EPL-FL1524-LED Series
Explosion Proof LED Aluminum Drop Light
Instruction Manual
WARNING
TO AVOIDTHE RISKOF FIRE,EXPLOSION OR ELECTRIC SHOCK, THIS PRODUCT SHOULD BE INSTALLED,
INSPECTEDAND MAINTAINEDBY A QUALIFIED ELECTRICIANONLY, IN ACCORDANCEWITHALL
APPLICABLEELECTRICAL CODES.
TO AVOIDELECTRIC SHOCK:
•BE CERTAIN ELECTRICAL POWER IS OFF BEFORE AND DURING INSTALLATION AND MAINTENANCE.
•PRODUCT MUST BE CONNECTED TO A WIRING SYSTEM WITH AN EQUIPMENT-GROUNDING
CONDUCTOR.
TO AVOID EXPLOSION:
•MAKE SURE THE SUPPLY VOLTAGE IS WITHIN THE VOLTAGE RATING.
•ENSURE THE MARKED T RATING IS LESS THAN THE IGNITION TEMPERATURE OF THE HAZARDOUS
ATMOSPHERE.
•DO NOT OPERATE IN AMBIENT TEMPERATURES ABOVE THOSE INDICATED ON THE PRODUCT
NAMEPLATE.
•DO NOT OPERATE IF THE LENS, CORD, SEALS, HOUSING, RECEPTACLES, ETC. IS CRACKED OR
DAMAGED. IF SO, DISCONTINUE USE AND CONTACT MANUFACTURER FOR REPLACEMENT PARTS.
•ALL FASTENERS SHOULD BE PROPERLY SEATED.
The EPL-FL1524-LED from Larson Electronics is a Hazardous Area LED Work Light that is approved for use in Class
I Divisions 1 & 2 hazardous locations. With a 26 watt LED tube lamp, this hazardous location light provides better
quality light than higher wattage incandescent lights and more light than previous fluorescent lamp equipped models.
This light is suitable for exposure to vapors and dusts and ideal for use in paint spray booth inspections or as general
portable lighting in confined spaces like fuel tanks or grain storage areas.
WARNING:
USER SHOULD BE TRAINED IN THE PROPER USE AND MAINTENANCE OF THIS DEVICE. IF WIRING OR LAMP REPLACEMENT
INSTRUCTIONS ARE NOT FOLLOWED EXACTLY, THE HANDLAMP MAY NOT BE SUITABLE FOR THE HAZARDOUS LOCATION INVOLVED.
WHEN HANDLAMP IS CONNECTED TO A POWER SOURCE IN HAZARDOUS AREA, PLUG AND MATCHING RECEPTACLE MUST BE SUITABLE
FOR HAZARDOUS LOCATION INVOLVED. WHEN HANDLAMP IS CONNECTED TO POWER SOURCES OUTSIDE OF HAZARDOUS AREA,
STANDARD DUTY PLUGS AND RECEPTACLES MAY BE USED.
STANDARD PLUG AND TRANSFORMER MUST ONLY BE CONNECTED TO A RECEPTACLE LOCATED OUTSIDE THE
HAZARDOUS AREA!
IMPROPER USE OF THIS HANDLAMP, ASSOCIATED PLUG, RECEPTACLE, AND CORD CAN LEAD TO SERIOUS INJURIES OR DEATH TO
PERSONNEL.
PERIODIC INSPECTION OF THE HANDLAMP AND CORD IS NECESSARY.
THE CORD MUST BE ROUTINELY CHECKED FOR CUTS, BREAKS, OR ANY SEVERE ABRASIONS, AND IF ANY ARE FOUND, THE CORD MUST
BE REPLACED BEFORE RESUMING USE OF THE HANDLAMP.
THE GLOBE IS MADE OF TEMPERED GLASS. IF THIS GLASS BECOMES SCRATCHED OR CHIPPED IT SHOULD BE REPLACED IMMEDIATELY.
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com 1of 2
MOUNTING
The EPL-FL1524-LED is designed
to be handheld by the user, or hang mounted
using the mount ing hook at the top of the fixture. The fixture can freely swivel on the
hook mount, providing versat ile mounting capabilities. Be sure to hang from
something secure, level, and capable of supporting the load of the lamp.

EPL-FL1524-LED Series
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com 2of 2
POWER
The EPL-FL1524-LED series handlamp is available in a variety of cord options and voltages. Be sure to check the
product label for correct input voltage and/or compatible cord cap and receptacle.
We strongly encourage a licensed electrician install this product,in all locations especially in outdoor areas
where weatherproofing may be required.
Warning: Check product label for correct input voltage!
FOR FLYING LEADS:
Attach supply line wires to the appropriate light fixture wires as shown
in thediagram 
Secure each pair of wires according to the applicable diagram. Utilize a
junction box or similar device and take precautionary steps for
weatherproofing all connections if installed in a location where water may
come in contact with the unit. Ensure the unit is properly grounded and that
wiring is done according to all local and national electrical/building codes.
Standard Cord Cap
This unit may also come pre-wired from factory with the selected cord
cap. Mate the cord cap with a compatible receptacle outputting the correct
voltage. Take precautionary steps for weatherproofing all connections if
installed in a location where water may come in contact with the unit.
All outdoor installations and indoor installations near a wet location require
the use of a GFCI device for safety, according to the National Electrical
Code® (NEC). Ensure the unit is properly grounded.
MAINTENANCE
There are no serviceable parts inside the fixture. However, it is good practice to routinely clean and check the
fixture for proper function.
•Disconnect power running to the lamp and be sure the fixture is cool to the touch.
•Use a non-abrasive glass cleaning solution to clean the lens.
Note: It is not necessary to open the fixture and clean or touch the LED’s.
USE AND CARE
Unauthorized modification may impair the function and/or safety of this device and could affect the life of the equipment.
Always check for damaged or worn out parts before using the device. Store it in a secure place out of the reach of
children when not in use.Inspect for good working condition prior to storage and before re-use.
REPLACEMENT PARTS
The EPL-FL1524-LED is designed to provide years of reliable performance. Should the need for replacement parts arise,
please contact Larson Electronics.
THESE INSTRUCTIONS MAY NOT COVER ALL DETAILS OR VARIATIONS OF THIS PRODUCT FOR YOUR EQUIPMENT OR INSTALLATION REQUIREMENTS.
SHOULD FURTHER INFORMATION NOT COVERED BY THESE INSTRUCTIONS BE REQUIRED, PLEASE CONTACT LARSON ELECTRONICS BY EMAIL AT
SAL[email protected] OR BY PHONE AT 1-877-348-9680 FOR FURTHER ASSISTANCE.
PLEASE VISIT LARSONELECTRONICS.COM FOR WARRANTY AND RETURN INFORMATION.
