1. PREFACE
Congratulations.
We are delighted to welcome you to our family of customers. Thank you for choosing Numeric as
your power backup solution provider, you now have access to our widest network of 254 service
centers in the country.
Since 1984, Numeric has been enabling its clients to optimize their business with top notch power
solutions that promise seamless and clean power with controlled environmental footprints.
We look forward to your continued patronage in the years to come!
This manual provides general information regarding installation and operation of Onfiniti.
2. INTRODUCTION
Today's business continuity demands a cost-effective power protection solution, for ensuring
Power Continuity and Power Quality with optimal Total Cost of Ownership (TCO). The Onfiniti range
of UPS is a true online double conversion topology UPS, designed with IGBT-based rectifier and
inverter to suit customer requirements.
Onfiniti provides maximum protection and power quality for entry level servers,
workstations, communication equipment, ATMs, etc.
1
Disclaimer
• The contents of this manual are bound to change without prior notice.
• We have exercised reasonable care to give you an error-free manual. Numeric disclaims liability for
any inaccuracies or omissions that may have occurred. If you find information in this manual that is
incorrect, misleading or incomplete, we would appreciate your comments and suggestions.
• Before you begin the installation of the UPS system, please read this manual thoroughly.
The warranty of this product is null and void, if the product is abused/misused.
2

1. PREFACE
Congratulations.
We are delighted to welcome you to our family of customers. Thank you for choosing Numeric as
your power backup solution provider, you now have access to our widest network of 254 service
centers in the country.
Since 1984, Numeric has been enabling its clients to optimize their business with top notch power
solutions that promise seamless and clean power with controlled environmental footprints.
We look forward to your continued patronage in the years to come!
This manual provides general information regarding installation and operation of Onfiniti.
2. INTRODUCTION
Today's business continuity demands a cost-effective power protection solution, for ensuring
Power Continuity and Power Quality with optimal Total Cost of Ownership (TCO). The Onfiniti range
of UPS is a true online double conversion topology UPS, designed with IGBT-based rectifier and
inverter to suit customer requirements.
Onfiniti provides maximum protection and power quality for entry level servers,
workstations, communication equipment, ATMs, etc.
1
Disclaimer
• The contents of this manual are bound to change without prior notice.
• We have exercised reasonable care to give you an error-free manual. Numeric disclaims liability for
any inaccuracies or omissions that may have occurred. If you find information in this manual that is
incorrect, misleading or incomplete, we would appreciate your comments and suggestions.
• Before you begin the installation of the UPS system, please read this manual thoroughly.
The warranty of this product is null and void, if the product is abused/misused.
2

3
3. IMPORTANT SAFETY WARNING
Please read the following instructions carefully before installing the unit and strictly comply with all the
warnings and operating instructions herein. Save this manual for future reference and do not operate this unit
before reading through all safety information and operating instructions carefully.
3-1. Transportation
• Please transport the UPS system in the original package only to protect against shock and impact.
3-2. Preparation
• Condensation may occur if the UPS system is moved directly from a cold to warm environment.
The UPS system must be absolutely dry before being installed. Please allow at least two hours for the UPS
system to acclimatize to the environment.
• Do not install the UPS system near water or in moist environments.
• Do not install the UPS system where it would be exposed to direct sunlight or near a heater.
• Do not block ventilation holes in the UPS housing.
3-3. Installation
• Do not connect appliances or devices which would overload the UPS system (e.g. laser printers) to
the UPS output sockets.
• Do not place cables in such a way that one can step on or trip over them.
• Do not connect domestic appliances such as hair dryers to UPS output sockets.
• The UPS can be operated by any individual with no previous experience.
• Connect the UPS system to an earthed shock-proof outlet which must be easily accessible and
close to the UPS system.
• Use only VDE-tested, CE-marked, ISI-marked mains cable (e.g. the mains cable of your computer)
to connect the UPS system to the building wiring outlet (shock-proof outlet).
• Use only VDE-tested, CE-marked, ISI-marked power cables to connect the loads to the UPS system.
• When installing the equipment, it should ensure that the sum of the leakage current of the UPS
and the connected devices does not exceed 3.5 mA.
• UPS is designed for linear load, worst case inductive resistive load.
3-4. Operation
• Do not disconnect the mains cable on the UPS system or the building wiring outlet
(shock-proof socket outlet) during operations since this would cancel the protective earthing
of the UPS system and all connected loads.
• The UPS system features its own, internal current source (batteries). The UPS output sockets
or output terminals block may be electrically live even if the UPS system is not connected to
the building wiring outlet.
• In order to fully disconnect the UPS system, first press the OFF/Enter button to disconnect the mains.
• Prevent fluids or other foreign objects from entering the UPS system.
3-5. Maintenance, service and faults
• The UPS system operates with hazardous voltages. Repairs may be carried out only by qualified
maintenance personnel.
• Caution - Risk of electric shock. Even after the unit is disconnected from the mains
(building wiring outlet), components inside the UPS system are still connected to the battery.
They might be electrically live and dangerous.
• Before carrying out any kind of service and/or maintenance, disconnect the batteries and verify
that no current is present and no hazardous voltage exist in the terminals of high capability
capacitor such as BUS-capacitors.
• Only people adequately familiar with batteries and with the required precautionary measures
may replace batteries and supervise operations. Unauthorized persons must be kept away from
the batteries.
• Caution - Risk of electric shock. The battery circuit is not isolated from the input voltage.
Hazardous voltages may occur between the battery terminals and the ground. Before touching,
please verify that no voltage is present.
• Batteries may cause electric shock and have a high short-circuit current. Please take the
precautionary measures specified below and any other measures necessary when working
with batteries:
• Remove wristwatches, rings and other metal object
• Use only tools with insulated grips and handles
• When changing batteries, install the same number and same type of batteries.
• Do not attempt to dispose of batteries by burning them. This could cause battery explosion.
• Do not open or destroy batteries. Escaping electrolytes can be toxic and cause injury to the skin and eyes.
• Replace the fuse with the same type and amperage in order to avoid fire hazards.
• Do not dismantle the UPS system.
• Connect UPS to short-circuit protected building wiring.
• The UPS system has internal fuses on both DC & AC inputs. Those devices do not protect the
up stream cables connected to DC & AC inputs and upstream breakers or fuses shall be set up
in accordance with AC & DC wires ratings to meet the local national electrical code standard.
4

