LG STB-3000 User manual

OWNER’S MANUAL
SET-TOP BOX
Please read this manual carefully before operating your
product and retain it for future reference.
P/NO : MFL68080318 (1507-REV04)
STB-3000 STB-3500
STB-3501-UA
*mfl68080318* www.lgsolutions.com

2
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
Always comply with the following precautions to avoid dangerous situations and ensure peak
performance of your product.
WARNING/CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR
BACK). NO USER SERVICEABLE PARTS
INSIDE. REFER TO QUALIFIED SERVICE
PERSONNEL.
The lightning flash with arrowhead
symbol, within an equilateral triangle, is
intended to alert the user to the presence
of uninsulated dangerous voltage within the
product’s enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature accompanying
the appliance.
WARNING
- TO REDUCE THE RISK OF FIRE AND
ELECTRIC SHOCK, DO NOT EXPOSE THIS
PRODUCT TO RAIN OR MOISTURE.
CAUTION
- Do not attempt to modify this product in
any way without written authorization from
LG Electronics U.S.A., Inc. Unauthorized
modification could void the user’s authority
to operate this product.
COMPLIANCE
- The responsible party for this product’s
compliance is: LG Electronics U.S.A. Inc.
1000 Sylvan Avenue, Englewood Cliffs, NJ
07632, USA • Phone: [phone]
WARNING: This product contains chemicals
known to the State of California to cause cancer
and birth defects or other reproductive harm.
Wash hands after handling.
WARNING
If you ignore the warning message, you
may be seriously injured or there is a
possibility of accident or death.
CAUTION
If you ignore the caution message, you may
be slightly injured or the product may be
damaged.
NOTE
The note helps you understand and use
the product safely. Please read the note
carefully before using the product.
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with dry cloth.
• Do not block any ventilation openings. Install
in accordance with the manufacturer’s
instructions.
• Do not install near any heat sources, such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
• Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than
the other. A grounding-type plug has two
blades and a third grounding prong. The
wide blade or the third prong are provided
for your safety. If the provided plug does not
fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
• Protect the power cord from being walked on
or pinched, particularly at plugs, convenience
receptacles, and the point where it exits from
the apparatus.
• Only use attachments/accessories specified
by the manufacturer.
• Use only with the cart, stand, tripod, bracket,
or table specified by the manufacturer or sold
with the apparatus. When a cart is used, use
caution when moving the cart/apparatus

