LZP-4 Zoning SystemLZP-4 Zoning System
Four-Zone System
LZP-4
Designed to control
multistage heating and
cooling systems

Lennox’ LZP-4 zoning system enhances your comfort by allowing you to
control the flow of heated and cooled air through different areas of your home.
Say you have an upstairs floor that’s always too hot. With the LZP-4, you can
reduce heating in that area. And if you have a room that gets a lot of use
throughout the day, you can make sure it gets extra air conditioning.
The LZP-4 zoning system meets your specific comfort needs in one zone,
without affecting the other zones. It’s like having a heating and cooling
system for each living area in your home. This not only maximizes your
comfort—it also saves you money, year after year.
ROOM-BY-ROOM COMFORT CONTROL—
YEAR-ROUND ENERGY SAVINGS
2
Lennox LZP-4 Zoning System
Designed to adapt to
your comfort level and
lifestyle needs
Divides your home into four
comfort zones, giving you
more flexibility and control
Provides precise comfort
throughout the home,
throughout the year
Can save you hundreds of
dollars in energy costs over
the life of the system
Zone 1 – Seldom-used upstairs bedroom (needs little heat or cooling)
Zone 2 – Children’s upstairs bedroom (high heat in the summer requires
additional air conditioning)
Zone 3 – Home office or exercise room
Zone 4 – Family room (high-activity area needs extra air conditioning)




WARRANTY
2-year limited warranty.*
Innovation never felt so good.
™

3
*Applies to residential applications only.
**Not designed for use with variable speed gas furnace or electro-mechanical thermostats.
***Department of Energy statistics.
†Zone control panel must be installed in conditioned airspace. Used with heat pump systems only.
Feature How It Works How It Helps
Vacation Mode Allows you to adjust temperature settings in each zone Increases efficiency
for optimal efficiency when your home is unoccupied
Auto Changeover Maintains comfort by automatically alternating between Delivers enhanced comfort and efficiency
heating and cooling during transitional weather
Permanent Program Memory Maintains zone settings in the event of a power loss Provides an extra measure of reliability
Built-In Time Delay Keeps your HVAC system from short-cycling (constantly Delivers enhanced comfort and efficiency
stopping and restarting), so it can run at peak efficiency
LED Display Indicates heating and cooling status for each zone Offers timesaving convenience
Emergency Heat† Activates auxiliary heater during periods of extremely Assures your complete comfort during cold winter
cold weather months
Dual-Fuel Capability Allows integration of the zoning system with an electric Offers enhanced energy savings
heat pump and gas furnace
Dimensions HxWxD (in.)
LZP-4 12 x 9-1/2 x 2
Comfort Rises to every comfort challenge,
from chilly drafts to hot spots
As illustrated by the example shown on page 2, this system gives you many
options for comfort control around your home.**
Efficiency Reduces your energy costs by up to 35%,
when used with a programmable thermostat***
With the LZP-4 zoning system, you no longer have to pay to heat or cool
areas of your home you rarely use.
Component How It Works How It Helps
Solid-State Control Panel Divides your home into four different comfort zones, Gives you greater control over your energy costs
allowing you to adjust temperature and airflow according and comfort
to your lifestyle needs
Zone Damper (one for each zone) Regulates airflow and controls temperature consistently Helps eliminate hot and cold spots
throughout your home
Electronic Air Sensor Continually monitors temperature of the air leaving the zone Ensures accuracy and hassle-free operation
and automatically adjusts control panel settings to ensure
zone demands are satisfied

Innovation never felt so good.™
HOME COMFORT SYSTEMS
Innovation never felt so good.™
HOME COMFORT SYSTEMS
Innovation never felt so good.™
HOME COMFORT SYSTEMS
Innovation never felt so good.™
HOME COMFORT SYSTEMS
PC39481
© Lennox Industries Inc. 2004
Visit us at www.lennox.com, or contact us at 1-800-9-LENNOX.
(72M76) LZP-4 1/05
CONTINUOUS COMFORT NETWORK
Lennox® heating, cooling and indoor air quality products are designed to provide efficient, economical comfort—
not only as individual units, but also together as an integrated system. This combined network of products delivers on
every comfort count, from consistent temperatures and balanced humidity to improved indoor air quality.
DEALERS YOU CAN COUNT ON
Choosing the right dealer for your heating, cooling and indoor air quality needs is every bit as important as choosing the
right brand. We think you’ll agree our dealers are a big reason you can count on quality customer service when you call.
 Air conditioner or heat pump
 Thermostat
 Furnace or air handler
 Filtration device
 Germicidal light
 Indoor coil
 Humidifier
 HEPA bypass filtration system
 Energy recovery ventilator
 Supply duct
 Return duct
