level 15 min at 250/max
then 190 150 - 210
Fish
Fish 1 level 200 20 - 30
When cooking with 2 trays at the same time, place the deeper tray on the upper rack and the other one on the lower rack.
* It is suggested to perform preheating for all foods
If cooking requires preheating, heat the oven until the thermostat lamp goes out.
The values indicated in the tables below are
indicative. They may vary according to the type of
food as well as your preferences of cooking.
Baking and roasting
Level 1 is the bottom level in the oven.
11 - Cooking Tables
Cooking tables

18_
LAMONA Appliances
TOP OVEN COOKING TABLE
Food Cooking level Oven Function Temperature°C Cooking Time min
Cakes in tray 1 Level 175 25 - 30
Cakes in mould 1 Level 175 25 - 30
Cakes in bun cases 1 Level 175 25 - 30
Cookies 1 Level 175 25 - 30
Dough pastry 1 Level 200 35 - 40
Filled Savoury pastry 1 Level 180 25 - 35
Lasagna 1 level 180 30 - 40
Pizza 1 level 200 15 - 20
Roast Beef 1 level 25 min at 250/max
then 180 ... 190 100 - 120
Leg of Lamb 1 level 25 min at 220
then 180 ... 190 70 - 90
Roasted chicken 1 level 15 min at 250
then 190 55 - 65
Turkey (5.5kg) 1 level 25 min at 250
then 190 150 - 210
Fish 1 level 200 20 - 30
GRILL COOKING TABLE
Food Cooking level Oven Function Cooking Time (min)
Fish 1 Level 20 - 25
Sliced chicken 1 Level 25 - 30
Lamb chops 1 Level 20 - 25
Steak 1 level 25 - 30
Toast 1 Level 1 - 2
Please Note: cooking times may vary depending on their thickness of food
Cooking tables

_ 19
User manual LAM4601
12 - Care and maintenance
General information
Service life of the product will extend and the
possibility of problems will decrease if the product is
cleaned at regular intervals.
Risk of electric shock!
Switch off the electricity before cleaning appliance
to avoid possibility of an electric shock.
Hot surfaces may cause burns!
Allow the appliance to cool down before you clean it.
• Clean the product thoroughly after each use.
This way it will be possible to remove cooking
residues more easily and will avoid burning
them on the next time the appliance is used.
• No special cleaning agents are required for
cleaning the product. Use warm water with
washing liquid, a soft cloth or sponge to clean
the product and wipe with a dry cloth.
• Always ensure any excess liquid is thoroughly
wiped off after cleaning and any spillage is
immediately wiped dry.
• Do not use cleaning agents that contain
acid or chloride to clean the stainless steel
surfaces and the handle. Use a soft cloth with
a liquid detergent (not abrasive) to wipe those
parts clean, paying attention to sweep in a
horizontal direction.
The surface may be damaged by some
detergents or cleaning materials.
Do not use aggressive detergents, cleaning powder/
cream or any sharp objects.
Do not use steam cleaners for cleaning.
Cleaning the control panel
Clean the control panel and control knobs with a
damp cloth and wipe them dry.
Do not remove the control knobs for control
panel cleaning.
Cleaning oven door
Don’t use any harsh abrasive cleaners or sharp
metal scrapers for cleaning the oven door. They
could scratch the surface and damage the glass.
Removal of the oven door
1. Open the door.
2. Unlock the clips at the hinge housing on
the right and left hand sides of the door by
pressing them down as illustrated in the
diagram.
1. Door door
2. Hinge
3. Oven
4. Raise the door to the half-way position.
5. Remove the door by pulling it up-wards to slide
it from the hinges.
Steps carried out during removing process should
be performed in reverse order to reattach the door.
Do not forget to close the clips at the hinge
housing when reinstalling the door.
Care and maintenance

20_
LAMONA Appliances
Removing upper door inner glass
The inner glass panel of the upper oven/grill door
can be removed for cleaning.
In order to do this, use the spade supplied with the
oven as illustrated below.
1. Spade
2. Plastic housing
3. Inner glass
4. Pin
5. Pin housing
6. Metal Frame
• Place the spade at the position indicated
in the diagram and push in the direction
indicated to remove the glass.
• Inordertore-ttheglass,placethelowerside
of the glass to the plastic housings. Push the
glass against the metal frame on the upper
side to secure the pins to the housing.
Replacing the oven lamp
Hot surfaces may cause burns!
Make sure that the appliance is switched off
and cooled down in order to avoid the risk of an
electrical shock or burns.
The oven lamp is a special electric lamp that
can resist up to 300°C. See Technical
specications,fordetails.
Position of lamp might vary from the diagram.
1. Disconnect the product from mains.
2. Turn the glass cover counter clock-wise to
remove it.
3. Remove the oven lamp by turning it counter
clockwise and replace it with the new one.
4. Install the glass cover
Care and maintenance
