Lenovo Legion Phone Duel 2 User manual

Legion Phone Duel 2
User Guide V1.0
Lenovo L70081

Basics
Before using this guide and the related product, be sure to read the following:
Quick Start Guide
Regulatory Notice
Appendix
The Quick Start Guide and the Regulatory Notice have been uploaded to our website at
lenovomobilesupport.lenovo.com.
Note: All pictures and illustrations in this document are for your reference only and may
differ from the final product.
Home Screen
The home screen is the starting point for using your phone. For your convenience, the home
screen is already set up with some useful apps and widgets. Swipe left or right to view all the
home screen panels. Go one screen to the left to open frequently used cards and take
advantage of smart and convenient services.
Note: Your phone's features and home screen layout may be different depending on your
location, language, carrier, and model.
You can customize your home screen at any time.

To change the settings for the home screen, press and hold any blank area on the home
screen, tap Desktop Settings, and then select the option to change.
To add a widget to the home screen, press and hold any empty area on the home screen
and tap Widgets. Then, swipe left or right to locate the widget that you want, press and
hold the widget until it pops out, drag it to where you want to place it, and then release it.
Tip: Some widgets are grouped by app, swipe left or right to locate the app that you
want, and then tap it to see the available widgets.
To change the wallpaper and theme, press and hold any empty area on the home screen,
tap Wallpaper, and then choose your wallpaper and theme you want.
To move a widget or an app to another screen, tap and hold the widget or app until your
phone vibrates, drag it to where you want to place it, and then release it.
To move an app to another home screen panel, tap and hold the app until the phone
vibrates, drag it to the edge of the screen, and then release it.
To move an app to the shortcut menu, tap and hold the app until the phone vibrates, and
drag it to the shortcut menu at the bottom of the screen (other apps may need to be
removed first).
To create a folder, tap and hold an app until the phone vibrates and then drag it to another
app.
To uninstall an app, tap and hold the app you want to delete until the phone vibrates, tap
App Info or Remove App in the upper left corner of the icon, and follow the
instructions on the screen.
Note:
Some system apps cannot be uninstalled.
Because the processor and the operating system take up some memory space, your
phone's available storage space may be less than its physical capacity.
Screen Buttons

Go to Settings > System navigation, select Navigation keys. There are three buttons at
the bottom of the screen.
Back button: Tap to return to the previous menu or exit the current application. On
a text input interface, tap this button to close the on-screen keyboard.
Home button: Tap to return to the default home screen.
Multitask button: Tap to view recently used apps. Then, you can do any of the
following:
Tap an app to open it.
Swipe an app up to close it.
Swipe an app down to lock it.
Swipe a locked app window down again to unlock it.
Tap to close all unlocked apps. Press and hold to forcefully close all locked
applications.
In an application interface, press and hold to enter split screen mode.
Note: Some apps may not support split screen mode.
Screen Lock
When your phone is on, press the Power button to manually lock the screen. Press the
Power button again to display the lock screen, and then swipe up from the bottom of the
screen to unlock.
Note: Swipe is the default method to unlock the screen. To change your screen lock
configuration, see Settings.
Notifications and Shortcut Panel
The notifications panel informs you of new messages, USB connections, and activities in
progress, such as file downloads. The shortcut panel allows you to access frequently
used settings, such as the WLAN switch.

You can do any of the following:
To view the notifications and shortcut panel, swipe down from the top of the screen.
To close the notifications and shortcut panel, swipe up from the bottom of the screen.
To view the details of a notification, tap the corresponding message notification.
To delete a notification, swipe left or right on the notification; or swipe left on the
notification, tap , and follow the prompts to delete it.
To dismiss all notifications, tap at the bottom of the notifications panel.
To quickly enable a function such as WLAN, tap the corresponding icon and wait for it
to turn blue. Tap the icon again to disable this function.
To view more app icons, swipe left or right in the shortcut panel.
To add, hide, or reorder app icons, tap , hold down an app icon, and drag it to the
place you want.
USB Connection
When you connect your phone to a computer using a USB cable, the notification panel
displays a relevant notification, such as "Charging this device via USB." You can tap the
notification and then select one of the following options:
File Transfer: Select this mode if you want to transfer files between your phone and
the computer.
USB tethering: Select this mode if you want to share your internet data connection
through a USB cable.
PTP: Select this mode if you want to transfer photos and videos between your phone
and the computer.
MIDI: Select this mode if you want MIDI-enabled applications on your phone to work
with MIDI software on the computer.
No data transfer: Select this mode if you only want to charge your phone.

