Lenovo Storage S2200
Product Guide
The Lenovo Storage S2200 (shown in the following figure) provides simplicity, speed, scalability, security,
and high availability for small to large businesses. The S2200 SAN array delivers enterprise-class storage
management technology in an affordable solution with a wide choice of host connectivity options, flexible
drive configurations, and enhanced data management features.
The S2200 is a perfect fit for small offices and remote and branch offices of large enterprises that need a
primary storage solution that supports general purpose workloads, such as file and print serving, web
serving, email and collaboration, and small databases. The S2200 is also well-suited for secure archive
storage or a low-cost backup solution.
Figure 1. Lenovo Storage S2200
The S2200 offers the flexible choice of 6/12 Gb SAS, 1/10 Gb iSCSI, and 4/8 Gb Fibre Channel (FC) host
connectivity protocols. The Converged Network Controller (CNC) design of the S2200 makes the selection
of iSCSI or FC host connectivity as simple as attaching corresponding transceivers or Direct-Attach Copper
(DAC) cables to the SFP/SFP+ ports on the RAID controller.
The S2200 supports up to 96 drives with up to three external expansion enclosures. It also offers flexible
drive configurations with the choice of 2.5-inch and 3.5-inch drive form factors, 10 K or 15 K rpm SAS and
7.2 K rpm NL SAS hard disk drives (HDDs) and self-encrypting drives (SEDs), and SAS solid-state drives
(SSDs). The S2200 can be scaled up to 480 TB of raw storage capacity.
Did you know?
The S2200 supports Intelligent Real-time Tiering capabilities that help optimize system performance, reduce
costs, and simplify management. The base software includes the ability to move data dynamically between
SAS HDDs that are optimized for cost per IOPS and NL SAS HDDs that are optimized for cost per GB. With
the optional software license, the S2200 supports hybrid tiering across HDDs and SSDs.
The S2200 can be upgraded to the Lenovo Storage S3200 by replacing the RAID controllers in the
controller enclosure during a planned offline maintenance window without the need to migrate or move data
and re-configure the attached hosts. The new S3200 RAID controller recognizes the array configuration and
preserves the controller's host port parameters (for example, FC WWN).
The S2200 supports battery-free cache protection, which reduces maintenance costs and provides
permanent backup of unwritten cache data if there is a power failure.
Lenovo Storage S2200 1

Key features
The S2200 storage system includes the following key features and benefits:
Low-cost, entry-level storage with a single controller or dual active/active controller configurations
for high availability and performance.
Flexible host connectivity to match diverse client needs with support for 6/12 Gb SAS (SAS
controller) or 1/10 Gb iSCSI or 4/8 Gb FC connectivity (FC and iSCSI controller).
Support for 6 Gb SAS drive-side connectivity with support for 12x 3.5-inch large form factor (LFF) or
24x 2.5-inch small form factor (SFF) drives in the controller enclosure; scalable up to 48 LFF drives
per system with the attachment of Lenovo Storage E1012 expansion enclosure (12x LFF drives each)
or up to 96 SFF drives per system with the attachment of Lenovo Storage E1024 expansion
enclosure (24x SFF drives each) to satisfy growing needs for storage capacity and performance.
Flexibility in storing data on high-performance SAS SSDs, performance-optimized enterprise SAS
HDDs, or capacity-optimized enterprise NL SAS HDDs; mixing and matching drive types and form
factors within a single system to perfectly meet performance and capacity requirements for various
workloads.
Support for SEDs to allow clients to secure their sensitive data and to comply with various security
regulations, when required.
Rich set of standard functions available at no extra cost, including virtualized storage pools,
snapshots, thin provisioning, rapid rebuild, real-time HDD tiering, and SSD read cache.
Optional licensed functions, including higher number of snapshots for more scalability, real-time SSD
tiering for boosting IOPS performance, and asynchronous replication for 24x7 data protection and
disaster recovery.
In-chassis upgrade to the S3200 storage system without the need to migrate data or to re-configure
attached hosts.
Intuitive, web-based GUI for easy system set up and management.
Designed to comply with NEBS and MIL-STD requirements.
Designed for 99.999% availability.
The S2200 supports the complete range of data storage requirements, from highly used applications to
high-capacity, low usage applications.
The following 3.5-inch drives are supported:
High-performance solid-state drives (10 drive writes per day [DWD]): 400 GB
Performance-optimized, enterprise class disk drives: 600 GB and 900 GB 10 K rpm
High-capacity, archival-class nearline disk drives: 2 TB, 4 TB, 6 TB, 8 TB, and 10 TB 7.2 K rpm
The following 2.5-inch drives are supported:
High performance solid-state drives (3 DWD and 10 DWD): 400 GB, 800 GB, and 1.6 TB
High performance self-encrypting solid-state drives (10 DWD): 400 GB and 800 GB
Capacity-optimized solid-state drives (1 DWD): 3.84 TB
Performance-optimized, enterprise class disk drives:
300 GB and 600 GB 15 K rpm
600 GB, 900 GB, 1.2 TB, and 1.8 TB 10 K rpm
High-capacity, archival-class nearline disk drives: 1 TB and 2 TB 7.2 K rpm
Other drives and expansion units are designed to be dynamically added with virtually no downtime, which
helps to quickly and seamlessly respond to ever-growing capacity demands.
Lenovo Storage S2200 2

