A. Description of function
The vehicle is equipped wi h a sys em ha facili a es reverse parking manoeu-
vres by de ec ing obs acles ha could damage he vehicle. When reverse gear is
engaged, an audible beep signals ha he Lexus Parking Aid is ac ive. The de ec -
ed obs acle will be indica ed by an in ermi en beep, increasing in frequency
un il i becomes a con inuous one as he vehicle moves closer o he obs acle.
±30 cm
±120 cm
±200 cm
Caution
The dis ances men ioned are only a
guide, he shape of each de ec ion zone
can vary from vehicle o vehicle.
Infor ation
Please con ac your dealer for more
de ails abou he de ec ion zone of your
vehicle.
Caution
The de ec ion zone is always aken from he rear end of he bumper,
regardless a owing hi ch or spare wheel cover is ins alled. If applicable,
please ake he size of he spare wheel cover and owing hi ch in o
accoun .
=
Continuous signalling zone: his is he zone neares o he rear bumper. The
Lexus Parking Aid de ec s obs acles and emi s a con inuous beep, whe her or
no he vehicle is a a s ands ill.
=
Static zone: his is he in ermedia e zone. The Lexus Parking Aid de ec s obs a-
cles and emi s an in ermi en beep, whe her or no he vehicle is a a s ands ill.
=
Dyna ic zone: his is he mos dis an zone and also he wides . The Lexus
Parking Aid de ec s obs acles, bu only emi s an in ermi en beep if he dis ance
be ween he vehicle and he obs acle is diminishing.
Beeeeee......p
Beep Beep Beep
Beep

Lexus Parking Aid 04
ENG
No detection: in case he sys em is no able o de ec obs acles due o sensor
malfunc ioning, he sys em will genera e a con inuous in ermi en one wi h
long beeps and shor pauzes
Caution
Ensure ha you familiarise yourself wi h he sys em af er i has been fi ed
o your vehicle.
Caution
If he sensors are oo close o an obs acle, he sys em may no emi a
beep.
Notice
In case a owing hi ch is fi ed, a cancella ion swi ch can be ins alled as
well o allow emporarily cancella ion of he Lexus Parking Aid o avoid
false de ec ion of your railer during reversing.
B. Operating tips
1. General reco endations
Always remember ha while his device is a valid aid when reversing, i is he
driver who is ul ima ely responsible for assessing nearby obs acles. Always drive
wi h due care and cau ion in order o preven damage o persons or o proper y.
If you reverse a high speed he sensors will no be able o de ec obs acles in
ime.
2. Te porary alfunction
The Lexus Parking Aid may no opera e correc ly in he following si ua ions:
– where here is foreign ma er on he sensor (ice, snow, mud,...)
– if you are close o a radio communica ions an enna
– if you are approaching a source of ul rasonic waves (horn, mo orcycle
engine,...)
– if he road is bumpy
– if he sensor is covered
– if he vehicle is lis ing due o unequal load dis ribu ion
– in heavy rain or if wa er splashes on o he sensor
– if you ge oo close o an obs acle
– if he sensor is frozen.
3. Reduced sensing range
The sensing range may decrease in he following si ua ions:
– if he vehicle is parked for a long ime in ho sun or in cold wea her
– in case of objec s wi h low reflec ive proper ies
– if he de ec ion sensor is clogged wi h mud, snow or ice.

Lexus Parking Aid 05
ENG
4. No detection
Owing o heir low reflec ive proper ies, he sensors may no be able o de ec
he following objec s:
– very low, hin or poin ed objec s (wires, ropes, wire fences, e c.)
– objec s wi h high absorp ion proper ies (snow, co on, e c.)
– sharp angled objec s.
The sys em may no be able o de ec he lower par of cer ain designs of
bumper.
C. Operation procedure
1. S ar he engine.
Caution
Make sure he engine is running in order
o preven he ba ery from discharging.
2. Engage he shif lever o "R" (reverse) o
ac iva e he Lexus Parking Aid.
3. The sys em emi s a shor beep o confirm
ha i is working correc ly.
4. The sys em is now ready o de ec obs a-
cles.
Only if cancellation switch is installed (optional)
In case of using a railer, he cancella ion swi ch
has o be urned “off” o avoid false de ec ion
of he railer.
The cancella ion swi ch is ins alled in he runk
of he vehicle.
(A) “RED” = “OFF” = sensors no ac ive
(B) “BLACK” = “ON” = sensors ac ive
high beep
low beep
Beep Beep
Beep Beep
ON
high beep
low beep
Beep Beep
Beep Beep
R
high beep
high beep
low beep
low beep
BeepBeep
Beep Beep
BeepBeep
Beep Beep
Beep Beep
Beep Beep
B
A