3
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
combination in order to avoid injury from
tip-over.
PORTABLE CART WARNING
• Unplug this apparatus during lightning storms
or when unused for long periods of time.
• Refer all servicing to qualified service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does
not operate normally, or has been dropped.
• Never touch this apparatus or antenna during
a thunder or lighting storm.
• When mounting an Set-Top Box on the wall,
make sure not to install the Set-Top Box by
the hanging power and signal cables on the
back of the Set-Top Box.
• Do not allow an impact shock or any objects
to fall into the product.
• Power Cord
Caution: Check the specification page of
this owner’s manual to determine necessary
power requirements for this Set-Top Box.
Periodically examine the cord of your
appliance, and if its appearance indicates
damage or deterioration, unplug it,
discontinue use of the appliance, and have
the cord replaced with an exact replacement
part by an authorized servicer. Protect the
power cord from physical or mechanical
abuse, such as twisting, kinking, or pinching
or being closed in a door or walked upon. Pay
particular attention to plugs, wall outlets, and
the point where the cord exits the appliance.
Do not use a damaged or loose power cord.
Be sure to grasp the plug when unplugging
the power cord. Do not pull on the power
cord to unplug the Set-Top Box.
• Overloading
Do not connect too many appliances to the
same AC power outlet as this could result
in fire or electric shock. Do not overload
wall outlets. Overloaded wall outlets, loose
or damaged wall outlets, extension cords,
frayed power cords, or damaged or cracked
wire insulation are dangerous. Any of these
conditions could result in fire or electric shock.
• Outdoor Use/Wet Location
Warning: To reduce the risk of fire or
electrical shock, do not expose this
product to rain, moisture or other liquids.
Do not touch the Set-Top Box with wet
hands. Do not install this product near
flammable objects such as gasoline or
candles or expose the Set-Top Box to direct
air conditioning.
Do not expose to dripping or splashing and
do not place objects filled with liquids, such
as vases, cups, etc., on or over the apparatus
(e.g., on shelves above the unit).
• Disconnect Device
The mains plug is the disconnecting device.
The plug must remain readily operable.
As long as this unit is connected to the AC
wall outlet, it is not disconnected from the
AC power source even if you turn off this unit
by SWITCH.
• Outdoor Antenna Grounding
If an outside antenna or cable system
is connected to the product, follow the
precautions below.
An outdoor antenna system should not be
located in the vicinity of overhead power
lines or other electric light or power circuits
or where it can come into contact with such
power lines or circuits as death or serious
injury can occur.
Be sure the antenna system is grounded so
as to provide some protection against voltage
surges and built-up static charges.
Article 810 of the National Electrical Code
(NEC) in the U.S.A. provides information
with respect to proper grounding of the
mast and supporting structure, grounding
of the lead-in wire to an antenna-discharge
unit, size of grounding conductors, location
of antenna-discharge unit, connection to
grounding electrodes, and requirements for
the grounding electrode.
Antenna grounding according to the National
Electrical Code, ANSI/NFPA 70
Ground Clamp
Grounding Conductor
(NEC Section 810-21)
Antenna Lead in Wire
Electric Service
Equipment
Antenna Discharge Unit
(NEC Section 810-20)
Ground Clamp Power Service Grounding
Electrode System
(NEC Art 250, Part H)
NEC: National Electrical Code
• Cleaning
When cleaning, unplug the power cord and rub
gently with a soft cloth to prevent scratching.
Do not spray water or other liquids directly on
the Set-Top Box as electric shock may occur.
Do not clean with chemicals such as alcohol,
thinners, or benzene.
• Transporting Product
Make sure the product is turned off and
unplugged and that all cables have been
removed. Do not press against or put stress
on the Set-Top Box.

4
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
• Ventilation
Install the Set-Top Box where there is proper
ventilation. Do not install in a confined
space such as a bookcase. Do not cover the
product with cloth or other materials (e.g.,
plastic) while it is plugged in. Do not install in
excessively dusty places.
• If water or another substance enters the
product (like an AC adapter, power cord, or
TV), disconnect the power cord and contact
the service center immediately. Otherwise,
this may result in fire or electric shock.
• Use only an authorized AC adapter and
powercord approved by LG Electronics.
Otherwise, this may result in fire,
electricshock, malfunction, or product
deformation.
• Never disassemble the AC adapter or power
cord. This may result in fire or electric shock.
• Handle the adapter carefully to avoid dropping
or striking it. An impact could damage the
adapter.
• Do not touch the ventilation openings, as
they may become hot while the Set-Top Box
is operating.
• If you smell smoke or other odors coming
from the Set-Top Box or hear strange sounds,
unplug the power cord and contact an
authorized service center.
• Keep the product away from direct sunlight.
• Keep the packing anti-moisture material or
vinyl packing out of the reach of children.
Anti-moisture material is harmful if swallowed.
If swallowed, force the patient to vomit and
visit the nearest hospital. Additionally, vinyl
packing can cause suffocation. Keep it out of
the reach of children.
• Do not stick metal objects or any other
conductive material into the power cord. Do
not touch the end of the power cord while it
is plugged in.
• Do not expose to dripping or splashing and
do not place objects filled with liquids, such
as vases, cups, etc. on or over the apparatus.
(e.g., on shelves above the unit).
• Grounding
(Except for devices which are not grounded.)
Ensure that you connect the earth ground
wire to prevent possible electric shock
(i.e., a TV with a three-prong grounded AC
plug must be connected to a three-prong
grounded AC outlet). If grounding methods
are not possible, have a qualified electrician
install a separate circuit breaker. Do not try to
ground the unit by connecting it to telephone
wires, lightning rods, or gas pipes.
• As long as this unit is connected to the AC
wall outlet, it is not disconnected from the AC
power source even if the unit is turned off.
• Do not attempt to modify this product in any
way without written authorization from LG
Electronics. Unauthorized modification could
void the user’s authority to operate this product.
FCC NOTICE
(For USA)
This equipment has been tested and found
to comply with the limits for a Class B
digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is
no guarantee that interference will not occur
in a particular installation. If this equipment
does cause harmful interference to radio or
television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by
one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the
equipment and the receiver.
- Connect the equipment to an outlet on a
circuit different from that to which the receiver
is connected.
- Consult the dealer or an experienced radio/TV
technician for help.
This device complies with part 15 of the FCC
Rules.Operation is subject to the following
two conditions: (1) this device may not cause
harmful interference and (2) this device must
accept any interference received, including
interference that may cause undesired
operation of the device.

