714/715 ZONE EXPANSION MODULE
Installation Guide
DESCRIPTION
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
714 and 715 zone expander
modules allow you to increase the
number of reporting zones available
on DMP panels.
The modules connect to the panel
Keypad Bus or LX‑Bus and are set
to an address that determines the
reporting zone number.
The 714 provides four 5VDC Class
B, Style A zones for use with
burglary and non‑powered fire
devices.
The 715 provides four 12VDC Class
B zones for use with burglary,
non‑powered, or powered fire
devices.
Compatibility
• XT30/XT50 Panels
• XR150/XR550 Panels
What is Included?
• One 714 Zone Expansion Module
or One 715 Zone Expansion
Module
• Four 1K Ohm Resistors (714)
• Four 3.3K Resistors (715)
• 12‑Wire Harness
• Hardware Pack
1PROGRAM THE PANEL
Program the zones on 714 or 715 zone expander modules with any
of the panel’s burglary or fire zone types. You can also program
zones as an Arming zone type when they are being used with key
switches. For more information, refer to the appropriate panel
programming guide.
MOUNT THE MODULE
2The714/715comes in a high‑impact plastic housing that you can
mount directly to a wall, backboard, or other flat surface. For easy
installation, the housing base contains holes that allow you to
mount themodule on a single‑gang switch box or ring. Mount the
module outside the panel enclosure.
1. Remove the housing fastener screws and separate the top
housing from the base.
2. Insert screws through the desired mounting holes on
the housing base. Refer to Figure 2 for mounting hole
locations.
3. Tighten the screws into place.
4. After wiring and addressing the module, attach the
housing top to the mounted base with the housing
fastener screws. Refer to Figure 3.
Figure 1: 714/715 Module
Figure 2: Mounting Hole Locations
Figure 3: Assembling the Housing
Mounting
holes
Housing Base
Housing
fastener
hole
Housing
fastener
hole

2 714/715 INSTALLATION GUIDE | DIGITAL MONITORING PRODUCTS
SET THE MODULE ADDRESS
714 and 715 Zone Expansion Modules use two rotary switches (TENS and ONES) to set the module address.
For keypad bus addresses, set the switches to match the device address. For LX‑Bus addresses, set the
switches to match the last two digits of the addresses. For example, for address 02 set the switches to TENS 0
and ONES 2 as shown in Figure 4. For more information, refer to Table 1 and Table 2.
SWITCH XR150 SERIES XR550 SERIES
TENS ONES LX500 LX500 LX600 LX700 LX800 LX900
0 0 500 500 600 700 800 900
0 1 501 501 601 701 801 901
0 2 502 502 602 702 802 902
0 3 503 503 603 703 803 903
0 4 504 504 604 704 804 904
... ... ... ... ... ... ... ...
9 5 595 595 695 795 895 995
9 6 596 596 696 796 896 996
9 7 597 597 697 797 897 997
9 8 598 598 698 798 898 998
9 9 599 599 699 799 899 999
Table 1: LX-Bus Addresses and Corresponding Zone Numbers
4
3Connect to the LX-Bus
To wire the 714, join the red, yellow, green, and black wires to a 4‑wire harness and connect it to the LX‑Bus.
To wire the 715, connect the red wire to panel Terminal 11 (Smoke power terminal). This allows Sensor Reset
to drop power to the module and devices connected to its zones. Join the yellow, green, and black wires to a
4‑wire harness and connect it to the LX‑Bus.
Connect the 714 to the Keypad Bus
1. Connect the red, yellow, green, and black wires to panel Terminals 7, 8, 9, and 10 respectively.
2. Observe polarity and wire zones 1‑4.
3. Install the included 1K Ohm EOL resistors.
Connect the 715 to the Keypad Bus
1. Connect the red wire to panel Terminal 11 (Smoke power terminal). This allows Sensor Reset to drop
power to the module and devices connected to its zones. Alternately, connect red to a regulated, power
limited power supply listed for Fire Protective Signaling through a Model 716 relay. Use the Sensor Reset
Output programming to drop power to the 715 module.
