Chapter1.Aboutthedock
Thischaptercontainsproductdescription,connectorandcontrollocations,andsystemrequirementsforthe
ThinkPad®OneLinkDock(hereaftercalledthedock).
Productdescription
Thedockisaportableexpansionmodulethatenablesyoutoeasilyconnectyournotebookcomputertothe
Ethernetandmultipledevices,suchasaHighDenitionMultimediaInterface(HDMI)monitororprojector,a
headsetandmicrophonecombojack,andUniversalSerialBus(USB)devices.ItprovidestwoUSB3.0
connectorsforhigherbandwidthandbetterperformance,andtwoUSB2.0connectorsforcommonUSB
devices.ThedockalsosupportsGigabitEthernetspeedwhenyouconnectittonetworks.
YoucansetupyourworkareabyconnectingyournotebookcomputertothedockwiththeOneLinkcable,
connectingmultipledevicestothedock,andsettingthedockonyournotebookcomputer;then,youare
readytousethemultipledeviceseachtimeyouconnectyournotebookcomputertothedock.
Youroptionpackageincludesthefollowing:
•ThinkPadOneLinkDock
•HDMI-to-VGAadapter
•Cablemanagementstand
•Warrantyposter
Contactyourplaceofpurchaseifanyitemismissingordamaged.Besuretoretainyourproofofpurchase
andpackingmaterial.Theymightberequiredtoreceivewarrantyservice.
©CopyrightLenovo20131

Locatingconnectorsandcontrolsonthedock
Thefollowingillustrationhelpsyoulocatetheconnectorsandcontrolsonthedock.
Figure1.Overviewofthedock
1Powerindicator7Cablemanagementstand
2Headsetandmicrophonecombojack8Powerconnector
3USB3.0connectorwithbatterychargingfunction9HDMIconnector
4USB3.0connector10GigabitEthernetconnector
5Security-lockslot11USB2.0connectors
6OneLinkcable12Powerbutton
1Powerindicator
Thepowerindicatorisusedtoindicatethepowerstatusofthenotebookcomputerthatconnectswiththe
dock.
•Ifthepowerindicatorislitinred,itindicatesthatthenotebookcomputeristurnedon.
•Ifthepowerindicatorisoff,itindicatesthatyournotebookcomputeristurnedoff,insleepmode,orin
hibernationmode;orthedockisdisconnectedfromyournotebookcomputer.
2Headsetandmicrophonecombojack
Theheadsetandmicrophonecombojackisusedtoconnectaheadset,amicrophone,oraspeaker.
2ThinkPadOneLinkDockUserGuide

3USB3.0connectorwithbatterychargingfunction
TheUSB3.0connectorwithbatterychargingfunctionisusedtodothefollowing:
•ConnectingUSBdevices(USB1.0,USB1.1,USB2.0,andUSB3.0compatible)
•Chargingdevicesevenwhenyournotebookcomputeristurnedoff,insleepmode,orinhibernation
mode;orwhenthedockisdisconnectedfromyournotebookcomputer
4USB3.0connector
TheUSB3.0connectorisusedtoconnectUSBdevices(USB1.0,USB1.1,USB2.0,andUSB3.0
compatible).
5Security-lockslot
Thesecurity-lockslotisusedtosecurethedockwithasecuritycablelock.
Note:Thesecuritycablelockisnotincludedinyouroptionpackage.Ifnecessary,purchaseasecurity
cablelock.
6OneLinkcable
TheOneLinkcableisusedtoconnectthedocktoyournotebookcomputer.
Note:Toavoidanyredamage,ensurethatthenotebookcomputerconnectingtheOneLinkcablemeets
eitherofthefollowingrequirements:
•TheammabilityofthenotebookcomputerenclosureisnotlowerthanClassV-1.
•Thenotebookcomputerenclosureismetallic.
7Cablemanagementstand
ThecablemanagementstandisusedtomanagetheOneLinkcabletooptimizedeskspace.
8Powerconnector
Thepowerconnectorisusedtoconnectthepoweradapter.
Note:Thepowerinputratingofthedockis20Vand3.25A.
9HDMIconnector
TheHDMIconnectorisusedtoconnectanexternalHDMImonitortothedockusinganHDMIcable,
ortoconnectanexternalmonitorwithaVideoGraphicsArray(VGA)connectortothedockusingan
HDMI-to-VGAadapter.
10GigabitEthernetconnector
TheGigabitEthernetconnectorisusedtoconnectthedocktoanetworkusinganEthernetcable.
11USB2.0connectors
ThetwoUSB2.0connectorsareusedtoconnectUSBdevices(USB1.0,USB1.1,andUSB2.0compatible).
Chapter1.Aboutthedock3