The S2200 storage system offers high levels of system and data availability with the following technologies:
Dual-active RAID controllers with low latency cache mirroring
Dual-port drives (HDDs and SSDs) with automatic drive failure detection and rapid RAID rebuild with
global hot spares
Redundant hardware, including host ports, controller modules, and power supplies and fans
Hot-swappable and customer replaceable components, including controllers, power supplies with
fans, and drives
Automated path failover support for the data path between the host and the drives with multipathing
software
Non-disruptive controller firmware upgrades for dual controller configurations with multipathing
The following functions are included with every S2200:
Intelligent Real-time Tiering for HDDs: Storage tiering helps optimize storage use with intelligent
data placement to improve system performance, reduce costs, and simplify management. S2200
automatically and dynamically moves frequently accessed data to higher performing HDDs in the
system without manually creating and managing storage tier policies.
RAID levels 1, 5, 6, and 10: Provide the flexibility to choose the level of data protection that is
required.
Virtualized storage pools: Enables rapid, flexible storage provisioning and simple configuration
changes. Stored data is distributed across all drive groups in the pool (wide striping), which helps
improve performance, lower latency, and achieve higher volume capacities. When a new drive group
is added to the pool, the system performs automatic rebalancing to use all drives in the pool for
better performance.
Thin provisioning: Optimizes efficiency by allocating drive storage space in a flexible manner among
multiple applications that is based on the minimum required space by each application at any
specific time. With thin provisioning, applications use only the space they are actually using and not
the total space that was allocated to them, which allows clients to purchase storage they need today
and add storage as application requirements grow.
SSD Read Cache: An extension of the controller's cache to improve performance of read-centric
workloads.
Rapid RAID Rebuild: Helps significantly decrease the time to recover lost data by rebuilding only
the stripe where the corruption occurred, not the empty space or other stripes.
Snapshots: Enables creation of copies of data for backup, parallel processing, testing, and
development, and have the copies available almost immediately. Base software supports up to 64
snapshot targets per system.
The S2200 storage capabilities can be expanded with optional licensed functions. Each optional S2200
function is licensed on a per-system basis and covers controller enclosure and all attached expansion units.
The following optional licensed functions are available:
Intelligent Real-time Tiering for SSDs: The SSD tiering upgrade option enables the use of SSDs as
read and write data storage in the hybrid HDD and SSD storage configurations. Also, this option
makes it easy and economical to deploy hybrid storage by dynamically moving frequently accessed
data to SSDs in the system, which results in flash drive performance without manually creating and
managing storage tier policies.
Snapshots upgrade: The snapshot upgrade options increase the supported number of snapshot
targets to 256 or 512 per system.
Lenovo Storage S2200 3

Asynchronous Replication: The asynchronous replication feature provides storage system-based
data replication between two peers by using asynchronous data transfers over IP communication
links.
The replication is done at predetermined intervals (Now, 1-hour, 12-hour, 24-hour) and does not
require high-bandwidth network connection. For ultimate flexibility, S2200 asynchronous replication
interoperates with Lenovo Storage S3200 and ThinkSystem DS Series.
The asynchronous replication option must be acquired (or licensed) for both primary (local) and
secondary (remote) systems.
The S2200 supports the following management interfaces:
Web-based graphical user interface (GUI) via HTTP that requires only a supported browser
(Microsoft Internet Explorer, Google Chrome, or Mozilla Firefox); therefore, there is no need for a
separate console or plug-in.
Command line interface (CLI) via Telnet or SSH or through Direct Connect USB.
HTTP scripting interface with XML encoding.
SNMP and email notifications.
Components and connectors
The following figure shows the front of the S2200 SFF chassis and E1024 drive expansion enclosure.
Figure 2. Front view of the S2200 SFF chassis and E1024 drive enclosure
The following figure shows the front of the S2200 LFF chassis and E1012 drive expansion enclosure.
Figure 3. Front view of the S2200 LFF chassis and E1012 drive enclosure
Lenovo Storage S2200 4

The following figure shows the rear of the S2200 with FC or iSCSI host interfaces with dual RAID controllers.
Single RAID controller configurations also are supported.
Figure 4. Rear view of the S2200 with FC or iSCSI host interfaces
The following figure shows the rear of the S2200 with SAS host interfaces with dual RAID controllers. Single
RAID controller configurations also are supported.
Figure 5. Rear view of the S2200 with SAS host interfaces
Lenovo Storage S2200 5

The following figure shows the rear of the E1012 and E1024 drive enclosures with dual I/O expansion
modules. Single I/O module configurations also are supported with the single-controller S2200.
Figure 6. Rear view of the E1012 and E1024 drive enclosures
Note: The RAID controllers (as shown in Figure 4 and Figure 5) and expansion modules (as shown in Figure
6) include extra service ports with a specialized connector. These ports are reserved for use by a Lenovo
service technician.
System specifications
The following table lists the S2200 storage system specifications.
Table 1. System specifications
Components Specification
Form factor S2200 controller enclosure: 2U rack mount
E1012 or E1024 drive expansion enclosure: 2U rack mount
RAID controller
configuration
Two types of controllers:
S2200 SAS controller
S2200 FC and iSCSI controller
Single or dual RAID controller configurations supported. Single controller systems can be
upgraded to dual controller non-disruptively. Both controllers in the system must be the same.
RAID levels RAID 1, 5, 6, and 10
RAID controller
cache
6 GB per controller. Battery-free cache protection with flash memory and supercapacitors.
Low latency cache mirroring protection for dual controller configurations.
Drive bays Up to 96 SFF drive bays per system:
24 SFF drive bays in the S2200 controller enclosure
24 SFF drive bays in the E1024 drive expansion enclosure; up to 3x E1024 enclosures
Up to 48 LFF drive bays per system:
12 LFF drive bays in the S2200 controller enclosure
12 LFF drive bays in the E1012 drive expansion enclosure; up to 3x E1012 enclosures
Intermix of SFF and LFF enclosures is supported.
Drive
technologies
SAS and NL SAS HDDs and SEDs; eMLC SAS SSDs. Intermix of HDDs and SSDs is
supported. Intermix of SEDs with HDDs or SSDs is not supported.
Lenovo Storage S2200 6

