Leader LV 5490 User manual

LV 5490 MULTI WAVEFORM MONITOR
LV 5490SER01 SDI INPUT
LV 5490SER02 SDI INPUT / EYE
LV 5490SER03 DIGITAL AUDIO
LV 5490SER04 FOCUS ASSIST
LV 5490SER05 CIE DIAGRAM
INSTRUCTION MANUAL
USO RESTRITO

TABLE OF CONTENTS
USO RESTRITO

USO RESTRITO

USO RESTRITO

USO RESTRITO

I
GENERAL SAFETY SUMMARY
Read This before Using the Instrument
This instrument should only be used by persons with sufficient knowledge of electronics who
thoroughly understand the contents of this manual.
This instrument is not designed or manufactured for households or ordinary consumers.
If unqualified personnel are to use the instrument, be sure the instrument is handled under the
supervision of qualified personnel (those who have electrical knowledge). This is to prevent the
possibility of personal injury or damage to the instrument.
Note about Reading This Manual
The contents of this manual contain specialized terminology and may be difficult to understand. If
you have any questions about the contents of this manual, please contact your local LEADER
agent.
Symbols and Terms
The following symbols and terms are used in this instruction manual and on the instrument to
indicate important warnings and notes.
<Symbol> This symbol appears in this instruction manual and on the instrument to
indicate an area where improper handling could result in personal injury,
damage to the instrument, or malfunction of the instrument or devices
connected to it.
When you encounter this symbol on the instrument, be sure to refer to the
information in this instruction manual that corresponds to the area that the
symbol marks.
<Term> Ignoring the precautions that this term indicates could lead to death or
serious injury.
<Term> Ignoring the precautions that this term indicates could lead to personal injury
or damage to the instrument.
USO RESTRITO

II
GENERAL SAFETY SUMMARY
Read the warnings and information below thoroughly to avoid death, personal injury, and damage and
deterioration of the instrument.
Warnings Concerning the Case and Panels
Do not remove the instrument’s case or panels for any reason. Touching the internal components
of the instrument could lead to fire or electric shock.
Also, do not allow foreign materials, such as liquids, combustible matter, and metal, to enter the
instrument. Turning the instrument on when such materials are inside it could lead to fire, electric
shock, damage to the instrument, or some other accident.
Installation Environment
Operating Temperature Range
Use this instrument in a 0 to 40 °C environment. Using the instrument with its vents blocked or
in a high temperature environment could lead to fire.
Drastic changes in temperature, such as might be caused by moving the instrument between
two rooms with different temperatures, can damage the instrument by causing condensation to
form within it. If there is a possibility that the instrument has condensation within it, wait for
approximately 30 minutes before turning on the power.
Operating Humidity Range
Use this instrument in an environment whose relative humidity is 85 %RH or less where there
is no threat of condensation forming.
Also, do not operate this instrument with wet hands. Doing so could lead to electric shock or
fire.
Do Not Operate in an Explosive Atmosphere
Using this instrument in an environment where flammable gasses, explosive gasses, or steam
is emitted or stored could lead to an explosion or fire. Do not use the instrument in such an
environment.
Do Not Insert Foreign Materials
Do not insert foreign materials, such as metal and flammable objects, through the vents or
allow liquid to enter the instrument. Such acts can lead to fire, electric shock, damage to the
instrument, or some other accident.
If You Notice Something Wrong during Operation
If you notice smoke, fire, a strange smell, or something else that is wrong with the instrument
while you are operating it, stop operation immediately. Failing to do so could lead to fire. Turn
OFF the power switch, and remove the power cord from the outlet. After making sure that fire
has not spread anywhere, contact your local LEADER agent.
USO RESTRITO

