Larson Electronics 2000-M Manual

IMPORTANT SAFETY INFORMATION
This symbol is to alert you to important operating or servicing
instructions that appear in your instructions. Always follow
basic safety precautions when using this product to reduce
the risk of injury, fire or electric shock.
This light is for off road and utility use only. It is not de-
signed for road use as a driving light.
The RadioRay® complies with Part. 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
light and remote may not cause harmful interference, and (2)
this light and remote must accept any interference received,
including interference that may cause undesired operation.
 FCC RULE Part. 15.21 - Changes or modifications made by
the user not expressly approved by Golight, Inc. for compli-
ance could void the user’s authority to operate the equip-
ment.
For safe and efficient operation of your Golight® RadioRay®,
observe these guidelines:
Using your RadioRay® in icing conditions could damage the gear
motors.
The remote must be kept clean and dry to avoid damage to the
internal circuitry.
Your Golight® RadioRay® is a radio transmitter and receiver
operating at 433MHz. Whenever the light is on, the internally
mounted antenna sends out and receives radio frequency (RF)
energy.
• Modern electronic equipment, i.e. Personal medical devices
such as pacemakers, hearing aids, etc., are shielded from RF
energy. However, RF energy may affect some electronic equip-
ment.
• Vehicle electronic systems may be affected by RF energy.
Check with your vehicle manufacturer representative to be
sure that your RadioRay® will not affect the electronic system
of your vehicle.
HALOGEN BULB REPLACEMENT / PARTS / ACCESSORIES
The Golight® RadioRay® utilizes a Philips® H-9 bulb, which may
be purchased through Golight, Inc. along with other parts and
accessories. Visit our web store at: https://www.larsonelectronics.com/ or
contact us at [phone].
THREE YEAR LIMITED WARRANTY
Golight, Inc. warrants the RadioRay® against any deemed defects
that are due to workmanship for parts or faulty materials, except
halogen lamps, for three years from the date of the original
purchase. This warranty to the RadioRay® does not cover damage
resulting from unreasonable use or misuse, unreasonable
maintenance or loss, or labor costs.
Mounting the light upside down will void the warranty.
Warranty information must be filled out within 30 days of purchase
at: https://www.larsonelectronics.com, for warranty
protection.
Any consequential damages to person or property are excluded
from this warranty. Some states do not allow the exclusion and
limitation of incidental or consequential damages, therefore the
above limitations or exclusions may not apply to you. This war-
ranty gives you specific legal rights and you may also have other
rights.
Larson Electronics LLC
[phone]
9419 US-175, Kemp, TX 75143
https://www.larsonelectronics.com
MODEL NUMBERS: 2000-M, 2051-M, 9000-M, 9051-M
Instruction Guide
Congratulations
You are now the owner of one of the finest remote control
searchlights available today. Thank you for letting Golight®
assist you in your lighting application needs. We’re proud
of our products and the technology that we’ve developed to
ensure our customers the most durable, versatile and powerful
searchlights in the lighting industry.
Please read these instructions before using your new Golight®
Radioray®.

The Golight® RadioRay® Model 2000-M, 2051-M, 9000-M,
9051-M
are designed to be permanently attached to a vehicle.
The 2-Speed Searchlight with Directional Flexibility is controlled by
a wireless remote, which gives the operator a full 370°
horizontal rotation and a 135° vertical tilt with fingertip control.
The RadioRay® provides superior light penetration with Cr5
PentaBeam™ technology in a halogen configuration or with
The RadioRay® Includes:
•RadioRay® Searchlight
• Wireless Remote Control
• 2 A23 12V Batteries
• Permanent Mounting Gasket
• Rockguard (not Available with LED units)
MOUNTING INSTRUCTIONS
Temporary (Suction):
1. Always clean mounting surface with a clean cloth.
2. Remove light from permanent mount shoe by depressing
spring-loaded lock and sliding light out.
3. Place suction base on clean, dry surface and move side lever
into the locked position.
WARNING: Check the suction cup frequently to ensure
that suction strength is maintained. Temperature
variations, rough terrain, grease and dirt affect the length
of time that the suction cup will remain in place. Suction
mounting is not recommended for road use.
Permanent:
1. On clean, dry surface, place gasket and shoe in desired
location. Using 3/16” screws, attach shoe to vehicle.
2. Slip the RadioRay® into the shoe. Verify that the spring lock
secures the RadioRay® into the shoe. An optional magnetic
mounting shoe is available (see web store).
Magnetic Mount:
1. Select the best location on your vehicle for the magnetic
mount. Make sure the metal area under the magnetic base
is flat and clean to ensure a strong bond.
2. Route the power cord into the vehicle through a door frame
and connect to 12V power outlet.
PROGRAMMABLE REMOTE INSTRUCTIONS
The Golight® RadioRay® is controlled with a programmable remote
with 2187 different channels. This feature allows you the freedom
to change the channel selection, and the receiver relearns the new
selection.
PROGRAMMING THE TRANSMITTER.
This light has been pre-programmed at the factory, and it is not
necessary to re-program the transmitter, unless you experience
outside interference.
1. IMPORTANT: Disconnect power by removing fuse or
disconnecting vehicle battery.
2. Remove battery cover from remote control.
3. Set the 7 dip switches to a selection of your choice. There are 3
positions on each; positive, negative and neutral. Use a small
screwdriver and select a position for each dip switch. *Please
note that the orientation of the +/– switch positions may vary
among different models of wireless remote controls.
4. Insert both A23 12V batteries with the +/– in the same direction.
Be sure batteries have adequate charge.
5. Replace battery cover.
a. Depress the on/off button and hold it down. Red LED
will light.
b. While holding the on/off button down, reinstall the
power (replace fuse or connect vehicle battery).
c. Keep your finger on the on/off button for 5-6 seconds.
and then release. The light should now be programmed.
OPERATION OF GOLIGHT® RADIORAY®
1. Using the remote control, turn on the light by depressing the on/
off button.
2. With the 4-way arrows on the remote control, rotate your light
to the desired location. Depending upon conditions, the wireless
remote may be used up to 80 feet from the RadioRay®.
3. The speed of the light rotation can be controlled by depressing
the tortoise/hare button one time and by depressing it again
to restore the original speed.
4. The spotlight should not be turned on when the snap on lens
cover (rockguard) is attached. (Not applicapble for LED)
BATTERY INSTALLATION AND DISPOSAL
• Remove Battery Cover: remove the phillips head screw
securing the battery cover then remove the cover. With the
battery compartment now exposed, insert batteries according
to correct polarity. Remove the batteries by gripping the
positive end of each battery and lifting.
For information regarding the proper disposal/recycling of the
batteries contact Larson Electronics at [phone]
Use only 12v-A23 batteries in the Golight remote control
USAGE:
» This light is intended for off-road and utility use only
» This light is intended to be mounted outside the vehicle while
in use
» This light may only be disassembled and repaired by an
authorized representative
MISUSE:
» This light is not approved for road or highway use
» This light is not approved for underwater use
» This light is not approved for inverted mounting
» This light is not approved for use inside a vehicle or enclosure
and power should be removed prior to placing the light in such
circumstance
» This light may be damaged if operated in icing conditions
» This light may only be dismantled by an authorized Golight
representative
» Any violation of the above referenced misuses will be
considered grounds for warranty refusal
The magnetic mount Golight® RadioRay® should be removed from
vehicle’s exterior while traveling at excessive speeds and in strong
wind conditions.