Drive connectivity Dual-ported 6 Gb SAS drive attachment infrastructure.
Controller enclosure with one or two RAID controllers (ports per one controller):
24x 6 Gb SAS internal drive ports (SFF chassis)
12x 6 Gb SAS internal drive ports (LFF chassis)
1x 6 Gb SAS x4 (Mini-SAS SFF-8088) expansion port for the attachment of the external
drive enclosures
Drive expansion enclosure with one or two expansion modules (ports per one module):
24x 6 Gb SAS internal drive ports (SFF chassis)
12x 6 Gb SAS internal drive ports (LFF chassis)
2x 6 Gb SAS x4 (Mini-SAS SFF-8088) expansion ports (IN and OUT) for the daisy
chained attachment of the external drive enclosures
Drives SFF drives:
400 GB, 800 GB, and 1.6 TB SAS SSDs (3 DWD and 10 DWD)
400 GB and 800 GB SAS SED SSDs (10 DWD)
3.84 TB SAS SSDs (1 DWD)
300 GB and 600 GB 15K rpm SAS HDDs
600 GB, 900 GB, 1.2 TB, and 1.8 TB 10K rpm SAS HDDs
1 TB and 2 TB 7.2K rpm NL SAS HDDs
LFF drives:
400 GB SAS SSDs (10 DWD)
600 GB and 900 GB 10K rpm SAS HDDs
2 TB, 4 TB, 6 TB, 8 TB, and 10 TB 7.2K rpm NL SAS HDDs
Storage capacity Up to 480 TB (48x 10 TB NL SAS HDDs)
Host connectivity S2200 SAS controller: 2x 6/12 Gb SAS host ports (Mini-SAS HD, SFF-8644)
S2200 FC and iSCSI controller: 2x SFP/SFP+ CNC host ports
CNC host port options (per RAID controller):
2x 1 Gb iSCSI SFP (1 Gb speed, UTP, RJ-45)
2x 10 Gb iSCSI SFP+ (1/10 Gb speeds, SW fiber optics, LC)
2x 8 Gb FC SFP+ (4/8 Gb speeds, SW fiber optics, LC)
2x 10 Gb iSCSI SFP+ DAC cables
Host operating
systems
Microsoft Windows Server 2012 R2 and 2016; Red Hat Enterprise Linux (RHEL) 6 and 7; SUSE
Linux Enterprise Server (SLES) 11 and 12; VMware vSphere 5.5, 6.0, and 6.5.
Standard software
features
Intelligent Real-time Tiering for HDDs, Virtualized Storage Pools, Thin Provisioning, SSD Read
Cache, Rapid RAID Rebuild, Snapshots (up to 64 targets).
Optional software
features
Intelligent Real-time Tiering for SSDs, Snapshots (up to 512 targets), Asynchronous
Replication.
Performance Dual controller configuration:
Up to 80,000 random read IOPS (4 KB blocks)
Up to 3.3 GBps sequential read throughput (512 KB blocks)
Up to 2.4 GBps sequential write throughput (512 KB blocks)
Components Specification
Lenovo Storage S2200 7

Configuration
maximums
Per system:
Maximum number of virtual storage pools: 2 (1 per controller)
Maximum number of logical volumes (total/mapped): 2,048/1,024
Maximum logical volume size: 128 TB
Maximum number of drives in a drive group: 16
Maximum number of drive groups: 32
Maximum global spares: 16
Maximum number of initiators: 8,192 (1,024 per port)
Maximum number of hosts in a host group: 256
Maximum number of host groups: 32
Maximum number of initiators per host: 128
Maximum number of snapshots: 512 (requires an optional license)
Maximum number of replication peers: 1 (requires an optional license)
Maximum number of replication volumes: 32 (requires an optional license)
Cooling Redundant cooling with two fans that are built into power supplies.
Power supply Two redundant hot-swap 595 W AC power supplies.
Hot-swap parts RAID controllers, expansion modules, optical transceivers, drives, power supplies with fans.
Management
interfaces
Web-based GUI; Telnet, SSH, or Direct Connect USB CLI; HTTP scripting with XML encoding;
SNMP and email notifications
Security features Secure Socket Layer (SSL), Secure Shell (SSH), and SEDs
Warranty Three-year customer-replaceable unit, parts-only limited warranty with 9x5 next business day.
Service and
support
Optional warranty service upgrades are available through Lenovo: on-site support, 24x7
coverage, 4-hour response time, 1-year or 2-year warranty extensions, Hard Drive Retention.
Dimensions LFF chassis: Height: 87 mm (3.4 in), width: 447 mm (17.6 in), depth: 523 mm (20.6 in)
SFF chassis: Height: 89 mm (3.5 in), width: 447 mm (17.6 in), depth: 519 mm (20.5 in)
Weight S2200 LFF: Minimum: 17.7 kg (39.0 lb); Maximum: 27.5 kg (60.6 lb)
S2200 SFF: Minimum: 17.8 kg (39.2 lb); Maximum: 24.3 kg (53.6 lb)
E1012: Minimum: 16.8 kg (37.0 lb); Maximum: 26.6 kg (58.6 lb)
E1024: Minimum: 16.9 kg (37.2 lb); Maximum: 23.4 kg (51.6 lb)
Components Specification
Lenovo Storage S2200 8

