Launch J-Box 3 User manual

User Guide

Important Notes
J-Box 3 interfaces have been carefully designed and tested to comply with OBDII
protocols. However, some vehicle models are not in full compliance with these
protocols for various reasons. In addition, the computer control systems or
sensors on any given vehicle may be malfunctioning or out of specification.
While Launch’s testing and the experiences of thousands of J-Box 3 users have
shown the unit to be safe and reliable, there is an inherent risk in using any
product that may potentially affect the operation or drive-ability of your vehicle.
If you are concerned about the operation of your vehicle at any time while
using J-Box 3:
* Pull off the roadway immediately or as soon as it is safe to do so.
* Disconnect the J-Box 3 from the OBDII port.
* Consult a licensed mechanic or automobile service center.
Please report any issues or concerns to our Technical Support Department at
suppor[email protected] or 87 7-5 28-6249. We maintain an active database of
the feedback we receive, and your comments can help us continuously
improve the product.
2 of 17
User Guide

Limited Warranty
Launch guarantees that every J-Box 3 is free from physical defects in material
and workmanship under normal use for one year from the date of purchase.
IN NO EVENT SHALL LAUNCH’S LIABILITY EXCEED THE PRICE PAID FOR THE
PRODUCT. LAUNCH SHALL BE EXEMPT FROM ALL OTHER CLAIMS WHETHER
BASED UPON DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES RESULTING FROM THE USE OF THE PRODUCT, ITS ACCOMPANYING
SOFTWARE, OR ITS DOCUMENTATION.
Launch makes no warranty or representation, expressed, implied, or statutory,
with respect to its products or the contents or use of this documentation and
all accompanying software, and specifically disclaims its quality, performance,
merchantability, or fitness for any particular purpose. Launch reserves the right to
revise or update its products, software, or documentation without obligation to
notify any individual or entity.
Please direct all inquiries to:
Launch
1820 South Milliken Ave.
Ontario, CA 91761
3 of 17
User Guide

Copyright & Trademarks
© 2018 Launch, All Rights Reserved.
is a registered trademark of Launch, and is registered in the United States and
other countries. All other marks are trademarks or registered trademarks of
their respective holders.
Pictures are for illustration purposes only. Specifications are subject to change.
FCC Statement
The wireless module has been tested and found to comply with the FCC part 15
and ICRSS210 rules. These limits are designed to provide reasonable protection
against harmful interference in approved installations. This equipment generates,
uses, and can radiate radio frequency energy. If not installed and used in accordance
with the instructions, this device may cause harmful interference to radio
communications. However, there is no guarantee that interference may not occur
in a particular installation. This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. Modifications or
changes to this equipment not expressly approved by the party responsible for
compliance may render void the user’s authority to operate this equipment.
* Modular Approval, FCC and IC
* FCC ID: X3ZBTMOD3
* IC: 8828A-MOD3
In accordance with FCC part 15, the SPT2632C1A.AT2 is listed above as a
modular transmitter device.
4 of 17
User Guide

Contents
Important Notes.........................................2
Limited Warranty........................................3
Copyright & Trademarks ..................................4
FCC Statement ..........................................4
Introduction ............................................6
Getting to Know the J-Box 3 ..............................6
Installation & Device Activation............................7
J2534 Toolbox 3®........................................ 12
Product Specifications .................................. 15
Technical Support ......................................16
5 of 17
User Guide

Introduction
Thank you for choosing J-Box 3! The J-Box 3 will allow you to re-flash modern
vehicle controllers to stock as well as perform dealer level diagnostics on
select manufacturer’s vehicles. This Quick Start Guide covers the initial setup,
features, and common questions. This manual is always available at www.
launchtechusa.com. Information for individual manufacturers can be found in
the J2534 Toolbox 3 application.
Getting to Know the J-Box 3
LED Status Lights
 
   
 Firmware error: Call
Technical Support –Device startup in progress Device is functioning

 – –
Connected and
communicating with
vehicle
Connected to vehicle

 –Cable not connected
or cable error –
Cable OK /
Vehicle power
(Communication)

 –Installation Issue:
Call Technical Support – Connected to PC
Power
Protocol Vehicle Cable
USB Cable USB
Cable Port
Vehicle Cable
Connection
Auxiliary Programming
Voltage Connection
6 of 17
User Guide

