IBM UPS5000 HV Uninterruptible Power Supply for
IBM System x
Product Guide
The IBM UPS5000 HV is a 5 KVA rack-mountable uninterruptible power supply (UPS) that utilizes
advanced backup power technology to ensure maximum protection of equipment and data and increase
availability. High power efficiency is delivered through the capability of automatically switching the UPS to
the efficiency mode appropriate for required power protection. Support for different line cords lets
multinational customers implement this single model UPS5000 HV in multiple geographies.
The IBM UPS5000 HV uninterruptible power supply is shown in Figure 1.
Figure 1. IBM UPS5000 HV uninterruptible power supply for IBM System x
Did you know?
The UPS5000 HV packs 4500W of power into a space-efficient 3U form. This provides maximum power
density, thereby leaving more space for other computer hardware in rack and BladeCenter server
environments.
Double Conversion UPS technology provides maximum protection from potential power input problems.
This leads to higher availability and fewer problems that threaten data and equipment.
IBM UPS5000 HV Uninterruptible Power Supply for IBM System x 1

Part number information
Table 1. Ordering part numbers and feature codes
Description Part number Feature code
IBM UPS5000 HV uninterruptible power supply 2419-5KX Not applicable
IBM UPS 3U Online Battery Pack 39Y8857 5743
IBM DPI 32a Line Cord (IEC 309 P+N+G) 40K9612 6502
IBM DPI 30a Line Cord (NEMA L6-30P) 40K9614 6500
IBM DPI Australian/NZ Line Cord 40K9617 6505
IBM DPI Korean Line Cord 40K9618 6506
The uninterruptible power supply designated by part number IBM UPS5000 HV includes the following
items:
One IBM UPS5000 HV with network management card
Accesory kit, containing the following items:
Front bezel
Serial cable (5m, 15 ft)
Network Management Card console cable (2 m, 6 ft)
Temperature sensor AP9335T on a 4 meter (13 ft) cable
Left and right rack mount rails
Miscellaneous Hardware Kit, containing the following items:
Miscellaneous hardware
Rack mounting hardware
Documentation Kit, containing the following items:
Warranty flyer
The publication IBM UPS5000 HV Quick Installation Guide
Important Notices flyer
Documentation CD
Software CD, which contains PowerChute Business Edition, PowerChute Network Shutdown,
and MIB files
IBM UPS5000 HV Uninterruptible Power Supply for IBM System x 2

Note: The uninterruptible power supply does not ship with any line cords. These must be ordered
separately.
Figure 2 shows three of the four available line cords as listed in Table 1.
Figure 2. Line cords (l-r): Australian/NZ Line Cord, Korean Line Cord, 30a Line Cord (NEMA L6-30P)
Features
IBM UPS5000 HV Uninterruptible Power Supply for IBM System x 3

Features
The IBM UPS5000 HV uninterruptible power supply includes the following features and capabilities:
High efficiency 5KVA (4.5 kW) UPS for increased rack power density.
Occupies only 3U of vertical rack space.
Eight C13 and two C19 receptacles with 20A circuit breaker protection.
Requires a 200 V to 240 V, 30-32 A single-phase circuit.
Advanced technology Double Conversion operation providing protection from four more power
failures than typical interactive UPS technology.
Bimodal operation provides 97% efficiency when Double Conversion protection not required.
Hot swap battery capability increases availability.
Optional Online Battery Packs for additional runtime capacity. With four external battery packs, the
UPS can supply up to 75 minutes of run time at full load. Up to 10 external battery packs can be
attached to the UPS.
A suite of easy-to-use management tools.
Network Management Card provides standard serial and Ethernet (10/100 MBps) communications
as well as connections for environmental management. A temperature sensor on a 13 foot cable is
supplied with the UPS. Additional sensors can be purchased from APC using part number AP9335T.
Emergency Power Off option to remotely power off UPS unit to prevent battery operation during
power failure.
Load: Up to 5000VA or up to 4500W.
Physical specifications
Height: 130 mm (5.1 in)
Width: 483 mm (19.0 in)
Depth: 660 mm (26.0 in)
Weight: 59 kg (130 lb)
Operating environment
IBM UPS5000 HV Uninterruptible Power Supply for IBM System x 4

Operating environment
The IBM UPS5000 HV uninterruptible power supply is supported in the following environment:
Temperature:
Operation: 0 to 40 °C (32 to 104 °F)
Storage: -15° to 30° C (5° to 86° F) - charge the UPS battery every six months
Storage: 30° to 45° C (86° to 113° F) - charge the UPS battery every three months
Relative humidity: 5 to 95%
Maximum altitude:
Operation: 3,000 m (10,000 ft)
Storage: 15,000 m (50,000 ft)
Warranty
The IBM UPS5000 HV uninterruptible power supply has a three-year limited warranty.
Supported rack installation
The IBM UPS5000 HV uninterruptible power supply requires 3 U of rack space in one of the following rack
cabinets:
IBM 42U Enterprise rack
IBM S2 42 U Dynamic rack
IBM S2 25 U rack
IBM S2 42 U rack
IBM 11U Office Enablement kit
Front panel controls
IBM UPS5000 HV Uninterruptible Power Supply for IBM System x 5

