Lennox V8MSBB01 User manual

1
©2018 Lennox Industries Inc.
Dallas, Texas, USA
INSTALLATION
INSTRUCTIONS
VRF SYSTEMS
507453-05
05/2018
THIS MANUAL MUST BE LEFT WITH THE
OWNER FOR FUTURE REFERENCE
Shipping and Packing List
Check the components for shipping damage. If you find
any damage, immediately contact the last carrier.
Package 1 of 1 contains the following:
1 - Assembled mode selection box
3 - Insulation sleeves for piping from outdoor unit
1 - 1” X ¾” condensate drain adaptor
1 to 6* - ⅜” to ¼” adaptors
1 to 6* - ⅝” to ½” adaptors
1 to 6* - ¼” brass flare nuts
1 to 6* - ½” brass flare nuts
1 to 6* - Gas pipe insulation sleeve(s)
1 to 6* - Liquid pipe insulation sleeves
*Quantity of these items depends on number of refrigerant
piping connection pairs.
Installation
Mode Selection Box
Mode selection boxes V8MSBB01, V8MSBB02, V8MS-
BB03 and V8MSBB04 are used with VRA heat recovery
outdoor units to allow simultaneous heating and cooling in
multiple zones. Mode selection boxes are designed for in-
door installation only.
Mode selection boxes include solenoid valves which control
refrigerant flow through the individual indoor units so that
unit operation (heating or cooling) matches the comfort re-
quirements being sent by the occupant.
Mode selection boxes are sized to accommodate up to 24
indoor units. See Table 1.
Mode selection boxes are equipped with flared fittings for
indoor unit refrigerant piping connections and braze fittings
for outdoor unit connections.
Refer to the Product Specification bulletin (EHB) for the
proper use of mode selection boxes with matching VRA
heat recovery units, indoor units, branch pipes, line sets
and controls.
V8MSBB04 Shown
These instructions are intended as a general guide and do
not supersede local codes in any way. Consult authorities
having jurisdiction before installation.
CAUTION
As with any mechanical equipment, contact with sharp
sheet metal edges can result in personal injury. Take
care while handling this equipment and wear gloves and
protective clothing.
WARNING
Improper installation, adjustment, alteration, ser-
vice or maintenance can cause property damage,
personal injury or loss of life.
Installation and service must be performed by a li-
censed professional HVAC installer, service agency
or the gas supplier.
Failure to follow safety warnings and these instruc-
tions exactly could result in property damage, dan-
gerous operation, serious injury, or death.
Any additions, changes, or conversions required in
order for the appliance to satisfactorily meet the ap-
plication needs must be made by a licensed profes-
sional HVAC installer (or equivalent) using factory-
specified parts.
Do not use this system if any part has been under
water. A flood-damaged appliance is extremely dan-
gerous. Immediately call a licensed professional
HVAC service technician (or equivalent) to inspect
the system and to replace all controls and electrical
parts that have been wet, or to replace the system, if
deemed necessary.
WARNING
The Mode Selection Box is factory fitted with Black
plastic caps over the flare connection points. These
must be replaced with the supplied brass flare nuts.
Under no circumstances can the plastic caps be used
as a permanent seal even when not all ports are used.
A suitable blanking device must be fitted on all unused
ports.

2
System Piping
CAUTION
VRF system piping is customized for each installation.
The LVSS (Lennox VRF Selection Software) piping report
is an engineered design that must be followed. The piping
diagram or diagrams included within the LVSS report have
been prepared based on the information provided to the
Lennox VRF applications department.
When the indicated lengths change from the figures
stated within the report, it is imperative that prior to the
commencement of the refrigerant pipe work installation,
Lennox VRF applications department are informed of
these proposed changes.
Upon receipt of this new information the Lennox VRF
applications department will confirm any changes that
may be applicable to this installation. If changes are
required, a new piping diagram will be produced and will
supersede all other previously provided documents.
Failure to provide this information regarding changes
to the original design may lead to insufficient capacity,
equipment failure, warranty being made void and the
refusal to commission the system.
IMPORTANT
The Clean Air Act of 1990 bans the intentional venting
of refrigerant (CFC’s and HCFC’s) as of July 1, 1992.
Approved methods of recovery, recycling or reclaiming
must be followed. Fines and/or incarceration may be
levied for non-compliance.
CAUTION
To ensure proper system performance and reliability, Len-
nox does not recommend operation of VRF systems dur-
ing any phase of construction. Construction debris, low
temperatures, harmful vapors, and operation of the unit
with misplaced filters can damage the units. Failure to
follow these guidelines will result in the warranty being
voided.