III
GENERAL SAFETY SUMMARY
Warnings Concerning the Power Source
Do not use a power source with a voltage other than the rated power source voltage for the
instrument. Doing so could lead to fire.
Confirm the voltage of the power source before you connect the power cord to it.
Only use a power source whose frequency is 50/60 Hz.
Use a power cord that is appropriate for the voltage of the power source. Also, use a power cord
that meets the safety standards of the country that you are using it in.
Using a power cord that does not meet the standards could lead to fire. If the power cord is
damaged, stop using it, and contact your local LEADER agent. Using a damaged power cord
could lead to electrical shock or fire.
When removing the power cord from the power outlet, do not pull on the cord. Pull from the plug.
Warnings Concerning Grounding
The instrument has a ground terminal to protect the user and the instrument from electric shock.
Ensure that the product is properly grounded for safe operation.
Warnings Concerning the Panel
Sections of the panel are made out of glass. If the glass breaks, the broken glass may lead to
injury. Do not apply a strong shock to the panel, cut it with sharp metal, or damage it in any
similar manner.
Cautions Concerning the Input and Output Connectors
To avoid damaging the instrument, only apply signals to the input connectors that conform to the
specifications in this instruction manual. Do not short or apply external voltage to the output
connectors. Doing so could damage the instrument.
Cautions Concerning the Ethernet Port
When you are connecting the instrument to the communication provider's equipment, connect to
the Ethernet port through a hub that is authorized for use in the country that you are using the
instrument in.
USO RESTRITO

IV
GENERAL SAFETY SUMMARY
Calibration and Repairs
This instrument has been carefully examined at the factory to ensure that its performance is in
accordance with the standards. However, because of factors such as parts wearing out over time,
the performance of the instrument may degrade. To ensure stable performance, we recommend
that you have the instrument calibrated regularly. Also, if the instrument malfunctions, repairs are
necessary. For repairs and calibration, contact your local LEADER agent.
Routine Maintenance
When you clean the instrument, remove the power plug from the outlet.
Do not use thinner or benzene when you clean the instrument's case, panels, or knobs. Doing so
could lead to paint chipping and the corrosion of plastic components. To clean the case, panels,
and knobs, use a soft cloth with mild detergent, and wipe gently. While cleaning, make sure that
foreign materials, such as water and detergent, do not enter the product. If liquid or a metal object
enters into the instrument, fire or electric shock may result.
About the European WEEE Directive
This instrument and its accessories are subject to the European WEEE Directive.
Follow the applicable regulations of your country or region when discarding this instrument or its
accessories. Follow the EU Battery Directive when discarding the batteries that you removed from
this instrument.
(WEEE stands for Waste Electrical and Electronic Equipment.)
Follow the warnings and precautions that have been listed in this section to use the instrument
correctly and safely. Precautions are also contained in various other sections of this instruction manual.
To use the instrument correctly, be sure to follow those precautions as well.
If you have any questions or comments about this instruction manual, please contact your local
LEADER agent.
USO RESTRITO

1. INTRODUCTION
1
1. INTRODUCTION
Thank you for purchasing this LEADER instrument. To use this instrument safely, read this
instruction manual thoroughly, and make sure that you know how to use the instrument
properly.
If some point about the operation of this instrument is still unclear after you have read this
instruction manual, refer to the contact information on the back cover of the manual to contact
LEADER, or contact your local LEADER agent.
After you have finished reading this manual, keep it in a convenient place so that you can refer
to it when necessary.
1.1 Scope of Warranty
This LEADER instrument has been manufactured under the strictest quality control
guidelines.
LEADER shall not be obligated to furnish the following free services during the warranty
period.
1. Repair of malfunction or damages resulting from fire, natural calamity, or improper voltage
applied by the user.
2. Repair of a product that has been improperly repaired, adjusted, or modified by personnel
other than a factory-trained LEADER representative.
3. Repair of malfunctions or damages resulting from improper use.
4. Repair of malfunctions caused by devices other than this instrument.
5. Repair of malfunctions or damages without the presentation of a proof of purchase or
receipt bill for the instrument.
1.2 Operating Precautions
1.2.1 Maximum Allowable Input Voltage
The maximum signal voltage that can be applied to the input connectors is indicated below.
Do not apply excessive voltage to the connectors. Doing so may damage the device or
lead to injury.
Table 1-1 Maximum allowable input voltage
Input Connector Maximum Allowable Input Voltage
LV 5490 EXT REF ±5 V (DC + peak AC)
REMOTE 0 to +5 V
SER01 SDI INPUT ±2 V (DC + peak AC)
SER02 SDI INPUT (1A to 1D) 0 to +12 V (DC), ±1V (AC)
SDI INPUT (2A to 2D) ±2 V (DC + peak AC)
SER03 DIGITAL AUDIO INPUT ±5 V (DC + peak AC)
1.2.2 Mechanical Shock
This instrument contains sensitive components, so it may be damaged if it is dropped or
otherwise exposed to a strong shock.
USO RESTRITO

