LG ARNU093SEL2 User manual

Date:
JobName/Location:
PONo.:
Architect:
Engr:
GC:
Rep:
For: File
A
pp
roval
Mech:
Resubmit
Other
(Company) (ProjectManager)
Tag#:
ARNU093SEL2
MultiV™WallMountedUnit
Btu/hIndoorUnit
ControlsFeatures:
•Autochangeover
(HeatRecoveryonly)
•Autooperaon
•Autoclean(coildry)
•Autorestart
•Childlock
•Dualthermistorcontrol
•Forcedoperaon
•Groupcontrol
•Hotstart
•Selfdiagnoscs
•Sleepmode
•Timer(on/off)
•Weeklyschedule
•Sodry(dehumidificaon)
•Autodirecon/swing(up/down)
•ManualDirection(left/right)
•Fanspeedcontrol
•Chaosswing(randomlouverswing)
•Chaoswind(randomfanspeed)
•Jetcool(fastcooling)
O
p
tionalAccessories:
LGElectronicsUSA,Inc.1000SylvanAve,EnglewoodCliffs,NJ07632/www.lg.com/us/
Forcontinualproductdevelopment,LGreservestherighttochangespecificationswithoutnotice. Page1of2VRF‐SB‐DB‐002‐US011H03
StandardFeatures:
•LimitedWarrantywithLGCerfiedInstallaon
•TwoYearFunconalPartsWarranty
UnitData:
RefrigerantType R410A
RefrigerantControl EEV
NetUnitWeight(lbs) 20
ShippingWeight(lbs) 25
Fan:
Type CrossFlow
Quantity 1
Motor/Drive BrushlessDigitallyControlled/Direct
AirflowRateH/M/L(CFM) 247/230/212
Enterin
g
MixedAir:
HeatingMin(°FDB) 59
WirelessHandheldRemoteController(PQWRHDF0)
7‐DayProgrammableController(PQRCUSA)
SimpleControllerwithMode(PQRCUCS0C)
SimpleControllerwithoutMode(PQRCFCS0C)
DryContactUnit(PQDSB1,PQDSBC)
Performance:
CoolingNominalTestConditions: HeatingNominalTestConditions:
Indoor: 80°FDB/67°FWB
Outdoor: 95°FDB
Indoor: 70°FDB
Outdoor: 47°FDB/43°FWB
HeatingCapacity(Btu/h)10,900
Electrical:
PowerSupply(V/Hz/Ø) 208‐230/60/1
RatedAmps(A)0.3
Pi
p
in
g
:
Refrigerant:
LiquidLine(in,OD) 1/4Flare
VaporLine(in,OD) 1/2Flare
Condensate:
PowerIn
p
ut¹
(
W
)
40
CondensateLine(in,OD) 5/8
TotalCoolingCapacity(Btu/h) 9,600
9,600
Notes:
FactoryInstalledPump No
CoolingMax²(°FWB) 76
SoundPressure³dB(A)(H/M/L) 39/35/25
PrimaryFilter WashablePre‐filter
SecondaryFilter Plasma
1.ThePowerInputisratedathighspeed.
2.SeeEngineeringManualforsensibleandlatentcapacies.
3.SoundPressurelevelsaretestedinananechoicchamberunderISOStandard1996.
4.Allcommunicaoncabletobeminimum18AWG,2‐conductor,stranded,shieldedandmust
complywithapplicablelocalandnationalcode.
5.Powerwiringcablesizemustcomplywiththeapplicablelocalandnaonalcode.
6.Thisunitcomeswithadrynitrogencharge.
7.Thisdataisrated0abovesealevel,with25ofrefrigerantlineperindoorunitanda0
leveldifferencebetweenoutdoorandindoorunits.Allcapacitiesarenetwithacombinationratio
between95–105%.
8.MustfollowinstallaoninstruconsintheapplicableLGinstallaonmanual.

ARNU093SEL2
MultiV™WallMountedUnit
JobName/Location:
Tag#:
Date:
PONo.:
Btu/hIndoorUnit
LGElectronicsUSA,Inc.1000SylvanAve,EnglewoodCliffs,NJ07632/www.lg.com/us/
Forcontinualproductdevelopment,LGreservestherighttochangespecificationswithoutnotice. Page2of2VRF‐SB‐DB‐002‐US011H03
9,600
Note‐Alldimensionshavea
toleranceof±0.25in.
