Leisure Concepts Smartop Upright 2.0 User manual

Installation Instructions - Updated as of 04/23/19
Page 1
Smartop Upright 2.0 190423
Upright 2.0
Figure 2
Figure 3
Step #1
Position the Smartop (in closed position) on the spa making sure that all four
corners are properly postioned and square on the spa.
Step #3
Slide the rear mounting bracket over the exposed tube attached to the Smartop
cover (see Fig. 2). Attach the rear mounting brackets to the rear panel on the spa
using the supplied #10 x 1-1/2” mounting screws (see Fig. 3).
Rear Mounng
Bracket
Mounng Screws
Figure 4
Side
Mounng Bracket
Step #5
Attach the ball stud to the side mounting bracket. Next, attach the side
mounting brackets to the side of the spa, directly underneath the acrylic,
using the supplied #10 x 1-1/2” mounting screws (see Fig. 4). Note: Make sure the
center of the ball stud is 3-1/4” in from the back of the spa.
Step #6
Gently raise the Smartop into the upright position making sure to keep a firm
grip on the cover and attach the shocks to the ball studs (see Fig. 4). Note:
When attaching the shocks, make sure the body of the shock is on top.
Rubber
Bumper
Step #4
Attach the rubber bumpers to the rear mounting brackets using the supplied
#10 x 1” self-tapping screws (see Fig. 2).
Step #7
Attach the side tub lock cable assembly to the pre-installed tub lock bracket on
the side of the aluminum trim on the Smartop and turn the knob to lock it in
place. Next, apply downward pressure on the Smartop and mark where the
tub lock assembly needs to be attached to the spa cabinet. Unlock and remove
the side tub lock cable assembly from the tub lock bracket on the Smartop.
Attach the tub lock assembly triangle plate to the spa cabinet using the supplied
#8 x 3/4” philips flat head screws (black). Note: Do not overtighten the screws
when attaching to the spa cabinet. Swing the tub lock assembly cable up and
re-attach to the tub lock assembly bracket on the Smartop and lock it in place.
Note: Do not cover the service panel with the side tub lock assembly (see Fig. 5 & 6
for complete look).
Figure 1
EAS Bracket
EAS Handle Buon Head
Socket Bolt
Step #2
Attach the EAS handle to the EAS bracket using the supplied 5/16 x 1-1/4”
button head socket bolt (see Fig. 1).
GH
A
F
J
B
Shock
L
Ball
Stud
C

Figure 6
Page 2
CAUTION! Do not use the Smartop in high wind conditions. Injury from the spa cover being blown over
and impacting the spa user can occur.
For additional information on our Smartop product, please visit our website: “www.smartopspacover.com”
Smartop Upright 2.0 190423
Figure 5
B
Press down to
compress thermal
seal when installing
lock-down straps
Step #8
If the thermal seal on the underside of the Smartop does not completely
seal around the control panel of your spa, an additional thermal seal control
pad has been included with the Smartop. Close the Smartop and determine
the position of the thermal seal pad. Open the Smartop cover onto itself, dry
thoroughly and remove the backing of the thermal seal pad and attach it to
the underside of the Smartop in the desire position (see Fig. 7).
Operation of your Smartop Cover
1) Fold the first half of the Smartop cover off the spa. While gripping the
EAS handle, motion the Smartop cover into it’s vertical upright position.
Aach to
Sides
of Spa
Side Tub Lock
Assembly
(Front of Spa)
N
Thermal Seal
Control Pad Control Panel
Q
ITEM PART# DESCRIPTION QTY
A(L) 101725 ST UPRIGHT 2.0 REAR MOUNTING BRACKET (L) 1
A(R) 101726 ST UPRIGHT 2.0 REAR MOUNTING BRACKET (R) 1
B 101727 ST UPRIGHT 2.0 SIDE MOUNTING BRACKET 2
C 100244 5/16 BALL STUD 2
D 100032 5/16 NYLON LOCKNUT 2
E 101729 PLASTIC BUSHING 2
F 101728 RUBBER BUMPER 2
G 101596 EAS HANDLE 2
H 101751 5/16 X 1-1/4" BUTTON HEAD SOCKET SCREW - BLACK ZINC 2
I 101753 #8 X 3/4" PHILIPS PAN HEAD SELF-TAPPING SCREW 2
J 100909 #10 X 1-1/2" PHILIPS PAN HEAD MOUNTING SCREW 44
K 100016 SMALL BLACK DOME CAPS 44
L 101754 SHOCK - 120 LB 2
M 101748 #10 X 1" PHILIPS PANCAKE SELF-TAPPING SCREW (BLACK ZINC) 2
N 101056 SIDE TUB LOCK ASSEMBLY 4
O 101065 #8 X 3/4" PHILIPS FLAT HEAD SCREW (BLACK ZINC) 12
Q 101079 THERMAL SEAL CONTROL PAD 1
R 101078 LOCK 1
Side Tub Lock
Assembly
(Rear of Spa)
N
Figure 7
