LENCO DVP-9412 User manual

Before connecting, operating or adjusting this product,
please read this user's manual carefully and completely.
USER'S MANUAL
DVP-9412
WWW.LENCO.COM
PORTABLE DVD

Warning: To reduce the risk of electric shock, do not remove
the cover or back. There are no user-serviceable parts
inside. Refer servicing to qualified personnel.
Warning: To prevent fire or electric shock hazard, do not
expose the unit to rain or moisture.
Do not expose the Adaptor and portable DVD to water
(dripping or splashing) and no objects filled with liquids,
such as vases, should be placed on the unit.
Keep the portable DVD away from direct sunlight and heat
source such as radiators or stoves.
Do not block the ventilation openings. Slots and openings on
the unit are provided for ventilation. The openings should
never be blocked by placing your portable DVD on a cushion,
sofa or other similar surface.
Do not place the portable DVD on unstable cart, stand,
tripod, bracket or table. The unit may fall, resulting in
possible damage or injury.
Never place heavy or sharp objects on the LCD panel or
frame.
Only use the AC adapter included with portable DVD. Using
any other adapter will void your warranty.
The plug of AC adaptor is used as the disconnect device, the
disconnect device shall remain readily operable.
Unplug the power from the outlet when the unit is not in use.
Attention should be drawn to the environmental aspects of
battery disposal.
This marking indicates that this product should
not be disposed with other household wastes
throughout the EU. To prevent possible harm to
the environment or human health from
uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse
of material resources. To return your used
device, please use the return and collection
systems or contact the retailer where the
product was purchased. They can take this
product for environmental safe recycling.
1
Important Safety Instructions
CAUTION: Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent type.
WARNNING: The battery (battery or batteries or battery
pack) shall not be exposed to excessive heat such as
sunshine, fire or the like.
WARNNING: Excessive sound pressure from earphones or
headphones can cause hearing loss.
WARNNING: Only use attachments/accessories specified
provided by the manufacturer, the portable DVD is supplied
by AC adapter, the AC adapter is used as disconnect device,
the disconnect device shall remain readily operable.
Caution: Danger of explosion if battery is incorrectly
replaced, replaced only with the same or equivalent type
(Lithium battery)
Power supply adaptor
Manufacturer：Shenzhen Mass Power Electronics Limited
Model number: EFF0900150E1BA
Use only the power supply listed in the user instructions

NNotes on Copyrights:
It is forbidden by law to copy, broadcast, show,broadcast via
cable, play in public, or rent copyrighted material without
permission.
This product features the copy protection function developed by
Macrovision.Copy protection signals are recorded on some discs.
When recording and playing the pictures of these discs picture
noise will appear.This product incorporates copyright protection
technology that is protected by method claims of certain U.S.
Patents and other intellectual property rights owned by Macrovision
Corporation and other rights owners.Use of this copyright protection
technology must be authorized by Macrovision Corporation, and is
intended for home and other limited viewing uses only unless
otherwise authorized by macrovision Corporation. Reverse
engineering or disassembly is prohibited.
SERIAL NUMBER:
You can find the serial number on the back of the unit.This number
is unique to this unit and not available to others.You should record
requested information here and retain this guide as a permanent
record of your purchase.
Model No. ______________________________
Serial No. ______________________________
Date of Purchase_________________________
2
Safety Precautions
N
Warning: when the unit using by child, parents must make sure
to let the child understand all contents in Instruction book how
battery using to guarantee using battery correctly all the time.
Warning: when find battery overheat, swell or dour, please
stop using battery and contact service centre for getting
replacement.
Warning: do not charging battery on the place of insufficient
ventilation such as: mattress, sofa, cushion , soft mat......
Warning: we will not take any responsibility if user incorrectly
use battery, not following our warning instruction label on the
battery case.
Warning: more than 250mm USB extension cord is prohibited
to use for USB port
Warning: This digital video disc player employs a laser system.
Use of controls,adjustments, or the performance of procedures
other than those specified herein may result in hazardous
radiation Exposure.
Warning: To prevent direct exposure to laser beam,do not open
the enclosure.Visible laser radiation when open.
Warning: Never stare directly into the laser beam.
Caution: Do not install this product in a confined space such
as a book case or similar unit.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING
charge
over
heat
40 C
strong
impact

