Lanier LD433B User manual

For exceptional black
& white printing and
color and black &
white scanning.
For a complete document
management system with
printing, faxing, color and
black & white scanning in
a single, compact device.
For robust copying and a
flexible upgrade path to
black & white printing,
scanning and faxing.
DIGITAL IMAGING SYSTEM
LD425B/LD425/LD433B/LD433
L2684
SPECIFICATIONS
ENGINE/COPIER SPECIFICATIONS
Configuration Console
Scanning Element Flatbed with Moving CCD
Array Image Sensor
Printing Process Single Laser Beam Scanning &
Electrophotographic Printing
Document Feeding Optional 50-Sheet ARDF
Toner Dry, Dual Component
System Memory LD425B/LD433B: 256/512 MB RAM
(std./max.) LD425/LD433: 768/768 MB RAM
Hard Disk Drive LD425/LD433: 40 GB Standard
LD425B/LD433B: 40 GB Optional
Copy Resolution 600 x 600 dpi
Grayscale 256 levels
Exposure Adjustment Manual & Automatic
Quantity Indicator Up to 999
Original Type Book/Sheet
Maximum Original Size Up to 11" x 17"
Copy Size 5.5" x 8.5" to 11" x 17"
Copy Type Plain Paper, Transparencies, Envelopes,
Cardstock, Recycled
Warm-Up Time 14 seconds
First Copy Speed 4.5 seconds
Continuous Copying LD425B/LD425: 25 copies/minute (LTR)
Speed LD433B/LD433: 33 copies/minute (LTR)
Recovery Time 10 seconds (from Auto Off)
Power Source 120V/60Hz
Dimensions 24.8"(W) x 25.7"(D) x 27.9"(H)
Weight 143 lbs.
Standard Paper 500 sheets x 2 trays, and
Capacity 100-Sheet Bypass Tray
Optional Paper 500 sheets x 2 trays or
Capacity 2,000-Sheet Large Capacity Tray
Paper Size 5.5" x 8.5" to 11" x 17"
A5 to A3
Paper Weight 16 – 28 lb. Bond/60 – 105 g/m2
(Tray 1 and Duplex)
14 – 42 lb. Bond/52 – 157 g/m2
(Tray 2 and Bypass)
Standard Output Tray 500 sheets (Letter),
Capacity 250 sheets (Legal, Ledger)
Reduction Ratios 25%, 50%, 65%, 73%, 78%, 85%,
93%, 100%
Enlargement Ratios 121%, 129%, 155%, 200%, 400%
Zoom 25% to 400% in 1% increments
Standard Features Auto Magnification, Auto Paper Select,
Auto Tray Switch, Center/Border Erase,
Chapters, Combine Mode, Cover Insertion,
Date Stamp, Directional Magnification,
Electronic/Rotate Sorting, English Pre-Set
Stamps, Full-Color VGA Touch-Screen
Control Panel, 10 Job Programs,
Negative/Positive, OHP Slip Sheet, Page
Number Stamp, 500 User Codes
Hard Drive Required 8 Job Presets, Background Numbering,
Booklet/Magazine Copy, Document
Server (3,000 File Capacity), Series Copy,
User Stamps
PRINTER SPECIFICATIONS (STANDARD)*
Print Speed LD425B/LD425: 25 ppm
LD433B/LD433: 33 ppm
CPU RM7035C 533 MHz
Standard Interfaces 10/100BaseTX Ethernet, USB 2.0
Optional Interfaces IEEE 802.11a/b/g Wireless LAN, Bluetooth,
IEEE 1284, Gigabit Ethernet
Memory Capacity Shared with Copier
Network Protocol TCP/IP, IPX/SPX, AppleTalk
Network Operating Windows Vista/2000/ME/XP/Server 2003,
Systems Netware 3.12, 3.2, 4.1, 4.11, 5.0, 5.1,
6.0, 6.5, Unix; Sun Solaris, HP-UX,
SCO OpenServer, Red Hat Linux,
IBM AIX, Mac OS 8.6 – 9.2x, OS X 10.1
or later, SAP R/3, NDPS Gateway,
IBM iSeries/AS/400®using OS/400
Host Print Transform, Citrix Metaframe
Utilities SmartDeviceMonitor,
Web SmartDeviceMonitor,
DeskTopBinder,
Web Image Monitor
Page Description PCL 5e/6 emulation
Languages Lanier RPCS
Adobe PostScript 3 (optional)
Print Resolution Up to 600 dpi (2400 x 600 dpi
with smoothing)
Grayscale 256 levels
Fonts for PCL 5e/6 35 Intellifonts, 10 TrueType,
1 Bitmap and 13 International Fonts
Fonts for PS3 136 PostScript Fonts
Standard Features Sample/Locked/Hold/Stored Print
(Hard Disk Drive)
SCANNER SPECIFICATIONS (STANDARD)*
Scanning Speed Embedded Scanning: 50/29 ipm
B&W/Color (@ 200 dpi)
Scanning Resolution 600 dpi
Grayscale 256 levels
Scan Area Up to 11" x 17"
Standard Interfaces 10/100BaseTX Ethernet
Optional Interfaces IEEE 802.11a/b/g Wireless LAN, Gigabit
Ethernet
Protocol TCP/IP
, NCP, SMB, SMTP, POP 3,
LDAP
, FTP
Memory Capacity Shared with Copier
File Types Single page and Multi-page TIFF/PDF,
High Compression PDF, Single page JPEG
Standard Features Embedded Scan-to-Email/HDD/Folder/
URL and TWAIN
Note: Color Scanning, Color Dropout and High Compression
PDF are not available on the LD425B/LD433B models.
FAX SPECIFICATIONS (OPTION)
Circuit PSTN, PBX
Compatibility ITU-T G3
ResoIution 200 x 200/100 dpi
400 x 400 dpi (Optional)
Compression Method MH, MR, MMR, JBIG
Scanning Speed 0.40 seconds (LEF)
Modem Speed 33.6 Kbps with Auto Fallback
Transmission Speed G3: 3 seconds per page
(MMR Compression)
G3: 2 seconds per page
(JBIG Compression)
Memory 4 MB standard/28 MB maximum
320 pages/2,240 pages
Std/Max Auto Dials 2,000 (with HDD)
Group Dials 100 (max. 500 numbers per group)
ID Code Programming 4 digits
User Function Key 3 keys
Standard Features Book Transmission, Dual Access, Duplex
Reception, Image Rotation, 1 Hour
Backup, LAN-Fax Capability*, Internet
Faxing (T.37)*, IP Faxing (T.38)*,
Fax Forwarding to E-Mail/HDD/Folder*
Optional Features Simultaneous Operation of up to
3 lines (G3 x 3)
Note: Fax is standard on the LD425SPF/LD433SPF models.
