Lenovo Smart 750xla User manual

Lenovo®qualiﬁed ThinkServer®

Ready for the ThinkServer TD230,

TS130 and TS430.

and Mac OS X. Supports detailed monitoring of equipment

load levels, self-test data and utility power conditions via all 3

network interfaces at once. Includes PowerAlert monitoring

soware and complete cabling. Features 3-stage load current

monitoring and battery charge status, plus line power and

voltage boost/cut status LEDs. Dataline surge suppression

protects dialup, DSL or network Ethernet connection. Audible

alarm. Self-test. Field replaceable, hot-swappable internal

batteries and external battery packs. Attractive all-black color

scheme. 2-year warranty and $250,000 connected equipment

insurance; extended warranty and service contracts available.

Applications

Ideal for the protection of network ﬁle servers, remote

unattended servers and web servers.

Package Includes

• SMART750XLaUPSSystem

• PowerAlertSowareCD-Rom

• USBandserialcabling

• Usermanualwithwarrantyinformation

Features

• SmartProline-interactiveUPSsystemisidealforvoice,

data, medical and industrial networking applications

• Largeinternalbatteriesoer27minutesathalfload

 (375VA/250W)and10minutesatfullload(750VA/500W)

Highlights

• 750VAline-interactive,extended-runtowerUPS

for networks

• MaintainsuserselectableSineWave120,110or100V

nominal output

• SimultaneouscommunicationsviaSNMPWEBCARDslot,

 DB9serialandHIDenabledUSBports

• FreePowerAlertUPSmonitoringsowareandcabling

• Input:NEMA5-15P(120V,15A)/Output:8NEMA5-15R(120V)

• 2-yearproductwarranty/$250,000UltimateLifetime

 Insurance(U.S.,PuertoRicoandCanadaonly)

Description

750VA line-interactive tower UPS system for server,

networking and telecommunications equipment. Compatible

with120V,110Vor100Vnominalvoltageat60Hz.Switches

to battery-derived AC output during power failures and

extremevoltagevariations.Line-interactiveAutomaticVoltage

Regulation(AVR)providesvoltageboostduringbrownoutsand

voltage cut during overvoltages to maintain regulated output

during brownouts and overvoltages. Includes NEMA 5-15P

inputplugand8NEMA5-15Routputreceptacles.Network-

gradeACsurgeandnoisesuppression.Networkmanagement

viaUSBport,DB9serialportandSNMPWEBCARDslot.HID-

compliant USB interface enables integration with built-in

powermanagementandautoshutdownfeaturesofWindows®

TRIPP LITE SMARTPRO

BATTERY BACKUP

Tripp Lite SmartPro

Interactive Sine Wave

Tower UPS System

(P/N 0B33107)

For more information

www.lenovo.com/thinkserver

Output Input

OutputVoltAmpCapacity(VA)

OutputWattCapacity(watts)

NominalOutputVoltage(s)

Supported

FrequencyCompatibility

OutputVoltageRegulation

(linemode)

Built-inUPSOutput

Receptacles

750

500

100V,110V,120V

60Hz

-13%,+15%

85-15Routlet(s)

Ratedinputcurrent

(atmaximumload)

Nominalinputvoltage(s)

supported

UPSinputconnectiontype

UPSinputcordlength()

Recommendedelectrical

service

Voltagecompatibility(VAC)

5.4A(120V),5.8A(110V),

6.4A(100V)

100VAC,110VAC,120VAC

5-15P

6

120V,15A

120

Battery Voltage Regulation

Fullloadruntime(minutes)

Halfloadruntime(minutes)

Expandable battery runtime

External battery pack

compatibility

DCSystemVoltage(VDC)

Batteryrechargerate

(includedbatteries)

Replacementbattery

cartridge(internalUPS

batteryreplacement)

Batteryaccess

10minutes(500W)

27minutes(250W)

Runtimeisexpandablewith

BP24V28-2U(limit1)or

BP24V70-3U(multi-pack

compatible)

BP24V15RT2U

Less than 4.5 hours from

10%to90%

RBC24-SLT

Supports battery access

and hot-swap replacement

without powering connected

equipmento

Voltageregulation

description

Overvoltage correction

Undervoltagecorrection

AutomaticVoltage

Regulation(AVR)circuits

maintain clean, regulated

computer-grade120,

110,100Vnominaloutput,

without using battery

power, during brownouts

95V(120V),87V(110V),

83V(100V)

Inputvoltagesbetween127V

and145V(120V),116and

133(110V),111and121

(100V)arereducedby12%

Voltageboostof14%

applieswheninputis95

–108(120V),87–99

(110V),83–90(100V)

LEDs Alarms and Switches Surge/Noise Suppression

LED Indicators

Alarms

Switches

9LEDsindicatelinepower,

batterypower,AVR,

overload and replace battery

status—with a 3-LED level

meter for load and battery

charge level

Audible alarm warns of

power failure condition

Includes two pushbutton

switchesforon/opower

control and self-test/

alarm cancel functions.