5
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
Any changes or modifications in construction of
this device which are not expressly approved
by the party responsible for compliance
could void the user’s authority to operate the
equipment.
FCC Radio Frequency Interference
Requirements (for UNII devices)
High power radars are allocated as primary
users of the 5.25 to 5.35 GHz and 5.65 to 5.85
GHz bands. These radar stations can cause
interference with and/or damage this device.
This device cannot be co-located with any other
transmitter.
FCC RF Radiation Exposure Statement
[For having wireless function (WLAN,
Bluetooth,...)]
This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment. This transmitter must not be
colocated or operating in conjunction with any
other antenna or transmitter. This equipment
should be installed and operated with minimum
distance 20 cm (7.8 inches) between the
antenna and your body. Users must follow the
specific operating instructions for satisfying RF
exposure compliance.
Industry Canada Statement
(For Canada)
[For having wireless function (WLAN,
Bluetooth,...)]
This device complies with RSS-210 of the
Industry Canada Rules. Operation is subject to
the following two conditions:
1. this device may not cause interference and
2. this device must accept any interference,
including interference that may cause
undesired operation of the device.
IC Radiation Exposure Statement
(For Canada)
[For having wireless function (WLAN,
Bluetooth,...)]
This equipment complies with IC radiation
exposure limits set forth for an uncontrolled
environment. This equipment should be
installed and operated with minimum distance
20 cm (7.8 inches) between the antenna and
your body.
NOTE: THE MANUFACTURER IS NOT
RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED
MODIFICATIONS TO THIS EQUIPMENT. SUCH
MODIFICATIONS COULD VOID THE USER’S
AUTHORITY TO OPERATE THE EQUIPMENT.
WARNING
(For Canada)
[For product having the wireless function using
5 GHz frequency bands]
• The device for operation in the band
5150–5250 MHz is only for indoor use to
reduce the potential for harmful interference
to co-channel mobile satellite systems;
• The maximum antenna gain permitted for
devices in the bands 5250–5350 MHz and
5470–5725 MHz shall comply with the EIRP
limit; and
• The maximum antenna gain permitted for
devices in the band 5725–5825 MHz shall
comply with the EIRP limits specified for
point-to-point and non point-topoint operation
as appropriate.
• High-power radars are allocated as primary
users (i.e., priority users) of the bands
5250–5350 MHz and 5650–5850 MHz and
that these radars could cause interference
and/or damage to LE-LAN devices.
NOTE TO CABLE/TV INSTALLER
(For USA and Canada)
This reminder is provided to call the CATV
system installer’s attention to Article 820-40 of
the National Electric Code (U.S.A.). The code
provides guidelines for proper grounding and, in
particular, specifies that the cable ground shall
be connected to the grounding system of the
building, as close to the point of the cable entry
as practical.
LG RECYCLING POLICY
(For USA)
LG Electronics offers a customized e-waste
take-back and recycling service that meets local
needs and requirements in the countries where
e-waste regulations are in place, and also
provides product and packaging take-back and
recycling service voluntarily in some countries.
LG Electronics evaluates products’ recyclability
at the design step using LG’s recyclability
evaluation tool, with the goal of improving
recyclability where practicable. Through
these activities, LG seeks to contribute to
conserving natural resources and protecting the
environment.
For more information about the LG Recycling
Policy, please visit our global site at
http://www.lg.com/global/sustainability/
environment/take-back-recycling.