SECURITY FEATURES (STANDARD)*
S/MIME, IPsec Communication, Locked Print Password Encryption,
Encrypt Address Book, SSL Secure Socket Layer, User Authentication,
SNMP v3, Encryption of Password PDF, Encrypted PDF
PB3030 PAPER BANK UNIT (OPTION)
Paper Size 5.5" x 8.5"
A5 to A3
Paper Weight 16 to 28 lb. Bond/60 to 105 g/m2
Paper Capacity 2 x 500 sheets
Dimensions 21.7"(W) x 20.5"(D) x 10.7"(H)
PS500 LARGE CAPACITY TRAY (OPTION)
Paper Size 8.5" x 11"/A4
Paper Weight 16 to 28 lb. Bond/60 to 105 g/m2
Paper Capacity 2,000 sheets x 1
Dimensions 21.7"(W) x 20.5"(D) x 10.7"(H)
ONE-BIN TRAY BN3030 (OPTION)
Paper Size 5.5" x 8.5" to 11" x 17"/A5 to A3
Paper Weight 16 to 28 lb. Bond/60 to 105 g/m2
Paper Capacity 125 sheets
SR3050 500-SHEET FINISHER (OPTION)
Paper Size 5.5" x 8.5" to 11" x 17"/A6 to A3
Paper Weight 14 to 42 lb. Bond/52 to 157 g/m2
Stack Capacity Shift Tray: 500 sheets
(8.5" x 11" or smaller)
250 sheets (8.5" x 14" or larger)
Staple Capacity 50 sheets (8.5" x 11")
30 sheets (8.5" x 14" or larger)
Staple Position 1 staple/4 positions;
2 staples/1 position
Dimensions 15.6"(W) x 21.7"(D) x 10.9"(H)
SR790 1,000-SHEET FINISHER (OPTION)
Paper Size 5.5" x 8.5" to 11" x 17"/A6 to A3
Paper Weight 14 to 42 lb. Bond/52 to 260 g/m2
Stack Capacity Proof Tray: 250 sheets
(8.5" x 11" or smaller)
50 sheets (8.5" x 14" or larger)
Shift Tray: 1,000 sheets
(8.5" x 11" or smaller)
500 sheets
(8.5" x 14" or larger)
Staple Capacity 50 sheets (8.5" x 11")
30 sheets (8.5" x 14" or larger)
Staple Position 1 staple/2 positions;
2 staples/1 position
Dimensions 10.7"(W) x 20.5"(D) x 31.2"(H)
SR3000 BOOKLET FINISHER (OPTION)
Paper Size 5.5" x 8.5" to 11" x 17"/A6 to A3
Paper Weight 14 to 28 lb. Bond/52 to 105 g/m2(Proof
Tray); 14 to 68 lb. Bond/52 to 256 g/m2
(Shift Tray)
Stack Capacity Proof Tray: 100 sheets
(8.5" x 11" or smaller)
50 sheets (8.5" x 14" or larger)
Shift Tray: 1,000 sheets
(8.5" x 11" or smaller)
500 sheets
(8.5" x 14" or larger)
Staple Capacity 50 sheets (8.5" x 11")
30 sheets (8.5" x 14" or larger)
Staple Position 1 staple/2 positions;
2 staples/1 position
Dimensions 21.1"(W) x 23.7"(D) x 36.7"(H)
Punch Unit (Option) 2 or 3 hole punch
ARDF DF3030 (OPTION)
Paper Size 5.5" x 8.5" to 11" x 17"
Paper Weight 11 to 34 lb. Bond/40 to 128 g/m2
Stack Capacity 50 sheets
Dimensions 21.7"(W) x 19.3"(D) x 4.7"(H)
ADDITIONAL OPTIONS FOR LD425B/LD425
& LD433B/LD433
Platen Cover Type 3800C, FAC38 Cabinet, Fax Type 3350, G3
Interface Type 3350, 32 MB Fax Memory, Handset Type 1018,
IEEE 1284 Interface Board Type A, IEEE 802.11a/b/g Interface Unit
Type J, Adobe PostScript 3 Type 3350, Bridge Unit Type BU3020,
Internal Shift Sort Tray Type SH3010, Key Counter Bracket Type H,
File Format Converter Type E, DataOverwriteSecurity Unit Type I,
Copy Data Security Unit Type F, Bluetooth Interface Type 3245,
Java VM Card Type F, Punch Kit PU3000, HDD Encryption Type A,
Gigabit Ethernet Type A
ADDITIONAL OPTIONS FOR
LD425B/LD433B MODELS ONLY
Hard Disk Drive Type 5000, Printer Enhance Type 3350,
Printer/Scanner Unit Type 3350, RPCS Printer Unit Type 3350,
Scanner Enhance Type 3350
*Options for Lanier LD425B/LD433B
LD425B/LD425/LD433B/LD433
Complete document management solutions for offices on the move
DIGITAL IMAGING SYSTEM
LD425B/LD425 LD433B/LD433
From affordable to sophisticated, a powerful and efficient
combination of copying, printing, faxing and color scanning
capabilities in a single device
www.lanier.com
Lanier Five Dedrick Place, West Caldwell, NJ 07006
©2008 Lanier is a registered trademark of Ricoh Americas Corporation. All rights reserved. Windows®and Windows®95/98/ Me/NT4.0/2000/XP are registered trademarks of Microsoft Corporation. Macintosh®, Mac®OS
and AppleTalk®are registered trademarks of Apple Computer, Inc. Adobe®and PostScript®are registered trademarks of Adobe Systems, Inc. RPCS™is a trademark of Ricoh Company, Ltd. All other trademarks are the property
of their respective owners. Print speed may be affected by network, application or PC performance. Specifications and external appearances are subject to change without notice. Products are shown with optional features.
Printed in U.S.A. on recycled paper.
For a low-cost network
printer, where a specific
printer language is not
required, start with Lanier’s
RPCS printer unit.
For the next step up,
add the Printer Enhance
and get PCL printing
and document storage
capabilities.
For a device that can
send cost-free documents
electronically anywhere in
the world, simply add the
Scanner Enhance for black
& white scanning.
Choose the configuration that best meets
your office requirements and budgets.
Flexible upgrade path (LD425B/
LD433B)
One-Bin Tray (optional)
Provides a cost-effective
option to separate output
generated from two different
system functions, such as
faxes and prints.
100-Sheet Bypass Tray
Holds a variety of paper
types and sizes for printing
envelopes, labels and
transparencies.
Easy-Access Tray Handles
Unique design makes
accessing trays fast and
simple for everyone.
Duplex Unit
Provides stackless, two-sided
printing—cutting paper, filing
and postage costs in half.
2 x 500-Sheet Paper Trays (standard)
User-adjustable paper trays holds
envelopes, plus a range of paper sizes up
to 11” x 17” and weights up to 42 lb. Bond.
1,000-Sheet Booklet Finisher
(optional)
Provides three destinations for
output, including the ability to produce
paginated, saddle-stitched, punched
and folded booklets, greatly expanding
your in-house capabilities.
1,000-Sheet or 500-Sheet Finisher
also available.
50-Sheet Automatic Reversing
Document Feeder (ARDF)
(optional)
Efficiently processes multi-page
originals, even mixed sizes up
to 11” x 17”.
2 x 500-Sheet Paper Trays (optional)
Adjustable paper bank increases
capacity to hold up to five different
sizes and orientations of paper,
reducing maintenance requirements.
2,000-Sheet Large Capacity Tray also available.
Color Control Panel
Full-color VGA display with
the simplified display feature
makes using the system easy
and accessible for everyone.
LD425B/LD433B LD425SP/LD433SP LD425SPF/LD433SPF
For an all inclusive solution, a
Printer/Scanner Kit is also available.

Every office is unique. Yet all have the same overriding
pressures: raise productivity, complete projects faster,
improve quality and encourage collaboration. That’s
why the Lanier LD425B/LD425 & LD433B/LD433 is
such a compelling office solution. It’s engineered with
all the speed, quality, finishing capabilities and easy
usability you need to help accomplish the universal
objectives of your office. These systems also streamline
document distribution with the color/black & white
scanning capabilities of the Lanier LD425 & LD433,
and the black & white scanning capabilities of the
LD425B & LD433B.
