Larson Electronics GL-2000-24 Manual

GL-2000-24
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com
1of 2
Golight Radioray GL-2000-24 Wireless Remote Control Spotlight
Handheld Remote - Permanent Mount
Instruction Guide
The GL-2000-24 Golight Radioray is designed for use in all weather conditions
and produces 1,300 lumens of intense light output. These units feature remote
control operation that allows users to rotate the light 370 degrees with a hard stop and to
adjust vertical tilt through 135 degrees. Remote operation is provided by a wireless
hand held remote control. The hand held remote measures 3 inches long by 2 inches
wide by 3/8 inch thick.
MOUNTING INSTRUCTIONS
Light Unit Mount
Determine the location for the light on your vehicle or boat. The light is permanently mounted with
four screws and a rubber gasket, which are included with the light.
Note: Once power is applied to the system the light will pan and tilt prior to illumination. Each
spotlight needs to be wired on a single dedicated circuit and the power fused at 5 amps. With the
power connected, your light is ready for operation.
POWER SUPPLY
On this particular model, the light ends in a 1 foot pigtail with stripped and tinned leads. The operator is
responsible for providing the wiring from the battery and/or fuse box to the light. 16 AWG is recommended.
OPERATION OF SPOTLIGHT
1. Using the remote control, turn on the light by depressing the on/ off button.
2. With the arrows on the wireless control, rotate your light to the desired location.
3. The speed of the light rotation can be controlled by depressing the fast/slow button one time
and by depressing it again to restore the original speed.
BATTERY INSTALLATION AND REMOVAL FOR TRANSMITTER Remove battery cover: for
wireless hand-held transmitter, remove phillips head screw to remove cover. With battery
compartment now exposed, insert GP 23A 12V batteries according to the correct polarity or gently
remove batteries by grabbing the positive end and lifting up.
PROGRAMMABLE REMOTE INSTRUCTIONS
The Light is controlled with a programmable remote with 2187 different channels. This feature
allows you the freedom to change the channel selection, and the receiver re-learns the new
selection. This light has been pre-programmed at the factory, and it is not necessary to re-program
the transmitter, unless you experience outside interference.
To program transmitter:
1. IMPORTANT Disconnect power.
2. Remove battery cover from remote control.
3. Set the 7 dip switches to a selection of your choice. There are 3 positions on each; positive,
negative and neutral. Use a small screwdriver and select a position for each dip switch.
*Please note that the orientation of the +/- switch positions may vary among different models
of wireless remote controls.
4. Insert both GP 23A 12V batteries. Be sure batteries have adequate charge.

GL-2000-24
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com
2of 2
5. Replace battery cover.
a. Depress the on/off button and hold it down. Red LED will light.
b. While holding the on/off button down, reinstall the power (replace fuse or connect
vehicle battery).
c. Keep on/off button depressed for 5-6 seconds, and then release. The light should now
be programmed.
USAGE:
This light is intended for off-road and utility use only
This light is intended to be mounted outside the vehicle while in use
This light may only be disassembled and repaired by an authorized representative
MISUSE:
This light is not approved for road or highway use
This light is not approved for underwater use
This light is not approved for inverted mounting
This light is not approved for use inside a vehicle or enclosure and power should be
disconnected prior to placing the light in such circumstance
This light may be damaged if operated in icing conditions
This light may only be dismantled by an authorized representative
Any violation of the above referenced misuses will be considered grounds for warranty
refusal
Lens installation:
Press the flood lens up against your Golight until it clicks in place. Press all edges
to ensure the lens is securely attached flush with the Golight lens.
To remove the flood lens, pull two edges until the lens releases from the Golight. Store in a safe
place.
Note: Ensure the lens lines up properly. Do not force the lens as this could cause damage to the
lens and/or Golight
If the lens becomes dirty, wash with a mild soap and water.
IMPORTANT SAFETY INFORMATION
This symbol is to alert you to important operating or servicing instructions that appear in your instructions. Always follow
basic safety precautions when using this product to reduce the risk of injury, fire or electric shock.
This light is for off road and utility use only. It is not designed for road use as a driving light.
The GL-30204 complies with Part. 15.105 of the FCC Rules. This equipment has been tested and found to comply with the limits for
a Class B digital device. These limits are designed to provide reasonable protection against harmful interference in a residential
installation.
FCC RULE Part. 15.21 - Changes or modifications made by the user not expressly approved by Larson Electronics, LLC for
compliance could void the user’s authority to operate the equipment.
THESE INSTRUCTIONS MAY NOT COVER ALL DETAILS OR VARIATIONS OF THIS PRODUCT FOR YOUR EQUIPMENT OR INSTALLATION REQUIREMENTS. SHOULD FURTHER
INFORMATION NOT COVERED BY THESE INSTRUCTIONS BE REQUIRED, PLEASE CONTACT LARSON ELECTRONICS BY EMAIL AT [email protected] OR BY PHONE
AT 1-800-369-6671 FOR FURTHER ASSISTANCE.
PLEASE VISIT LARSONELECTRONICS.COM FOR WARRANTY AND RETURN INFORMATION.