1. INTRODUCTION
2
1.2.3 Electrostatic Damage
Electronic components can be damaged by static discharge. Static electricity can build up
in the core wire of a coaxial cable. Before connecting a coaxial cable to the instrument,
short the core wire of the cable with the external conductor.
1.2.4 Warming Up
To ensure more accurate measurements, turn ON the instrument approximately 30 minutes
before you intend to use it to allow its internal temperature to stabilize.
1.2.5 About Standby Mode
Even if you press the power switch to turn off this instrument, the instrument remains in
standby mode as long as the power cord is connected to the outlet. In standby mode, some
of the internal circuits operate and may generate heat. Unless necessary, keep the power
cord disconnected from the outlet.
1.2.6 Backup
This instrument has a last-memory feature. When you turn the power on, the instrument
starts with the panel settings that were in use the last time that it was turned off. If the
backup battery is out of power, the message “The last memory feature is disabled.” will
appear, and this last-memory feature will no longer work.
To continually use the last-memory feature, we recommend that you replace the backup
battery with a new one every five years after you purchase the instrument. You cannot
replace the backup battery yourself. For details, contact your nearest LEADER agent.
1.2.7 About the LCD Panel
There may be a small number of pixels in the LCD panel that do not light or are always on.
Note that this is not a malfunction.
The LCD panel supports a large number of video signals. SDI input signals are displayed
asynchronously on the LCD. Therefore, images may appear to flicker on the waveform and
picture displays.
In addition, the input SDI signal is temporarily stored in frame memory and is loaded by
using the LCD display synchronization signal—which is not synchronized with the input
SDI signal. Therefore, because frame skip—which skips over frames in the memory—and
frame repeat—which reads the same frames of the memory twice—occur, the image may
appear to flicker.
(An external sync signal can be used to synchronize the LCD to the input signal.)
1.3 About Trademarks and Licenses
The company and product names in this document are trademarks or registered trademarks
of their respective holders.
USO RESTRITO

1. INTRODUCTION
3
1.4 About Terminology Used in this Manual
SER01/SER02/SER03/SER04/SER05
LV 5490SER01 is referred to as SER01; LV 5490SER02 is referred to as SER02; LV
5490SER03 is referred to as SER03, LV 5490SER04 is referred to as SER04, LV
5490SER05 is referred to as SER05.
Single Input Mode
This refers to the mode in which on the INPUT menu, DISPLAY is set to SINGLE.
It is a mode for measuring a single input signal.
Simul Mode
This refers to the mode in which on the INPUT menu, DISPLAY is set to SIMUL.
It is a mode for measuring multiple input signals simultaneously.
Input Formats and Link Systems
The following names are used for the input formats and link systems.
Multi link may be used as a collective term to refer to dual link and quad link.
Table 1-2 Input formats and link systems
Name Description Link System
SD SD-SDI Single link
HD HD-SDI Single link
3G-A 3G-SDI level A Single link
3G-B-DL 3G-SDI level B dual link mapping Single link
3G-B-DS 3G-SDI level B dual stream mapping Single link
HD (DL) HD-SDI dual link Dual Link
HD (QL) HD-SDI quad link Quad link
3G (DL) 3G-B-DS dual link Dual Link
3G (QL) 3G-A, 3G-B-DL quad link Quad link
3G Collective name for 3G links -
3G-B Collective name for 3G-B-DL and 3G-B-DS -
About Underlining (_)
Underlined options indicate the default values.
USO RESTRITO

2. SPECIFICATIONS
4
2. SPECIFICATIONS
2.1 General
The LV 5490 is a multi waveform monitor that supports 4K video formats. It can receive and
display up to four signals up to 3G-SDI simultaneously. Up to eight signals can be displayed
by switching. For 4K video formats, 3G-SDI dual link and quad link and HD-SDI quad link are
supported.
The display is a 9-inch full high definition LCD enabling the LV 5490 to also be used as a
high-quality picture monitor. In addition, the LV 5490 is equipped with SDI and DVI-D output
connectors. The content shown on the LV 5490 display can be output to an external full high
definition monitor.
The display incorporates a new free layout technology that allows the size and position of the
display layout to be customized with a mouse to suit your application.
The following units and options are available. You can combine them to suit your application.
LV 5490SER01 (SDI INPUT): SDI input (*1)
LV 5490SER02 (SDI INPUT / EYE): SDI input with eye pattern (*1)
LV 5490SER03 (DIGITAL AUDIO): Digital audio I/O
LV 5490SER04 (FOCUS ASSIST): Focus assist
LV 5490SER05 (CIE DIAGRAM): CIE diagram
*1 The LV 5490 requires an LV 5490SER01 or LV 5490SER02 to be installed.
These units cannot be installed simultaneously.
2.2 Features
4K Video Format
The LV 5490 supports 4K video formats (4096×2160 and 3840×2160) based on 3G dual
link and quad link and HD quad link.
Up to four 3G dual link 4K video signals can be displayed by switching.
Up to two 3G quad link or HD quad link 4K video signals can be displayed by switching.
Full High Definition LCD
The LV 5490 is equipped with a 9-inch LCD with excellent viewing angle and color
reproducibility. It can also be used as a high-quality high definition picture monitor.
Free Layout
The LV 5490 can display not only the video signal waveform, vector waveform, picture, and
the like of an input SDI signal simultaneously, but it can also display multiple input signals
simultaneously and overlay them for comparison. The measurement screens can be
adjusted in size and position as you like.
Different layout configurations can be achieved simply by using the mouse.
USO RESTRITO