6
ENGLISH
LICENSES / OPEN SOURCE SOFTWARE NOTICE INFORMATION
LICENSES
Supported licenses may differ by model. For more information about licenses, visit www.lg.com.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI
logo are trademarks or registered trademarks of HDMI Licensing LLC in the
United States and other countries.
For DTS patents, see http://patents.dts.com. Manufactured under license from
DTS Licensing Limited. DTS, the Symbol, & DTS and the Symbol together are
registered trademarks, and DTS 2.0+Digital Out is a trademark of DTS, Inc. ©
DTS, Inc. All Rights Reserved.
OPEN SOURCE SOFTWARE NOTICE INFORMATION
To obtain the source code under GPL, LGPL, MPL, and other open source licenses, that is contained in
this product, please visit http://opensource.lge.com. In addition to the source code, all referred license
terms, warranty disclaimers and copyright notices are available for download.
LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of
performing such distribution (such as the cost of media, shipping, and handling) upon email request to
[email protected]. This offer is valid for three (3) years from the date on which you purchased the
product.
•Image shown may differ from your product.
•The available menus and options may differ from the input source or product model that you are
using.
•New features may be added to this product in the future.
NOTE

7
ENGLISH
TABLE OF CONTENTS
2 IMPORTANT SAFETY
INSTRUCTIONS
6 LICENSES
6 OPEN SOURCE SOFTWARE
NOTICE INFORMATION
7 TABLE OF CONTENTS
8 ASSEMBLING AND PREPARING
8 Unpacking
9 Parts and Components
9 - Front Panel
9 - Back Panel
10 How to Use Dual Lock™ (Optional)
12 MAKING CONNECTIONS
12 Connecting to an Antenna or Cable
13 Other Connections
15 MAINTENANCE
15 Cleaning Your Set-Top Box
15 TROUBLESHOOTING
16 SPECIFICATIONS
18 LIMITED WARRANTY
TABLE OF CONTENTS

8
ENGLISH
ASSEMBLING AND PREPARING
ASSEMBLING AND PREPARING
Unpacking
Check your product box for the following items. If there are any missing accessories, contact the local
dealer where you purchased your product. The illustrations in this manual may differ from the actual
product and item.
Set-Top Box Owner’s Manual AC/DC Adapter
HDMI Cable TLM Cable MPI Cable
(For STB-3000) (For STB-3500, STB-3501-UA)
A/ V Adapter Cable Dual Lock™
2 EA
Dual Lock™
4 EA
(For STB-3500, STB-3501-UA) (For STB-3500, STB-3501-UA)
Screw
1 EA, M6 x L18
Spacer
1 EA
• Do not use any unapproved items to ensure the safety and product’s lifespan.
• Any damages or injuries by using unapproved items are not covered by the warranty.
CAUTION

9
ENGLISH
ASSEMBLING AND PREPARING
• The items supplied with your product may vary depending upon the
model.
• Product specifications or contents of this manual may be changed
without prior notice due to upgrade of product functions.
• For an optimal connection, HDMI cables and USB devices should
have bezels less than 10 mm (0.39 inches) thick and 18 mm
(0.7 inches) width.
• When connecting two USB devices at the same time, each one
should have bezels less than 8.5 mm (0.33 inches) thick.
• Use an extension cable that supports USB 2.0 if the USB cable or USB flash drive does not fit into
your TV’s USB port.
• Use a certified cable with the HDMI logo attached. If you do not use a certified HDMI cable, the
screen may not display or a connection error may occur.
• Recommended HDMI cable types (3 m or less)
- High-Speed HDMI®/TM cable
- High-Speed HDMI®/TM cable with Ethernet
NOTE
B
AA
B
*A 10 mm (0.39 inches)
*B 18 mm (0.7 inches)
Parts and Components
Front Panel
MPI/MTI
TELEVISION
CONTROL
EXT MPI
CONTROL
HDMI IN 1 HDMI IN 2 USB IN 1 USB IN 2
Power Indicator
Back Panel
HDMI OUT LAN DIGITAL
AUDIO
AV IN
IR IN
POWER
ANTENNA/
CABLE IN
AUDIO
LINE OUT SERVICE
RS-232C
TELEVISION
CONTROL
TV-LINK
CFG
(For STB-3500)