3
Unit Dimensions - inches (mm)
MOUNTING
LUGS (4)
A
B
11-3/4
(298)
23-5/8
(600)
9
(229)
LOW
PRESSURE
GAS PIPE
TO OUTDOOR
UNIT
HIGH
PRESSURE
GAS PIPE
TO OUTDOOR
UNIT
LIQUID PIPE
TO OUTDOOR
UNIT
LIQUID
PIPE
GAS
PIPE
CONNECTIONS TO
OUTDOOR UNIT
CONNECTIONS TO INDOOR UNITS
V8MSBB01, V8MSBB02, V8MSBB03, V8MSBB04
CONDENSATE
DRAIN 1 (25) dia.
Model No. AB
in. mm in. mm
V8MSBB01 24-3/4 629 19-1/4 489
V8MSBB02 24-3/4 629 19-1/4 489
V8MSBB03 37-3/4 959 32-1/4 819
V8MSBB04 37-3/4 959 32-1/4 819
Model No.
Pipe Diameter - in.
Connections to Outdoor Unit Connections to Indoor Unit
Low Pressure
Gas Pipe High Pressure Gas Pipe Liquid Pipe 1Liquid Pipe 2Gas Pipe
V8MSBB01 7/8 3/4 1/2 3/8 5/8
V8MSBB02 7/8 3/4 1/2 3/8 5/8
V8MSBB03 1-1/8 7/8 5/8 3/8 5/8
V8MSBB04 1-1/8 7/8 5/8 3/8 5/8
13/8 x 1/4 in. adaptor furnished for liquid pipe connection to outdoor unit (if required).
25/8 x 1/2 in. adaptor furnished for gas pipe connection to outdoor unit (if required).

4
Installation Clearances - inches (mm)
CONNECTIONS TO
OUTDOOR UNIT
CONNECTIONS TO INDOOR UNITS
15-3/4
(400)
24
(610)
36
(914)
Minumum
36
(914)
Minimum
11-7/8 (300) Minimum
2 (51)
Minimum
CONCRETE CEILING
SUSPENDED CEILING
PIPE
HANGER
REFRIGERANT
PIPE
59 (1500)
Maximum
59 (1500)
Maximum
Required! Suitably sized access
panel required to provide full
access to electrical panel
Suitably sized access panel for gaining access to flare nuts or isolating
ball valves if mounted above a solid ceiling
Access panels are a requirement for system commissioning and future
preventative maintenance.

5
Mode Selection Box Location
Consider the following items when positioning the mode
selection box for installation:
• Sounds are made by refrigerant as solenoid valves
open and close inside the mode selection box. Do not
install the mode selection box where these sounds
may disturb building occupants.
• The mode selection box must be sloped 1/8” toward
condensate drain outlet.
• Provide sufficient clearance around mode selection
box to allow 3 feet of straight pipe before the first
elbow or branch pipe is installed. See Figure 3.
• If the unit is being installed in an application that
includes a sheet rock (plasterboard) ceiling, it is
required that an access panel be installed in a
suitable location. This will also allow access for
future maintenance (requirement of Lennox warranty
program).
Access is required during the commissioning process
to check the internal components, solenoid valves and
associated flare nuts (See page 3), and to check the
local disconnect.
ANGLE IRON
BOLTED IN PLACE
ACROSS WOODEN JOISTS
WOODEN JOIST
Ǫ´7+5($'(D
ROD ANGLE IRON
ACROSS
WOODEN JOISTS
$1&+25
CONCRETE CEILING
USING ANCHORS
Ǫ´7+5($'(D
ROD
STRUCTURALCEILING
LEVELING NUT
Ǫ´7+5($'('
52'
SUSPENSION
BRACKET
SUSPENSION
BRACKETS
%2;08676/23(´
72:$5'&21'(16$7('5$,1&211(&7,21
Mode Selection Box Installation
Use the provided suspension brackets to suspend the
mode selection box(es) between the outdoor and indoor
units. The mode selection box location must be able to
accommodate the size of the box, as well as the required
3 feet of straight pipe length between the box and the first
elbow or branch pipe. Refer to the dimension drawing on
Page 3 and Figure 3.
1. Make sure that the structural ceiling is able to support
the weight of the mode selection box(es). It may be
necessary to add extra support. If the structural ceiling
is constructed of concrete, install anchors to accept
four ⅜inch threaded rods to suspend the mode
selection box. If the structural ceiling includes wooden
joists, use angle iron or a Unistrut channel fixed
securely in place to accept the ⅜inch threaded rods.
See Figure 1.
Figure 1. Suspending Methods
Figure 2. Suspension Hardware
NOTE - Threaded rod (requirement of Lennox
warranty program) is the ONLY acceptable method of
suspending the unit; do not use chains or straps.
2. Slide one nut and one washer onto each threaded rod.
Use electrical tape to keep the washer from failing off.
Position the nuts slightly above the final resting place
of the four suspension brackets.
Model No. Application
V8MSBB01* 1 group, 1 indoor unit maximum
V8MSBB02 2 groups, 4 indoor units maximum per group,
8 indoor units maximum
V8MSBB03 4 groups, 4 indoor units maximum per group,
16 indoor units maximum
V8MSBB04 6 groups, 4 indoor units maximum per group
24 indoor units maximum
*Use with VHIA072 and VHIA096 only.
Table 1. Mode Selection Boxes
3. Raise the mode selection box and insert the threaded
rods into the suspension brackets. Slide a washer
and then a nut onto each rod below each suspension
bracket. Use the leveling nut (beneath suspension
bracket) to adjust the mode selection box. Remove
the electrical tape holding the upper washers and nuts
in place and tighten each of the four nuts above the
brackets down onto the brackets. The mode selection
box must be sloped 1/8” toward condensate drain
outlet.
4. Continue with refrigerant piping connections.
IMPORTANT
The Clean Air Act of 1990 bans the intentional venting
of refrigerant (CFC’s and HCFC’s) as of July 1, 1992.
Approved methods of recovery, recycling or reclaiming
must be followed. Fines and/or incarceration may be
levied for non-compliance.