Controller enclosures
The following table lists the relationship models of the S2200 chassis.
Product availability: Relationship models of the Lenovo Storage S2200 listed in this section are
withdrawn and no longer available for ordering.
Table 2. Part numbers for ordering S2200 relationship models
Description Part number
LFF models
Lenovo Storage S2200 LFF Chassis SAS Single Controller, Rack Kit, 9x5NBD 64112B1*
Lenovo Storage S2200 LFF Chassis SAS Dual Controller, Rack Kit, 9x5NBD 64112B2
Lenovo Storage S2200 LFF Chassis FC/iSCSI Single Controller, Rack Kit, 9x5NBD 64114B1*
Lenovo Storage S2200 LFF Chassis FC/iSCSI Dual Controller, Rack Kit, 9x5NBD 64114B2
SFF models
Lenovo Storage S2200 SFF Chassis SAS Single Controller, Rack Kit, 9x5NBD 64112B3*
Lenovo Storage S2200 SFF Chassis SAS Dual Controller, Rack Kit, 9x5NBD 64112B4
Lenovo Storage S2200 SFF Chassis FC/iSCSI Single Controller, Rack Kit, 9x5NBD 64114B3*
Lenovo Storage S2200 SFF Chassis FC/iSCSI Dual Controller, Rack Kit, 9x5NBD 64114B4
* Not available for ordering in North America (United States and Canada).
The part numbers for the S2200 relationship models include the following items:
One S2200 chassis with two power supplies and fans:
With one or two SAS RAID controllers installed
With one or two FC and iSCSI RAID controllers installed
Two 4.3 m, 10 A/100 - 250 V, C13 to IEC 320-C14 Rack Power Cables
Lenovo Storage SAN Rack Mount Kit: Rails 25-inch to 36-inch
Lenovo 1.5 m USB console cable (USB to Mini-USB)
Getting Started Guide
Warranty Flyer
Important Notices Flyer
Documentation Flyer
Lenovo Storage S2200 9

The following table lists the TopSeller models of the S2200 chassis.
Note: S2200 TopSeller models are not available for ordering in North America (United States and Canada)
Product availability: TopSeller models of the Lenovo Storage S2200 listed in this section are withdrawn
and no longer available for ordering.
Table 3. Part numbers for ordering S2200 TopSeller models
Description Part number
LFF models
S2200 LFF Dual SAS Controller/4x 6Gb SAS/Rack Kit/Base Warranty 6411E11
S2200 LFF Dual SAS Controller/4x 6Gb SAS/8x 6TB 7.2K HDDs/Rack Kit/Base Warranty 6411E12
S2200 LFF Dual FC/iSCSI Controller/4x 1Gb iSCSI RJ45/Rack Kit/Base Warranty 6411E13
S2200 LFF Dual FC/iSCSI Controller/4x 8Gb FC/8x 4TB 7.2K HDDs/Rack Kit/Base Warranty 6411E14
S2200 LFF Dual FC/iSCSI Controller/4x 8Gb FC/8x 2TB 7.2K HDDs/Rack Kit/Base Warranty 6411E1D
SFF models
S2200 SFF Dual SAS Controller/4x 6Gb SAS/Rack Kit/Base Warranty 6411E16
S2200 SFF Dual FC/iSCSI Controller/2x 1Gb iSCSI RJ45/Rack Kit/Base Warranty 6411E17
S2200 SFF Dual FC/iSCSI Controller/4x 1Gb iSCSI RJ45/4x 600GB 10K HDDs/Rack Kit/Base WTY 6411E23
S2200 SFF Dual FC/iSCSI Controller/4x 8Gb FC/8x 600GB 10K HDDs/Rack Kit/Base Warranty 6411E18
S2200 SFF Dual FC/iSCSI Controller/4x 8Gb FC/8x 900GB 10K HDDs/Rack Kit/Base Warranty 6411E19
S2200 SFF Dual FC/iSCSI Controller/4x 8Gb FC/12x 600GB 10K HDDs/Rack Kit/Base Warranty 6411E22
S2200 SFF Dual FC/iSCSI Controller/4x 8Gb FC/4x 400GB SSDs/10x 600GB 10K HDDs/Tiering 6411E21
The S2200 TopSeller model part numbers include the following items:
One S2200 chassis with two power supplies and fans:
With two SAS RAID controllers installed (see Table 3 for details)
With two FC and iSCSI RAID controllers installed (with 2x or 4x SFPs; see Table 3 for details)
Without drives, or with HDDs, or with HDDs and SSDs (see Table 3 for details)
Tiering license (part number 6411E21 only)
Two 4.3 m, 10 A/100 - 250 V, C13 to IEC 320-C14 Rack Power Cables
Lenovo Storage SAN Rack Mount Kit: Rails 25-inch to 36-inch
Lenovo 1.5 m USB console cable (USB to Mini-USB)
Getting Started Guide
Warranty Flyer
Important Notices Flyer
Documentation Flyer
Lenovo Storage S2200 10

RAID controller modules
The S2200 supports single and dual controller configurations. Standard models of the S2200 ship with one
or two RAID controller modules (for more information, see Table 2). Single-controller models can be
upgraded to dual-controller models non-disruptively.
The following types of RAID controller modules are available:
S2200 SAS RAID Controllers
S2200 FC and iSCSI RAID Controllers
S2200 SAS RAID Controllers provide direct SAS attachment for up to two hosts with a supported SAS HBA
installed. Each S2200 SAS Controller has two 6/12 Gb SAS ports with Mini-SAS HD (SFF-8644) connectors.
S2200 FC and iSCSI RAID Controllers provide SAN based iSCSI or FC connectivity to the hosts with a
supported software initiator or HBA installed. Each S2200 FC and iSCSI Controller has a built-in CNC,
which has two SFP/SFP+ ports.
The CNC supports the following storage connectivity protocols, depending on the SFP/SFP+ transceiver
installed or DAC cables attached:
1 Gb iSCSI with 1 GbE RJ-45 SFP optical modules
1/10 Gb iSCSI with 10 GbE SW SFP+ optical modules with LC connectors
10 Gb iSCSI with 10 GbE SFP+ DAC cables
4/8 Gb Fibre Channel with 8 Gb FC SW SFP+ optical modules with LC connectors
Notes:
Both ports on the CNC on the S2200 FC and iSCSI RAID Controller must have the same connectivity
type (the same type of SFP/SFP+ modules or DAC cables).
For dual-controller configurations, both RAID controllers in the system must be of the same type and
they must have matching port configurations (that is, the ports on both S2200 RAID controllers must
have SFP/SFP+ modules of the same type).
Both SAS controllers and FC and iSCSI controllers have one 6 Gb SAS x4 expansion port (Mini-SAS SFF-
8088 connector) for the attachment of the E1012 and E1024 expansion enclosures.
Lenovo Storage S2200 11