3
3. IMPORTANT SAFETY WARNING
Please read the following instructions carefully before installing the unit and strictly comply with all the
warnings and operating instructions herein. Save this manual for future reference and do not operate this unit
before reading through all safety information and operating instructions carefully.
3-1. Transportation
• Please transport the UPS system in the original package only to protect against shock and impact.
3-2. Preparation
• Condensation may occur if the UPS system is moved directly from a cold to warm environment.
The UPS system must be absolutely dry before being installed. Please allow at least two hours for the UPS
system to acclimatize to the environment.
• Do not install the UPS system near water or in moist environments.
• Do not install the UPS system where it would be exposed to direct sunlight or near a heater.
• Do not block ventilation holes in the UPS housing.
3-3. Installation
• Do not connect appliances or devices which would overload the UPS system (e.g. laser printers) to
the UPS output sockets.
• Do not place cables in such a way that one can step on or trip over them.
• Do not connect domestic appliances such as hair dryers to UPS output sockets.
• The UPS can be operated by any individual with no previous experience.
• Connect the UPS system to an earthed shock-proof outlet which must be easily accessible and
close to the UPS system.
• Use only VDE-tested, CE-marked, ISI-marked mains cable (e.g. the mains cable of your computer)
to connect the UPS system to the building wiring outlet (shock-proof outlet).
• Use only VDE-tested, CE-marked, ISI-marked power cables to connect the loads to the UPS system.
• When installing the equipment, it should ensure that the sum of the leakage current of the UPS
and the connected devices does not exceed 3.5 mA.
• UPS is designed for linear load, worst case inductive resistive load.
3-4. Operation
• Do not disconnect the mains cable on the UPS system or the building wiring outlet
(shock-proof socket outlet) during operations since this would cancel the protective earthing
of the UPS system and all connected loads.
• The UPS system features its own, internal current source (batteries). The UPS output sockets
or output terminals block may be electrically live even if the UPS system is not connected to
the building wiring outlet.
• In order to fully disconnect the UPS system, first press the OFF/Enter button to disconnect the mains.
• Prevent fluids or other foreign objects from entering the UPS system.
3-5. Maintenance, service and faults
• The UPS system operates with hazardous voltages. Repairs may be carried out only by qualified
maintenance personnel.
• Caution - Risk of electric shock. Even after the unit is disconnected from the mains
(building wiring outlet), components inside the UPS system are still connected to the battery.
They might be electrically live and dangerous.
• Before carrying out any kind of service and/or maintenance, disconnect the batteries and verify
that no current is present and no hazardous voltage exist in the terminals of high capability
capacitor such as BUS-capacitors.
• Only people adequately familiar with batteries and with the required precautionary measures
may replace batteries and supervise operations. Unauthorized persons must be kept away from
the batteries.
• Caution - Risk of electric shock. The battery circuit is not isolated from the input voltage.
Hazardous voltages may occur between the battery terminals and the ground. Before touching,
please verify that no voltage is present.
• Batteries may cause electric shock and have a high short-circuit current. Please take the
precautionary measures specified below and any other measures necessary when working
with batteries:
• Remove wristwatches, rings and other metal object
• Use only tools with insulated grips and handles
• When changing batteries, install the same number and same type of batteries.
• Do not attempt to dispose of batteries by burning them. This could cause battery explosion.
• Do not open or destroy batteries. Escaping electrolytes can be toxic and cause injury to the skin and eyes.
• Replace the fuse with the same type and amperage in order to avoid fire hazards.
• Do not dismantle the UPS system.
• Connect UPS to short-circuit protected building wiring.
• The UPS system has internal fuses on both DC & AC inputs. Those devices do not protect the
up stream cables connected to DC & AC inputs and upstream breakers or fuses shall be set up
in accordance with AC & DC wires ratings to meet the local national electrical code standard.
4