2. Connect the yellow, green, and black wires to panel Terminals 8, 9, and 10 respectively.
3. Observe polarity and wire zones 1‑4.
4. Install the included 3.3K Ohm EOL resistors.
WIRE THE MODULE
R
E
D
714
Module
White/Yellow: Zone 4
White/Orange: Zone 3
White/Red: Zone 2
White/Brown: Zone 1
Black
Green
Yellow
Red 714 Module:
Connect Red to LX-Bus Wire or Panel Terminal 7
715 Module:
Connect Red to Panel Terminal 11 or a
regulated, power limited power supply listed for
Fire Protective Signaling through a Model 716 relay
+
–
+
–
+
–
+
–
714 Module Specifications
Normal Operating Range 650-2100 Ohms
Zone Resistors 1K Ohm EOL
Max line impedance 100 Ohms
Zone Ground Fault 1500 Ohms or less
Zone Supervision All Zones
715 Module Specifications
Normal Operating Range 1200-6000 Ohms
Zone Resistors 3.3k Ohm EOL
Max line impedance 100 Ohms
Zone Ground Fault 80 Ohms or less
Zone Supervision All Zones
To Keypad Bus or LX-Bus
0
1
2
3
4
5
6
7
8
9
S2
0
1
2
3
4
5
6
7
8
9
S1
TENS ONES
Figure 4: Module Wiring

714/715 INSTALLATION GUIDE | DIGITAL MONITORING PRODUCTS 3
ADDITIONAL INFORMATION
Wiring Specifications
DMP recommends using 18 or 22 AWG for all LX‑Bus and Keypad Bus connections. The maximum wire distance between
any module and the DMP Keypad Bus or LX‑Bus circuit is 10 feet. To increase the wiring distance, install an auxiliary
power supply, such as a DMP Model 505‑12. Maximum voltage drop between a panel or auxiliary power supply and any
device is 2.0 VDC. If the voltage at any device is less than the required level, add an auxiliary power supply at the end of
the circuit.
To maintain auxiliary power integrity when using 22‑gauge wire on Keypad Bus circuits, do not exceed 500 feet. When
using 18‑gauge wire, do not exceed 1,000 feet. Maximum distance for any bus circuit is 2,500 feet regardless of wire
gauge. Each 2,500 foot bus circuit supports a maximum of 40 LX‑Bus devices.
For additional information refer to the LX‑Bus/Keypad Bus Wiring Application Note (LT‑2031) and the 710 Bus Splitter/
Repeater Module Installation Guide (LT‑0310).
Optional Accessories
You can replace the standard wiring harness with the optional 718T Plug‑in Screw Terminal. The enclosure base can also
accommodate the 719T Terminal Boards for the 714 or the 720T Terminal Boards for the 715, both of which pass through
panel LX‑Bus wiring. The 719T includes 1k EOL resistors. The 720T includes 3.3k EOL resistors.
LED Operation
The LED on the zone expanders flashes each time the module responds to a poll from the panel. If there is a problem
with the hardware, panel programming, or the green data wire between the panel and the zone expander module, the
LED stops flashing and System Trouble appears in the keypad display.
KEYPAD BUS
ADDRESS
SWITCH ZONE NUMBERS
TENS ONES XT30/XT50 AND
XR150 SERIES XR550 SERIES
1 0 1 11 to 14 11 to 14
2 0 2 21 to 24 21 to 24
3 0 3 31 to 34 31 to 34
4 0 4 41 to 44 41 to 44
5 0 5 51 to 54 51 to 54
6 0 6 61 to 64 61 to 64
7 0 7 71 to 74 71 to 74
8 0 8 81 to 84 81 to 84
9 0 9 N /A 91 to 94
10 1 0 N/A 101 to 104
11 1 1 N/A 111 to 114
12 1 2 N /A 121 to 124
13 1 3 N /A 131 to 134
14 1 4 N/A 141 to 144
15 1 5 N /A 151 to 154
16 1 6 N /A 161 to 164
Table 2: Keypad Bus Addresses and Corresponding Zone Numbers

Designed, engineered, and
manufactured in Springfield, MO
using U.S. and global components.
