Lenovo 7D9F User manual

ThinkSystem SR655 V3
Messages and Codes Reference
Machine Types: 7D9E, 7D9

Note
Before using this information and the product it supports, be sure to read and understand the safety
information and the safety instructions, which are available at:
http://thinksystem.lenovofiles.com/help/topic/safety_documentation/pdf_files.html
In addition, be sure that you are familiar with the terms and conditions of the Lenovo warranty for your server,
which can be found at:
http://datacentersupport.lenovo.com/warrantylookup
Second Edition (April 2023)
© Copyright Leno o 2023.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is deli ered pursuant to a General Ser ices
Administration (GSA) contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No.
GS-35F-05925

Contents
Contents . . . . . . . . . . . . . . . . . i
Chapter 1. Messages . . . . . . . . . . 1
Event and alert message format . . . . . . . . . 1
Chapter 2. XClarity Controller
e ents . . . . . . . . . . . . . . . . . . 5
XCC events that automatically notify Support . . . . 6
XCC events organized by severity. . . . . . . . . 7
List of XClarity Controller events . . . . . . . . 28
Chapter 3. UEFI e ents . . . . . . . . 165
UE I events organized by severity . . . . . . . 165
List of UE I events. . . . . . . . . . . . . . 169
Chapter 4. XClarity Pro isioning
Manager e ents . . . . . . . . . . . . 193
LXPM events organized by severity . . . . . . . 193
List of XClarity Provisioning Manager events . . . 196
Appendix A. Getting help and
technical assistance . . . . . . . . . . 217
Before you call . . . . . . . . . . . . . . . 217
Collecting service data . . . . . . . . . . . . 218
Contacting Support . . . . . . . . . . . . . 219
© Copyright Lenovo 2023 i

ii ThinkSystem SR655 V3 Messages and Codes Reference

Chapter 1. Messages
When attempting to resolve issues with your server, the best practice is to begin with the event log of the
application that is managing the server.
• If you are managing the server from the Lenovo XClarity Administrator, begin with the Lenovo XClarity
Administrator event log.
• If you are using some other management application, begin with the Lenovo XClarity Controller event log.
The event log contains server hardware events that are recorded by the Lenovo XClarity Controller or by
UE I. In addition, events can be generated when you perform diagnostic testing on hard drives or memory
through the Lenovo XClarity Provisioning Manager (although these events are not stored in the event log).
Use this section to view the events that can be generated by Lenovo XClarity Controller, UE I, or the Lenovo
XClarity Provisioning Manager. or each event, a user action is available to help you understand what must
be done to resolve the issue.
Important:
•
• Lenovo XClarity Provisioning Manager (LXPM) supported version varies by product. All versions of Lenovo
XClarity Provisioning Manager are referred to as Lenovo XClarity Provisioning Manager and LXPM in this
document, unless specified otherwise. To see the LXPM version supported by your server, go to https://
sysmgt.lenovofiles.com/help/topic/lxpm_frontend/lxpm_product_page.html.
E ent and alert message format
You can use the following content to help you understand the event and alert message format.
The following information is provided for each event message.
E ent identifier
A string that uniquely identifies the event or class of events. This is a 12 character string in the following
format:
FQXppnnxxxxc
where:
• pp indicates the product where the event originate, as follows.
– CM. Chassis Management.
– HM. Hardware manager.
– PM. XClarity Provisioning manger - LXPM (LEPT).
– SF. System irmware.
– SP. Service Processor.
• nn identifies the component or system management where the event originated, as follows:
Components
– AA. Canister/Appliance - Contains system components not expected to be serviced by a
customer.
– CA. Cooling - ans, blowers, mux cards, policies, chillers/refrigeration, water management units,
water pumps, water filtration, air flow sensors, thermal monitors.
© Copyright Lenovo 2023 1