Identification of Controls
Main Unit
3
1.PLAY/PAUSE
2.STOP
3.SOURCE
4.VOL-
5.VOL+
6.MENU
7.▲/▼/◄/►(up/down/right/left)
Select an item in the menu.OK key confirms menu selection.
when playing,VCD,DVD,if available:
right: fast forward
left: fast reverse
up: previous track
down: next track
8.ENTER
9.OPEN
10. SETUP
11. SD/MMC
12. USB
13. AV OUT
14. Earphone Socket
15. COAXIAL
16. ON/OFF
17. DC IN 9-12V
18. ANT
19.
HDMI (only in TV mode, not in DVD mode)
11
12
18
13
19
14
15 17
16
7
8
9
10
180°
SOURCE
VOL- VOL+ MENU
SETUP
1
2
3
6
5
4

4
Remote control unit
Identification of Controls
1. SOURCE
DVD/CARD/USB.
3.0-9 NUMBER BUTTON
Selects numbered items in a menu.
4.INFO
To display the playtime and status information.
2. MUTE
Disable Audio output.
5.10+ RECALL
In order to select a track 10 or greater, first press 10+, For example;
select track 12, first press 10+, and then press number 2 button.
6. PBC/FAV
PBC on/off switch (VCD) .
7.AUDIO
Press AUDIO repeatedly during playback to hear a different
audio language or audio track, if avilable.
Press AUDIO repeatedly during playback to
hear a different audio channel ( Left,Right,Mix,Stereo).
DVD
VCDCD
10. STEP/TV/RADIO
Step the motion in DVD mode.
14. BUTTON
Press BUTTON allow skipping ahead at 5-level speed(X2->X4->
X8->X16->X32->PLAY), press PLAY button return to normal playback.
8.PLAY/PAUSE
Press PLAY/PAUSE once to pause playback, pressing PLAY/
PAUSE second time will resume the playback.
13.Reverse Skip
Go to previous chapter/ track to the beginning.
12.Forward Skip
Go to next chapter/ track.
9.STOP
When this buttom is pressed once, the unit records the stopped
point,from where playback will resume if PLAY( )is pressed after
wards. But if STOP button is pressd again instead of PLAY( )
button, there will be no resume function.
11.VOL+
Adjust volume
1 2 34
56 7 8
9 0
SETUP
OK
STEP/
TV/RADIO
SUBTITLE
AUDIO
MUTE
SOURCE
VOL+VOL-
SLOW
/EXIT
ZOOM
INFO
REPEAT
PROGRAM
ANGLE
10+
/RECALL
PBC
/FAV
TITLE
16
17 2
1
3
4
5
6
7
8
9
10
11
12
13
14
15
27
26
25
22
23
24
21
20
18
19

Identification of Controls
5
Remote control unit
23.VOL-
Adjust volume
17.SEARCH
Goto time point , title or chapter you want in DVD Mode.
15. BUTTON
Press BUTTON allow skipping back at 5-level speed(X2->X4->
X8->X16->X32 PLAY), press PLAY button return to normal playback.->
16.
Turn on/off the power.
22.SETUP
Accesses or removes setup menu.
18.SUBTITLE
Press SUBTITLE repeatedly during playback to see a different
subtitle languages.
20.TITLE
Return to DVD title menu
21.OK
Confirms menu selection..
24.REPEAT
Press REPEAT during playback to select a desired repeat mode.
: you can play select repeat chapter/title/all.
DVD
: you can select repeat shuffle/random/single/repeat one/
repeat folder/folder.
VCD : you can select repeat track/all. CD
MP3
19.ANGLE
:Press ANGLE will change the view angle, on DVDs that
support this feature.
DVD
25.SLOW
Press Slow button repeatedly to enter slow playback, and cycle
between different speeds. The speeds are 1/2,1/4,1/8,1/16,and
normal.
26.PROGRAM
:The program function enables you to store
your favourite tracks from the disc. Press PROGRAM button ,then
PROGRAM MENU will appear on screen, now you can use the
number key to direct input the titles,chapters or tracks number and
select PLAY option. TO resume normal playback, press PROGRAM
and select clear program option on the program menu,press
PROGRAM again to exit program menu,Mp3 has function Folder/
File list..
DVD VCD
: Use ZOOM to enlarge or shrink the video image.
1.Press ZOOM during playback or still playback to activate the
Zoom function. The square frame appears briefly in the right bottom
of the picture.
2. Each press of the ZOOM button changes the TV screen in the
following sequence:
: Use ZOOM to enlarge or shrink the picture.
1.Press 'ZOOM' .
2,Used " " to enlarge,or " " to shorten the picture.
Use the button to move through the zoomed picture.
DVD VCD
JPEG
27.ZOOM
CD