6
Refrigerant Piping Connections
From
Outdoor
Unit First Elbow or
Branch Pipe
Conection
>36”
>36”
To
Indoor
Unit
MS
Box
Figure 3. Mode Selection Box Piping
WARNING
Refrigerant leaks are unlikely; however, if a refrigerant
leak occurs, open a door or windows to dilute the
refrigerant in the room. Turn off the unit and all other
appliances that may cause a spark. Call a licensed
professional HVAC technician (or equivalent) to repair
the leak.
Use only R410A refrigerant to charge this system. Use of
other refrigerant or gas will damage the equipment.
Do not allow air or other contaminants to enter system
during installation of refrigerant piping. Contaminants
will result in lower system capacity and abnormally high
operating pressures and may result in system failure or
explosion.
Insulate all refrigerant piping.
Refrigerant pipes may be very hot during unit operation.
Do not allow contact between wiring and bare copper
pipes.
After refrigerant piping connections have been
completed, check the system for leaks per
commissioning instructions.
IMPORTANT
Do not remove seals from refrigerant piping stubs until
connections are being made. This will prevent dust or
water from getting into the refrigerant piping before it is
connected.
WARNING
The Mode Selection Box is factory fitted with Black
plastic caps over the flare connection points. These
must be replaced with the supplied brass flare nuts.
Under no circumstances can the plastic caps be used
as a permanent seal even when not all ports are used.
A suitable blanking device must be fitted on all unused
ports.

