LG TP Series User manual

P/NO : MFL67655412
INSTALLATION MANUAL
4-WAY CEILING CASSETTE
AIR
CONDITIONER
www.lg.com
Please read this installation manual completely before installing the product.
Installation work must be performed in accordance with the national wiring
standards by authorized personnel only.
Please retain this installation manual for future reference after reading it
thoroughly.
Copyright © 2017 LG Electronics Inc. All Rights Reserved.
ESPAÑOL
PORTUGUÊS
ENGLISH
1,MFL67655412,영어 2017. 11. 9. 오전 11:23 페이지 1

2
ENGLISH
• Do not cool excessively indoors. This may be harmful for your health and may consume more
electricity.
• Block sunlight with blinds or curtains while you are operating the air conditioner.
• Keep doors or windows closed tightly while you are operating the air conditioner.
• Adjust the direction of the air flow vertically or horizontally to circulate indoor air.
• Speed up the fan to cool or warm indoor air quickly, in a short period of time.
• Open windows regularly for ventilation as the indoor air quality may deteriorate if the air condition-
er is used for many hours.
• Clean the air filter once every 2 weeks. Dust and impurities collected in the air filter may block the
air flow or weaken the cooling / dehumidifying functions.
For your records
Staple your receipt to this page in case you need it to prove the date of purchase or for warranty
purposes. Write the model number and the serial number here:
Model number :
Serial number :
You can find them on a label on the side of each unit.
Dealer’s name :
Date of purchase :
Here are some tips that will help you minimize the power consumption when you use the air
conditioner. You can use your air conditioner more efficiently by referring to the instructions
below:
TIPS FOR SAVING ENERGY
TIPS FOR SAVING ENERGY
1,MFL67655412,영어 2017. 11. 9. 오전 11:23 페이지 2

3
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.
Always comply with the following precautions to avoid dangerous situations and ensure peak
performance of your product
WARNING
It can result in serious injury or death when the directions are ignored
CAUTION
It can result in minor injury or product damage when the directions are ignored
WARNING
• Installation or repairs made by unqualified persons can result in hazards to you and others.
• Installation MUST conform with local building codes or, in the absence of local codes, with
the Nation Electrical Code NFPA 70/ANSI C1-1003 or current edition and Canadian Electrical
Code Part1 CSA C.22.1.
• The information contained in the manual is intended for use by a qualified service technician
familiar with safety procedures and equipped with the proper tools and test instruments.
• Failure to carefully read and follow all instructions in this manual can result in equipment mal-
function, property damage, personal injury and/or death.
Installation
• Do not use a defective or underrated circuit breaker. Use this appliance on a dedicated circuit.
- There is risk of fire or electric shock.
• For electrical work, contact the dealer, seller, a qualified electrician, or an Authorized Service Center.
- Do not disassemble or repair the product. There is risk of fire or electric shock.
• Always ground the product. - There is risk of fire or electric shock.
• Install the panel and the cover of control box securely. - There is risk of fire or electric shock.
• Always install a dedicated circuit and breaker. - Improper wiring or installation may cause fire or elec-
tric shock.
• Use the correctly rated breaker or fuse. - There is risk of fire or electric shock.
• Do not modify or extend the power cable. - There is risk of fire or electric shock.
• Do not install, remove, or re-install the unit by yourself (customer). - There is risk of fire, electric
shock, explosion, or injury.
• Be cautious when unpacking and installing the product. - Sharp edges could cause injury. Be espe-
cially careful of the case edges and the fins on the condenser and evaporator.
• For installation, always contact the dealer or an Authorized Service Center. - There is risk of fire,
electric shock, explosion, or injury.
• Do not install the product on a defective installation stand. - It may cause injury, accident, or damage
to the product.
• Be sure the installation area does not deteriorate with age. - If the base collapses, the air conditioner
could fall with it, causing property damage, product failure, and personal injury.
• Do not turn on the breaker or power under condition that front panel, cabinet, top cover, control box
cover are removed or opened. - Otherwise, it may cause fire, electric shock, explosion or death.
!
!
!
IMPORTANT SAFETY INSTRUCTIONS
1,MFL67655412,영어 2017. 11. 9. 오전 11:23 페이지 3

