Larson Electronics TPM-2XWP60E-10C User manual

TPM-2XWP60E-10C
120W LED Light with Telescoping Pole Mount
Adjustable from 3' to 8.5' - 10,800 Lumens - 120-277VAC
Instruction Manual
Thank you for your purchase of the Larson Electronics TPM-2XWP60E-10C 120W LED Light.
IMPORTANT
READ CAREFULLY BEFORE INSTALLING THIS FIXTURE. SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE. THE LEDWP-600E MUST BE WIRED IN ACCORDANCE WITH NATIONAL ELECTRICAL CODE AND
ALL APPLICABLE LOCAL CODES. PROPER GROUNDING IS REQUIRED FOR SAFETY.
WE STRONGLY ENCOURAGE ONLY A LICENSED ELECTRICIAN INSTALL, OPERATE AND MAINTAIN THIS
PRODUCT. IF YOU ARE NOT QUALIFIED OR UNFAMILIAR WITH ANY ASPECT OF THIS INSTRUCTION SHEET,
CONSULT AN ELECTRICIAN. THERE ARE NO SERVICEABLE PARTS INSIDE.
WARNING: MAKE SURE POWER IS TURNED OFF BEFORE STARTING THE
INSTALLATION OR PERFORMING ANY MAINTENANCE.
RISK OF FIRE/ELECTRIC SHOCK –DISCONNECT POWER AT BREAKER BEFORE INSTALLING OR SERVICING.
RISK OF PERSONAL INJURY –FIXTURE MAY BECOME UNSTABLE OR DAMAGED IF NOT INSTALLED PROPERLY.
RISK OF BURN –ALLOW FIXTURE TO COOL BEFORE SERVICING.
The TPM-2XWP60E-10C from Larson Electronics is an Industrial LED Light with Telescoping Pole that offers high light
output from a compact form factor, and is designed to provide a more durable and long lived alternative to halogen and
metal halide units. This powerful, telescoping LED light produces 10,800 lumens, operates on 120 to 277V AC, features a
telescoping pole that is adjustable from 3 to 8.5 feet, and includes a mounting plate with four predrilled holes for easy
mounting on flat surfaces.
Mounting and Installation
The TPM-2XWP60E-10C features a telescoping pole that is adjustable from 3 to 8.5
feet. The telescoping pole features a mounting plate that has four predrilled holes for
easy mounting to flat surfaces. This pole features a pneumatic braking system that
prevents unexpected or sudden collapse of the pole. If the pole is loaded with a pair of
heavy fixtures for instance and the operator inadvertently releases the locking tabs, the
pole will simple ease down gently rather than suddenly collapse. Simply mount this
fixture to any flat surface capable of supporting the load via the four mounting holes in
the mount plate at the base of the pole. The light also comes with optional hoods that
can be mounted over the top of the light via holes in the back of the fixture housing.
Screws are provided for this.
Wiring
This unit comes pre-wired from factory with the selected cord cap. Simply mate this cord cap with a compatible receptacle
outputting the correct voltage. Take precautionary steps for weatherproofing all connections if installed in a location where
water may come in contact with the unit. All outdoor installations and indoor installations near a wet location require the use
of a GFCI device for safety, according to the National Electrical Code® (NEC). Ensure the unit is properly grounded. We
also offer a flying leads option, for those who wish to hardwire or supply their own cord cap.
We strongly encourage a licensed electrician install this product, in all locations
especially in outdoor areas where weatherproofing may be required.
Warning: Check product label for correct input voltage!
Attach supply line wires to the appropriate light fixture wires as shown in the diagram 
Secure each pair of wires according to the diagram. Utilize a junction box or similar
device and take precautionary steps for weatherproofing all connections if installed in a
location where water may come in contact with the unit. Ensure the unit is properly
grounded and that wiring is done according to all local and national electrical/building
codes.
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com 1of 2

TPM-2XWP60E-10C
MAINTENANCE
There are no serviceable parts inside the fixture. However, it is good practice to routinely clean and check the
fixture for proper function.
•Disconnect power running to the lamp and be sure the fixture is cool to the touch.
•Use a non-abrasive glass cleaning solution to clean the lens.
Note: It is not necessary to open the fixture and clean or touch the LED’s.
USE AND CARE
Unauthorized modification may impair the function and/or safety of this device and could affect the life of the equipment.
Always check for damaged or worn out parts before using the device. Store it in a secure place out of the reach of
children when not in use.Inspect for good working condition prior to storage and before re-use.
REPLACEMENT PARTS
The TPM-2XWP60E-10C is designed to provide years of reliable performance. Should the need for replacement parts
arise, please contact Larson Electronics.
THESE INSTRUCTIONS MAY NOT COVER ALL DETAILS OR VARIATIONS OF THIS PRODUCT FOR YOUR EQUIPMENT OR INSTALLATION REQUIREMENTS.
SHOULD FURTHER INFORMATION NOT COVERED BY THESE INSTRUCTIONS BE REQUIRED, PLEASE CONTACT LARSON ELECTRONICS BY EMAIL AT
[e-mail] OR BY PHONE AT 1-800-369-6671 FOR FURTHER ASSISTANCE.
PLEASE VISIT LARSONELECTRONICS.COM FOR WARRANTY AND RETURN INFORMATION.
