Lennox HYDROCONTROL User manual

-0-HYDROCTROL-IOM-1903-E
CHILLERANDFANCOILCONTROL
HYDROCONTROL
HYDROCONTROL-IOM-1903-E

-1-HYDROCTROL-IOM-1903-E

-2-HYDROCTROL-IOM-1903-E
TABLE OF CONTENTS
HYDROCONTROL
3
4
4
4
5
5
INTRODUCTION
TECHNICAL SPECIFICATIONS
Technical features
INSTALLATION
Dimensions & weight
Compatibility
Opening the HMI
Fastening
Installation, operating
and maintenance
Ref : HYDROCONTROL-IOM-1804-E
6
Wirings 8
Software installation
9
14
OPERATING
Fan Coils settings
HMI settings
18
Password management
20
Chiller screens 23
Fan coil screens 24
Schedule management 27
Multi temp view
HYDROCONTROL Home page 17
28
Set the fan coil using the HMI 29
Connect the HMI using a browser
19
HYDROCONTROL Start up
30
Diagnostics 30
Chiller parameter (Climatic™)
APPENDIX 31
Screen list
DIP Switch Position 32

-3-HYDROCTROL-IOM-1903-E
INTRODUCTION
Safety codes &regulations
THE DISPLAY MUST BE INSTALLED IN ACCORDANCE WITH LOCAL SAFETY CODES AND REGULATIONS.
PLEASE READ CAREFULLY THE MANUFACTURER’S INSTRUCTIONS BEFORE STARTING THIS DISPLAY.
Version concerned
The following manual is only valid for version higher or equal to 11.7 of LennoxHydrocontrol display. In case of Chiller connected to
the LennoxHydrocontrol the version of Chiller control must be higher than Ch60 v2r3.3 or eCH v0r2.2
WARNING - All the technical and technological information contained in this manual, including any drawing and technical descriptions
provided by us, remain the property of LENNOX and must not be utilised (except in operation of this product),reproduced, issued to or
made available to third parties without the prior written agreement of LENNOX. The technical information and specifications contained
in this manual are for reference only. The manufacturer reserves the right to modify these without warning and without obligation to
modify equipment alreadysold.
WARRANTY
The warranty of the display is subject to the warranty definitionsas agreed upon in the order.
It is expected that the design and installation of the display utilises good working practices.
The warranty will be legally null and void if:
•Modifications have been made to the equipment without prior written permission by LENNOX.
•Settings and protections have been modified without prior written permission by LENNOX.
•The equipment has not been installed and/or connected in accordance with the installation instructions.
•The equipment is being used improperly,incorrectly, negligently or not in accordance with its nature and/or purpose.
In these circumstances LENNOX is indemnified from any product liability claims from third parties.
Abbreviations
The following abbreviations are used in this document
. HMI = LennoxHydrocontrol display
. FCU = FanCoil units

-4-HYDROCTROL-IOM-1903-E
TECHNICAL SPECIFICATIONS
Technical features
The HMI is a touch-sensitive screen LCD display. It is managing up to 32 FCU. This display can also be connected to 1 Chiller
which allows to managed the working mode changeover and the water temperature. The HMI is able to control up to 9 different
schedules.
Six languages are supported by the HMI
- English
- French
- Italian
- Spanish
- German
- Portuguese
The HMI uses 24Vac 50/60Hz power supply. In case of power failure the HMI will use its supercapacitor for internal memory.
2 entire days are necessary to fully charge the supercapacitor
The HMI is compatible with the LENNOX Chillers with a version higher than Ch60 v2r3.3 or eCH v0r2.2 and the FCU mounted with
the CTRL2303D4A-BDC controller. It can be used even if the FCU already have a connected thermostat.
Dimensions & weight
The following table indicates the dimensions and the weight of the HMI:
Device Height
(mm) Width (mm) Thickness (mm) Weight (g)
HMI 142 208 35 460
Compatibility
The HMI offers a web access via an Ethernet connection using a web browser.
The connection between HMI and FCU uses the MS/TP BACnet protocol.
The HMI can be connected to the FCU even if a thermostats is already connected.