2. SPECIFICATIONS
5
Eight Inputs and Simultaneous Four Input Display
The LV 5490 has four SDI input connectors compatible with 3G, HD, and SD and can
display up to four SDI input signals simultaneously. It also has four additional SDI I/O
connectors. (*1) If these connectors are used as inputs, the LV 5490 can receive up to eight
SDI input signals.
*1
SDI Signal I/O.”
The four SDI input connectors are equipped with an equivalent cable length measurement
function. This function displays SDI signal attenuation in terms of a coaxial cable length,
which can be used to check the margin that the system has.
Pattern Generator Function and Reclock Output
By using the four SDI I/O connectors as outputs, you can use them as reclock outputs of
the SDI signals received through the SDI input connectors. They can also be used as
outputs for generating patterns such as color bars. In pattern output, the phase of each SDI
output can be varied up to ±0.5H. This feature can be used to check the system’s phase
margin.
External Monitor Output and SDI Routing
The measurement screen can be output in SDI or DVI-D from the monitor output connector.
The output signal can be displayed on an external LCD in full high definition resolution. In
addition, an SDI signal received through one of the SDI input or SDI I/O connectors can be
reclocked and output, serving as a routing function.
USB Mouse Operation
A USB mouse can be used to operate the panel. If the measurement screen is displayed
on an external monitor in SDI or DVI-D, you can control the LV 5490 by using a USB mouse
while viewing the external monitor.
SDI Signal Analysis
The status display also has a feature for detecting CRC and embedded audio errors.
It also has event log, data dump, and phase difference measurement features enabling you
to perform detailed SDI signal analysis.
Screen Capture
The LV 5490 is equipped with a screen capture feature, which captures the entire display
as still-image data. Not only can captured data be displayed by the LV 5490, but it can also
be compared with an input signal or saved to a USB memory device as bitmap data for
viewing on a PC.
Frame Capture
The LV 5490 is equipped with a frame capture feature, which captures single frames in an
SDI signal. Frames can be captured manually or automatically when errors occur.
USO RESTRITO

2. SPECIFICATIONS
6
Time Code Display
The LV 5490 can display the LTC or VITC that is embedded in an SDI signal and the
D-VITC of an SD signal. The timecode can also be used for time stamps in the event log.
External Remote Connector
The remote control connector can be used to load presets, switch the input signal, and
transmit alarms.
Ethernet Port (to be supported in the future)
By connecting the Ethernet interface to a PC, you can control the LV 5490 remotely over
TELNET, transfer files over FTP, control the LV 5490 remotely and detect errors over SNMP,
and control the LV 5490 over HTTP.
Eye Pattern Display (SER02)
This feature can display eye pattern waveforms and jitter waveforms of SDI signals as well
as measurement results of various parameters. The feature displays the information of the
SDI signals received through the four SDI input connectors, one input at a time.
Embedded Audio Display (SER03)
Embedded audio can be separated from the SDI signal and shown in Lissajous, surround,
and meter displays. Other types of analysis displays are also available. 16 channels of one
SDI signal or 4 channels of four SDI signals can be displayed simultaneously.
Digital Audio I/O (SER03)
The digital Audio I/O option has eight digital I/O connectors. Switching between input and
output is possible in groups of four connectors (eight channels).
When used as inputs, digital audio can be shown in Lissajous, surround, and meter
displays. Other types of analysis displays are also available.
When used as outputs, embedded audio is separated from SDI signals and output as
digital audio signals.
Focus Assist (SER04)
A new focusing algorithm based on nonlinear super-resolution technology has been
developed, allowing highly sensitive focusing even on low-contrast images that were
difficult to be focused in on in the past. You can select the sensitivity from the five available
levels according to the image scene.
CIE Diagram (SER05)
Chromaticity diagrams based on ITU-R BT.601, ITU-R BT.709, and ITU-R BT.2020
colorimetries can be displayed. Display mode supports CIE 1931 (xy display) and CIE 1976
(u'v' display).
RS-422/485 Connector (custom order feature)
The camera ID can be displayed using serial communication.
USO RESTRITO