12Powerbutton
Thepowerbuttonisusedtoturnonorturnoffyournotebookcomputer,ortoputthenotebookcomputer
intosleeporhibernationmode.Toachievethis,youneedtochangethepowerplansettingsofyour
notebookcomputer.Formoreinformation,refertotheuserguidethatcomeswithyournotebookcomputer.
Systemrequirements
Beforeusingthedock,ensurethatyournotebookcomputerhasoneofthefollowingoperatingsystems
installed:
•Microsoft®Windows®7
•MicrosoftWindows8
4ThinkPadOneLinkDockUserGuide

Chapter2.Installingthedock
Thischapterprovidesinstructionsonhowtoconnectthedocktoyournotebookcomputer,andmanually
installthedevicedriver.
Connectingthedocktoyournotebookcomputer
ThistopicprovidesinstructionsonhowtoconnectthedocktoyournotebookcomputerusingtheOneLink
cablealongwiththepoweradapterandpowercordofyourcomputer.
Notes:
•Ensurethatyoucorrectlyconnectthedocktoanacpowersource.
•YoucanpresstheOneLinkcableintothecablemanagementstandtooptimizedeskspace.
Toconnectthedocktoyournotebookcomputer,dothefollowing:
1.Removethepoweradapterfromyournotebookcomputer.
2.RemovetheLenovo®OneLinkconnectorcoverfromyournotebookcomputer.
Figure2.RemovingtheLenovoOneLinkconnectorcover
©CopyrightLenovo20135

3.Connectthedocktoanacpowersourceandyournotebookcomputerbydoingthefollowing:
a.Connectthepoweradaptertothepowercord1.
b.Connectthedc-inconnectorofthepoweradaptertothepowerconnectoronthedock2.
c.ConnecttheOneLinkcabletotheLenovoOneLinkconnectoronyournotebookcomputer3.
d.Connectthepowerplugofthepowercordtoanelectricaloutlet4.Thedockisreadyforuse.
Figure3.Connectingthedocktothepowersupplyandyournotebookcomputer
InstallingthedevicedriveronWindowsoperatingsystems
Bydefault,thedockdevicedriverispreinstalledonyournotebookcomputer.Thedockisreadyforuseafter
yousuccessfullyconnectittoanacpowersourceandyournotebookcomputer.
Ifnecessary,youalsocanobtainthelatestdevicedriverathttp://www.lenovo.com/onelinkdrivers.Then,
followtheinstructionsonthescreentocompletethedevicedriverinstallation.
6ThinkPadOneLinkDockUserGuide