-5-HYDROCTROL-IOM-1903-E
INSTALLATION
Fastening
The HMI is a wall mounted display. To fasten the HMI on a wall we recommend to use the dedicated holes at the back of the
device.
There are two possibilities to fasten the HMI.
1. Partially build in the wall
Cut a hole into the surface
Mount the HMI using the 4 outside mounting holes
Opening the HMI
To access the wiring and fixing area you have to open the HMI on the top of the device and spin the screen. /!\ The display is
screwed to the black case.
Picture1: Top view of the Hydroctonrol
Picture2: Hydrocontrol schematic (Partially build in wall)

-6-HYDROCTROL-IOM-1903-E
INSTALLATION
Wirings
Two different connections are necessary. But some other can be added in case of option
1. Power supply connection
The 24Vac 50/60 Hz power supply is required and has to be connected in the following pins: See picture index 1
2. BACnet MS/TP connection
Connect the BACnet MS/TP network to the dedicated pins. We recommend to use shielded twisted pair cable. The daisy-
chain connection is required. (star and ring connections are forbidden): See picture index 2
Chiller connection (Option)
In case the HMI is also connected to the Lennox chiller, The BACnet MS/TP communication card (S/n: (EL)4770643E) is
required on the controller of the chiller.
3. Ethernet connection (Option)
The HMI offers the possibility to be a web server. This means the display is also accessible via internet. You can connect
the HMI to your network using the RJ45 cable. See picture index 3
2. On a wall
Place the HMI on the wall and mark at least 4 points for screws and the hole for electrical wirings
Cut the hole for wiring and drill screw holes
Mount the HMI on the surface
12
3
Picture3: Hydrocontrol schematic (On a wall)
Picture4: Hydrocontrol main board

-7-HYDROCTROL-IOM-1903-E
INSTALLATION
Other devices
•HMI at the end of daisy-chain connection:
Set the jumper of the MS/TP communication card according the following:
•HMI in the middle of daisy-chain connection:
Set the jumper of MS/TP communication card according the following:
Other devices
Picture6: BACnet MS/TP wiring example (HMI in middle of the line)
Picture5: BACnet MS/TP wiring example (HMI in middle of the line)

-8-HYDROCTROL-IOM-1903-E
INSTALLATION
Software installation
The HMI is supply without the HYDROCONTROL application loaded inside it.To load the application you must use one USB flash
drive with the both files (ask them to a LENNOX technician):
•Lennox Suite V11_7.PDB (You have to use at least the version 11.7)
•eTCH_V340_B-3935.FLS
Then insert the flash drive in one of the USB connectors of the HMI and power the display. The following display will appear:
Press “Oui”(yes) and the installation will start and the next screen will appear:
Wait the end of the installation
Once it is done please remove the flash drive and the HMI will restart automatically
Picture8: Update home screen
Picture9: Update progression
Picture10: Update finished
Picture7: USB port for software update

-9-HYDROCTROL-IOM-1903-E
OPERATING
Fan coil settings
To make the FCU communicating with the Hydrocontrol and working accordingly your requests you will have to set them with the
EC-Smart_Vue thermostat.
Connect the thermostat to the FCU controller using a RJ45 cable
To access all the parameters, from the home screen press the menu button for 5 seconds.
Use the arrows to set the password to 9995
You will then access the different setting menu. Use the button menu to choose the submenu you want to go and use one of both
arrow to enter inside the submenu. Once you are inside the submenu you the button menu to choose the parameter you want to set
and use the arrow to change the value. Once the value is set use the button menu to go to “Exit” and press an arrow to validate and
come back to the submenu selection
Home scrren
Password
Submenu 1
Setting 1
Setting 2
Setting n
Exit
Submenu 2
Setting 1
Setting 2
Setting n
Exit
Submenu n
Setting 1
Setting 2
Setting n
Exit
Exit
Picture11:EC-Smart-Vue / CTRL2303D4A-BDC
EC-Smart-Vue
FCU Controller:
CTRL2303D4A-BDC

