Lanier SP 5210SR User manual

User-friendly design, productivity-enhancing results
Choose the Lanier SP 5200S/SP 5210SF/SP 5210SR
for exceptional speed, multifunction versatility and
superior productivity in an intuitive, compact design
D I G I T A L I M A G I N G S Y S T E M
SP 5200S/SP 5210SF/
SP 5210SR
D I G I T A L I M A G I N G S Y S T E M
SP 5200S/SP 5210SF/SP 5210SR
M A I N U N I T
Configuration
Desktop
Printing Technology
Laser beam scanning & electrophotographic
printing; Monocomponent toner development;
All-In-One Print Cartridge Technology
Scanning Technology
Full-Color Flatbed Scanning w/CCD Image Sensor
Scan Type
Sheet, book, three-dimensional objects
Print Speed (LTR)
SP 5200S: 47-ppm, SP 5210SF: 52-ppm,
SP 5210SR: 52-ppm
First Print Speed
7.5 seconds or less
Warm-up Time
20 seconds or less
Grayscale
256 levels
Copy Resolution
600 x 600 dpi via Platen Glass, 600 x 300 dpi
via ARDF
Print Resolution
1200 x 600 dpi, 600 x 600 dpi, 300 x 300 dpi
Fax Resolution
200 x 200 dpi, 200 x 100 dpi standard; 200 x
400 dpi, 400 x 400 dpi with optional memory
Document Feeding
Automatic Reversing Document Feeder
(Standard); Original Capacity: 50 sheets
Original Size: 5.5" x 8.5" – 8.5" x 14" (128 mm
x 139.7 mm – 216 mm x 355.6 mm);
Custom: Up to 49.6" (1260 mm) (Simplex only)
Max. Imageable Area
Platen: 8.5" x 11.69" (216 x 297 mm)
ARDF: 8.5" x 49.6" (216 x 1260 mm)
Multiple Copies
Up to 999
Zoom
Platen: 25% – 400% in 1% increments
ARDF: 25% – 200% in 1% increments
Preset Reduction
93%, 78%, 65%
Preset Enlargement
155%, 129%
Standard Paper Supply
550-sheet Tray + 100-sheet Bypass = 650 sheets
Optional Paper Supply
550-sheet Paper Feed Unit (Up to 3 may be
installed)
Max. Paper Capacity
2,300 sheets
Automatic Duplexing
Standard, up to 8.5" x 14" (Approx. 90%
productivity)
Output Capacity
SP 5200S: 500 sheets face down; SP 5210SF:
600 sheets face down (w/1Bin Tray); SP 5210SR:
250 sheets face down (w/Finisher)
Paper Sizes
Standard Tray, Standard Sizes: Letter, Legal,
Executive, Half Letter, A4, A5, A6, B5, B6, F/GL,
Foolscap, Folio; Envelopes: Com10, Monarch,
C6, C5, DL. Custom Sizes: Width: 3.86" – 8.5"
(98 mm – 216 mm), Length: 5.52" – 14.01"
(140 mm – 356 mm). Bypass Tray, Standard
Sizes: Letter, Legal, Executive, Half Letter, A4,
A5, A6, B5, B6, F/GL, Foolscap, Folio; Envelopes:
Com10, Monarch, C6, C5, DL. Custom Sizes:
Width: 2.52" – 8.5" (64 mm – 216 mm),
Length: 5.52" – 35.43" (140 mm – 900 mm).
Optional PFU(s), Standard Sizes: Letter, Legal,
Executive, Half Letter, A4, A5, B5, B6, F/GL,
Foolscap, Folio; Envelopes: Com10, Monarch,
C6, C5, DL. Custom Sizes: Width: 3.86" – 8.5"
(98 mm – 216 mm), Length: 6.3" – 14.01"
(160 mm – 356 mm)
Paper Weights
Standard & Optional Tray(s): 14 – 59 lb. Bond/
120 lb. Index (52 – 220 g/m
2
)
Bypass Tray: 14 – 59 lb. Bond/120 lb. Index
(52 – 220 g/m
2
). When Duplexing: 16 – 44 lb.
Bond/90 lb. Index (60 – 163 g/m
2
)
Paper Types (all sources)
Plain Paper, Recycled Paper, Middle Thick Paper,
Thick Paper, Thin Paper, Transparency, Letterhead,
Label, Color, Preprinted, Envelopes
Dimensions (WxDxH)
SP 5200S: 18.1" x 20" x 27" (460 mm x 510 mm
x 686 mm); SP 5210SF: 18.1" x 20" x 27" (460 mm
x 510 mm x 686 mm); SP 5210SR: 18.1" x 24.2"
x 27" (460 mm x 615 mm x 686 mm)
Weight
SP 5200S: 99.2 lb. (45 kg); SP 5210SF: 103.6 lb.
(47 kg); SP 5210SR: 116.8 lb. (53 kg)
Power Requirements
120 – 127V, 60Hz
Power Consumption
Operating: SP 5200S: 863 W, SP 5210SF: 892 W,
SP 5210SR: 858 W
Energy Saver: 8 W or less
Safety Regulations
UL60950-1, CAN/CSA C22.2 No.60950-1 (c-UL)
EMI
FCC Part 15 Subpart B, IC ES-003
Environmental Standard
ENERGY STAR Tier 2, ECP
Average Monthly Volume
5,500 – 15,000 total impressions/month
Maximum Duty Cycle
Up to 200,000 total impressions/month
P R I N T C O N T R O L L E R
CPU
533 MHz
Memory
1 GB RAM standard/maximum
Hard Disk Drive*
128 GB (standard)
*Includes HDD Encryption Unit and Overwrite (DOSS)
Interfaces
Standard: 10/100Base-TX Ethernet, USB 2.0 Hi
Speed Type B (for direct computer connection),
Dual USB 2.0 Host Interfaces Type A (for external
device connection), Front USB 2.0/SD Card
Slot Interface (for Scan To/Print From portable
media). Optional: Gigabit Ethernet (1000Base-T),
IEEE 802.11a/g Wireless, Bluetooth
Printer Languages/Drivers
PCL 5e, PCL 6, XPS, Adobe PostScript3
®
, PDF
Direct Print, Genuine IPDS (optional)
Fonts
PCL: 45 fonts + 13 International fonts; Post-
Script 3: 136 fonts; IPDS: 108 fonts (optional)
Supported Environments
Windows XP, Vista, 7, Server 2003/2003R2,
Server 2008/2008R2, Mac OS X v.10.2+, Novell
NetWare v 6.5+, Citrix Presentation Server,
UNIX/Linux
Network Protocols
TCP/IP (IPv4, IPv6), IPX/SPX, Bonjour
Software Utilities
Bundled Utilities: Web Image Monitor,
Font Manager 2000. Optional Utilities:
SmartDeviceMonitor for Admin Acounting
Package, SmartDeviceMonitor for Client,
DeskTopBinder Lite, @Remote Communication
Gate S Pro
Standard Security Features
Administrator Authentication (5 levels), User
Authentication (5 types), HDD Overwrite (DOSS)
& Data Encryption, Secure Print, Encrypted
Secure Print, Encrypted PDF Mode, Scan-to-
Web Mail (SMTP over SSL), IP Address Filtering,
Transport Layer Security (TLS), SSL Communication,
IPv6, IP Sec, SNMPv3, Quota Setting
Controller Options
IEEE802.11 a/g Interface Unit Type J; Gigabit
Ethernet Board Type C; Bluetooth Interface Unit
Type D; IPDS Unit Type 5210; Data Overwrite
Security Unit Type I*; Remote Communication
Gate A; Fax Option Type SP5200; Fax Memory
Unit Type B 32MB; Telephone Handset Type
1018; HotSpot MFP Option Type E; Browser Unit
Type E; File Format Converter Type E
*For Common Criteria Certification (CCC) use. Certification pending.
S C A N N E R
Scanner Type
Full Color CCD
Scanning Resolutions
Scan-To Modes: 100/200/300/400/600 dpi
(Black & White, ARDF & Platen); 100/200/300
dpi (Full Color, ARDF); 100/200/300/400/600
dpi (Full Color, Platen). TWAIN/WSD/ WIA: 100
– 600 dpi in 1% increments (Black & White,
ARDF); 100 – 1200 dpi in 1% increments
(Black & White, Platen); 100 – 600 dpi in 1%
increments (Full Color, ARDF & Platen)
Default Resolution
200 dpi
Scanning Speed
Over 30-ipm (B&W/FC, LTR @ 200 dpi)
Max. Original Size
Platen: Up to 8.5" x 11.7" (216 mm x 297 mm);
ARDF: Up to 8.5" x 49.6" (216mm x 1260 mm)
Protocols
Network: TCP/IP; Scan-to-Email: POP, SMTP;
Scan-to-Folder: SMB, FTP, NCP
Scan Modes
B&W Text, B&W Text/Line Art, B&W Text/Photo,
B&W Photo, Grayscale, Full-Color Text/Photo,
Full-Color Glossy Photo, Auto Color Select (ACS)
Image Density
Auto + 7-step Manual scale
Image Rotation
Supported
SADF/Batch Mode
Supported
Supported File Formats
Single/Multi Page TIFF, Single Page JPEG, Single/
Multi Page PDF, High Compression PDF
Scan-To Modes
Scan-to-Email, Scan-to-Folder (SMB/FTP/NCP);
Scan-to-URL, Scan-to-Media (USB/SD Card)
Scan-to-Email
Standard; Authorization: SMTP authentication,
POP before SMTP authentication
Max. Addresses/Send
500; Attention: To, cc, bcc
LDAP Search
Supported
Maintain E-mail Address
Direct input from control panel, Web Image
Monitor, SmartDeviceMonitor for Admin
E-mail Attachments
Up to 2 GB without restriction
Input File Name
Yes
Input Subject
Up to 128 characters
Input Body Message
Up to 80 characters + 5 pre-registered messages
Scan-to-Folder
Standard; Protocol Support: SMB, FTP, NCP
Maintain Address
Direct input from control panel, Web Image
Monitor, SmartDeviceMonitor for Admin
Max. Folders/Send
100
Max. Addresses/Send
500
File Attachment Size
Up to 2000 MB
Input File Name
Yes
Network TWAIN Scanning
Standard – All models + Web Services (WSD)
Scanner for Vista; Operating Systems: Windows
XP, Server 2003, Vista, 7, Server 2008/R2; Scan
Modes: Standard, Photo, OCR, Filing; Image
Adjustment: Brightness, Contrast, Threshold,
Gamma Adjustment, Halftone Pattern
Endorse
Date, Page Number, Text
D O C U M E N T S E R V E R
Total HDD Capacity
128 GB (Shared with other functions)
Max. Stored Documents
3,000 documents
Max. Pages per Document
2,000 pages
F A X O P T I O N T Y P E S P 5 2 0 0
(Standard for SP 5210SF, Optional for SP 5200S/ 5210SR)
Type
Super G3 Transceiver
Circuit
PSTN, PBX
Number of Lines
1
Compatibility
ITU-T, Group 3
Resolution (dpi)
200 x 100, 200 x 200, 200 x 400, 400 x 400
(for Internet & IP Fax, requires optional SAF
memory)
Modem Speed
33,600 bps – 2,400 bps w/Auto Fallback
Compression Method
MH, MR, MMR, JBIG
Transmission Speed
G3: Approximately 2 seconds/page (w/JBIG)
G3: Approximately 3 seconds/page (w/MMR)
Scanning Speed
Up to 40-ppm (B&W, LTR @ 200 x 100 dpi)
Original Capacity/Size
See Scanner & Document Feeding Specifications
Auto Dialing
Up to 2,000 Quick Dial numbers in Address Book
100 Group Dial numbers (500 locations per Group)
Page Memory Capacity
Standard: 4 MB RAM (approx. 320 pages)
Maximum: 28 MB RAM (approx. 2,240 pages)
Memory Backup
1 hour
Additional Fax Modes
LAN Fax, Internet Fax (T.37), IP Fax (T.38)
LAN Fax
Standard on SP 5210SF, requires Fax Option Type
5200 for SP 5200S and SP 5210SR; Connection;
10/100Base-TX Ethernet, IEEE 802.11 a/g Wireless,
or Gigabit Ethernet interface; Protocol: G3; Max.
Addresses Per TX: 500; Operating Systems:
Windows XP, Server 2003, Vista, 7, Server 2008/
R2; Document Size: Letter, Legal, A4, A5
Internet Fax
Standard on SP 5210SF, requires Fax Option Type
5200 for SP 5200S and SP 5210SR; Connection:
10/100Base-TX Ethernet, IEEE 802.11 a/g Wireless,
or Gigabit Ethernet interface; Protocol: T.37 Full
Mode; Max. Addresses Per TX: 500; Transmission
Function: Conversion of files to TIFF format for
E-mail TX to a PC; Original Size: Letter, A4
IP Fax
Standard on SP 5210SF, requires Fax Option Type
5200 for SP 5200S and SP 5210SR; Connection:
