Lenovo A319 User manual

English/Français
Quick Start Guide v1.0
Lenovo A319

English
Learning more
Getting support
Read this guide carefully before using your smartphone.
To learn more information about your
Lenovo smartphone and obtain the latest
smartphone manuals, go to:
http://support.lenovo.com/.
For support on network service and billing,
contact your wireless network operator.
For instructions on how to use your
device, go to:
http://support.lenovo.com/.
Legal notices Lenovo and the Lenovo logo are
trademarks of Lenovo in the United States,
other countries, or both.
Other company, product, or service names
may be trademarks or service marks of
others.
Manufactured under license from Dolby
Laboratories. Dolby and the double-D
symbol are trademarks of Dolby
Laboratories.
European Union conformity
Radio and Telecommunications
Terminal Equipment Directive
This product is in compliance with the
essential requirements and other relevant
provisions of the Radio and
Telecommunications Terminal Equipment
Directive, 1999/5/EC.
Electronic emission
notices
First Edition (August 2014)
© Copyright Lenovo 2014.

Type: CMOS
Pixels: 5.0 megapixels (back) + 2.0 megapixels (front)
Processor: MTK MT6572 , Dual Core , 1.3GHz
Size: 4.0 inches Screen: 2-touch
Resolution: 800 × 480 pixels LCD type: TN
Model: Lenovo A319 System: Android
Bluetooth 4.0; WLAN 802.11 b/g/n; WCDMA, GSM; GPS
Battery: 1500 mAh
Height: 123.5 mm (4.862 inches) Width: 63.8 mm (2.512 inches)
Depth: 10.2 mm (0.406 inch) Weight: 129 g (0.284 lb)
Model and system
① Depending on the measuring method, the dimensions and weight
might vary slightly.
Display
Battery
Processor
①Dimensions and weight
Camera
Wireless Communication
Technical specifications

Microphone
Flashlight
Micro USB
connector
Speaker
On/Off button
Volume buttons
Receiver
1
4
7
10
2
5
8
3
6
9
Front-facing
camera
Rear-facing
camera
Headset
connector
6
5
7
8
9
10
2
3
4
1
First glance

You must insert the SIM card provided by your carrier to use cellular
services. Set up your smartphone as shown.
Step 1. Open the back cover.
Step 2. Insert the SIM cards and
the memory card.
Tip: Insert the (U)SIM card into
SIM1 slot and SIM card
into SIM2 slot.
Step 3. Install the battery.
a. Align the battery
connectors on the battery
with the pins in the
battery compartment.
b. Push the battery down
into place.
Step 4. Install the back cover.
Always turn off your smartphone first before you insert or remove a
SIM card. Insert or remove a SIM card with your smartphone on may
damage your SIM card or smartphone permanently.
SIM1
SIM2
SIM1
SIM2
Preparing your smartphone
