An extraordinary printer for all your ordinary printing needs.
Regain control over quality, workflow, and cost.
COLOR LASER PRINTER
LP137CN/LP142CN

Make ordinary documents look brilliant
The Lanier LP137CN/LP142CN
lets you produce vibrant color
output and crisp text at true
1200 x 1200 dpi resolution.
Invest in a business asset that will pay dividends for
years to come. Spend your hard earned technology
dollars wisely on the LANIER®LP137CN/LP142CN
Color Laser Printer. Solidly built for lasting value,
this powerful yet easy-to-use network printer combines
speed, reliability, and superior image quality with a
broad range of media support. The Lanier LP137CN/
LP142CN does it all at a low cost of ownership with
security and cost-saving tools that make dynamic color
accessible to every authorized user.
You’re in Command of Productivity
The Lanier LP137CN/LP142CN keeps pace with
the busiest workgroups through its fast speed,
powerful controller, and simplified ease of use.
• Choose from two engines to meet your volume and productivity
requirements: The Lanier LP137CN offers full-color and monochrome
print speeds of 37 pages per minute. Busier workgroups can step up
to the faster 42-ppm Lanier LP142CN.
• Rip through files faster with the high-performance 600MHz CPU
and vast megabytes of memory. Get full-color first prints in as little
as 15 seconds.
• Maximize uptime and ease of use with long-lasting supplies
designed for quick and clean replacement, plus an angled
4-line LCD that displays system and consumable status
at a glance.
You’re in Charge of
Quality and Cost
The Lanier LP137CN/LP142CN
delivers outstanding image quality
at minimal cost.
• Produce vibrant color output and crisp text at true
1200 x 1200 dpi resolution for superior results.
• Optimize output quality for every job with advanced
color calibration, ink simulation, and PANTONE
®
color matching support.
• Drive down printing costs with long-lasting supplies
that yield up to 24,000 pages per color (CMY)
toner bottle*.
• Plus, Lanier’s Economy Color mode reduces the
density of graphic elements while printing text
at full strength to lower printing costs without
impacting legibility.
*Toner yields in accordance with ISO/IEC 19798.

Make ordinary documents look brilliant Lanier LP137CN/LP142CN
You Choose the Media for
Your Message
The Lanier LP137CN/LP142CN offers a versatile,
expandable media supply to handle jobs of any size.
• Install up to three optional 550-Sheet Paper Feed Units for a maximum
2,300-sheet capacity. Keep up to 5 different media sizes/types available
at all times for unmatched flexibility.
• Adjust each paper tray for media sizes up to 8.5” x 14” with support
for thick stocks up to 120 lb. Index. Duplex printing is supported up to
90 lb. Index.
• Use the 100-Sheet Bypass Tray for extra heavy stocks up to 140 lb. Index
and banners up to 8.5” x 49” long.
You’re in Control of Data
Security
The Lanier LP137CN/LP142CN delivers simple
yet advanced device access and data protection.
• Restrict device access, set volume limits, and track printer
usage for up to 500 individual users.
• Use the 80 GB Hard Disk Drive (standard on the Lanier
LP142CN) to enable advanced features like Locked Print,
Stored Print, and Hold Print.
Economy Color mode lowers color printing costs without
sacrificing quality.
The Total Green Office Solution
Lanier continues its long-standing
commitment to developing office solutions
with environmentally friendly and superior
energy- and supply-saving features, without
compromising productivity.
*The LP142CN is Energy Star compliant.
Locked Print* enables secure, password-protected printing.
The LP137CN/LP142CN Control Panel includes a 12-key alphanumeric
keypad to make entering passwords easier.
*Standard on Lanier LP142CN.
Vie supply levels at a glance with the easy-to-use control panel.

COLOR LASER PRINTER
LP137CN/LP142CN
L3205-3
Lanier, Five Dedrick Place, West Caldwell, NJ 07006
©2010 Lanier is a registered trademark of Ricoh Americas Corporation. All other trademarks are the property of
their respective owners. Print speed may be affected by network, application or PC performance. Specifications
and external appearances are subject to change without notice. Products are shown with optional features.
www.lanier.com
Bringing Lanier Value to Your Organization
Lanier technology offers a diverse portfolio of solutions to help your organization stay competitive and move
ahead. Let Lanier show you how to empower your business to improve critical processes, keep information
secure, ensure compliance and promote environmental sustainability while reducing the total cost of ownership.