10/100Base-TX Ethernet, IEEE 802.11 a/g Wireless,
or Gigabit Ethernet interface; Protocol: T.38,
TCP, UDP/IP communication; TX/RX Function:
To/from IP Fax compatible machines via network;
To/from G3 Fax machines via VoIP gateway;
Original Size: Letter, A4 (216 mm x 356 mm);
Custom: Up to 8.5" x 47" (216 mm x 1200 mm)
H A R D W A R E A C C E S S O R I E S
Optional Paper Feed Unit (TK1090)
Capacity
550 sheets, 1 or 2 units may be installed
Paper Size Range
3.86" x 6.3" – 8.5" x 14.01" (98 mm x 160 mm
– 216 mm x 356 mm)
Paper Weight
14 lb. Bond – 80 lb. Cover/120 lb. Index
(52 – 220 g/m
2
)
Dimensions (WxDxH)
17.8" x 20.3" x 5.9" (450 mm x 516 mm x 150 mm)
Weight
19.9 lb (9.0 kg)
Optional Paper Feed Unit with Casters (TK1100)
Capacity
550 sheets, 1 unit may be installed as bottom PFU
Paper Size Range
3.86" x 6.3" – 8.5" x 14.01" (98 mm x 160 mm
– 216 mm x 356 mm)
Paper Weight
14 lb. Bond – 80 lb. Cover/120 lb. Index
(52 – 220 g/m
2
)
Dimensions (WxDxH)
24.7" x 25.0" x 8.7" (627 mm x 635 mm x
220 mm) (including casters)
Weight
26.5 lb (12.0 kg)
Internal Finisher (Standard for SP 5210SR only)
Tray Capacity
250 sheets
Modes
Shift Sort, Stack, Staple
Paper Weight
14 – 59 lb. Bond/120 lb. Index (52 – 220 g/m
2
)
Stapling
1 position; Top parallel
Staple Sheet Sizes
Letter, Legal, Executive, A4, B5, Foolscap, Folio, F
Staple Capacity
50 sheets/set (Letter)
(21 lb. Bond, 80g/m
2
)
30 sheets/set (Legal)
Stack Capacity after Stapling
2 sheets: 33 sets; 30 sheets: 7 sets; 50 sheets: 4 sets
Staple Paper Weight
14 – 24 lb. Bond (52 – 90 g/m
2
)
Staple Cartridge Capacity
5,000 staples
1-Bin Tray (Standard for SP 5210SF only)
Tray Capacity
100 sheets
Paper Weight
14 lb. Bond – 80 lb. Cover/120 lb. Index
(52 – 220 g/m
2
)
S U P P L I E S A N D C O N S U M A B L E S
Item Yield
Black AIO Print Cartridge
25,000 pages*
SP 5200HA
Staple Type T
5,000/carton
Refill Staple Type T
10,000/carton
Maintenance Kit SP 5200
120,000 pages
Includes 1 Fusing Unit, 1 Transfer Roller, 5 Feed Rollers and 5 Friction Pads
*Declared yield values based on ISO/IEC 19752. Actual yields may vary based on types
of images printed and other factors.
The Lanier SP 5200S/SP 5210SF/SP 5210SR ships with one starter AIO cartridge yielding
6,000 pages. All other consumables ship at full yield.
For maximum performance and yield, we recommend using genuine Lanier parts
and supplies.
Specifications subject to change without notice.
W A R R A N T Y
The Lanier SP 5200S/SP 5210SF/SP 5210SR is under warranty against defects for a period
of one year from the date of purchase. Consumables are under warranty for a period of
90 days from the date of purchase or until depleted, whichever comes first. Please refer
to warranty documents shipped with the product for more details.
L3288
www.lanier.com
Lanier, Five Dedrick Place, West Caldwell, NJ 07006
Lanier® and the Lanier Logo are registered trademarks of Ricoh Americas Corporation. All other trademarks are the property of their respective owners. The content of this document,
and the appearance, features and specifications of Lanier products and services are subject to change from time to time without notice. Products are shown with optional features.
While care has been taken to ensure the accuracy of this information, Lanier makes no representation or warranties about the accuracy, completeness or adequacy of the information
contained herein, and shall not be liable for any errors or omissions in these materials. Actual results will vary depending upon use of the products and services, and the conditions and
factors affecting performance. The only warranties for Lanier products and services are as set forth in the express warranty statements accompanying them.
SP 5200S/SP 5210SF/SP 5210SR
User-friendly design improves office productivity.
Standard 550-Sheet Paper Tray
Front-facing, user-adjustable paper trays
accommodate envelopes and paper sizes
up to 8.5" x 14" and stock weights up
to 80 lb. Bond/120 lb. Index.
User-Adjusted LCD Control Panel*
See the easy-to-read, tilted control panel
comfortably from virtually anywhere.
Super G3 Faxing
Perform a variety of fax functions with pre-
programmed speed, quick and group dial
shortcuts on the SP 5210SF. A 1-Bin Tray is
included to collect inbound faxes.
100-Sheet Bypass Tray
Extend paper sizes up to 35" long for
banner production.
50-Sheet Automatic Reversing
Document Feeder (ARDF)
Process originals efficiently—up to
8.5" x 14" and custom banner
scanning up to 49" long—to speed
the scanning process.
Internal Finisher
Staple up to 50 pages and stack up
to 250 sheets with the space-saving
internal finisher on the SP 5210SR.
Duplex Unit
Copy and print on both sides of
each sheet of paper, reducing paper
usage by half.
Easy-Grip Paper Tray Handles
Open and close doors with only
one hand, sitting or standing.
3 x 550-Sheet Paper Trays
Add up to three additional paper
trays to expand paper capacity to
2,300 sheets.
Pre-configured to
meet your needs.
Model SP 5200S SP 5210SF SP 5210SR
Standard Functions Copy / Print / Scan Copy / Print / Scan / Fax Copy / Print / Scan / Finishing
Print Speed 47 cpm/ppm 52 cpm/ppm
Super G3 Faxing Optional Standard Optional
Color Touch Panel Fixed Placement Adjustable
Internal Staple Finisher N/A N/A Standard
Inner 1-Bin Tray N/A Standard N/A
Output Capacity 500 sheets 600 sheets 250 sheets
*SP 5210SF and SP 5210SR only.
• Convert hardcopy documents to electronic files and incorporate
them into new documents using TWAIN scanning capabilities.
• Send scanned documents to hundreds of recipients cost-free over
the network in one operation with Scan-to-Email/Folder/URL with
LDAP support.
• Quickly transfer documents and images to portable media with
Scan-to-Media (USB/SD Card) to streamline distribution in any
environment.
• Reduce file sizes for scanned color documents without compromising
image quality with high compression PDF for faster transmission and
printing.
Connect Your User Network
The Lanier SP 5200S/SP 5210SF/SP 5210SR includes
flexible networking support that enables workgroups
to produce a wide range of jobs efficiently.
• Use the robust Controller to support advanced networking features,
device monitoring utilities and data protection functions, including
innovative device customization and host print capabilities.
• Complete multiple projects with ease. Powerful performance from
the 533 MHz processor provides the bandwidth to prepare data
streams and expedite project queues to meet the needs of corporate
workgroups with 8.5" x 11"/A4 monochrome workflows.
• Enjoy full compatibility throughout the office with standard USB 2.0
Hi Speed Interface and Ethernet connectivity, including support for
PCL and genuine Adobe PostScript3® in Windows and Macintosh
network environments.
• Store up to 3,000 documents (up to 9,000 pages) on the powerful
128 GB Hard Disk Drive for easy, secure document management.
Handle Every Task
Engineered to help users complete everyday office
tasks with ease, the Lanier SP 5200S/SP 5210SF/SP
5210SR offers flexible media handling and finishing
to expedite workflow.
• Support up to 8.5" x 14" paper sizes with front-loading, user-
adjustable paper sources.
• Increase paper supply without compromising floor space. Up to
three additional paper trays can be added for a maximum paper
capacity of 2,300 sheets.
• Finish sets up to 50 pages automatically, and offset stack up to
250 sheets, with the internal finisher that comes standard on
the SP 5210SR.
• Accommodate stocks up to 59 lb. Bond/120 lb. Index (220
g/m2) from any paper source to ensure print jobs are executed
on time and deadlines are met.
• Enhance envelope output productivity with universal feeding.
• Extend acceptable paper sizes up to 35" long in the bypass tray to
accommodate banner printing and keep more projects in house.
Manage More Conveniently
Designed to simplify administrative and maintenance
tasks, the Lanier SP 5200S/SP 5210SF/SP 5210SR
includes user-friendly controls for convenient,
intuitive operation.
•
Maximize uptime, streamline maintenance and reduce cost-per-page
output with a high-yield, 25,000-page AIO print cartridge. When
depleted, users can quickly replace the cartridge without technical
assistance and recycle the spent cartridge with a provided return label.
• Gain clear, unobstructed access to critical device information from
virtually any angle with an innovative 8.5" full-color tilting LCD panel.*
•
Perform all of your general office tasks from a single machine without
compromising floor space or your budget. The compact footprint
offers users more options for placement in more office environments.
• Access most functions, including all paper sources and the print
cartridge, in even the tightest spaces via the forward-facing design.
• Set dozens of system parameters such as paper supplies and user
authentication from the desktop with Web Image Monitor.
• Monitor device usage in real time with the Lanier @Remote™
Intelligent Management System and receive service notifications
quickly to minimize downtime.
Protect Document Integrity
Ensure the right information gets in the right hands
with advanced security features that can protect
sensitive information from a multitude of threats.
• Restrict access to system functions with user authentication. Up to
500 user codes can be registered and assigned for optimal efficiency
in larger workgroups.
• Ensure optimal data protection with the Data OverwriteSecuritySystem
(DOSS). When enabled, it destroys latent images and data from the
internal hard drive to prevent document reconstruction.
• Stifle attempts by hackers to steal print job data and passwords