Chapter3.Usingthedock
Thischapterprovidesinformationaboutusingtheheadsetandmicrophonecombojack,USBconnectors,
GigabitEthernetconnector,andHDMIconnectoronthedock.
Youcanconnectdevicestotheappropriateconnectorsonthedockwhileyournotebookcomputeristurned
on.Normallyitwilltakeseveralsecondsforthenotebookcomputertorecognizenewdevices.
Usingtheheadsetandmicrophonecombojack
Theheadsetandmicrophonecombojackonthedockisa3.5mmheadsetandmicrophonecombinedjack.
Itonlyworksforthestandard3.5mmheadset,microphone,orspeaker.
Tousetheheadsetandmicrophonecombojackonthedock,connectyourheadset,microphone,orspeaker
totheheadsetandmicrophonecombojackonthedock.
Notes:Theheadset,microphone,orspeakerconnectedtotheheadsetandmicrophonecombojackonthe
dockisautomaticallyenabledafterthedockissuccessfullyconnectedandrecognizedbyyournotebook
computer.However,ifyoucannothearanythingfromyourdevice,dothefollowing:
•InstallthelatestdevicedriverbyfollowingtheinstructionsontheWebsiteat:
http://www.lenovo.com/onelinkdrivers
•Manuallyenabletheheadsetandmicrophonecombojackonthedock.See“Manuallyenablingthe
headsetandmicrophonecombojack”onpage11formoreinformation.
UsingtheUSB3.0connectorwithbatterychargingfunction
TheUSB3.0connectorwithbatterychargingfunctionenablesyoutochargedevicesevenwhenthe
computerisshutdown,isinsleeporhibernationmode,orthedockisdisconnectedfromthenotebook
computer.
Tochargeadevice,connectthedevicetotheUSB3.0connectorwithbatterychargingfunctiononthe
dockusingaUSBcable.
Notes:
•MostdevicescanbechargedbytheUSB3.0connectorwithbatterychargingfunction,butsomedevices
withspecialcongurationmightnotbecharged.
•Thechargingtimevariesdependingonthedevicecongurationandtheenvironment.
UsingtheUSBconnectors
TousetheUSBconnectors,connectaUSBdevicetoanyofthefourUSBconnectorsonthedockwitha
USBcable.
WhentheUSBdeviceiscorrectlyconnectedtoaUSBconnectoronthedock,aninformationwindowwill
bedisplayedintheWindowsnoticationarea,indicatingthattheUSBdevicehasbeenconnectedtothe
computer.
©CopyrightLenovo20137

UsingtheGigabitEthernetconnector
TousetheGigabitEthernetconnectoronthedock,connectthedocktoanetworkusinganEthernetcable,
andwaituntilthedockisfullyconguredbytheWindowsoperatingsystem.
Note:TheGigabitEthernetconnectoronthedockfullysupportstheThinkVantage®AccessConnections™
program.
UsingtheHDMIconnector
ThevideooutputconnectoronthedockisastandardHDMIconnector.TousetheHDMIconnector,connect
anexternalHDMImonitortothedockusinganHDMIcable.Youalsocanconnectanexternalmonitorwitha
VGAconnectortothedockusingtheHDMI-to-VGAadapterthatcomeswiththedock.
Youcanadjustvideosettingstocustomizetheuseofthedock.Formoreinformation,seeChapter4
“Workingwiththedock”onpage9.
Note:Forbetterperformance,occasionallyadjusttheexternalmonitortorealignitssettingswiththevideo
outputofthedock.Formoreinformationabouttheadjustmentprocedure,refertothedocumentation
thatcomeswithyourexternalmonitor.
8ThinkPadOneLinkDockUserGuide

Chapter4.Workingwiththedock
Thischapterprovidesinformationaboutthevideooutputfunctionofthedockandinstructionsonhowto
congurethedocktoyourneeds.
Understandingthevideooutputmodes
Thedockworksinthefollowingthreevideooutputmodes:
•Extendmode
Whenthedockisinextendmode,itsplitsyourdisplayacrosstwomonitors.Yournotebookcomputer
monitorbecomestheprimarydisplayandtheexternalmonitorbecomesthesecondarydisplay.By
default,theexternalmonitordisplayisontherightsideofthenotebookcomputermonitordisplay.
Inextendmode,youcandraganddropwindowsfromonedisplaytotheother.Also,youcanincrease
yourproductivitybydoingthefollowing:
–Readinge-mailsononedisplayandopeningtheattachmentsontheother
–Expandingaspreadsheetacrosstwodisplays
–Increasingyourworkareabyputtingallthepaletteandtoolbarsontheotherdisplaywhenyouare
doinggraphicsediting
–Keepingthedesktopononedisplayandwatchingvideosontheother
•Mirrormode
Whenthedockisinmirrormode,itclonesyournotebookcomputerscreentotheexternalmonitor.The
dockautomaticallyselectsthesettings(screenresolution,colorquality,andrefreshrate)fortheexternal
monitor,whichwillenablethebestresolutionbasedonyournotebookcomputer.
•Single-displaymode
Whenthedockisinsingle-displaymode,itenablesyoutoshowyourdesktopononlyonescreen.
Enteringavideooutputmode
Thissectionprovidesinstructionsonhowtoenteryourdesiredvideooutputmode.
Enteringextendmode
Toenterextendmode,dothefollowing:
FortheWindows7operatingsystem:
1.ClickStart➙ControlPanelorStart➙Settings➙ControlPanel.
2.DependingonyourControlPanelmode,dooneofthefollowing:
•ClickDisplay➙Changedisplaysettings.
•ClickAppearanceandPersonalization➙Display➙Changedisplaysettings.
3.IntheMultipledisplaysdrop-downlistbox,selectExtendthesedisplays.
4.Followtheinstructionsonthescreentocompletethesetting.
©CopyrightLenovo20139

