LENCO MC-141 User manual

1. SPEAKERS (L&R)
2. BUTTON (ON/STANDBY)
3. TIMER / SLEEP BUTTON
4. MEMORY / CLOCK ADJ. BUTTON
5. REMOTE SENSOR
6. ENTER / PLAY / PAUSE BUTTON
7. LCD DISPLAY
8. CD DOOR
9. NEXT /TUNE BUTTON
BACK /TUNE BUTTON
10. CD OPEN/CLOSE BUTTON
11. FUNCTION BUTTON
12. ID3 / DISPLAY BUTTON
13. PHONES JACK
14. PRESET EQ BUTTON
15. STEREO/MONO/PLAY MODE BUTTON
16. FOLDER UP/P BUTTON
17. FOLDER DOWN/P BUTTON
18. STOP /BAND BUTTON
19. VOLUME / BUTTON
20. FM WIRE ANTENNA
21. AUX.IN JACK
22. AC CORD
CONTROLS
MAIN UNIT
PLL MICROSET WITH CD, MP3 AND WMA
Instruction Manual
MC141
+ -
+ -
+
-
For information and support, www.lenco.eu

WARNING
CLASS 1 LASER PRODUCT
This product contains a low power laser device.
CLASS 1 LASER PRODUCT
APPAREIL Á LASER DE CLASSE 1
PRODUCTO LASER DE CLASE 1
CAUTION
INVISIBLE LASER RADIATION
WHEN OPEN AND INTERLOCKS
DEFEATED.
AVOID EXPOSURE TO BEAM
PRECAUTIONS
Follow the advice below for safe and appropriate operations.
ON PLACEMENT
• Do not use the unit in places which are extremely hot, cold, dusty, or humid.
• Placetheunitonaatandevensurface.
• Donotrestricttheairowoftheunitbyplacingitinaplacewithpoorairow,bycoveringitwithacloth, 
 orbyplacingitonacarpet.
ON SAFETY
• WhenconnectinganddisconnectingtheACcord,griptheplugandnotthecorditself.Pullingthecordmaydamage
it and create hazard.
• Whenyouarenotgoingtousetheunitforalongperiodoftime,disconnecttheACpowercord.
ON AC VOLTAGE
• Beforeuse,checkthattheratedvoltageofyourunitmatchesyourlocalvoltage.
ON CONDENSATION
• When left in a heated room where it is warm and damp, water droplets or condensation may form inside the CD player.
• When there is condensation inside the unit, the unit may not function normally.
• Letitstandfor1to2hoursbeforeturningthepoweron,orgraduallyheattheroomupanddrytheunitbeforeuse.
* Ensureaminimumdistanceof5cmaroundtheapparatusforsufcientventilation.
* Ensurethattheventilationisnotimpededbycoveringtheventilationopeningswithitems,suchasnewspapers,
table-cloths, curtains, etc..
* Donotplacenakedamesources,suchaslightedcandlesontheapparatus.
* Take attention to the environmental aspects of battery disposal.
* Use the apparatus only in moderate climates (not in tropical climates).
* Donotexposetheapparatustodrippingorsplashing.
* Donotplaceobjectslledwithliquids,suchasvases,ontheapparatus.
• Mainsplugisusedasthedisconnectdevice.Itshallremainreadilyoperableandshouldnotbeobstructedduring
 intendeduse.Tobecompletelydisconnectedtheapparatusfromsupplymains,themainsplugoftheapparatusshall
be disconnected from the mains socket outlet completely.
Should any trouble occur, disconnect the AC power cord and refer servicing to qualied personnel.
Warning: Do not touch the lens.
DO NOT THROW BATTERIES IN FIRE !
ATTENTION : To reduce the risk
of electric shock, do not remove the
cover. There are no user serviceable
partsinsidetheunit.Referallservicing
toqualiedpersonnel.
The exclamation point within
thetriangleisawarningsign
alertingtheuserofimportant
instructions accompanying
the product.
The lightening flash with
arrowhead symbol within the
triangle is a warning sign
alertingtheuserof"danger-
ousvoltage"insidetheunit.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
In case of misfunction due to electrostatic discharge the apparatus has to be reset by disconnecting it from
mains supply.
THE MARKING PLATE IS LOCATED AT THE BACK OF ENCLOSURE OF THE APPARATUS.