SETUP Menu Setting
General Setup Page
6
Angle Mark
Displays current angle setting information on the right hand corner
of the TFT screen if available on the disc.
OSD Language
You can select your own preferred language settings.
Closed Captions
Closed captions are data that are hidden in the video signal of some
discs.Before you select this function,please ensure that the disc
contains closed captions information and your TV set also has this
function.
Screen Saver
This function is used to turn the screen saver On or Off.
Audio Setup Page
Audio Setup Page
Press SETUP button to get the setup menu. Use direction buttons
to select the preferred item. After finishing settings, press
SETUP again to normal display.
The following menu items can be changed:
GENERAL: selects the GENERAL PAGE menu.
AUDIO: selects the AUDIO PAGE menu.
VIDEO: selects the VIDEO PAGE menu.
PREFERENCE : selects the PREFERENCE PAGE menu.
General Setup Page
- - GENERALSETUP PAGE - -
GOTO GENERAL SETUP PAGE
TV DISPLAY WIDE
ANGLE MARK ON
OSD LANGUAGE ENG
CLOSED CAPTIONS ON
SCREEN SAVER ON
4:3 PANSCAN
4:3 LETTERBOX
16:9
TFT 16:9
TFT 4:3
ENGLISH
FRENCH
GERMAN
SPANISH
DUTCH
ON
OFF
ON
OFF
TV DISPLAY: selects the aspect ratio of the playback picture.
4:3 PANSCAN: if you have a normal TV and want both sides of the
picture to be trimmed or formatted to fit your TV screen.
4:3 LETTERBOX: if you have a normal TV. In this case, a wide
picture with black bands on the upper and lower portions of the TV
screen will be displayed.
16:9:wide screen display.
-- --
DOWNMINX STR
DIGITAL OUTPUT RAW
DOLBY DIGITAL
LT/RT
STEREO
SPDIF/OFF
SPDIF/RAW
SPDIF/PCM
DUAL MONO
DYNAMIC
STR STR
L-MONO
R-MONO
MIX-MONO
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
FULL
OFF
-
- - - -AUDIO SETUP PAGE
GO TO AUDIO SETUP PAGE
AUTO STANDBY
3H
oFF
3 HOUR
4 HOUR
Auto Standby
This function is used to
standby.
TFT DISPLAY 16:9
TFT DISPLAY
selects the aspect ratio during playback.
HUNGARIAN
POLISH

SETUP Menu Setting
7
Video Setup Page
Video Setup Page
- - VIDEO SETUP PAGE - -
GOTO VIDEO SETUP PAGE
SHARPNESS MID
BRIGHTNESS 00
CONTRAST 00
HUE 00
SATURATION 00
HIGH
MEDIUM
LOW
Sharpness,Brightness,Contrast,Hue,Saturation:setting the video
quality.
Preference Page
Preference Page
- - PREFERENCE SETUP PAGE - -
GOTO PREFERENCE PAGE
TV TYPE PAL
AUDIO ENG
SUBTITLE ENG
DISC MENU ENG
DEFAULT
PAL
AUTO
NTSC
RESET
TV Type
Selecting the colour system that corresponds to your TV when AV
outputs.This DVD Player is compatible with both NTSC and PAL.
Downmix
This options allows you to set the stereo analog output of your
DVD Player.
LT/RT :Select this option if your DVD Player is connected to a
Dolby Pro Logic decoder.
Stereo :Select this option when output delivers sound from only
the two front speakers.
Digital Output
The function is used to select the SPDIF Output:SPDIF Off,SPDIF
/RAW,SPDIF/PCM.
SPDIF Off: Turns off the SPDIF output.
SPDIF/RAW: If you have connected your DIGITAL AUDIO OUT
to a multi-channel decoder/receiver.
SPDIF/PCM: Only if your receiver is not capable of decoding
multi-channel audio.
Dolby digital
The options included in Dolby Digital Setup are: 'Dual Mono ' and
'Dynamic '.
Dual Mono
Stereo:Left mono sound will send output signals to Left speaker
and Right mono sound will send output signals to Right speaker.
L-Mono:Left mono sound will send output signals to Left speaker
and Right speaker.
R-Mono:Right mono sound will send output signals to Left speaker
and Right speaker.
Mix-Mono:Left and Right mixed mono sound will send output
signals to Left and Right speakers.
Dynamic
Dynamic range compression.
Audio Setup Page
OFF
OTHERS
ENGLISH
FRENCH
GERMAN
SPANISH
DUTCH
POLISH
HUNGARIAN
OTHERS
ENGLISH
FRENCH
GERMAN
SPANISH
DUTCH
POLISH
HUNGARIAN
ENGLISH
FRENCH
GERMAN
SPANISH
DUTCH
POLISH
HUNGARIAN
OTHERS