*Only the LP142CN is Energy Star compliant.
GENERAL SPECIFICATIONS
Lanier LP137CN
Lanier LP142CN Ships with 80 GB HDD and 768 MB RAM
Configuration Desktop
Technology Laser beam scanning &
electrophotographic printing
4 drum tandem method
Resolution 1200 x 1200 dpi (1 bit)
600 x 600 dpi (1 bit)
600 x 600 dpi (2 bit)
Print Speed (LTR) LP137CN: 37-ppm Full-color &
Monochrome
LP142CN: 42-ppm Full-color &
Monochrome
First Print Speed Full-color: 15 seconds
Monochrome: 10 seconds
Warm-up Time 50 seconds or less
Standard Paper 550-Sheet Tray + 100-Sheet
Supply Bypass Tray
Optional Paper 550-Sheet Paper Feed Unit
Supply (Up to 3 may be installed)
Maximum Paper 2,300 sheets
Capacity
Automatic Duplexing* Standard
*Duplex output speeds run approximately 100% of the rated simplex speed for
each paper size.
Output Capacity 500 sheets, face down
Paper Sizes:
Std. & Optional Trays Letter (8.5” x 11”), Legal (8.5” x 14”),
Executive (10.5” x 7.25”), Half Letter
(5.5” x 8.5”), A4 (210 x 297 mm), A5
(148 x 210 mm), A6 (105 x 148 mm),
B5 (148 x 257 mm), B6 (128 x 182 mm),
F (8” x 13”), Foolscap (8.5” x 13”),
Folio (8.25” x 13”),Envelopes: Com10/
Monarch/C6/C5/DL, Custom Size Range:
Width: 3.86” – 8.5” (98 – 216 mm),
Length: 5.83” – 14” (148 – 356 mm)
Bypass Tray Letter (8.5” x 11”), Legal (8.5” x 14”),
Executive (10.5” x 7.25”), Half Letter
(5.5” x 8.5”), A4 (210 x 297 mm), A5
(148 x 210 mm), A6 (105 x 148 mm),
B5 (148 x 257 mm), B6 (128 x 182 mm),
F (8” x 13”), Foolscap (8.5” x 13”),
Folio (8.25” x 13”), Envelopes: Com10/
Monarch/C6/C5/DL, Custom Size Range:
Width: 2.76” – 8.5” (70 – 216 mm),
Length: 5.0” – 49.6”
(127 – 1260 mm)
Paper Weights:
Std. & Optional Trays 14 – 59 lb. Bond/120 lb. Index
(52 – 220 g/m2)
Bypass Tray 14 – 69 lb. Bond/140 lb. Index
(52 – 256 g/m2)
When Duplexing 16 – 44 lb. Bond/90 lb. Index
(60 – 163 g/m2)
Paper Types Plain Paper, Recycled Paper, Middle
(all sources) Thick Paper, Thick Paper, Thin Paper,
Transparency, Letterhead, Labels,
Coated Paper (Glossy/Semi-Gloss/Matte),
Waterproof, Preprinted, Envelopes
Dimensions (WxDxH) 17.48” x 25.91” x 19.29”
(444 x 658 x 490 mm)
Weight 126 lb. (57 kg) Includes standard paper
tray and PCU
Power Requirements 120 – 127V, 60Hz
Power Consumption Operating: LP137CN: 825W or less
LP142CN: 894W or less
Energy Saver: 110W
Sleep: 6W
Safety Regulations UL60950-1, CAN/CSA C22.2 No.60950-1
(c-UL)
EMI FCC Part15 Subpart B, IC ES-003
PRINT CONTROLLER SPECIFICATIONS
CPU 600 MHz
Memory LP137CN: 384 MB RAM standard, 768
MB RAM maximum
LP142CN: 768 MB RAM standard, 768
MB RAM maximum
Hard Disk Drive LP137CN: 80 GB (optional)
LP142CN: 80 GB (standard)
Standard Interfaces 10/100Base-TX Ethernet,
USB 2.0 (Type A & B)
Optional Interfaces IEEE 802.11a/g Wireless LAN, Gigabit
Ethernet, IEEE 1284/ECP Parallel
Fonts PCL: 45 fonts + 13 International fonts,
PostScript 3: 136 fonts
Printer Languages PCL 5c, PCL 6, Adobe PostScript 3 + PDF
Direct Print, PictBridge (optional)
Network Protocols TCP/IP (IPv4, IPv6), AppleTalk, IPX/SPX
(optional)