4
ENGLISH
• Use a vacuum pump or Inert (nitrogen) gas when doing leakage test or air purge. Do not compress
air or Oxygen and Do not use Flammable gases. Otherwise, it may cause fire or explosion. - There is
the risk of death, injury, fire or explosion.
Operation
• Do not let the air conditioner run for a long time when the humidity is very high and a door or a win-
dow is left open. - Moisture may condense and wet or damage furniture.
• Take care to ensure that power cable could not be pulled out or damaged during operation. - There
is risk of fire or electric shock.
• Do not place anything on the power cable. - There is risk of fire or electric shock.
• Do not plug or unplug the power supply plug during operation. - There is risk of fire or electric shock.
• Do not touch(operate) the product with wet hands. - There is risk of fire or electrical shock.
• Do not place a heater or other appliances near the power cable. - There is risk of fire and electric
shock.
• Do not allow water to run into electric parts. - There is risk of fire, failure of the product, or electric
shock.
• Do not store or use flammable gas or combustibles near the product. - There is risk of fire or failure
of product.
• Do not use the product in a tightly closed space for a long time. - Oxygen deficiency could occur.
• When flammable gas leaks, turn off the gas and open a window for ventilation before turn the prod-
uct on. - Do not use the telephone or turn switches on or off.
• There is risk of explosion or fire. If strange sounds, or small or smoke comes from product. Turn the
breaker off or disconnect the power supply cable. - There is risk of electric shock or fire.
• Stop operation and close the window in storm or hurricane. If possible, remove the product from the
window before the hurricane arrives. - There is risk of property damage, failure of product, or electric
shock.
• Do not open the inlet grill of the product during operation. (Do not touch the electrostatic filter, if the
unit is so equipped.) - There is risk of physical injury, electric shock, or product failure.
• When the product is soaked (flooded or submerged), contact an Authorized Service Center. - There
is risk of fire or electric shock.
• Be cautious that water could not enter the product. - There is risk of fire, electric shock, or product
damage.
• Ventilate the product from time to time when operating it together with a stove, etc. - There is risk
of fire or electric shock.
• Turn the main power off when cleaning or maintaining the product. - There is risk of electric shock.
• When the product is not be used for a long time, disconnect the power supply plug or turn off the
breaker. - There is risk of product damage or failure, or unintended operation.
• Take care to ensure that nobody could step on or fall onto the outdoor unit. - This could result in per-
sonal injury and product damage.
IMPORTANT SAFETY INSTRUCTIONS
1,MFL67655412,영어 2017. 11. 10. 오전 9:55 페이지 4

IMPORTANT SAFETY INSTRUCTIONS 5
ENGLISH
CAUTION
Installation
• Always check for gas (refrigerant) leakage after installation or repair of product. - Low refrigerant lev-
els may cause failure of product.
• Install the drain hose to ensure that water is drained away properly. - A bad connection may cause
water leakage.
• Keep level even when installing the product. - To avoid vibration or water leakage.
• Do not install the product where the noise or hot air from the outdoor unit could damage the neigh-
borhoods. - It may cause a problem for your neighbors.
• Use two or more people to lift and transport the product. - Avoid personal injury.
• Do not install the product where it will be exposed to sea wind (salt spray) directly. - It may cause
corrosion on the product. Corrosion, particularly on the condenser and evaporator fins, could cause
product malfunction or inefficient operation.
Operation
• Do not expose the skin directly to cool air for long periods of time. (Don't sit in the draft.) - This
could harm to your health.
• Do not use the product for special purposes, such as preserving foods, works of art, etc. It is a con-
sumer air conditioner, not a precision refrigeration system. - There is risk of damage or loss of prop-
erty.
• Do not block the inlet or outlet of air flow. - It may cause product failure.
• Use a soft cloth to clean. Do not use harsh detergents, solvents, etc. - There is risk of fire, electric
shock, or damage to the plastic parts of the product.
• Do not touch the metal parts of the product when removing the air filter. They are very sharp! -
There is risk of personal injury.
• Do not step on or put anyting on the product. (outdoor units) - There is risk of personal injury and fail-
ure of product.
• Always insert the filter securely. Clean the filter every two weeks or more often if necessary. - A
dirty filter reduces the efficiency of the air conditioner and could cause product malfunction or dam-
age.
• Do not insert hands or other objects through the air inlet or outlet while the product is operated. -
There are sharp and moving parts that could cause personal injury.
• Do not drink the water drained from the product. - It is not sanitary and could cause serious health
issues.
• Use a firm stool or ladder when cleaning or maintaining the product. - Be careful and avoid personal
injury.
• Replace the all batteries in the remote control with new ones of the same type. Do not mix old and
new batteries or different types of batteries. - There is risk of fire or explosion.
• Do not recharge or disassemble the batteries. Do not dispose of batteries in a fire. - They may burn
or explode.
• If the liquid from the batteries gets onto your skin or clothes, wash it well with clean water. Do not
use the remote if the batteries have leaked. - The chemicals in batteries could cause burns or other
health hazards.
• If you eat the liquid from the batteries, brush your teeth and see doctor. Do not use the remote if
the batteries have leaked. - The chemicals in batteries could cause burns or other health hazards.
!
1,MFL67655412,영어 2017. 11. 9. 오전 11:23 페이지 5