SYSTEM CONNECTIONS
Power is fed to the unit even when it is in standby.
Ensure that the unit is switched off before you make any connections.
FITTING THE BATTERIES INTO THE REMOTE CONTROL
REMOTE CONTROL UNIT
VOLUME BUTTON VOLUME BUTTON
TUNE + NEXT BUTTON
ON / STANDBY BUTTON
+10 TRACK BUTTON
FOLDER UP / P + BUTTON
ENTER /PLAY
/PAUSE BUTTON
FUNCTION BUTTON
STOP / BAND BUTTON
TUNE - BACK BUTTON
FOLDER DOWN / P- BUTTON
- +
ID3/DISPLAY BUTTON
MEMORY/CLOCK/ADJ. BUTTON
- 10 TRACK BUTTON
GB 1
Remove the battery door. Insert the batteries (2 x AAA SIZE battery, not included) and ensure that the polarities are correct (see
illustration inside the battery compartment).
Close the battery door.
To an AC outlet
LEFT SPEAKER
RIGHT SPEAKER FM WIRE ANTENNA
* LEFT/RIGHT
SPEAKER SOCKET
Connect the black wire to the (-) terminal.
Connect the white wire to the (+) terminal.
SPEAKER WIRE
AC POWER CORD
SPEAKER WIRE
MUTE BUTTON PRESET EQ BUTTON
ST./MO./PLAY MODE BUTTON
TIMER/SLEEP BUTTON

GB 2
Press VOLUME +/- to adjust volume level. Volume level is shown on the display.
FOR PRIVATE LISTENING
Pluginheadphones(ø3.5mmstereomini-plug)tothePHONESjack.
Whenheadphonesarepluggedin,thespeakersareautomaticallydisconnected.
TO ADJUST THE VOLUME
ADJUSTING THE SOUND
PRE-SET EQ
Preset EQ : FLAT, JAZZ, ROCK, CLASSIC, POP.
Press PRESET EQUALIZER button to select your preferred
sound, preset mode is shown on the display.
1. Powerison/offbypressingSTANDBYbutton.
2. Thefunctionischangedcyclically
 bypushingFUNCTIONbutton:
CD TUNER AUX .
POWER ON/OFF AND FUNCTION CHANGE
STANDBY
VOL. +
VOL. -
PRESET EQ
The mute on/ off is changed cyclically by pressing MUTE
button.
The“mute”markisonduringmuteison.
The mute on is cancelled in case as shown below.
a. The power is off/on
b. The Volume is adjusted by the VOL +/- button.
MUTE ON/OFF
MUTE
AUX IN
Connect an external LINE OUT to AUX. IN socket at the back of the unit.
Press the FUNCTION button and select AUX mode.
( AUX IN CABLE NOT INCLUDED )
(Plugotherendinto
external source )
FUNCTION
AUX. IN
FUNCTION

3. TurninastationbypressingtheUP/DOWN
button.
5 . The FM stereo indicator (Stereo) will appear on
the LCD display panel when an FM Stereo
Broadcast is received.
1 . Press the FUNCTION button and select Radio
mode.
2. SelectAMorFMbypressingthe
STOP/BAND button.
4. Releasethebuttonassoonasthefrequencystarts
 tochange.Thetunerwillsearchupordownthe
selected band and stop at the next receivable
 station.Whenscanningstops,thefrequencyof
the received station will be displayed.
LISTENING TO THE RADIO
GB 3
1. The clock is displayed on CD display at power off condition.
2. PresstheMEMORYCLOCK-ADJ.button,hourofclockash.
3. Press the or to
 adjusthourdigit.
4. PresstheMEMORYCLOCK-ADJ.button,theminutedigitash.
5. Press the or to adjust
 minutedigit.
6. PresstheMEMORYCLOCK-ADJ.buttonagain,
the correct time is shown on display.
CLOCK ADJUSTMENT
MEMORY/CLOCK-ADJ.
Maximum 20 preset stations can be memorized, each in FM and AM.
1. Pressthe"or"buttonto
 selectedthedesiredfrequency.
2. Pressthe"MEMORY"button.
3. Pressthe"P+/FOLDERUP"onradiooronremotecontroltoselect
the memory number.
4. Pressthe"MEMORY"buttonagaintoconrmtheselection.
5. Pressthe"P+/FOLDERUP"buttontoreadthedesiredfrequency.
RADIO MEMORY FUNCTION
MEMORY / CLOCK-ADJ.
FOR BETTER RECEPTION
FM AM
AM : Rotate the unit from side to side.
FM:Extendandchangepositionoftheantenna.
After Listening: Press the STANDBY button off.
FUNCTION