SETUP Menu Setting
PAL - Select this if the connected TV is PAL system.It will change the
video signal of a NTSC disc and output in PAL format.
NTSC-Select this if the connected TV is NTSC system.It will change
the video signal of a PAL disc and output in NTSC format.
Auto:Change the video signal output automatic according to the
playing disk format.
Audio:Selects a language for audio (if available).
Subtitle:Selects a language for subtitle (if available).
Disc Menu:Selects a language for disc menu (if available).
Preference Page
Item Standard requirement
Audio :Speaker:1WX2, outputHeadphones
VIDEO OUT
AUDIO OUT :1.4 Vrms (1 KHz, 0 dB)
Power requirements
Power consumption
Operating humidity
: AC 100-240 V , 50/60 Hz
: <10W
: 5 % to 90 %
Parameters and specifications
Electronical parameters
:Semiconductor laser, wavelength 650 nm
Signal system : NTSC / PAL
Frequency
Signal-to-noise ratio :More than 80 dB (ANALOG OUT connectors only)
Dynamic range :More than 85 dB (DVD/CD)
Note: Design and specifications are subject to change prior notice.
: 20Hz to 20 kHz(1dB)
Output
System
Laser
response
N
Battery Specifications：
Output：7.4V
Charge / Discharge Time：
Standard charge time：3h ~ 4h
Storage and work circumstances：
1. Storage circumstances Temperature Humidity
2.Work circumstances Temperature Humidity
6 months -20°C +45°C~
-20°C +65°C~
65±20%
65±20%
Standard charge 0°C +45°C~ 65±20%
1 week
Battery Parameters
Standard discharge -20°C +65°C~ 65±20%
8
Battery Charging
Connect the DVD player to the supplied power adaptor, the LED
indicator will be RED when the battery is charging and will turn into
green when the battery is full charged.When battery is no power,
LED is OFF.

003 ITV1
004 Channel 4
006 ITV2
010 ITV3
013 More 4
014 E4
030 ITV4
037 Quiz Call
Program Edit
LockMove
ALL TV
21:00-22:30 Secret Smile
22:30-22:50 ITV News
DeleteSkip RenameFAV
GOTO
FAV
Basic Operation
Program Manage Settings
Program Edit
OSD Language English
Country Germany
Channel Search
Installation Guide
ConfirmExit OK
Exit
Program Edit
Sort By LCN
LCN On
Program
ConfirmReturn OK
Exit
First Time Installation
After all connections have been made properly, switch on TV and
makesure the receiver is connected to the Main Power. Press Power
Button toswitch receiver on. If you are using the receiver for the first
time or restored to Factory Default, the Main Menu will appear on
your TV screen.
Menu provides options to adjust the
To access the Menu, press the MENU button and select [Program].
The Program Manage Settings.
Select an option and press OK or RIGHT to adjust that setting.
Press the EXIT button to exit the Menu.
To edit your program preferences (lock, skip, favourite,
move or delete), you will need to enter the Program Edit
Menu. This Menu requires a password to access. Enter
the default password '000000'.
(1) Select [OSD Language] and press RIGHT/LEFT key to select an
language.
(2) Select [Country] and press RIGHT/LEFT key to select your
country of residence.
(3) Select [Channel Search] and press RIGHT or OK key to begin
Automatic channel search.
(4) Once channel tuning is complete, you are now ready to watch TV.
9