LT-0161 20021
714/715 ZONE
EXPANSION MODULE
Specifications
Operating Voltage 12VDC
714 Operating Current 7mA + 1.6mA per zone
714 Zone Voltage 5VDC, max 2mA
715 Operating Current 7mA + 4mA per active zone
+ 30mA per smoke in alarm
+ 58mA per zone shorted
715 Zone Voltage 12VDC, max 58mA
Dimensions 4.50” W x 2.75” H x 1.75” D
11.43 cm W x 6.99 cm H x 4.45 cm D
Zones 4 Supervised Class B Style A Power
Limited
Compatibility
XT30/XT50 Series panels
XR150/XR550 Series panels
Ordering Information
714 Module in Pyramid Housing
714-19T Module with 719T Terminal Board
714-X Module in Snap Track Housing
714-X-18T Module with 718T Terminal Board
715 Module in Pyramid Housing
715-20T Module with 720T Terminal Board
715-18T Module with 718T Terminal Board
Accessories
718T Single Strip Terminal Boards (714/715)
719T Dual Strip Terminal Boards (714)
720T Dual Strip Terminal Boards (715)
Certifications
California State Fire Marshal (CSFM)
New York City (FDNY COA #6167)
Underwriters Laboratory (UL) Listed
ANSI/UL 365 Police Station Connect Burglar
Alarm Systems
ANSI/UL 609 Local Burglar Alarm Units & Systems
ANSI/UL 864 Fire Protective Signaling Systems
ANSI/UL 985 Household Fire Warning System
Units
ANSI/UL 1023 Household Burglar Alarm System
Units
ANSI/UL 1076 Proprietary Burglar Alarm Units &
Systems
ANSI/UL 1610 Central Station Burglar Alarm Units
ANSI/UL 1635 Digital Alarm Communication
System Units
ULC Subject-C1023 Household Burglar
ULC/ORD-C1076 Proprietary Burglar
ULC S304 Central Station Burglar
ULC S545 Household Fire
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
INTRUSION • FIRE• ACCESS• NETWORKS
2500 North Partnership Boulevard
Springfield, Missouri 65803-8877
800.641.4282 | DMP.com
COMPLIANCE LISTING SPECIFICATIONS
UL Commercial Burglary
To comply with ANSI/UL 365 Police‑Connected Burglary System or ANSI/UL 609 Local Burglary Alarm Systems, the
module must be mounted in the supplied, UL listed enclosure with a tamper.
UL Commercial Fire
Please see the panel installation guide for details for selecting compatible 2‑wire smoke detectors. Any auxiliary power
supply used must be regulated, power limited and listed for Fire Protective Signaling.
ULC Commercial Burglary (XR150/XR550 Series Panels)
Place the zone expander module in a listed enclosure and connect a DMP Model 307 Clip‑on Tamper Switch to the
enclosure programmed as a 24‑hour zone.
The 714/715 zones can be installed in medium or high risk applications when two zones are used as shown in the Dual
Zone Protection diagram in the XR150/XR550 Canadian Installation guide. Otherwise, 714/715 zones can only be used in
low risk applications.
ULC Residential Fire (XR150/XR550 Series Panels)
Refer to Table 3 for ULC approved 2‑Wire Smoke Detectors. Refer to the appropriate panel installation guide for the
complete list of UL approved smoke detectors.
MANUFACTURER MODEL DETECTOR ID DC VOLTAGE RANGE NUMBER OF DETECTORS
Sentrol/ESL 528B, 528BXT S09A 6.5‑20 12
Table 3: ULC Approved 2-Wire Smoke Detectors
