LG TS-C092YDA0 User manual

Room Air Conditioner
SVC MANUAL(Exploded View)
MODEL : TS-C092YDA0
CAUTION
Before Servicing the unit, read the safety precautions in General SVC manual.
Only for authorized service personnel.
http://biz.lgservice.com

2Room Air Conditioner
1. Specification
Note:
O : Applied, - : No relation
* For circuit breaker rating, please conform to local standards wherever necessary.
Some of functions are slightly different depending upon models.
The specification may be subject to change without prior notice for purpose of
improvement.
TS-C092YDA0
2.67
9,101
-
-
Power Input Cooling/Heating 910/-
Running Current Cooling/Heating 4.1/-
Starting Current Cooling/Heating 26/-
2.93
10.00
-
1/230/60
98.5
Indoor,Max 6.73
Outdoor,Max 18
1.1
Indoor,H/M/L 39
Outdoor,Max 49
R22, 550(22.92)
20(0.22)
Rotary(Non Tropical)
QK134KBL
PSC
SUNISO 4GSI
Oil Charge
280 cc
MRA98996-12026
Cross Flow Fan
Motor Output 7.7
Propeller
AC Induction
Motor Output 18
10
3*0.75
3*0.75*5.8m
Liquid Side 6.35(1/4)
Gas Side 9.52(3/8)
Drain Hose O.D , I.D 21.5,16(0.85,0.63)
840*270*166
33.1*10.62*6.54
575*520*260
22.6*20.5*10.2
Indoor 7(-)
Outdoor 25(-)
7.5
Tool Code(Chassis) SY + UA
Models
Cooling Capacity
(Min∼Rating∼Max)
kW
Btu/h
W
A
Heating Capacity
(Min∼Rating∼Max)
kW
Btu/h
A
EER
W/W
Btu/h.W
COP
W/W
Power Supply
Φ/ V / Hz
Power Factor
%
Air Flow Rate
㎥/min(cfm)
㎥/min(cfm)
Moisture Removal
l/h
Sound Level
dB(A)+3
dB(A)+3
Refrigerant & Charge(at 7.5m)
g(oz)
Additional Refrigerant Charge
g/m(oz/ft)
Fan(Indoor)
Type
W
Compressor
Type
Model
Motor Type
Oil Type
cc
O.L.P Name
Fan(outdoor)
Type
Motor Type
W
Circuit Breaker*
A
Power Supply Cable
No.*㎟
Power and Transmission Cable
No.*㎟+No.*㎟
Piping
Connections
mm(in)
mm(in)
mm(in)
Dimension
Indoor(W*H*D)
mm
inch
Outdoor(W*H*D)
mm
m(ft)
inch
Net Weight
kg(lbs)
kg(lbs)
Max. Piping Length
Indoor + Outdoor
Thermistor
-
○
-
-
3/4
Auto
Manual
Wireless Simple
18 ∼30
-
-
-
○
7h, On/Off
○
○
3
-
-
○
-
Temperature Control
Plasma Filter
Prefilter(washable/anti-fungus)
Cooling
Heating
Auto Clean
Airflow Direction Control(up&down)
Airflow Direction Control(left&right)
CHAOS Wind(Auto Wind)
Steps, Fan/Cool/Heat
Functions
WIND
Sleep Operation
Soft Dry Operation
Self Diagnosis
Timer
Auto Operation (Micom Control)
Auto Changeover (Micom Control)
Remocon Type
Setting Temperature
Range
Hot Start
Jet Cool
Restart Delay(minute)
Deice Control(Defrost)

2. Piping Diagrams
Service Manual 3
tinUroodtuOtinUroodnI
Heat
Exchanger
(Evaporator)
Heat
Exchanger
(Condenser)
Capillary Tube
Compressor
Accumulator
Gas Side
3-Way Valve
2-Way Valve
Liquid Side
Cooling
High Pressure S/W
Th1
Th2
rotcennoCBCPnoitpircseD.COL
Th1 Thermistor for indoor air temperature CN-TH1
Th2 Thermistor for evaporating temperature
TINUROODTUOTINUROODNI
HEAT
EXCHANGE
(EVAPORATOR)
HEAT
EXCHANGE
(CONDENSER)
COMPRESSOR
ACCUMU
LATOR
GAS SIDE
3-WAY VALVE
LIQUID SIDE
3-WAY VALVE
CAPILLARY TUBE
CHECK VALVE
(Heating Model only)
COOLING
HEATING
REVERSING
VALVE
(Heating Model Only)
(2) Cooling & Heating Models
(1) Cooling

4 Room Air Conditioner
3. Wiring Diagrams
CN-MOTOR
CN-N2
CN-N1
FUSE
RY-COMP4
CN-U/D
CN-DISP2
CN-HVB
RY-COMP3
3854A23009
BR
BL
GN
/
YL
1(L)2(N) 3
GN
/
YL
BR
BL
(1)Indoor Unit
TS-C092YDA0

Capacitor
Terminal Block
(1)Outdoor Unit
YELLOW
RED
CAPACITOR
HCF
BLUE
RED
BLUE
BLUE
C
S
R
YELLOW
OVERLOAD
PROTECT
2(N)
BLUE
/GREEN
BLUE
BROWN BROWN
1(L)
THE UNIT INDOOR
OUTDOOR DIAGRAM WIRING
TERMINAL BLOCK
EBY36312302
FAN
TS-C092YDA0
Service Manual 5

Exploded View
Exploded View
6 Room Air Conditioner
1. Indoor Unit
346810
146811
263230
249941
264110
131410
359011
342800
147581-1
268712
135311
135316
267110
249951
733010
135314
152302
35211B
135516
W0CZZ
352150
354210
135301
354212
W6640
268711
W0FZZ
435301 147582-1
147582-2
135511

P/NO : MFL37322715 MAY, 2008