First Time Installation
Set Favourite Program/s
You can create a shortlist of favourite programs that you can easily
access.Set Favourite TV or Radio program:
1.Select the preferred program then press the PAVOURITE button.
A heart-shaped symbol will appear and the program is marked as a
favourite.
2.Repeat the previous step to select more Favourite programs.
3.To confirm and exit the Menu,press the EXIT key.
Disable Favourite TV or Radio Program:
Press the FAV buton on the Remote Control with the heart-shaped
symbol.
View Favourite Programs:
1.Press the Fav button and the Favourite Menu will appear.
2.Press UP/DOWN to selest your Favourite Programs.
3.Press OK to select your favourite program.
Delete a TV or Radio Program/s
1.Select the Program and then press the BLUE button A message
will appear.Press OK to delete the program.
2.Repeat the previous step to select more programs to delete.
Skip TV or Radio Program/s
1.Select the program you would like to skip and press the GREEN
button A skip symbol is displayed. The program is marked as a
skip.
2.Repeat the previous step to select more programs.
3.To confirm and exit themenu,press EXIT key.
Disable a skip TV or Radio Program:
Press the GREEN button on the skip program with the skip symbol.
Move a TV or Radio Program/s
1. Select the preferred program then press the RED button. A
move symbolwill appear.
2. Press UP/DOWN to move the program.
3. Press OK to confirm.
4. Repeat the above steps to move more channels .
Lock Program/s
You can lock selected programs for restricted view.
Lock a TV or Radio Program:
1.Select the preferred program then press the YELLOW button. A
lock-shaped symbol is displayed. The program is now marked as
locked.
2. Repeat the previous step to select more programs .
3. To confirm and exit the menu, press the EXIT button.
4. Press the YELLOW button to disable the locked program.
5. To view the locked program, you will be require to enter either
the default.
10

Sort
LCN (Logical channel number)
Video Setting
You must set the display format to either 4:3 PanScan, 4:3 Letter
Box,16:9 Wide Screen or Auto to get the maximum display when
watching TV.
Sort your channels from the following options:
[LCN] - Sort the channels in ascending order.
[Name] - Sort the channels in alphabetical order.
[Service ID] - Sort the channels according to the station.
Set LCN on or off.
To access the Menu, press MENU then select [Picture]. The Menu
provides options to adjust the video settings. Press UP/DOWN to
select an option and press RIGHT/LEFT to adjust that setting.
Press EXIT to exit the menu.
Aspect Ratio
TV format
To access the menu,press MENU and select [Search Channel].
The Menu provides options to adjust the Search Channel settings.
Select an option and press RIGHT/LEFT to adjust the settings.
Press EXIT to exit the Menu.
Resolution
If the video does not appear correctly, change the setting. This
setting is to match the most common setting for HDMI.
Please note : HDMI-out can only be used in the TV mode, not
in the DVD model.
[576i] for PAL system TV.
[576P]: for PAL system TV.
[720P]: for NTSC or PAL system TV.
[1080I]: for NTSC or PAL system TV.
If the video does not appear correctly, you need to change the
settings. This should match the most common setting for TVs in
your country.
[NTSC]: for NTSC system TV.
[PAL]: for PAL system TV.
Channel Search
HDMI Aspect Ratio 16:9 Wide Screen
HDMI Resolution 1080i
TV Format PAL
ConfirmReturn OK
EXIT
Auto Search
Manual Search
Country Germany
Channel Search
ConfirmReturn OK
EXIT
11
First Time Installation

Auto Search
Search and install all channels automatically. This option
overwrites all preset channels.
1. Select [Auto Search] and press OK or RIGHT to start channel
search.
2. To cancel channel search, press EXIT.
2. Press the RIGHT/LEFT key to select the channel frequency.
3. Press OK to start searching channels.
If a channel is found, it is saved and added to the channels list. If
channels cant be found, then exit the menu.
Country
Select your country of residence.
Manual Search
Install new channels manually. This option adds new channels
without changing the current channels list.
1. Select [Manual Search] then press OK or RIGHT. The channel
search screen will appear.
Time Offset Auto
Country Region Berlin
Time Zore GMT +1
Time
ConfirmReturn OK
EXIT
To access the Menu,press MENU then select [Time]. The Menu
provides options to adjust the time settings.
elect an option and press RIGHT/LEFT to adjust the
settings.Press EXIT to exit the menu.
Time Setting
Press UP/DOWN to
s
Time offset
Country Region
Country Region is set automatically when you set the country at channel
Select auto or manual for GMT offset adjustments.
Time Zone
Select the Time Zone Offset when [Time Offset] is set to Manual.
001 ITV1
002 ITV2
003 ITV3
004 ITV News
005 Channel 4
006 Quiz Call
007 E4
008 More 4
009 ITV4
Channel Search
Progress
506.0MHz/8MHZ
DTV:009 Radio: 000
SkipExit
MENU
EXIT
Quality
Manual Search
Frequency channel 5
Frequency(MHZ) 177.5
Bandwidth: 7M
Confirm
EXIT
OK
EXIT
12
First Time Installation
search menu.