– DA. Display - Graphics adapters, op panel, monitor/console (including front/back panel, control
panel, LCD panel etc).
– IO. I/O connectivity - PCI/USB hub, bridge, bus, risers, configuration settings, interconnect,
keyboard, mouse, KVM.
– MA. Memory - Includes DIMMs, memory card, configuration settings, memory controller,
redundant modes (mirroring, spare, etc), RAID memory, NVRAM, EPROM.
– PU. Processing - Involves the processor, processor cards and system board (system board
assembly), configuration settings, and microcode, cache, Trusted Computing Module, processor
interconnect (QPI cables).
– PW. Power - Can be power supplies, VRMs, VRDs, voltage levels, system power state, policies,
batteries, AT power width, TPMD, power controllers, external power, Battery Backup Unit (UPS),
PDUs.
– SB. System Board - Main system board, associated risers, system planar, mid-planes,
backplanes, interconnects.
– SD. Client Data Storage Device - lash storage adapters, drives, cd/dvd drives, SSD, SAS, DASD,
lash storage, tape, volumes, remoteCopy, flashCopy, managed Storage Systems.
– SR. Storage RAID - Adapters, configuration, settings, interconnect, arrays, drive enclosures.
– VD. VPD - Configuration settings, EPROMs, communication.
Systems Management - SM, PSM, HMC, DMC UE I, CMM, IOMC, CCE, PMC, DPSM, SVC,
management of storage, services, IMM, SP, systems management networking.
– BR. Systems Management - Backup/Restore & ailover (HA).
– BT. System management - Boot, reboot, hard/warm reset, shutdown.
– CL. LEPT Clone.
– CN. Systems Management - Console.
– CP. Systems Management - Config Patterns.
– CR. Systems Management - Core / Virtual Appliance.
– DD. Device Driver - AIX, IBM I, Subsystem Device Driver (SDD), IPMI Service.
– DM. Systems Management - Data Management.
– EA. Vendor Events.
– EM. Events Monitoring - LEPT Dash Board.
– EM. Systems Management - Events / Monitoring.
– FC. Systems Management - lexCat OS/Config deployment.
– FW. System management - irmware.
– HA. Hypervisor - Virtual Components, Boots, Crashes, SRIOV, LPARs.
– IF. Interconnect ( abric) - common, podm, icm, lrim (SW W major, various minors & functions).
– II. Interconnect (Interfaces) - cimp, smis, cli, mapi (SC G major).
– IM. Interconnect (PCI Manager) - pcim (SW W major, various minors and functions).
– IN. Interconnect (Networking) - bos, ethm, fcf, npiv ( C major plus SW W major, various minors &
functions) data network, network settings, ports, security, adapters, switches, fiber channel,
optical ports, Ethernet.
– IP. Interconnect (PIE) - tbd.
– IU. Interconnect (Utilities / Infrastructure) - util, infr, serv, isds (IBIS major), remote copy (storage).
– NM. Network Management - LEPT Welcompage.
– NM. Systems Management - Network Management.
– OH. OS/Hypervisor Interface - Passing of error logs, partition management, services (time, etc).
– OS. LEPT OS Deploy.
– OS. OS - Power Linux, AIX IPL, AIX, crash and dump codes, IBM i kernal code, IBM i OS,
management of storage.
– PR. System management - Entity presence.
– RC. Systems Management - Remote Control.
– SD. LEPT Storage Test.
– SE. Systems Management - Security.
– SR. LEPT Raid Setup.
– SS. Service & Support - LEPT DC Collection.
2ThinkSystem SR655 V3 Messages and Codes Reference

– SS. Systems Management - Service & Support.
– TR. Time Reference - RTC, Master clock, drawer clocks, NTP.
– UN. Unknown/any entity.
– UP. LEPT irmware Update.
– UP. Systems Management - Updates.
– WD. System management - Watchdog.
• xxxx is an incrementing number of the Sub-System events set.
• c identifies the severity, as follows.
– A. Reserved as Immediate Action.
– B. Unknown / No action.
– D. Reserved - Immediate Decision.
– E. Reserved - Eventual Action.
– F. Warning / No Action.
– G. Warning / Deferred Action.
– H. Minor / Deferred Action.
– I. Information / No Action.
– J. Minor / Immediate Action.
– K. Major / Deferred Action.
– L. Major / Immediate Action.
– M. Critical / Immediate Action.
– N. atal / Immediate Action.
– W. Reserved - System Wait.
Chapter 1.Messages 3

4ThinkSystem SR655 V3 Messages and Codes Reference

Chapter 2. XClarity Controller e ents
When a hardware event is detected by the Lenovo XClarity Controller on the server, the Lenovo XClarity
Controller writes that event in the system-event log on the server.
Notes: Event identifier (ID) is a unique identifier used to search for XCC events. The event message may
have one or more arguments, which could be replaceable text of RU name or sensor name to identify the
failed component. So one XCC event ID could represent a generic event or similar faults that happened on
different hardware components. The general way of problem determination is to locate the event by ID,
identify the hardware component by message argument if it contains hardware component name, and then
perform actions defined in User Action.
Example:
FQXSPCA0017M: Sensor [SensorElementName] has transitioned to critical from a less severe state
where:
• FQXSPCA0017M is the event ID.
• [SensorElementName] is a sensor variable, indicating the name of hardware component. It can be CPU,
PCI adapter, OCP card or chipset. You can find the event by the event ID FQXSPCA0017M and perform
actions defined in User Action for the component.
or additional information about the Lenovo XClarity Controller event log, see “Viewing Event Logs” section
in the XCC documentation compatible with your server at https://sysmgt.lenovofiles.com/help/topic/lxcc_
frontend/lxcc_overview.html.
or each event code, the following fields are displayed:
E ent identifier
An identifier that uniquely identifies an event.
E ent description
The logged message string that appears for an event. When the event string is displayed in the event
log, information such as a specific component is displayed. In this documentation, that additional
information appears as variables, which include but not limited to the following:
• [SensorElementName], [ManagedElementName] , [ProcessorElementName],
[ComputerSystemElementName], [PowerSupplyElementName], ...
• [arg1], [arg2], [arg3], [arg4], [arg5]...
Explanation
Provides additional information to explain why the event occurred.
Se erity
An indication of the level of concern for the condition. The following severities can be displayed.
• Informational. The event was recorded for audit purposes, usually a user action or a change of states
that is normal behavior.
• Warning. The event is not as severe as an error, but if possible, the condition should be corrected
before it becomes an error. It might also be a condition that requires additional monitoring or
maintenance.
• Error. The event is a failure or critical condition that impairs service or an expected function.
Alert Category
© Copyright Lenovo 2023 5