Mode Wire size in sq. mm./No. of runs Recommended input breaker
1 kVA – FM/FMI 2.5/3 16 A AC (C Curve)
2 kVA – FM/FMI 6.0/3 32 A AC (C Curve)
3 kVA – FM/FMI 10.0/3 40 A AC (C Curve)
6
RS-232 portUSB port Intelligent slot
Communication port:
1. AC input
2. Input circuit breaker
3. USB communication port
4. RS-232 communication port
5. SNMP intelligent slot (optional)
6. External battery connection
7. Output receptacles
8. Output terminal
5
1 kVA FM 2 kVA FM 3 kVA FM
1 kVA FMI 2 kVA FMI 3 kVA FMI
4. INSTALLATION AND SETUP
Note: Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. Please
keep the original package in a safe place for future use.
4-1. Rear panel view
UPS without ISO transformer
UPS with ISO transformer
4-2. Setting up the UPS
Step 1: UPS input connection
Plug the UPS into a 2-pole, 3-wire, grounded receptacle only. Please use recommended cable and breaker
for input.
Step 2: UPS output connection
• For socket-type outputs, simply connect the devices to the outlets.
• For terminal-type input or outputs, please follow the steps below, for the wiring configuration:
a) Remove the small cover of the terminal block.
b) Use AWG14 or 2.1 mm2 power cords.
c) Upon completion of the wiring configuration, please check whether the wires are securely affixed.
d) Put the small cover back to the rear panel.
Step 3: Communication connection
To allow for unattended UPS shutdown/start-up and status monitoring, connect one end of then communication
cable to the USB/RS-232 port and the other to the communication port of your PC.
With the monitoring software installed, you can schedule UPS shutdown/start-up and monitor UPS
status through a PC.
The UPS is equipped with intelligent slot for either SNMP or AS400 card. Installing either SNMP
or AS400 card in the UPS, will provide advanced communication and monitoring options.
Note: USB port and RS-232 port can’t work at the same time.

Mode Wire size in sq. mm./No. of runs Recommended input breaker
1 kVA – FM/FMI 2.5/3 16 A AC (C Curve)
2 kVA – FM/FMI 6.0/3 32 A AC (C Curve)
3 kVA – FM/FMI 10.0/3 40 A AC (C Curve)
6
RS-232 portUSB port Intelligent slot
Communication port:
1. AC input
2. Input circuit breaker
3. USB communication port
4. RS-232 communication port
5. SNMP intelligent slot (optional)
6. External battery connection
7. Output receptacles
8. Output terminal
5
1 kVA FM 2 kVA FM 3 kVA FM
1 kVA FMI 2 kVA FMI 3 kVA FMI
4. INSTALLATION AND SETUP
Note: Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. Please
keep the original package in a safe place for future use.
4-1. Rear panel view
UPS without ISO transformer
UPS with ISO transformer
4-2. Setting up the UPS
Step 1: UPS input connection
Plug the UPS into a 2-pole, 3-wire, grounded receptacle only. Please use recommended cable and breaker
for input.
Step 2: UPS output connection
• For socket-type outputs, simply connect the devices to the outlets.
• For terminal-type input or outputs, please follow the steps below, for the wiring configuration:
a) Remove the small cover of the terminal block.
b) Use AWG14 or 2.1 mm2 power cords.
c) Upon completion of the wiring configuration, please check whether the wires are securely affixed.
d) Put the small cover back to the rear panel.
Step 3: Communication connection
To allow for unattended UPS shutdown/start-up and status monitoring, connect one end of then communication
cable to the USB/RS-232 port and the other to the communication port of your PC.
With the monitoring software installed, you can schedule UPS shutdown/start-up and monitor UPS
status through a PC.
The UPS is equipped with intelligent slot for either SNMP or AS400 card. Installing either SNMP
or AS400 card in the UPS, will provide advanced communication and monitoring options.
Note: USB port and RS-232 port can’t work at the same time.

Step 4: Turn on the UPS
Press the ON/Mute button on the front panel for two seconds to power on the UPS.
Note: The battery charges fully during the first five hours of normal operation. Do not expect full battery run
capability during this initial charge period.
Step 5: Install software
tshutdown. You may insert the CD provided into the CD-ROM to install the monitoring software.
If not, please follow the on screen instructions to install the software. When your computer restarts, the
monitoring software will appear as an orange plug icon located in the system tray near the clock.
Step 6: External battery connection
This UPS series is not including batteries. Batteries are connected in a separate cabinet with protection.Please
connect external batteries as below chart.
Button Function
• Turn on the UPS: Press and hold ON/Mute button for at least 2 seconds to
turn on the UPS.
• Mute the alarm: When the UPS is on battery mode, press and hold this
button for at least 5 seconds to disable or enable the alarm system.
But it is not applied to the situations when warnings or errors occur.
ON/Mute button • Up key: Press this button to display previous selection in UPS setting mode.
Switch to UPS self-test mode: Press and hold ON/Mute button for
5 seconds to enter UPS self-testing while in AC mode, ECO mode,
or Converter mode.
• Turn off the UPS: Press and hold this button at least 2 seconds to turn off
UPS. UPS will be in standby mode under power normal or transfer to Bypass
mode if the Bypass setting is enabled by pressing
OFF/Enter button this button.
• Confirm selection key: Press this button to confirm selection in
UPS setting mode.
• Switch LCD message: Press this button to change the LCD message for
input voltage, input frequency, battery voltage, output voltage and output
frequency. It will return back to default display when pausing
for 10 seconds.
Select button • Setting mode: Press and hold this button for 5 seconds to enter UPS
setting mode when UPS is in standby mode or Bypass mode.
• Down key: Press this button to display next selection in
UPS setting mod
• Switch to Bypass mode: When the main power is normal, press ON/Mute
ON/Mute + Select and Select buttons simultaneously for 5 seconds. Then UPS will enter to
button Bypass mode. This action will be ineffective when the input voltage is out of
acceptable range.
TO EXTERNAL BATTERY
+-
7
Recommended External Breaker Rating
S. No. Rating of UPS Battery Breaker
1 1 kVA - FM/FMI 50 A DC (C Curve)
2 2 kVA - FM/FMI 50 A DC (C Curve)
3 3 kVA - FM/FMI 50 A DC (C Curve)
8
5. OPERATIONS
5-1. Button operation