6TABLE OF CONTENTS
ENGLISH
2TIPS FOR SAVING
ENERGY
3IMPORTANT SAFETY
INSTRUCTIONS
7INSTALLATION PLACES
8THE INDOOR UNIT
INSTALLATION
9Indoor Unit Drain Piping
10 Wiring Connection
12 INSTALLATION OF DEC-
ORATIVE PANEL
(ACCESSORY)
14 TEST RUNNING
15 INSTALLATION
INSTRUCTIONS
15 Installer Setting - Setting Address of
Central Control
15 Installer Setting - Checking Address of
Central Control
16 Installer Setting -How to enter installer
setting mode
TABLE OF CONTENTS
1,MFL67655412,영어 2017. 11. 9. 오전 11:23 페이지 6

7
ENGLISH
INSTALLATION PLACES
INSTALLATION PLACES
- There should not be any heat source or steam near the unit.
- There should not be any obstacles to prevent the air circulation.
- A place where air circulation in the room will be good.
- A place where drainage can be easily obtained.
- A place where noise prevention is taken into consideration.
- Do not install the unit near the door way.
- Ensure the spaces indicated by arrows from the wall, ceiling, or other obstacles.
- The indoor unit must keep the maintenance space.
Unit : mm
Ceiling
Ceiling Board
Ceiling Board
300 or more
Above 250
1 000 or less
1 000
or more
500 or
more
500 or
more
300 or less
Floor
* Please use an annexed sheet or the corru-
gated cardboard on the bottom of packing
as installation sheet.
* When using the bottom sheet, please use it
after separating the installation sheet from
packing of the product floor by using a knife
etc as a picture below.
Annexed sheet
Or
Packing corrugated
cardboard on the
bottom
1,MFL67655412,영어 2017. 11. 9. 오전 11:23 페이지 7

8
ENGLISH
Level gauge
Ceiling
Ceiling board
Unit:mm
Unit:mm
875(Ceiling opening)
787(Hanging bolt)
684
(Hanging bolt)
671
875(Ceiling opening)
840 Unit size
840 Unit size
TQ/TR Series
TP/TN/TM Series
585~660
517
461
517
585~660
523
570
570
319
CAUTION
• This air-conditioner uses a drain pump.
• Install the unit horizontally using a level
gauge.
• During the installation, care should be
taken not to damage electric wires.
!
- Select and mark the position for fixing bolts
and piping hole.
- Decide the position for fixing bolts slightly
tilted to the drain direction after considering
the direction of drain hose.
- Drill the hole for anchor bolt on the wall.
NOTE
!
Avoid the following installation location.
1Such places as restaurants and kitchen
where considerable amount of oil steam
and flour is generated. These may cause
heat exchange efficiency reduction, or
water drops, drain pump mal-function. In
these cases, take the following actions;
- Make sure that ventilation fan is enough
to cover all noxious gases from this
place.
- Ensure enough distance from the cook-
ing room to install the air conditioner in
such a place where it may not suck oily
steam.
2Avoid installng air conditioner in such
places where cooking oil or iron powder is
generated.
3Avoid places where inflammable gas is
generated.
4Avoid place where noxious gas is generat-
ed.
5Avoid places near high frequency genera-
tors.
Use the ventilation fan
for smoke-collecting
hood with sufficient
capacity.
Cooking table
Air conditioner
Take enough
distance
THE INDOOR UNIT INSTALLATION
THE INDOOR UNIT INSTALLATION
1,MFL67655412,영어 2017. 11. 9. 오전 11:23 페이지 8