Powerful Productivity
Getting your office up to speed in today’s global
marketplace means stepping up your delivery on a wide
range of variables. The Lanier LD425B/LD425 &
LD433B/LD433 is designed to help you get there.
• Boost your productivity with up to 33 prints per minute.
• Scan your documents and enter the world of cost-free electronic
document storage and distribution.
• Expand your faxing capabilities while greatly reducing faxing time
with up to three Super G3 fax lines.
• Give your documents the right finishing touch with three different
finishing options—including a 1,000-Sheet Booklet Finisher—all
designed to make you and your work look better than ever.
• The Lanier LD425B/LD425 & LD433B/LD433 can store up to 3,000
frequently used documents in its Document Server,where they can
be instantly accessed for reprinting, re-faxing or re-scanning.
• Special design features provide easy access for every
authorized user, such as the simplified color display,
easy-access paper tray handles and animated guidance.
The Intelligent Approach to Networking
To say the Lanier LD425B/LD425 & LD433B/LD433 is an
“intelligent” system sounds cliché, until you see just how
smart it is at helping you accomplish your objectives.
• Prioritize your job list by automatically moving the most critical jobs
to the head of the print queue, making sure they’re finished first.
• Choose the capabilities you need—from economical Refined Print
Command Stream (RPCS), PCL or sophisticated Adobe®PostScript®3™
—to handle exactly the type of documents you have.
• Reduce network traffic with PDF Direct Print by sending PDF files
directly to the printer without opening Adobe®Acrobat™Software.
Office productivity moves to the next level LD425B/LD425/LD433B/LD433
Color scanning combined with Scan-to-URL improves project
collaboration and reduces network traffic. (Color scanning is
not available on the LD425B/LD433B models).
With the Lanier RPCS Driver, you can simplify complex jobs
to one-click operations. For example, you can program the
driver to automatically duplex, three-hole punch, and insert
a front and back cover on a document—and then run the
program with a single button.
LAN Fax allows you to fax documents right from your desktop,
maximizing convenience and boosting productivity.
Manage the entire spectrum of your document
management tasks—from creation to production
to distribution—with the Lanier LD425B/LD425 &
LD433B/LD433 Digital Imaging Systems.
• Using Locked Print, you can protect your confidential documents from
being seen or accidentally picked up in the output tray by unauthorized
users—eliminating costly mail boxes.
• For the highest security requirements, you can use the
DataOverwriteSecurity System (DOSS) to prevent the
possibility of reconstructing data from “latent images”
of documents left in the internal hard drive.
• Use Unauthorized Copy Control to deter copying of sensitive documents—
a necessity for workgroups creating and distributing confidential information.
Simplified Management
With the Lanier LD425B/LD425 & LD433B/LD433, you can
turn your computer into a control center for everything from
system management and device monitoring to troubleshooting.
• Get instant access to system settings, program address books, and much
more with Web Image Monitor.
• Efficiently configure,monitor and manage multiple connected Lanier
devices with Web SmartDeviceMonitor.
• Rely on Auto E-mail Notification to generate an alert when the system is
low on toner or otherwise not functioning at optimum performance levels.
Technology to Empower
Your Business
At Lanier, we’re committed to helping you
achieve your goals for reducing overall Total
Cost of Ownership, optimizing fleet management
and ultimately increasing employee productivity.
• Automating service call procedures, eliminating the need for end-users
to initiate service calls. If a service call is required, the @Remote network
appliance automatically places a request for service—including detailed
and accurate diagnostic information.
• Upgrading and adjusting your devices via remote firmware applications,
which means that your devices will always be functioning within the
most current and productive operational parameters.
• To ensure that your devices are constantly up and running, alerts can be
sent, such as a low toner warning.
Your Environmental Partner
Lanier continues its long-standing
commitment to developing office solutions
with environmentally friendly and superior
energy- and supply-saving features, including:
• Quick Start-Up (QSU) Technology
• Power-saving Sleep Mode
• Duplex and Combine Copy Modes
• Internal Toner Recycling
• Low Noise Levels
• Minimal Ozone Emissions
• Restriction of Hazardous Substances (RoHS) Compliant
Experience the Benefits of Cost-Free
Document Distribution
The Lanier LD425B/LD425 & LD433B/LD433 gives you
the power to capture important documents and distribute
them anywhere in the world.
• Scan and capture documents and reports with the color/black & white
scanning capabilities of the LD425/LD433 and the black & white scanning
capabilities of the LD425B/LD433B, and then share them cost free using
the powerful Scan-to-Email/Folder/Hard Disk Drive features.
• Reduce programming time and make more efficient use of company
information by accessing up to five LDAP servers.
• Improve productivity and accuracy by viewing full-color thumbnails on
the control panel and confirming that scanned documents were captured
correctly before you distribute them.
• Use High Compression PDF to dramatically reduce the file sizes on
color documents—alleviating the problem of large documents moving
over your network—while still producing high quality prints.
• Reduce network traffic with Scan-to-URL, which allows you to store
documents on the Hard Disk Drive, where they can be viewed and
downloaded with a Web browser.
Powerful, Next-Generation Faxing
Sending and receiving faxes have never been easier, faster
or more convenient than with the Lanier LD425B/LD425 &
LD433B/LD433, cutting your costs no matter how you
distribute your documents.
• The Super G3 modem allows you to send out documents on up to three
analog lines, boosting your fax capabilities and reducing faxing time significantly.
• Internet Fax lets you send scanned documents directly to e-mail addresses,
eliminating both phone charges and wasted paper.
• Go completely paperless by automatically forwarding inbound faxes to e-mail
addresses,network folders or for storage on the systems’ Hard Disk Drive.
Keep Your Work Secure
The Lanier LD425B/LD425 & LD433B/LD433 is designed to
be an integral part of a total system of document security.
• Restrict access to the system only to people who are authorized and have
a password. You can also restrict usage rights by application; for example,
you can restrict scanning or faxing to authorized personnel only.

Every office is unique. Yet all have the same overriding
pressures: raise productivity, complete projects faster,
improve quality and encourage collaboration. That’s
why the Lanier LD425B/LD425 & LD433B/LD433 is
such a compelling office solution. It’s engineered with
all the speed, quality, finishing capabilities and easy
usability you need to help accomplish the universal
objectives of your office. These systems also streamline
document distribution with the color/black & white
scanning capabilities of the Lanier LD425 & LD433,
and the black & white scanning capabilities of the
LD425B & LD433B.
Powerful Productivity
Getting your office up to speed in today’s global
marketplace means stepping up your delivery on a wide
range of variables. The Lanier LD425B/LD425 &
LD433B/LD433 is designed to help you get there.
• Boost your productivity with up to 33 prints per minute.
• Scan your documents and enter the world of cost-free electronic
document storage and distribution.
• Expand your faxing capabilities while greatly reducing faxing time
with up to three Super G3 fax lines.
• Give your documents the right finishing touch with three different
finishing options—including a 1,000-Sheet Booklet Finisher—all
designed to make you and your work look better than ever.
• The Lanier LD425B/LD425 & LD433B/LD433 can store up to 3,000
frequently used documents in its Document Server,where they can
be instantly accessed for reprinting, re-faxing or re-scanning.
• Special design features provide easy access for every
authorized user, such as the simplified color display,
easy-access paper tray handles and animated guidance.
The Intelligent Approach to Networking
To say the Lanier LD425B/LD425 & LD433B/LD433 is an
“intelligent” system sounds cliché, until you see just how
smart it is at helping you accomplish your objectives.
• Prioritize your job list by automatically moving the most critical jobs
to the head of the print queue, making sure they’re finished first.