10
ENGLISH
ASSEMBLING AND PREPARING
How to Use Dual Lock™ (Optional)
(Image shown may differ from your product.)
Fix the Set-Top Box to the TV and use it when you want to.
(For STB-3000)
1After removing the protection paper from the Dual Lock™, stick it to the TV and the Set-Top Box as
shown.
Dual Lock™
2Attach the Set-Top Box to the TV by pressing the Dual Lock™together.
• Be sure the product surface is clean, and then firmly attach the Dual Lock™.
• Before attaching the Set-Top Box to the TV, let the attached Dual Lock™dry for at least three days.
NOTE

11
ENGLISH
ASSEMBLING AND PREPARING
(For STB-3500, STB-3501-UA)
1Attach the Dual Lock™in pairs first. Press firmly the whole part of Dual Lock™to ensure firm
fastening of the protruding parts with each other.
2After removing the protection paper from the one side of Dual Lock™, stick them to the back of Set-
Top Box as shown.
Dual Lock™
3After removing the protection paper from the spacer, stick it to a VESA screw hole on the back of
the TV. (However, you can choose the location to attach the spacer randomly by considering the
shape of the rear side of the TV and the attachment location of the Set-Top Box.)
or
Spacer
4After removing the protection paper from the Dual Lock™, stick Set-Top Box to the TV. Insert and
tighten the screw on the hole with the spacer attached. (When tightening the screws, be sure not
to over tighten them to avoid deformation of the spacer.)
M6 x L18
1 EA
or
• Do not mount by Dual lock™only without screw.
• If Set-Top Box is not a perfect fit on the rear side of your TV, please place and use it on a flat surface.
• Do not fasten the screw with excessive force.
• Be sure the product surface is clean, and then firmly attach the Dual Lock™.
• Before attaching the Set-Top Box to the TV, let the attached Dual Lock™dry for at least three days.
NOTE

12
ENGLISH
MAKING CONNECTIONS
MAKING CONNECTIONS
• Image shown may differ from your product.
You can connect various external devices to the product. Supported external devices are: HD receivers,
DVD players, VCRs, audio systems, USB storage devices, PC, gaming devices, and other external
devices. For more information on external device’s connection, refer to the manual provided with each
device.
• If you record a TV program on a DVD recorder or VCR, make sure to connect the TV signal input
cable to the Set-Top Box through a DVD recorder or VCR. For more information about recording,
refer to the manual provided with the connected device.
• The external device connections shown may differ slightly from illustrations in this manual.
• Connect external devices to the Set-Top Box regardless about the order of the Set-Top Box port.
• If you connect a gaming device to the Set-Top Box, use the cable supplied with the gaming device.
• Refer to the external equipment’s manual for operating instructions.
• Using a DVI to HDMI cable may cause compatibility issues.
NOTE
Connecting to an Antenna or Cable
Connect an antenna, cable, or cable box to watch TV. The illustrations may differ from the actual items
and an RF cable is optional.
VHF Antenna
UHF Antenna
Coaxial (75Ω)
(*Not provided)
Antenna
Terminal
• Use a signal splitter to use 2 Set-Top Boxes
or more.
• DTV Audio Supported Codec: MPEG, Dolby
Digital
NOTE
• Make sure not to bend the copper wire of
the RF cable.
Copper wire
• Complete all connections between devices,
and then connect the power cord to the
power outlet to prevent damage to your
Set-Top Box.
CAUTION

13
ENGLISH
MAKING CONNECTIONS
Other Connections
Connect your Set-Top Box to external devices. For the best picture and audio quality, connect digital
devices using an HDMI cable.
• Image shown may differ from your product.
• A separate cable is not provided.
• Do not connect your headphones or earphones to the port for connecting an external speaker.
NOTE
Front
USB IN 2
USB IN 1
EXT MPI
IN 2
MPI/MTI
TELEVISION
HDMI OUT
MPI
MPI
DVI OUT AUDIO OUT
IN 1
CONTROL CONTROL
SI Box
USB
Blu-Ray / HD Cable Box / HD STB / DVD / PC
TV Speaker