Supported Windows 8.1, 8, 7, Vista, XP, Server
Environments 2012/2012R2, 2008/2008R2,
2003/2003R2; Mac OS X 10.2 and later;
Novell Netware v 6.5 or later; UNIX
(Lanier Filter) Sun Solaris, HP-UX, SCO
OpenServer, RedHat Linux, IBM AIX; SAP
R/3 v.3.x or later; Citrix MetaFrame
Security Capabilities* Administrator Authentication
(5 levels)
User Authentication (5 types)
SNMP v3 Authentication
128-bit SSL Print Job Data Encryption
500 User Codes
User Lockout/Auto Logout
Locked Print
DataOverwriteSecurity System (DOSS)
(option)
HDD Data Encryption (option)
Address Book & Password Encryption
WPA (Wi-Fi Protect Access)
*Security features may require 80 GB Hard Disk Drive (standard on
LP142CN, optional on LP137CN) and other optional equipment
CONTROLLER OPTIONS
256 MB RAM DIMM (Type G)
512 MB RAM DIMM (Type I) (Std. on LP142CN)
80GB Hard Disk Drive (Type 5000) (Std. on LP142CN)
VM Card (Type O)
IEEE 802.11a/g Wireless LAN (Type L)
Gigabit Ethernet (Type A)
IEEE 1284/ECP Parallel (Type A)
Camera Direct Print Card (Type H)
Data Overwrite Security Unit (Type IJK-E)
SD Card for Netware Printing (Type D)
HARDWARE ACCESSORIES
Paper Feed Unit
(PB1020)
Paper Size Letter, Legal, Executive, Half letter,
A4, A5, A6, B5, B6, F, Foolscap,
Folio, Envelopes: Com10/
Monarch/C6/C5/DL, Custom: width
3.86” – 8.5”, length 5.8” – 14”
Paper Weights 14 – 59 lb. Bond /120 lb. Index
(52 – 220 g/m2)
Capacity 550 sheets; up to 3 units may be added
Dimensions (WxDxH) 17.48” x 23.22” x 5.51”
(444 x 590 x 140mm)
Weight 26.46lb (12Kg)
Tip-resistant Caster
Table (Type C)*
Dimensions (WxDxH) 23.39” x 24.23” x 5.04”
(594 x 615.5 x 128mm )
Weight 21.16lb (9.6Kg)
*Installation requires the assistance of a technician.
CONSUMABLES AND YIELDS
Black Toner Bottle SP C430A 21,000 pages*
Yellow Toner Bottle SP C430A 24,000 pages*
Magenta Toner Bottle SP C430A 24,000 pages*
Cyan Toner Bottle SP C430A 24,000 pages*
Black Photoconductor Unit SP C430 50,000 pages**
Color Photoconductor Unit SP C430 50,000 pages**
Intermediate Transfer Unit SP C430 100,000 pages**
Waste Toner Bottle SP C430 50,000 prints**
Fusing Unit SP C430 120,000 pages**
*Declared yield values in accordance with ISO/IEC 19798. Actual yields may vary
based on images printed and other factors.
**Declared yield based on 5% coverage, 3 pages/job and a 50% color ratio.
Actual yields may vary based on images printed and other factors.
The Lanier LP137CN and Lanier LP142CN ship with
starter toner bottles yielding 3,000 pages @ 5% coverage each. All other
consumables ship at full yield.
For maximum performance and yield, we recommend using genuine
Lanier parts and supplies.
PANTONE®SUPPORT
PANTONE Look-up Tables and Color Palettes are available at
www.lanier.com/downloads.
WARRANTY
The Lanier LP137CN and LP142CN are under warranty against defects for a
period of one year from the date of purchase. Consumables are under warranty
for a period of 90 days from the date of purchase or until depleted, whichever
comes first. Please refer to warranty documents shipped with the product for
more details.