7
Low-pressure gas pipe (1-1/8” O.D.)
High-pressure gas pipe (7/8” O.D.)
Liquid pipe (5/8” O.D.)
V8MSBB03
V8MSBB04
Low-pressure gas pipe (1-1/8” O.D.)
High-pressure gas pipe (7/8” O.D.)
Liquid pipe (5/8” O.D.)
13/8 x 1/4 in. adaptor furnished for liquid pipe connection to indoor unit (if required).
25/8 x 1/2 in. adaptor furnished for gas pipe connection to indoor unit (if required).
31 inch x 3/4 in. condensate drain adaptor furnished for field installation (if required).
Gas pipe O.D. (5/8” O.D.1)
Liquid pipe O.D. (3/8” O.D.2)
Drain connection (1” O.D.3)
Gas pipe O.D. (5/8” O.D.1)
Liquid pipe O.D. (3/8” O.D.2)
Drain connection (1” O.D.3)
Low-pressure gas pipe (7/8” O.D.)
High-pressure gas pipe (3/4” O.D.)
Liquid pipe O.D. (1/2” O.D.)
V8MSBB01*
V8MSBB02
Gas pipe O.D. (5/8” O.D.1)
Liquid pipe O.D. (3/8” O.D.2)
Drain connection (1” O.D.3)
Figure 4. Mode Selection Box Piping Connection Details
* Use with VHIA072 and 096 only. Connective branch pipe kit included with indoor unit.
• Refrigerant piping connections from outdoor unit(s)
are made with field-brazed connections. Field piping
connections for the outdoor unit gas pipes and liquid
pipe are provided on the right side of the mode
selection box.
• The four available mode selection boxes can
accommodate varying numbers of indoor units. See
Table 1 and Figure 4.
Outgoing gas and liquid connections for the indoor
units are on the front of the box. Connections to the
indoor units are made using the provided brass flare
nuts. Adaptors are provided with the mode selection
box to accommodate the use of different pipe sizes.
Refer to the LVSS (Lennox VRF Selection Software)
piping report for pipe sizes.
• Refer to the VRA heat recovery unit installation
instructions and product specifications (EHB) bulletin
for more detailed information on refrigerant piping
connections.
• Field refrigerant piping for the VRA heat recovery units
includes a variety of branch pipe kits, mode selection
boxes and field-provided piping.
Outdoor unit branch pipe kits are used to join multiple
outdoor units to reach the required system capacity.
Mode selection box branch pipe kits are available
to evenly split system capacity among the varying
numbers of mode selection boxes.
Indoor unit branch pipe kits split the system capacity
among up to four indoor units per connection from
each mode selection box. See mode selection box
branch pipe kits in Figure 8 and a typical VRA system
piping schematic in Figure 9.
• Allow a minimum of 3 feet between the mode selection
box and the first elbow or branch pipe in refrigerant
piping. See Figure 3.
• After refrigerant piping has been installed and checked
for leaks, apply the provided insulation sleeves over all
connections.

8
All lines must be individually insulated.
1. The seal on the mode selection box refrigerant piping
connections should remain in place until the last
possible moment. This will prevent dust or water from
getting into the refrigerant piping before it is connected.
2. Remove the black plastic caps from the mode selection
box connections and discard.
3. Slide the flare nuts onto the ends of the field-provided
refrigerant piping before using a suitable flaring tool to
flare the end of the copper pipe.
4. Apply recommended R-410A refrigerant lubricant to the
outside of the flared refrigerant lines (Figure 5-A).
5. Align the threaded connections with the flared refrigerant
lines. Tighten the flare nuts lightly at first to obtain a
smooth match (Figure 5-B).
Size
(Btuh) Liquid Line in. Vapor Line in.
7000
12000
15000
1/4 1/2
18000
24000
30000
36000
48000
3/8 5/8
Table 2. Refrigerant Piping Connections
(Up to a maximum of 32 ft. only)
6. Then, use two wrenches to continue to tighten the nuts
without twisting the pipes. Once snug, continue another
half-turn on each nut which should create a leak-free
joint. A torque wrench may be used to tighten flare
nuts using table 3 recommendations. See Figure 6. Do
not over-tighten a flared joint. Flared connections
should always be accessible and must be insulated
to prevent condensation.
7. After refrigerant piping has been installed and checked
for leaks, apply insulation over the piping and all flare
connections.
A
B
CANT ON THE OUTSIDE OF
THE FLARE
MALE FLARE
CONNECTION
Figure 5. Making Connections
(Male to Female Connection)
Figure 6. Tighten Flare Nut
To
Mode
Selection
Box
To Indoor Unit
Backup
Wrench
Torque
Wrench
Always refer to the provided piping diagram for correct pip-
ing sizes. Contact Lennox VRF Application support for as-
sistance with piping sizing or an updated piping diagram.
NOTE - 5/8” and 3/8” flare nuts are part of the reducing
adapters. Cut the reducing adapters to release the 5/8”
and 3/8” flare nuts.
IMPORTANT
Always use two wrenches when tightening flare nuts to
avoid twisting refrigerant piping. DO NOT over-tighten
flare nuts.