2. SPECIFICATIONS
7
2.3 Specifications
2.3.1 SDI Formats and Standards
Table 2-1 SD video signal formats and standards
Color System Quantization Image Field Frequency/Scanning Compliant Standard
YCBCR4:2:2 10 bits 720×487 59.94/I SMPTE ST 259
720×576 50/I
Table 2-2 HD video signal formats and standards
Color System Quantization Image Frame (Field) Frequency/Scanning Compliant Standard
YCBCR4:2:2 10 bits 1280×720 60/59.94/50/30/29.97/25/24/23.98/P SMPTE ST 292-1
SMPTE ST 296
1920×1080 60/59.94/50/I SMPTE ST 274
SMPTE ST 292-1
30/29.97/25/24/23.98/P
30/29.97/25/24/23.98/PsF
Table 2-3 3G-A video signal formats and standards
Color System Quantization Image Frame (Field) Frequency/Scanning Compliant Standard
YCBCR4:2:2 10 bits 1920×1080 60/59.94/50/P SMPTE ST 274
SMPTE ST 425-1
2048×1080 60/59.94/50/48/47.95/P SMPTE ST 425-1
SMPTE ST 2048-2
12 bits 1920×1080 60/59.94/50/I SMPTE ST 274
SMPTE ST 425-1
30/29.97/25/24/23.98/P
30/29.97/25/24/23.98/PsF
2048×1080 30/29.97/25/24/23.98/P SMPTE ST 425-1
SMPTE ST 2048-2
30/29.97/25/24/23.98/PsF
YCBCR4:4:4 10 bits 1280×720 60/59.94/50/30/29.97/25/24/23.98/P SMPTE ST 296
SMPTE ST 425-1
1920×1080 60/59.94/50/I SMPTE ST 274
SMPTE ST 425-1
30/29.97/25/24/23.98/P
30/29.97/25/24/23.98/PsF
2048×1080 30/29.97/25/24/23.98/P SMPTE ST 425-1
SMPTE ST 2048-2
30/29.97/25/24/23.98/PsF
12 bits 1920×1080 60/59.94/50/I SMPTE ST 274
SMPTE ST 425-1
30/29.97/25/24/23.98/P
2048×1080 30/29.97/25/24/23.98/P SMPTE ST 425-1
SMPTE ST 2048-2
30/29.97/25/24/23.98/PsF
USO RESTRITO

2. SPECIFICATIONS
8
Color System Quantization Image Frame (Field) Frequency/Scanning Compliant Standard
RGB 4:4:4 10 bits 1280×720 60/59.94/50/30/29.97/25/24/23.98/P SMPTE ST 296
SMPTE ST 425-1
1920×1080 60/59.94/50/I SMPTE ST 274
SMPTE ST 425-1
30/29.97/25/24/23.98/P
30/29.97/25/24/23.98/PsF
2048×1080 30/29.97/25/24/23.98/P SMPTE ST 425-1
SMPTE ST 2048-2
30/29.97/25/24/23.98/PsF
12 bits 1920×1080 60/59.94/50/I SMPTE ST 274
SMPTE ST 425-1
30/29.97/25/24/23.98/P
2048×1080 30/29.97/25/24/23.98/P SMPTE ST 425-1
SMPTE ST 2048-2
30/29.97/25/24/23.98/PsF
Table 2-4 3G-B-DL and HD (DL) video signal formats and standards
Color System Quantization Image Frame (Field) Frequency/Scanning Compliant Standard
YCBCR4:2:2 10 bits 1920×1080 60/59.94/50/P SMPTE ST 274
SMPTE ST 372
SMPTE ST 425-1
2048×1080 60/59.94/50/48/47.95/P SMPTE ST 372
SMPTE ST 425-1
SMPTE ST 2048-2
12 bits 1920×1080 60/59.94/50/I SMPTE ST 274
SMPTE ST 372
SMPTE ST 425-1
30/29.97/25/24/23.98/P
30/29.97/25/24/23.98/PsF
2048×1080 30/29.97/25/24/23.98/P SMPTE ST 372
SMPTE ST 425-1
SMPTE ST 2048-2
30/29.97/25/24/23.98/PsF
YCBCR4:4:4 10 bits 1920×1080 60/59.94/50/I SMPTE ST 274
SMPTE ST 372
SMPTE ST 425-1
30/29.97/25/24/23.98/P
30/29.97/25/24/23.98/PsF
2048×1080 30/29.97/25/24/23.98/P SMPTE ST 372
SMPTE ST 425-1
SMPTE ST 2048-2
30/29.97/25/24/23.98/PsF
12 bits 1920×1080 60/59.94/50/I SMPTE ST 274
SMPTE ST 372
SMPTE ST 425-1
30/29.97/25/24/23.98/P
30/29.97/25/24/23.98/PsF
2048×1080 30/29.97/25/24/23.98/P SMPTE ST 372
SMPTE ST 425-1
SMPTE ST 2048-2
30/29.97/25/24/23.98/PsF
USO RESTRITO