-10-HYDROCTROL-IOM-1903-E
OPERATING
Once you enter in the submenu list you have access to (See the end of this Paragraph):
−Unit: set here the unit in °Cof °F
•Use directly the arrow to change the value
−SYS CFG: System configuration Use it to set the system configuration
•Type: Choose the system type (2 Tubes/ 4 Tubes…)
•Ctrl: Choose the control type (Local, Master, Slave).
•TEMPCTRL: Choose the temperature control type
•Room: Set the room number to configure the master/slave network.
•FAN: Choose the fan type.
•FANM: Choose the fan functioning mode.
•Exit
−IN CFG: Inputs configuration Use it to set the inputs of the controller
•SI3: Set the source of SI3
•UI2: Set the source of UI2
•DI4: Set the source of DI4
•DI5: Set the source of DI5
•DI6: Set the source of DI6
•Exit
−OUT CFG: Outputs configuration Use it to set the outputs of the controller
•CLG TYPE: Set the type of the cool water valve
•CLG NO/NC: set the direction of the cool water valve
•HTG TYPE: Set the type of the heat water valve (only for 4 tubes)
•HTG NO/NC: set the direction of the heat water valve (only for 4 tubes)
•Exit

-11-HYDROCTROL-IOM-1903-E
OPERATING
−INPUTS: Display input values Use it to see the current input values
•UI1: Displays the UI1 value (Volt)
•Disch Temp: Displays the discharge (supply) temperature
•Return Temp: Displays the return temperature
•Water Temp: Displays the water temperature
•SP Offset UI2: Displays the set point offset input on UI2
•Space Temp SI3: Displays the room temperature
•DI4: Displays the DI4 status
•DI5: Displays the DI5 status
•DI6: Displays the DI6 status
•Exit
−OUTPUTS: Equipment overrideUse it to override the current controller outputs. Press both arrow buttons at the same time to
release an override)
•CLG/CHG Valve: Override the water cooling valve position (only if cooling configured)
•Heat Valve: Override the water heating valve position (only if heating configured)
•Elec Heat: Override the electrical element (PWM)
•Damper: Override the damper position
•Exit
−GEN CFG: General Configuration Use it to set the general configuration and the BACnet MS/TP address
•Mac Address: Set the BACnet MS/TP address. (Unique from 10 to 32)
•Subnet: Set the subnet parameter
•Dev ID: Hardware version of the controller
•Contrast: Set the contrast of the EC Smart View
•Baud Rate: Set the BACnet MS/TP Baud Rate value
•Exit