9
Outside
Diameter Recommended Torque No torque wrench available
Finger tighten and
use an appropriately
sized wrench to turn an
additional:
Inches U.S.
1/4” 15 ft.-lb. 1/4 turn
3/8” 26 ft.-lb. 1/2 turn
1/2” 41 ft.-lb. 7/8 turn
5/8” 48 ft.-lb. 1 full turn
Table 3. Flare Nut Torque Recommendations IMPORTANT!
Flared connections should always be accessi-
ble and must be insulated to prevent condensa-
tion. See Figure 7.
MS Box
Insulate ALL flared connections
to prevent condensation.
Figure 7. Insulate Flared Connections
Table 4. Piping Connection Information
Indoor Unit
Capacity BTUs
Indoor Unit
Factory Flare
Connection
Sizes Gas/Liquid
Piping Length
From MS Box
to Indoor Unit Is
equal to or less
than 32 ft.
Adaptor
Required for
Connection to
MS Box
Piping Length
from MS Box to
Indoor Unit is
greater than 32
ft.
Adaptor
Required for
Connection to
MS Box
7,000 1/2 x 1/4 1/2 x 1/4 Yes -Factory
Supplied 5/8 x 3/8 No
9,000 1/2 x 1/4 1/2 x 1/4 Yes -Factory
Supplied 5/8 x 3/8 No
12,000 1/2 x 1/4 1/2 x 1/4 Yes -Factory
Supplied 5/8 x 3/8 No
15,000 1/2 x 1/4 1/2 x 1/4 Yes -Factory
Supplied 5/8 x 3/8 No
18,000 5/8 x 3/8 5/8 x 3/8 No 3/4 x 1/2 Yes -Field
Supplied
24,000 5/8 x 3/8 5/8 x 3/8 No 3/4 x 1/2 Yes -Field
Supplied
30,000 5/8 x 3/8 5/8 x 3/8 No 3/4 x 1/2 Yes -Field
Supplied
36,000 5/8 x 3/8 5/8 x 3/8 No 3/4 x 1/2 Yes -Field
Supplied
48,000 5/8 x 3/8 5/8 x 3/8 No 3/4 x 1/2 Yes -Field
Supplied
54,000 5/8 x 3/8 5/8 x 3/8 No 3/4 x 1/2 Yes -Field
Supplied
Flare nuts may need further tightening. Check ALL system
flare nut connections during pressure testing process.
NOTE - For VHIA072/096 indoor units, refer to the VHIA
installation manual and system piping diagram for correct
pipe sizes.
NOTE - All VVCA units have brazed connections. Piping
length rules still apply.
IMPORTANT
It is imperative that the system piping is installed per the
LVSS (Lennox VRF Selection Software) piping report! If
the measurements on the Lennox VRF piping diagram
do not match the anticipated field measurements, contact
Lennox VRF Application Support before beginning piping
installation.

10
Figure 8. Mode Selection Box Branch Pipe Kits
(Liquid side used) (Liquid side used)
Low-pressure
side used
High-pressure
side used
Liquid
side used
V8MSBP01 V8MSBP02 V8MSBP03 V8MSBP04 V8MSBP05
OD:1/2
ID:1/4
ID:3/8
OD:1/2
OD:1/2
ID:1/2
ID:3/8
ID:1/2
ID:1/4
ID:3/8
ID:5/8
OD:5/8
ID:3/4
(ID:1/2)
OD:5/8
ID:3/8
ID:5/8
(ID:1/2)
OD:5/8
ID:3/8
ID:1/4
ID:5/8
OD:5/8
ID:3/4
(ID:1/2)
OD:5/8
ID:3/8
ID:5/8
(ID:1/2)
OD:5/8
ID:3/8
ID:1/4
ID:1-3/8
ID:1-5/8
ID:1-3/8
ID:1-5/8
ID:1-5/8
ID:1-3/4
ID:1-3/4
OD:1-5/8
ID:1-1/8
ID:1-1/4
OD:1-1/8
ID:1-1/8
ID:3/4
ID:7/8
OD:1-1/8
ID:3/4
ID:7/8
OD:1-1/8
ID:5/8
ID:1-1/8
ID:1-1/4
OD:1-1/8
ID:1-1/8
ID:3/4
ID:7/8
OD:1-1/8
ID:3/4
ID:7/8
OD:1-1/8
ID:5/8
ID:5/8
(ID:3/4)
OD:7/8
ID:7/8
OD:7/8
ID:7/8
ID:1
ID:5/8
(ID:3/4)
OD:7/8
ID:1/2
ID:5/8
(ID:3/4)
OD:7/8
ID:7/8
OD:7/8
ID:7/8
ID:1
ID:5/8
(ID:3/4)
OD:7/8
ID:1/2
ID:5/8
(ID:3/4)
OD:7/8
ID:7/8
OD:7/8
ID:7/8
ID:1
ID:5/8
(ID:3/4)
OD:7/8
ID:1/2
ID:1/2
(ID:5/8)
OD:3/4
ID:3/4
OD:3/4
ID:3/4
ID:7/8
ID:1/2
(ID:5/8)
OD:3/4
ID:3/8
ID:1/2
(ID:5/8)
OD:3/4
ID:3/4
OD:3/4
ID:3/4
ID:5/8
ID:1/2
(ID:5/8)
OD:3/4
ID:1/2
(ID:5/8)
OD:3/4
ID:3/4
OD:3/4
ID:3/4
ID:5/8
ID:1/2
(ID:5/8)
OD:3/4
ID:3/4
ID:7/8
ID:1-1/8
OD:1-3/8
ID:1-3/8
OD:1-3/8
ID:1-1/2
ID:7/8
ID:1-1/8
OD:1-3/8
ID:1-3/8
ID:3/4
ID:7/8
ID:1-1/8
OD:1-3/8
ID:1-3/8
OD:1-3/8
ID:1-1/2
ID:7/8
ID:1-1/8
OD:1-3/8
ID:1-3/8
OD:1/2
ID:3/8
ID:3/8
ID:1/4
OD:3/8
ID:1/4
OD:3/8
ID:3/8
Name Low-Pressure Gas Side Joints - Inch High-Pressure Gas Side Joints - Inch Liquid Side Joints - Inch Insulation
Material
(furnished)
(3 sets)
(3 sets)
(3 sets)
(3 sets)
(3 sets)
Adapter Pipe - Inch
OD:5/8
ID:1/2
ID:1/2
ID:3/4
OD:7/8
ID:5/8 OD:3/4
OD:3/8
ID:1/4
ID:3/8
ID:1/2 ID:5/8
OD:3/4
IMPORTANT
Locate first branch pipe kit of system centrally to ensure
even distribution of refrigerant.