FortheWindows8operatingsystem:
1.GotoControlPanelbydoingoneofthefollowing:
•FromtheStartscreen,movethecursortothetop-rightorbottom-rightcornerofthescreentodisplay
thecharms,andthenclickSearchcharmtosearchControlPanel.Then,clickControlPanel.
•Right-clickanywhereonthedesktop,andthenclickPersonalize➙ControlPanelHome.
2.DependingonyourControlPanelmode,dooneofthefollowing:
•ClickDisplay➙Changedisplaysettings.
•ClickAppearanceandPersonalization➙Display➙Changedisplaysettings.
3.IntheMultipledisplaysdrop-downlistbox,selectExtendthesedisplays.
4.Followtheinstructionsonthescreentocompletethesetting.
Enteringmirrormode
Toentermirrormode,dothefollowing:
FortheWindows7operatingsystem:
1.ClickStart➙ControlPanelorStart➙Settings➙ControlPanel.
2.DependingonyourControlPanelmode,dooneofthefollowing:
•ClickDisplay➙Changedisplaysettings.
•ClickAppearanceandPersonalization➙Display➙Changedisplaysettings.
3.IntheMultipledisplaysdrop-downlistbox,selectDuplicatethesedisplays.
4.Followtheinstructionsonthescreentocompletethesetting.
FortheWindows8operatingsystem:
1.GotoControlPanelbydoingoneofthefollowing:
•FromtheStartscreen,movethecursortothetop-rightorbottom-rightcornerofthescreentodisplay
thecharms,andthenclickSearchcharmtosearchControlPanel.Then,clickControlPanel.
•Right-clickanywhereonthedesktop,andthenclickPersonalize➙ControlPanelHome.
2.DependingonyourControlPanelmode,dooneofthefollowing:
•ClickDisplay➙Changedisplaysettings.
•ClickAppearanceandPersonalization➙Display➙Changedisplaysettings.
3.IntheMultipledisplaysdrop-downlistbox,selectDuplicatethesedisplays.
4.Followtheinstructionsonthescreentocompletethesetting.
Enteringsingle-displaymode
Toentersingle-displaymode,dothefollowing:
FortheWindows7operatingsystem:
1.ClickStart➙ControlPanelorStart➙Settings➙ControlPanel.
2.DependingonyourControlPanelmode,dooneofthefollowing:
•ClickDisplay➙Changedisplaysettings.
•ClickAppearanceandPersonalization➙Display➙Changedisplaysettings.
3.IntheMultipledisplaysdrop-downlistbox,selectShowdesktoponlyon1orShowdesktoponly
on2.
10ThinkPadOneLinkDockUserGuide