Lexus Parking Aid 06
ENG
CAUTION
Always approach an obs acle slowly (a less han 5 km/h) and be ready o
press he brake pedal quickly.
CAUTION
When he signal changes from in ermi en beeps o a con inuous beep,
s op he vehicle immedia ely.
CAUTION
If he sensors are already oo close o an objec , hey may no be able o
de ec i .
D. Precautions
– Do no allow he sensor o be subjec ed o high impac .
– Do no use a powerful je spray on he sensors.

E. Troubleshooting
The flowchar shown below will assis you in de ermining whe her or no a mal-
func ion is in fac a sys em error. If he sys em s ill fails o opera e af er you have
carried ou he ins ruc ions in he flow char , please con ac your dealer.
1. The sensor is not working even though an obstacle is present
2. The buzzer is constantly ON or is e itting a continual fast inter ittent beep
3. The buzzer is e itting a continual inter ittent tone with long beeps and short
pauzes
There is a problem wi h he connec ion of he sensors, please con ac your dealer.
NO
NO
NO
Lexus Parking Aid 07
ENG
Is he igni ion swi ch “ON”? Turn on he igni ion swi ch.
Is he shif lever s ill in "R"
(reverse)?
Shif he lever o he "R" (reverse)
range.
YES
Is he cancella ion swi ch “ON”?
(if his swi ch is available) Turn on he cancella ion swi ch.
YES
Please consul your dealer.
YES
YES
Is he vehicle pulling a railer? Turn cancella ion swi ch o
“OFF” mode.
NO
YES
Is here any debris on he sens-
ing por ion of he sensor? Remove he debris.
NO YES
Are here any obs acles nearby? Remove he obs acle or move
he vehicle.
NO
Please consul your dealer.

Lexus Parking Aid 08
ENG
F. Specifications
Ra ed vol age: DC 12V
Opera ing vol age range: +9 ~ +16V
Curren consump ion: < 14mA (a 12V DC)
Opera ing empera ure range: -20 ~ +60°C
S orage empera ure range: -30 ~ +80°C
Transmission frequency: 40 kHz

Lexus Parking Aid 09
DE
A. Funktionsbeschreibung
Das Fahrzeug is mi einem Sys em ausges a e , welches das
Rückwär seinparken erleich er , indem es Hindernisse erkenn , die das Fahrzeug
beschädigen könn en. Sobald der Rückwär sgang eingeleg is , signalisier ein
Piep on, dass die Lexus Parking Aid ak iv is . Das erkann e Hindernis wird durch
einen un erbrochenen Piep on signalisier , dessen Frequenz zunimm , bis er zu
einem Dauer on wird, je näher sich das Fahrzeug auf das Hindernis zu beweg .
±30 cm
±120 cm
±200 cm
Achtung
Die Erkennungszone beginn immer am hin eren Ende des S oßfängers,
unabhängig davon, ob eine Anhängerkupplung oder eine
Reserveradabdeckung mon ier is . Sofern zu reffend bi e die Größe der
Reserveradabdeckung oder der Anhängerkupplung berücksich igen.
=
Dauersignalzone: diese Zone lieg unmi elbar hin er dem hin eren S oßfänger.
Die Lexus Parking Aid erkenn Hindernisse und erzeug einen Dauerpiep on, ob
das Fahrzeug s eh oder sich beweg .
=
Statische Zone: dies is die Zwischenzone. Die Lexus Parking Aid erkenn
Hindernisse und erzeug einen un erbrochenen Piep on, ob das Fahrzeug s eh
oder sich beweg .
=
Dyna ische Zone: dies is die am wei es en en fern e Zone und gleichzei ig die
brei es e. Die Lexus Parking Aid erkenn Hindernisse, erzeug aber nur einen
un erbrochenen Piep on, wenn der Abs and zwischen Fahrzeug und Hindernis
sich verringer .
Piieeeeeeee......p
Piep Piep Piep
Achtung
Die genann en En fernungen sind nur
Rich wer e, die Form jeder
Erkennungszone kann von Fahrzeug zu
Fahrzeug un erschiedlich sein.
Infor ation
Wei ere Einzelhei en über die
Erkennungszone Ihres Fahrzeug erfah-
ren Sie von Ihrem Händler.
Piep