11
Figure 9. Typical Piping Diagram
L1
0/
g3 g2 g1
G1
N3
(048)
N5
(048)
N6
(024)
N7
(024)
N9
(018)
N8
(009)
N2
(024)
N4
(009)
N1
(024)
N10
(018)
ABC
EFė
ęĘ
Ė
b
c
d
f
g
j
h
i
l
N11
(048)
p
N12
(048)
q
N13
(018)
r
k
mn
e
L2
L9L8
L7
L13
L11
L10 L12
L3
a
MS1
MS2
MS3
MS4
MS5
MS6
L4
L5
L6
D
MS7
(96) (120) (120)
NOTE - Indoor and outdoor unit
capacities are shown in parenthesis
LEGEND
Branch Pipe
Mode Selection
Box (MS)
Indoor Unit
PIPE AND COMPONENT NAMES
Name Designation
Outdoor Unit Connection Pipe g1, g2, g3, G1
Outdoor Unit Branch Pipe Assembly L, M
Main Pipe L1
Indoor Unit Main Pipe L2, L3, L4, L5, L6, L7, L8, L9, L10, L11, L12, L13
Branch Pipe Assembly between Main Pipe and Mode Selection Box (MS) A, B, C, D, E, F
Mode Selection Box (MS) MS1, MS2, MS3, etc.
Branch Pipe Assembly between Mode Selection Box (MS) and Indoor Unit I, II, III, IV
Indoor Unit auxiliary pipe between Mode Selection Box (MS) and downstream
Branch Pipe joint
a, g, j, k
Indoor Unit auxiliary pipe from Indoor Unit to the nearest Branch Pipe joint or
direct connected Mode Selection Box (MS)
b, c, d, e, f, h, i, l, m, n, p, q, r
Indoor Unit N1, N2, N3, etc.

12
FIRST ELBOW OR
BRANCH PIPE
CONNECTION
24” REQUIRED
36” PREFERRED
24” REQUIRED
36” PREFERRED
To Indoor Unit
From MS Box or
Previous Indoor
Unit
To Indoor Unit
Figure 10. Inches of Straight Pipe Before and After Branch Pipe Kit
Branch Pipe Kit Placement
Provide 24 inches to 36 inches of straight pipe before
and after each branch pipe kit to avoid creating refrig-
erant turbulence and flash points. Failure to follow 24
inch minimum guideline can lead to reduced capacity
and equipment damage. See Figure 7.
NOTE - A maximum of four indoor units can be connected to one port on the Mode Selection Box. The combined maxi-
mum capacity of all indoor units connected to one port on a Mode Selection Box must not exceed 54,000 BTUs.
Top View
Branch pipe kits MUST be installed horizontal +/- 10°
V8IDBP01
,'
,'
2'
,'
2'
,'
,'
,'
,'
2'
2'
,'
,'
,'
2'
,'
2'
,'
Name Gas Side Joints (inch) Liquid Side Joints (inch)
Insulation
Material
(furnished)
(2 sets)
CAUTION
24 inches minimum straight pipe required before and after
branch pipe kit to prevent capacity loss and equipment
damage.
IMPORTANT
OPERATION NOTE — All indoor units within a group
(units connected to a single piping connector on the mode
selection box) must operate in the same mode at all times.