Similar events are grouped together in categories. The alert category is in the following format: se erity -
de ice, where:
• se erity is one of the following severity levels:
– Critical. A key component in the server is no longer functioning.
– Warning. The event might progress to a critical level.
– System. The event is the result of a system error or a configuration change.
• de ice is the specific device in the server that caused the event to be generated.
Ser iceable
Specifies whether user action is required to correct the problem.
CIM Information
Provides the prefix of the message ID and the sequence number that is used by the CIM message
registry.
SNMP Trap ID
The SNMP trap ID that is found in the SNMP alert management information base (MIB).
Automatically contact Ser ice
You can configure the Lenovo XClarity Administrator to automatically notify Support (also known as call
home) if certain types of errors are encountered. If you have configured this function and this field is set
to Yes, Lenovo Support will be notified automatically if the event is generated. While you wait for Lenovo
Support to call, you can perform the recommended actions for the event.
Note: This documentation includes references to IBM web sites, products, and information about
obtaining service. IBM is Lenovo's preferred service provider for the Lenovo server products.
or more information about enabling Call Home from Lenovo XClarity Administrator, see http://
sysmgt.lenovofiles.com/help/topic/com.lenovo.lxca.doc/admin_setupcallhome.html. In addition, see “XCC
events that automatically notify Support” on page 6 for a consolidated list of all Lenovo XClarity
Controller events that are called home to Lenovo Support.
User Action
Indicates what actions you should perform to solve the event. Perform the steps listed in this section in
the order shown until the problem is solved. If you cannot solve the problem after performing all steps,
contact Lenovo Support.
XCC e ents that automatically notify Support
You can configure the XClarity Administrator to automatically notify Support (also known as call home) if
certain types of errors are encountered. If you have configured this function, see the table for a list of events
that automatically notify Support.
Table 1. E ents that automatically notify Support
E ent ID Message String
QXSPEM4014I The RAID controller has problem with the battery. Please contact technical
support to resolve this issue.([arg1],[arg2],[arg3],[arg4],[arg5])
QXSPEM4015I The RAID controller detected unrecoverable error. The controller needs
replacement.([arg1],[arg2],[arg3],[arg4],[arg5])
QXSPEM4025I One or more virtual drive have problem. Please contact technical support to
resolve this issue.([arg1],[arg2],[arg3],[arg4],[arg5])
QXSPEM4026I Drive error was detected by RAID controller. Please contact technical support
to resolve this issue.([arg1],[arg2],[arg3],[arg4],[arg5])
6ThinkSystem SR655 V3 Messages and Codes Reference

Table 1. E ents that automatically notify Support (continued)
E ent ID Message String
QXSPIO0011N An Uncorrectable Error has occurred on [SensorElementName].
QXSPIO0015M ault in slot [PhysicalConnectorSystemElementName] on system
[ComputerSystemElementName].
QXSPPW0002L [PowerSupplyElementName] has ailed.
QXSPPW0035M Numeric sensor [NumericSensorElementName] going low (lower critical) has
asserted.
QXSPPW0047M Numeric sensor [NumericSensorElementName] going high (upper critical) has
asserted.
QXSPPW0063M Sensor [SensorElementName] has transitioned to critical from a less severe
state.
QXSPSD0001L The [StorageVolumeElementName] has a fault.
QXSPSD0002G ailure Predicted on [StorageVolumeElementName] for array
[ComputerSystemElementName].
QXSPSD0002L Drive [arg1] in the enclosure/chassis(MTM-SN: [arg2]) has a fault.
QXSPSD0003G ailure Predicted on drive [arg1] in the enclosure/chassis (MTM-SN: [arg2]).
QXSPSD0006L Array [ComputerSystemElementName] has failed.
QXSPSD0008L Array failed on drive [arg1] in the enclosure/chassis (MTM-S/N: [arg2]).
QXSPSS4004I Test Call Home Generated by user [arg1].
QXSPSS4005I Manual Call Home by user [arg1]: [arg2].
XCC e ents organized by se erity
The following table lists all XCC events, organized by severity (Information, Error, and Warning).
Table 2. E ents organized by se erity
E ent ID Message String Se erity
QXSPBR4000I Management Controller [arg1]: Configuration restored from a file by
user [arg2] from [arg3] at IP address [arg4].
Informational
QXSPBR4002I Management Controller [arg1] Reset was caused by restoring default
values.
Informational
QXSPBR4004I Server timeouts set by user [arg1]: EnableOSWatchdog=[arg2],
OSWatchdogTimout=[arg3], EnableLoaderWatchdog=[arg4],
LoaderTimeout=[arg5].
Informational
QXSPBR4005I Management Controller [arg1]: Configuration saved to a file by user
[arg2].
Informational
QXSPBR4006I Management Controller [arg1]: Configuration restoration from a file by
user [arg2] completed from [arg3] at IP address [arg4].
Informational
QXSPBR4009I Management Controller [arg1]: cloning configuration from neighbor
server [arg2] by group name [arg3].
Informational
QXSPBR400AI Management Controller [arg1]: cloning configuration from neighbor
server [arg2] by group name [arg3] completed.
Informational
Chapter 2.XClarity Controller events 7