9
ENGLISH
THE INDOOR UNIT INSTALLATION
Set screw of
paper model (4 pieces)
Paper model
for installation
Ceiling
board
150 mm
Ceiling board
Ceiling
Flat washer for M10
(accessory)
Keep the length of the bolt
from the bracket to 40 mm
Open the ceiling board
along the outer edge of the
paper model
Flat washer for M10
(accessory)
Hanging bolt
(W3/8 or M10)
Nut
(W3/8 or M10)
Nut
(W3/8 or M10)
Spring washer
(M10)
Air Conditioner body
Keep the length of 15~18 mm
between the air conditioner
bottom surface and the ceiling
surface
Adjust the
same height
The following parts is option.
①Hanging Bolt - W 3/8 or M10
②Nut - W 3/8 or M10
③Spring Washer - M10
④Plate Washer - M10
Drill the piping hole on the wall slightly tilted to the outdoor side using a Ø 70 hole-core drill.
Wall
Indoor Outdoor
5~7 mm
CAUTION
Tighten the nut and bolt to prevent unit
falling.
!
Maintenance
drain port
Upward
routing
not allowed
Pipe clamp
Indoor unit
300 mm or less
Indoor Unit Drain Piping
- Drain piping must have down-slope (1/50 to
1/100): be sure not to provide up-and-down
slope to prevent reversal flow.
- During drain piping connection, be careful
not to exert extra force on the drain port on
the indoor unit.
- The outside diameter of the drain connection
on the indoor unit is 32 mm.
- Be sure to execute heat insulation on the
drain piping.
- Install the drain raising pipes at a right
angle to the indoor unit and no more than
300 mm from the unit.
Piping material: Polyvinyl chloride pipe VP-
25 and pipe fittings
1,MFL67655412,영어 2017. 11. 9. 오전 11:23 페이지 9

10
ENGLISH
700 mm or less
1 -1.5 m
Clamp metal(attached) Drain hose(attached)
Drain raising pipe
300 mm or less300 mm or less300 mm or less
Heat insulation material: Polyethylene
foam with thickness more than 8 mm.
Drain test
The air conditioner uses a drain pump to drain
water.
Use the following procedure to test the drain
pump operation:
- Connect the main drain pipe to the exterior
and leave it provisionally until the test comes
to an end.
- Feed water to the flexible drain hose and
check the piping for leakage.
- Be sure to check the drain pump for normal
operating and noise when electrical wiring is
complete.
- When the test is complete, connect the flexi-
ble drain hose to the drain port on the indoor
unit.
Feed water
Drain Pump
Drain pan
Flexible drain hose
(accessory)
Main
drain pipe
Glue the joint
Drain
port
Drain hose connection
Use the clip (accessory)
high humid atmosphere (dew point tempera-
ture: more than 23 °C), water drops are liable
to fall. In this case, add heat insulation mate-
rial according to the following procedure:
- Heat insulation material to be prepared...
Adiabatic EPDM or NBR with thickness 10 to
20 mm.
- Stick glass wool on all air conditioners that
are located in ceiling atmosphere.
HEAT INSULATION
- Use the heat insulation material for the
refrigerant piping which has an excellent
heat-resistance (over 120 °C).
- Precautions in high humidity circumstance:
This air conditioner has been tested accord-
ing to the "KS Standard Conditions with Mist"
and confirmed that there is not any default.
However, if it is operated for a long time in
Indoor
unit
Thermal insulator
(accessory)
Fastening band
(accessory)
Refrigerant
piping
Wiring Connection
- Open the control box cover and connect the
Remote controller cord and Indoor power
wires.
- Remove the control box cover for electrical
connection between the indoor and outdoor
unit. (Remove screws ¿)
- Use the cord clamper to fix the cord.
Remote
controller
cord
1
1
Connection
cord
between the
indoor unit and
the outdoor
unit
Control box cover
(On which the
Electric Wiring
Connection is put)
THE INDOOR UNIT INSTALLATION
1,MFL67655412,영어 2017. 11. 9. 오전 11:23 페이지 10