4.Followtheinstructionsonthescreentocompletethesetting.
FortheWindows8operatingsystem:
1.GotoControlPanelbydoingoneofthefollowing:
•FromtheStartscreen,movethecursortothetop-rightorbottom-rightcornerofthescreentodisplay
thecharms,andthenclickSearchcharmtosearchControlPanel.Then,clickControlPanel.
•Right-clickanywhereonthedesktop,andthenclickPersonalize➙ControlPanelHome.
2.DependingonyourControlPanelmode,dooneofthefollowing:
•ClickDisplay➙Changedisplaysettings.
•ClickAppearanceandPersonalization➙Display➙Changedisplaysettings.
3.IntheMultipledisplaysdrop-downlistbox,selectShowdesktoponlyon1orShowdesktoponly
on2.
4.Followtheinstructionsonthescreentocompletethesetting.
Note:IfyouselectShowdesktoponlyon1,thedisplayofyournotebookcomputermonitorwillbeonand
theexternalmonitordisplaywillturnoff.However,theotherfunctionssuchasaudio,Ethernet,andUSB
connectioncanstillworkthoughtheexternalmonitordisplayisoff.IfyouselectShowdesktoponlyon2,
theexternalmonitordisplaywillbeonandthedisplayofyournotebookcomputermonitorwillturnoff.
Manuallyenablingtheheadsetandmicrophonecombojack
Tomanuallyenabletheheadsetandmicrophonecombojackonthedock,dothefollowing:
1.Right-clickthespeakericonintheWindowsnoticationarea.Apop-upmenuopens.
2.ClickPlaybackdevicestoselectaUSBaudioline-outdevice,andthenclicktheRecordingtab
toselectaUSBaudioline-indevice.
3.ClickOK.
Note:Toapplythenewsettings,restarttheapplicationsthatareusingtheaudiodevices.
Rotatingtheexternalmonitordisplay
Thedockenablesyoutorotateonlyyourexternalmonitordisplayasyouwant.
Torotatetheexternalmonitordisplay,dothefollowing:
FortheWindows7operatingsystem:
1.ClickStart➙ControlPanelorStart➙Settings➙ControlPanel.
2.DependingonyourControlPanelmode,dooneofthefollowing:
•ClickDisplay➙Changedisplaysettings.
•ClickAppearanceandPersonalization➙Display➙Changedisplaysettings.
3.IntheOrientationdrop-downlistbox,selectoneofthefollowingoptions:
•Landscape:Theexternalmonitordisplayremainsthesameasyournotebookcomputermonitor
display.
•Portrait:Theexternalmonitordisplayrotates90degreestotheleft.
•Landscape(ipped):Theexternalmonitordisplaybecomesupside-down.
•Portrait(ipped):Theexternalmonitordisplayrotates90degreestotheright.
4.Followtheinstructionsonthescreentocompletethesetting.
Chapter4.Workingwiththedock11

FortheWindows8operatingsystem:
1.GotoControlPanelbydoingoneofthefollowing:
•FromtheStartscreen,movethecursortothetop-rightorbottom-rightcornerofthescreentodisplay
thecharms,andthenclickSearchcharmtosearchControlPanel.Then,clickControlPanel.
•Right-clickanywhereonthedesktop,andthenclickPersonalize➙ControlPanelHome.
2.DependingonyourControlPanelmode,dooneofthefollowing:
•ClickDisplay➙Changedisplaysettings.
•ClickAppearanceandPersonalization➙Display➙Changedisplaysettings.
3.IntheOrientationdrop-downlistbox,selectoneofthefollowingoptions:
•Landscape:Theexternalmonitordisplayremainsthesameasyournotebookcomputermonitor
display.
•Portrait:Theexternalmonitordisplayrotates90degreestotheleft.
•Landscape(ipped):Theexternalmonitordisplaybecomesupside-down.
•Portrait(ipped):Theexternalmonitordisplayrotates90degreestotheright.
4.Followtheinstructionsonthescreentocompletethesetting.
Note:Foranormaldisplay,youcancontinuallyclickPortraitorPortrait(ipped)untilthedisplaybecomes
upside-down.
Settingthecolorqualityoftheexternalmonitor
TosetthecolorqualityoftheexternalmonitorontheWindows7operatingsystem,dothefollowing:
Notes:
•Thedefaultandrecommendedsettingis32-bit.
•ThisfeatureisnotsupportedintheWindows8operatingsystem.
1.ClickStart➙ControlPanelorStart➙Settings➙ControlPanel.
2.DependingonyourControlPanelmode,dooneofthefollowing:
•ClickDisplay➙Changedisplaysettings.
•ClickAppearanceandPersonalization➙Display➙Changedisplaysettings.
3.ClickAdvancedsettings,andthenclicktheMonitortab.
4.SelectHighColor(16bit)orTrueColor(32bit)fromtheColorsdrop-downlistbox.
5.ClickOKtosavethesetting.
Settingtheresolutionoftheexternalmonitor
Thedockenablesyoutosettheresolutionoftheexternalmonitor.
Tosettheresolutionoftheexternalmonitor,dothefollowing:
FortheWindows7operatingsystem:
1.ClickStart➙ControlPanelorStart➙Settings➙ControlPanel.
2.DependingonyourControlPanelmode,dooneofthefollowing:
•ClickDisplay➙Changedisplaysettings.
12ThinkPadOneLinkDockUserGuide