Step 4: Turn on the UPS
Press the ON/Mute button on the front panel for two seconds to power on the UPS.
Note: The battery charges fully during the first five hours of normal operation. Do not expect full battery run
capability during this initial charge period.
Step 5: Install software
tshutdown. You may insert the CD provided into the CD-ROM to install the monitoring software.
If not, please follow the on screen instructions to install the software. When your computer restarts, the
monitoring software will appear as an orange plug icon located in the system tray near the clock.
Step 6: External battery connection
This UPS series is not including batteries. Batteries are connected in a separate cabinet with protection.Please
connect external batteries as below chart.
Button Function
• Turn on the UPS: Press and hold ON/Mute button for at least 2 seconds to
turn on the UPS.
• Mute the alarm: When the UPS is on battery mode, press and hold this
button for at least 5 seconds to disable or enable the alarm system.
But it is not applied to the situations when warnings or errors occur.
ON/Mute button • Up key: Press this button to display previous selection in UPS setting mode.
Switch to UPS self-test mode: Press and hold ON/Mute button for
5 seconds to enter UPS self-testing while in AC mode, ECO mode,
or Converter mode.
• Turn off the UPS: Press and hold this button at least 2 seconds to turn off
UPS. UPS will be in standby mode under power normal or transfer to Bypass
mode if the Bypass setting is enabled by pressing
OFF/Enter button this button.
• Confirm selection key: Press this button to confirm selection in
UPS setting mode.
• Switch LCD message: Press this button to change the LCD message for
input voltage, input frequency, battery voltage, output voltage and output
frequency. It will return back to default display when pausing
for 10 seconds.
Select button • Setting mode: Press and hold this button for 5 seconds to enter UPS
setting mode when UPS is in standby mode or Bypass mode.
• Down key: Press this button to display next selection in
UPS setting mod
• Switch to Bypass mode: When the main power is normal, press ON/Mute
ON/Mute + Select and Select buttons simultaneously for 5 seconds. Then UPS will enter to
button Bypass mode. This action will be ineffective when the input voltage is out of
acceptable range.
TO EXTERNAL BATTERY
+-
7
Recommended External Breaker Rating
S. No. Rating of UPS Battery Breaker
1 1 kVA - FM/FMI 50 A DC (C Curve)
2 2 kVA - FM/FMI 50 A DC (C Curve)
3 3 kVA - FM/FMI 50 A DC (C Curve)
8
5. OPERATIONS
5-1. Button operation

10
5-2. LCD panel
9
X
Remaining
Battery Info
Mode Operation Info
Input & Battery
Voltage Info
Vac
Vdc
Hz
BATT. FA U LT
LOW BATT.
OVER LOAD
SHORT
Backup Time Info
Fault
Info Mute
Operation
Load Info
Output & Battery
Voltage Info
INPUT
I/P
OUTPUT
O/P
H
M
S
Vac
Vdc
Hz
BYPASS
888 888
88
Display Function
Indicates the remaining backup time in pie chart.
Indicates the remaining backup time in numbers.
H: hours, M: minute, S: second
Indicates the warning and fault occurs.
Indicates that the UPS alarm is disabled.
Indicates the warning and fault codes.
The codes are listed in details in section 3-5.
Indicates the output voltage, frequency or battery voltage.
Vac: output voltage, Vdc: battery voltage, Hz: frequency
H
M
S
88
88
OUTPUT
Vac
Vdc
Hz
888
Remaining backup time information
Fault information
Mute operation
Output and battery voltage information
Display Function
Indicates the load level by 0-25%, 26-50%, 51-75% and 76-100%.
Indicates the load or the UPS output is short circuit.
Indicates overload.
Indicates the output is working.
Indicates the ECO mode is enabled.
Indicates the bypass circuit is working.
Indicates the inverter circuit is working.
Indicates the battery level by 0-25%, 26-50%, 51-75% and 76-100%.
Indicates the battery is faulty.
Indicates low battery level and low battery voltage.
Indicates the input voltage or frequency or battery voltage.
Vac: Input voltage, Vdc: battery voltage, Hz: input frequency
Load information
Mode operation information
Battery information
Input and battery voltage information
BATT.FAULT
LOW BATT.
OVER LOAD
SHORT
I/P
O/P
BYPASS
INPUT
Vac
Vdc
Hz
888
Indicates the UPS connects to the mains.
Indicates the battery is working.