Table 2. E ents organized by se erity (continued)
E ent ID Message String Se erity
QXSPBR400BI Management Controller [arg1]: cloning configuration from neighbor
server [arg2] by group name [arg3] failed to complete.
Informational
QXSPBR400CI Management Controller [arg1]: cloning configuration from neighbor
server [arg2] by group name [arg3] failed to start.
Informational
QXSPBR400DI Neighbor group clone configuration was initiated by user [arg1]. Informational
QXSPBR400EI Neighbor group firmware update was initiated by user [arg1]. Informational
QXSPBR400 I The neighbor group management is [arg1] by user [arg2] from [arg3] at
IP address [arg4].
Informational
QXSPBT0007I No bootable media available for system
[ComputerSystemElementName].
Informational
QXSPCA0012I Sensor [SensorElementName] has transitioned to normal state. Informational
QXSPCA0013I Sensor [SensorElementName] has transitioned to normal state. Informational
QXSPCA2002I Numeric sensor [NumericSensorElementName] going low (lower
critical) has deasserted.
Informational
QXSPCA2007I Numeric sensor [NumericSensorElementName] going high (upper
non-critical) has deasserted.
Informational
QXSPCA2009I Numeric sensor [NumericSensorElementName] going high (upper
critical) has deasserted.
Informational
QXSPCA2011I Numeric sensor [NumericSensorElementName] going high (upper
non-recoverable) has deasserted.
Informational
QXSPCA2016I Sensor [SensorElementName] has transitioned to a less severe state
from critical.
Informational
QXSPCA2017I Sensor [SensorElementName] has transitioned to a less severe state
from critical.
Informational
QXSPCN4000I Serial Redirection set by user [arg1]: Mode=[arg2], BaudRate=[arg3],
StopBits=[arg4], Parity=[arg5], SessionTerminateSequence=[arg6].
Informational
QXSPCN4001I Remote Control session started by user [arg1] in [arg2] mode. Informational
QXSPCN4002I User [arg1] has terminated an active console session. Informational
QXSPCN4003I Remote Control session started by user [arg1] in [arg2] mode has
been closed.
Informational
QXSPDA2000I The System [ComputerSystemElementName] has detected a POST
Error deassertion.
Informational
QXSPDM4000I Inventory data changed for device [arg1], new device data hash=
[arg2], new master data hash=[arg3] .
Informational
QXSPDM4001I Storage [arg1] has changed. Informational
QXSPDM4003I TKLM servers set by user [arg1]: TKLMServer1=[arg2] Port=[arg3],
TKLMServer2=[arg4] Port=[arg5], TKLMServer3=[arg6] Port=[arg7],
TKLMServer4=[arg8] Port=[arg9].
Informational
QXSPDM4004I TKLM servers device group set by user [arg1]:
TKLMServerDeviceGroup=[arg2] .
Informational
QXSPDM4005I User [arg1] has generated a new encryption key pair and installed a
self-signed certificate for the TKLM client.
Informational
8ThinkSystem SR655 V3 Messages and Codes Reference

Table 2. E ents organized by se erity (continued)
E ent ID Message String Se erity
QXSPDM4006I User [arg1] has generated a new encryption key and certificate
signing request for the TKLM client.
Informational
QXSPDM4007I User [arg1] has imported a signed certificate for the TKLM client from
[arg2].
Informational
QXSPDM4008I User [arg1] has imported a server certificate for the TKLM server. Informational
QXSPDM4009I User [arg1] has [arg2] file [arg3] from [arg4]. Informational
QXSPDM4010I Inventory data collecting and processing complete for [arg1],
sequence number is [arg2].
Informational
QXSPDM4011I EKMS server protocol set by user [arg1]: TKLMServerProtocol=[arg2]
.
Informational
QXSPEA2001I Sensor [SensorElementName] has deasserted the transition from
normal to non-critical state.
Informational
QXSPEA2002I Sensor [SensorElementName] has transitioned to a less severe state
from critical.
Informational
QXSPEM0003I The Log [RecordLogElementName] has been cleared. Informational
QXSPEM0004I The Log [RecordLogElementName] is full. Informational
QXSPEM0005I The Log [RecordLogElementName] is almost full. Informational
QXSPEM0009I The System [ComputerSystemElementName] has generated an
auxiliary Log Entry in Log [RecordLogElement].
Informational
QXSPEM2004I The Log [RecordLogElementName] is no longer full. Informational
QXSPEM4000I The [arg1] on system [arg2] cleared by user [arg3]. Informational
QXSPEM4001I The [arg1] on system [arg2] is 75% full. Informational
QXSPEM4002I The [arg1] on system [arg2] is 100% full. Informational
QXSPEM4003I LED [arg1] state changed to [arg2] by [arg3]. Informational
QXSPEM4004I SNMP [arg1] enabled by user [arg2] . Informational
QXSPEM4005I SNMP [arg1] disabled by user [arg2] . Informational
QXSPEM4006I Alert Configuration Global Event Notification set by user [arg1]:
RetryLimit=[arg2], RetryInterval=[arg3], EntryInterval=[arg4].
Informational
QXSPEM4007I Alert Recipient Number [arg1] updated: Name=[arg2],
DeliveryMethod=[arg3], Address=[arg4], IncludeLog=[arg5], Enabled=
[arg6], EnabledAlerts=[arg7], Allowed ilters=[arg8] by user [arg9] from
[arg10] at IP address [arg11].
Informational
QXSPEM4008I SNMP Traps enabled by user [arg1]: EnabledAlerts=[arg2],
Allowed ilters=[arg3] .
Informational
QXSPEM4009I The UE I Definitions have been changed. Informational
QXSPEM4010I UE I Reported: [arg1]. Informational
QXSPEM4011I XCC failed to log previous event [arg1]. Informational
QXSPEM4012I User [arg1] made system [arg2] Encapsulation lite Mode. Informational
Chapter 2.XClarity Controller events 9