The following table lists ordering information for the RAID controllers and related connectivity options.
Table 4. RAID controllers and connectivity options
Description Part
number
Feature
code (MTM
6411-HC1)
Max qty
per one
S2200
RAID controller modules
Lenovo Storage S2200 FC and iSCSI Controller 00WC081 AT25 2
Lenovo Storage S2200 SAS Controller 00WC082 AT26 2
FC and iSCSI controller host connectivity options
Lenovo Storage S2200/S3200 1G RJ45 iSCSI SFP+ Module 1 pack 00WC086 AT2C 4*
Lenovo Storage S2200/S3200 10G SW Optical iSCSI SFP+ Module 1 pack 00WC087 AT2A 4*
Lenovo Storage S2200/S3200 8G Fibre Channel SFP+ Module 1 pack 00WC088 AT28 4*
Cable options for FC and optical iSCSI host connectivity
Lenovo 1m LC-LC OM3 MMF Cable 00MN502 ASR6 4**
Lenovo 3m LC-LC OM3 MMF Cable 00MN505 ASR7 4**
Lenovo 5m LC-LC OM3 MMF Cable 00MN508 ASR8 4**
Lenovo 10m LC-LC OM3 MMF Cable 00MN511 ASR9 4**
Lenovo 25m LC-LC OM3 MMF Cable 00MN517 ASRB 4**
DAC cable options for 10 Gb iSCSI host connectivity
Lenovo 1m Passive SFP+ DAC Cable 90Y9427 A1PH 4**
Lenovo 2m Passive SFP+ DAC Cable 00AY765 A51P 4**
Lenovo 3m Passive SFP+ DAC Cable 90Y9430 A1PJ 4**
SAS host connectivity cables - Mini-SAS HD (controller) to Mini-SAS (host)
1.5m HD-miniSAS to miniSAS SAS Cable 00D5224 A3HX 4**
3m HD-miniSAS to miniSAS SAS Cable 00D5226 A3HY 4**
SAS host connectivity cables - Mini-SAS HD (controller) to Mini-SAS HD (host)
External MiniSAS HD 8644/MiniSAS HD 8644 1m cable 00WE748 AT1D 4**
External MiniSAS HD 8644/MiniSAS HD 8644 2m cable 00WE749 AT1E 4**
Cable options for 1 Gb iSCSI and Ethernet management ports
Lenovo Ethernet CAT5E shielded 6m cable 00WE747 AT1G 6***
Spare cables for serial management ports
Lenovo USB A Male-to-Mini-B 1.5m cable 00WE746 AT1F 1
* Up to two SFP/SFP+ modules per controller; the modules must be of the same type.
** Up to two cables per controller.
*** Up to three cables per controller: one cable for 1 GbE management port connection; up to two cables for CNC port
connections with 1G RJ45 modules attached.
System upgrades
Lenovo Storage S2200 12

System upgrades
The S2200 can be upgraded to Lenovo Storage S3200 functionality by replacing the S2200 controllers with
the S3200 controllers during a planned offline maintenance window without the need to migrate or move
data and re-configure the attached hosts. The new S3200 controller recognizes the array configuration and
preserves the controller's host port parameters, such as FC World Wide Names (WWNs) or iSCSI Qualified
Names (IQNs).
For more information about the S3200 storage, including features, capabilities, and ordering information for
the S3200 controllers and other S3200 options, see the following Lenovo Storage S3200 Product Guide:
http://lenovopress.com/tips1299
Expansion enclosures
The S2200 supports attachment of up to three Lenovo Storage E1012 or E1024 expansion enclosures.
Intermix of E1012 and E1024 is supported. The enclosures can be added to the system non-disruptively.
The following table lists the models of the E1012 and E1024 expansion enclosure models.
Table 5. Part numbers for ordering E1012 and E1024 models
Description Part number
LFF models
Lenovo Storage E1012 LFF Disk Expansion Single SAS IO Module, Rail Kit, 9x5 NBD 64111B1
Lenovo Storage E1012 LFF Disk Expansion Dual SAS IO Module, Rail Kit, 9x5 NBD 64111B2
SFF models
Lenovo Storage E1024 SFF Disk Expansion Single SAS IO Module, Rail Kit, 9x5 NBD 64111B3
Lenovo Storage E1024 SFF Disk Expansion Dual SAS IO Module, Rail Kit, 9x5 NBD 64111B4
The part number for the E1012 or E1024 includes the following items:
One enclosure with two power supplies and fans and with two expansion modules installed
Two 4. 3m, 1 0A/100 - 250 V, C13 to IEC 320-C14 Rack Power Cables
Lenovo Storage SAN Rack Mount Kit: Rails 25-inch to 36-inch
Getting Started Guide
Warranty Flyer
Important Notices Flyer
Documentation Flyer
The E1012 and E1024 support single and dual expansion module configurations. Standard models of the
E1012 and E1024 ship with one or two expansion modules (for more information, see Table 5). Single
module configurations can be upgraded to dual module configurations non-disruptively. The number of
expansion modules in the E1012 or E1024 must match the number of RAID controllers in the S2200.
Each expansion module has two 6 Gb SAS x4 ports (Mini-SAS SFF-8088 connectors) that are labelled IN
and OUT. These ports are used for connections to the S2000 and for daisy chaining the E1012 and E1024
enclosures between each other. The expansion port on the S2200 controller is connected to the IN port on
the expansion module. The OUT port on the expansion module is connected to the IN port on the expansion
module in the adjacent enclosure, and so on.
Lenovo Storage S2200 13

