Larson Electronics The LE-9 Series User manual

LE-9XXX Series
Remote Control LED Spotlight
Instruction Manual
IMPORTANT
READ CAREFULLY BEFORE INSTALLING THIS FIXTURE. SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE. THE SPOTLIGHT MUST BE WIRED IN ACCORDANCE WITH NATIONAL ELECTRICAL CODE AND
ALL APPLICABLE LOCAL CODES. PROPER GROUNDING IS REQUIRED FOR SAFETY.
WE STRONGLY ENCOURAGE ONLY A LICENSED ELECTRICIAN INSTALL, OPERATE AND MAINTAIN THIS
PRODUCT. IF YOU ARE NOT QUALIFIED OR UNFAMILIAR WITH ANY ASPECT OF THIS INSTRUCTION SHEET,
CONSULT AN ELECTRICIAN. THERE ARE NO SERVICEABLE PARTS INSIDE.
WARNING: MAKE SURE POWER IS TURNED OFF BEFORE STARTING THE
INSTALLATION OR PERFORMING ANY MAINTENANCE.
RISK OF FIRE/ELECTRIC SHOCK –DISCONNECT POWER AT BREAKER BEFORE INSTALLING OR SERVICING.
RISK OF PERSONAL INJURY –FIXTURE MAY BECOME UNSTABLE OR DAMAGED IF NOT INSTALLED PROPERLY.
RISK OF BURN –ALLOW FIXTURE TO COOL BEFORE SERVICING.
The LE-9XXX from Larson Electronics is a 48 Watt
Motorized LED Spotlight that operates with a handheld
wireless remote control. This particular model is available in
black and is magnetically mounted. It outputs a spot beam
with an effective working length of 1,312 feet and produces
4,320 lumens of bright, white light.
POWER
Check product label for correct input voltage!
The LE-9XXX is equipped with a Deutsch connector and a
16` C-16-CC-CP coil cord for easy connection to cigarette
plugs. Simply connect the coil cord via the Deutsch
connector, and plug the cigarette cord into a compatible
outlet outputting the correct voltage, as identified on the
product label.
MOUNTING
The light can be either magnetically mounted or
permanently mounted depending on the user's desired
application and mounting surface. Spotlight can be
mounted permanently by using the 4 mounting holes in the
base of the unit. Mounting can be achieved on any flat
surface that is capable of supporting the load of the light,
and which the light can be screwed or bolted to. Mounting
hardware is not provided. Alternately, the light can also be
temporarily mounted using the magnets at the base of the
unit. This will work on any magnetized, flat surface that is
capable of supporting the light.
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com 1of 2

Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com 2of 2
OPERATION
•Switch: Press the button, turn on/turn off spotlight.
•SOS Distress Signal Button: Press the button, the light will flash
as the SOS signal, 3 long flash-3 short flash.
•Upward: Press the button, the light will turn up. Keep pressing
the button, the light will keep rotating upward (110 degrees).
•Downward: Press the button, the light will turn down. Keep
pressing the button, the light will keep rotating downward (110
degrees).
•Left Button: Press the button, the light will turn left. Keep
pressing the button, the light will keep rotating left (360 degrees).
•Right Button: Press the button, the light will turns right. Keep
pressing the button, the light will keep rotating right (360
degrees).
PAIRING REMOTE
Remote should work without coding or pairing, but we do recommend coding to avoid disruption from other remotes and
devices.
HOW TO PAIR:
•Keep the light connected to power source, press On/Off button on the remote to turn the light ON.
•Press and hold the On/Off button for at least 6 seconds, until the light flashes 3 times (long-flash), pairing succeeded.
•lf it flashes 3 times short-flash instead of long-flash in step 2, this means the remote was paired to this light
previously, and you just unpaired them. To pair them again please repeat step 1 and 2.
•One light can be paired to 2 remotes at most. When a third remote is paired to the light, the first paired remote will be
removed immediately.
HOW TO UNPAIR:
•Connect the light to a power source, keep it OFF.
•Use any remotes, no matter if it was paired previously or not, press and hold the On/Off button for at least 6 seconds,
until the light flashes 3 times (short-flash), un-pairing succeeded.
MAINTENANCE
There are no serviceable parts inside the fixture. However, it is good practice to routinely clean and check the
fixture for proper function.
•Disconnect power running to the lamp and be sure the fixture is cool to the touch.
•Use a non-abrasive glass cleaning solution to clean the lens.
Note: It is not necessary to open the fixture and clean or touch the LED’s.
USE AND CARE
Unauthorized modification may impair the function and/or safety of this device and could affect the life of the equipment.
Always check for damaged or worn out parts before using the device. Store it in a secure place out of the reach of
children when not in use.Inspect for good working condition prior to storage and before re-use.
REPLACEMENT PARTS
This spotlight is designed to provide years of reliable performance. Should the need for replacement parts arise, please
contact Larson Electronics.
THESE INSTRUCTIONS MAY NOT COVER ALL DETAILS OR VARIATIONS OF THIS PRODUCT FOR YOUR EQUIPMENT OR INSTALLATION REQUIREMENTS.
SHOULD FURTHER INFORMATION NOT COVERED BY THESE INSTRUCTIONS BE REQUIRED, PLEASE CONTACT LARSON ELECTRONICS BY EMAIL AT
SAL[email protected] OR BY PHONE AT 1-877-348-9680 FOR FURTHER ASSISTANCE.
PLEASE VISIT LARSONELECTRONICS.COM FOR WARRANTY AND RETURN INFORMATION.
LE-9XXX Series