• Choose the capabilities you need—from economical Refined Print
Command Stream (RPCS), PCL or sophisticated Adobe®PostScript®3™
—to handle exactly the type of documents you have.
• Reduce network traffic with PDF Direct Print by sending PDF files
directly to the printer without opening Adobe®Acrobat™Software.
Office productivity moves to the next level LD425B/LD425/LD433B/LD433
Color scanning combined with Scan-to-URL improves project
collaboration and reduces network traffic. (Color scanning is
not available on the LD425B/LD433B models).
With the Lanier RPCS Driver, you can simplify complex jobs
to one-click operations. For example, you can program the
driver to automatically duplex, three-hole punch, and insert
a front and back cover on a document—and then run the
program with a single button.
LAN Fax allows you to fax documents right from your desktop,
maximizing convenience and boosting productivity.
Manage the entire spectrum of your document
management tasks—from creation to production
to distribution—with the Lanier LD425B/LD425 &
LD433B/LD433 Digital Imaging Systems.
• Using Locked Print, you can protect your confidential documents from
being seen or accidentally picked up in the output tray by unauthorized
users—eliminating costly mail boxes.
• For the highest security requirements, you can use the
DataOverwriteSecurity System (DOSS) to prevent the
possibility of reconstructing data from “latent images”
of documents left in the internal hard drive.
• Use Unauthorized Copy Control to deter copying of sensitive documents—
a necessity for workgroups creating and distributing confidential information.
Simplified Management
With the Lanier LD425B/LD425 & LD433B/LD433, you can
turn your computer into a control center for everything from
system management and device monitoring to troubleshooting.
• Get instant access to system settings, program address books, and much
more with Web Image Monitor.
• Efficiently configure,monitor and manage multiple connected Lanier
devices with Web SmartDeviceMonitor.
• Rely on Auto E-mail Notification to generate an alert when the system is
low on toner or otherwise not functioning at optimum performance levels.
Technology to Empower
Your Business
At Lanier, we’re committed to helping you
achieve your goals for reducing overall Total
Cost of Ownership, optimizing fleet management
and ultimately increasing employee productivity.
• Automating service call procedures, eliminating the need for end-users
to initiate service calls. If a service call is required, the @Remote network
appliance automatically places a request for service—including detailed
and accurate diagnostic information.
• Upgrading and adjusting your devices via remote firmware applications,
which means that your devices will always be functioning within the
most current and productive operational parameters.
• To ensure that your devices are constantly up and running, alerts can be
sent, such as a low toner warning.
Your Environmental Partner
Lanier continues its long-standing
commitment to developing office solutions
with environmentally friendly and superior
energy- and supply-saving features, including:
• Quick Start-Up (QSU) Technology
• Power-saving Sleep Mode
• Duplex and Combine Copy Modes
• Internal Toner Recycling
• Low Noise Levels
• Minimal Ozone Emissions
• Restriction of Hazardous Substances (RoHS) Compliant
Experience the Benefits of Cost-Free
Document Distribution
The Lanier LD425B/LD425 & LD433B/LD433 gives you
the power to capture important documents and distribute
them anywhere in the world.
• Scan and capture documents and reports with the color/black & white
scanning capabilities of the LD425/LD433 and the black & white scanning
capabilities of the LD425B/LD433B, and then share them cost free using
the powerful Scan-to-Email/Folder/Hard Disk Drive features.
• Reduce programming time and make more efficient use of company
information by accessing up to five LDAP servers.
• Improve productivity and accuracy by viewing full-color thumbnails on
the control panel and confirming that scanned documents were captured
correctly before you distribute them.
• Use High Compression PDF to dramatically reduce the file sizes on
color documents—alleviating the problem of large documents moving
over your network—while still producing high quality prints.
• Reduce network traffic with Scan-to-URL, which allows you to store
documents on the Hard Disk Drive, where they can be viewed and
downloaded with a Web browser.
Powerful, Next-Generation Faxing
Sending and receiving faxes have never been easier, faster
or more convenient than with the Lanier LD425B/LD425 &
LD433B/LD433, cutting your costs no matter how you
distribute your documents.
• The Super G3 modem allows you to send out documents on up to three
analog lines, boosting your fax capabilities and reducing faxing time significantly.
• Internet Fax lets you send scanned documents directly to e-mail addresses,
eliminating both phone charges and wasted paper.
• Go completely paperless by automatically forwarding inbound faxes to e-mail
addresses,network folders or for storage on the systems’ Hard Disk Drive.
Keep Your Work Secure
The Lanier LD425B/LD425 & LD433B/LD433 is designed to
be an integral part of a total system of document security.
• Restrict access to the system only to people who are authorized and have
a password. You can also restrict usage rights by application; for example,
you can restrict scanning or faxing to authorized personnel only.

Every office is unique. Yet all have the same overriding
pressures: raise productivity, complete projects faster,
improve quality and encourage collaboration. That’s
why the Lanier LD425B/LD425 & LD433B/LD433 is
such a compelling office solution. It’s engineered with
all the speed, quality, finishing capabilities and easy
usability you need to help accomplish the universal
objectives of your office. These systems also streamline
document distribution with the color/black & white
scanning capabilities of the Lanier LD425 & LD433,
and the black & white scanning capabilities of the
LD425B & LD433B.
Powerful Productivity
Getting your office up to speed in today’s global
marketplace means stepping up your delivery on a wide
range of variables. The Lanier LD425B/LD425 &
LD433B/LD433 is designed to help you get there.
• Boost your productivity with up to 33 prints per minute.
• Scan your documents and enter the world of cost-free electronic
document storage and distribution.
• Expand your faxing capabilities while greatly reducing faxing time
with up to three Super G3 fax lines.
• Give your documents the right finishing touch with three different
finishing options—including a 1,000-Sheet Booklet Finisher—all
designed to make you and your work look better than ever.
• The Lanier LD425B/LD425 & LD433B/LD433 can store up to 3,000
frequently used documents in its Document Server,where they can
be instantly accessed for reprinting, re-faxing or re-scanning.
• Special design features provide easy access for every
authorized user, such as the simplified color display,
easy-access paper tray handles and animated guidance.
The Intelligent Approach to Networking
To say the Lanier LD425B/LD425 & LD433B/LD433 is an
“intelligent” system sounds cliché, until you see just how
smart it is at helping you accomplish your objectives.
• Prioritize your job list by automatically moving the most critical jobs
to the head of the print queue, making sure they’re finished first.
• Choose the capabilities you need—from economical Refined Print
Command Stream (RPCS), PCL or sophisticated Adobe®PostScript®3™
—to handle exactly the type of documents you have.
• Reduce network traffic with PDF Direct Print by sending PDF files
directly to the printer without opening Adobe®Acrobat™Software.
Office productivity moves to the next level LD425B/LD425/LD433B/LD433
Color scanning combined with Scan-to-URL improves project
collaboration and reduces network traffic. (Color scanning is
not available on the LD425B/LD433B models).
With the Lanier RPCS Driver, you can simplify complex jobs
to one-click operations. For example, you can program the
driver to automatically duplex, three-hole punch, and insert
a front and back cover on a document—and then run the
program with a single button.
LAN Fax allows you to fax documents right from your desktop,
maximizing convenience and boosting productivity.
Manage the entire spectrum of your document
management tasks—from creation to production
to distribution—with the Lanier LD425B/LD425 &
LD433B/LD433 Digital Imaging Systems.