transmitted over the LAN with SSL Data Encryption or Wi-Fi Protect
Access Support.
• Choose the optional Enhanced Locked Print-NX to store print jobs
with encrypted data at the MFP until the user swipes an ID card or
enters ID information at the control panel to release the job.
Share Information Cost-Effectively
The Lanier SP 5200S/SP 5210SF/SP 5210SR offers a host
of scanning capabilities to make electronic document
capture and distribution quick, easy and free.
• Speed scanning tasks with the 50-sheet Automatic Reversing
Document Feeder (ARDF). It accepts originals up to 8.5" x 14"
(up to 49" long in custom mode for banner scanning) for incredible
flexibility and productivity.
The adjustable full-color touch screen control panel on the
SP 5210SF and SP 5210SR can be tilted to give users greater
visibility and easy access to the 1-bin and finisher trays. It even
offers animated guidance screens for step-by-step instructions.
These flexible systems can be configured for desk or floor
placement. Stack up to 3 optional Paper Feed Units to boost
input capacity to 2,300 sheets.* The Paper Feed Unit TK1100
with casters is designed specifically for floor placement.
*Requires the assistance of a service technician.
A USB Type A port is conveniently located in the control panel
for quick and easy printing from/scanning to removable media.
The Total Green Office Solution
Lanier continues its long-standing
commitment to developing office solutions
with environmentally friendly and superior
energy- and supply-saving features, without
compromising productivity.
Turn new challenges and everyday demands
into cost-saving opportunities—with the flexible
LANIER® SP 5200S/SP 5210SF/SP 5210SR Digital
Imaging System. The powerful system is specifically
designed to simplify everyday general office
tasks for midsize workgroups. Users can quickly
access exceptional multifunction performance—
including monochrome copy, color scan, print and
fax capabilities—to complete a wide range of
projects faster with incredibly low cost-per-page.
Ideal for busier workloads, it offers incredible
speed, quality, finishing and intuitive controls to
streamline workflow so you can manage your
documents more efficiently. Its compact design is
packed with versatility for optimal production and
value. Plus, it’s ideal for organizations deploying a
print management solution with Lanier’s Managed
Document Services (MDS)
.
Deliver More Efficiently
Complete more projects and meet even
the busiest office demands in less time.
The Lanier SP 5200S/SP 5210SF/SP 5210SR
offers a wide range of innovative features to
improve productivity.
• Boost throughput with exceptional print speeds. The
SP 5200S generates up to 47 pages-per-minute. The SP
5210SF and SP 5210SR print up to 52 pages-per-minute.
• Produce crisp, sharp text at up to 1200 x 600 dpi
resolution for high-quality, compelling results.
• Take advantage of easy-to-use scanning capabilities
to simplify workflow with cost-effective electronic
document storage and distribution.
• Work quickly with near-instant system readiness. Warm-
up time is less than 20 seconds and first print/copy times
are less than 8 seconds.
• Reduce paper, mailing costs and filing space with
standard automatic duplexing at nearly 90% of rated
simplex speeds.
• Maximize convenience with paperless faxing. Super G3
faxing, Internet Fax, IP Fax, and LAN Fax support come
standard on the SP 5210SF and are optional on the
SP 5200S and SP 5210SR.
The Lanier SP 5200S/SP 5210SF/
SP 5210SR combines multifunction
performance with user-friendly
convenience to streamline workflow
for mid-size workgroups in a wide
range of environments.
SP 5200S/SP 5210SF/SP 5210SR
More efficiency and value for everyday office tasks
desk
Paper Feed
Unit
TK1090
Paper Feed
Unit
TK1100
floor
*SP 5210SF and SP 5210SR only.
• Convert hardcopy documents to electronic files and incorporate
them into new documents using TWAIN scanning capabilities.
• Send scanned documents to hundreds of recipients cost-free over
the network in one operation with Scan-to-Email/Folder/URL with
LDAP support.
• Quickly transfer documents and images to portable media with
Scan-to-Media (USB/SD Card) to streamline distribution in any
environment.
• Reduce file sizes for scanned color documents without compromising
image quality with high compression PDF for faster transmission and
printing.
Connect Your User Network
The Lanier SP 5200S/SP 5210SF/SP 5210SR includes
flexible networking support that enables workgroups
to produce a wide range of jobs efficiently.
• Use the robust Controller to support advanced networking features,
device monitoring utilities and data protection functions, including
innovative device customization and host print capabilities.
• Complete multiple projects with ease. Powerful performance from
the 533 MHz processor provides the bandwidth to prepare data
streams and expedite project queues to meet the needs of corporate
workgroups with 8.5" x 11"/A4 monochrome workflows.
• Enjoy full compatibility throughout the office with standard USB 2.0
Hi Speed Interface and Ethernet connectivity, including support for
PCL and genuine Adobe PostScript3® in Windows and Macintosh
network environments.
• Store up to 3,000 documents (up to 9,000 pages) on the powerful
128 GB Hard Disk Drive for easy, secure document management.
Handle Every Task
Engineered to help users complete everyday office
tasks with ease, the Lanier SP 5200S/SP 5210SF/SP
5210SR offers flexible media handling and finishing
to expedite workflow.
• Support up to 8.5" x 14" paper sizes with front-loading, user-
adjustable paper sources.
• Increase paper supply without compromising floor space. Up to
three additional paper trays can be added for a maximum paper
capacity of 2,300 sheets.
• Finish sets up to 50 pages automatically, and offset stack up to
250 sheets, with the internal finisher that comes standard on
the SP 5210SR.
• Accommodate stocks up to 59 lb. Bond/120 lb. Index (220
g/m2) from any paper source to ensure print jobs are executed
on time and deadlines are met.
• Enhance envelope output productivity with universal feeding.
• Extend acceptable paper sizes up to 35" long in the bypass tray to
accommodate banner printing and keep more projects in house.
Manage More Conveniently
Designed to simplify administrative and maintenance
tasks, the Lanier SP 5200S/SP 5210SF/SP 5210SR
includes user-friendly controls for convenient,
intuitive operation.
•
Maximize uptime, streamline maintenance and reduce cost-per-page
output with a high-yield, 25,000-page AIO print cartridge. When
depleted, users can quickly replace the cartridge without technical
assistance and recycle the spent cartridge with a provided return label.
• Gain clear, unobstructed access to critical device information from
virtually any angle with an innovative 8.5" full-color tilting LCD panel.*
•
Perform all of your general office tasks from a single machine without
compromising floor space or your budget. The compact footprint
offers users more options for placement in more office environments.
• Access most functions, including all paper sources and the print
cartridge, in even the tightest spaces via the forward-facing design.
• Set dozens of system parameters such as paper supplies and user
authentication from the desktop with Web Image Monitor.
• Monitor device usage in real time with the Lanier @Remote™
Intelligent Management System and receive service notifications
quickly to minimize downtime.
Protect Document Integrity
Ensure the right information gets in the right hands
with advanced security features that can protect
sensitive information from a multitude of threats.
• Restrict access to system functions with user authentication. Up to
500 user codes can be registered and assigned for optimal efficiency
in larger workgroups.
• Ensure optimal data protection with the Data OverwriteSecuritySystem
(DOSS). When enabled, it destroys latent images and data from the
internal hard drive to prevent document reconstruction.
• Stifle attempts by hackers to steal print job data and passwords
transmitted over the LAN with SSL Data Encryption or Wi-Fi Protect
Access Support.
• Choose the optional Enhanced Locked Print-NX to store print jobs
with encrypted data at the MFP until the user swipes an ID card or
enters ID information at the control panel to release the job.
Share Information Cost-Effectively
The Lanier SP 5200S/SP 5210SF/SP 5210SR offers a host
of scanning capabilities to make electronic document
capture and distribution quick, easy and free.
• Speed scanning tasks with the 50-sheet Automatic Reversing
Document Feeder (ARDF). It accepts originals up to 8.5" x 14"
(up to 49" long in custom mode for banner scanning) for incredible
flexibility and productivity.
The adjustable full-color touch screen control panel on the
SP 5210SF and SP 5210SR can be tilted to give users greater
visibility and easy access to the 1-bin and finisher trays. It even
offers animated guidance screens for step-by-step instructions.
These flexible systems can be configured for desk or floor
placement. Stack up to 3 optional Paper Feed Units to boost
input capacity to 2,300 sheets.* The Paper Feed Unit TK1100
with casters is designed specifically for floor placement.
*Requires the assistance of a service technician.
A USB Type A port is conveniently located in the control panel
for quick and easy printing from/scanning to removable media.
The Total Green Office Solution
Lanier continues its long-standing
commitment to developing office solutions
with environmentally friendly and superior