Calls
Make a Call
Manual dialing
1. Open the Phone app.
2. Tap to display the dialpad if necessary.
3. Enter the phone number, and then tap .
Call from the Call Log
1. Open the Phone app.
2. Tap the Recents tab to display the call log. Swipe up on the call list to display more call
logs.
3. Tap from a call log entry to call the corresponding number.
Call a Contact
1. Open the Phone app.
2. Tap the Contacts tab.
3. Locate the contact that you want to call and tap the contact name to display the contact
details.
4. Tap the phone number that you want to dial.
Receive Calls
Answer or Reject a Call
When a call is received, the incoming call screen is displayed. You can do either of the
following:
Tap ANSWER to answer the call.
Tap DECLINE to reject the call.
Mute calls
You can mute an incoming call in two ways:
Press the Volume Up button or the Volume Down button.
Press the Power button.
In-call Options
When you are in a call, the following options are available on the screen:
Mute: turns the microphone on or off.
Hold: puts the current call on hold or resumes the call.
Speaker: turns the speaker on or off.
Add call: displays the dialpad so you can call another person.
Keypad: displays or hides the keypad.

: ends the call.
You can also press the volume button to turn the volume up or down.
Note: The Hold function may function differently depending on your carrier.
Use the Call Log
The call log contains entries for missed, outgoing, and received calls. Tap a call log entry to
open the options menu and then tap an option. For example, you can tap the Add contact
option to add the corresponding number to the Contacts list.

Contacts
Create Contacts
1. Open the Contacts app.
2. Tap and enter the contact information.
3. Tap Save.
Search for Contacts
1. Open the Contacts app.
2. Search for contacts using either of the following methods:
Scroll up or down on the contacts list to locate the desired contact.
Tap Search contacts, and then enter the contact name or initials. The matching
contacts are displayed as you type.
Edit Contacts
1. Open the Contacts app.
2. Find and tap the contact that you want to edit.
3. Tap Edit contact, and then edit the contact information.
4. Tap Save.
Share Contacts
1. Open the Contacts app.
2. Tap > Select, select the contact that you want to share with others, and then tap .
Delete Contacts
1. Open the Contacts app.
2. Find and tap the contact that you want to delete to enter the contact details interface.
3. Tap > Delete, and then tap delete in the pop-up dialog box.
Import Contacts
1. Open the Contacts app.
2. Tap > Settings > Import.
3. Select Import contacts from .vcf file or SIM card.
4. Tap OK.
Export Contacts
1. Open the Contacts app.
2. Tap > Settings > Export.
3. Tap contacts.vcf SAVE.

Messages
Send a Message
You can use the Messages app to send text messages and multimedia messages.
1. Open the Messages app.
2. Tap Start chat.
3. Tap the recipient text box, and then enter a contact name or phone number. Matching
contacts are displayed as you type. Select a contact.
Or, tap to add more recipients.
4. Tap the message text box, and then enter a message.
Tip: If you want to send a multimedia message, tap to select a media object type
such as pictures or video clips, and then attach the desired media object to the
message.
5. Tap .
Search for a Message
1. Open the Messages app.
2. Tap , and then enter the search keyword in the search text box. The matching messages
will be listed automatically.
Delete Messages
1. Open the Messages app.
2. In the list of message threads, delete the messages in either of the following ways.
Tap a contact name or phone number to view the message thread. Tap > Delete, and
then tap Delete in the pop-up dialog box.
Press and hold a message until it is selected, tap , and then tap Delete in the pop-up
dialog box.

