OPERATION
SWITCHING ON/OFF THE UNIT
Switch on the unit by pressing any button
(except REL button (7) and EJECT
button (4)). When system is on, press
PWR button (9) to turn off the unit.
FACEPLATE RELEASE
Press REL button (7) to detach the
removable faceplate.
SOUND ADJUSTMENT
Press SEL button (10) shortly to select
the desired adjustment mode.
The adjustment mode will change in the
following order:
By pressing the AUDIO SELECT
button (11) or AUDIO SELECT
button (12), it is possible to adjust the
desired sound quality.
Press SEL Button (10) for several
seconds, it is activated as cyclical
mode of following functions for user’s
selection.
a) TA SEEK or TA ALARM
- TA SEEK mode:
When newly tuned station does not
receive TP information for several
seconds, the radio retunes to next
station which has not the same
station (PI) as the last station, but
has the TP information.
When TP information gets lost at
the current station for retune time
which is set by RETUNE SHORT
(30 sec.) or RETUNE LONG (90
sec.), the radio start to retune to
next same PI station.
When same PI station does not
catch in 1 cyclic search, the radio
retunes to next station with TP
information.
-TA ALARM mode:
When this mode is selected, any
automatic retune mode is not
activated. Only double beep sound
(ALARM) is output.
When newly tuned station does not
have TP information for several
seconds, beeps come out.
When TP information gets lost at
the current station for retune time,
the beep sound is out-putted.
When newly tuned station has not
RDS signal, “PI SEEK” is
suppressed somewhat.
b) PI SOUND or PI MUTE
While AF switching is implemented
in C201 station, AF can switch to
100 MHz, which is non genuine AF
(where, different PI with same AF) in
short “DIP”.
If a car cruises that critical area back
and forth, an oscillation
phenomenon can be occurred,
because the different PI code can
be received from 100 MHz with
“XXX” PI.
The car radio has special procedure
to reduce even this kind of
unavoidable situation however there
is a limit to be escaped from this
serious case perfectly.
In that serious case, 2 mode is
selectable as follows:
- PI SOUND mode:
When above different PI sound
(DIP) is heard once in a while, the
DIP’s sound will be heard for a
short time.
- PI MUTE mode:
Under above same situation, a
mute sound will be heard for a
short time.
VOL BAS TRE BAL FAD
(Volume) (Bass) (Treble) (Balance) (Fader)
TA SEEK or ALARM PI SOUND or MUTE
MASK DPI or ALL RETUNE L or S
BEEP 2’nd, ALL or OFF
100 90
98
100
PI : C201 PI : XXX
GB-9