Option
To access the Menu,press MENU and select [Option]. The menu
provides options to adjust the OSD Language, Subtitle Language
and Audio Language. Select an option and press RIGHT/LEFT to
adjust the setting.Press EXIT to exit The Menu.
System Setting
To access the Menu,press MENU and select [System].The menu.
Provides options to adjust the system settings. Press the
UP/DOWN key to select an option and press RIGHT/LEFT to adjust
the setting.Press EXIT to exit the Menu.
OSD Language
Audio Language
Select the preferred audio language for watching TV channels.If
the language is not available, the default program language will be
used.
Subtitle Language
Select an OSD language.
Select the preferred subtitle language.
Set Password
Restore Factory Default
Information
View model, hardware and software information.
Set or change the password for Locked programs. Enter your old
Password or the default password '000000'. You will then be asked
to enter your new password. To confirm re-enter your new
password. Once it is confirmed, press EXIT to exit the Menu.
Reset your Set Top Box to the Default Factory Settings.In Main
Menu select [Restore Factory Default] and press OK or RIGHT to
select. Enter your password or the default password '000000' and
press OK to confirm. This option will delete all preset channels and
settings.
OSD Language English
Subtitle Language Off
Audio Language English
Digital Audio PCM
Option
ConfirmReturn OK
EXIT
Set Password
System
ConfirmReturn OK
EXIT
13
First Time Installation
Restore Factory Default
Information
Software update
Software update
Software update

USB
To access the Menu, press the Menu button and select USB.
Multi-Media
Switch to USB mode and plug in USB to view files.
Multimedia
Photo Configure
USB
ConfirmReturn OK
EXIT
Troubleshooting
The image stopped
suddenly or mosaic
Problem Potential Reasons What to do
No picture Power isn't connected Connect the power
The power switch
is not on Switch on the power
Screen shows
No Signal
DVB-T cable not Plug in the DVB-T cable
Incorrect setting Reset setting
No sound from
speaker
No or incorrect connection
with audio cable
Connect the audio
correctly
Sound on mute Turn off mute function
Incorrect sound track Try another sound track
Only sound, no
image on the
screen
No or incorrect connection
with AV cable
Make sure cables
connected correctly
The program is a radio
program
Press <TV/RADIO> key
shift into TV mode
Remote Control
is not responding
The battery is exhausted Change battery
Remote Control is not
facing or close enough
to the Set Top Box
Adjust the position
Remote Control and
closer to the unit
The signal is too weak Strengthen the signal
cable
are
to
of the
move
connected
14
First Time Installation
Technical Specifications
Video
Decoder Format MPEG4 AVC/H.264 HP@L4
MPEG2 [email protected]
Output Format 576P , 720P, 1080i, 4:3 and 16:9
Output Port HDMI (only for TV mode)
Item Sub Item Parameter
Tuner
Input Frequency 170~230MHz
470~860MHz
RF Input level -25~-82dBm
IF Bandwidth 7MHz and 8MHz
Modulation QPSK,16QAM,64QAM
Movie Configure

15
Service and support
For information: www.lenco.com
For support: http://lencosupport.zendesk.com
Lenco helpdesk:
Germany 0900-1520530 (Local charges)
The Netherlands 0900-23553626 (Local charges + 1ct p/min)
Belgium 02-6200115 (Local charges)
France 03-81484280 (Local charges)
The helpdesk is accessible from Monday till Friday from 9 AM till 6 PM.
When contacting Lenco, you will always be asked for the model and
serial number of your product. The serial number can be found on the
back of the device. Please write down the serial number below:
Model: DVP-9412
Serial number:_________________________________
Lenco offers service and warranty in accordance to European law,
which means that in case of repairs (both during and after the
warranty period) you should contact your local dealer.
Important note: It is not possible to send products that need repairs
to Lenco directly.
Important note: If this unit is opened or accessed by a non-official
service center in any way, the warranty expires.
This device is not suitable for professional use. In case of professional
use, all warranty obligations of the manufacturer will be voided.
WARNING: Prolonged exposure to loud sounds from
personal music players may lead to temporary or
permanent hearing loss.
Products with the CE marking comply with the EMC
Directive (2004/108/EC) and the Low Voltage
Directive (2006/95/EC) issued by the Commission of
the European Community.
The declaration of conformity may be consulted at
https://lencosupport.zendesk.com/forums/22413161
-CE-Documents
This symbol indicates that the relevant electrical
product or battery should not be disposed of as
general household waste in Europe. To ensure the
correct waste treatment of the product and battery,
please dispose them in accordance to any applicable
local laws of requirement for disposal of electrical
equipment or batteries. In so doing, you will help to
conserve natural resources and improve standards
of environmental protection in treatment and
disposal of electrical waste (Waste Electrical and
Electronic Equipment Directive).
®All rights reserved