11
ENGLISH
THE INDOOR UNIT INSTALLATION
Precautions when laying power
wiring
Use round pressure terminals for connections
to the power terminal block.
When none are available, follow the instruc-
tions below.
- Do not connect wiring of different thickness-
es to the power terminal block. (Slack in the
power wiring may cause abnormal heat.)
- When connecting wiring which is the same
thickness, do as shown in the figure below.
CAUTION
The connecting cable connected to the
indoor and outdoor unit should be com-
plied with the following specifications
(This equipment shall be provided with a
cord set complying with the national regu-
lation).
!
CAUTION
The Power cord connected to the unit
should be selected according to the fol-
lowing specifications.
!
If the supply cord is damaged, it must be
replaced by a special cord or assembly
available from the manufacturer of its
service agent.
NORMAL
CROSS-SECTIONAL
AREA 0.75 mm
2
20 mm
35±5 mm
GN/YL
10*3 mm
Power wirer
Round pressure terminal
Connect same thickness
wiring to both sides.
It is forbidden to
connect two to one
side.
It is forbidden to
connect wiring of
different thicknesses.
- For wiring, use the designated power wire
and connect firmly, then secure to prevent
outside pressure being exerted on the termi-
nal block.
- Use an appropriate screwdriver for tightening
the terinal screws. A screwdriver with a
small head will strip the head and make prop-
er tighterning impossible.
- Over-tightening the terminal screws may
break them.
1,MFL67655412,영어 2017. 11. 9. 오전 11:23 페이지 11

INSTALLATION OF DECORATIVE PANEL(ACCESSORY)
The decorative panel has its installation
direction.
Before installing the decorative panel,
always remove the paper template.
1Remove the packing and take out air inlet
grille from front panel.
Front
grille
2Remove the Corner covers of the panel.
Coner
cover
3Fit the panel on the unit by inserting hooks
as shown in picture. 5Fit the corner covers.
4Insert two screws on diagonal corners of
panel. Do not tighten the bolts completely.
(The fixing screws are included in the
indoor unit box.)
Check the alignment of panel with the ceil-
ing. Height can be adjusted using hanging
bolts as shown in picture. Insert the other
two screws and tighten all screws com-
pletely.
Hook
clip
Hook
12
ENGLISH
INSTALLATION OF DECORATIVE PANEL(ACCESSORY)
1,MFL67655412,영어 2017. 11. 9. 오전 11:23 페이지 12

INSTALLATION OF DECORATIVE PANEL(ACCESSORY) 13
ENGLISH
6Open two screws of control panel cover.
Screw
7Connect one display connector and two
vane control connectors of front panel to
indoor unit PCB.
The position marking on PCB is as:
Display connector : CN-DISPLAY
Vane control connector: CN-VANE 1,2
8Close the cover for control box.
9Install the air inlet grille and Filter on the
panel.
CN-VANE 1,2 CN-DISPLAY
Air conditioner
unit
Decorative panel
Fit the insulator (this part) and
be careful for cool air leakage
Good example
Ceiling
board
Ceiling
board
Decorative
panel
Air Cool air leakage
(no good)
Bad example Air conditioner unit
CAUTION
Install certainly the decorative panel.
Cool air leakage causes sweating. 
Water drops fall.
!
1,MFL67655412,영어 2017. 11. 9. 오전 11:23 페이지 13

14 TEST RUNNING
ENGLISH
TEST RUNNING
PRECAUTIONS IN TEST RUN
- The initial power supply must provide at least
90 % of the rated voltage.
Otherwise, the air conditioner should not be
operated.
Connection of power supply
- Connect the power supply cord to the inde-
pendent power supply.
Circuit breaker is required.
- Operate the unit for 15 minutes or more.
CHECK THE FOLLOWING ITEMS WHEN
INSTALLATION IS COMPLETED
- After completing work, be sure to measure
and record trial run properties, and store
measured data, etc.
- Measuring items are room temperature, out-
side temperature, suction temperature, blow
out temperature, wind velocity, wind vol-
ume, voltage, current, presence of abnormal
vibration and noise, operating pressure, pip-
ing temperature, compressive pressure.
- As to the structure and appearance, check
following items.
* Is the circulation of air adequate?
* Is the draining smooth?
* Is the heat insulation complete
(refrigerant and drain piping)?
* Is there any leakage of refrigerant?
* Is the remote controller switch operated?
* Is there any faulty wiring?
* Are not terminal screws loosened?
M4......118 N.cm{12 kgf.cm}
M5......196 N.cm{20 kgf.cm}
M6......245 N.cm{25 kgf.cm}
M8......588 N.cm{60 kgf.cm}
- To cancel the test run, press any button.
CAUTION
• For test run, carry out the cooling opera-
tion firstly even during heating season.
If heating operation is carried out firstly,
it leads to the trouble of compressor.
Then attention must be paid.
• Carry out the test run more than 5 min-
utes without fail.
(Test run will be cancelled 18 minutes
later automatically)
!
Evaluation of the performance
- Measure the temperature of the intake and
discharge air.
- Ensure the difference between the intake
temperature and the discharge one is more
than 8 °C (Cooling) or reversely (Heating).
Thermometer
1,MFL67655412,영어 2017. 11. 9. 오전 11:23 페이지 14