-12-HYDROCTROL-IOM-1903-E
OPERATING
−CALIB: Calibration Calibrate the temperature, humidity and motion sensor reading. On each screen use the arrow to change
the calibration and the menu button to validate the value.
•1st screen: Temperature calibration.
•2nd screen: Humidity calibration.
•3rd screen: Motion sensor calibration
•Exit
−EXIT Press one of the arrow buttons to go back to the home screen
The FCU controller can be addressed using the EC-Smart-View thermostat or using the DIP switch directly physically on the
controller. To set it directly using the DIP see appendix 2 « DIP switch position » page 32.To set the MAC address using the EC-
Smart-View enter the main menu with the password. Once you are in the main menu go to the GEN CFG menu by pressing 7 times
on the menu button and 1 time on one arrow button to enter in it. You access directly to the MAC address setting so use the arrow
to select the MAC address (10-32) then press 5 times on the menu button to access the Exit and press one arrow to validate. /!\If
the address is set manually with the DIP you will not be able to change it using the EC-Smart-View. To reset the manual address
setting set all DIP switches in OFF position like the following:
ECB-PTU-207
Submenu
Parameter
Default
Valid Choices
Description
SYS CFG
TYPE
1CL
2 Pipes cooling
2CL-EH
2 Pipes cooling with electric heater
3CO
2 Pipes changeover
4CO-EH
2 Pipes change over with electric heater
5HT
2 pipes heating
6HT-EH
2 pipes heating with electric heater
X 7 CL-HT
4 pipes
8CL-HT-EH
4 pipes with electrical heater
CTRL
X 1 LOCAL
Stand alone FCU
2 MASTER
Master FCU
3 SLAVE
Slave FCU
TEMPCTRL
X 1 LOCAL
Local space temperature is used
2 MASTER
Local space temperature is used and sent
over the network
3 SLAVE
Space temperature of master controller is
used
4 AUTO
Space temperature of master controller is
used with fallback to local value
ROOM 1 0 127
Room value for master/slave network
FAN
1 NONE
Fan control not used
X 2 ECM
ECM motor (0
-10V output)
3 3SP
3 Speed fan is used
FANM
1ON
Fan control between minimum speed and
100%
2 AUTO
Fan control based on terminal load
(stopped when dead band)
X 3 SMART
Fan control based on terminal load when
unoccupied, controlled between
minimum speed and 100% in other
occupancy
1### ### OFF
2### ### OFF
4### ### OFF
8### ### OFF
16 ### ### OFF
32 ### ### OFF
64 ### ### OFF
-
EOL
EOL
DIP Switch

-13-HYDROCTROL-IOM-1903-E
OPERATING
ECB-PTU-207
Submenu
Parameter
Default
Valid Choices
Description
IN CFG
SI3
1 UNUSED
Not used
2 DISCH TEMP
Discharge temperature sensor connected to
this input
3 RETURN TEMP
Return air temperature sensor connected to
this input
4 WATER TEMP
Water temperature sensore connected to
this input
X 5 SPACE TEMP
Room temperature sensor connected to this
input
UI2
1 UNUSED
Not used
2 DISCH TEMP
Discharge temperature sensor connected to
this input
3 RETURN TEMP
Return air temperature sensor connected to
this input
4 WATER TEMP
Water temperature sensore connected to
this input
X 5 SETPOINT OFFSET
Setpoint offset connected to this input
DI4
1 UNUSED
Not used
X 2 WINDOW NO
Window contact normaly open
3 WINDOW NC
Window contact normaly close
DI5
1 UNUSED
Not used
2 AUX CONT NO
Auxilliary contact normaly open
3 AUX CONT NC
Auxilliary contact normaly close
4 CHG OVER HEAT
Change over contact (TRUE = Heat / FALSE =
Cool)
5 CHG OVER COOL
Change over contact (TRUE = Cool / FALSE =
Heat)
X 6 COND SENSOR NO
Condensation sensor normaly open
7 COND SENSOR NC
Condensation sensor normaly close
DI6
X 1 UNUSED
Not used
2 AUX CONT NO
Auxilliary contact normaly open
3 AUX CONT NC
Auxilliary contact normaly close
4 CHG OVER HEAT
Change over contact (TRUE = Heat / FALSE =
Cool)
5 CHG OVER COOL
Change over contact (TRUE = Cool / FALSE =
Heat)
6 OCC SENSOR NO
Occupancy sensor normaly open
7 OCC SENSOR NC
Occupancy sensor normaly close
OUT CFG
CLG TYPE
X 1 UNUSED
Cooling valve is not used
2 0-10V
0-
10V cooling valve only is used
3 THERMAL
Thermal and 0
-10V cool valve is used
4 ON_OFF
On/Off and 0
-10V cool valve is used
5 FLOATING
Floating and 0
-10V cool valve is used
CLG NO/NC
X 1 NORM CLOSE
Cooling valve is normaly close
2 NORM OPEN
Cooling valve is normaly open
HTG TYPE
1 UNUSED
heating valve is not used
X 2 0-10V
0-
10V heating valve only is used
3 THERMAL
Thermal and 0
-10V heat valve is used
4 ON_OFF
On/Off and 0
-10V heat valve is used
5 FLOATING
Floating and 0
-10V heat valve is used
HTG NO/NC
X 1 NORM CLOSE
Heating valve is normaly close
2 NORM OPEN
Heating valve is normaly open
GEN CFG
MAC
ADDRESS 10 1126
BACnet MS/TP address of the controller
SUBNET 1 1 12
Subnet address
CONTRAST
100 0100
Contrast value
BAUD RATE
1 9.6
BAUD = 9600
2 19.2
BAUD = 19200
3 38.4
BAUD = 38400
4 76.8
BAUD = 76800
X 5 AUTO
The BAUD will be automatically search on
the network