10
5-2. LCD panel
9
X
Remaining
Battery Info
Mode Operation Info
Input & Battery
Voltage Info
Vac
Vdc
Hz
BATT. FA U LT
LOW BATT.
OVER LOAD
SHORT
Backup Time Info
Fault
Info Mute
Operation
Load Info
Output & Battery
Voltage Info
INPUT
I/P
OUTPUT
O/P
H
M
S
Vac
Vdc
Hz
BYPASS
888 888
88
Display Function
Indicates the remaining backup time in pie chart.
Indicates the remaining backup time in numbers.
H: hours, M: minute, S: second
Indicates the warning and fault occurs.
Indicates that the UPS alarm is disabled.
Indicates the warning and fault codes.
The codes are listed in details in section 3-5.
Indicates the output voltage, frequency or battery voltage.
Vac: output voltage, Vdc: battery voltage, Hz: frequency
H
M
S
88
88
OUTPUT
Vac
Vdc
Hz
888
Remaining backup time information
Fault information
Mute operation
Output and battery voltage information
Display Function
Indicates the load level by 0-25%, 26-50%, 51-75% and 76-100%.
Indicates the load or the UPS output is short circuit.
Indicates overload.
Indicates the output is working.
Indicates the ECO mode is enabled.
Indicates the bypass circuit is working.
Indicates the inverter circuit is working.
Indicates the battery level by 0-25%, 26-50%, 51-75% and 76-100%.
Indicates the battery is faulty.
Indicates low battery level and low battery voltage.
Indicates the input voltage or frequency or battery voltage.
Vac: Input voltage, Vdc: battery voltage, Hz: input frequency
Load information
Mode operation information
Battery information
Input and battery voltage information
BATT.FAULT
LOW BATT.
OVER LOAD
SHORT
I/P
O/P
BYPASS
INPUT
Vac
Vdc
Hz
888
Indicates the UPS connects to the mains.
Indicates the battery is working.

5-3. Audible alarm
Battery mode Sounds every 4 seconds
Low battery Sounds every second
Overload Sounds twice every second
Fault Sounds continuously
Bypass mode Sounds every 10 seconds
11
5-4. LCD display wordings index
Abbreviation
ENA
DIS
ESC
HLS
LLS
BAT
CF
TP
CH
FU
EE
Display content Meaning
Enable
Disable
Escape
High loss
Low loss
Battery
Converter
Temperature
Charger
Bypass frequency unstable
EEPROM error
EnA
dIS
ESC
HLS
LLS
CF
CH
FU
EE
5-5. UPS setting
12
Interface Setting
01: Output voltage setting
02: Frequency converter enable/disable
03: Output frequency setting
0 1
230
OUTPUT
Vac
02
EnACF
03
5OOCF
Hz
OUTPUT
Parameter 2 & 3: Output frequency setting. You
may set the initial frequency on battery mode:
BAT 50: presents output frequency is 50Hz.
BAT 60: presents output frequency is 60 Hz. If
converter mode is enabled, you may choose the
following output frequency:
CF 50: presents output frequency is 50 Hz.
CF 60: presents output frequency is 60 Hz.
Parameter 3: Output voltage
For 200/208/220/230/240 Vac models, you may
choose the following output voltage:
200: Presents output voltage is 200 Vac
208: Presents output voltage is 208 Vac
220: Presents output voltage is 220 Vac
230: Presents output voltage is 230 Vac (Default)
240: Presents output voltage is 240 Vac
Parameter 2 & 3: Enable or disable converter
mode. You may choose the following two options:
CF ENA: Converter mode enable
CF DIS: Converter mode disable (Default)
There are three parameters to set up the UPS.
Parameter 1: For program alternatives. Refer to table.
Parameter 2 and Parameter 3 are setting options or values for
each program.
88
888888
Parameter 1
Parameter 2 Parameter 3

5-3. Audible alarm
Battery mode Sounds every 4 seconds
Low battery Sounds every second
Overload Sounds twice every second
Fault Sounds continuously
Bypass mode Sounds every 10 seconds
11
5-4. LCD display wordings index
Abbreviation
ENA
DIS
ESC
HLS
LLS
BAT
CF
TP
CH
FU
EE
Display content Meaning
Enable
Disable
Escape
High loss
Low loss
Battery
Converter
Temperature
Charger
Bypass frequency unstable
EEPROM error
EnA
dIS
ESC
HLS
LLS
CF
CH
FU
EE
5-5. UPS setting
12
Interface Setting
01: Output voltage setting
02: Frequency converter enable/disable
03: Output frequency setting
0 1
230
OUTPUT
Vac
02
EnACF
03
5OOCF
Hz
OUTPUT
Parameter 2 & 3: Output frequency setting. You
may set the initial frequency on battery mode:
BAT 50: presents output frequency is 50Hz.
BAT 60: presents output frequency is 60 Hz. If
converter mode is enabled, you may choose the
following output frequency:
CF 50: presents output frequency is 50 Hz.
CF 60: presents output frequency is 60 Hz.
Parameter 3: Output voltage
For 200/208/220/230/240 Vac models, you may
choose the following output voltage:
200: Presents output voltage is 200 Vac
208: Presents output voltage is 208 Vac
220: Presents output voltage is 220 Vac
230: Presents output voltage is 230 Vac (Default)
240: Presents output voltage is 240 Vac
Parameter 2 & 3: Enable or disable converter
mode. You may choose the following two options:
CF ENA: Converter mode enable
CF DIS: Converter mode disable (Default)
There are three parameters to set up the UPS.
Parameter 1: For program alternatives. Refer to table.
Parameter 2 and Parameter 3 are setting options or values for
each program.
88
888888
Parameter 1
Parameter 2 Parameter 3