energy- and supply-saving features, without
compromising productivity.
Turn new challenges and everyday demands
into cost-saving opportunities—with the flexible
LANIER® SP 5200S/SP 5210SF/SP 5210SR Digital
Imaging System. The powerful system is specifically
designed to simplify everyday general office
tasks for midsize workgroups. Users can quickly
access exceptional multifunction performance—
including monochrome copy, color scan, print and
fax capabilities—to complete a wide range of
projects faster with incredibly low cost-per-page.
Ideal for busier workloads, it offers incredible
speed, quality, finishing and intuitive controls to
streamline workflow so you can manage your
documents more efficiently. Its compact design is
packed with versatility for optimal production and
value. Plus, it’s ideal for organizations deploying a
print management solution with Lanier’s Managed
Document Services (MDS)
.
Deliver More Efficiently
Complete more projects and meet even
the busiest office demands in less time.
The Lanier SP 5200S/SP 5210SF/SP 5210SR
offers a wide range of innovative features to
improve productivity.
• Boost throughput with exceptional print speeds. The
SP 5200S generates up to 47 pages-per-minute. The SP
5210SF and SP 5210SR print up to 52 pages-per-minute.
• Produce crisp, sharp text at up to 1200 x 600 dpi
resolution for high-quality, compelling results.
• Take advantage of easy-to-use scanning capabilities
to simplify workflow with cost-effective electronic
document storage and distribution.
• Work quickly with near-instant system readiness. Warm-
up time is less than 20 seconds and first print/copy times
are less than 8 seconds.
• Reduce paper, mailing costs and filing space with
standard automatic duplexing at nearly 90% of rated
simplex speeds.
• Maximize convenience with paperless faxing. Super G3
faxing, Internet Fax, IP Fax, and LAN Fax support come
standard on the SP 5210SF and are optional on the
SP 5200S and SP 5210SR.
The Lanier SP 5200S/SP 5210SF/
SP 5210SR combines multifunction
performance with user-friendly
convenience to streamline workflow
for mid-size workgroups in a wide
range of environments.
SP 5200S/SP 5210SF/SP 5210SR
More efficiency and value for everyday office tasks
desk
Paper Feed
Unit
TK1090
Paper Feed
Unit
TK1100
floor
*SP 5210SF and SP 5210SR only.
• Convert hardcopy documents to electronic files and incorporate
them into new documents using TWAIN scanning capabilities.
• Send scanned documents to hundreds of recipients cost-free over
the network in one operation with Scan-to-Email/Folder/URL with
LDAP support.
• Quickly transfer documents and images to portable media with
Scan-to-Media (USB/SD Card) to streamline distribution in any
environment.
• Reduce file sizes for scanned color documents without compromising
image quality with high compression PDF for faster transmission and
printing.
Connect Your User Network
The Lanier SP 5200S/SP 5210SF/SP 5210SR includes
flexible networking support that enables workgroups
to produce a wide range of jobs efficiently.
• Use the robust Controller to support advanced networking features,
device monitoring utilities and data protection functions, including
innovative device customization and host print capabilities.
• Complete multiple projects with ease. Powerful performance from
the 533 MHz processor provides the bandwidth to prepare data
streams and expedite project queues to meet the needs of corporate
workgroups with 8.5" x 11"/A4 monochrome workflows.
• Enjoy full compatibility throughout the office with standard USB 2.0
Hi Speed Interface and Ethernet connectivity, including support for
PCL and genuine Adobe PostScript3® in Windows and Macintosh
network environments.
• Store up to 3,000 documents (up to 9,000 pages) on the powerful
128 GB Hard Disk Drive for easy, secure document management.
Handle Every Task
Engineered to help users complete everyday office
tasks with ease, the Lanier SP 5200S/SP 5210SF/SP
5210SR offers flexible media handling and finishing
to expedite workflow.
• Support up to 8.5" x 14" paper sizes with front-loading, user-
adjustable paper sources.
• Increase paper supply without compromising floor space. Up to
three additional paper trays can be added for a maximum paper
capacity of 2,300 sheets.
• Finish sets up to 50 pages automatically, and offset stack up to
250 sheets, with the internal finisher that comes standard on
the SP 5210SR.
• Accommodate stocks up to 59 lb. Bond/120 lb. Index (220
g/m2) from any paper source to ensure print jobs are executed
on time and deadlines are met.
• Enhance envelope output productivity with universal feeding.
• Extend acceptable paper sizes up to 35" long in the bypass tray to
accommodate banner printing and keep more projects in house.
Manage More Conveniently
Designed to simplify administrative and maintenance
tasks, the Lanier SP 5200S/SP 5210SF/SP 5210SR
includes user-friendly controls for convenient,
intuitive operation.
•
Maximize uptime, streamline maintenance and reduce cost-per-page
output with a high-yield, 25,000-page AIO print cartridge. When
depleted, users can quickly replace the cartridge without technical
assistance and recycle the spent cartridge with a provided return label.
• Gain clear, unobstructed access to critical device information from
virtually any angle with an innovative 8.5" full-color tilting LCD panel.*
•
Perform all of your general office tasks from a single machine without
compromising floor space or your budget. The compact footprint
offers users more options for placement in more office environments.
• Access most functions, including all paper sources and the print
cartridge, in even the tightest spaces via the forward-facing design.
• Set dozens of system parameters such as paper supplies and user
authentication from the desktop with Web Image Monitor.
• Monitor device usage in real time with the Lanier @Remote™
Intelligent Management System and receive service notifications
quickly to minimize downtime.
Protect Document Integrity
Ensure the right information gets in the right hands
with advanced security features that can protect
sensitive information from a multitude of threats.
• Restrict access to system functions with user authentication. Up to
500 user codes can be registered and assigned for optimal efficiency
in larger workgroups.
• Ensure optimal data protection with the Data OverwriteSecuritySystem
(DOSS). When enabled, it destroys latent images and data from the
internal hard drive to prevent document reconstruction.
• Stifle attempts by hackers to steal print job data and passwords
transmitted over the LAN with SSL Data Encryption or Wi-Fi Protect
Access Support.
• Choose the optional Enhanced Locked Print-NX to store print jobs
with encrypted data at the MFP until the user swipes an ID card or
enters ID information at the control panel to release the job.
Share Information Cost-Effectively
The Lanier SP 5200S/SP 5210SF/SP 5210SR offers a host
of scanning capabilities to make electronic document
capture and distribution quick, easy and free.
• Speed scanning tasks with the 50-sheet Automatic Reversing
Document Feeder (ARDF). It accepts originals up to 8.5" x 14"
(up to 49" long in custom mode for banner scanning) for incredible
flexibility and productivity.
The adjustable full-color touch screen control panel on the
SP 5210SF and SP 5210SR can be tilted to give users greater
visibility and easy access to the 1-bin and finisher trays. It even
offers animated guidance screens for step-by-step instructions.
These flexible systems can be configured for desk or floor
placement. Stack up to 3 optional Paper Feed Units to boost
input capacity to 2,300 sheets.* The Paper Feed Unit TK1100
with casters is designed specifically for floor placement.
*Requires the assistance of a service technician.
A USB Type A port is conveniently located in the control panel
for quick and easy printing from/scanning to removable media.
The Total Green Office Solution
Lanier continues its long-standing
commitment to developing office solutions
with environmentally friendly and superior
energy- and supply-saving features, without
compromising productivity.
Turn new challenges and everyday demands
into cost-saving opportunities—with the flexible
LANIER® SP 5200S/SP 5210SF/SP 5210SR Digital
Imaging System. The powerful system is specifically
designed to simplify everyday general office
tasks for midsize workgroups. Users can quickly
access exceptional multifunction performance—
including monochrome copy, color scan, print and
fax capabilities—to complete a wide range of
projects faster with incredibly low cost-per-page.
Ideal for busier workloads, it offers incredible
speed, quality, finishing and intuitive controls to
streamline workflow so you can manage your
documents more efficiently. Its compact design is
packed with versatility for optimal production and
value. Plus, it’s ideal for organizations deploying a
print management solution with Lanier’s Managed
Document Services (MDS)
.
Deliver More Efficiently
Complete more projects and meet even
the busiest office demands in less time.
The Lanier SP 5200S/SP 5210SF/SP 5210SR
offers a wide range of innovative features to
improve productivity.
• Boost throughput with exceptional print speeds. The
SP 5200S generates up to 47 pages-per-minute. The SP
5210SF and SP 5210SR print up to 52 pages-per-minute.
• Produce crisp, sharp text at up to 1200 x 600 dpi
resolution for high-quality, compelling results.
• Take advantage of easy-to-use scanning capabilities
to simplify workflow with cost-effective electronic
document storage and distribution.