Table 2. E ents organized by se erity (continued)
E ent ID Message String Se erity
QXSPEM4014I The RAID controller has problem with the battery. Please contact
technical support to resolve this issue.([arg1],[arg2],[arg3],[arg4],
[arg5])
Informational
QXSPEM4015I The RAID controller detected unrecoverable error. The controller
needs replacement.([arg1],[arg2],[arg3],[arg4],[arg5])
Informational
QXSPEM4016I The RAID controller detected one or more problems. Please contact
technical support for additional assistance.([arg1],[arg2],[arg3],[arg4],
[arg5])
Informational
QXSPEM4017I The RAID controller detected one or more possible configuration
changes within the subsystem. Please check the drive LED status. If
necessary, contact technical support for additional assistance.([arg1],
[arg2],[arg3],[arg4],[arg5])
Informational
QXSPEM4018I Enclosure/Chassis issue detected with one or more units. Please
check the enclosure/chassis units to repair the problem.([arg1],[arg2],
[arg3],[arg4],[arg5])
Informational
QXSPEM4019I Connectivity issue detected with the enclosure/chassis. Please check
your cable configurations to repair the problem.([arg1],[arg2],[arg3],
[arg4],[arg5])
Informational
QXSPEM4020I an problem detected with the enclosure/chassis. Please check the
enclosure/chassis unit fan for correct operation.([arg1],[arg2],[arg3],
[arg4],[arg5])
Informational
QXSPEM4022I Enclosure/Chassis power supply has problem. Please check the
enclosure/chassis unit power supply for correct operation.([arg1],
[arg2],[arg3],[arg4],[arg5])
Informational
QXSPEM4023I One or more virtual drive are in abnormal status that may cause
unavailable virtual drive. Please check the event logs and if events are
targeted to the same disk then replace the drive. If necessary, contact
technical support for additional assistance.([arg1],[arg2],[arg3],[arg4],
[arg5])
Informational
QXSPEM4024I The RAID controller detected one or more possible configuration
problem within the subsystem. Please check the event logs and if
events are targeted to the same disk then replace the drive. If
necessary, contact technical support for additional assistance.([arg1],
[arg2],[arg3],[arg4],[arg5])
Informational
QXSPEM4025I One or more virtual drive have problem. Please contact technical
support to resolve this issue.([arg1],[arg2],[arg3],[arg4],[arg5])
Informational
QXSPEM4026I Drive error was detected by RAID controller. Please contact technical
support to resolve this issue.([arg1],[arg2],[arg3],[arg4],[arg5])
Informational
QXSPEM4027I Drive error was detected by RAID controller. Please check the event
logs and if events are targeted to the same disk then replace the drive.
If necessary, contact technical support for additional assistance.
([arg1],[arg2],[arg3],[arg4],[arg5])
Informational
QXSPEM4028I The port [arg1] of PCIe device [arg2] at [arg3] has link [arg4]. Informational
QXSPEM4029I All PCIe slots on [arg1] may not be functional based upon your current
CPU population.
Informational
10 ThinkSystem SR655 V3 Messages and Codes Reference

Table 2. E ents organized by se erity (continued)
E ent ID Message String Se erity
QXSPEM4030I A scheduled operation on the RAID controller has encountered an
issue. Refer to RAID Logs under Server Management, Local Storage,
for details.([arg1],[arg2],[arg3],[arg4],[arg5])
Informational
QXSPEM4031I SSD wear threshold setting is changed from [arg1] to [arg2] by user
[arg3] from [arg4] at IP address [arg5].
Informational
QXSPEM4032I Acoustic Mode [arg1] has been engaged. an speed limits are in
place.
Informational
QXSPEM4033I Acoustic Mode [arg1] has been disengaged to allow adequate
cooling.
Informational
QXSPEM4041I The SmartNIC in slot [arg1] encountered boot timeout. Informational
QXSPEM4042I The SmartNIC in slot [arg1] went through a crash dump. Informational
QXSP C4000I The bare metal connection process has been started. Informational
QXSP C4001I The bare metal update application reports a status of [arg1]. Informational
QXSP C4002I System running in setup. Informational
QXSP C4003I UE I deployment boot mode is enabled for NextBoot. Informational
QXSP C4004I UE I deployment boot mode is enabled for NextAc. Informational
QXSP C4005I UE I deployment boot mode has been disabled. Informational
QXSP W0003I The System [ComputerSystemElementName] encountered firmware
progress.
Informational
QXSP W0004I UE I advanced memory test is running. Informational
QXSP W0005I UE I advanced memory test is completed. Informational
QXSP W0006I UE I advanced memory test is interrupted. Informational
QXSP W0007I UE I advanced memory test encountered a hang. Informational
QXSP W2000I The System [ComputerSystemElementName] has detected a POST
Error deassertion.
Informational
QXSP W2001I The System [ComputerSystemElementName] has detected a POST
Error deassertion.
Informational
QXSPIO0000I The connector [PhysicalConnectorElementName] has been detected
as present or connected.
Informational
QXSPIO0010I A Correctable Bus Error has occurred on bus [SensorElementName]. Informational
QXSPIO0017I Package installed in slot [PhysicalConnectorElementName] for system
[ComputerSystemElementName].
Informational
QXSPIO2002I The System [ComputerSystemElementName] has detected a POST
Error deassertion.
Informational
QXSPIO2003I System [ComputerSystemElementName] has recovered from a
diagnostic interrupt.
Informational
QXSPIO2004I Bus [SensorElementName] has recovered from a bus timeout. Informational
QXSPIO2006I System [ComputerSystemElementName] has recovered from an NMI. Informational
QXSPIO2007I A PCI PERR recovery has occurred on system
[ComputerSystemElementName].
Informational
Chapter 2.XClarity Controller events 11