14
ENGLISH
MAKING CONNECTIONS
Back
OUT
DIGITAL
AUDIO
AUDIO
LINE OUT AV IN SERVICE
IR IN
POWER LAN
TELEVISION
CONTROL ANTENNA/
CABLE IN
ETHERNET
DIGITAL
AUDIO IN
SPEAKER
IN
HDMI IN
RS-232C IN
VIDEO RAUDIOL/MONO
DVI IN
TV-LINK
CFG
RS-232C
LEFT
GND
RIGHT
TV / Monitor
Digital Audio System Speaker
Power Outlet
TV
Blu-Ray / HD Cable Box
/ DVD / VCR
Yellow
White
Red
Yellow
White
Red
Yellow
White
Red
(For STB-3500)
• Audio Line Out Jack should be connected with SE (Single Ended) mode 3-pin type audio cable.
Use only with the 3 Pole 3.5 mm Stereo Jack.
NOTE

15
ENGLISH
MAINTENANCE / TROUBLESHOOTING
MAINTENANCE
Cleaning Your Set-Top Box
Clean your Set-Top Box regularly to keep it at peak performance and to extend the product’s lifespan.
To remove dust or light dirt, wipe the surface with a dry, clean, and soft cloth.
To remove major dirt, wipe the surface with a soft cloth dampened in clean water or a diluted mild
detergent. Then wipe immediately with a dry cloth.
Remove the accumulated dust or dirt on the AC/DC adapter regularly.
• Before cleaning, turn the power off and disconnect the power cord and all other cables.
• When the Set-Top Box is left unattended or unused for a long time, disconnect the AC/DC adapter
from the wall outlet to prevent possible damage from lightning or power surges.
• Do not push, rub, or hit the surface with your fingernail or a sharp object, as this may result in
scratches on the product cover.
• Do not use any chemicals, such as waxes, benzene, alcohol, thinners, insecticides, air fresheners, or
lubricants, as these may damage the product’s finish and cause discoloration.
• Do not spray liquid onto the surface. If water enters the Set-Top Box, it may result in fire, electric
shock, or malfunction.
CAUTION
TROUBLESHOOTING
The software may be updated for improvement in performance. The customer is responsible to ensure
the compatibility of their equipment with any LG Electronics software. If needed, please consult LG
Electronics and update new software versions according to the guidance provided by LG Electronics.
Problem Solution
Cannot control the
Set-Top Box with the
remote control.
• Check if anything such as tape has been placed over the receiver.
• Check if there is any obstacle between the product and the remote
control.
• Replace the batteries with new fresh ones.
Set-Top Box does not
output any video or audio.
• Check if the product is turned on.
• Check if the power cord is connected to a wall outlet.
• Check if there is a problem in the wall outlet by connecting other
products.
Set-Top Box turns off
suddenly.
• Check the power control settings. The power supply may be interrupted.
• Check if the auto off feature is activated in the Time settings.
When connecting to
the PC (HDMI/ DVI), No
signal or Invalid Format is
displayed.
• Turn the Set-Top Box off/on using the remote control.
• Reconnect the HDMI/DVI cable.
• Restart the PC with the Set-Top Box on.

16
ENGLISH
SPECIFICATIONS
SPECIFICATIONS
Product specifications may be changed without prior notice due to upgrade of product functions.
Television System ATSC, NTSC-M, 64 & 256 QAM
Program Coverage VHF 2-13, UHF 14-69, DTV 2-69, CATV 1-135, CADTV 1-135
External Antenna Impedance 75 Ω
Environment
condition
Operating Temperature 0 °C to 40 °C (32 °F to 104 °F)
Operating Humidity Less than 80 %
Storage Temperature -20 °C to 60 °C (-4 °F to 140 °F)
Storage Humidity Less than 85 %
MODELS STB-3000
Dimensions (W x H x D) 221 x 28.5 x 175.2 (mm)
8.7 x 1.1 x 6.8 (inches)
Weight 0.55 kg (1.2 lbs)
Power requirement 19 V 2.1 A
AC/DC Adapter Manufacturer : Lien Chang
Model : LCAP16B
MODELS STB-3500 STB-3501-UA
Dimensions (W x H x D) 357 x 36 x 201 (mm)
14 x 1.4 x 7.9 (inches)
Weight 1.12 kg (2.4 lbs)
Power requirement 19 V 2.1 A
AC/DC Adapter Manufacturer : Lien Chang
Model : LCAP16B
Wireless module (LGSBW41) Specifications
Wireless LAN Bluetooth
Standard IEEE 802.11a/b/g/n Standard Bluetooth Version 3.0
Frequency range
2400 to 2483.5 MHz
5150 to 5250 MHz
5725 to 5850 MHz
Frequency range 2400 to 2483.5 MHz
Output power
(Max.)
802.11a: 11.5 dBm
802.11b: 11 dBm
802.11g: 10.5 dBm
802.11n - 2.4 GHz: 11 dBm
802.11n - 5 GHz: 12.5 dBm
Output power
(Max.) 10 dBm or Lower
• Because the band channel used by the country could be different, the user can not change or adjust
the operating frequency. This product is set for the regional frequency table.
• This device should be installed and operated with minimum distance 20 cm (7.8 inches) between
the device and your body. This phrase is for the general statement for consideration of user
environment.
• Contains FCC ID BEJLGSBW41
• Contains IC 2703H-LGSBW41

