Thank you for your purchase
THANK YOU FOR YOUR PURCHASE!
We are pleased that you have chosen Sears for your outdoor furniture purchase. We hope that you
enjoy the unmatched quality, comfort, and style of your new patio set. Every piece is meticulously
considered all the way down to the smallest details, exclusively for you, by our world class design
team. We know you have a choice when it comes to your patio furniture needs, so from our team to
yours, thank you for letting us be a part of your outdoors.
Table of Contents..........................................2
Safety Information ........................................ 3
Set up your furniture properly...................... 3
Examine your furniture................................ 3
Warranty ........................................................ 3
What is Covered ......................................... 3
What is Not Covered................................... 3
Care and Maintenance.................................. 4
Pre-Assembly................................................ 5
Planning Assembly ..................................... 5
Observe weight limits.................................. 5
Hardware Included...................................... 5
Package Contents....................................... 7
Assembly Instructions
Swivel Rocker Lounge................................ 10
Loveseat ...................................................... 15
Coffee Table ................................................ 18
Customer Services ..................................... 21
Table of Contents

3
SET UP YOUR FURNITURE
PROPERLY
□Ensure that all parts are assembled
properly and fully tightened as per the
instructions.
□When placing in the desired location,
ensure that all legs are resting on the same
surface. You may adjust the legs levelers
as required to ensure that the item stands
in a rigid position.
EXAMINE YOUR FURNITURE
□Examine occasionally to ensure that there
are no loose parts. If loose parts are found,
they must be retightened fully before
additional use.
THIS IS A RESIDENTIAL WARRANTY AND DOES NOT APPLY FOR
COMMERCIAL USE.
7 YEARS WARRANTY FOR FRAME, 1 YEAR WARRANTY FOR RESIN WICKER
AND CUSHIONS
WHAT IS COVERED
We warrant the frame to be free of Manufacturing defects to the original purchaser for 7 years, and
resin wicker for 1 year.
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service
center.
This warranty does not cover commercial use, hardware, acts of nature, fire, freezing and abusive
use.
Discoloration or fading of the finish or fabrics as a result of chemicals or spills is not covered.
Glass table top breakage and corrosion or rusting of hardware are not covered.
In addition, purchase parts are not covered under this warranty.
Safety Information
WARNING:
1. Do not crawl, stand, or sit on table tops.
2. Do not set or lay heavy items on table
tops.
3. Avoid extreme hot & cold items being
placed on table tops.
CAUTION: Read all of the instructions in
this manual before you begin assembly.
Failure to do so may result in faulty
assembly and potential injury!
Warranty

4
Proof of purchase (dated register receipt) is required for warranty claims.
We reserve the right to make substitutions with similar merchandise, if the model in question is no
longer in production.
For a copy of our full limited warranty, please contact our customer service team below.
Contact the Customer Service Team at 1-866-391-4868 or visit www.Bjifurniture.com.
Care and Maintenance
□Do not allow water to build up in frames. This will cause corrosion and possible freezing damage
in cold climates.
□Use a mild soap and water for normal cleaning. DO NOT use janitorial or alcohol based cleaners.
Some cleaners may be marked as natural, but some ingredients can cause discoloration or have
adverse reaction to your finish.
□Rinse with clean water and dry with a soft, absorbent cloth towel.
□Cushions, slings, and/or an umbrella may be cleaned by hand with a solution of soap and water
with a clean water rinse. Never machine wash as this will result in shrink or damage. After
cleaning, tip on end and allow to drip dry. Never use a commercial or home dryer to tumble dry
fabric goods.
□Treat frames with liquid wax for maximum protection against UV rays and /or salty, damp air.
□Umbrella should be closed when not in use. Umbrella should be removed and stored in the event
of wind, rain, hail, sleet, snow, or any other inclement weather. To prevent damage to your table,
always use an umbrella base with your umbrella. Store indoors during winter months.
□Use and operation: To prolong the life of your outdoor furniture, cover when not in use. Store
indoors during winter months.
Warranty (continued)

5
Pre-Assembly
PLANNING ASSEMBLY
PLEASE READ COMPLETE USE AND CARE GUIDE PRIOR TO ASSEMBLY!
Identify all parts packed in the carton against the parts list. Remove all protective materials and place
the parts on a nonabrasive surface to avoid scratching. It takes about 45 minutes for 3 persons to
complete all the assembly.
NOTE: More than one person may be
required to complete the assembly of this
product.
OBSERVE WEIGHT LIMITS
The recommended weight limit for each item is listed below:
□loveseat:450lbs
□Swivel rocker lounge: 300lbs
SWIVEL ROCKER LOUNGE HARDWARE INCLUDED
NOTE: Hardware not shown to actual
size.
Part Description Quantity
AA M6*40mm Hex Bolt 10
BB M8*45mm Hex Bolt 4
CC M6 washer 10
DD M8 washer 4
EE M8 nut 4
FF M6 bolt cap 10
GG M8 bolt cap 4
HH Hex wrench 2