13
Mode Selection Box Wiring Connections
In the U.S.A., wiring must conform with current local codes
and the current National Electric Code (NEC). In Canada,
wiring must conform with current local codes and the current
Canadian Electrical Code (CEC).
Refer to unit nameplate for minimum circuit ampacity and
maximum overcurrent protection size.
NOTE - Three-conductor shielded cable must be used for
the communication wiring. This is necessary to ensure
proper system communication and operation.
Remove the cover panel from the mode selection box and
locate the terminal strip.
Connect properly sized power wiring and three-conductor
shielded cable as shown.
Indoor units and mode selection boxes on the same
refrigeration circuit should have a common power supply
but must have an independent disconnect switch installed
adjacent to the mode selection box for servicing and
maintenance purposes. Indoor unit and mode selection
box power supply MUST not be taken from the outdoor
unit. Always follow NEC/CEC and Local Codes.
Condensate Drain Connection
A 1 inch OD condensate drain connection is provided
on the mode selection box. Route condensate piping to
a suitable drain per best practices, taking care to slope
the drain properly to ensure drainage. A 1 inch to ¾ inch
adaptor is provided if ¾ inch condensate pipe is preferred.
The mode selection box must be sloped 1/8” toward drain
outlet.
WARNING
Isolate the power supply before accessing unit electrical
terminals.
Install unit so that unit disconnect is accessible.
Follow all local and national codes, as well as this
installation instruction, during installation. Do NOT
overload electrical circuit, as this may lead to failure and
possible fire.
Use specified wiring and cable to make electrical
connections. Clamp cables securely and make sure that
connections are tight to avoid strain on wiring. Insecure
wiring connections may result in equipment failure and
risk of fire.
Wiring must be installed so that all cover plates can be
securely closed.
This unit must be properly grounded and protected by a
circuit breaker. The ground wire for the unit must not be
connected to a gas or water pipe, a lightning conductor or
a telephone ground wire.
Do not connect power wires to the outdoor unit until all
other wiring and piping connections have been completed.

14
PQE CommunicaƟon wiring
L1/L2/L3 Three-Phase power wiring
Electrical disconnect switch
Legend
Power DistribuƟon Box
L1/L2/L3
MS
Box
MS
Box
L1/L2
L1/L2
L1/L2
L1/L2
L1/L2
L1/L2
L1/L2
PQE
PQE
PQE
PQE
L1/L2
L1/L2
L1/L2
L1/L2
PQE
PQE
PQE
PQE PQE
L1/L2/L3
L1/L2/L3
L1/L2
L1/L2 Single-Phase power wiring
PQE
PQE
Figure 11. Typical Power Wiring Diagram (VRF Heat Recovery System Shown)

15
Figure 12. Typical Communication Wiring Diagram (VRF Heat Recovery System)
NOTE - Each communication wire from the mode selection box should follow the refrigerant piping for that port.

16
Figure 14. V8MSBB02 Connections
REFRIGERANT PIPING
COMMUNICATIONS CABLE
gnituoRelbaCsnoitacinummoCdnagnipiPsnoitcennoCgniriW
NOTE - Use 3-conductor, shielded cable
for communication wiring.
NOTE - Indoor communications cable
must match indoor piping connections.
208-230V
M-O
M-I
TRANS
T2C1 T2C2
Y/G
CN13
BLUE WHITE BLACK BLACK
YELLOW
ORANGE YEIIOW GRAY
BLACK
L1 L2
2# MS UNIT
1# MS UNIT
(P Q E)
(P Q E)
OUTDOOR UNIT
1# MS UNIT
06í,1'22RMSíOUTDOOR
NO.2 NO.1
12
12
(P Q E)
INDOOR UNIT
INDOOR UNIT
PQE PQE PQE
EXVA
208-230V
M-O M-I
TRANS
T2C1 T2C2
CN10 CN13
TO OUTDOOR TO INDOOR
1 2
S1
O N
L1 L2
Y/G
YEIIOW GRAY BLACK BLACK
RED
BROWN
1# MS UNIT
1# MS UNIT
2# MS UNIT
OUTDOOR
UNIT
INDOOR
UNIT (P Q E)
(P Q E)
gnituoRelbaCsnoitacinummoCdnagnipiPsnoitcennoCgniriW
REFRIGERANT PIPING
COMMUNICATIONS CABLE
NOTE - Use 3-conductor, shielded cable
for communication wiring.
NOTE - Indoor communications cable
must match indoor piping connections.
EXVA
PQEPQE
Figure 13. V8MSBB01 Connections
VHIA072 and VHIA096 Only
To other MS boxes on
same refrigeration circuit.
To other
MS boxes
on same
refrigeration
circuit.