INSTALLATION INSTRUCTIONS 15
ENGLISH
Installer Setting - Checking Address of Central Control
With the MODE button pressed, press the RESET button.
1
With the PLASMA button pressed, press the RESET button.
1
Press the ON/OFF button toward the indoor unit 1 time, and the indoor unit will
display the set address in the display window.
- The address display time and method can differ by the indoor unit type.
2
Reset the remote controller to use the general operation mode.
3
By using the TEMPERATURE SETTING button, set the indoor unit address.
- Setting range : 00 ~ FF
2
After setting the address, press the ON/OFF
button toward the indoor unit 1 time.
3
The indoor unit will display the set address to complete the address set-
ting.
- The address display time and method can differ by the indoor uint type.
Reset the remote controller to use the general operation mode.
4
5
Group No.
Indoor Unit No.
INSTALLATION INSTRUCTIONS
Installer Setting - Setting Address of Central Control
1,MFL67655412,영어 2017. 11. 9. 오전 11:23 페이지 15

16 INSTALLATION INSTRUCTIONS
ENGLISH
Installer Setting -How to enter installer setting mode
CAUTION
Installer setting mode is to set the detail function of the remote controller.
If the installer setting mode is not set correctly, it can cause problems to the product, user
injury or property damage. This must be set by an certificated installer, and any installation or
change that is carried out by a non-certificated person should be responsible for the results.
In this case, free service cannot be provided.
!
With the FAN SPEED button pressed, press the RESET button.
1
By using the TEMPERATURE SETTING button, set function code and
setting value. (Please refer the Installer Setting Code Table.)
2
Press the ON/OFF button toward the indoor unit 1 time.
3
Reset the remote controller to use the general operation mode.
4
Refer to the Installer Setting Code Table on the next page.
Function Code
Setting Code
1,MFL67655412,영어 2017. 11. 9. 오전 11:23 페이지 16

INSTALLATION INSTRUCTIONS 17
ENGLISH
Installer Setting Code Table
Mode Override
This Function is only for Non-Auto Changeover H/P model.
Ceiling Height Selection
Indoor unit connected to wired remote controller operate as wired remote controller setting.
Group Control
This function is only for group control. Please don’t set this function in case of non-group control.
After setting Group Control of the product, turn off the power then turn it back on after 1 minute.
Auxiliary heater
This function is only applied to models with Auxiliary Heater function being activated.
No. Function Function
Code Setting Value Remote Controller LCD
0 Mode Override 00 : Set to Master
1 : Set to Slave
1Ceiling Height
Selection 1
1 : Standard
2 : Low
3 : High
4 : Super High
2
Group Control 2
0 : Set to Master
1 : Set to Slave
2 : Check Master/Slave
Auxiliary heater 2
3 : Set to Auxiliary heater
4 : Cancel Auxiliary heater
5 : Check Auxiliary heater Installation
00
01
11
12
13
14
20
21
22
23
24
25
1,MFL67655412,영어 2017. 11. 9. 오전 11:23 페이지 17

18
ENGLISH
1,MFL67655412,영어 2017. 11. 9. 오전 11:23 페이지 18

LG Electronics México, S.A de C.V
Sor Juana lnés de la Cruz No. 555
Col. San Lorenzo Industrial
Tlalnepantla de Baz Estado de México C.P. 54033
Tel. [phone]
Página web http://www.lg.com.mx
1. Não ê recomendável o descarte de. pilhas, baterias em lixo comum.
Após o uso, estes itens devem ser descartados de forma adequada, sob pena de
ocasionarem danos ao meio ambiente e à saúde humana.
2. A LG criou o Programa Coleta Inteligente, para facilitar e viabilizar o descarte ade-
quado de parelhos celulares, pilhas e baterias.
3. Através do Programa Coleta Inteligente, a LG disponíbiliza pontos de coleta em
localidades diversas, incluindo assistências técnicas autorizadas da LG Electron-
ics. Para mais informações visite o site www.lge.com/br/coleta-seletivaou contate
nosso SAC através do número 4004-5400 (Capitais e Regiòs metropolitanas) ou
0800-707-5454 (demais localidades).
1,MFL67655412,영어 2017. 11. 9. 오전 11:23 페이지 100