6
Pre-Assembly (continued)
LOVESEAT HARDWARE INCLUDED
NOTE: Hardware not shown to actual
size.
COFFEE TABLE HARDWARE INCLUDED
NOTE: Hardware not shown to
actual size.
Part Description Quantity
AA M6*40mm Hex Bolt 10
BB M6*15mm Hex Bolt 1
CC M6 washer 11
DD M6 bolt cap 11
EE Hex wrench 1
Part Description Quantity
AA M6*20mm Hex Bolt 8
BB M6*15mm Hex Bolt 4
CC M6 washer 12
DD M6 bolt cap 12
EE Hex wrench 2

7
SWIVEL ROCKER LOUNGE PACKAGE CONTENTS
Pre-Assembly (continued)
Part Description Quantity
A Right arm 2
B Left arm 2
C Back frame 2
D Seat frame 2
E T-Rocker 2
F Base 2
G Seat cushion 2
H Back cushion 2
I toss pillow 2

8
Pre-Assembly (continued)
LOVESEAT PACKAGE CONTENTS
Part Description Quantity
A Right arm 1
B Left arm 1
C Back frame 1
D Seat frame 1
E Seat cushion 1
F Back cushion 2
G Toss pillow 2

9
Pre-Assembly (continued)
COFFEE TABLE PACKAGE CONTENTS
□EVERY BOLT NEEDS TO BE USED WITH A WASHER.
□DO NOT FULLY TIGHTEN BOLT UNTIL INDICATED IN STEP 3 FOR SWIVEL ROCKER
LOUNGE CHAIR AND STEP 2 FOR LOVESEAT & COFFEE TABLE.
Part Description Quantity
A Table rim 1
B left leg 2
C Right leg 2
D Leg connector Ring 1
E Ceramic tile 1
Safety Information

10
Swivel Rocker Lounge
Assembly Instruction
1 Attaching the arm
□Attach the left arm (B) to the back (C) using M6 hex bolts (AA) and M6 washers (CC).
□Repeat these instructions to attach the right arm (A) to the back (C).
□Do not tighten the hex bolts until assembly is complete.
X 6 X6

11
Swivel Rocker Lounge
Assembly Instruction
(continued)
2
Attaching the T-Rocker
□Attach the seat (D) to the T-Rocker (E) using M8 hex bolts (BB), M8 nut (EE) and M8
washers (DD).
□Tighten all hex bolts (BB) with the hex wrench (HH). Attach the M8 hex bolt caps (GG).

12
Swivel Rocker Lounge
Assembly Instruction
(continued)
3 Attaching the Seat
□Attach the seat (D) to the left right (B) using M6 Hex bolts (AA) and M6 washer (CC).
□Tighten all M6 hex bolts (AA) with the hex wrench (HH). Attach the M6 bolt caps (FF).

13
Swivel Rocker Lounge
Assembly Instruction
(continued)
4 Inserting the T-Rocker
□Insert the T-Rocker (E) into the base (F). Make sure the seat bottoms out in the base for
safety.

14
Swivel Rocker Lounge
Assembly Instruction
(continued)
5 Adding the cushion
□Place the seat cushion (G), back cushion (H) and toss pillow (I) onto the swivel rocker lounge
chair.
□Repeat these instructions to another swivel rocker lounge.
□Swivel rocker lounges are ready for your enjoyment

15
Loveseat Assembly
Instruction
1 Attaching the arm
□Attach the Left arm (B) to the back (C) using hex bolts (AA) and washers (CC)
□Repeat these instructions to attach the right arm (A) to the back (C)
□Do not tighten the hex bolts until assembly is complete
X 6 X 6

16
Loveseat Assembly
Instruction (continued)
2
Attaching the seat
□Attach the seat (D) to the left arm (B) using hex bolts (AA) and washer (CC)
□Repeat these instructions to attach the seat (D) to the right arm (A)
□Attach the seat (D) to the back (C) using hex bolts (BB) and washer (CC)
□Ensure all bolts are aligned and assembled correctly
□Tighten all hex bolts (AA) and (BB) with the hex wrench (EE). Attach the hex bolt caps (DD).

17
Loveseat Assembly
Instruction (continued)
3 Adding the cushion
□Place the seat cushion (E) , the back cushion (F) and toss pillow (G) onto the loveseat
□The loveseat is now ready for use.

18
Coffee Table Assembly
Instruction
1 Attaching the connector ring
□Remove the plastic clamps from the table rim (A), and remove the ceramic tile top (E) form
the table rim (A), and carefully place the ceramic top (E) on a soft surface.
□Carefully place the table top upside down on a soft, flat and non-abrasive surface.
□Attach the leg (B) to the connector ring (D) using hex bolt (BB) and washers (CC).

19
Coffee Table Assembly
Instruction (continued)
2 Attaching the table rim
□Attach the leg (C) to the table rim (A) using hex bolt (AA) and washer (CC).
□Ensure all bolts are aligned and assembled correctly
□Tighten all hex bolts (AA) and (BB) with the hex wrench (EE). Attach the hex bolt caps (DD)

20
Coffee Table Assembly
Instruction (continued)
3 Replacing the ceramic top
WARNING:
1,Do not crawl ,stand ,or sit on tile table tops.
2,Do not set or lay heavy items on tile table
tops.
3, Avoid extreme hot &cold items being
placed on tile table tops.
□With the assistance of another person carefully turn the table over and set it down on its
legs.
□Place the tile top (E) onto the table.
□The coffee table is ready for your enjoyment.