17
ENGLISH
SPECIFICATIONS
HDMI (PC) supported mode
(For HDMI IN 1 and HDMI IN 2)
Resolution Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
640 x 350 31.468 70.09
720 x 400 31.469 70.08
640 x 480 31.469 59.94
800 x 600 37.879 60.31
1024 x 768 48.363 60.00
1152 x 864 54.348 60.053
1360 x 768 47.712 60.015
1280 x 1024 63.981 60.02
1920 x 1080 67.50 60.00
HDMI (DTV) supported mode
(For HDMI IN 1 and HDMI IN 2)
Resolution Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
640 x 480p 31.469 59.94
31.5 60
720 x 480p 31.469 59.94
31.50 60.00
1280 x 720p 44.96 59.94
45.00 60.00
1920 x 1080i 33.72 59.94
33.75 60.00
1920 x 1080p
26.97 23.976
27.00 24.00
33.716 29.976
33.75 30.00
67.43 59.94
67.50 60.00

18
ENGLISH
LIMITED WARRANTY
LIMITED WARRANTY
WHAT THIS LIMITED WARRANTY COVERS:
Your LG HD Commercial Interface Set-Top-Box (“Product”) will be repaired or replaced, at LG’s option,
if it proves to be defective in material or workmanship under normal and manufacturer suggested use
during the Limited Warranty period (“Warranty Period”) listed below, effective from the date of original
purchase or delivery (“Purchase Date””) of the Product, whichever is later. This Limited Warranty is
exclusively for the benefit of the original purchaser (“Purchaser” or “You”) and cannot be transferred
or assigned, and is valid only when purchased and used within the U.S.A., Puerto Rico, and any U.S.
territories.
LIMITED WARRANTY PERIOD:
Parts and labor: Two (2) years from the original Purchase Date or Delivery, whichever occurs later.
Note:
1. Replacement Product and repair part(s) may be new, reconditioned, refurbished, or otherwise
factory remanufactured and any replacement Product or part(s) is warranted for the remaining portion
of the original Warranty Period or for ninety (90) days, whichever is greater.
2. Replaced Product or part(s) under this Limited Warranty will become the property of LG.
HOW TO OBTAIN WARRANTY SERVICE & ADDITIONAL INFORMATION:
Please call 1-888-865-3026 between 8:00 AM to 6:00 PM, Central Standard Time, Monday through
Friday, excluding holidays, or visit our website at www.lgecommercial.com, or mail to LG Electronics
B2B Commercial Display SVC team, P.O. Box 240007, 201 James Record Road, Huntsville, Alabama
35813.
Please have Product model number, serial number, dealer’s dated bill of sale or delivery ticket available
as evidence of Purchase Date for proof of warranty.
HOW WARRANTY SERVICE IS HANDLED:
To obtain warranty service, please contact LG for troubleshooting or to obtain information on service
procedures. You will be informed of the details of obtaining service which may include delivery of
the Product, inbound and outbound freight paid by LG, in either its original packaging or packaging
affording an equal degree of protection, to LG or an LG authorized service center. LG does not
warrant or guarantee that there will be no risk or loss of program data during Product repair or
replacement. Under some circumstances, you may be asked to provide credit card information for
advanced shipment or cost of unreturned loaner product. To ensure proper credit and avoid any
unnecessary charges, you must obtain Return Authorization before returning Product to LG or an LG
authorized service center.
LIMITATION OF WARRANTY SCOPE:
EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OR
CONDITION OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THE
PRODUCT IS LIMITED IN DURATION TO THE EXPRESS WARRANTY PERIOD ABOVE. NEITHER
MANUFACTURER NOR ITS U.S. DISTRIBUTOR SHALL BE LIABLE FOR ANY INDIRECT,
STATUTORY, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES INCLUDING, WITHOUT
LIMITATION, LOSS OF GOODWILL, LOST REVENUES OR PROFITS, WORK STOPPAGE,
PRODUCT FAILURE, IMPAIRMENT OF OTHER GOODS, COSTS OF INSTALLATION, REMOVAL
OR REINSTALLATION OF THE PRODUCT, LOSS OF USE, INJURY TO PERSONS OR PROPERTY
ARISING OUT OF OR RELATED TO THE PRODUCT. LG’S TOTAL LIABILITY, IF ANY, DAMAGES
OR OTHERWISE, SHALL NOT EXCEED THE INVOICE VALUE PAID BY THE PURCHASER FOR THE
PRODUCT OR SERVICE(S) FURNISHED, WHICH IS THE SUBJECT OF A CLAIM OR DISPUTE.
SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, OR ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY
LASTS, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO PRUCHASER. THIS
LIMITED WARRANTY GIVES THE PURCHASER SPECIFIC LEGAL RIGHTS; PRUCHASER MAY ALSO
HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE.

