Larson Electronics EPL-HB-2X150LED-RT User manual

EPL-HB-2X150LED-RT
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com
1of 2
Class 1 Division 1 Explosion Proof 300 Watt High Bay LED Light
Fixture - Paint Spray Booth Approved
Instruction Manual
This explosion proof light is designed for illumination of industrial locations. It uses the latest in
solid state lighting technology for long life, low maintenance and high efficiency.
The unique design focuses the light where it is needed, giving improved efficiency over a
conventional HID luminaire.
An internal, universal input, power-factor-corrected switch-mode supply allows it to be used from any
nominal 100-277V AC 50/60 Hz power supply without any variation in light output.
WARNING
To avoid the risk of fire, explosion or electric shock, this product should be installed, inspected
and maintained by a qualified electrician only, in accordance with all applicable electrical codes.
To avoid electric shock:
•Be certain electrical power is OFF before and during installation and maintenance.
•Luminaire must be connected to a wiring system with an equipment-grounding conductor.
To avoid explosion:
•Make sure the supply voltage is within the luminaires’ voltage rating.
•Ensure the marked T rating is less than the ignition temperature of the Hazardous
Atmosphere.
•Do not operate in ambient temperatures above those indicated on the luminaire nameplate.
•Do not operate if the lens is cracked or damaged. All fasteners should be properly seated.
For supply connections, use wire rated for at least 110°C
Recommended mounting height is 25-40 feet.
MOUNTING
This fixture offers an adjustable mounting system that allows it to be mounted to any
flat surface including walls and ceilings. Three heavy duty bolts are used to mount the fixture to the
surface through predrilled holes on mount. Hole diameter is .563”. Fixture is heavy - two people and
capable equipment are required for hanging fixture.
Fixture angle can be adjusted by loosening the set screws on either side of mount. Swap outer bolts
to move mount in opposite direction. Keep center bolt in place! Otherwise fixture will free from mount.
Use appropriate wiring methods for the area following all NEC, local, and state electrical codes.
Conduit attaches to the junction box on the back for wiring.
ADJUSTMENT BOLTs
CENTER BOLT
DO NOT REMOVE COMPLETELY
WHILE MOUNTED TO SURFACE

EPL-HB-2X150LED-RT
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com
2of 2
WIRING (see attached wiring diagram)
This unit comes preconfigured in selected Voltage and Beam Spread. Wire light via junction box on
the back to the correct voltage. Follow applicable local and/or National Electrical Code for the
hazardous area. Voltage: 100-277 Volts AC, 50/60Hz or 11-25 Volts AC/DC based on model.
MAINTENANCE
Caution: To avoid personal injury, disconnect power to the light and allow the unit to cool
down before performing maintenance.
Warning: No user serviceable parts inside of fixture. Risk of electric shock. Removal of the lens
will void the warranty.
1. Perform visual, mechanical and electrical inspections on a regular basis. We recommend
routine checks to be made on a yearly basis. Frequency of use and environment should
determine this. It is recommended to follow an Electrical Preventive Maintenance Program
as described in NFPA 70B: Recommended practice for Electrical Equipment.
2. The lens should be cleaned periodically as needed to ensure continued photometric
performance. Clean the lens with a damp, non-abrasive, lint-free cloth. If not sufficient, use
mild soap or a liquid cleaner.
3. Inspect the cooking fins on the luminaire to ensure that they are free of any obstructions
or contamination (i.e. excessive dust build-up). Clean with a non-abrasive cloth if
needed.
4. Do not operate if the lens is cracked or damaged. All fasteners should be properly seated.
WARRANTY
Should further information not covered by these instructions be required, please contact Larson Electronics at
1-800-369-6671 or [e-mail] for further assistance.
Please visit LarsonElectronics.com for Warranty and Return information.
WARNING: CHECK NAMEPLATE
FOR PROPER VOLTAGE. DAMAGE
FROM IMPROPER VOLTAGE WILL
VOID WARRANTY.