Camera
Launch Camera
You can launch the camera in any of the following ways.
Tap the Camera app to open the camera.
When the screen is locked, light up the screen, press and hold the camera icon in the
lower-right corner, and swipe up to start the camera.
Swipe down from the top of the phone screen to display the shortcut panel and tap the
camera function icon to start the camera.
Camera Basics
You can use the Camera app to take photos and record videos.
1. Open the camera.
2. You can do the following:
Focus: Tap the area where you want to focus.
To lock the focus, tap and hold the viewfinder to activate the AE/AF lock.
Adjust brightness: Tap the viewfinder. When the symbol appears next to the focus
frame, drag it up or down.
Zoom in or out: On the viewfinder, pinch or spread two fingers, or drag the zoom slider.
Select a camera mode: Swipe left or right across the camera mode options.
Tap More to choose from the Macro, Pro, Panorama, Slow-motion, Time-lapse,
Director or HDR10+ shooting modes.
Turn the flash on or off: Tap and select (Auto), (On), (Off), or
(Always on).

When you select (Auto), if the camera detects that you are in a dark
environment, the flash icon will appear in the viewfinder, and the camera will flash
automatically while shooting.
3. Tap to take a photo.
Adjust Camera Settings
Set Photo Size
Go to Camera > > Picture size defaults and select the desired photo size.
Add Device Watermarks to Photos
Go to Camera > > Watermark and select the method used to add watermarks. Then, a
device watermark is added to photos and videos shot with the camera.
Use the Assistive Grid to Compose Your Photos
Use the assistive grid feature to help you line up the perfect shot.
1. Go to Camera > and enable the Reference Line switch. Grid lines will appear in the
viewfinder.
2. Place the subject of your photo at one of the intersecting points, and then tap .

Gallery
View Photos and Videos
1. Open the Photos app.
2. Tap a photo or video to view it in full-screen mode.
3. Do any of the following:
Swipe left or right to see the next or previous photo or video.
To zoom in or out on a photo, spread or pinch the photo. When you zoom in, you can
drag to see other parts of the photo.
To watch a video, tap .
Share Photos and Videos
When you are viewing a photo or video, tap anywhere on the screen, tap , and then select a
sharing channel such as Messages or Bluetooth to share the photo or video with others. If
you want to share multiple photos and videos at the same time, do the following:
1. Open the Photos app.
2. Long-press a photo or a video until a checkbox appears in the upper-left corner.
3. Select the photos or videos that you want to share with others.
4. Tap in the upper-right corner, and then select a sharing channel such as Messages or
Bluetooth to share the photos or videos with others.
Delete Photos and Videos
When you are viewing a photo or video, tap in the lower-right corner of the screen to delete
the photo or video.
If you want to delete multiple photos and videos at the same time, do the following:
1. Open the Photos app.
2. Long-press a photo or a video until a checkbox appears in the upper-left corner.
3. Select the photos or videos you want to delete.
4. Tap in the upper-right corner and tap Move to trash in the pop-up dialog box.