Table 2. E ents organized by se erity (continued)
E ent ID Message String Se erity
QXSPIO2008I A PCI SERR on system [ComputerSystemElementName] has
deasserted.
Informational
QXSPIO2010I Bus [SensorElementName] has recovered from a Correctable Bus
Error.
Informational
QXSPIO2013I Bus [SensorElementName] has recovered from a atal Bus Error. Informational
QXSPIO2014I Bus [SensorElementName] is no longer operating in a degraded state. Informational
QXSPIO2015I ault condition removed on slot [PhysicalConnectorElementName] on
system [ComputerSystemElementName].
Informational
QXSPIO2017I Slot [PhysicalConnectorElementName] empty for system
[ComputerSystemElementName].
Informational
QXSPMA0003I [PhysicalMemoryElementName] Added on Subsystem
[MemoryElementName].
Informational
QXSPMA0004I [PhysicalMemoryElementName] Disabled on Subsystem
[MemoryElementName].
Informational
QXSPMA0009I Memory sparing initiated for [PhysicalMemoryElementName] on
Subsystem [MemoryElementName].
Informational
QXSPMA0022I Memory sparing initiated for [PhysicalMemoryElementName] on
Subsystem [MemoryElementName].
Informational
QXSPMA0023I Memory sparing initiated for [PhysicalMemoryElementName] on
Subsystem [MemoryElementName].
Informational
QXSPMA0025I Sensor [SensorElementName] has asserted. Informational
QXSPMA2003I [PhysicalMemoryElementName] Removed on Subsystem
[MemoryElementName].
Informational
QXSPMA2005I The System [ComputerSystemElementName] has detected a POST
Error deassertion.
Informational
QXSPMA2007I Scrub ailure for [PhysicalMemoryElementName] on Subsystem
[MemoryElementName] has recovered.
Informational
QXSPMA2009I Memory sparing concluded for [PhysicalMemoryElementName] on
Subsystem [MemoryElementName].
Informational
QXSPMA2010I [PhysicalMemoryElementName] on Subsystem
[MemoryElementName] is no longer Throttled.
Informational
QXSPMA2012I An Over-Temperature Condition has been removed on the
[PhysicalMemoryElementName] on Subsystem
[MemoryElementName].
Informational
QXSPMA2013I The System [ComputerSystemElementName] has detected a POST
Error deassertion.
Informational
QXSPMA2017I Non-redundant:Sufficient Resources from Redundancy Degraded or
ully Redundant for [RedundancySetElementName] has deasserted.
Informational
QXSPMA2019I Non-redundant:Insufficient Resources for
[RedundancySetElementName] has deasserted.
Informational
QXSPMA2024I Sensor [SensorElementName] has deasserted. Informational
QXSPNM4000I Management Controller [arg1] Network Initialization Complete. Informational
12 ThinkSystem SR655 V3 Messages and Codes Reference

