Larson Electronics GL5150-12IR Manual

Wireless Remote Controlled Infrared
Military Spotlight –Magnet Base
INSTRUCTION GUIDE
Part# GL5150-12IR
Congratulations
You are now the owner of one of the finest remote control searchlights available today. Thank you for
letting Larson Electronics assist you in your lighting application needs. We're proud of our products and
the technology that we've developed to ensure our customers the most durable, versatile and powerful
searchlights in the lighting industry.
Please read these instructions before using your new Remote Control Spotlight from Larson Electronics.
MODEL SHOWN MAY VARY

The GL5150-12IR is a Portable Searchlight designed
to be permanently or temporarily attached to a
vehicle for your specific use. The 2-Speed
Searchlight with Directional Flexibility is controlled by
a wireless remote, which gives the operator a full
370° horizontal rotation and a 135° vertical tilt with
fingertip control. The GL5150-12IR provides superior
light penetration with state of the art Infrared
technology.
GL5150-12IR Searchlight
Wireless Remote Control
Mounting Shoe (Press spring lock to release and
remove light.)
MOUNTING INSTRUCTIONS
Temporary (Suction):
1. Always clean mounting surface with a clean
cloth.
2. Remove light from permanent mount shoe by
depressing spring-loaded lock and sliding light
out.
3. Place suction base on clean, dry surface and
move side lever into the locked position.
WARNING: Check the suction cup frequently to
ensure that suction strength is maintained.
Temperature variations, rough terrain, grease and
dirt affect the length of time that the suction cup will
remain in place. Suction mounting is not
recommended for road use.
Magnetic Mount:
1. Select the best location on your vehicle for
the magnetic mount. Make sure the metal
area under the magnetic base is flat and
clean to ensure a strong bond.
2. Route the power cord into the vehicle
through a door frame and connect to 12V
power outlet.
The magnetic mount Golight should be removed from
vehicle’s exterior while traveling at excessive speeds
and in strong wind conditions.
Route the power cord into the vehicle through a
door frame and connect to 12V power outlet.
PROGRAMMABLE REMOTE INSTRUCTIONS
The GL5150-12IR is controlled with a programmable
remote with 2187 different channels. This feature
allows you the freedom to change the channel
selection, and the receiver relearns the new
selection.
PROGRAMMING THE TRANSMITTER.
This light has been pre-programmed at the factory, it
is not necessary to re-program the transmitter, but is
recommended.
PROGRAMMABLE REMOTE INSTRUCTIONS
The GL5150-12IR Light is controlled with a
programmable remote with 2187 different channels.
This feature allows you the freedom to change the
channel selection, and the receiver re- learns the
new selection. This light has been pre-programmed
at the factory, and it is not necessary to re-program
the transmitter, unless you experience outside
interference. To program transmitter:
1.IMPORTANT Disconnect power.
2.Remove battery cover from remote control.
3.Set the 7 dip switches to a selection of your
choice. There are 3 positions on each; positive,
negative and neutral. Use a small screwdriver and
select a position for each dip switch. *Please note
that the orientation of the +/- switch positions may
vary among different models of wireless remote
controls.
4.Insert both GP 23A 12V batteries. Be sure
batteries have adequate charge.
5.Replace battery cover.
a. Depress the on/off button and hold it down.
Red LED will light.
b. While holding the on/off button down,
reinstall the power (replace fuse or connect
vehicle battery).
c. Keep on/off button depressed for 5-6
seconds, and then release. The light should
now be programmed.
BATTERY INSTALLATION AND REMOVAL FOR
TRANSMITTER
Remove Battery Cover: remove the Phillips head
screw securing the battery cover then remove the
cover. With the battery compartment now exposed,
insert batteries according to correct polarity.
Remove the batteries by gripping the positive end of
each battery and lifting.
Use only 12v-A23 batteries in the Golight remote
control

OPERATION OF GL5150-12IR
1.Place your light into the mounting shoe or attach
to the outside of your vehicle (see mounting
instructions).
2.Plug light into your vehicle’s cigarette lighter outlet
or 12 Volt direct battery hookup.
3.Using the remote control, turn on the light by
depressing the on/off button.
4.With the 4-way arrows on the remote control,
rotate your light to the desired location.
Depending upon conditions, the wireless remote
may be used up to 80 feet from the GL5150-12IR.
5.The speed of the light rotation can be controlled
by depressing the tortoise/hare button one time
and by depressing it again to restore the original
speed.
6.Unplug and remove light from vehicle. Store the
light and remote control in optional carrying case
when not in use to extend the life of your GL5150-
12IR.
USAGE:
» This light is intended for off-road and utility use only
» This light is intended to be mounted outside the
vehicle while in use
» This light may only be disassembled and repaired
by an authorized representative
MISUSE:
» This light is not approved for road or highway use
» This light is not approved for underwater use
» This light is not approved for inverted mounting
» This light is not approved for use inside a vehicle or
enclosure and power should be disconnected prior to
placing the light in such circumstance
» This light may be damaged if operated in icing
conditions
» This light may only be dismantled by an authorized
Larson Electronics representative.
» Any violation of the above referenced misuses
will be considered grounds for warranty refusal
IMPORTANT SAFETY INFORMATION
This symbol is to alert you to important operating
or servicing instructions that appear in your
instructions. Always follow basic safety
precautions when using this product to reduce the
risk of injury, fire or electric shock.
This light is for off road and utility use only. It
is not designed for road use as a driving light.
The GL5150-12IR complies with Part. 15.105 of
the FCC Rules. This equipment has been tested
and found to comply with the limits for a Class B
digital device. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses, and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is encouraged
to try to correct the interference by one or more
of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment
and receiver.
Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced
radio/TV technician for help.
FCC RULE Part. 15.21 - Changes or
modifications made by the user not expressly
approved by Larson Electronics, LLC. for
compliance could void the user’s authority to
operate the equipment.
PARTS / ACCESSORIES
Contact manufacturer for GL5150-12IR parts and
accessories.
Should further information not covered by these
instructions be required, please contact Larson
Electronics at 1-800-369-6671 or
[e-mail] for further assistance.
Please visit LarsonElectronics.com for Warranty
and Return information.