• Using Locked Print, you can protect your confidential documents from
being seen or accidentally picked up in the output tray by unauthorized
users—eliminating costly mail boxes.
• For the highest security requirements, you can use the
DataOverwriteSecurity System (DOSS) to prevent the
possibility of reconstructing data from “latent images”
of documents left in the internal hard drive.
• Use Unauthorized Copy Control to deter copying of sensitive documents—
a necessity for workgroups creating and distributing confidential information.
Simplified Management
With the Lanier LD425B/LD425 & LD433B/LD433, you can
turn your computer into a control center for everything from
system management and device monitoring to troubleshooting.
• Get instant access to system settings, program address books, and much
more with Web Image Monitor.
• Efficiently configure,monitor and manage multiple connected Lanier
devices with Web SmartDeviceMonitor.
• Rely on Auto E-mail Notification to generate an alert when the system is
low on toner or otherwise not functioning at optimum performance levels.
Technology to Empower
Your Business
At Lanier, we’re committed to helping you
achieve your goals for reducing overall Total
Cost of Ownership, optimizing fleet management
and ultimately increasing employee productivity.
• Automating service call procedures, eliminating the need for end-users
to initiate service calls. If a service call is required, the @Remote network
appliance automatically places a request for service—including detailed
and accurate diagnostic information.
• Upgrading and adjusting your devices via remote firmware applications,
which means that your devices will always be functioning within the
most current and productive operational parameters.
• To ensure that your devices are constantly up and running, alerts can be
sent, such as a low toner warning.
Your Environmental Partner
Lanier continues its long-standing
commitment to developing office solutions
with environmentally friendly and superior
energy- and supply-saving features, including:
• Quick Start-Up (QSU) Technology
• Power-saving Sleep Mode
• Duplex and Combine Copy Modes
• Internal Toner Recycling
• Low Noise Levels
• Minimal Ozone Emissions
• Restriction of Hazardous Substances (RoHS) Compliant
Experience the Benefits of Cost-Free
Document Distribution
The Lanier LD425B/LD425 & LD433B/LD433 gives you
the power to capture important documents and distribute
them anywhere in the world.
• Scan and capture documents and reports with the color/black & white
scanning capabilities of the LD425/LD433 and the black & white scanning
capabilities of the LD425B/LD433B, and then share them cost free using
the powerful Scan-to-Email/Folder/Hard Disk Drive features.
• Reduce programming time and make more efficient use of company
information by accessing up to five LDAP servers.
• Improve productivity and accuracy by viewing full-color thumbnails on
the control panel and confirming that scanned documents were captured
correctly before you distribute them.
• Use High Compression PDF to dramatically reduce the file sizes on
color documents—alleviating the problem of large documents moving
over your network—while still producing high quality prints.
• Reduce network traffic with Scan-to-URL, which allows you to store
documents on the Hard Disk Drive, where they can be viewed and
downloaded with a Web browser.
Powerful, Next-Generation Faxing
Sending and receiving faxes have never been easier, faster
or more convenient than with the Lanier LD425B/LD425 &
LD433B/LD433, cutting your costs no matter how you
distribute your documents.
• The Super G3 modem allows you to send out documents on up to three
analog lines, boosting your fax capabilities and reducing faxing time significantly.
• Internet Fax lets you send scanned documents directly to e-mail addresses,
eliminating both phone charges and wasted paper.
• Go completely paperless by automatically forwarding inbound faxes to e-mail
addresses,network folders or for storage on the systems’ Hard Disk Drive.
Keep Your Work Secure
The Lanier LD425B/LD425 & LD433B/LD433 is designed to
be an integral part of a total system of document security.
• Restrict access to the system only to people who are authorized and have
a password. You can also restrict usage rights by application; for example,
you can restrict scanning or faxing to authorized personnel only.

For exceptional black
& white printing and
color and black &
white scanning.
For a complete document
management system with
printing, faxing, color and
black & white scanning in
a single, compact device.
For robust copying and a
flexible upgrade path to
black & white printing,
scanning and faxing.
DIGITAL IMAGING SYSTEM
LD425B/LD425/LD433B/LD433
L2684
SPECIFICATIONS
ENGINE/COPIER SPECIFICATIONS
Configuration Console
Scanning Element Flatbed with Moving CCD
Array Image Sensor
Printing Process Single Laser Beam Scanning &
Electrophotographic Printing
Document Feeding Optional 50-Sheet ARDF
Toner Dry, Dual Component
System Memory LD425B/LD433B: 256/512 MB RAM
(std./max.) LD425/LD433: 768/768 MB RAM
Hard Disk Drive LD425/LD433: 40 GB Standard
LD425B/LD433B: 40 GB Optional
Copy Resolution 600 x 600 dpi
Grayscale 256 levels
Exposure Adjustment Manual & Automatic
Quantity Indicator Up to 999
Original Type Book/Sheet
Maximum Original Size Up to 11" x 17"
Copy Size 5.5" x 8.5" to 11" x 17"
Copy Type Plain Paper, Transparencies, Envelopes,
Cardstock, Recycled
Warm-Up Time 14 seconds
First Copy Speed 4.5 seconds
Continuous Copying LD425B/LD425: 25 copies/minute (LTR)
Speed LD433B/LD433: 33 copies/minute (LTR)
Recovery Time 10 seconds (from Auto Off)
Power Source 120V/60Hz
Dimensions 24.8"(W) x 25.7"(D) x 27.9"(H)
Weight 143 lbs.
Standard Paper 500 sheets x 2 trays, and
Capacity 100-Sheet Bypass Tray
Optional Paper 500 sheets x 2 trays or
Capacity 2,000-Sheet Large Capacity Tray
Paper Size 5.5" x 8.5" to 11" x 17"
A5 to A3
Paper Weight 16 – 28 lb. Bond/60 – 105 g/m2
(Tray 1 and Duplex)
14 – 42 lb. Bond/52 – 157 g/m2
(Tray 2 and Bypass)
Standard Output Tray 500 sheets (Letter),
Capacity 250 sheets (Legal, Ledger)
Reduction Ratios 25%, 50%, 65%, 73%, 78%, 85%,
93%, 100%
Enlargement Ratios 121%, 129%, 155%, 200%, 400%
Zoom 25% to 400% in 1% increments
Standard Features Auto Magnification, Auto Paper Select,
Auto Tray Switch, Center/Border Erase,
Chapters, Combine Mode, Cover Insertion,
Date Stamp, Directional Magnification,
Electronic/Rotate Sorting, English Pre-Set
Stamps, Full-Color VGA Touch-Screen
Control Panel, 10 Job Programs,
Negative/Positive, OHP Slip Sheet, Page
Number Stamp, 500 User Codes
Hard Drive Required 8 Job Presets, Background Numbering,
Booklet/Magazine Copy, Document
Server (3,000 File Capacity), Series Copy,
User Stamps
PRINTER SPECIFICATIONS (STANDARD)*
Print Speed LD425B/LD425: 25 ppm
LD433B/LD433: 33 ppm
CPU RM7035C 533 MHz
Standard Interfaces 10/100BaseTX Ethernet, USB 2.0
Optional Interfaces IEEE 802.11a/b/g Wireless LAN, Bluetooth,
IEEE 1284, Gigabit Ethernet
Memory Capacity Shared with Copier
Network Protocol TCP/IP, IPX/SPX, AppleTalk
Network Operating Windows Vista/2000/ME/XP/Server 2003,
Systems Netware 3.12, 3.2, 4.1, 4.11, 5.0, 5.1,
6.0, 6.5, Unix; Sun Solaris, HP-UX,
SCO OpenServer, Red Hat Linux,
IBM AIX, Mac OS 8.6 – 9.2x, OS X 10.1
or later, SAP R/3, NDPS Gateway,
IBM iSeries/AS/400®using OS/400
Host Print Transform, Citrix Metaframe
Utilities SmartDeviceMonitor,
Web SmartDeviceMonitor,
DeskTopBinder,
Web Image Monitor
Page Description PCL 5e/6 emulation
Languages Lanier RPCS
Adobe PostScript 3 (optional)
Print Resolution Up to 600 dpi (2400 x 600 dpi
with smoothing)
Grayscale 256 levels
Fonts for PCL 5e/6 35 Intellifonts, 10 TrueType,
1 Bitmap and 13 International Fonts
Fonts for PS3 136 PostScript Fonts
Standard Features Sample/Locked/Hold/Stored Print
(Hard Disk Drive)
SCANNER SPECIFICATIONS (STANDARD)*
Scanning Speed Embedded Scanning: 50/29 ipm
B&W/Color (@ 200 dpi)
Scanning Resolution 600 dpi
Grayscale 256 levels
Scan Area Up to 11" x 17"
Standard Interfaces 10/100BaseTX Ethernet
Optional Interfaces IEEE 802.11a/b/g Wireless LAN, Gigabit
Ethernet
Protocol TCP/IP
, NCP, SMB, SMTP, POP 3,
LDAP
, FTP
Memory Capacity Shared with Copier
File Types Single page and Multi-page TIFF/PDF,
High Compression PDF, Single page JPEG
Standard Features Embedded Scan-to-Email/HDD/Folder/
URL and TWAIN
Note: Color Scanning, Color Dropout and High Compression
PDF are not available on the LD425B/LD433B models.