CD display
5. Press the PLAY/PAUSE button.
 Tracknumber"1"&thesymbol""willbe
 shownduringnormalcompactdiscplayback.
 Tracknumber"001",thesymbol""&"MP3"
 willbeshownduringMP3playback.
 Tracknumber"001",thesymbol""&"WMA"
 willbeshownduringWMAplayback.
GB 4
MP3 display
WMA display
COMPACT DISC PLAYBACK
1 . Press the FUNCTION button and select CD
mode.
2 . Press OPEN/CLOSE button to open CD door.
3. Insertadiscwiththelabelsidefacingup.
4 . Press OPEN/CLOSE button to close the CD door.
For CD: Total number of tracks and time will be
shown on the display.
For MP3: Total number of folder and tracks will be
shown on the display.
For WMA: Total number of folder and tracks will be
shown on the display.
CD display
CD display
TO SKIP TO THE BEGINNING OF A TRACK
• Presseitheroneoftheskipbuttonsaccordingtothedesiredskipdirection.
• Play/back resumes from the selected track.
• Whenthebuttonispressedonceduringplay,theprevioustrackstartsagain.
• Whenthebuttonispressedonceduringplay,thenexttrackplays.
SEARCHING FOR A PASSAGE WITHIN A TRACK
• Keeptheorbuttonpressedduringplayback,
 andreleasethebuttonassoonasyourecognisethedesiredpassage.
Then normal CD playback will resume from this point.
TO INTERRUPT PLAYBACK
Press the PLAY/PAUSE button and the symbolPLAY/PAUSE button and the symbolbutton and the symbol
""andcurrenttimewillash.Pressthebuttonagain
to resume playback.
TO STOP PLAYBACK
Press the STOP/BAND button.
For CD: Total number of track and time will be
shown.
For MP3: Total number of folder and track will be
shown.
For WMA: Total number of folder and track will be
shown.
CD display
MP3 display
WMA display
FUNCTION
PLAY/PAUSE
STOP/BAND

GB 5
FOR NORMAL COMPACT DISC PLAYBACK
ModesequenceREPEAT>>REPEATALL
>>RANDOM>>REPEATOFF.
DuringRepeat1mode,
display shows
DuringRepeat2mode,
display shows
DuringMixmode,
display shows
REPEAT , REPEAT FOLDER AND MIX PLAYBACK
CD display
FOR MP3/WMA PLAYBACK
Mode sequence REPEAT >> REPEAT FOLDER >>
REPEATALL>>RANDOM>>REPEATOFF.
DuringRepeat1mode,
display shows
DuringRepeat2mode,
display shows
DuringRepeat3mode,
display shows
DuringMixmode,
display shows
PressPLAYMODEbuttonduringstopmode.CDplayswithasingletrackrepeat,alltracksrepeatorrandomly.
MP3/WMA display
Note on CD-R/RW discs
- Becauseofnon-standardizedformatdenition/
 productionofCD-R/RW,playbackqualityandperformancearenotguaranteed.
- ManufacturerisnotresponsiblefortheplayabilityofCD-R/RWduetorecordingconditions,suchasPCperformance,
 writingsoftware,mediaability,etc.
- Do not attach a seal or label to either side of the CD-R/RW disc. It may cause a malfunction.
- ItisrecommendedtorecordonlyaudiolesonCD-R/RWdiscsforeasyreading.
- Press FOLDER UP/DOWN to select desired folder.
- PressUP/DOWNtoselectdesiredsongs.
- PressPLAY/PAUSEbuttontostartplaying.Theword“MP3/WMA”
will show on display.
Press FOLDER UP/DOWN to select desired folder. Press UP/DOWN to select the desire track.
The operations of buttons of PLAY/PAUSE, UP/DOWN and STOP/BAND are the same as
CD disc.
FOLDER UP / DOWN
Duringplayback,press10+or10-buttontoselectthenextorprevious10tracks.
+10 / -10 BUTTON
FOLDER UP/DN.