•ClickAppearanceandPersonalization➙Display➙Changedisplaysettings.
3.IntheResolutiondrop-downlistbox,movetheslideruptoincreaseordowntodecreasetheresolution
oftheexternalmonitor.
4.Followtheinstructionsonthescreentocompletethesetting.
FortheWindows8operatingsystem:
1.GotoControlPanelbydoingoneofthefollowing:
•FromtheStartscreen,movethecursortothetop-rightorbottom-rightcornerofthescreentodisplay
thecharms,andthenclickSearchcharmtosearchControlPanel.Then,clickControlPanel.
•Right-clickanywhereonthedesktop,andthenclickPersonalize➙ControlPanelHome.
2.DependingonyourControlPanelmode,dooneofthefollowing:
•ClickDisplay➙Changedisplaysettings.
•ClickAppearanceandPersonalization➙Display➙Changedisplaysettings.
3.IntheResolutiondrop-downlistbox,movetheslideruptoincreaseordowntodecreasetheresolution
oftheexternalmonitor.
4.Followtheinstructionsonthescreentocompletethesetting.
Chapter4.Workingwiththedock13

14ThinkPadOneLinkDockUserGuide

Chapter5.Troubleshooting
Thischapterprovidessometroubleshootinghintsandtipstoassistyouifyouexperienceanyproblemswith
thedock.Checkthefollowingitemsrsttotrytosolvetheproblem.
Thepowerindicatorofthedockisnoton.
Ensurethatyouhavecorrectlyconnectedthepowersupplytothedockandaworkingelectricaloutlet.Do
notuseanypowersupplyotherthantheoneprovidedwithyournotebookcomputer.
Iconnectthedocktomynotebookcomputer,butthedockdoesnotwork.
Tosolvetheproblem,dothefollowing:
1.Ensurethatthepoweradapteriscorrectlyconnectedtothepowerconnectoronthedockandthe
dockiswellpoweredbyanacpowersource.
2.Ensurethatthedevicedriverofthedockiscorrectlyinstalled.Ifnot,installthelatestdevicedriverby
followingtheinstructionsontheWebsiteat:
http://www.lenovo.com/onelinkdrivers
3.EnsurethattheOneLinkcableiscorrectlyconnectedtotheLenovoOneLinkconnectoronyour
notebookcomputer.Ifnot,connecttheOneLinkcabletotheLenovoOneLinkconnectoragain.
Icannothearanythingthroughmynotebookcomputerspeakersafterconnectingthedocktothe
notebookcomputer.
Tosolvetheproblem,dothefollowing:
1.Ensurethatthedevicedriverofthedockiscorrectlyinstalled.Ifnot,installthelatestdevicedriverby
followingtheinstructionsontheWebsiteat:
http://www.lenovo.com/onelinkdrivers
2.Enablethebuilt-inaudioconnectorsonyournotebookcomputerbydoingthefollowing:
a.Right-clickthespeakericonintheWindowsnoticationarea.
b.SelectSounds,andtheSoundwindowisdisplayed.
c.ClickthePlaybacktabtoselectabuilt-inaudiodevice,andthenclicktheRecordingtabtoselect
anotherbuilt-inaudiodevice.
Notes:
•Toapplythenewsettings,restarttheapplicationsthatareusingtheaudiodevices.
•Thesettingsyouhaveadjustedwillbesaveduntilyouchangethesettingsthenexttime.
ThedockcannotconnecttotheInternet.
Tosolvetheproblem,dothefollowing:
1.Ensurethatthedevicedriverofthedockiscorrectlyinstalled.Ifnot,installthelatestdevicedriverby
followingtheinstructionsontheWebsiteat:
http://www.lenovo.com/onelinkdrivers
2.EnsurethatthetwoindicatorsoftheGigabitEthernetconnectorareon.Ifnot,inserttheEthernet
cableagain.
©CopyrightLenovo201315

16ThinkPadOneLinkDockUserGuide