The expansion connectivity topology for dual controller configurations is shown in the following figure. For
single controller configurations, only Controller A path is present.
Figure 7. Expansion connectivity topology
The following table lists the ordering information for the expansion modules and related connectivity
options.
Table 6. Expansion modules and connectivity options
Description Part
number
Feature code
(MTM 6411-
HC3)
Max qty per
one E1012 or
E1024
Expansion modules
Lenovo Storage Expansion SAS IO Module 00WC085 AT27 2
SAS expansion connectivity cables
External MiniSAS 8088/MiniSAS 8088 1m cable 00WE755 AT1B 2*
External MiniSAS 8088/MiniSAS 8088 0.6m cable 00WE754 AT1A 2*
External MiniSAS 8088/MiniSAS 8088 2m cable 00WE756 AT1C 2*
* One cable per SAS expansion module
Lenovo Storage S2200 14

Drives
The S2200 LFF chassis and the E1012 expansion enclosure support up to 12 LFF hot-swap drives. The
S2200 SFF chassis and the E1024 expansion enclosure support up to 24 SFF hot-swap drives.
The following table lists drive options for the S2200 LFF chassis and the E1012 expansion enclosure.
Table 7. LFF drive options
Description Part
number
Feature code
(MTM 6411-HC1,
6411-HC3)
Max qty per
one S2200 LFF
or E1012
3.5-inch SAS hot-swap HDDs
Lenovo Storage 3.5" 600GB 10K SAS HDD (2.5" in 3.5") 00WC040 AT21 12
Lenovo Storage 3.5" 900GB 10K SAS HDD (2.5" in 3.5") 00WC035 AT1Z 12
3.5-inch NL SAS hot-swap HDDs
Lenovo Storage 3.5" 2TB 7.2k NL-SAS HDD 00MM735 AT1V 12
Lenovo Storage 3.5" 4TB 7.2k NL-SAS HDD 00MM730 AT1W 12
Lenovo Storage 3.5" 6TB 7.2k NL-SAS HDD 00MM725 AT1Y 12
Lenovo Storage 3.5" 8TB 7.2k NL-SAS HDD 00WE790 AT47 12
Lenovo Storage 3.5" 10TB 7.2k NL-SAS HDD 01DC631 AU7W 12
3.5-inch NL SAS hot-swap SEDs
Lenovo Storage 3.5" 4TB 7.2k NL-SAS HDD (SED) 00WC025 AT1X 12
3.5-inch SAS hot-swap SSDs (10 DWD)
Lenovo Storage 3.5" 400GB SSD SAS (2.5" in 3.5") 00WC030 AT20 12
Lenovo Storage S2200 15

The following table lists drive options for the S2200 SFF chassis and the E1024 expansion enclosure.
Table 8. SFF drive options
Description Part
number
Feature code
(MTM 6411-HC1,
6411-HC3)
Max qty per
one S2200 SFF
or E1024
2.5-inch SAS hot-swap HDDs
Lenovo Storage 2.5" 300GB 15k SAS HDD 00MM685 AT1H 24
Lenovo Storage 2.5" 600GB 10k SAS HDD 00MM700 AT1K 24
Lenovo Storage 2.5" 600GB 15k SAS HDD 00MM680 AT1J 24
Lenovo Storage 2.5" 900GB 10k SAS HDD 00MM695 AT1M 24
Lenovo Storage 2.5" 1.2TB 10k SAS HDD 00MM690 AT1P 24
Lenovo Storage 2.5" 1.8TB 10k SAS HDD 00YG718 ATSK 24
2.5-inch SAS hot-swap SEDs
Lenovo Storage 2.5" 600GB 10k SAS HDD (SED) 00WC020 AT1L 24
Lenovo Storage 2.5" 900GB 10k SAS HDD (SED) 00MM745 AT1N 24
Lenovo Storage 2.5" 1.2TB 10k SAS HDD (SED) 00MM740 AT1Q 24
2.5-inch NL SAS hot-swap HDDs
Lenovo Storage 2.5" 1TB 7.2k NL-SAS HDD 00MM705 AT1R 24
Lenovo Storage 2.5" 2TB 7.2k NL-SAS HDD 00YG698 ATSL 24
2.5-inch SAS hot-swap SSDs (1 DWD)
Lenovo Storage 2.5" 3.84TB 1DWD SSD 01CX868 AUJN 24
2.5-inch SAS hot-swap SSDs (3 DWD)
Lenovo Storage 2.5" 400GB 3DWD SSD 00YH988 AU22 24
Lenovo Storage 2.5" 800GB 3DWD SSD 00YH978 AU21 24
Lenovo Storage 2.5" 1.6TB 3DWD SSD 00YH968 AU20 24
2.5-inch SAS hot-swap SSDs (10 DWD)
Lenovo Storage 2.5" 400GB SSD (SAS) 00MM720 AT1S 24
Lenovo Storage 2.5" 800GB SSD (SAS) 00MM715 AT1T 24
Lenovo Storage 2.5" 1.6TB SSD (SAS) 00MM710 AT1U 24
2.5-inch SAS hot-swap SED SSDs (10 DWD)
Lenovo Storage 2.5” 400GB 10DWD SED SSD 00YH983 AU24 24
Lenovo Storage 2.5" 800GB 10DWD SED SSD 00YH973 AU23 24
Software
The S2200 comes standard with the following software features:
Intelligent Real-time Tiering for HDDs
Virtualized Storage Pools
Thin Provisioning
SSD Read Cache
Rapid RAID Rebuild
Snapshots: up to 64 targets
Lenovo Storage S2200 16