-14-HYDROCTROL-IOM-1903-E
OPERATING
HMI settings
To access the following setting one account need to be logged on the HMI (see Password management paragraph)
Except for the date and the hour the HMI setting are set by default and it is not required to set them during start up.
To access the HMI setting click on the arrow button at the top left on the screen and then click on settings
Then you will access the following setting menu:
The setting menu is divided into 7 different parts.
If you click on the clock you will access the time setting. To set the hour just click on the part you want to edit and use the numeric
keypad to enter the correct value
Picture12: Home page (Admin) Picture13: Home page (HMI setting access)
Picture14: Main setting menu
Picture15: Date / Time setting

-15-HYDROCTROL-IOM-1903-E
OPERATING
enteliTOUCH setup:
You can set the device address (BACnet Ethernet),the device name, the volume, backlight time out. The photo gallery start is not
available until one USB drive with picture inside is not connected. The pictures are displayed according the following:
1) Root directory Alphanumeric order
2) Folder directory The folder are chosen using alphanumeric order
3) Inside the folder The pictures are displayed using alphanumeric order
You can download some graphic view (Only for Lennox technicians) using the web browser. If you access this screen directly with
the HMI the download is replaced by the Calibration.
To edit one screen click on modify (HMI view) and use the alphanumeric keypad to edit the field or drop the list and select the
correct field value.
Network Setup:
You can set the remote access from this screen. The modification is available only in the HMI screen. If you access this screen via a
browser you will not be able to modify the settings.
In case you have more than 1 HMI connected on your network remove the BACnet Ethernet flag. The BACnet /IP is not used and
has to be unchecked.
If the remote access flag is not checked the connection from a computer will not be allowed. In the HMI screen you will also be able
to modify the remote access port which is by default equal to 80.
Picture16: enteliTOUCH setup
Picture17: Network setup

-16-HYDROCTROL-IOM-1903-E
OPERATING
Access setup:
The first field « Login Required » has to be checked if you want to have a password management. If this flag is not checked all
users will be able to modify some FCU and chiller settings even if there is no account logged in.
The alarm pop up at the bottom of the screen can be disabled if the «Disable Alarm Pop-up »is flagged
You can select the default screen and welcome screen (see Appendix 1: “Screen list” for screen name)
Default screen This is the default screen which will appear as home page or when the user touches the default graphic button on
menu bar.
Welcome screen this screen is displayed on power-up and when a user logs off. This graphic is not display by the web access.
The language can be selected from this screen. If the language is also available inside the HYDROCONTROL application, the
application will also changes its language. Otherwise the application language will remain the same as the previous one.
User Setup:
To add one new user touch “Add New User”. Then follow the steps:
1) Enter the name using the keypad
2) Enter the password using the keypad (Exactly same screen than step 1)
3) Modify the start graphic by dropping the list (see Edit user screen)
4) Modify the Auto logoff period (use the modify button when using HMI) (see edit user screen)
5) Press the green button “OK” to validate
Picture18: Access setup
Picture19: Alarm pop up
Picture20: User setup