Table 2. E ents organized by se erity (continued)
E ent ID Message String Se erity
QXSPNM4001I Ethernet Data Rate modified from [arg1] to [arg2] by user [arg3]. Informational
QXSPNM4002I Ethernet Duplex setting modified from [arg1] to [arg2] by user [arg3]. Informational
QXSPNM4003I Ethernet MTU setting modified from [arg1] to [arg2] by user [arg3]. Informational
QXSPNM4004I Ethernet locally administered MAC address modified from [arg1] to
[arg2] by user [arg3].
Informational
QXSPNM4005I Ethernet interface [arg1] by user [arg2]. Informational
QXSPNM4006I Hostname set to [arg1] by user [arg2]. Informational
QXSPNM4007I IP address of network interface modified from [arg1] to [arg2] by user
[arg3].
Informational
QXSPNM4008I IP subnet mask of network interface modified from [arg1] to [arg2] by
user [arg3].
Informational
QXSPNM4009I IP address of default gateway modified from [arg1] to [arg2] by user
[arg3].
Informational
QXSPNM4011I ENET[[arg1]] DHCP-HSTN=[arg2], DN=[arg3], IP@=[arg4], SN=[arg5],
GW@=[arg6], DNS1@=[arg7] .
Informational
QXSPNM4012I ENET[[arg1]] IP-Cfg:HstName=[arg2], IP@=[arg3] ,NetMsk=[arg4],
GW@=[arg5] .
Informational
QXSPNM4013I LAN: Ethernet[[arg1]] interface is no longer active. Informational
QXSPNM4014I LAN: Ethernet[[arg1]] interface is now active. Informational
QXSPNM4015I DHCP setting changed to [arg1] by user [arg2]. Informational
QXSPNM4016I Domain name set to [arg1] by user [arg2]. Informational
QXSPNM4017I Domain Source changed to [arg1] by user [arg2]. Informational
QXSPNM4018I DDNS setting changed to [arg1] by user [arg2]. Informational
QXSPNM4019I DDNS registration successful. The domain name is [arg1]. Informational
QXSPNM4020I IPv6 enabled by user [arg1] . Informational
QXSPNM4021I IPv6 disabled by user [arg1] . Informational
QXSPNM4022I IPv6 static IP configuration enabled by user [arg1]. Informational
QXSPNM4023I IPv6 DHCP enabled by user [arg1]. Informational
QXSPNM4024I IPv6 stateless auto-configuration enabled by user [arg1]. Informational
QXSPNM4025I IPv6 static IP configuration disabled by user [arg1]. Informational
QXSPNM4026I IPv6 DHCP disabled by user [arg1]. Informational
QXSPNM4027I IPv6 stateless auto-configuration disabled by user [arg1]. Informational
QXSPNM4028I ENET[[arg1]] IPv6-LinkLocal:HstName=[arg2], IP@=[arg3] ,Pref=[arg4]
.
Informational
QXSPNM4029I ENET[[arg1]] IPv6-Static:HstName=[arg2], IP@=[arg3] ,Pref=[arg4],
GW@=[arg5] .
Informational
QXSPNM4030I ENET[[arg1]] DHCPv6-HSTN=[arg2], DN=[arg3], IP@=[arg4], Pref=
[arg5], DNS1@=[arg5].
Informational
Chapter 2.XClarity Controller events 13

Table 2. E ents organized by se erity (continued)
E ent ID Message String Se erity
QXSPNM4031I IPv6 static address of network interface modified from [arg1] to [arg2]
by user [arg3].
Informational
QXSPNM4033I Telnet port number changed from [arg1] to [arg2] by user [arg3]. Informational
QXSPNM4034I SSH port number changed from [arg1] to [arg2] by user [arg3]. Informational
QXSPNM4035I Web-HTTP port number changed from [arg1] to [arg2] by user [arg3]. Informational
QXSPNM4036I Web-HTTPS port number changed from [arg1] to [arg2] by user [arg3]. Informational
QXSPNM4037I CIM/XML HTTP port number changed from [arg1] to [arg2] by user
[arg3].
Informational
QXSPNM4038I CIM/XML HTTPS port number changed from [arg1] to [arg2] by user
[arg3].
Informational
QXSPNM4039I SNMP Agent port number changed from [arg1] to [arg2] by user
[arg3].
Informational
QXSPNM4040I SNMP Traps port number changed from [arg1] to [arg2] by user [arg3]. Informational
QXSPNM4041I Syslog port number changed from [arg1] to [arg2] by user [arg3]. Informational
QXSPNM4042I Remote Presence port number changed from [arg1] to [arg2] by user
[arg3].
Informational
QXSPNM4043I SMTP Server set by user [arg1] to [arg2]:[arg3]. Informational
QXSPNM4044I Telnet [arg1] by user [arg2]. Informational
QXSPNM4045I DNS servers set by user [arg1]: UseAdditionalServers=[arg2],
PreferredDNStype=[arg3], IPv4Server1=[arg4], IPv4Server2=[arg5],
IPv4Server3=[arg6], IPv6Server1=[arg7], IPv6Server2=[arg8],
IPv6Server3=[arg9].
Informational
QXSPNM4046I LAN over USB [arg1] by user [arg2]. Informational
QXSPNM4047I LAN over USB Port orwarding set by user [arg1]: ExternalPort=
[arg2], USB-LAN port=[arg3].
Informational
QXSPNM4048I PXE boot requested by user [arg1]. Informational
QXSPNM4049I User [arg1] has initiated a TKLM Server Connection Test to check
connectivity to server [arg2].
Informational
QXSPNM4050I User [arg1] has initiated an SMTP Server Connection Test. Informational
QXSPNM4051I User [arg1] has set the SMTP Server reverse-path to [arg2]. Informational
QXSPNM4052I DHCP specified hostname is set to [arg1] by user [arg2]. Informational
QXSPNM4053I DNS discovery of Lenovo XClarity Administrator has been [arg1] by
user [arg2].
Informational
QXSPNM4054I The hostname from DHCP is [arg1] by user [arg2]. Informational
QXSPNM4055I The hostname from DHCP is invalid. Informational
QXSPNM4056I The NTP server address [arg1] is invalid. Informational
QXSPNM4057I Security: IP address: [arg1] had [arg2] login failures, it will be blocked
to access for [arg3] minutes.
Informational
14 ThinkSystem SR655 V3 Messages and Codes Reference