17
Figure 15. V8MSBB03 and V8MSBB04 Connections
Wiring Connections
208-230V
M-O
M-I(1~4)
TRANS1
M-I(5, 6)
TRANS2
T4C T4C1
BLUE
RED
Y/G
POWER IN TO INDOOR 6 TO INDOOR 5 TO INDOOR 4 TO INDOOR 3 TO INDOOR 2 TO INDOOR 1
L1 L2
TO OUTDOOR
YEIIOW BLACK
YEIIOW GRAY BLACK
BLUE WHITE BLACK BLACK RED BROWN
PURPLE GRAY BLACK BLACK ORANGE GREEN
ORANGE BLUE WHITE
BLACK
Piping and Communications Cable Routing
REFRIGERANT PIPING
COMMUNICATIONS CABLE
NOTE - Use 3-conductor, shielded cable for communication wiring.
NOTE - Indoor communications cable must match indoor piping connections.
2# MS UNIT
1# MS UNIT
(P Q E)
OUTDOOR
UNIT
1# MS UNIT
MS-INDOOR MS-OUTDOOR
NO.6 NO.5 NO.4 NO.3 NO.2 NO.1
(P Q E)
123456
1234 56
(P Q E)
(P Q E)
(P Q E)
(P Q E)
(P Q E)
INDOOR UNIT
INDOOR UNIT
INDOOR UNIT
INDOOR UNIT
INDOOR UNIT
INDOOR UNIT
PQEPQE PQEPQE PQE PQE PQE
EXVA
Network Address and Commissioning
After the system has been installed, use the system
remote control to assign a separate address for each of
the indoor units as part of the commissioning procedure.
To other MS boxes on
same refrigeration circuit.
Mode selection boxes do not require an address; however,
each indoor unit connected to the mode selection box
must be assigned an individual address.

18
Refrigerant Piping
• Use the provided branch pipe kit to connect both sets
of refrigerant line connections.
• Locate branch pipes no more than 32 feet from indoor
unit.
Figure 16. Piping for VHIA072 or 096 when V8MSBB01 is Greater Than 15 ft. (4.5 m) Away - VRA Heat Recovery
• Piping between branch pipe and indoor unit: liquid line
= 3/8” and gas line = 5/8“.
• Consult LVSS piping report diagram for all other piping
sizes.
Figure 17. Piping for VHIA072 or 096 when V8MSBB01 is Equal To or Less Than 15 ft. (4.5 m) Away - VRA Heat
Recovery
3/8” 5/8”
VHIA072/096
V8MBB01
V8MBB01 Piping and Wiring Connection to VHIA072 or 096
3/8”
5/8”
32’ maximum distance
between branch pipes and indoor unit
See piping report
for pipe sizes
Liquid branch pipe
(Provided with Mode
Selection Box)
Gas branch pipe
(Provided with Mode
Selection Box)
Liquid branch pipe
(Provided with VHIA unit)
Gas branch pipe
(Provided with VHIA unit)
VHIA072/096V8MBB01
Top view of piping. Branch pipe kits MUST be installed level +/- 10°.

19
Figure 18. VHIA072 and 096 Refrigerant Connections
Figure 19. VHIA072 and 096 Communication Terminal Block
System Communication Wiring
• Connect PQE wiring to Board A of the VHIA072 or 096
Indoor unit.
Incoming
liquid line
connection
Incoming
suction line
connection
Connect these
two pipes as
shown in “A”
below.
Connect these two
pipes as shown in
“A” left.
Incoming
liquid line
connection
Incoming
suction line
connection
A
Terminal Block A
PQE Terminal Block B PQE

20
Troubleshooting
0 OFF
2 COOLING MODE
3 HEATING MODE
4 FORCED COOLING MODE
5 MAIN COOLING MODE
6 MAIN HEATING MODE
LED Lamp Normally ON Slow Flash Flash
LED 1 Outdoor unit ON Outdoor unit standby Outdoor unit communication error
LED 2 Indoor unit ON of this MS Indoor unit OFF this MS Indoor unit communication error
LED Lamp Definitions
Operation Mode References
