LDARC THUNDER 600X User manual

THUNDER 600X
WWW.LDARC.COM
THUNDER 600X
LDARC
30
30
155mm
FLY WING PNP PARTS
FLY WING FPV PARTS
PNP
KIT +FLY WING
PNP PARTS
PNP+FPV
KIT +FLY WING
PNP PARTS
FLY WING
FPV PARTS
+
User manual and video please visit：WWW.LDARC.COM
说明书和视频教程请访问：WWW.LDARC.COM
Departments 》 FPV FLY WING 》 THUNDER 600X
分类 》 FPV飞翼 》 THUNDER 600X
重心/Center of gravity
描述/Specification
翼展/Wingspan:656mm
长度/Length:357mm
材质/Material:EPO
配置/Configuration
电机/Motor:A2205-2500KV
电调/ESC:35A BLheli
UBEC:2-6S 5V 3A
舵机/Servo:12g EMAX ES08MA Ⅱ
图传/VTX:5.8G 400mW Mini 40CH
摄像头/Camera:RunCam Swift Mini
螺旋桨/Prop:5*5E and 6*4E
颜色/Color:橙色或黑色/Orange or Black
Antenna*1PC（Height size:36.5mm）
RunCam Swift Mini*1PC 400mW VTX*1PC(90。) *1PC *1PC
A2205-2500KV*1PC ES08MA Ⅱ Servo*2PCS UBEC*1PC A-35A ESC*1PC Cooling fin*1PC
副翼和升降/Aileron and Elevator
电池仓尺寸/Battery position size:
91*35*21mm
-1- -2-

KIT
Part 4
Part 5
Part 5-1 Part 5-3
*2PCS *2PCS *2PCS
5*5E*5PCS 6*4E*5PCS
*1PC *1PC Φ4*250mm*1PC *2PC
*4PCS *2PCS *2PCS
*2PCS
*2PCS *1Pair
*1PC *1PC
Φ1.5*4PCS M3*5*4PCS
ST1.4*6*4PCS Φ1.5*105*2PCS
*1PC
Φ5*Φ1*8PCS
ST2*6*8PCS
*4PCS
M2*5*8PCS Φ4.2*Φ2.2*4PCS
2.用胶水将LED和碳棒固定在EPO上。
Fixed LED and carbon onto EPO by glue.
(请使用EPO泡沫胶水粘贴/Please use EPO foam glue stick)
3.用胶水把机翼和机身粘好。
Combine the fuselage and wing by glue.
4.用M3*6螺丝将电机固定在电机座上。
Used M3*6 screw fix motor onto motor base.
5.电机线穿过机身底部，然后与电调焊接好，然后安装电机的
固定座在飞翼上。
The motor line cuts through the bottom of the fuselage,
then welding with ESC, Assemble motor-ESC base onto
flying wing.
10.用胶水将塑胶配件粘贴好
Stick plastic parts 4
7.用胶水将塑胶配件粘贴好
Stick plastic parts 1
8.用胶水将塑胶配件粘贴好
Stick plastic parts 2
9.用胶水将塑胶配件粘贴好
Stick plastic parts 3
6.将舵机安装在左、右机翼上
Assemble servos onto left and right wing.
11.电调和UBEC并联焊接，然后盖上头罩，PNP安装完成。
Welding ESC and UBEC by paralleling, cover canopy
and finish PNP assembly.
12.焊接好图传与摄像头连接线在分电板上。
Welding VTX and camera connecting line onto PCB.
13.组装好摄像头模块，并与头罩固定好。
Fix camera module onto canopy by screw.
14.用ST2*6螺丝安装图传与天线在头罩上。
Used ST2*6 screw fix ESC and antenna onto canopy.
15.连接好图传与摄像头，盖上头罩，FPV安装完成。
Connect ESC and camera by wire,cover canopy ,
inish assembly.
安装步骤/Installation Steps
1.将UBEC线分割成两段，并焊上锡，然后将LED，UBEC，
接收机电源线与分电板焊接好。
Cut the wire of UBEC into two parts, and soldering tin，
Finish welding LED, UBEC, and power wire onto PCB.
-3- -4-