• Work quickly with near-instant system readiness. Warm-
up time is less than 20 seconds and first print/copy times
are less than 8 seconds.
• Reduce paper, mailing costs and filing space with
standard automatic duplexing at nearly 90% of rated
simplex speeds.
• Maximize convenience with paperless faxing. Super G3
faxing, Internet Fax, IP Fax, and LAN Fax support come
standard on the SP 5210SF and are optional on the
SP 5200S and SP 5210SR.
The Lanier SP 5200S/SP 5210SF/
SP 5210SR combines multifunction
performance with user-friendly
convenience to streamline workflow
for mid-size workgroups in a wide
range of environments.
SP 5200S/SP 5210SF/SP 5210SR
More efficiency and value for everyday office tasks
desk
Paper Feed
Unit
TK1090
Paper Feed
Unit
TK1100
floor
*SP 5210SF and SP 5210SR only.
User-friendly design, productivity-enhancing results
Choose the Lanier SP 5200S/SP 5210SF/SP 5210SR
for exceptional speed, multifunction versatility and
superior productivity in an intuitive, compact design
D I G I T A L I M A G I N G S Y S T E M
SP 5200S/SP 5210SF/
SP 5210SR
D I G I T A L I M A G I N G S Y S T E M
SP 5200S/SP 5210SF/SP 5210SR
M A I N U N I T
Configuration
Desktop
Printing Technology
Laser beam scanning & electrophotographic
printing; Monocomponent toner development;
All-In-One Print Cartridge Technology
Scanning Technology
Full-Color Flatbed Scanning w/CCD Image Sensor
Scan Type
Sheet, book, three-dimensional objects
Print Speed (LTR)
SP 5200S: 47-ppm, SP 5210SF: 52-ppm,
SP 5210SR: 52-ppm
First Print Speed
7.5 seconds or less
Warm-up Time
20 seconds or less
Grayscale
256 levels
Copy Resolution
600 x 600 dpi via Platen Glass, 600 x 300 dpi
via ARDF
Print Resolution
1200 x 600 dpi, 600 x 600 dpi, 300 x 300 dpi
Fax Resolution
200 x 200 dpi, 200 x 100 dpi standard; 200 x
400 dpi, 400 x 400 dpi with optional memory
Document Feeding
Automatic Reversing Document Feeder
(Standard); Original Capacity: 50 sheets
Original Size: 5.5" x 8.5" – 8.5" x 14" (128 mm
x 139.7 mm – 216 mm x 355.6 mm);
Custom: Up to 49.6" (1260 mm) (Simplex only)
Max. Imageable Area
Platen: 8.5" x 11.69" (216 x 297 mm)
ARDF: 8.5" x 49.6" (216 x 1260 mm)
Multiple Copies
Up to 999
Zoom
Platen: 25% – 400% in 1% increments
ARDF: 25% – 200% in 1% increments
Preset Reduction
93%, 78%, 65%
Preset Enlargement
155%, 129%
Standard Paper Supply
550-sheet Tray + 100-sheet Bypass = 650 sheets
Optional Paper Supply
550-sheet Paper Feed Unit (Up to 3 may be
installed)
Max. Paper Capacity
2,300 sheets
Automatic Duplexing
Standard, up to 8.5" x 14" (Approx. 90%
productivity)
Output Capacity
SP 5200S: 500 sheets face down; SP 5210SF:
600 sheets face down (w/1Bin Tray); SP 5210SR:
250 sheets face down (w/Finisher)
Paper Sizes
Standard Tray, Standard Sizes: Letter, Legal,
Executive, Half Letter, A4, A5, A6, B5, B6, F/GL,
Foolscap, Folio; Envelopes: Com10, Monarch,
C6, C5, DL. Custom Sizes: Width: 3.86" – 8.5"
(98 mm – 216 mm), Length: 5.52" – 14.01"
(140 mm – 356 mm). Bypass Tray, Standard
Sizes: Letter, Legal, Executive, Half Letter, A4,
A5, A6, B5, B6, F/GL, Foolscap, Folio; Envelopes:
Com10, Monarch, C6, C5, DL. Custom Sizes:
Width: 2.52" – 8.5" (64 mm – 216 mm),
Length: 5.52" – 35.43" (140 mm – 900 mm).
Optional PFU(s), Standard Sizes: Letter, Legal,
Executive, Half Letter, A4, A5, B5, B6, F/GL,
Foolscap, Folio; Envelopes: Com10, Monarch,
C6, C5, DL. Custom Sizes: Width: 3.86" – 8.5"
(98 mm – 216 mm), Length: 6.3" – 14.01"
(160 mm – 356 mm)
Paper Weights
Standard & Optional Tray(s): 14 – 59 lb. Bond/
120 lb. Index (52 – 220 g/m
2
)
Bypass Tray: 14 – 59 lb. Bond/120 lb. Index
(52 – 220 g/m
2
). When Duplexing: 16 – 44 lb.
Bond/90 lb. Index (60 – 163 g/m
2
)
Paper Types (all sources)
Plain Paper, Recycled Paper, Middle Thick Paper,
Thick Paper, Thin Paper, Transparency, Letterhead,
Label, Color, Preprinted, Envelopes
Dimensions (WxDxH)
SP 5200S: 18.1" x 20" x 27" (460 mm x 510 mm
x 686 mm); SP 5210SF: 18.1" x 20" x 27" (460 mm
x 510 mm x 686 mm); SP 5210SR: 18.1" x 24.2"
x 27" (460 mm x 615 mm x 686 mm)
Weight
SP 5200S: 99.2 lb. (45 kg); SP 5210SF: 103.6 lb.
(47 kg); SP 5210SR: 116.8 lb. (53 kg)
Power Requirements
120 – 127V, 60Hz
Power Consumption
Operating: SP 5200S: 863 W, SP 5210SF: 892 W,
SP 5210SR: 858 W
Energy Saver: 8 W or less
Safety Regulations
UL60950-1, CAN/CSA C22.2 No.60950-1 (c-UL)
EMI
FCC Part 15 Subpart B, IC ES-003
Environmental Standard
ENERGY STAR Tier 2, ECP
Average Monthly Volume
5,500 – 15,000 total impressions/month
Maximum Duty Cycle
Up to 200,000 total impressions/month
P R I N T C O N T R O L L E R
CPU
533 MHz
Memory
1 GB RAM standard/maximum
Hard Disk Drive*
128 GB (standard)
*Includes HDD Encryption Unit and Overwrite (DOSS)
Interfaces
Standard: 10/100Base-TX Ethernet, USB 2.0 Hi
Speed Type B (for direct computer connection),
Dual USB 2.0 Host Interfaces Type A (for external
device connection), Front USB 2.0/SD Card
Slot Interface (for Scan To/Print From portable
media). Optional: Gigabit Ethernet (1000Base-T),
IEEE 802.11a/g Wireless, Bluetooth
Printer Languages/Drivers
PCL 5e, PCL 6, XPS, Adobe PostScript3
®
, PDF
Direct Print, Genuine IPDS (optional)
Fonts
PCL: 45 fonts + 13 International fonts; Post-
Script 3: 136 fonts; IPDS: 108 fonts (optional)
Supported Environments
Windows XP, Vista, 7, Server 2003/2003R2,
Server 2008/2008R2, Mac OS X v.10.2+, Novell
NetWare v 6.5+, Citrix Presentation Server,
UNIX/Linux
Network Protocols
TCP/IP (IPv4, IPv6), IPX/SPX, Bonjour
Software Utilities
Bundled Utilities: Web Image Monitor,
Font Manager 2000. Optional Utilities:
SmartDeviceMonitor for Admin Acounting
Package, SmartDeviceMonitor for Client,
DeskTopBinder Lite, @Remote Communication
Gate S Pro
Standard Security Features
Administrator Authentication (5 levels), User
Authentication (5 types), HDD Overwrite (DOSS)
& Data Encryption, Secure Print, Encrypted
Secure Print, Encrypted PDF Mode, Scan-to-
Web Mail (SMTP over SSL), IP Address Filtering,
Transport Layer Security (TLS), SSL Communication,
IPv6, IP Sec, SNMPv3, Quota Setting
Controller Options
IEEE802.11 a/g Interface Unit Type J; Gigabit
Ethernet Board Type C; Bluetooth Interface Unit
Type D; IPDS Unit Type 5210; Data Overwrite
Security Unit Type I*; Remote Communication
Gate A; Fax Option Type SP5200; Fax Memory
Unit Type B 32MB; Telephone Handset Type
1018; HotSpot MFP Option Type E; Browser Unit
Type E; File Format Converter Type E
*For Common Criteria Certification (CCC) use. Certification pending.
S C A N N E R
Scanner Type
Full Color CCD
Scanning Resolutions
Scan-To Modes: 100/200/300/400/600 dpi
(Black & White, ARDF & Platen); 100/200/300
dpi (Full Color, ARDF); 100/200/300/400/600
dpi (Full Color, Platen). TWAIN/WSD/WIA: 100
– 600 dpi in 1% increments (Black & White,
ARDF); 100 – 1200 dpi in 1% increments
(Black & White, Platen); 100 – 600 dpi in 1%
increments (Full Color, ARDF & Platen)
Default Resolution
200 dpi
Scanning Speed
Over 30-ipm (B&W/FC, LTR @ 200 dpi)
Max. Original Size
Platen: Up to 8.5" x 11.7" (216 mm x 297 mm);
ARDF: Up to 8.5" x 49.6" (216mm x 1260 mm)
Protocols
Network: TCP/IP; Scan-to-Email: POP, SMTP;
Scan-to-Folder: SMB, FTP, NCP
Scan Modes
B&W Text, B&W Text/Line Art, B&W Text/Photo,
B&W Photo, Grayscale, Full-Color Text/Photo,
Full-Color Glossy Photo, Auto Color Select (ACS)
Image Density
Auto + 7-step Manual scale
Image Rotation
Supported
SADF/Batch Mode
Supported
Supported File Formats
Single/Multi Page TIFF, Single Page JPEG, Single/
Multi Page PDF, High Compression PDF
Scan-To Modes
Scan-to-Email, Scan-to-Folder (SMB/FTP/NCP);
Scan-to-URL, Scan-to-Media (USB/SD Card)
Scan-to-Email
Standard; Authorization: SMTP authentication,
POP before SMTP authentication
Max. Addresses/Send
500; Attention: To, cc, bcc
LDAP Search
Supported
Maintain E-mail Address
Direct input from control panel, Web Image
Monitor, SmartDeviceMonitor for Admin
E-mail Attachments
Up to 2 GB without restriction
Input File Name
Yes
Input Subject
Up to 128 characters
Input Body Message
Up to 80 characters + 5 pre-registered messages
Scan-to-Folder
Standard; Protocol Support: SMB, FTP, NCP
Maintain Address
Direct input from control panel, Web Image
Monitor, SmartDeviceMonitor for Admin
Max. Folders/Send
100
Max. Addresses/Send
500
File Attachment Size
Up to 2000 MB
Input File Name
Yes
Network TWAIN Scanning
Standard – All models + Web Services (WSD)
Scanner for Vista; Operating Systems: Windows
XP, Server 2003, Vista, 7, Server 2008/R2; Scan
Modes: Standard, Photo, OCR, Filing; Image
Adjustment: Brightness, Contrast, Threshold,
Gamma Adjustment, Halftone Pattern
Endorse
Date, Page Number, Text
D O C U M E N T S E R V E R
Total HDD Capacity
128 GB (Shared with other functions)
Max. Stored Documents
3,000 documents
Max. Pages per Document
2,000 pages
F A X O P T I O N T Y P E S P 5 2 0 0
(Standard for SP 5210SF, Optional for SP 5200S/ 5210SR)
Type
Super G3 Transceiver
Circuit
PSTN, PBX
Number of Lines
1
Compatibility
ITU-T, Group 3
Resolution (dpi)
200 x 100, 200 x 200, 200 x 400, 400 x 400
(for Internet & IP Fax, requires optional SAF
memory)
Modem Speed
33,600 bps – 2,400 bps w/Auto Fallback
Compression Method
MH, MR, MMR, JBIG
Transmission Speed
G3: Approximately 2 seconds/page (w/JBIG)
G3: Approximately 3 seconds/page (w/MMR)
Scanning Speed
Up to 40-ppm (B&W, LTR @ 200 x 100 dpi)
Original Capacity/Size
See Scanner & Document Feeding Specifications
Auto Dialing
Up to 2,000 Quick Dial numbers in Address Book
100 Group Dial numbers (500 locations per Group)
Page Memory Capacity
Standard: 4 MB RAM (approx. 320 pages)
Maximum: 28 MB RAM (approx. 2,240 pages)
Memory Backup
1 hour
Additional Fax Modes
LAN Fax, Internet Fax (T.37), IP Fax (T.38)