Vor dem Anschluss, Betrieb oder der Einstellung dieses Geräts lesen Sie bitte
dieses Handbuch sorgfältig und vollständig durch.
BEDIENUNGSANLEITUNG
DVP-9412
WWW.LENCO.COM
TRAGBARER DVD-PLAYER

1
Wichtige Sicherheitshinweise
Netzadapter
Hersteller: Shenzhen Mass Power Electronics Limited
Modellnummer: EFF0900150E1BA
Verwenden Sie nur den in der Bedienungsanleitung erwähnten
Netzadapter.
Warnung: Zur Verringerung eventueller Stromschlaggefahr
öffnen Sie niemals das Gehäuse (bzw. die Geräterückseite).Es
befinden sich im Inneren des Geräts keine Teile die vom
Benutzer gewartet werden können. Wenden Sie sich bei Bedarf
an entsprechend ausgebildetes Wartungspersonal.
Warnung: Um Feuer und Stromschlägen vorzubeugen,
vermeiden Sie es das Gerät Regen oder Feuchtigkeit
auszusetzen.
Setzen Sie den Adapter und den tragbaren DVD-Player niemals
Wassertropfen oder -spritzern aus. Gegenstände die mit
Flüssigkeiten gefüllt sind, wie z.B. Vasen sollten niemals auf das
Gerät gestellt werden.
Stellen Sie den tragbaren DVD-Player in ausreichender
Entfernung zu Hitzequellen wie z. B. Heizkörpern bzw. Öfen auf
und halten Sie ihn von direkter Sonnenstrahlung fern.
Blockieren Sie nicht die Lüftungsöffnungen. Die Öffnungen des
Geräts dienen der Belüftung. Die Lüftungsöffnungen dürfen
niemals, indem Sie den DVD-Player auf ein Kissen, Sofa oder
ähnliche Oberflächen stellen, blockiert werden.
Benutzen Sie zur Aufstellung des tragbaren DVD-Players keine
instabilen Wagen, Gestelle, Stative, Haltevorrichtungen oder
Tische. Das Gerät kann herunterfallen und damit zu
Verletzungen oder Beschädigungen am Gerät führen.
Legen Sie niemals schwere oder scharfe Gegenstände auf den
LCD-Bildschirm oder den Bildschirmrahmen.
Verwenden Sie zusammen mit dem DVD-Player nur den im
Lieferumfang enthaltenen Netzadapter. Die Benutzung anderer
Netzadapter macht Ihre Garantie ungültig.
Der Netzstecker des Adapters dient dazu das Gerät vom Strom
zu trennen und sollte deshalb immer leicht zugänglich bleiben.
Ziehen Sie den Netzstecker aus der Steckdose, wenn das Gerät
nicht benutzt wird.
Entsorgen Sie Batterien umweltgerecht.
VORSICHT: Bei falsch eingelegten Batterien besteht
Explosionsgefahr! Benutzen Sie nur Batterien des gleichen
Typs.
WARNUNG: Die Batterien (Akkupack oder Batterien) dürfen
niemals übermäßiger Hitze, wie bei direkter Sonnenstrahlung,
Feuer oder dergleichen, ausgesetzt werden.
WARNUNG: Übermäßiger Schalldruck von Kopfhörern kann
zu Hörschäden führen.
WARNUNG: Verwenden Sie nur Zusatzgeräte bzw.
Zubehörteile, die vom Hersteller des Geräts geliefert oder
empfohlen werden. Der tragbare DVD-Player wird über einen
Netzadapter mit Strom versorgt. Der Netzadapter wird zudem
als Trennvorrichtung verwendet und sollte deshalb immer frei
zugänglich bleiben.
Achtung: Es besteht bei falsch eingelegtem Akku
Explosionsgefahr! Benutzen Sie zum Austauschen nur einen
Lithium-Akku eines gleichwertigen Typs.
Dieses Zeichen bedeutet, dass das vorliegende
Produkt innerhalb der EU nicht zusammen mit
dem Hausmüll entsorgt werden darf. Geben Sie
Altgeräte bei Sammelstellen ab oder wenden
Sie sich an den Händler bei dem das Gerät
gekauft wurde. Dort wird das Gerät dann auf
umweltverträgliche Weise entsorgt.