The functionality of the S2200 can be expanded with the following optional software features:
Intelligent Real-time Tiering for SSDs (Required for hybrid array configurations with SSDs and HDDs)
Snapshots: up to 256 targets
Snapshots: up to 512 targets
Asynchronous replication
The following table lists the Feature on Demand (FoD) upgrades for the S2200 to enable optional software
features. Each optional S2200 function is licensed on a per-system basis and covers both controller
enclosure and all attached expansion units.
Table 9. Optional FoD upgrades for software features
Description
Part
number
Feature
code
256 Snapshot Upgrade License 01GV558 AWGL
512 Snapshot Upgrade License 01GV559 AWGM
SSD Data Tiering License* 01GV561 AWGP
Asynchronous Replication License** 01GV562 AWGQ
* Prior to the firmware version GL221R019-05, the SSD Data Tiering Upgrade option was required for all flash array
configurations (a storage system with SSDs only; no HDDs installed) and for hybrid array configurations (a storage system with
SSDs and HDDs). With the firmware version GL221R019-05 or later, the SSD Data Tiering Upgrade option is no longer required
for all flash array configurations; however, it is required for hybrid configurations.
** Asynchronous Replication requires an FC and iSCSI Controller-based S2200 storage unit.
Software maintenance for standard software features is included in the S2200 base warranty and optional
warranty extensions, which provides 3-year software support with the option to extend it up to 5 years in 1-
year or 2-year increments (see the Warranty section for details).
Optional software features that are listed in Table 9 include 3-year software maintenance with the ability to
extend it up to 5 years in 1-year or 2-year increments with the purchase of the software maintenance
extension options that are listed in the following table.
Note: The S2200 must have active warranty coverage for the duration of an intended software maintenance
extension period.
Table 10. Software maintenance extension options
Description Part
number
Feature code
(MTM 6411-HC1)
Lenovo Storage 256 Snapshot Upgrade Maintenance 1 yr 00WF817 ATT2
Lenovo Storage 256 Snapshot Upgrade Maintenance 2 yr 00WF821 ATT3
Lenovo Storage 512 Snapshot Upgrade Maintenance 1 yr 00WF825 ATT4
Lenovo Storage 512 Snapshot Upgrade Maintenance 2 yr 00WF829 ATT5
Lenovo Storage SSD Data Tiering Maintenance 1 yr 00WF841 ATT8
Lenovo Storage SSD Data Tiering Maintenance 2 yr 00WF845 ATT9
Lenovo Storage Asynch Replication Maintenance 1yr 00YG680 ATTA
Lenovo Storage Asynch Replication Maintenance 2yr 00YG684 ATTB
Power cables
Lenovo Storage S2200 17

Power cables
The S2200, E1012, and E1024 ship standard with two 4.3 m, 10 A/100 - 250 V, C13 to IEC 320-C14 Rack
Power Cables. Other power cable options are also available. The part numbers and feature codes to order
them (two power cables are required per each S2200, E1012, and E1024) are listed in the following table.
Table 11. Part numbers and feature codes for ordering power cables
Description Part
number
Feature code (MTM
6411-HC1, 6411-HC3)
Rack power cables
1.2m, 10A/100-250V, 2 Short C13s to Short C14 Rack Power Cable 47C2487 A3SS
1.2m, 16A/100-250V, 2 Short C13s to Short C20 Rack Power Cable 47C2491 A3SW
1.5m, 10A/100-250V, C13 to IEC 320-C14 Rack Power Cable 39Y7937 6201
2.5m, 10A/100-250V, 2 Long C13s to Short C14 Rack Power Cable 47C2488 A3ST
2.5m, 16A/100-250V, 2 Long C13s to Short C20 Rack Power Cable 47C2492 A3SX
2.8m, 10A/100-250V, 2 Short C13s to Long C14 Rack Power Cable 47C2489 A3SU
2.8m, 10A/100-250V, C13 to IEC 320-C14 Rack Power Cable None* 6311
2.8m, 10A/100-250V, C13 to IEC 320-C20 Rack Power Cable 39Y7938 6204
2.8m, 16A/100-250V, 2 Short C13s to Long C20 Rack Power Cable 47C2493 A3SY
4.1m, 10A/100-250V, 2 Long C13s to Long C14 Rack Power Cable 47C2490 A3SV
4.1m, 16A/100-250V, 2 Long C13s to Long C20 Rack Power Cable 47C2494 A3SZ
4.3m, 10A/100-250V, C13 to IEC 320-C14 Rack Power Cable 39Y7932 6263
Country-specific power cords
10A/125V C13 to NEMA 5-15P 4.3m line cord 39Y7931 6207
10A/250V C13 to NEMA 6-15P 2.8m line cord 46M2592 A1RF
Argentina 10A/250V C13 to IRAM 2073 2.8m line cord 39Y7930 6222
Australia/NZ 10A/250V C13 to AS/NZ 3112 2.8m line cord 39Y7924 6211
Brazil 10A/250V C13 to NBR 14136 2.8m line cord 69Y1988 6532
China 10A/250V C13 to GB 2099.1 2.8m line cord 39Y7928 6210
Denmark 10A/250V C13 to DK2-5a 2.8m line cord 39Y7918 6213
European 10A/230V C13 to CEE7-VII 2.8m line cord 39Y7917 6212
India 10A/250V C13 to IS 6538 2.8m line cord 39Y7927 6269
Israel 10A/250V C13 to SI 32 2.8m line cord 39Y7920 6218
Italy 10A/250V C13 to CEI 23-16 2.8m line cord 39Y7921 6217
Japan 12A/125V C13 to JIS C-8303 2.8m line cord 46M2593 A1RE
Korea 12A/250V C13 to KETI 2.8m line cord 39Y7925 6219
South Africa 10A/250V C13 to SABS 164 2.8m line cord 39Y7922 6214
Switzerland 10A/250V C13 to SEV 1011-S24507 2.8m line cord 39Y7919 6216
Taiwan 15A/125V C13/CNS 10917 2.8m line cord 00CG267 6402
United Kingdom 10A/250V C13 to BS 1363/A 2.8m line cord 39Y7923 6215
Physical specifications
Lenovo Storage S2200 18

