LENCO Xemio-154 User manual

Xemio-154
User Manual
User manual Sport MP3 Player with Micro SD Card of 4GB

SRO1059 / 1061 / 1062
2
IMPORTANT:
Read all instructions carefully before using this product. Retain this
owner’s manual for future reference.
Cautions
•Do not place on or near naked flames, such as lit candles.
•Do not place objects filled with liquids such as vases on or near the
product.
•Do not use or store this product in a place where it is subject to direct
sunlight, heat, excessive dust or vibration.
•Do not use this product with wet hands.
•Do not clean this product with water or other liquids.
•Do not block or cover the slots and holes in the product.
•Do not push foreign objects into the slots or holes in the product.
•Do not attempt to open this product yourself. There are no user
serviceable parts inside.
•Do not allow children access to the packaging including plastic bags.
Safety Warnings
•Before using this product, read and follow all warnings and
instructions.
•This product is not intended for use by young children. Young children
should be properly supervised.
•This product is intended for household use only and not for
commercial or industrial use.
•Do not expose to dripping or splashing liquid.
•No naked flame sources, such as lit candles, should be placed near
the product.
•Ventilation should not be impeded by covering ventilation openings
with items such as newspapers, table cloths, curtains and the like.
•Damage caused by using this product by failure to follow any other
warning or precaution contained within this user manual will not be
covered by warranty.
Note: Dispose of this product responsibly.
WARNING: When Driving in the traffic listening to a personal
music player can make the listener less aware of potential
dangers such as approaching cars and emergency vehicles.
WARNING: To prevent possible hearing damage, do not
listen at high volume levels for long periods.

SRO1059 / 1061 / 1062
3
A. Key Navigation and Connection
No.
Description
Function
Clip
Micro USB Port
For PC connection/Charge
Status LED Indicator
(Red and Blue)
For charging and play status
Button
On/Off, Play/Pause,
Button
Back Track/Fast-Backward
Button
Next Track/Fast-Forward
Button
Volume down
Button
Volume up
Earphone Output Jack
3.5mm earphone connection
Reset (Bulit-in tact switch)
For hardware reset
Memory Card Slot
Under the Silicon Cover
4
1
2
3
5
6
7
8
9
10
11

SRO1059 / 1061 / 1062
4
B. Insert Micro SD Memory Card (not included)
This device is design without an internal memory; before you use it,
insert a Micro SD memory card into player.
1. Turn “Off” the play;
2. Open the silicon cover and then insert the memory card into the
player’s memory card slot; make sure the memory card is firmly and
correctly inserted. Then close the silicon cover back to position.
3. Now you can use the player for upload/download the desired media
files with your PC computer.
4. Or, Upload the desired media files direct to the Micro SD memory
card direct with your computer before insert it into player.
5. However, the device will turn to OFF automatically in few seconds if
Micro SD card not in place or not in proper position.
Note: Make sure the player power is in “Off” status when insert/remove
the Micro SD memory card from memory card slot. Otherwise, the player
functional may result dead halt or the internal data/files will be
lost/damaged.
C. About player’s battery
The Player has an internal, non-user-replaceable rechargeable lithium
battery. For best results, the first time you use the player, let it charge for
about 2 ~ 3 hours or until the charging LED shows a constant red light.
Important: The player may continue to use battery power after it’s been
turned to standby off mode, if the unit isn’t used for a while it will need to
be recharged. For longevity of the lithium battery life, we recommended
to recharge the battery at least once per month.
D. Charging Mode
You can recharge the Player’s battery in two ways:
1. Connect the player to your computer. Or,
2. Use a USB power wall charger. (not included)
3. The Status LED will blink red when the USB power source is
connected.
4. When the battery is fully charged, the Status LED will switch to a
constant red light.
E. PC Connection Mode
1. Connect the player to a computer
1.1 Connect the player to a Windows OS computer with the USB
cable, then “USB Mass Storage Device” is detected and the
related driver is installed by your computer. A removable disk
drive will display in the “My computer” folder where the user can
operate Read and Write functions. And the battery will charge in

SRO1059 / 1061 / 1062
5
the background. (for Windows 2000/XP System or above)
1.2 Or, connect the player with a MAC OS computer, then an
“Untitled” icon will display on the desktop indicating the player is
a removable disk, the user can operate Read and Write functions.
And the battery is charging in the background. (For Mac System
9.2 or above)
Note: In USB power charger or PC connection mode, the player can go to
eject mode, press the button to eject from PC connection mode for
start the music playback if you wish.
2. Remove the player from a computer:
2.1 If you’re using a Windows OS PC, you can disconnect the player in
My Computer or by clicking the “Safely Remove Hardware” icon
in the Windows system tray.
2.2 If you’re using a Mac OS PC, you can also disconnect player by
dragging the player icon on the desktop to the Trash.
2.3 Once it is safe to disconnect the player with your computer,
unplug the USB connector from player and then your computer.
2.4 If you accidentally disconnect the player without disconnecting
correctly, reconnect it to your computer.
Note: Please safely remove the player when connected to the computer,
otherwise, the transferring data stored in the Player might be lost.
F. Getting Started
1. Power On/Off
1.1 Plug-in the earphone set into the player’s earphone output jack;
1.2 Press and hold the button, until the Status LED lights up in
blue, to power On the player.
1.3 The blue light will switch to blinking and then the music will play
automatically.
1.4 To turn Off the Player; press and hold the button until the
status LED light blinks fast and then the Player will switch Off in
seconds later.
Note: If any unsupported music files are added to the player’s memory;
the status indicator light will flash fast and then will go Off, and the player
will turn Off automatically a few seconds after.
2. Play/Pause Music
2.1 Press the button to pause the playing music.
2.2 Press it again to resume playback.
2.3 If player is in a pause state for 3 minutes, it will turn to standby
Off mode automatically.
3. Adjusting the Volume
3.1 Pressing the / button will increase or decrease the volume
level one step at a time.