13
Interface Setting
Parameter 3: Enable or disable ECO function.
You may choose the following two options:
ENA: ECO mode enable
DIS: ECO mode disable (Default)
Parameter 3: Enable or disable Bypass function.
You may choose the following two options:
ENA: Bypass enable
DIS: Bypass disable (Default)
05: ECO voltage range setting
04: ECO enable/disable
06: Bypass enable/disable when UPS is off
Parameter 2 & 3: Set the acceptable high voltage
point and low voltage point for ECO mode by
pressing Down or Up key.
HLS: High loss voltage in ECO mode in Parameter
2. For 200/208/220/230/240 VAC models, the setting
range in Parameter 3 is from +7 V to +24 V of the
nominal voltage. (Default: +12 V)
LLS: Low loss voltage in ECO mode in Parameter 2.
For 200/208/220/230/240 VAC models, the setting
range in Parameter 3 is from -7 V to -24 V of the
nominal voltage. (Default: -12 V)
06
EnA
BYPASS
04
EnA
05
260HLS
Vac
INPUT
14
Interface Setting
08: Autonomy limitation setting
07: Bypass voltage range setting
Parameter 3: Set backup time on battery mode
for general outlets.
0-999: Setting the backup time in minutes from
0-999 for general outlets on battery mode.
0: When setting as ‘0’, the backup time will be
only 10 seconds.
999: When setting as ‘999’, the backup time
setting will be disabled. (Default)
Parameter 2 & 3: Set the acceptable high
voltage point and acceptable low voltage point
for Bypass mode by pressing the Down key
or Up key.
HLS: Bypass high voltage point
For 200/208/220/230/240 Vac models:
230-264: Setting the high voltage point in
Parameter 3 from 230 Vac to 264 Vac.
(Default: 264 Vac)
LLS: Bypass low voltage point
For 200/208/220/230/240 Vac models:
170-220: Setting the low voltage point in
Parameter 3 from 170 Vac to 220 Vac.
(Default: 170 Vac)
07
260HLS
Vac
INPUT
BYPASS
08
999
M

13
Interface Setting
Parameter 3: Enable or disable ECO function.
You may choose the following two options:
ENA: ECO mode enable
DIS: ECO mode disable (Default)
Parameter 3: Enable or disable Bypass function.
You may choose the following two options:
ENA: Bypass enable
DIS: Bypass disable (Default)
05: ECO voltage range setting
04: ECO enable/disable
06: Bypass enable/disable when UPS is off
Parameter 2 & 3: Set the acceptable high voltage
point and low voltage point for ECO mode by
pressing Down or Up key.
HLS: High loss voltage in ECO mode in Parameter
2. For 200/208/220/230/240 VAC models, the setting
range in Parameter 3 is from +7 V to +24 V of the
nominal voltage. (Default: +12 V)
LLS: Low loss voltage in ECO mode in Parameter 2.
For 200/208/220/230/240 VAC models, the setting
range in Parameter 3 is from -7 V to -24 V of the
nominal voltage. (Default: -12 V)
06
EnA
BYPASS
04
EnA
05
260HLS
Vac
INPUT
14
Interface Setting
08: Autonomy limitation setting
07: Bypass voltage range setting
Parameter 3: Set backup time on battery mode
for general outlets.
0-999: Setting the backup time in minutes from
0-999 for general outlets on battery mode.
0: When setting as ‘0’, the backup time will be
only 10 seconds.
999: When setting as ‘999’, the backup time
setting will be disabled. (Default)
Parameter 2 & 3: Set the acceptable high
voltage point and acceptable low voltage point
for Bypass mode by pressing the Down key
or Up key.
HLS: Bypass high voltage point
For 200/208/220/230/240 Vac models:
230-264: Setting the high voltage point in
Parameter 3 from 230 Vac to 264 Vac.
(Default: 264 Vac)
LLS: Bypass low voltage point
For 200/208/220/230/240 Vac models:
170-220: Setting the low voltage point in
Parameter 3 from 170 Vac to 220 Vac.
(Default: 170 Vac)
07
260HLS
Vac
INPUT
BYPASS
08
999
M