Network
Connect to a Wi-Fi Network
You can enable the Wi-Fi function through the shortcut panel, or connect by the following
methods:
1. Go to Settings > Wi-Fi and enable the Wi-Fi switch.
2. Connect to a Wi-Fi network on the Wi-Fi screen using either of the following methods:
Select a Wi-Fi network to connect to under Choose WLAN. A passcode is required for
encrypted networks.
To manually add a Wi-Fi network, scroll down to the bottom of the screen, tap Add
network, and enter the SSID and passcode as prompted to complete the connection.
Mobile Data
Connect to Mobile Data
1. Make sure that mobile data is available through your SIM card.
2. Connect to mobile data using either of the following methods:
Swipe down from the top of the screen to open the shortcut panel. Tap to enable
Mobile data.
Go to Settings > Mobile network and enable Cellular Data.
Select a SIM Card for Mobile Data
Your phone comes with dual SIM slots. Both slots support 5G/4G/3G/2G data services,
but you can enable mobile data for only one SIM card at a time.
To decide which SIM card to use for mobile data, go to Settings > Cellular networks &
SIM > Cellular Data and select a SIM card. To use a 5G network, enable the 5G switch.
Personal Hotspot
Once the personal hotspot function has been enabled, you can share your mobile data or
the Wi-Fi network your phone is currently connected to with other devices.
Share Your Network Connection via Personal Hotspot
1. Go to Settings > Hotspot & tethering and enable Hotspot & tethering.
2. Tap Set up Wi-Fi hotspot to view or change the hotspot configuration information.
Note: Tell your friends the network name and passcode so they can connect to your
network.
Share Your Network Connection via Bluetooth
1. Go to Settings > Bluetooth and enable Bluetooth. Then, follow the onscreen
instructions to complete pairing.
2. Go to Settings > Hotspot & tethering and enable Bluetooth tethering.

3. On the Bluetooth screen of the paired device, tap next to your device name, and
then enable Internet access to establish an Internet connection and share your
network connection.
Share Your Network Connection via USB
1. Use a USB cable to connect your phone to a computer.
2. On your phone, go to Settings > Hotspot & tethering and enable USB tethering to
share your mobile data or Wi-Fi network.

NFC
Near Field Communication (NFC) is a short-range wireless communications technology that
allows mobile and other electronic devices to connect in many different ways.
Enable or Disable NFC
You can enable or disable NFC as follows:
Swipe down from the top of the screen to open the shortcut panel, and then add the
icon. Tap this icon to enable or disable NFC. Tap and hold the icon to enter the NFC
settings screen.
Go to Settings > NFC and toggle the NFC switch on or off.
Make Quick Payments with NFC
If you have installed a payment app on your phone and enabled the corresponding payment
service, you can make payments with NFC.
1. Go to Settings > NFC and enable NFC.
2. Tap Default Wallet on the NFC settings screen and select a default wallet, such as Lenovo
Wallet.
3. In the payment app, tap Tap & pay or Bus Card Recharge to enable the NFC payment
function.
4. When paying, complete the payment according to the prompt on the phone screen.

Lenovo One
With Lenovo One, you can quickly connect your phone and computer to perform the following
operations: screen projection from the phone to the computer, game or video screen projection
from the phone to the computer, and phone operations from the computer.
Connect Your Phone and Computer with Lenovo One
1. Go to Settings > General settings, enable the Lenovo One switch, and turn on both
Bluetooth and Location.
2. Find the Lenovo One icon on the computer and double-click it to open the main interface.
3. Check the WLAN connection between your computer and phone to ensure that the two
devices are in the same WLAN.
4. On the main Lenovo One interface on the computer, locate your mobile device and click
the Connect button.
5. After receiving the connection request pop-up on your phone, click Accept. Wait a few
seconds for a connection to be established between the two devices.

4D U-Touch
U-Touch
1. Go to Settings > System navigation and check U-Touch to enable this function.
Note: Navigation keys are hidden when U-Touch is enabled.
2. Using U-Touch, you can perform the following operations in any area of your phone.
Swipe in from the left or right edge of the screen to go back to the previous menu.
Swipe up from the bottom of the screen to return to Home.
Swipe up from the bottom of the screen and hold to go to recent apps.
4D Gesture
Chop twice for flashlight: enable the Chop twice for flashlight switch to turn the
flashlight on/off with two chopping motions.
Twist for quick capture: enable the Twist for quick capture switch to open the camera
anytime by twisting your wrist twice.
Raise to wake: enable the Raise to wake switch to wake up the system automatically when
you pick up your phone.