LAN Fax
Standard on SP 5210SF, requires Fax Option Type
5200 for SP 5200S and SP 5210SR; Connection;
10/100Base-TX Ethernet, IEEE 802.11 a/g Wireless,
or Gigabit Ethernet interface; Protocol: G3; Max.
Addresses Per TX: 500; Operating Systems:
Windows XP, Server 2003, Vista, 7, Server 2008/
R2; Document Size: Letter, Legal, A4, A5
Internet Fax
Standard on SP 5210SF, requires Fax Option Type
5200 for SP 5200S and SP 5210SR; Connection:
10/100Base-TX Ethernet, IEEE 802.11 a/g Wireless,
or Gigabit Ethernet interface; Protocol: T.37 Full
Mode; Max. Addresses Per TX: 500; Transmission
Function: Conversion of files to TIFF format for
E-mail TX to a PC; Original Size: Letter, A4
IP Fax
Standard on SP 5210SF, requires Fax Option Type
5200 for SP 5200S and SP 5210SR; Connection:
10/100Base-TX Ethernet, IEEE 802.11 a/g Wireless,
or Gigabit Ethernet interface; Protocol: T.38,
TCP, UDP/IP communication; TX/RX Function:
To/from IP Fax compatible machines via network;
To/from G3 Fax machines via VoIP gateway;
Original Size: Letter, A4 (216 mm x 356 mm);
Custom: Up to 8.5" x 47" (216 mm x 1200 mm)
H A R D W A R E A C C E S S O R I E S
Optional Paper Feed Unit (TK1090)
Capacity
550 sheets, 1 or 2 units may be installed
Paper Size Range
3.86" x 6.3" – 8.5" x 14.01" (98 mm x 160 mm
– 216 mm x 356 mm)
Paper Weight
14 lb. Bond – 80 lb. Cover/120 lb. Index
(52 – 220 g/m
2
)
Dimensions (WxDxH)
17.8" x 20.3" x 5.9" (450 mm x 516 mm x 150 mm)
Weight
19.9 lb (9.0 kg)
Optional Paper Feed Unit with Casters (TK1100)
Capacity
550 sheets, 1 unit may be installed as bottom PFU
Paper Size Range
3.86" x 6.3" – 8.5" x 14.01" (98 mm x 160 mm
– 216 mm x 356 mm)
Paper Weight
14 lb. Bond – 80 lb. Cover/120 lb. Index
(52 – 220 g/m
2
)
Dimensions (WxDxH)
24.7" x 25.0" x 8.7" (627 mm x 635 mm x
220 mm) (including casters)
Weight
26.5 lb (12.0 kg)
Internal Finisher (Standard for SP 5210SR only)
Tray Capacity
250 sheets
Modes
Shift Sort, Stack, Staple
Paper Weight
14 – 59 lb. Bond/120 lb. Index (52 – 220 g/m
2
)
Stapling
1 position; Top parallel
Staple Sheet Sizes
Letter, Legal, Executive, A4, B5, Foolscap, Folio, F
Staple Capacity
50 sheets/set (Letter)
(21 lb. Bond, 80g/m
2
)
30 sheets/set (Legal)
Stack Capacity after Stapling
2 sheets: 33 sets; 30 sheets: 7 sets; 50 sheets: 4 sets
Staple Paper Weight
14 – 24 lb. Bond (52 – 90 g/m
2
)
Staple Cartridge Capacity
5,000 staples
1-Bin Tray (Standard for SP 5210SF only)
Tray Capacity
100 sheets
Paper Weight
14 lb. Bond – 80 lb. Cover/120 lb. Index
(52 – 220 g/m
2
)
S U P P L I E S A N D C O N S U M A B L E S
Item Yield
Black AIO Print Cartridge
25,000 pages*
SP 5200HA
Staple Type T
5,000/carton
Refill Staple Type T
10,000/carton
Maintenance Kit SP 5200
120,000 pages
Includes 1 Fusing Unit, 1 Transfer Roller, 5 Feed Rollers and 5 Friction Pads
*Declared yield values based on ISO/IEC 19752. Actual yields may vary based on types
of images printed and other factors.
The Lanier SP 5200S/SP 5210SF/SP 5210SR ships with one starter AIO cartridge yielding
6,000 pages. All other consumables ship at full yield.
For maximum performance and yield, we recommend using genuine Lanier parts
and supplies.
Specifications subject to change without notice.
W A R R A N T Y
The Lanier SP 5200S/SP 5210SF/SP 5210SR is under warranty against defects for a period
of one year from the date of purchase. Consumables are under warranty for a period of
90 days from the date of purchase or until depleted, whichever comes first. Please refer
to warranty documents shipped with the product for more details.
L3288
www.lanier.com
Lanier, Five Dedrick Place, West Caldwell, NJ 07006
Lanier® and the Lanier Logo are registered trademarks of Ricoh Americas Corporation. All other trademarks are the property of their respective owners. The content of this document,
and the appearance, features and specifications of Lanier products and services are subject to change from time to time without notice. Products are shown with optional features.
While care has been taken to ensure the accuracy of this information, Lanier makes no representation or warranties about the accuracy, completeness or adequacy of the information
contained herein, and shall not be liable for any errors or omissions in these materials. Actual results will vary depending upon use of the products and services, and the conditions and
factors affecting performance. The only warranties for Lanier products and services are as set forth in the express warranty statements accompanying them.
SP 5200S/SP 5210SF/SP 5210SR
User-friendly design improves office productivity.
Standard 550-Sheet Paper Tray
Front-facing, user-adjustable paper trays
accommodate envelopes and paper sizes
up to 8.5" x 14" and stock weights up
to 80 lb. Bond/120 lb. Index.
User-Adjusted LCD Control Panel*
See the easy-to-read, tilted control panel
comfortably from virtually anywhere.
Super G3 Faxing
Perform a variety of fax functions with pre-
programmed speed, quick and group dial
shortcuts on the SP 5210SF. A 1-Bin Tray is
included to collect inbound faxes.
100-Sheet Bypass Tray
Extend paper sizes up to 35" long for
banner production.
50-Sheet Automatic Reversing
Document Feeder (ARDF)
Process originals efficiently—up to
8.5" x 14" and custom banner
scanning up to 49" long—to speed
the scanning process.
Internal Finisher
Staple up to 50 pages and stack up
to 250 sheets with the space-saving
internal finisher on the SP 5210SR.
Duplex Unit
Copy and print on both sides of
each sheet of paper, reducing paper
usage by half.
Easy-Grip Paper Tray Handles
Open and close doors with only
one hand, sitting or standing.
3 x 550-Sheet Paper Trays
Add up to three additional paper
trays to expand paper capacity to
2,300 sheets.
Pre-configured to
meet your needs.
Model SP 5200S SP 5210SF SP 5210SR
Standard Functions Copy / Print / Scan Copy / Print / Scan / Fax Copy / Print / Scan / Finishing
Print Speed 47 cpm/ppm 52 cpm/ppm
Super G3 Faxing Optional Standard Optional
Color Touch Panel Fixed Placement Adjustable
Internal Staple Finisher N/A N/A Standard
Inner 1-Bin Tray N/A Standard N/A
Output Capacity 500 sheets 600 sheets 250 sheets
*SP 5210SF and SP 5210SR only.
D I G I T A L I M A G I N G S Y S T E M
D I G I T A L I M A G I N G S Y S T E M
SP 5200S/SP 5210SF/SP 5210SR
M a i n U n i t
Configuration
Desktop
Printing Technology
Laser beam scanning & electrophotographic
printing; Monocomponent toner development;
All-In-One Print Cartridge Technology
Scanning Technology
Full-Color Flatbed Scanning w/CCD Image Sensor
Scan Type
Sheet, book, three-dimensional objects
Print Speed (LTR)
SP 5200S: 47-ppm, SP 5210SF: 52-ppm,
SP 5210SR: 52-ppm
First Print Speed
7.5 seconds or less
Warm-up Time
20 seconds or less
Grayscale
256 levels
Copy Resolution
600 x 600 dpi via Platen Glass, 600 x 300 dpi
via ARDF
Print Resolution
1200 x 600 dpi, 600 x 600 dpi, 300 x 300 dpi
Fax Resolution
200 x 200 dpi, 200 x 100 dpi standard; 200 x
400 dpi, 400 x 400 dpi with optional memory
Document Feeding
Automatic Reversing Document Feeder
(Standard); Original Capacity: 50 sheets
Original Size: 5.5" x 8.5" – 8.5" x 14" (128 mm
x 139.7 mm – 216 mm x 355.6 mm);
Custom: Up to 49.6" (1260 mm) (Simplex only)
Max. Imageable Area
Platen: 8.5" x 11.69" (216 x 297 mm)
ARDF: 8.5" x 49.6" (216 x 1260 mm)
Multiple Copies
Up to 999
Zoom
Platen: 25% – 400% in 1% increments
ARDF: 25% – 200% in 1% increments
Preset Reduction
93%, 78%, 65%
Preset Enlargement
155%, 129%
Standard Paper Supply
550-sheet Tray + 100-sheet Bypass = 650 sheets
Optional Paper Supply
550-sheet Paper Feed Unit (Up to 3 may be
installed)
Max. Paper Capacity
2,300 sheets
Automatic Duplexing
Standard, up to 8.5" x 14" (Approx. 90%
productivity)
Output Capacity
SP 5200S: 500 sheets face down; SP 5210SF:
600 sheets face down (w/1Bin Tray); SP 5210SR:
250 sheets face down (w/Finisher)
Paper Sizes
Standard Tray, Standard Sizes: Letter, Legal,
Executive, Half Letter, A4, A5, A6, B5, B6, F/GL,
Foolscap, Folio; Envelopes: Com10, Monarch,
C6, C5, DL. Custom Sizes: Width: 3.86" – 8.5"
(98 mm – 216 mm), Length: 5.52" – 14.01"
(140 mm – 356 mm). Bypass Tray, Standard
Sizes: Letter, Legal, Executive, Half Letter, A4,
A5, A6, B5, B6, F/GL, Foolscap, Folio; Envelopes:
Com10, Monarch, C6, C5, DL. Custom Sizes:
Width: 2.52" – 8.5" (64 mm – 216 mm),
Length: 5.52" – 35.43" (140 mm – 900 mm).
Optional PFU(s), Standard Sizes: Letter, Legal,
Executive, Half Letter, A4, A5, B5, B6, F/GL,
Foolscap, Folio; Envelopes: Com10, Monarch,
C6, C5, DL. Custom Sizes: Width: 3.86" – 8.5"
(98 mm – 216 mm), Length: 6.3" – 14.01"
(160 mm – 356 mm)
Paper Weights
Standard & Optional Tray(s): 14 – 59 lb. Bond/
120 lb. Index (52 – 220 g/m
2
)
Bypass Tray: 14 – 59 lb. Bond/120 lb. Index
(52 – 220 g/m
2
). When Duplexing: 16 – 44 lb.
Bond/90 lb. Index (60 – 163 g/m
2
)
Paper Types (all sources)
Plain Paper, Recycled Paper, Middle Thick Paper,
Thick Paper, Thin Paper, Transparency, Letterhead,
Label, Color, Preprinted, Envelopes
Dimensions (WxDxH)
SP 5200S: 18.1" x 20" x 27" (460 mm x 510 mm
x 686 mm); SP 5210SF: 18.1" x 20" x 27" (460 mm
x 510 mm x 686 mm); SP 5210SR: 18.1" x 24.2"
x 27" (460 mm x 615 mm x 686 mm)
Weight
SP 5200S: 99.2 lb. (45 kg); SP 5210SF: 103.6 lb.
(47 kg); SP 5210SR: 116.8 lb. (53 kg)
Power Requirements
120 – 127V, 60Hz
Power Consumption
Operating: SP 5200S: 863 W, SP 5210SF: 892 W,
SP 5210SR: 858 W
Energy Saver: 8 W or less
Safety Regulations
UL60950-1, CAN/CSA C22.2 No.60950-1 (c-UL)
EMI
FCC Part 15 Subpart B, IC ES-003
Environmental Standard
ENERGY STAR Tier 2, ECP
Average Monthly Volume
5,500 – 15,000 total impressions/month
Maximum Duty Cycle