NHinweise zum Urheberrecht:
SERIENNUMMER:
Modellnr. ______________________________
Seriennr. ______________________________
Kaufdatum __________________________
2
Sicherheitshinweise
N
STROMSCHLAGGEFAHR!
NICHT ÖFFNEN!
WARNUNG
charge
over
heat
40 C
strong
impact
Warnung: Dieser digitale Disc-Player verwendet ein
Lasersystem. Die Verwendung von Bedienungsweisen, die
nicht in dieser Anleitung beschrieben werden, kann zudem zur
Aussetzung von gefährlicher Strahlung führen.
Achtung: Um direkte Laserstrahlen zu vermeiden, öffnen Sie
das Gehäuse niemals. Es tritt beim Öffnen des Gehäuses
sichtbare Laserstrahlung aus.
Warnung: Niemals direkt in den Laserstrahl blicken.
Achtung: Stellen Sie dieses Produkt nicht an beengten Orten,
wie z. B. einem Bücherregal, auf.
Achtung: Wenn das Gerät von Kindern benutzt wird, sind
dessen Eltern dazu verpflichtet dafür zu sorgen, dass vom Kind
der gesamte Inhalt der Bedienungsanleitung verstanden wird,
um sicher zu stellen, dass der Akku jederzeit sachgemäß
benutzt wird.
Warnung: Wenn der Akku überhitzt, anschwellt oder fehlerhaft
ist, hören Sie bitte auf den Akku zu benutzen und wenden Sie
sich an den Kundendienst für Ersatz.
Achtung: Laden Sie den Akku nicht an Orten auf, an denen
einen ausreichende Belüftung nicht gewährleistet ist, wie z. B.:
Matratzen, Sofas, Kissen, weiche Matten etc.
Achtung: Wir übernehmen keine Verantwortung, wenn der
Benutzer den Akku nicht ordnungsgemäß verwendet bzw. die
Warnhinweise auf dem Gehäuses des Akkupacks nicht befolgt.
Warnung: Die Benutzung eines USB-Verlängerungskabels von
einer Länge von mehr als 250 mm ist untersagt.
Es ist gesetzlich verboten urheberrechtlich geschütztes Material
ohne Erlaubnis zu kopieren, auszustrahlen, öffentlich
wiederzugeben oder zu vermieten.
Dieses Produkt verwendet eine der Firma Macrovision entwickelte
Kopierschutzfunktion. Auf bestimmten Discs werden
Kopierschutzsignale aufgezeichnet. Bei der Wiedergabe von
Kopien dieser Discs erscheint ein Bildrauschen. Dieses Produkt
verwendet Kopierschutzmechnismen der Firma Macrovision und
anderen Firmen, die durch bestimmte U.S. Patente und andere
Rechte für geistiges Eigentum geschützt sind. Die Benutzung
dieser Kopierschutztechnologie muss durch die Firma
Macrovision autorisiert werden und ist nur für die Benutzung zu
Hause und anderen eingeschränkten Benutzungsweisen gedacht,
solange es nicht ausdrücklich von der Firma Macrovision anders
angegeben wird. Reverse-Engineering und Auseinanderbauen
sind nicht gestattet.
Sie können die Seriennummer auf der Rückseite des Gerätes finden.
Diese Zahl ist für dieses Gerät einzigartig und ist auf anderen
Geräten des gleichen Modells anders. Sie sollten die betreffenden
Informationen hier notieren und diese Bedienungsanleitung als
dauerhaft gültigen Kaufbeleg aufbewahren.

Bezeichnung der Bedienelemente
Hauptgerät
3
11
12
18
13
19
14
15 17
16
7
8
9
10
180°
SOURCE
VOL- VOL+ MENU
SETUP
1
2
3
6
5
4
1. PLAY/PAUSE
2. STOPP
3. EINGANGSSIGNAL
4. LAUTSTÄRKE -
5. LAUTSTÄRKE +
6. MENÜ
7.▲/▼/◄/► (oben/unten/rechts/links)
Wählen Sie ein Element im Menü. Betätigen Sie die OK-Taste zu
Bestätigung Ihrer Auswahl.
Während der Wiedergabe einer VCD / DVD, falls verfügbar:
rechts: Schnellvorlauf
links: Schnellrücklauf
oben: voriger Titel
unten: nächster Titel
8. EINGABE
9. ÖFFNEN
10. EINSTELLUNGEN
11. SD/MMC
12. USB-Anschluss
13. AV-AUSGANG
14. Kopfhörerausgang
15. KOAXIALANSCHLUSS
16. EIN/AUS
17. Stromversorgungseingang 9 - 12 V
18. ANTENNE
19.
HDMI (nur im TV Modus, nicht im DVD Modus)