2. SPECIFICATIONS
9
Color System Quantization Image Frame (Field) Frequency/Scanning Compliant Standard
RGB 4:4:4 10 bits 1920×1080 60/59.94/50/I SMPTE ST 274
SMPTE ST 372
SMPTE ST 425-1
30/29.97/25/24/23.98/P
30/29.97/25/24/23.98/PsF
2048×1080 30/29.97/25/24/23.98/P SMPTE ST 372
SMPTE ST 425-1
SMPTE ST 2048-2
30/29.97/25/24/23.98/PsF
12 bits 1920×1080 60/59.94/50/I SMPTE ST 274
SMPTE ST 372
SMPTE ST 425-1
30/29.97/25/24/23.98/P
30/29.97/25/24/23.98/PsF
2048×1080 30/29.97/25/24/23.98/P SMPTE ST 372
SMPTE ST 425-1
SMPTE ST 2048-2
30/29.97/25/24/23.98/PsF
* When these signals are displayed, phase differences of up to 100 clocks (approx. 1.34 s) between
HD (DL) links are automatically corrected.
Table 2-5 3G-B-DS video signal formats and standards
Color System Quantization Image Frame (Field) Frequency/Scanning Compliant Standard
YCBCR4:2:2 10 bits 1920×1080 60/59.94/50/I SMPTE ST 274
SMPTE ST 425-1
30/29.97/25/24/23.98/P
30/29.97/25/24/23.98/PsF
1280×720 60/59.94/50/30/29.97/25/24/23.98/P SMPTE ST 296
SMPTE ST 425-1
Table 2-6 3G (DL) video signal formats and standards
Division
Transmission
System
Color System Quantization Image Frame Frequency/Scanning Compliant Standard
Square YCBCR4:2:2 10 bits 3840×2160 30/29.97/25/24/23.98/P SMPTE ST 425-3
SMPTE ST 2036-1
30/29.97/25/24/23.98/PsF -
4096×2160 30/29.97/25/24/23.98/P SMPTE ST 425-3
SMPTE ST 2048-1
30/29.97/25/24/23.98/PsF -
2 sample
interleave
YCBCR4:2:2 10 bits 3840×2160 30/29.97/25/24/23.98/P SMPTE ST 425-3
SMPTE ST 2036-1
4096×2160 30/29.97/25/24/23.98/P SMPTE ST 425-3
SMPTE ST 2048-1
* When these signals are displayed, phase differences of up to 100 clocks (approx. 0.67 s) between
links are automatically corrected.
USO RESTRITO