5-7. Operating mode description
16
15
5-6. Charging current setting
10: Charger boost voltage setting
11: Charger float voltage setting
00: Exit setting
Parameter 3: Set up the charger boost voltage.
225-240: Setting the charger boost voltage
point in Parameters from 225 to 240.
Unit: 0.01 V/CELL (Default: 236)
Parameter 3: Set the acceptable battery
minimum cut-off voltage point by pressing
the Down key or Up key.
167-190: Setting the minimum battery cut-off
voltage point in parameter 3 from 167 to 190.
Unit: 0.01 V/CELL (Default: 175)
Parameter 3: Set up the charger float voltage.
220-233: Setting the charger float voltage point
in Parameters from 220 to 233.
Unit: 0.01 V/CELL (Default: 228)
09
167bC0
Vdc
10
236Cbu
Vdc
Interface Setting
09: Battery minimum cut-off voltage setting
1 1
228CF
u
Vdc
Operating mode Description LCD display
Online mode
230230
OUTPUT
INPUT
Vac Vac
BYPASS
I/P O/P
0230
OUTPUT
INPUT
Vac Vac
I/P
CF
230230
OUTPUT
INPUT
Vac Vac
I/P O/P
230230
OUTPUT
INPUT
Vac Vac
I/P O/P
4.8
23072.0
OUTPUT
Vac
Vac
O/P
M
230230
OUTPUT
INPUT
Vac Vac
BYPASS
I/P O/P
When the input voltage is within acceptable
range, UPS will provide pure and stable AC
power to output. The UPS will also charge
the battery in online mode.
ECO mode
Energy saving mode: When the input voltage
is within voltage regulation range, UPS will
bypass voltage to output for energy saving.
Frequency
converter mode
When input frequency is within 40 Hz. to 70
Hz, the UPS can be set at a constant output
frequency, 50 Hz. or 60 Hz. The UPS will still
charge battery under this mode.
Battery mode
When the input voltage is beyond the
acceptable range or power failure and alarm
sounds every 4 seconds, UPS will backup
power from battery.
Bypass mode
When input voltage is within the acceptable
range but UPS is overloaded, UPS will enter
Bypass mode or Bypass mode can be set by
front panel. Alarm sounds every 10 seconds.
Standby mode UPS is powered off and no output supply
power, but still can charge batteries.
3 Batt. CHG (36 V 6 Batt. (72 V)/8 Batt (96 V)CHG)
J1 1 A 1 A
J2 2 A 2 A
J3 4 A 4 A
J4 (Default) 8 A 6 A

5-7. Operating mode description
16
15
5-6. Charging current setting
10: Charger boost voltage setting
11: Charger float voltage setting
00: Exit setting
Parameter 3: Set up the charger boost voltage.
225-240: Setting the charger boost voltage
point in Parameters from 225 to 240.
Unit: 0.01 V/CELL (Default: 236)
Parameter 3: Set the acceptable battery
minimum cut-off voltage point by pressing
the Down key or Up key.
167-190: Setting the minimum battery cut-off
voltage point in parameter 3 from 167 to 190.
Unit: 0.01 V/CELL (Default: 175)
Parameter 3: Set up the charger float voltage.
220-233: Setting the charger float voltage point
in Parameters from 220 to 233.
Unit: 0.01 V/CELL (Default: 228)
09
167bC0
Vdc
10
236Cbu
Vdc
Interface Setting
09: Battery minimum cut-off voltage setting
1 1
228CF
u
Vdc
Operating mode Description LCD display
Online mode
230230
OUTPUT
INPUT
Vac Vac
BYPASS
I/P O/P
0230
OUTPUT
INPUT
Vac Vac
I/P
CF
230230
OUTPUT
INPUT
Vac Vac
I/P O/P
230230
OUTPUT
INPUT
Vac Vac
I/P O/P
4.8
23072.0
OUTPUT
Vac
Vac
O/P
M
230230
OUTPUT
INPUT
Vac Vac
BYPASS
I/P O/P
When the input voltage is within acceptable
range, UPS will provide pure and stable AC
power to output. The UPS will also charge
the battery in online mode.
ECO mode
Energy saving mode: When the input voltage
is within voltage regulation range, UPS will
bypass voltage to output for energy saving.
Frequency
converter mode
When input frequency is within 40 Hz. to 70
Hz, the UPS can be set at a constant output
frequency, 50 Hz. or 60 Hz. The UPS will still
charge battery under this mode.
Battery mode
When the input voltage is beyond the
acceptable range or power failure and alarm
sounds every 4 seconds, UPS will backup
power from battery.
Bypass mode
When input voltage is within the acceptable
range but UPS is overloaded, UPS will enter
Bypass mode or Bypass mode can be set by
front panel. Alarm sounds every 10 seconds.
Standby mode UPS is powered off and no output supply
power, but still can charge batteries.
3 Batt. CHG (36 V 6 Batt. (72 V)/8 Batt (96 V)CHG)
J1 1 A 1 A
J2 2 A 2 A
J3 4 A 4 A
J4 (Default) 8 A 6 A