19
ENGLISH
LIMITED WARRANTY
THIS LIMITED WARRANTY DOES NOT APPLY TO:
The cost of repair or replacement of Products under the circumstances listed below shall be borne by
the Purchaser.
• Damage to or failure of Product caused in shipping or transit;
• Service required as a result of improper installation or reinstallation, including incorrect or insufficient
AC supply (please consult the Owner’s Manual for power supply requirements);
• Cost of set up or adjustment of the Product or damage caused by improper adjustments;
• Damage or failure caused by other system components or by connecting the Product to external
devices;
• Product that has been modified or incorporated into any other product;
• Installation or repair of antenna systems, cable converters, equipment supplied by the cable
company, or other components in any other video system;
• Operation failure caused by issues with reception resulting from inadequate home antenna or faulty
antenna connections, or computer software.
• Operation of the Product in abnormal conditions or in an environment where the temperature or
humidity is not within the acceptable range as specified in the Owner’s Manual;
• Damage or loss to software programs, data, or removable storage media;
• Minor imperfections within design specifications that do not materially alter or affect functionality;
• Damage (including cosmetic damage), deterioration, malfunction, loss or personal injury due to
misuse, abuse, negligence, improper maintenance or storage, or to acts of nature or other causes
beyond LG’s control (Causes beyond LG’s control include, but are not limited to, lightning strike,
power surges, power outages, or water damage.);
• Damage or failure caused by service performed by someone other than an LG technician or an LG
authorized service technician;
• Product purchased or used outside the U.S.A., Puerto Rico, and other U.S. territories;
• Product where the original factory serial numbers have been removed, defaced, or changed in any
way;
• Product sold and labeled as “AS IS”, “WITH ALL FAULTS” or similar disclaimer, including
replacement of missing parts or accessories, or purchased through an unauthorized online seller;
• Consumable parts or accessories such as remote control, fuses, and batteries; or
• Use of the Product contrary to the instructions outlined in the Owner’s Manual.

The model and serial numbers of the product
are located on the back and on one side of the
product. Record them below should you ever
need service.
MODEL
SERIAL
LG Customer Information Center
For inquires or comments, visit www.lg.com or call;
1-888-865-3026 USA, Commercial User
1-888-542-2623 CANADA
Declaration of Conformity
Trade Name: LG
Model:STB-3000, STB-3500,
STB-3501-UA
Responsible Party: LG Electronics Inc.
Address: 1000 Sylvan Ave.
Englewood Cliffs NJ 07632
U.S.A
TEL: [phone]