Also includes two dip switch

controls for setting the

nominal voltage

UPSACsuppressionjoule

rating

EMI/RFIACnoise

suppression

ACsuppressionresponsetime

Dataline suppression

570J

Yes

Instantaneous

Includes8-wireRJ45jack;

pins1,2,3and6provide

10baseTEthernetline

surge suppression with

7.5Vclamping;pins4and

5 provide single-line tel/

DSL line surge suppression

startingat260V

SPECIFICATIONS

• Line-interactiveAutomaticVoltageRegulation(AVR)

 maintainsselectable120V,110Vor100Vnominaloutput

 duringbrownoutsaslowas83Vandovervoltagesto145V

• Networkinterfacessupportsimultaneouscommunications

 viabuilt-inUSBport,DB9serialportandSNMPWEBCARDslot

• HID-compliantUSBinterfaceenablesintegrationwith

built-in power management and auto shutdown features of

 Windows®and Mac OS X

• IncludedPowerAlertUPSmonitoringsowaresupports

safe unattended shutdown, monitoring and control via local

connected servers, plus any number of additional servers

over IP

• UPSinterfacesupportson-battery,low-battery, 

 power-restored,AC-voltage,DC-voltage,outputcurrent

monitoring, battery charge current, battery capacity, timed

 invertershuto,activateself-testandoutputpower

control

• NEMA5-15Pinputplug;8battery-supportedNEMA5-15R

output receptacles

• Datalinesurgesuppressionprotectsdialup,DSLor

network Ethernet connection

• FrontpanelLEDsoercurrentmonitoring,voltage 

regulation and battery charge level information

• UPSshipsfullyassembledinfullcompliancewithDOT

regulations; no time-consuming connection of internal

batteries by user required

• 2-yearwarranty;$250,000UltimateLifetimeInsurance

 (U.S.andCanadaonly)

MMG_US_DS_Q2_12_24709

Physical

Installation form factors

supported with included

accessories

Primary form factor

UPS/PowerModule

dimensions in primary form

factor (heightxwidthxdepth/

inches)

UPS/PowerModuledimensions

in primary form factor (heightx

widthxdepth/cm)

UPS/PowerModuleweight(lb)

Tower

10.1x6.7x13.8

25.7x17x35.1

33.9

UPS/PowerModuleweight(kg)

UPSShippingdimensions

(heightxwidthxdepth/inches)

UPSShippingdimensions

(heightxwidthxdepth/cm)

Shippingweight(lb)

Shippingweight(kg)

UPShousingmaterial

Coolingmethod

15.4

13x10x23.8

33x25.4x60.3

16.8

Steel

Fan

Environmental Communications

Operating temperature range

Storage temperature range

Relativehumidity

ACmodeBTU/hr(fullload)

BatterymodeBTU/hr

(fullload)

Audible noise

+32to+1040F/0to+400C

+5to+1220F/-15to+500C

0to95%,non-condensing

70.8

300

AudibleNoise<50dBAat

FrontSide1Meter

Communicationsinterface

WatchDogcompatibility

SNMPcompatibility

Soware and cabling

included

USB;DB9Serial;Slotfor

SNMP/Webinterface

CompatiblewithTrippLite’s

WatchDogSowareto

restore operation to locked

equipment through so

reboot of application/OS or

hardpowero/onreboot

of connected equipment;

ideal for unattended kiosk

applications

SNMPadapteraccessory#

SNMPWEBCARD

IncludesPowerAlertUPS

monitoring soware for

all common network and

stand-alone operating

systems. Ships with 2

cables,1USBand1DB9

Line/Battery Transfer Special Features

Transfertime

Low voltage transfer to

batterypower(setpoint)

Highvoltagetransferto

batterypower(setpoint)

4–8milliseconds

95V(120V),87V(110V),

83V(100V)

145V(120V),133V(110V),

121V(100V)

Coldstart

(startup in battery mode

duringapowerfailure)

Appearance

Coldstartoperation

supported

Attractive all-black tower

UPS

Certiﬁcations Warranty

Certications

TestedtoUL1778(U.S.),

CSA(Canada),RoHS

Compliant,ClassB(Emissions),

NOM(Mexico),FCCPart

68/IndustryCanada

(telecommunications)

ProductWarrantyPeriod

(U.S.,CanadaandPuerto

Rico)ConnectedEquipment

Insurance(U.S.,Canadaand

PuertoRico)

OptionalCoverage

2-year limited warranty

$250,000UltimateLifetime

Insurance

3 – 5 year warranties,

plus next day and on-site

warranty coverage

available for select

opportunities.Contact

TrippLiteforadditional

information