FAX SPECIFICATIONS (OPTION)
Circuit PSTN, PBX
Compatibility ITU-T G3
ResoIution 200 x 200/100 dpi
400 x 400 dpi (Optional)
Compression Method MH, MR, MMR, JBIG
Scanning Speed 0.40 seconds (LEF)
Modem Speed 33.6 Kbps with Auto Fallback
Transmission Speed G3: 3 seconds per page
(MMR Compression)
G3: 2 seconds per page
(JBIG Compression)
Memory 4 MB standard/28 MB maximum
320 pages/2,240 pages
Std/Max Auto Dials 2,000 (with HDD)
Group Dials 100 (max. 500 numbers per group)
ID Code Programming 4 digits
User Function Key 3 keys
Standard Features Book Transmission, Dual Access, Duplex
Reception, Image Rotation, 1 Hour
Backup, LAN-Fax Capability*, Internet
Faxing (T.37)*, IP Faxing (T.38)*,
Fax Forwarding to E-Mail/HDD/Folder*
Optional Features Simultaneous Operation of up to
3 lines (G3 x 3)
Note: Fax is standard on the LD425SPF/LD433SPF models.
SECURITY FEATURES (STANDARD)*
S/MIME, IPsec Communication, Locked Print Password Encryption,
Encrypt Address Book, SSL Secure Socket Layer, User Authentication,
SNMP v3, Encryption of Password PDF, Encrypted PDF
PB3030 PAPER BANK UNIT (OPTION)
Paper Size 5.5" x 8.5"
A5 to A3
Paper Weight 16 to 28 lb. Bond/60 to 105 g/m2
Paper Capacity 2 x 500 sheets
Dimensions 21.7"(W) x 20.5"(D) x 10.7"(H)
PS500 LARGE CAPACITY TRAY (OPTION)
Paper Size 8.5" x 11"/A4
Paper Weight 16 to 28 lb. Bond/60 to 105 g/m2
Paper Capacity 2,000 sheets x 1
Dimensions 21.7"(W) x 20.5"(D) x 10.7"(H)
ONE-BIN TRAY BN3030 (OPTION)
Paper Size 5.5" x 8.5" to 11" x 17"/A5 to A3
Paper Weight 16 to 28 lb. Bond/60 to 105 g/m2
Paper Capacity 125 sheets
SR3050 500-SHEET FINISHER (OPTION)
Paper Size 5.5" x 8.5" to 11" x 17"/A6 to A3
Paper Weight 14 to 42 lb. Bond/52 to 157 g/m2
Stack Capacity Shift Tray: 500 sheets
(8.5" x 11" or smaller)
250 sheets (8.5" x 14" or larger)
Staple Capacity 50 sheets (8.5" x 11")
30 sheets (8.5" x 14" or larger)
Staple Position 1 staple/4 positions;
2 staples/1 position
Dimensions 15.6"(W) x 21.7"(D) x 10.9"(H)
SR790 1,000-SHEET FINISHER (OPTION)
Paper Size 5.5" x 8.5" to 11" x 17"/A6 to A3
Paper Weight 14 to 42 lb. Bond/52 to 260 g/m2
Stack Capacity Proof Tray: 250 sheets
(8.5" x 11" or smaller)
50 sheets (8.5" x 14" or larger)
Shift Tray: 1,000 sheets
(8.5" x 11" or smaller)
500 sheets
(8.5" x 14" or larger)
Staple Capacity 50 sheets (8.5" x 11")
30 sheets (8.5" x 14" or larger)
Staple Position 1 staple/2 positions;
2 staples/1 position
Dimensions 10.7"(W) x 20.5"(D) x 31.2"(H)
SR3000 BOOKLET FINISHER (OPTION)
Paper Size 5.5" x 8.5" to 11" x 17"/A6 to A3
Paper Weight 14 to 28 lb. Bond/52 to 105 g/m2(Proof
Tray); 14 to 68 lb. Bond/52 to 256 g/m2
(Shift Tray)
Stack Capacity Proof Tray: 100 sheets
(8.5" x 11" or smaller)
50 sheets (8.5" x 14" or larger)
Shift Tray: 1,000 sheets
(8.5" x 11" or smaller)
500 sheets
(8.5" x 14" or larger)
Staple Capacity 50 sheets (8.5" x 11")
30 sheets (8.5" x 14" or larger)
Staple Position 1 staple/2 positions;
2 staples/1 position
Dimensions 21.1"(W) x 23.7"(D) x 36.7"(H)
Punch Unit (Option) 2 or 3 hole punch
ARDF DF3030 (OPTION)
Paper Size 5.5" x 8.5" to 11" x 17"
Paper Weight 11 to 34 lb. Bond/40 to 128 g/m2
Stack Capacity 50 sheets
Dimensions 21.7"(W) x 19.3"(D) x 4.7"(H)
ADDITIONAL OPTIONS FOR LD425B/LD425
& LD433B/LD433
Platen Cover Type 3800C, FAC38 Cabinet, Fax Type 3350, G3
Interface Type 3350, 32 MB Fax Memory, Handset Type 1018,
IEEE 1284 Interface Board Type A, IEEE 802.11a/b/g Interface Unit
Type J, Adobe PostScript 3 Type 3350, Bridge Unit Type BU3020,
Internal Shift Sort Tray Type SH3010, Key Counter Bracket Type H,
File Format Converter Type E, DataOverwriteSecurity Unit Type I,
Copy Data Security Unit Type F, Bluetooth Interface Type 3245,
Java VM Card Type F, Punch Kit PU3000, HDD Encryption Type A,
Gigabit Ethernet Type A
ADDITIONAL OPTIONS FOR
LD425B/LD433B MODELS ONLY
Hard Disk Drive Type 5000, Printer Enhance Type 3350,
Printer/Scanner Unit Type 3350, RPCS Printer Unit Type 3350,
Scanner Enhance Type 3350
*Options for Lanier LD425B/LD433B
LD425B/LD425/LD433B/LD433
Complete document management solutions for offices on the move
DIGITAL IMAGING SYSTEM
LD425B/LD425 LD433B/LD433
From affordable to sophisticated, a powerful and efficient
combination of copying, printing, faxing and color scanning
capabilities in a single device
www.lanier.com
Lanier Five Dedrick Place, West Caldwell, NJ 07006
©2008 Lanier is a registered trademark of Ricoh Americas Corporation. All rights reserved. Windows®and Windows®95/98/ Me/NT4.0/2000/XP are registered trademarks of Microsoft Corporation. Macintosh®, Mac®OS
and AppleTalk®are registered trademarks of Apple Computer, Inc. Adobe®and PostScript®are registered trademarks of Adobe Systems, Inc. RPCS™is a trademark of Ricoh Company, Ltd. All other trademarks are the property
of their respective owners. Print speed may be affected by network, application or PC performance. Specifications and external appearances are subject to change without notice. Products are shown with optional features.