Up to 200,000 total impressions/month
P r i n t C o n t r o l l e r
CPU
533 MHz
Memory
1 GB RAM standard/maximum
Hard Disk Drive*
128 GB (standard)
*Includes HDD Encryption Unit and Overwrite (DOSS)
Interfaces
Standard: 10/100Base-TX Ethernet, USB 2.0 Hi
Speed Type B (for direct computer connection),
Dual USB 2.0 Host Interfaces Type A (for external
device connection), Front USB 2.0/SD Card
Slot Interface (for Scan To/Print From portable
media). Optional: Gigabit Ethernet (1000Base-T),
IEEE 802.11a/g Wireless, Bluetooth
Printer Languages/Drivers
PCL 5e, PCL 6, XPS, Adobe PostScript3
®
, PDF
Direct Print, Genuine IPDS (optional)
Fonts
PCL: 45 fonts + 13 International fonts; Post-
Script 3: 136 fonts; IPDS: 108 fonts (optional)
Supported Environments
Windows XP, Vista, 7, Server 2003/2003R2,
Server 2008/2008R2, Mac OS X v.10.2+, Novell
NetWare v 6.5+, Citrix Presentation Server,
UNIX/Linux
Network Protocols
TCP/IP (IPv4, IPv6), IPX/SPX, Bonjour
Software Utilities
Bundled Utilities: Web Image Monitor,
Font Manager 2000. Optional Utilities:
SmartDeviceMonitor for Admin Acounting
Package, SmartDeviceMonitor for Client,
DeskTopBinder Lite, @Remote Communication
Gate S Pro
Standard Security Features
Administrator Authentication (5 levels), User
Authentication (5 types), HDD Overwrite (DOSS)
& Data Encryption, Secure Print, Encrypted
Secure Print, Encrypted PDF Mode, Scan-to-
Web Mail (SMTP over SSL), IP Address Filtering,
Transport Layer Security (TLS), SSL Communication,
IPv6, IP Sec, SNMPv3, Quota Setting
Controller Options
IEEE802.11 a/g Interface Unit Type J; Gigabit
Ethernet Board Type C; Bluetooth Interface Unit
Type D; IPDS Unit Type 5210; Data Overwrite
Security Unit Type I*; Remote Communication
Gate A; Fax Option Type SP5200; Fax Memory
Unit Type B 32MB; Telephone Handset Type
1018; HotSpot MFP Option Type E; Browser Unit
Type E; File Format Converter Type E
*For Common Criteria Certification (CCC) use. Certification pending.
S C a n n e r
Scanner Type
Full Color CCD
Scanning Resolutions
Scan-To Modes: 100/200/300/400/600 dpi
(Black & White, ARDF & Platen); 100/200/300
dpi (Full Color, ARDF); 100/200/300/400/600
dpi (Full Color, Platen). TWAIN/WSD/WIA: 100
– 600 dpi in 1% increments (Black & White,
ARDF); 100 – 1200 dpi in 1% increments
(Black & White, Platen); 100 – 600 dpi in 1%
increments (Full Color, ARDF & Platen)
Default Resolution
200 dpi
Scanning Speed
Over 30-ipm (B&W/FC, LTR @ 200 dpi)
Max. Original Size
Platen: Up to 8.5" x 11.7" (216 mm x 297 mm);
ARDF: Up to 8.5" x 49.6" (216mm x 1260 mm)
Protocols
Network: TCP/IP; Scan-to-Email: POP, SMTP;
Scan-to-Folder: SMB, FTP, NCP
Scan Modes
B&W Text, B&W Text/Line Art, B&W Text/Photo,
B&W Photo, Grayscale, Full-Color Text/Photo,
Full-Color Glossy Photo, Auto Color Select (ACS)
Image Density
Auto + 7-step Manual scale
Image Rotation
Supported
SADF/Batch Mode
Supported
Supported File Formats
Single/Multi Page TIFF, Single Page JPEG, Single/
Multi Page PDF, High Compression PDF
Scan-To Modes
Scan-to-Email, Scan-to-Folder (SMB/FTP/NCP);
Scan-to-URL, Scan-to-Media (USB/SD Card)
Scan-to-Email
Standard; Authorization: SMTP authentication,
POP before SMTP authentication
Max. Addresses/Send
500; Attention: To, cc, bcc
LDAP Search
Supported
Maintain E-mail Address
Direct input from control panel, Web Image
Monitor, SmartDeviceMonitor for Admin
E-mail Attachments
Up to 2 GB without restriction
Input File Name
Yes
Input Subject
Up to 128 characters
Input Body Message
Up to 80 characters + 5 pre-registered messages
Scan-to-Folder
Standard; Protocol Support: SMB, FTP, NCP
Maintain Address
Direct input from control panel, Web Image
Monitor, SmartDeviceMonitor for Admin
Max. Folders/Send
100
Max. Addresses/Send
500
File Attachment Size
Up to 2000 MB
Input File Name
Yes
Network TWAIN Scanning
Standard – All models + Web Services (WSD)
Scanner for Vista; Operating Systems: Windows
XP, Server 2003, Vista, 7, Server 2008/R2; Scan
Modes: Standard, Photo, OCR, Filing; Image
Adjustment: Brightness, Contrast, Threshold,
Gamma Adjustment, Halftone Pattern
Endorse
Date, Page Number, Text
D o C U M e n t S e r v e r
Total HDD Capacity
128 GB (Shared with other functions)
Max. Stored Documents
3,000 documents
Max. Pages per Document
2,000 pages
F a x o P t i o n t y P e S P 5 2 0 0
(Standard for SP 5210SF, Optional for SP 5200S/ 5210SR)
Type
Super G3 Transceiver
Circuit
PSTN, PBX
Number of Lines
1
Compatibility
ITU-T, Group 3
Resolution (dpi)
200 x 100, 200 x 200, 200 x 400, 400 x 400
(for Internet & IP Fax, requires optional SAF
memory)
Modem Speed
33,600 bps – 2,400 bps w/Auto Fallback
Compression Method
MH, MR, MMR, JBIG
Transmission Speed
G3: Approximately 2 seconds/page (w/JBIG)
G3: Approximately 3 seconds/page (w/MMR)
Scanning Speed
Up to 40-ppm (B&W, LTR @ 200 x 100 dpi)
Original Capacity/Size
See Scanner & Document Feeding Specifications
Auto Dialing
Up to 2,000 Quick Dial numbers in Address Book
100 Group Dial numbers (500 locations per Group)
Page Memory Capacity
Standard: 4 MB RAM (approx. 320 pages)
Maximum: 28 MB RAM (approx. 2,240 pages)
Memory Backup
1 hour
Additional Fax Modes
LAN Fax, Internet Fax (T.37), IP Fax (T.38)
LAN Fax
Standard on SP 5210SF, requires Fax Option Type
5200 for SP 5200S and SP 5210SR; Connection;
10/100Base-TX Ethernet, IEEE 802.11 a/g Wireless,
or Gigabit Ethernet interface; Protocol: G3; Max.
Addresses Per TX: 500; Operating Systems:
Windows XP, Server 2003, Vista, 7, Server 2008/
R2; Document Size: Letter, Legal, A4, A5
Internet Fax
Standard on SP 5210SF, requires Fax Option Type
5200 for SP 5200S and SP 5210SR; Connection:
10/100Base-TX Ethernet, IEEE 802.11 a/g Wireless,
or Gigabit Ethernet interface; Protocol: T.37 Full
Mode; Max. Addresses Per TX: 500; Transmission
Function: Conversion of files to TIFF format for
E-mail TX to a PC; Original Size: Letter, A4
IP Fax
Standard on SP 5210SF, requires Fax Option Type
5200 for SP 5200S and SP 5210SR; Connection:
10/100Base-TX Ethernet, IEEE 802.11 a/g Wireless,
or Gigabit Ethernet interface; Protocol: T.38,
TCP, UDP/IP communication; TX/RX Function:
To/from IP Fax compatible machines via network;
To/from G3 Fax machines via VoIP gateway;
Original Size: Letter, A4 (216 mm x 356 mm);
Custom: Up to 8.5" x 47" (216 mm x 1200 mm)
H a r D w a r e a C C e S S o r i e S
Optional Paper Feed Unit (TK1090)
Capacity
550 sheets, 1 or 2 units may be installed
Paper Size Range
3.86" x 6.3" – 8.5" x 14.01" (98 mm x 160 mm
– 216 mm x 356 mm)
Paper Weight
14 lb. Bond – 80 lb. Cover/120 lb. Index
(52 – 220 g/m
2
)
Dimensions (WxDxH)
17.8" x 20.3" x 5.9" (450 mm x 516 mm x 150 mm)
Weight
19.9 lb (9.0 kg)
Optional Paper Feed Unit with Casters (TK1100)
Capacity
550 sheets, 1 unit may be installed as bottom PFU
Paper Size Range
3.86" x 6.3" – 8.5" x 14.01" (98 mm x 160 mm
– 216 mm x 356 mm)
Paper Weight
14 lb. Bond – 80 lb. Cover/120 lb. Index
(52 – 220 g/m
2
)
Dimensions (WxDxH)
24.7" x 25.0" x 8.7" (627 mm x 635 mm x
220 mm) (including casters)
Weight
26.5 lb (12.0 kg)
Internal Finisher (Standard for SP 5210SR only)
Tray Capacity
250 sheets
Modes
Shift Sort, Stack, Staple
Paper Weight
14 – 59 lb. Bond/120 lb. Index (52 – 220 g/m
2
)
Stapling
1 position; Top parallel
Staple Sheet Sizes
Letter, Legal, Executive, A4, B5, Foolscap, Folio, F
Staple Capacity
50 sheets/set (Letter)
(21 lb. Bond, 80g/m
2
)
30 sheets/set (Legal)
Stack Capacity after Stapling
2 sheets: 33 sets; 30 sheets: 7 sets; 50 sheets: 4 sets
Staple Paper Weight
14 – 24 lb. Bond (52 – 90 g/m
2
)
Staple Cartridge Capacity
5,000 staples
1-Bin Tray (Standard for SP 5210SF only)
Tray Capacity
100 sheets
Paper Weight
14 lb. Bond – 80 lb. Cover/120 lb. Index
(52 – 220 g/m
2
)
S U P P l i e S a n D C o n S U M a b l e S
Item Yield
Black AIO Print Cartridge
25,000 pages*
SP 5200HA
Staple Type T
5,000/carton
Refill Staple Type T
10,000/carton
Maintenance Kit SP 5200
120,000 pages
Includes 1 Fusing Unit, 1 Transfer Roller, 5 Feed Rollers and 5 Friction Pads
*Declared yield values based on ISO/IEC 19752. Actual yields may vary based on types
of images printed and other factors.
The Lanier SP 5200S/SP 5210SF/SP 5210SR ships with one starter AIO cartridge yielding
6,000 pages. All other consumables ship at full yield.
For maximum performance and yield, we recommend using genuine Lanier parts
and supplies.
Specifications subject to change without notice.
w a r r a n t y
The Lanier SP 5200S/SP 5210SF/SP 5210SR is under warranty against defects for a period
of one year from the date of purchase. Consumables are under warranty for a period of
90 days from the date of purchase or until depleted, whichever comes first. Please refer
to warranty documents shipped with the product for more details.
L3288
www.lanier.com
Lanier, Five Dedrick Place, West Caldwell, NJ 07006
Lanier® and the Lanier Logo are registered trademarks of Ricoh Americas Corporation. All other trademarks are the property of their respective owners. The content of this document,
and the appearance, features and specifications of Lanier products and services are subject to change from time to time without notice. Products are shown with optional features.
While care has been taken to ensure the accuracy of this information, Lanier makes no representation or warranties about the accuracy, completeness or adequacy of the information
contained herein, and shall not be liable for any errors or omissions in these materials. Actual results will vary depending upon use of the products and services, and the conditions and
factors affecting performance. The only warranties for Lanier products and services are as set forth in the express warranty statements accompanying them.