Installation & Device Activation
Windows 10 users:
1. It is important that you connect the device to your PC first.
a. Initial low-level drivers will be automatically downloaded and
installed as Windows Update recognizes your device.
2. Leave your device connected to your PC and proceed to Step 1
of the Installation & Device Activation process.
1. Insert the CD included with your J-Box 3 into your PC. You will need to have
an internet connection to get the latest drivers. If your PC does not have a
Disk Drive, please go to the Launch website and click on Downloads to get
the J-Box 3 Ins taller.
2. Run the Setup application, check the box next to I accept the terms…
and click Install.
7 of 17
User Guide

3. The Setup application will install the J-Box 3 Drivers, the J2534 Toolbox 3
on your PC.
4. Once the setup application has finished, Connect the USB cable to your
J-Box 3 and to the PC. Once you have gotten a message in the lower right
hand corner that the device has been installed, click Activate My device.
Then Click Exit.
8 of 17
User Guide

5. The activator application will open after clicking Activate My Device in the
setup application. Click the Activate My Device! Button.
6. Select the interface you want to activate and click Continue.
9 of 17
User Guide

7. Enter your information and click Continue.
8. Select your type of business and level of programming experience, then
select the OEMs you are planning to support.
Click Continue once you are done.
10 of 17
User Guide

9. Unplug your J-Box 3 from your PC and click OK.
10. Plug your J-Box 3 back into your PC, and click OK.
11. Your device has been successfully activates, click Close Application.
11 of 17
User Guide

J2534 TOOLBOX 3®
1. Double Click the J2534 Toolbox 3 Icon on the Desktop.
2. Select your interface from the drop down and click Auto Login.
3. The Toolbox will open with 6 tabs available. The first is General, it has news,
current OEM concerns, and training broadcast invitations.
12 of 17
User Guide

4. The Diagnostics tab has basic Diagnostic functions, as well as links,
information and videos about all OEMs that currently provide diagnostics
via J2534.
5. The Flashing tab contains the information pertaining to OEM J2534 re-flashing
including links, information, walk-throughs, and some helper functions.
13 of 17
User Guide

6. The Support tab has functions to check driver installation, vehicle
communication, update your device, create debug logs, and contact
Technical Support.
7. The Training tab includes videos of installing and using OEM J2534
applications with Launch products.
14 of 17
User Guide

PRODUCT SPECIFICATIONS
Protocols Supported:
* CAN Bus (CAN FD, ISO 15765, GMLAN, J1939, & ISO14229)
* 4 CAN channels (FD CAN, DUAL WIRE)
* Single-wire CAN support
* Ford SCP (J1850PWM)
* GM Class2 (J1850VPW)
* KWP2000 (ISO9141/14230)
* Chrysler SCI (J2610)
* Compliant to SAE J2534 (FEB 2002)and SAE J2534-1 (DEC 2004)
* Compliant to ISO 22900-1 MVCI physical layer
* Programming voltage on J1962 (PIN 6,9,11,12,13,14,OR AUX)
* Ground Pin 9
Operating Systems Supported:
* Windows 7®(32-BIT/64-BIT)
* Windows 8®(32-BIT/64-BIT)
* Windows 8.1®(32-BIT/64-BIT)
* Windows 10®(32-BIT/64-BIT)
Physical Specifications/Tolerances:
 
Dimensions (approximate) 6.5" × 6" × 1.5"
Input Voltage Range 7VDC to 36VDC
Supply Current 220mA @ 7VDC
175mA @ 12VDC
Operating Temperature 0°C to 60°C (ambient)
Storage Temperature -20°C to 85°C (ambient)
PC Communications Type USB version 1.1 or higher
15 of 17
User Guide

Technical Support
Please contact Launch for technical support at suppor[email protected].
Or you can call, 87 7-528-6249.
If technical support finds it necessary for the unit to be returned for repair, you
will be asked for your contact information and then provided with a Return
Authorization number (RA#). Launch will use the RA to track the unit through
the repair process. Please write this number on the outside of your shipping box
so it can be routed to the correct department. If the necessary repair is not
covered by Launch’swarranty, you will be contacted for payment arrangements.
16 of 17
User Guide

© 2018 Launch. All Rights Reserved.
1820 South Milliken Ave.
Ontario, CA 91761
87 7-528-6249
launchtechusa.com