Physical specifications
The S2200, E1012, and E1024 have the following dimensions and weight (approximate):
LFF chassis:
Height: 87 mm (3.4 in.)
Width: 447 mm (17.6 in.)
Depth: 523 mm (20.6 in.)
SFF chassis:
Height: 89 mm (3.5 in.)
Width: 447 mm (17.6 in.)
Depth: 519 mm (20.5 in.)
Weight:
S2200 LFF: Minimum: 17.7 kg (39.0 lb); Maximum: 27.5 kg (60.6 lb)
S2200 SFF: Minimum: 17.8 kg (39.2 lb); Maximum: 24.3 kg (53.6 lb)
E1012: Minimum: 16.8 kg (37.0 lb); Maximum: 26.6 kg (58.6 lb)
E1024: Minimum: 16.9 kg (37.2 lb); Maximum: 23.4 kg (51.6 lb)
Operating environment
The S2200, E1012, and E1024 are supported in the following environment:
Air temperature:
Operating: 5 °C - 40 °C (41 °F - 104 °F); decrease the maximum ambient temperature by 3.3
°C for every 1,000 m (3,280 ft)
Storage: -10 °C - +60 °C (14 °F - 140 °F)
Maximum altitude: 3,000 m (9,842 ft)
Humidity:
Operating: 8% - 85% (non-condensing)
Storage: 5% - 90% (non-condensing)
Electrical: 100 to 240 (nominal) V AC; 50 Hz - 60 Hz
BTU output: 1488 Btu/hr (436 W)
Noise level: 6.8 bels
Warranty
The S2200 includes a three-year parts-only warranty with 9x5/next business day (NBD) terms. Lenovo
offers the service upgrades through warranty maintenance upgrades and post-warranty maintenance
agreements with a well-defined scope of services, including service hours, response time, term of service,
and service agreement terms and conditions.
Lenovo warranty service upgrade offerings are country-specific. Not all warranty service upgrades are
available in every country. For more information about Lenovo warranty service upgrade offerings that are
available in your country, refer to the Data Center Advisor and Configurator (DCACT; formerly known
as LESC):
http://lesc.lenovo.com.
Lenovo Storage S2200 19

Warranty service definitions for the S2200 system are listed in the following table.
Table 12. Warranty service definitions
Term Description
On-site
service
A service technician will arrive at the client’s location for equipment service.
24x7x4
hour
A service technician is scheduled to arrive at the client’s location within four hours after remote
problem determination is completed. Lenovo provides service around the clock, every day, including
Lenovo holidays.
9x5x4
hour
A service technician is scheduled to arrive at the client’s location within four business hours after
remote problem determination is completed. Lenovo provides service 8:00 am - 5:00 pm in the client's
local time zone, Monday-Friday, excluding Lenovo holidays. For example, if a customer reports an
incident at 3:00 pm on Friday, the technician arrives by 10:00 am the following Monday.
9x5 next
business
day
A service technician is scheduled to arrive at the client’s location on the business day after remote
problem determination is completed. Lenovo provides service 8:00 am - 5:00 pm in the client's local
time zone, Monday - Friday, excluding Lenovo holidays. Calls received after 4:00 pm local time require
an extra business day for service dispatch. Next business day service is not guaranteed.
In general, the following types of Lenovo warranty service upgrades for the S2200 are available:
Warranty and maintenance service upgrades:
Onsite support for 9x5 NBD coverage
4-hour target response time with onsite, 9x5 or 24x7 service coverage
Up to five years of warranty extension for all service levels in one or two year increments
Hard Drive Retention
Lenovo’s Hard Drive Retention service is a multi-drive hard drive retention offering that ensures your
data is always under your control, regardless of the number of hard drives that are installed in your
Lenovo system. In the unlikely event of a hard drive failure, you retain possession of your hard drive
while Lenovo replaces the failed drive part. Your data stays safely on your premises, in your hands.
The Hard Drive Retention service can be purchased in convenient bundles with our warranty
upgrades and extensions.
Regulatory compliance
The S2200 conforms to the following regulations:
UL 60950-1, 2nd Edition, 2007-03-27 (USA)
CAN/CSA-C22.2 No 60950-1-07, 2nd Edition, 2007-03 (Canada)
IEC 60950-1:2005 (2nd Edition); Am 1:2009
EN 60950-1:2005, 2nd Edition, AM1 2009 (EU)
CFR 47 Part 15 Subpart B Class A (USA FCC)
ICES-003:2012, Class A (Canada)
EN 55022: 2010 Class A (EU)
EN 55024: 2010 (EU)
ASNZS CISPR 22 -2009 Class A
CNS 14338 (2006)
KN22 Class A
VCCI Technical Requirements 2012 Class A
RoHS Directive 2011/65/EU
EAC
NOM
BMSI
CCC
Lenovo Storage S2200 20