1. If you want to fall asleep to music, press and hold SLEEP button.
2. You may adjust the radio or CD player's sleep function to play
 from90,80,70upto10minutesofmusicbeforeshutting
itself off automatically.
TO SET SLEEP FUNCTION
GB 6
CD display
PROGRAM PLAYBACK
FOR NORMAL COMPACT DISC PLAYBACK
Programmedplaybackenablestracksonadisctobeplayedinthedesiredorder.
Upto60trackscanbeprogrammed.
1. Press the “ MEMORY “ button.
2. Press the skip buttons to select the desired track number.
3. Press“MEMORY“buttonagaintomemorizethetrack.
4. Repeatsteps2and3untilalldesiredtracksareprogrammed.
5. Press the “ PLAY/PAUSE “ button to start. “ MEMORY “ is shown on the CD display.
6. Press“STOP“buttontostopprogrammedplayback.
7. Press “ MEMORY “ and “ PLAY/PAUSE “ buttons to resume
 programmedplayback.
8. Press"STOP/BAND"buttontocleartheprogrammedmemory.
FOR MP3/WMAPLAYBACK
Programmedplaybackenablesfolders/albumsortracksonadisctobeplayedinthedesired
order.Upto60folders/albumsortrackscanbeprogrammed.
1. Press the “ MEMORY “ button.
2. Press the M-UP/FOLDER UP button to select the desired folder.
3. Press“MEMORY“buttonagaintomemorizethefolder.
4. Press the skip buttons to select the desired track number.
5. Press“MEMORY“buttonagaintomemorizethetrack.
6. Repeatsteps2and5untilalldesiredtracksareprogrammed.
7. Press the “ PLAY/PAUSE “ button to start. “ MEMORY “ is shown on the CD display.
8. Press“STOP“buttontostopprogrammedplayback.
9. Press“MEMORY“and“PLAY/PAUSE“buttonstoresumeprogrammedplayback.
10. Press"STOP/BAND"buttontocleartheprogrammedmemory.
Note :Programmingcanonlybemadewhentheplayerisinstopmode.
CD display
MP3/WMA display
90 80 70 60 50 40 30 20 10 90
ID 3 DISPLAY
- Songname,Singernameandalbumnamecanbedisplayedcyclically 
 bypressingID3buttonduringplayingMP3.
- Title-songnameArtist-singernameAlbum-Albumname
- PressID3againtocancelID3display.
TIMER SETTING
1. Press the STANDBY button to put the machine in the standby mode.
2. Pressandholdthe"TIMER/SLEEP"button,"ONTIME"willdisplay,"TIMER"
 andthehourdigitsash.Presstheskipbuttonstosetthehour.
 Pressthe"TIMER/SLEEP"buttontoconrm,theminutesdigitsash,press
 theskipbuttonstosettheminutes.Pressthe"TIMER/SLEEP"
 buttontoconrmand"OFFTIME"willdisplay.Followsameprocedureofsetting
"ONTIME"tosetthe"OFFTIME".
3. Aftersettingthe"OFFTIME",youcanalsoselecttheFUNCTION(CD,TUNER,
AUX)forTIMERbypressing.Pressthe"TIMER/SLEEP"toconrm.
4. Then, press skip buttons to select the volume of the sound,
 pressthe"TIMER/SLEEP"toconrm.
ID3
MEMORY/CLOCK ADJ.
MEMORY/CLOCK ADJ.
TIMER/SLEEP
TIMER/SLEEP

GB 7
CD SECTION
Channels: 2 channels
S / N ratio: 60 dB
Wow & Flutter: undetectable
Samplingfrequency: 44.1kHz8xoversampling
Quantization: 16 bits DA converter
Pickuplightsource: Semi-conductorlaser
Pickupwavelength 790nm
RADIO SECTION
Tuningranges: FM87.5-108MHz
AM 522 - 1620 kHz
Antennas: AM Built - in ferrite bar
FM Wire antenna
GENERAL
Output power: 2 W + 2 W
Power consumption: 17 WATTS
Speaker: 3"8OHM
Phones jack: 3.5MM
Power source: AC : 230V ~ 50Hz
Dimensions
Main Unit: 175 (L) x 207 (D) x 133 (H)mm
Speaker: 110 (L) x 174 (D) x 133 (H)mm
Remote control: 35 (L) x 18 (D) x 190 (H)mm
Weight: 2.63Kgs
Duetocontinuingimprovement,thefeaturesandthedesignaresubjecttochangewithoutnotice.
Where to place the item :
Today’sfurnitureiscoatedwithawidevarietyoflacquersandsynthetic-coatingsthataretreatedwithanextensiverange
ofcleaningproducts.Therefore,thepossibilitythatsomeofthesesubstancescontaincomponentsthatreactadverselyto
the rubber feet of the item and soften them, cannot be completely excluded. The rubber feet of the appliance can cause
discoloringtofurnituresurfaces.Ifnecessary,placetheapplianceonanon-slidesurface.
If at any time in the future you should need to dispose of this product please note that Waste
electrical products should not be disposed of with household waste.Please recycle where
facilitiesexist.CheckwithyourLocalAuthorityorretailerforrecyclingadvice.
(WasteElectricalandElectronicEquipmentDirective)
SPECIFICATIONS
CLEANING CD
If the CD skips or will not play , the disc may
needcleaning.Beforeplaying,wipethedisc
fromthecentreoutwithacleaningcloth.After
playing,storethediscinitscase.
MAINTENANCE
CLEANING THE UNIT
Donotusevolatilechemicalsonthisunit.Cleanbylightly
wipingwithasoftcloth.
IMPORTANT NOTE
Ifanabnormaldisplayindicationoranoperatingproblem
occurs, disconnect the AC power cord. Wait at least 5 seconds,
then reconnect the AC power cord.
WARNING
ShouldtheCDdoorbeopenedbeforethereadingoftheCD
completed,ajammingnoisemayoccur.Thisisresolvedby
closingtheCDdoor.
CLEANING THE CD LENS
If the CD lens is dusty, clean it with a brush-blower. Blow
several times on the lens and remove the dust with the brush.
Fingerprints may be removed with a cotton swab moistened
with alcohol.
For information and support, www.lenco.eu