SRO1059 / 1061 / 1062
6
3.2 Press and hold the / button to increase or decrease volume
level continuously.
3.3 For hearing protection; a beep warning will be heard from the
earphones every time you increase the volume level and reach
the default setting level which may exceed 85dB. Press the
button to accept the warning and the user can continue to
increase the volume level until the maximum level is reached.
4. Play Next/Previous Music
4.1 In music playing mode;
4.2 Press the button to play next track.
4.3 Press the button to play previous track.
5. Play Fast-Forward/Fast-Backward
5.1 Press and hold the button to enter fast-forward mode.
5.2 Press and hold the button to enter fast-backward mode.
6. Shuffle
6.1 During playback, press the button twice to activate the
shuffle and hear two beeps signal to confirm.
6.2 Press the button twice again to deactivate the shuffle and
hear tone beep signal to confirm.
G. LED Light Function
•Playing mode
:
Blue light blinking once per second.
•Pause mode
:
Blue light constant bright.
•PC connecting mode
:
Blue light blinking fast when data is
transferring.
:
Red light blinking once per second. (In
charging)
•In charging Mode
:
Red light blinking once per second. (In
charging)
•Charging completed
:
Red light constant bright.
•Low battery < 20%
:
Red light blinking.
H. Reset the Player
In some circumstances, the device may encounter technical issues during
use. This device has been designed with a built-in a mini tact switch
through a hole which located on the right side of the device.
To Reset:
1. Use a 0.8 ~ 1 mm stick or similar object (like a toothpick), and
carefully insert into the reset hole.
2. Apply a small bit of force and you will get a click sound and feeling
from the switch. The device is reset and will restart.
Important: Do not reset the device if it is proper working.

SRO1059 / 1061 / 1062
7
I. Troubleshooting
Player cannot turn ON
•Check whether the battery has enough
energy.
•Charge the battery.
No sound is heard
•Check whether the Volume is set to
“minimum” and connect the headphone plug
firmly.
•Check whether the headphone plug is dirty.
•Corrupted WMA/MP3 files may make a static
noise and the sound may cut off. Make sure
that the music files are not corrupted.
•Check whether music file formats are
supported.
Upload/Download of
music files fail.
•Check whether the player’s USB connector is
connected with the computer properly.
•Check whether the driver is installed
correctly.
•Check whether the player’s memory is full.
J. Technical Specifications
Dimension
50 mm (H) x 33 mm (W) x 17 mm (D)
Weight
14.5g (approximate)
PC Connection
USB 2.0 (High Speed)
Earphone Impedance
32 Ohm
Memory Card Slot
For Micro SD Memory Card
(Support up to 32GB and 64GB possible)
Power Source
DC Input: DC 5V 500mA
Rechargeable Battery
Lithium-Polymer: 3.7V 110mAh
Playing Time: 5 ~ 6 hours
Supports Music Format
MP3
32kbps - 320kbps
WMA
32kbps - 320kbps
Audio
Earphone Output
2mW x 2 channels (at 32
Ohm)
Freq. Response
20Hz - 20,000Hz
SNR
80dB
Operation Temperature
0°C - 40°C
Operation Systems
Windows 2000/XP/Vista/Win7/Win8/Win10
MAC 9.2 or above
K. Disclaimer
Updates to Firmware and/or hardware components are made regularly.
Therefore some of the instruction, specifications and pictures in this
documentation may differ slightly from your particular situation. All items

SRO1059 / 1061 / 1062
8
described in this guide for illustration purposes only and may not apply to
particular situation. No legal right or entitlements may be obtained from
the description made in this manual.
L. Recycling
This symbol indicates that the relevant electrical
product or battery should not be disposed of as general
household waste in Europe. To ensure the correct
waste treatment of the product and battery, please
dispose them in accordance to any applicable local
laws of requirement for disposal of electrical
equipment or batteries. In so doing, you will help to
conserve natural resources and improve standards of
environmental protection in treatment and disposal of
electrical waste (Waste Electrical and Electronic
Equipment Directive).
M. CE Marking
Products with the CE marking comply with the EMC
Directive (2014/30/EU) and the Low Voltage Directive
(2014/35/EU) issued by the Commission of the
European Community.
N. Service
For more information and helpdesk support, please visit www.lenco.com
Lenco Benelux BV, Thermiekstraat 1a, 6361 HB Nuth, The Netherlands.