Printed in U.S.A. on recycled paper.
For a low-cost network
printer, where a specific
printer language is not
required, start with Lanier’s
RPCS printer unit.
For the next step up,
add the Printer Enhance
and get PCL printing
and document storage
capabilities.
For a device that can
send cost-free documents
electronically anywhere in
the world, simply add the
Scanner Enhance for black
& white scanning.
Choose the configuration that best meets
your office requirements and budgets.
Flexible upgrade path (LD425B/
LD433B)
One-Bin Tray (optional)
Provides a cost-effective
option to separate output
generated from two different
system functions, such as
faxes and prints.
100-Sheet Bypass Tray
Holds a variety of paper
types and sizes for printing
envelopes, labels and
transparencies.
Easy-Access Tray Handles
Unique design makes
accessing trays fast and
simple for everyone.
Duplex Unit
Provides stackless, two-sided
printing—cutting paper, filing
and postage costs in half.
2 x 500-Sheet Paper Trays (standard)
User-adjustable paper trays holds
envelopes, plus a range of paper sizes up
to 11” x 17” and weights up to 42 lb. Bond.
1,000-Sheet Booklet Finisher
(optional)
Provides three destinations for
output, including the ability to produce
paginated, saddle-stitched, punched
and folded booklets, greatly expanding
your in-house capabilities.
1,000-Sheet or 500-Sheet Finisher
also available.
50-Sheet Automatic Reversing
Document Feeder (ARDF)
(optional)
Efficiently processes multi-page
originals, even mixed sizes up
to 11” x 17”.
2 x 500-Sheet Paper Trays (optional)
Adjustable paper bank increases
capacity to hold up to five different
sizes and orientations of paper,
reducing maintenance requirements.
2,000-Sheet Large Capacity Tray also available.
Color Control Panel
Full-color VGA display with
the simplified display feature
makes using the system easy
and accessible for everyone.
LD425B/LD433B LD425SP/LD433SP LD425SPF/LD433SPF
For an all inclusive solution, a
Printer/Scanner Kit is also available.

DIGITAL IMAGING SYSTEM
LD425B/LD425/LD433B/LD433
L2684
SPECIFICATIONS
ENGINE/COPIER SPECIFICATIONS
Configuration Console
Scanning Element Flatbed with Moving CCD
Array Image Sensor
Printing Process Single Laser Beam Scanning &
Electrophotographic Printing
Document Feeding Optional 50-Sheet ARDF
Toner Dry, Dual Component
System Memory LD425B/LD433B: 256/512 MB RAM
(std./max.) LD425/LD433: 768/768 MB RAM
Hard Disk Drive LD425/LD433: 40 GB Standard
LD425B/LD433B: 40 GB Optional
Copy Resolution 600 x 600 dpi
Grayscale 256 levels
Exposure Adjustment Manual & Automatic
Quantity Indicator Up to 999
Original Type Book/Sheet
Maximum Original Size Up to 11" x 17"
Copy Size 5.5" x 8.5" to 11" x 17"
Copy Type Plain Paper, Transparencies, Envelopes,
Cardstock, Recycled
Warm-Up Time 14 seconds
First Copy Speed 4.5 seconds
Continuous Copying LD425B/LD425: 25 copies/minute (LTR)
Speed LD433B/LD433: 33 copies/minute (LTR)
Recovery Time 10 seconds (from Auto Off)
Power Source 120V/60Hz
Dimensions 24.8"(W) x 25.7"(D) x 27.9"(H)
Weight 143 lbs.
Standard Paper 500 sheets x 2 trays, and
Capacity 100-Sheet Bypass Tray
Optional Paper 500 sheets x 2 trays or
Capacity 2,000-Sheet Large Capacity Tray
Paper Size 5.5" x 8.5" to 11" x 17"
A5 to A3
Paper Weight 16 – 28 lb. Bond/60 – 105 g/m2
(Tray 1 and Duplex)
14 – 42 lb. Bond/52 – 157 g/m2
(Tray 2 and Bypass)
Standard Output Tray 500 sheets (Letter),
Capacity 250 sheets (Legal, Ledger)
Reduction Ratios 25%, 50%, 65%, 73%, 78%, 85%,
93%, 100%
Enlargement Ratios 121%, 129%, 155%, 200%, 400%
Zoom 25% to 400% in 1% increments
Standard Features Auto Magnification, Auto Paper Select,
Auto Tray Switch, Center/Border Erase,
Chapters, Combine Mode, Cover Insertion,
Date Stamp, Directional Magnification,
Electronic/Rotate Sorting, English Pre-Set
Stamps, Full-Color VGA Touch-Screen
Control Panel, 10 Job Programs,
Negative/Positive, OHP Slip Sheet, Page
Number Stamp, 500 User Codes
Hard Drive Required 8 Job Presets, Background Numbering,
Booklet/Magazine Copy, Document
Server (3,000 File Capacity), Series Copy,
User Stamps
PRINTER SPECIFICATIONS (STANDARD)*
Print Speed LD425B/LD425: 25 ppm
LD433B/LD433: 33 ppm
CPU RM7035C 533 MHz
Standard Interfaces 10/100BaseTX Ethernet, USB 2.0
Optional Interfaces IEEE 802.11a/b/g Wireless LAN, Bluetooth,
IEEE 1284, Gigabit Ethernet
Memory Capacity Shared with Copier
Network Protocol TCP/IP, IPX/SPX, AppleTalk
Network Operating Windows Vista/2000/ME/XP/Server 2003,
Systems Netware 3.12, 3.2, 4.1, 4.11, 5.0, 5.1,
6.0, 6.5, Unix; Sun Solaris, HP-UX,
SCO OpenServer, Red Hat Linux,
IBM AIX, Mac OS 8.6 – 9.2x, OS X 10.1
or later, SAP R/3, NDPS Gateway,
IBM iSeries/AS/400®using OS/400
Host Print Transform, Citrix Metaframe
Utilities SmartDeviceMonitor,
Web SmartDeviceMonitor,
DeskTopBinder,
Web Image Monitor
Page Description PCL 5e/6 emulation
Languages Lanier RPCS
Adobe PostScript 3 (optional)
Print Resolution Up to 600 dpi (2400 x 600 dpi
with smoothing)
Grayscale 256 levels
Fonts for PCL 5e/6 35 Intellifonts, 10 TrueType,
1 Bitmap and 13 International Fonts
Fonts for PS3 136 PostScript Fonts
Standard Features Sample/Locked/Hold/Stored Print
(Hard Disk Drive)
SCANNER SPECIFICATIONS (STANDARD)*
Scanning Speed Embedded Scanning: 50/29 ipm
B&W/Color (@ 200 dpi)
Scanning Resolution 600 dpi
Grayscale 256 levels
Scan Area Up to 11" x 17"
Standard Interfaces 10/100BaseTX Ethernet
Optional Interfaces IEEE 802.11a/b/g Wireless LAN, Gigabit
Ethernet
Protocol TCP/IP
, NCP, SMB, SMTP, POP 3,
LDAP
, FTP
Memory Capacity Shared with Copier
File Types Single page and Multi-page TIFF/PDF,
High Compression PDF, Single page JPEG
Standard Features Embedded Scan-to-Email/HDD/Folder/
URL and TWAIN
Note: Color Scanning, Color Dropout and High Compression
PDF are not available on the LD425B/LD433B models.