2. SPECIFICATIONS
10
Table 2-7 HD (QL) video signal formats and standards
Division
Transmission
System
Color System Quantization Image Frame Frequency/Scanning Compliant Standard
Square YCBCR4:2:2 10 bits 3840×2160 30/29.97/25/24/23.98/P -
30/29.97/25/24/23.98/PsF -
4096×2160 30/29.97/25/24/23.98/P -
30/29.97/25/24/23.98/PsF -
* When these signals are displayed, phase differences of up to 100 clocks (approx. 0.67 s) between
links are automatically corrected.
Table 2-8 3G (QL) video signal formats and standards
Division
Transmission
System
Color System Quantization Image Frame Frequency/Scanning Compliant Standard
Square YCBCR4:2:2 10 bits 3840×2160 60/59.94/50/P SMPTE ST 425-5
SMPTE ST 2036-1
4096×2160 60/59.94/50/48/47.95/P SMPTE ST 425-5
SMPTE ST 2048-1
12 bits 3840×2160 30/29.97/25/24/23.98/P SMPTE ST 425-5
SMPTE ST 2036-1
30/29.97/25/24/23.98/PsF -
4096×2160 30/29.97/25/24/23.98/P SMPTE ST 425-5
SMPTE ST 2048-1
30/29.97/25/24/23.98/PsF -
YCBCR4:4:4 10 bits 3840×2160 30/29.97/25/24/23.98/P SMPTE ST 425-5
SMPTE ST 2036-1
30/29.97/25/24/23.98/PsF -
4096×2160 30/29.97/25/24/23.98/P SMPTE ST 425-5
SMPTE ST 2048-1
30/29.97/25/24/23.98/PsF -
12 bits 3840×2160 30/29.97/25/24/23.98/P SMPTE ST 425-5
SMPTE ST 2036-1
30/29.97/25/24/23.98/PsF -
4096×2160 30/29.97/25/24/23.98/P SMPTE ST 425-5
SMPTE ST 2048-1
30/29.97/25/24/23.98/PsF -
RGB 4:4:4 10 bits 3840×2160 30/29.97/25/24/23.98/P SMPTE ST 425-5
SMPTE ST 2036-1
30/29.97/25/24/23.98/PsF -
4096×2160 30/29.97/25/24/23.98/P SMPTE ST 425-5
SMPTE ST 2048-1
30/29.97/25/24/23.98/PsF -
12 bits 3840×2160 30/29.97/25/24/23.98/P SMPTE ST 425-5
SMPTE ST 2036-1
30/29.97/25/24/23.98/PsF -
USO RESTRITO

2. SPECIFICATIONS
11
Division
Transmission
System
Color System Quantization Image Frame Frequency/Scanning Compliant Standard
4096×2160 30/29.97/25/24/23.98/P SMPTE ST 425-5
SMPTE ST 2048-1
30/29.97/25/24/23.98/PsF -
2 sample
interleave
YCBCR4:2:2 10 bits 3840×2160 60/59.94/50/P SMPTE ST 425-5
SMPTE ST 2036-1
4096×2160 60/59.94/50/48/47.95/P SMPTE ST 425-5
SMPTE ST 2048-1
12 bits 3840×2160 30/29.97/25/24/23.98/P SMPTE ST 425-5
SMPTE ST 2036-1
4096×2160 30/29.97/25/24/23.98/P SMPTE ST 425-5
SMPTE ST 2048-1
YCBCR4:4:4 10 bits 3840×2160 30/29.97/25/24/23.98/P SMPTE ST 425-5
SMPTE ST 2036-1
4096×2160 30/29.97/25/24/23.98/P SMPTE ST 425-5
SMPTE ST 2048-1
12 bits 3840×2160 30/29.97/25/24/23.98/P SMPTE ST 425-5
SMPTE ST 2036-1
4096×2160 30/29.97/25/24/23.98/P SMPTE ST 425-5
SMPTE ST 2048-1
RGB 4:4:4 10 bits 3840×2160 30/29.97/25/24/23.98/P SMPTE ST 425-5
SMPTE ST 2036-1
4096×2160 30/29.97/25/24/23.98/P SMPTE ST 425-5
SMPTE ST 2048-1
12 bits 3840×2160 30/29.97/25/24/23.98/P SMPTE ST 425-5
SMPTE ST 2036-1
4096×2160 30/29.97/25/24/23.98/P SMPTE ST 425-5
SMPTE ST 2048-1
* When these signals are displayed, phase differences of up to 100 clocks (approx. 0.67 s) between
links are automatically corrected.
2.3.2 Embedded Audio Playback Format (SER03)
Compliant Standards
3G, HD, HD (DL) SMPTE ST 299
SD SMPTE ST 272
Format L-PCM
Sampling Frequency 48 kHz
Quantization 24 bits
Clock Generation Generated from the video clock
Synchronization Must be synchronized to the video clock.
All SDI signals must be synchronized.
Channel Separation Separates up to four groups (16 channels) from an SDI
input.
USO RESTRITO