Fingerprints
Fingerprint Recognition
You can enroll a fingerprint and then use it to unlock your screen, access App Lock, and more.
1. Go to Settings > Passcode & fingerprints & face-recognition > Passcode, choose a
passcode, and follow the prompts to set the passcode.
Note: A passcode needs to be set before adding a fingerprint.
2. Tap Fingerprints and enter the unlock passcode.
3. In the Manage fingerprints interface, enable the Device unlock switch, or tap Add a
fingerprint, and follow the on-screen instructions to add fingerprints.
Note: Place your fingertip on the blue fingerprint sensor. When you feel a vibration,
lift your finger and then press again. Move your finger around to allow the phone to
recognize different parts of it.
4. Tap OK.
Face Recognition
Face Recognition allows you to unlock your phone or access locked apps using your face.
1. Go to Settings > Passcode & fingerprints & face-recognition > Passcode, choose a
passcode, and follow the prompts to set the passcode.
Note: A passcode needs to be set before adding a fingerprint.
2. Tap Face ID and enter the unlock passcode.
3. In the Face ID interface, enable the Face Unlock switch or tap Add Face, and follow the
on-screen instructions to start enrolling your face.
4. Tap OK.
Use Your Fingerprint to Access a Locked App
1. Go to Settings > Passcode & fingerprints & face-recognition > App lock and enter the
screen unlock passcode or fingerprint.
2. Enable Fingerprint lock and follow the on-screen instructions to link your fingerprint with
the app lock function.
You can now tap a locked app on your home screen and use your fingerprint to access it.

Chrome
If your phone has been connected to a wireless or a cellular network, you can use the Chrome
app to surf the web. For more information about connecting to a Wi-Fi or a cellular network,
see Network.
Visit Websites
1. Open the Chrome app.
2. Tap the address box, enter a website address or your search keywords, and then tap .
Tip: You do not need to enter a full website address with "http://" to access the
website. For example, to visit http://www.lenovo.com, enter "www.lenovo.com" in the
address box and tap .
3. When viewing a web page, you can do the following:
Tap > to refresh the current page.
Press the Back button to return to the previous web page.
Tap > to go forward to a recent web page.
Press and hold an image on the web page, and then tap Download image to save the
image to your phone's internal storage.
Add a Bookmark
When viewing a web page that you want to bookmark, tap > . The next time you open
the Chrome app, tap > Bookmarks, and then tap the bookmark to quickly access the web
page.
Clear Browser History
1. Open the Chrome app.
2. Tap > History.
3. Tap Clear browsing data....

Settings
Set the Date and Time
Your phone is able to sync to the local date, time, and time zone over a mobile network. You
can also manually set the date, time, and time zone for your phone.
1. Go to Settings > General settings > Date & time.
2. Set the date and time automatically or manually.
Enable Use network-provided time to have your phone sync to the local date and time
over its mobile network.
Disable Use network-provided time, and then tap Set date and Set time to manually
set the date and time.
3. Change the time zone.
Enable Use network-provided time zone to have your phone sync to the local time zone
over a mobile network.
Disable Use network-provided time zone, and then tap Select time zone to manually
set the time zone.
4. Change the time format.
Enable Use 24-hour format to have your phone display the time in 24-hour format.
Disable Use 24-hour format to have your phone display the time in 12-hour format.
Set the Language
1. Go to Settings > General settings > Languages & input > Language.
2. Tap the display language that you want to use.
Set the Input Method
You can download a third-party input method and set it as your default input method.
1. Download an input method from an official app store.
2. Follow the on-screen instructions to set it as the default input method. Or, go to Settings >
General settings > Languages & input > Virtual keyboard and tap Manage keyboards to
enable the input method you need. Then, tap Current keyboard to select the input method.
Enable App Installation
Before you install apps that you downloaded from unknown sources, perform the following
operations:
1. Go to Settings > General settings > Security & location > Install unknown apps.
2. Select the desired source, and then enable Allow from this source.
Screenshots & Screen Recording
Take a Screenshot
You can take a screenshot by any of the following methods:
