Larson Electronics EPL-FL26-LED Series User manual

MAINTENANCE:
WARNING: It is very important that only qualied per-
sonnel perform maintenance and repair operaons in a
NON-HAZARDOUS area. The integrity of the component
assembly and ame-path must be maintained in order
to provide adequate protecon for personnel using this
light. Comply with all NEC Rules and Regulaons when
performing maintenance operaons. Failure to comply
with these could result in an explosion, electrical shock,
or personal injury.
WARNING: When performing maintenance operaons
disconnect power. Failure to do so could result in electri-
cal shock.
Make a thorough visual inspecon of the work light for any
chips, cracks, or burns within the glass, aluminum handle,
and cage. Check the enre length of the cord for any frays
or visible wires that could aect the performance of the
light. Check that all the rubber bumpers are integral with
the aluminum. If there are any frays in the cord, cracks in
the glass or disturbances in the aluminum outside of nor-
mal wear, remove the light from service immediately and
contact Larson Electronics for replacement.
CAUTION: Clean external parts of work light only; inter-
nal parts do not require cleaning. Applying solvent could
result in damage to the electrical equipment.
The EPL-FL26-LED can be cleaned applying Simple Green®
or an equivalent cleanser and wiping any dust or grease off
with a rag. After cleaning process is performed, allow
adequate time for light to completely dry before placing in
operation.
INTRODUCTION
This document covers the operation, maintenance, and
re-lamping procedures for an EPL-FL26-LED hazardous
locations work light. This light is suitable for the
following hazardous locations only:
Class I, Divisions 1 & 2, Groups C & D
Class II, Divisions 1 & 2, Groups E, F, and G
Class III, Divisions 1 & 2
Refer to the National Electric Code (NEC) NFPA 70 for
more information on hazardous locations.
OPERATIONS AND USE
WARNING:
FOR FLYING LEADS:
This light is not supplied with a plug. If the light is used
in a hazardous location environment, it must be
terminated with a suitable plug or hard wired into an
appropriate junction box rated for the environment it
is to be used in. Comply with all NEC Rules and Regu-
lations when terminating light with a plug. Failure to
comply with this could result in an explosion, electri-cal
shock, or personal injury.
CAUTION:
Follow manufacturer’s instructions for attaching plug
to light ensuring all wires are properly terminated and
grounded.
CAUTION:
When hanging the light using the hook, use an ap-
propriate entity capable of holding at least 6 lbs. (2.72
kg).
EPL-FL26-LED Series
Explosion Proof Compact LED Handlamp
Instruction Manual
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com 1 of 2
PLUG OPERATION (for units pre-wired with explosion proof cord cap)
Electrical connection between plug and compatible receptacle is accomplished after plug fully inserts into receptacle and is rotated
clockwise.
1. Lift receptacle door and locate polarization on mating plug pin and receptacle face. Insert plug straight all the
way into receptacle until it cannot go further.
2. Rotate plug clockwise limit (37º), this closes internal contacts and completes circuit. This also mechanically locks
plug into receptacle so it cannot be pulled out.
3. To remove plug, push plug inward and turn to counterclockwise, pull plug straight out.

Relamping Instructions for EPL-FL26-LED
FIG. 1 EXPLODED VIEW EPL-FL26-LED WORK LIGHT
WARNING: When relamping work light, disconnect
power. Failure to do so could result in electrical
shock.
1. Loosen strain relief from handle end of light and
slide down the cord.
2. Loosen and remove the four brass Allen Head
screws using the appropriate tool.
3. Slide handle cap doughnut off the end of the
handle to gain access to the handle cap. With a
slow rocking motion, slide the handle cap and
lamp-head assembly from the handle and cage
casing assembly.
4. Remove the shock from the end of the lamp and
set aside. Grasping lamp holder in one hand and
lamp in other hand, remove the lamp with a slow
rocking motion and discard.
5. Replace lamp with same type and rating lamp or
equivalent. Slide shock on the end of the lamp.
Slide lamp into lamp holder assembly until a click
is heard.
6. Make a visual inspection of the “O” Ring. If “O”
Ring has any sign of wear contact Larson
Electronics for replacement part. Check the black
shrink-wrap fitting for any signs of damage.
7. Slide the lamp assembly back into handle and
cage assembly, aligning the four screw holds.
Tighten brass screws and torque to 35lbf-ft
(47.5N-m). Slide handle cap doughnut onto handle
cap, align holes with screws. Slide strain-relief into
place and tighten to a snug fit.
8. Test light in a non-hazardous location before using
in a hazardous location to ensure proper opera-
tion of lamp.
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com 2 of 2
EPL-FL26-LED Series
THESE INSTRUCTIONS MAY NOT COVER ALL DETAILS OR VARIATIONS OF THIS PRODUCT FOR YOUR EQUIPMENT OR INSTALLATION REQUIREMENTS.
SHOULD FURTHER INFORMATION NOT COVERED BY THESE INSTRUCTIONS BE REQUIRED, PLEASE CONTACT LARSON ELECTRONICS BY EMAIL AT
SAL[email protected] OR BY PHONE AT 1-877-348-9680 FOR FURTHER ASSISTANCE.
PLEASE VISIT LARSONELECTRONICS.COM FOR WARRANTY AND RETURN INFORMATION.