-17-HYDROCTROL-IOM-1903-E
OPERATING
To edit one user select the user on the screen and touch “edit user info”
Then modify the fields using the modify button for HMI view or directly by clicking on the field for web view. Once it is done touch the
green button “OK” to validate.
Graphic mode:
The graphic mode is displaying the HYDROCONTROL application using the default graphic set in the Access setup menu.
User Logoff:
It is login off the current user and it displays automatically the default graphic
HYDROCONTROL Home page
The home page of the HYDROCONTROL application is divided in 3 main screen depending on the user level
1) No user logged on
This screen gives the access to:
- The HMI menu (arrow top left)
- FCU menus (button FCU)
- Chiller menu (Button chiller)
- The time and date
- The average of all air temperature measured by the FCU (Indoor at the top right) (Note: hidden if the chiller option is disabled)
- The outside air temperature measured by the chiller (Note: hidden if the chiller option is disabled)
- HYDROCONTROL version number (at the bottom right)
Picture21: Edit user account
Picture22: Homepage (No user logged on)

-18-HYDROCTROL-IOM-1903-E
OPERATING
2) User logged on
This screen adds the access to
- Times/schedule menu (button times)
Moreover the word “User” is displayed at the bottom right just above the HYDROCONTROL version number.
3) Admin logged on
This screen adds the access to:
- Setting menu (button settings)
The word “User” is replaced by the “Admin”
Note: For all levels if the chiller option is disable, the chiller button will be hidden
Password management
Three main levels of password are managed by the application.
1) No connection: It is a visualisation level. The user has access only to functioning displays. The schedule and setting displays
are hidden.
2) User level: This is a operator level. The user has the access to schedule menus. He can change some set points, create the
schedule and add the FCU/chiller to the schedule zones.
3) Admin level: The user has the full access to the application. He can change the HMI settings and the application settings. This
mode is required during the start up.
By default the users/passwords are:
- user / user
- delta / login
Picture23: Homepage (User logged on)
Picture24: Homepage (Admin logged on)

-19-HYDROCTROL-IOM-1903-E
OPERATING
The usernames and password can be change in the HMI setting (see HMI settings paragraph / User setup). Note that the admin
level is mandatory and can’t be deleted but you can change the name and the password. All the following accounts which will be
created will have the user level.
To log in expend the menu bar and touch the Login button.
Use the drop list to select the account and enter the password using the keypad.
To log off expend the menu bar and touch the Logoff button or wait the period time define in user account.
HYDROCONTROL Start up
To setup the HYDROCONTROL application the admin password is required.
From the home page go to the setting page using the setting button.
1) First address: Select the first address of the FCU connected to the HMI i.e. FCU addresses = 12-13-14-15 first address =
364012
2) Number of FCUs: Select the number of fan coil connected to the HMI
3) Changeover:
1) Chiller: the FCU changeovers are based on the chiller changeover
2) First FCU: the FCU changeovers are based on the changeover of the FCU which have the first address
3) Cooling: All the FCU are forced in cooling mode
4) Heating: All the FCU are forced in heating mode
4) Reset FCU config: Check this flag to reset the display of the FCU according to there configuration
5) Chiller installed: If the HMI is connected to one chiller then check this flag.
6) Language: The HMI language will also change according the selection
7) IP address / Subnet Mask / Gateway: You can set here the Ethernet connections
8) DHCP:By default the HMI is not set as DHCP. must be flag for DHCP connection
9) MS/TP: This flag must be always checked to have the BACnet MS/TP connection with the FCU and the chiller. The drop list at
the right of MS/TP flag is the MS/TP baud rate. By default the baud rate is 38400.
/!\To change the IP / subnet / getaway setting please read the instruction on next page.
Picture25:Log in Picture26:Log out
Picture27: Start up settings