5-8. Fault reference codes
17
5-9. Warning indicator
Warning Icon (flashing) Alarm
Low battery Sounds every second
Overload Sounds twice every second
Battery is not connected Sounds every second
Overcharge Sounds every second
Over temperature Sounds every second
Charger failure Sounds every second
Battery fault Sounds every second
Out of Bypass voltage range Sounds every second
Bypass frequency unstable Sounds every second
EEPROM error Sounds every second
OVER LOAD
BATT.FAULT
LOW BATT.
BYPASS
CH
FU
EE
OVER LOAD
SHORT
Fault event Fault code Icon Fault event Fault code Icon
BUS start fail 01 x Inverter voltage low 13 x
BUS over 02 x Inverter output short 14
BUS under 03 x Battery voltage too high 27 x
BUS unbalance 04 x Battery voltage too low 28 x
Inverter soft start fail 11 x Temperature overload 41 x
Inverter voltage high 12 x Overload 43
Charger fail 45 x
18
6. TROUBLE SHOOTING
If the UPS system does not operate correctly, please solve the problem by using the table.
Symptom
No indication and alarm even
though the mains is normal.
The AC input power is not
connected well.
The AC input is connected
to the UPS output.
Plug AC input power cord to
AC input correctly.
Check if input power
cord firmly connected
to the mains.
The external or internal
battery is incorrectly
connected.
Check if all batteries
are connected well.
Battery voltage is too high
or the charger is faulty.
Contact your dealer.
Battery voltage is too low
or the charger is faulty.
Contact your dealer.
Remove excess loads
from UPS output.
Remove excess loads
from UPS output.
Remove excess loads
from UPS output first.
Then shut down the UPS
and restart it.
The UPS shutdown
automatically because of
overload at the UPS output.
Remove excess loads
from UPS output and
restart it.
The UPS shutdown
automatically because
short circuit occurs on
the UPS output.
Check output wiring and
if connected devices are
in short circuit status.
After repetitive overloads,
the UPS is locked in the
Bypass mode. Connected
devices are fed directly by
the mains.
UPS is overloaded. Devices
connected to the UPS are
fed directly by the electrical
network via the Bypass.
Possible cause Remedy
The icons and flashing on
LCD display and alarm is sounding
every second.
The icons and is
flashing on LCD display and alarm
is sounding twice every second.
OVER LOAD
OVER LOAD
Fault code is shown as 43, the icon
is lighting on LCD display and
alarm is sounding continuously.
Fault code is shown as 27 and the
icon is lighting on LCD display
and alarm is sounding continuously.
BAT T, FAULT
BAT T, FAULT
Fault code is shown as 28 and the
icon is lighting on LCD display
and alarm is continuously sounding.
Fault code is shown as 14 and the
icon is lighting on LCD display
and alarm is sounding continuously.
SHORT
UPS is overloaded.

5-8. Fault reference codes
17
5-9. Warning indicator
Warning Icon (flashing) Alarm
Low battery Sounds every second
Overload Sounds twice every second
Battery is not connected Sounds every second
Overcharge Sounds every second
Over temperature Sounds every second
Charger failure Sounds every second
Battery fault Sounds every second
Out of Bypass voltage range Sounds every second
Bypass frequency unstable Sounds every second
EEPROM error Sounds every second
OVER LOAD
BATT.FAULT
LOW BATT.
BYPASS
CH
FU
EE
OVER LOAD
SHORT
Fault event Fault code Icon Fault event Fault code Icon
BUS start fail 01 x Inverter voltage low 13 x
BUS over 02 x Inverter output short 14
BUS under 03 x Battery voltage too high 27 x
BUS unbalance 04 x Battery voltage too low 28 x
Inverter soft start fail 11 x Temperature overload 41 x
Inverter voltage high 12 x Overload 43
Charger fail 45 x
18
6. TROUBLE SHOOTING
If the UPS system does not operate correctly, please solve the problem by using the table.
Symptom
No indication and alarm even
though the mains is normal.
The AC input power is not
connected well.
The AC input is connected
to the UPS output.
Plug AC input power cord to
AC input correctly.
Check if input power
cord firmly connected
to the mains.
The external or internal
battery is incorrectly
connected.
Check if all batteries
are connected well.
Battery voltage is too high
or the charger is faulty.
Contact your dealer.
Battery voltage is too low
or the charger is faulty.
Contact your dealer.
Remove excess loads
from UPS output.
Remove excess loads
from UPS output.
Remove excess loads
from UPS output first.
Then shut down the UPS
and restart it.
The UPS shutdown
automatically because of
overload at the UPS output.
Remove excess loads
from UPS output and
restart it.
The UPS shutdown
automatically because
short circuit occurs on
the UPS output.
Check output wiring and
if connected devices are
in short circuit status.
After repetitive overloads,
the UPS is locked in the
Bypass mode. Connected
devices are fed directly by
the mains.
UPS is overloaded. Devices
connected to the UPS are
fed directly by the electrical
network via the Bypass.
Possible cause Remedy
The icons and flashing on
LCD display and alarm is sounding
every second.
The icons and is
flashing on LCD display and alarm
is sounding twice every second.
OVER LOAD
OVER LOAD
Fault code is shown as 43, the icon
is lighting on LCD display and
alarm is sounding continuously.
Fault code is shown as 27 and the
icon is lighting on LCD display
and alarm is sounding continuously.
BAT T, FAULT
BAT T, FAULT
Fault code is shown as 28 and the
icon is lighting on LCD display
and alarm is continuously sounding.
Fault code is shown as 14 and the
icon is lighting on LCD display
and alarm is sounding continuously.
SHORT
UPS is overloaded.