FAX SPECIFICATIONS (OPTION)
Circuit PSTN, PBX
Compatibility ITU-T G3
ResoIution 200 x 200/100 dpi
400 x 400 dpi (Optional)
Compression Method MH, MR, MMR, JBIG
Scanning Speed 0.40 seconds (LEF)
Modem Speed 33.6 Kbps with Auto Fallback
Transmission Speed G3: 3 seconds per page
(MMR Compression)
G3: 2 seconds per page
(JBIG Compression)
Memory 4 MB standard/28 MB maximum
320 pages/2,240 pages
Std/Max Auto Dials 2,000 (with HDD)
Group Dials 100 (max. 500 numbers per group)
ID Code Programming 4 digits
User Function Key 3 keys
Standard Features Book Transmission, Dual Access, Duplex
Reception, Image Rotation, 1 Hour
Backup, LAN-Fax Capability*, Internet
Faxing (T.37)*, IP Faxing (T.38)*,
Fax Forwarding to E-Mail/HDD/Folder*
Optional Features Simultaneous Operation of up to
3 lines (G3 x 3)
Note: Fax is standard on the LD425SPF/LD433SPF models.
SECURITY FEATURES (STANDARD)*
S/MIME, IPsec Communication, Locked Print Password Encryption,
Encrypt Address Book, SSL Secure Socket Layer, User Authentication,
SNMP v3, Encryption of Password PDF, Encrypted PDF
PB3030 PAPER BANK UNIT (OPTION)
Paper Size 5.5" x 8.5"
A5 to A3
Paper Weight 16 to 28 lb. Bond/60 to 105 g/m2
Paper Capacity 2 x 500 sheets
Dimensions 21.7"(W) x 20.5"(D) x 10.7"(H)
PS500 LARGE CAPACITY TRAY (OPTION)
Paper Size 8.5" x 11"/A4
Paper Weight 16 to 28 lb. Bond/60 to 105 g/m2
Paper Capacity 2,000 sheets x 1
Dimensions 21.7"(W) x 20.5"(D) x 10.7"(H)
ONE-BIN TRAY BN3030 (OPTION)
Paper Size 5.5" x 8.5" to 11" x 17"/A5 to A3
Paper Weight 16 to 28 lb. Bond/60 to 105 g/m2
Paper Capacity 125 sheets
SR3050 500-SHEET FINISHER (OPTION)
Paper Size 5.5" x 8.5" to 11" x 17"/A6 to A3
Paper Weight 14 to 42 lb. Bond/52 to 157 g/m2
Stack Capacity Shift Tray: 500 sheets
(8.5" x 11" or smaller)
250 sheets (8.5" x 14" or larger)
Staple Capacity 50 sheets (8.5" x 11")
30 sheets (8.5" x 14" or larger)
Staple Position 1 staple/4 positions;
2 staples/1 position
Dimensions 15.6"(W) x 21.7"(D) x 10.9"(H)
SR790 1,000-SHEET FINISHER (OPTION)
Paper Size 5.5" x 8.5" to 11" x 17"/A6 to A3
Paper Weight 14 to 42 lb. Bond/52 to 260 g/m2
Stack Capacity Proof Tray: 250 sheets
(8.5" x 11" or smaller)
50 sheets (8.5" x 14" or larger)
Shift Tray: 1,000 sheets
(8.5" x 11" or smaller)
500 sheets
(8.5" x 14" or larger)
Staple Capacity 50 sheets (8.5" x 11")
30 sheets (8.5" x 14" or larger)
Staple Position 1 staple/2 positions;
2 staples/1 position
Dimensions 10.7"(W) x 20.5"(D) x 31.2"(H)
SR3000 BOOKLET FINISHER (OPTION)
Paper Size 5.5" x 8.5" to 11" x 17"/A6 to A3
Paper Weight 14 to 28 lb. Bond/52 to 105 g/m2(Proof
Tray); 14 to 68 lb. Bond/52 to 256 g/m2
(Shift Tray)
Stack Capacity Proof Tray: 100 sheets
(8.5" x 11" or smaller)
50 sheets (8.5" x 14" or larger)
Shift Tray: 1,000 sheets
(8.5" x 11" or smaller)
500 sheets
(8.5" x 14" or larger)
Staple Capacity 50 sheets (8.5" x 11")
30 sheets (8.5" x 14" or larger)
Staple Position 1 staple/2 positions;
2 staples/1 position
Dimensions 21.1"(W) x 23.7"(D) x 36.7"(H)
Punch Unit (Option) 2 or 3 hole punch
ARDF DF3030 (OPTION)
Paper Size 5.5" x 8.5" to 11" x 17"
Paper Weight 11 to 34 lb. Bond/40 to 128 g/m2
Stack Capacity 50 sheets
Dimensions 21.7"(W) x 19.3"(D) x 4.7"(H)
ADDITIONAL OPTIONS FOR LD425B/LD425
& LD433B/LD433
Platen Cover Type 3800C, FAC38 Cabinet, Fax Type 3350, G3
Interface Type 3350, 32 MB Fax Memory, Handset Type 1018,
IEEE 1284 Interface Board Type A, IEEE 802.11a/b/g Interface Unit
Type J, Adobe PostScript 3 Type 3350, Bridge Unit Type BU3020,
Internal Shift Sort Tray Type SH3010, Key Counter Bracket Type H,
File Format Converter Type E, DataOverwriteSecurity Unit Type I,
Copy Data Security Unit Type F, Bluetooth Interface Type 3245,
Java VM Card Type F, Punch Kit PU3000, HDD Encryption Type A,
Gigabit Ethernet Type A
ADDITIONAL OPTIONS FOR
LD425B/LD433B MODELS ONLY
Hard Disk Drive Type 5000, Printer Enhance Type 3350,
Printer/Scanner Unit Type 3350, RPCS Printer Unit Type 3350,
Scanner Enhance Type 3350
*Options for Lanier LD425B/LD433B
www.lanier.com
Lanier Five Dedrick Place, West Caldwell, NJ 07006
©2008 Lanier is a registered trademark of Ricoh Americas Corporation. All rights reserved. Windows®and Windows®95/98/ Me/NT4.0/2000/XP are registered trademarks of Microsoft Corporation. Macintosh®, Mac®OS
and AppleTalk®are registered trademarks of Apple Computer, Inc. Adobe®and PostScript®are registered trademarks of Adobe Systems, Inc. RPCS™is a trademark of Ricoh Company, Ltd. All other trademarks are the property
of their respective owners. Print speed may be affected by network, application or PC performance. Specifications and external appearances are subject to change without notice. Products are shown with optional features.
Printed in U.S.A. on recycled paper.