Front panel controls
Figure 3 shows the front panel of the UPS 5000VA HV uninterruptible power supply.
Figure 3. Front panel
The callouts in Figure 3 correspond to the following functions:
1. Online indicator
2. On battery indicator
3. Battery bypass indicator
4. Overload indicator
5. Fault indicator
6. Replace battery indicator
7. Load on the uninterruptible power supply indicator
8. Power off button
9. Power on / Test button
10. Battery charge level / Diagnostic utility voltage indicator
Rear panel
Figure 4 shows the rear panel of the UPS 5000VA HV uninterruptible power supply.
IBM UPS5000 HV Uninterruptible Power Supply for IBM System x 6

Figure 4. Rear panel of the UPS5000 HV uninterruptible power supply
The callouts in Figure 4 correspond to the following components:
1. Outlets - eight C13 and two C19 receptacles
2. Output circuit breakers
3. Transient voltage surge-suppression (TVSS) screw
4. Serial port (use the supplied serial cable; standard cables are incompatible)
5. Bypass switch
6. Emergency Power Off (EPO) terminal
7. Network management card
8. Ethernet Link LED
9. Ethernet Status LED
10. Network management card reset
11. Ethernet port
12. Environmental sensor connectors
13. USB connector (reserved for future use)
14. Console connector
15. Connectors for optional Online Battery Packs for extended run time (remove the metal cover first)
16. Input fuse
17. Input power connector
IBM UPS5000 HV Uninterruptible Power Supply for IBM System x 7

Figure 5 shows a photo of the rear of the UPS5000 HV uninterruptible power supply.
Figure 5. Rear panel of the UPS5000 HV uninterruptible power supply
IBM UPS 3U Online Battery Pack
The 3U Online Battery Pack is a 3U rack-mounted device that contains additional batteries. Up to 10 can
be connected to the UPS5000 HV to provide longer uptime when running on battery power. Figure 6 and
Figure 7 show the front and rear of the 3U Online Battery Pack.
Figure 6. IBM 3U Online Battery Pack front
Figure 7. IBM 3U Online Battery Pack rear (green/yellow ground wire not shown)
Figure 8 shows the UPS connected to two 3U Online Battery Packs. The units are connected together
using the battery connectors shown in Figure 7 plus a green/yellow ground wire.
IBM UPS5000 HV Uninterruptible Power Supply for IBM System x 8

Figure 8. IBM UPS5000 HV uninterruptible power supply with two 3U Online Battery Packs
Battery run times and recharge times
Table 2 lists the approximate run times for the uninterruptible power supply when operating on battery
power. The run times vary depending on the load attached to the UPS. The table also lists the run times
when one, two, three, or four 3U Online Battery Packs (OBP) are attached.
Table 2. Run times when running on battery
IBM UPS5000 HV Uninterruptible Power Supply for IBM System x 9

Load UPS5000 battery
(hours:minutes)
With 1 OBP
(hours:minutes)
With 2 OBPs
(hours:minutes)
With 3 OBPs
(hours:minutes)
With 4 OBPs
(hours:minutes)
50 W 6:49 18:03 31:32 45:33 59:56
100 W 4:50 12:51 22:29 32:30 42:46
200 W 3:00 8:03 14:06 20:23 26:50
300 W 2:09 5:47 10:10 14:42 19:22
400 W 1:39 4:30 7:54 11:26 15:04
500 W 1:20 3:39 6:26 9:19 12:17
600 W 1:07 3:04 5:24 7:50 10:20
700 W 0:57 2:38 4:39 6:45 8:54
800 W 0:50 2:18 4:04 5:55 7:48
900 W 0:44 2:02 3:37 5:15 6:56
1000 W 0:39 1:50 3:15 4:43 6:14
1200 W 0:32 1:30 2:41 3:55 5:11
1400 W 0:26 1:16 2:17 3:20 4:25
1600 W 0:22 1:06 1:59 2:54 3:50
1800 W 0:19 0:58 1:45 2:33 3:23
2000 W 0:17 0:52 1:33 2:17 3:01
2500 W 0:12 0:40 1:13 1:47 2:22
3000 W 0:09 0:32 1:00 1:28 1:57
3400 W 0:07 0:25 0:50 1:12 1:40
4000 W 0:06 0:23 0:43 1:00 1:25
4500 W 0:05 0:20 0:38 0:54 1:15
Table 3 lists the number of hours needed to recharge the IBM UPS5000 HV uninterruptible power supply
and optional Online Battery Packs.
Table 3. Recharge times
UPS5000 battery With 1 OBP With 2 OBPs With 3 OBPs With 4 OBPs
Recharge time 3 hours 9 hours 15 hours 21 hours 27 hours