Table 2. E ents organized by se erity (continued)
E ent ID Message String Se erity
QXSPNM4058I IP address of network interface [arg1] is modified from [arg2] to [arg3]
by user [arg4].
Informational
QXSPNM4059I IP subnet mask of network interface [arg1] is modified from [arg2] to
[arg3] by user [arg4].
Informational
QXSPNM4060I IP address of default gateway of network interface [arg1] is modified
from [arg2] to [arg3] by user [arg4].
Informational
QXSPOS4000I OS Watchdog response [arg1] by [arg2] . Informational
QXSPOS4001I Watchdog [arg1] Screen Capture Occurred . Informational
QXSPOS4004I Operating System status has changed to [arg1]. Informational
QXSPOS4005I Host Power-On password changed by user [arg1] from [arg2] at IP
address [arg3].
Informational
QXSPOS4006I Host Power-On password cleared by user [arg1] from [arg2] at IP
address [arg3].
Informational
QXSPOS4007I Host Admin password changed by user [arg1] from [arg2] at IP
address [arg3].
Informational
QXSPOS4008I Host Admin password cleared by user [arg1] from [arg2] at IP address
[arg3].
Informational
QXSPOS4009I OS Crash Video Captured. Informational
QXSPOS4011I OS failure screen capture with hardware error is [arg1] by user [arg2]
from [arg3] at IP address [arg4].
Informational
QXSPOS4012I POST watchdog Screen Capture Occurred. Informational
QXSPPP4000I Attempting to [arg1] server [arg2] by user [arg3]. Informational
QXSPPP4001I Server Power Off Delay set to [arg1] by user [arg2]. Informational
QXSPPP4002I Server [arg1] scheduled for [arg2] at [arg3] by user [arg4]. Informational
QXSPPP4003I Server [arg1] scheduled for every [arg2] at [arg3] by user [arg4]. Informational
QXSPPP4004I Server [arg1] [arg2] cleared by user [arg3]. Informational
QXSPPP4005I The power cap value changed from [arg1] watts to [arg2] watts by
user [arg3].
Informational
QXSPPP4006I The minimum power cap value changed from [arg1] watts to [arg2]
watts.
Informational
QXSPPP4007I The maximum power cap value changed from [arg1] watts to [arg2]
watts.
Informational
QXSPPP4008I The soft minimum power cap value changed from [arg1] watts to
[arg2] watts.
Informational
QXSPPP4011I Power capping was activated by user [arg1]. Informational
QXSPPP4012I Power capping was deactivated by user [arg1]. Informational
QXSPPP4013I Static Power Savings mode has been turned on by user [arg1]. Informational
QXSPPP4014I Static Power Savings mode has been turned off by user [arg1]. Informational
QXSPPP4015I Dynamic Power Savings mode has been turned on by user [arg1]. Informational
Chapter 2.XClarity Controller events 15

Table 2. E ents organized by se erity (continued)
E ent ID Message String Se erity
QXSPPP4016I Dynamic Power Savings mode has been turned off by user [arg1]. Informational
QXSPPP4017I Power cap and external throttling occurred. Informational
QXSPPP4018I External throttling occurred . Informational
QXSPPP4019I Power cap throttling occurred. Informational
QXSPPP4020I The measured power value has returned below the power cap value. Informational
QXSPPP4021I The new minimum power cap value has returned below the power cap
value.
Informational
QXSPPP4022I The server was restarted for an unknown reason. Informational
QXSPPP4023I The server is restarted by chassis control command. Informational
QXSPPP4024I The server was reset via push button. Informational
QXSPPP4025I The server was powered-up via power push button. Informational
QXSPPP4026I The server was restarted when the watchdog expired.. Informational
QXSPPP4027I The server was restarted for OEM reason. Informational
QXSPPP4028I The server was automatically powered on because the power restore
policy is set to always on.
Informational
QXSPPP4029I The server was automatically powered on because the power restore
policy is set to restore previous power state..
Informational
QXSPPP4030I The server was reset via Platform Event ilter. Informational
QXSPPP4031I The server was power-cycled via Platform Event ilter. Informational
QXSPPP4032I The server was soft reset. Informational
QXSPPP4033I The server was powered up via Real Time Clock (scheduled power
on).
Informational
QXSPPP4034I The server was powered off for an unknown reason. Informational
QXSPPP4035I The server was powered off by chassis control command. Informational
QXSPPP4036I The server was powered off via push button. Informational
QXSPPP4037I The server was powered off when the watchdog expired. Informational
QXSPPP4038I The server stayed powered off because the power restore policy is set
to always off.
Informational
QXSPPP4039I The server stayed powered off because the power restore policy is set
to restore previous power state..
Informational
QXSPPP4040I The server was powered off via Platform Event ilter. Informational
QXSPPP4041I The server was powered off via Real Time Clock (scheduled power
off).
Informational
QXSPPP4042I Management Controller [arg1] reset was initiated due to Power-On-
Reset.
Informational
QXSPPP4043I Management Controller [arg1] reset was initiated by PRESET. Informational
QXSPPP4044I Management Controller [arg1] reset was initiated by CMM. Informational
16 ThinkSystem SR655 V3 Messages and Codes Reference
