LevelOne WAP-6012 User manual

2
300Mbps N_Max Wireless
Gigabit PoE Access Point WAP-6012
LevelOne’s WAP-6012 300Mbps N_Max Wireless
Gigabit PoE Access Point is designed specically
for business-class environments such as SOHO
or enterprises to provide security for network
administrators.
Ultimate Wireless Performance
The WAP-6012 allows network administrators to
deploy a highly manageable, robust wireless network.
For advanced installations, this new high-speed Access
Point has integrated 802.3af Power over Ethernet (PoE)
support, allowing installation of this device in areas
where power outlets are not readily available.
High Security
The WAP-6012 provides the latest in wireless security
technologies by supporting both personal and
enterprise versions of WPA and WPA2 (802.11i) with
support for a RADIUS (802.11x) server backend. It
includes support for up to 8 VLANs for implementing
multiple SSIDs to further help segment users on the
network. It also includes a wireless client isolation
mechanism, which limits direct client-to-client
communication.
Multiple Operation Modes
The WAP-6012 is a feature-rich 11n access point
that supports AP, Bridge and Repeater modes for
customized wireless deployments. In Bridge mode,
the WAP-6012 acts as a wireless bridge to connect
separate wireless networks into one. This provides
more users with greater access to network resources.
In Repeater mode, the WAP-6012 allows extended
coverage and greater signal strength for greatly
improved distance coverage of the Wireless network
(WLAN).
Key Features
- 3 antennas with 2T/3R MIMO technology for Wireless
Data Rates of up to 300Mbps
- Compatible with IEEE802.11b/g/n wireless standards
- Supports 8 multi-SSIDs assignment for dierent
clients
- Provides 1 Gigabit Ethernet port (1000Mbps)
- 802.3af Power over Ethernet (PoE) for simple
deployment
- Supports AP, AP Client, Bridge and Repeater Modes
- Supports WEP, WPA, WPA2 and 802.1x for high
security
- Supports Wi-Fi Protected Setup (WPS)
- Supports SNMP(Simple Network Management
Protocol)
WGR-6012
300Mbps N_Max Wireless Gigabit
Router
Works Well With
1. LED Indicators
2. Power Port
3. PoE LAN Port
4. Reset Button
5. Detachable Antennas
6. Wall Mount Holes
GEP-0520
4 GE PoE Port + 1 GE Switch
H/W Version: 1
1 2 3 4 5 6

3
Wireless Bridges/Access Points
www.level1.com
I
one world_one brand_one level_
Technical Specication
LAN-Interface
1 x Auto-MDIX RJ-45 10/100/1000Mbps PoE port
Wireless Data Transfer Rate
Rx Sensitivity: 11n: 300Mbps@ -69dBm, 11g: 54Mbps@ -73dBm,
11b: 11Mbps@ -88dBm OFDM; 802.11b: CCK
(11Mbps, 5.5Mbps), DQPSK (2Mbps), DBPSK (1Mbps)
Operating Frequencies
802.11 g/n:2.412~2.4835(US,ETSI)
Operating Channels
Ch.1 ~ 11 USA
Ch.1 ~ 13 EU
Transmit Power@Normal Temp Range
3T x For FCC:
MAX. :22.5 dBm @11b mode
MAX. :20.5 dBm @11g mode
MAX.: 22.5dBm @11n mode
3T x For ETSI
MAX.: 18.5dBm @11b/g/n modes
Antenna
3 x 2 dBi detachable antennas
Operating Temperature
0 °C~ 40°C
Storage Temperature
-20°C~70°C
Power Adapter
DC 12V/1A
Wireless
Access point support
Roaming support
IEEE 802.11b/g/n compliance
Auto Sensing Open System / Share Key authentication
Wireless Channels Support
Automatic Wireless Channel Selection
Country Selection
Preamble Type: long or short support
RTS Threshold Adjustment
Fragmentation Threshold Adjustment
Beacon Interval Adjustment
8 x Multi-SSID assignment
802.11i pre-authentication
Short Slot time support
IEEE 802.11d
CTS-only & CTS/RTS protect mechanism support
WMM support
WPS support
Wireless isolation
Operation Mode
Common AP+PTMP/PTP
Universal Repeater
Universal Client
Rogue AP Detection
Security
WPA, WPA-PSK, WPA-PSK and WPA2-PSK, WPA/WPA2 (802.11i)
and Radius (802.1x)
EAP-MD5, EAP-TLS, EAP-TTLS, PEAP
RADIUS based MAC authentication
Block inter-wireless station communication
(wireless separation)
Block SSID broadcast
Management
Web based conguration
Congurable Web port
RADIUS Accounting
RADIUS-On feature
RADIUS Accounting update
Telnet/CLI
Syslog/internal Log
Access Control list
Editable Conguration le backup/Restore
Statistics support
SNMP v1/v2/v3
LLTD
Only wired users to be able to control
Auto conguration
Other Features
DHCP client
WINS client
Radius client
Enable/Disable wireless
Network Integrality Check
FTP client
Firmware Upgrade
HTTP/FTP network protocol download
Dimension (L x W x H)
165mm x 153mm x 33mm
Weight
320g

4
V1.0
Order Information WAP-6012: 300Mbps N_Max Wireless Gigabit PoE Access Point
Package Content WAP-6012
LAN Cable
Power Adapter
Quick Installation Guide
CD Manual
All mentioned brand names are registered trademarks and property of their owners. Technical specications are subject to change without notice.
© Copyright Digital Data Communications GmbH. All Rights Reserved.
Product Diagram
Internet
Modem
WAP-6012
WAP-6012
Router
PoE Switch