Other Lanier All In One Printer manuals

Lanier LD225 Instruction and safety manual

Lanier

Lanier LD225 Instruction and safety manual

Lanier 5622 AG Manual

Lanier

Lanier 5622 AG Manual

Lanier LD160c User manual

Lanier

Lanier LD160c User manual

Lanier LP332c Owner's manual

Lanier

Lanier LP332c Owner's manual

Lanier LD116 User manual

Lanier

Lanier LD116 User manual

Lanier Pro 907EX User manual

Lanier

Lanier Pro 907EX User manual

Lanier LD225 Service manual

Lanier

Lanier LD225 Service manual

Lanier LD016 User manual

Lanier

Lanier LD016 User manual

Lanier SP C222SF User manual

Lanier

Lanier SP C222SF User manual

Lanier FAX1190L User manual

Lanier

Lanier FAX1190L User manual

Lanier MP 301SPF User manual

Lanier

Lanier MP 301SPF User manual

Lanier LD1110 User manual

Lanier

Lanier LD1110 User manual

Lanier LD225 Instruction and safety manual

Lanier

Lanier LD225 Instruction and safety manual

Lanier 5222 Manual

Lanier

Lanier 5222 Manual

Lanier 5722 Manual

Lanier

Lanier 5722 Manual

Lanier MP C4502 Owner's manual

Lanier

Lanier MP C4502 Owner's manual

Lanier MP4002 Owner's manual

Lanier

Lanier MP4002 Owner's manual

Lanier LF510 User manual

Lanier

Lanier LF510 User manual

Lanier lp145n Installation instructions

Lanier

Lanier lp145n Installation instructions

Lanier LD1110 Service manual

Lanier

Lanier LD1110 Service manual

Lanier LD335 User manual

Lanier

Lanier LD335 User manual

Lanier SP C231SF User manual

Lanier

Lanier SP C231SF User manual

Lanier LD225 Installation and maintenance instructions

Lanier

Lanier LD225 Installation and maintenance instructions

Lanier Copier System Edition User manual

Lanier

Lanier Copier System Edition User manual

Popular All In One Printer manuals by other brands

Sharp FO-47IF Service manual

Sharp

Sharp FO-47IF Service manual

Utax 5240L user manual

Utax

Utax 5240L user manual

Lexmark X463 Network user's guide

Lexmark

Lexmark X463 Network user's guide

Canon imageRUNNER ADVANCE 6075 manual

Canon

Canon imageRUNNER ADVANCE 6075 manual

Canon imageCLASS D530 brochure

Canon

Canon imageCLASS D530 brochure

Lexmark X502N Specifications

Lexmark

Lexmark X502N Specifications

BT PaperJet 50e user guide

BT

BT PaperJet 50e user guide

Ricoh Aficio MP 201SPF quick guide

Ricoh

Ricoh Aficio MP 201SPF quick guide

Canon imageCLASS D660 Setup instructions

Canon

Canon imageCLASS D660 Setup instructions

Sharp MX-B356W Quick start manual

Sharp

Sharp MX-B356W Quick start manual

Xerox AltaLink C8030 Customer expectation & installation guide

Xerox

Xerox AltaLink C8030 Customer expectation & installation guide

Brother MFC-L2712DN Quick setup guide

Brother

Brother MFC-L2712DN Quick setup guide

Oce cm2520 Safety information & getting started

Oce

Oce cm2520 Safety information & getting started

Epson 1000 ICS Software installation

Epson

Epson 1000 ICS Software installation

Muratec MFX-3595 Field engineering manual

Muratec

Muratec MFX-3595 Field engineering manual

Epson Stylus Photo RX700 Series Start here

Epson

Epson Stylus Photo RX700 Series Start here

Brother MFC-J430w quick start guide

Brother

Brother MFC-J430w quick start guide

Copystar CS 3050ci Speci?cations

Copystar

Copystar CS 3050ci Speci?cations

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
